Full Color Laser Projector
Version 2023-12

RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-2-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
Legal Notice
LaserAnimation Sollinger GmbH reserves the right to make changes to its products for the purpose of
technical improvement. These changes are not necessarily documented in each specic case. This document
and the information contained herein have been prepared with the utmost care. No responsibility can be
taken for the unlikely case of printing or other errors and any resulting damage.This device is a show laser
device for commercial use.This device is not a laser pointer and it must not be used for pointing purposes.
No part of this manual may be reproduced or transmitted in any form or by any means, electronic or me-
chanical, including photocopying, recording, or information storage and retrieval systems, for any purpose
other than for the purchaser‘ s personal use, without written permission.The brands and product names
mentioned in this manual are trademarks or registered trademarks of their respective owners. Information
in this document is subject to change without notice and does not represent a commitment on the part of
the manufacturer LaserAnimation Sollinger GmbH. No part of this manual may be reproduced or transmit-
ted in any form or by any means,electronic or mechanical, including photocopying, recording, or information
storage and retrieval systems, for any purpose other than for the purchaser‘ s personal use, without written
permission.

ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-3-
Contents
1 Contents of Package ...................................4
2 Safety Hints ..........................................5
2.1 General Hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2.2 Hints for Laser Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3 Connectivity and Physical Features ......................10
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2 Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2.1 Mains Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2.2 Connection Signal Source via ILDA. . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2.2 AVB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4 Installation and Commissioning .........................15
4.1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1.3 Hints for Application of the integrated Beam Blocker . . . . . . . . . . . 16
4.2 Commission. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5 Control.............................................18
5.1 LA.toolbox. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2 ShowNET*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6 Maintenance Hints....................................19
7 Malfunction .........................................20
8 Pin Assignments......................................21
8.1 ILDA in, ILDA out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8.2 Remote Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
8.3 DMX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
9 Technical Specifications ................................24
Final statement........................................26
EU Declaration of Conformity............................27
Technical Drawing - RTI PIKO Housing .....................28

RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-4-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
1 Contents of Package
Please make sure that all components were delivered correctly. Please also compare the separately
supplied packing list If something is missing, please contact your sales contact.
Name No. Picture
Laser projector 1
ABS ight case 1
powerCON TRUE1 / power cable 1
Interlock bridge 1
Set of keys 1
Manual 1
The unit is carefully packed before shipping. If you discover damages to the device or the packing
material due to improper transporta-tion, please inform the shipping company and return the
device to the supplier preferably in its original packing.

ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-5-
2 Safety Hints
2.1 General Hints
1. The laser projector is intended only for proper use for projecting laser beams onto a projection
surface (walls, screens) or into space indoors or outdoors.
2. The device may not be used when there is visible damage to the housing, the connectors in the
rear, especially the electric power supply, or the connecting cables.
3. The installation should be performed by specially trained personnel.The projector should not
be connected to the mains during installation. Please note the local safety regulations!
4. For operation of the laser unit at truss or on ceiling, the projector must be additionally secured
by a safety cable.This cable must be appropriately designed according to the weight of the laser
projector.The relevant accident prevention regulations of the professional associations must be
observed.
5. If the provided mains cable does not correspond with your existing mains supply please use an
appropriate adapter for mains connection. Do not use any electronically controlled sockets, e.g.
no dimmer or radio sockets, for mains connection of the laser projector.
6. The laser unit has to be used according to this manual. LaserAnimation Sollinger GmbH does not
assume liability for damages caused by non-observation of this manual.
7. Before starting any maintenance or cleaning remove the unit from the power supply!
8. In case of malfunctions please contact your dealer and after consultation send the device
back for inspection and repair in its original packing. Do not open the device!
Attention: Warranty is rendered void if the device is misused, damaged, modied in any
way, or for unauthorized repairs or parts.
9. The laser device is intended for use in a dry and suciently ventilated location.
When used outdoors the device has to be protected against humidity, overheating
and excessively low temperatures. Note the respective maximum and minimum ambi-
ent temperatures for operation specied in the technical details.

RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-6-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
10. When operating the device in humid or special outdoor conditions that can lead to con-
densation:
a. Allow the device to acclimatize suciently at the place of use.
b. Use LA.toolbox to check the internal temperature of the unit and the dew
point.
c. Do not operate the device if the dew point is > 20°C, as condensation can
occur on the cooler components.
d. Do not switch the device o between operating times, simply activate
interlock / E-stop to disable laser emission or set the laser projector state to
Standby (refer to LA.toolbox main tabs). This prevents the unit from cooling
down, as all temperature control loops remain active.
11. The laser unit may not be operated in environments polluted with sand, dust or acrid
fumes or gases.
Fog machines must not be operated in the immediate vicinity of the laser projector. Do
not point the fog nozzle directly at the laser projector.
12. Do not expose the laser unit to direct sunlight or other intensive light sources e.g. spot-
light.

ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-7-
2.2 Hints for Laser Safety
Caution – use of controls, adjustments or performance of procedures other than those
specied herein may result in hazardous radiation exposure.
This laser product is designated as Class 4 during all procedures of operation, maintenance
and service.
The local safety regulations for the application of Class 4 laser products must be observed!
1. Eye Protection
• Never look directly into the laser beam!
A laser beam is coherent, monochromatic light with very high energy.A laser beam
retains its intensity even over very long distances. If a laser beam hits the human eye
it can lead to irreparable damages to the cornea, the conjunctiva, the eye lens and
the retina.Avoid any reections back into the laser to prevent damages to the
laser system. Do not place any objects into the laser beam because even diffusely
reected radiation can cause eye damages.
Therefore remove any rings, watches or the like before you carry out work on the
device and use only non-reective tools.
• We strictly recommend wearing laser protective glasses for laser devices according to
laser class 4.
2. Fire Protection
• The high energy density of the laser beam causes painful burns when it hits human skin.
The beam may also burn holes into textiles.
Therefore never reach into the laser beam and do not let other parts of the body get
in the way of the laser beam.
• If the laser beam hits easily ammable materials such as paper, these will ignite and a re
can develop very quickly.
Therefore make sure that no ammable material is in the way of the beam before
activating the laser.
3. Audience Protection
• The operation of laser systems with Class 4 lasers requires an emergency stop (E-Stop).
Regardless of the way the laser is operated, an E-Stop must always be connected!
Place the E-Stop so that you can reach it immediately in emergency situations. Run a test
each time the laser is activated to ensure that it is turned off immediately by activating the
E-Stop.
• Mark an area of about 3 to 4 m around the laser system as off limits to the audience.
• Only test the laser system as long as no audience is present.

RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-8-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
• Never let the laser run unattended.
• Make sure that no unauthorized persons have access to your laser system.
The operation of laser equipment in the event sector with an audience requires an approval
by a technical inspection authority in many countries!
The following warning labels are placed on the laser device:
Pλ450 max XX W*
Pλ520 max XX W*
Pλ638 max XX W*
per output
VISIBLE AND INVISIBLE LASER RADIATION
AVOID EYE OR SKIN EXPOSURE
TO DIRECT OR SCATTERED RADIATION
CLASS 4 LASER PRODUCT
EN 60825-1:2014
On the bottom:
Next to emission laser window: On the top cover:
*depending on model

ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-9-
1
2
3
4
5
8
6
7
1. Laser radiation! Avoid exposure to beam
2. Laser class 4
3. Caution of radiation if cover is removed
4. Model type
5. Production year
6. Output power
7. Wavelength
8. Power supply & consumption

RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
3 Connectivity and Physical Features
3.1 Overview
All included signal cables are shielded. In case you use other cables (e.g. for remote control,
Interlock, external key switch) it is essential to use shielded cables only.
Made in Germany
Laser Radiation is emitted from this Aperture
PIKO
Emission Laser on
RTI PIKO back panel RTI PIKO back panel
1. Loop for safety cord
2. ShowNET / FB4 interface
3. ILDA thru: 25pin D-sub female for daisy chaining to other projector
4. ILDA in: 25pin D-sub male to connect an ILDA compliant signal source
5. LAN RJ-45 for Ethernet network (LAS software / AVB) connection
6. LAN RJ-45 for Ethernet network (ShowNET) connection
7. LAN RJ-45 for Ethernet network (ShowNET) connection
8. DMX in: 5pin XLR male
9. DMX thru: 5pin XLR female
10. Interlock: 7pin XLR for connection of
- emergency stop (E stop) (separately available)
- included Interlock plug (to close the interlock loop for testing purposes only)
11. Universal input: 86 VAC – 264VAC, 47 – 63 Hz
12. Fuse T 10A
13. Emission & status LEDs
14. Key switch
1. Laser aperture
2. Beam blocker mechanism
3. Emission LED
1
2
3
1
12 1413 11
1098765
4
3
2
RTI PIKO front panel RTI PIKO front panel
-10-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved

ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-11-
3.2 Connectivity
3.2.1 Mains Connection
The projector can be operated with supply voltages of 86VAC – 264 VAC / 47 – 63 Hz.
Note: If the provided mains cable does not correspond with your existing mains supply please use an
appropriate adapter for mains connection.
The highly-efcient power supply allows discharging external and internal disturbances via
the protective conductor (PE). Internal lters are ineffective without protective conductor
(PE). Operation without grounded protective conductor (PE) can cause damage to the com-
ponents of the power supply. For this we cannot provide any warranty!
3.2.2 Connection Signal Source via ILDA
Be sure to use fully connected 25 wire 1:1 shielded cables only!
All significant ILDA signals are true differential inputs i.e. each signal line must have its “inverted
signal” counterpart!
At the signal source “inverted signal” lines may be tied together and connected to GND. For rea-
sons of best noise suppression also in this case a fully connected 25 wire cable should be used!
Connect your projector to the 25pin ILDA output of a laser show controller, e.g. Lasergraph DSP
or another controller with an ILDA compliant output using a DSub25pin ILDA cable.

RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-12-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
3.2.2 AVB
Your projector can be controlled via AVB (Audio Video Briding) by means of an external AVB
stream.
To control your PIKO using AVB, please make sure that you exclusively use the “LAN 1” port of
your projector as LAN 2 and LAN 3 are internally routed towards ShowNET or FB4.
Using AVB will also require an AVB compliant network infrastructure (AVB compliant switch and
USB2AVB interface). For further information about AVB control, please refer to our LA.toolbox
user manual and/or tutorials.
3.2.4 Remote Connection
Different connections are possible:
1. Emergency Stop Switch (Interlock loop) with or without key switch
An external emergency (E-stop) button can be connected to the projector using the 7-pin remote
connector on the rear side of the device.
If you have special requirements for E-stops, you can connect them to the projector using this port.
An external IP-based E-stop (LAS Disable button) will distribute its heartbeat over network broad-
cast and doesn’t need to be connected to the laser directly.

ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-13-
• The operation of laser systems with lasers class 4 requires an emergency stop (E-Stop). Regardless of
the way the laser is operated, an E-Stop must always be connected.
• Place the E-Stop so that you can reach it immediately in emergency situations.
• Run a test each time the laser is activated to ensure that it is turned off immediately by activating the
E-Stop.
• After activating the E-Stop (opening the interlock loop) your device is blocked from any laser emis-
sion.
• To return to normal mode you have to reset the E-stop (will close the interlock loop again) and then
turn the key switch to “OFF” position and then to “ON” position again.This interlock latch process
will reactivate laser emission.
2. Interlock Plug
The included interlock plug is mandatory for closing the interlock loop.Always insert the interlock plug to
enable laser emission. If you’re using an external LAS disable button, you also need to connect the inter-
lock plug to the unit. :
3.2.5 DMX
The DMX In and Outputs are only available for ShowNET or FB4 control.
The applied DMX signal at “DMX in” is still available for transmission to other DMX devices at
“DMX thru”.
Note:
Please note that “DMX in” is not terminated with 120 Ohm.This needs to be done externally (most
easily using a terminating connector on “DMX thru”).

RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-14-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
For the connection between the laser projector and the DMX console, please use a DMXCable Type EIA
RS-485, Shielded,Twisted Pair
3.2.6 LAN
The laser unit can be integrated into an Ethernet network using the LAN ports on the rear side of
the unit.
The main control interface of the laser projector is accessible using the LA.toolbox software,
available for both PC or Mac.
Use “LAN 1” port for this purpose.Access to laser projector mainboard is not possible via LAN 2 or
LAN 3.
The laser projector output can be also controlled with different types of software using the
integrated
ShowNET card (or FB4 if applicable). Use either “LAN 2” or “LAN 3” for this purpose. Both ports
are connected on an internal network switch.
If you’re not using AVB for control, you can link LAN 1 with LAN 2 using a small network patch cable
and control the whole laser projector (mainboard functionalities and ShowNET or FB4) through
“LAN 3” port.
If you’re using AVB, connect your LAN cable to port “LAN 1” and access to the mainboard
functionalities and AVB receiver.

ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-15-
4 Installation and Commissioning
4.1 Installation
4.1.1 Hanging Operation
The laser projector is equipped with an extra stable stainless steel yoke for hanging operation (truss
or tripod). For mounting you will need minimum one C-clamp (not included).
Make sure that the projector is adequately secured by an additional steel cable during han-
ging operation.The manufacturer does not assume responsibility for damage to persons or
to property due to faulty attachment!
4.1.2 Standing Operation
Attention! The air is supplied by the fans on the right side of the projector. Do not block the
fans on the right side !
Place the laser unit in upright position on a stable platform and make sure that the position is sufciently
ventilated. Do not place the laser unit sideways and do not block the side panels.

RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-16-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
4.1.3 Hints for Application of the integrated Beam Blocker
A beam block panel is integrated into the front panel for safety reasons.This convenient cover can be
used to blank the laser output in order to protect the audience in a certain area.
1. Loosen silver screw by turning anticlockwise.
2. While holding the silver screw, slide it up and down until the beam blocking plate is in the desired posi-
tion.
3. Tighten the silver screw by turning clockwise.
1

ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-17-
4.2 Commission
4.2.1 Power On
The device is not equipped with a power switch.The power supply should only be performed by
connecting respectively disconnecting the laser projector to or from the mains.
1. Connect the included power cable to the mains input of your device: Pull the slider, insert the connector
and turn it clockwise until the connector is locked.
2. Connect the device to a power outlet. If mains power is available the fans will start.
3. For power off the projector turn the connector counterclockwise and disconnect it from the mains
input “Power”.
Note:
The powerCON TRUE1 connector can be connected or disconnected under load!
4.2.2 Laser On
Never look into the laser outlet window while turning the laser on! Ensure that no
individuals or highly ammable objects are situated in the line of the laser beam.
1. Ensure that the beam block panel in front of the laser outlet window is opened.
2. Make sure that the Interlock loop is closed.
3. Insert the key and activate the laser by turning the key to the ON position.
4. The laser can be switched off immediately by turning the key switch to the OFF position.

RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-18-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
5 Control
5.1 LA.toolbox
The RTI PIKO operating modes and main settings can be congured easily using the „LA.toolbox“
software.This intuitive software allows to monitor important functions of the laser unit and adjust
operating parameters.
The LA.toolbox communicates with the laser projector via LAN 1 port.The software offers PC
installation for Windows 7/8.1/10/11 operating systems. Mac version for installation on an Apple Macintosh
running macOS 13 (Ventura) or newer.
Both PC and Mac versions of LA.toolbox are included on the USB memory stick, along with a detailed
LA.toolbox manual.The software and manual are also available for download from our website:
https://laseranimation.com/en/downloads/
To install LA.toolbox, simply follow the instructions in the manual. For additional information, please
consult the LA.toolbox manual.
5.2 ShowNET*
ShowNet is a versatile laser controller with a broad set of functionalities, including that of a digital-analog-
converter for the use with laser show software. It converts a digital network signal to an analog laser
control signal.
The manual is available for download from this website:
https://www.laser-interface.com/en/user-manual/shownet-display-panel.html
*depending on model

ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-19-
6 Maintenance Hints
Ensure the laser is turned off and the device is disconnected from the mains before
conducting any maintenance.
Please ensure that the fans of the projector are checked regularly.
Depending on the operating environment, large amounts of dirt may accumulate on the fans over time,
which must be removed to ensure trouble-free operation.
It is recommended that you also periodically inspect the air inlets and outlets on both sides.
Make sure to remove any dust between the ribs with a brush, a vacuum cleaner, or an oil-free compressed
air cleaner.
To clean the device’s housing, use a soft uff-free cloth and a mild detergent.
Avoid touching the laser outlet window and always use the protector to close it after operation.
The window may become fogged during operation (fog machines, outdoor operation, etc.).
A contaminated window can lower the laser output power and affect the beam quality. It is
recommended to clean the laser outlet window regularly using isopropyl alcohol (for ngerprints) and/or
acetone and lens paper.
Be careful during cleaning and do not touch the cleaning surface of the lens paper with your ngers.
Isopropyl alcohol and Acetone are dangerous substances, so please adhere to the corresponding safety
measures.
-19-

RTI PIKO SERIES USER‘S MANUAL
Edited: 2023-12
-20-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone [phone] | Fax [phone]
Email [email protected] | www.laseranimation.com
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
7 Malfunction
Check the mains connection!
In case of a malfunction, rst check the mains connection and the mains cable. If needed, change the
power cable.
Additionally, check the device fuse as it may be faulty. Replacing the fuse is easy - remove the fuse holder
next to the power connector using a screwdriver and replace the defective fuse by a new one with
identical values:T 10A.
1 Fuse Holder
If any other malfunctions occur, kindly return the device to your dealer for inspection and repair in its
original packaging.
The status LED on the rear side of the device indicates the momentary operating status of the device.
Green blinking sequences signalizes normal operation, red ones an error state:
Blinking Sequence Meaning
Alternate red \green blinking The laser is in ‘Adjusting’ mode, temperatures have not reached their target values yet.
Green constantly on The laser is in ‘Run’ or ‘Test10%’ mode. ILDA signal is present for laser emission, laser
emission can follow.
Green blinking 1 time The device is in the “Shutdown” mode.
Green blinking 2 times Interlock loop is open.
Green blinking 3 times Key switch is not closed.
Green fast blinking emission
LED is off
Laser is in the ‘Standby’ mode, interlock and key switch are closed.
Green fast blinking emission
LED is constantly on
Laser is in the automatic ‘Standby’ or ‘Shutdown’ mode.This occurs if the laser in the ‘Run’
mode but no ILDA signal has been present for more than some seconds (adjustable).
The laser switches back to ‘Run’ immediately when the ILDA signal comes back.
A lot of heat dissipation can be saved in this mode.Your projector stays cooler especially in
higher ambient temperatures.The power of the fans will be reduced -> less noise.
Red blinking Warning! The temperature sensor for the heat sink or the RTC (Real Time Clock) is failing.
However, the laser can still be operated.
Red constantly on Error!
1. If ‘Run’ or ‘Test’ modes are no longer possible a system error has occurred.
2. If ‘Run’ and ‘Test’ modes are still possible, it means that one or more laser disable
drivers have signalized an error.
1
