RTI NEO Series User manual
USER‘S MANUAL
RTI NEO SERIES
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
Full Color Laser Projector
Version 2023-07
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-2-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
Information juridique
LaserAnimation Sollinger GmbH se réserve le droit d‘apporter des modications à ses produits à des ns
d‘amélioration technique. Ces modications ne sont pas nécessairement documentées dans chaque cas
spécique. Ce document et les informations qu‘il contient ont été préparés avec le plus grand soin. Aucune
responsabilité ne peut être prise dans le cas improbable d‘erreurs d‘impression ou autres et de tout dom-
mage qui en résulterait. Cet appareil est un projecteur laser destiné à un usage commercial. Cet appareil
n‘est pas un pointeur laser, il ne convient pas pour le pointage et ne doit pas être utilisé à cette n. Aucune
partie de ce manuel ne peut être reproduite ou transmise sous quelque forme ou par quelque moyen que
ce soit, électronique ou mécanique, y compris la photocopie, l‘enregistrement ou les systèmes de stockage
et de récupération de l‘information, à des ns autres que l‘usage personnel de l‘acheteur, sans autorisation
écrite. Les marques et les noms de produits mentionnés dans ce manuel sont des marques commerciales
ou des marques déposées de leurs propriétaires respectifs. Les informations contenues dans ce document
peuvent être modiées sans préavis et ne constituent pas un engagement de la part du fabricant LaserAni-
mation Sollinger GmbH.
Aucune partie de ce manuel ne peut être reproduite ou transmise sous quelque forme ou par quelque
moyen que ce soit, électronique ou mécanique, y compris la photocopie, l‘enregistrement ou les systèmes
de stockage et de récupération de l‘information, à des ns autres que l‘usage personnel de l‘acheteur, sans
autorisation écrite.
En cas de doutes, veuillez toujours contacter LaserAnimation Sollinger GmbH . Les noms de marques et
de produits utilisés dans ce mode d’emploi sont des marques de fabrique ou des marques déposées.
L’utilisation est réservée à un usage professionnel selon décret n°2007-665 du 2 mai 2007 re-
latif à la sécurité des appareils à laser sortant!
Article 4 bis :
« Les usages spéciques autorisés pour les appareils à laser sortant d’une classe supérieure à 2 sont les
usages professionnels suivants : (…)
9° Spectacle et afchage :
Toutes les applications de trajectoire, de visualisation, de projection ou de reproduction d’images en deux
ou trois dimensions. »
Legal Notice
LaserAnimation Sollinger GmbH reserves the right to make changes to its products for the purpose of
technical improvement. These changes are not necessarily documented in each specic case. This document
and the information contained herein have been prepared with the utmost care. No responsibility can be
taken for the unlikely case of printing or other errors and any resulting damage.This device is a show laser
device for commercial use.This device is not a laser pointer and it must not be used for pointing purposes.
No part of this manual may be reproduced or transmitted in any form or by any means, electronic or me-
chanical, including photocopying, recording, or information storage and retrieval systems, for any purpose
other than for the purchaser‘ s personal use, without written permission.The brands and product names
mentioned in this manual are trademarks or registered trademarks of their respective owners. Information
in this document is subject to change without notice and does not represent a commitment on the part of
the manufacturer LaserAnimation Sollinger GmbH. No part of this manual may be reproduced or transmit-
ted in any form or by any means,electronic or mechanical, including photocopying, recording,or information
storage and retrieval systems, for any purpose other than for the purchaser‘ s personal use, without written
permission.
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
-3-
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
-3-
Contents
1 Contents of Package ...................................4
2 Safety Hints ..........................................5
2.1 General Hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2.2 Hints for Laser Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3 Device Connectors ...................................10
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Operation...........................................11
4.1 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.2 DMX in / DMX out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.3 Interlock (RJ45 Interlock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.4 Key Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.5 Fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.6 Display / Settings at the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
RTI NEO 6............................................16
RTI NEO 12...........................................17
5 Technical Specifications ................................18
Final statement........................................19
EU Declaration of Conformity............................20
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-4-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
1 Contents of Package
Please make sure that all components were delivered correctly. Please also compare the separately
supplied packing list If something is missing, please contact your sales contact.
Name No. Picture
Laser projector 1
powerCON TRUE1 / power cable 1
Interlock bridge 1
Set of keys 1
Manual 1
The unit is carefully packed before shipping.
If you discover damages to the device or the packing material due to improper transporta-
tion, please inform the shipping company and return the device to the supplier preferably in its
original packing.
-5-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-5-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
2 Safety Hints
2.1 General Hints
1. The laser projector is intended only for proper use for projecting laser beams onto a projection
surface (walls, screens) or into space indoors or outdoors.
2. The device may not be used when there is visible damage to the housing, the connectors in the
rear, especially the electric power supply, or the connecting cables.
3. The installation should be performed by specially trained personnel.The projector should not
be connected to the mains during installation. Please note the local safety regulations!
4. For operation of the laser unit at truss or on ceiling, the projector must be additionally secured
by a safety cable.This cable must be appropriately designed according to the weight of the laser
projector.The relevant accident prevention regulations of the professional associations must be
observed.
5. If the provided mains cable does not correspond with your existing mains supply please use an
appropriate adapter for mains connection. Do not use any electronically controlled sockets, e.g.
no dimmer or radio sockets, for mains connection of the laser projector.
6. The laser unit has to be used according to this manual. LaserAnimation Sollinger GmbH does not
assume liability for damages caused by non-observation of this manual.
7. Before starting any maintenance or cleaning remove the unit from the power supply!
8. In case of malfunctions please contact your dealer and after consultation send the device
back for inspection and repair in its original packing. Do not open the device!
Attention: Warranty is rendered void if the device is misused, damaged, modied in any
way, or for unauthorized repairs or parts.
9. The laser device is intended for use in a dry and suciently ventilated location.
When used outdoors the device has to be protected against humidity, overheating
and excessively low temperatures. Note the respective maximum and minimum ambi-
ent temperatures for operation specied in the technical details.
10. When operating the device in humid or special outdoor conditions that can lead to con-
densation:
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-6-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
a. Allow the device to acclimatize suciently at the place of use.
b. Do not operate the device if the dew point is > 18°C, as condensation can
occur on the cooler components.
c. Do not switch the device o between operating times, simply activate
interlock / E-stop to disable laser emission. This prevents the unit from
cooling down, as all temperature control loops remain active.
11. The laser unit may not be operated in environments polluted with sand, dust or acrid
fumes or gases.
Fog machines must not be operated in the immediate vicinity of the laser projector. Do
not point the fog nozzle directly at the laser projector.
12. Do not expose the laser unit to direct sunlight or other intensive light sources e.g. spot-
light.
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-7-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
2.2 Hints for Laser Safety
Caution – use of controls, adjustments or performance of procedures other than those
specied herein may result in hazardous radiation exposure.
This laser product is designated as Class 4 during all procedures of operation, maintenance
and service.
The local safety regulations for the application of Class 4 laser products must be observed!
1. Eye Protection
• Never look directly into the laser beam!
A laser beam is coherent, monochromatic light with very high energy.A laser beam
retains its intensity even over very long distances. If a laser beam hits the human eye
it can lead to irreparable damages to the cornea, the conjunctiva, the eye lens and
the retina.Avoid any reections back into the laser to prevent damages to the
laser system. Do not place any objects into the laser beam because even diffusely
reected radiation can cause eye damages.
Therefore remove any rings, watches or the like before you carry out work on the
device and use only non-reective tools.
• We strictly recommend wearing laser protective glasses for laser devices according to
laser class 4.
2. Fire Protection
• The high energy density of the laser beam causes painful burns when it hits human skin.
The beam may also burn holes into textiles.
Therefore never reach into the laser beam and do not let other parts of the body get
in the way of the laser beam.
• If the laser beam hits easily ammable materials such as paper, these will ignite and a re
can develop very quickly.
Therefore make sure that no ammable material is in the way of the beam before
activating the laser.
3. Audience Protection
• The operation of laser systems with class 4 lasers requires an emergency stop (E-Stop).
Regardless of the way the laser is operated, an E-Stop must always be connected!
Place the E-Stop so that you can reach it immediately in emergency situations. Run a test
each time the laser is activated to ensure that it is turned off immediately by activating the
E-Stop.
• Mark an area of about 3 to 4 m around the laser system as off limits to the audience.
• Only test the laser system as long as no audience is present.
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-8-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
• Never let the laser run unattended.
• Make sure that no unauthorized persons have access to your laser system.
The operation of laser equipment in the event sector with an audience requires an approval
by a technical inspection authority in many countries!
The following warning labels are placed on the laser device:
Pλ450 max 0,9 W
Pλ520 max 0.5 W
Pλ638 max 0.6 W
per output
VISIBLE AND INVISIBLE LASER RADIATION
AVOID EYE OR SKIN EXPOSURE
TO DIRECT OR SCATTERED RADIATION
CLASS 4 LASER PRODUCT
EN 60825-1:2014
On the bottom:
Next to emission laser window: On the top cover:
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-9-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
1
2
3
4
5
8
6
7
1. Laser radiation! Avoid exposure to beam
2. Laser class 4
3. Caution of radiation if cover is removed
4. Model type
5. Production year
6. Output power
7. Wavelength
8. Power supply & consumption
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-10-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
3 Device Connectors
3.1 Overview
All included signal cables are shielded. In case you use other cables (e.g. for remote control,
Interlock, external key switch) it is essential to use shielded cables only.
Laser apertures
Emission LED
Beam Block Panel
RTI NEO 6
RTI NEO 12
Key switch
Key switch
Display &
setting buttons
Fuse, 2.5AT
Fuse, 2.5AT
Power supply
in / out
RJ45 for
Interlock
out / in
DMX out / in &
LED for Interlock
status
DMX out / in &
LED for Interlock
status
Serial number
Loops for safety cord
Loops for safety cord
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-11-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
4 Operation
4.1 Power
Power in
Make sure that your device is provided with the correct voltage.Wrong voltage could lead to irreparable
damages. Please nd the correct voltage data in the synoptical table at the end of this manual as well as at
the rear side of the device. It must be ensured that the device is not directed to people or inammable
objects during installation.
Connect the powerCON TRUE1 / power cable to the mains input ‚Power in‘ at the device: Pull the slider,
insert the connector and turn it clockwise until the connector is locked. After that, connect the power
cable to a power outlet.
4.2 DMX in / DMX out
DMX out / in
The device can be controlled via DMX.There are a ‚DMX in‘ (DMX input) and a ‚DMX out‘ (DMX
through) interface on the rear side of the device. Connect ‚DMX in‘ via a DMX cable to a DMX controller.
‚DMX out‘ is intended to Daisy Chain the control signal to the ‚DMX in‘ interface of a further RTI NEO
device.The device offers 60 channels, starting from the selected start address. Each universe can control a
maximum of 8 devices and each of the 6 outputs can be controlled individually. Each output of the device
uses 10 channels as shown here:
Channel Value Effect Comment
1 Red 0 - 255 Red: 0 - 100%
2 Green 0 - 255 Green: 0 - 100%
3 Blue 0 - 255 Blue: 0 - 100 %
4 Pan Coarse 0 - 255 Pan MSB
5 Pan Fine 0 - 255 Pan LSB
6 Tilt Coarse 0 - 255 Tilt MSB
7 Tilt Fine 0 - 255 Tilt LSB
8 Off / Dot / Gobo 0 Blackout Safety channel
1 - 10 Dot
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-12-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
11 - 20 Rectangle
21 - 30 Triangle
31 - 40 Line horizontal
41 - 50 Line vertical
51 - 60 2 dots horizontal
61 - 70 2 dots vertical
71 - 80 3 dots horizontal
81 - 90 3 dots vertical
91 - 100 Circle
101 - 110 4 quarter circle
111 - 120 Test picture
121 - 130 Rectangle with
grating
131 - 140 Triangle with
grating
141 - 150 Line horizontal
with grating
151 - 160 Line vertical with
grating
161 - 170 2 dots horizontal
with grating
171 - 180 2 dots vertical
with grating
181 - 190 3 dots horizontal
with grating
191 - 200 3 dots vertical
with grating
201 - 210 Circle with grating
211 - 220 4 quarter circle
with grating
221 - 230 Test picture with
grating
231 - 240 1 dot with grating
241 - 255 Blackout
9 Zoom 0 - 255 Gobo size active, if value of channel 8 between
11 and 110
10 Strobe 0 Stobe off Strobe effect
1 - 127 Strobe speed 2Hz - 12Hz
128 - 255 Grow effect 256 points - 0 points
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-13-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
4.3 Interlock (RJ45 Interlock)
Interlock in
There are a ‚Interlock in‘ and a ‚Interlock out‘ (Interlock loop) interface on the rear side of the
device.The RJ45 interlock bridge is provided for testing purposes. During normal operation, a
dedicated E-Stop with key switch has to be used. If the ‚Interlock in‘ is plugged in the laser sources
of the devices get enabled (if key switch is in ‚ON‘ position). Always use the Interlock connector
located on the left of the ‚active‘ LED as an input. ‚Interlock out‘ can be used as Interlock loop to
switch all connected devices simultaneously with only one E-Stop.
4.4 Key Switch
There is a key switch on the rear side of the device. Please insert the key into the key switch and
turn it to ‚Laser on‘ position to enable laser output.Turn the key to ‚Laser off‘ to switch off laser
emission. Please remove the key to avoid unauthorized access.
4.5 Fuse
There is a fuse at the rear side of the device. If the fuse should blow, please change it by a new
2.5AT fuse. If the problems recurs, please contact your dealer.
4.6 Display / Settings at the Device
It is possible to do settings directly at the device by means of the integrated 16 digit display and
the 5 buttons next to it.The arrow buttons (up/down) navigate you through the menu.
The + / - buttons change the value of the selected mode and the button in the middle changes the
channel (1-6).
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-14-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
By switching on the device for the very rst time, DMX:1 appears on the display:
Press the down button (arrow down) and change the DMX address by using the + /- buttons:
By pressing the down button (arrow down) again the mode can be changed by using the + / - buttons.
In‚normal‘ mode the device is in the hanging position or inverted as a oor stand:
In‚invert‘ mode the X and Y axis are inverted and the output channels are changed to the inverted order
6 to 1. So the output channel 1 is always on the left side from the front direction of the device if this
option is chosen:
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-15-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
Beam Block Panel
The Beam Block Panel is meant as additional protection to prevent laser emission, e.g. into the audi-
tion area. To prevent laser emission please loosen the screws and slide the panel in front of the beam
outlets. Fasten the screws again. Loosen the screws, slide the Beam Block Panel down and fasten the
screws to enable laser emission.
Attention: Do not open or close the Beam Block Panel while the device emits laser beams!
Turn o
To turn o the device, switch the key switch to o and disconnect the power cable from the mains.
Important:
Before transporting the laser device, remove both the key and the Interlock connector to prevent
damage.
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-16-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
Laser Radiation is emitted from this Aperture Laser Radiation is emitted from this Aperture Laser Radiation is emitted from this Aperture Laser Radiation is emitted from this Aperture Laser Radiation is emitted from this ApertureEmission Laseron Laser Radiation is emitted from this Aperture
Display
Laser Systems
active
DMX ou t in
Fuse 2.5AT
slow blow
INT ERLO CK
out in
6: GND
7:+5V
8:Interlock
Pow er thru
not fused
Po wer in
110Vac - 265 Vac , 50- 60Hz
Laser off
Laser on
Display
Laser Systems
Serial No.
RTI NEO 6
Technical Drawing
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
-17-
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
-17-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
RTI NEO 12
Technical Drawing
Laser Radiation is emitted from this Aperture Laser Radiation is emitted from this Aperture Laser Radiation is emitted from this Aperture Laser Radiation is emitted from this Aperture Laser Radiation is emitted from this ApertureEmission Laseron Laser Radiation is emitted from this Aperture
Display
Laser Systems
Display
Laser Systems
Serial No.
off
on
active
Fuse 2.5AT
slow blow
INT ERLO CK
out in
6: GND
7:+5V
8:Interlock
Pow er thru
not fused
Po wer in
110Vac - 265 Vac , 50- 60Hz
DMX ou t in
-18-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
5 Technical Specifications
Laser
Laser Source Diode (red / green / blue)
Type CW analog modulated, laser class 4
Typical wavelengths 638 nm 520 nm 450 nm
Scanner 45kpps ILDA 8°
Scan angle max. 45°
Operation mode DMX
Power supply 85 VAC – 264 VAC, 50 - 60 Hz, universal
Operationg temperature +10°C - +30°C
IP raded IP5X
Device-dependent laser specifications
RTI NEO 6
Total power 1800 mW
Power per color
at aperture
6 x 135 mW
(Red)
6 x 70 mW
(Green)
6 x 95 mW
(Blue)
Beam divergence*0.5 mrad*
Beam diameter 3 mm
Power consumption 360 W
Dimensions (L x W x H) 997.5 x 154 x 142.5 mm (open beam block panel, w/o bracket)
Weight (net) 8 kg
RTI NEO 12
Total power 12000 mW
Power per color
at aperture
6 x 600 mW
(Red)
6 x 500 mW
(Green)
6 x 900 mW
(Blue)
Beam divergence*0.9 mrad*
Beam diameter 5 mm
Power consumption 500 W
Dimensions (L x W x H) 997.5 x 168 x 142,5 mm (open beam block panel, w/o bracket)
Weight (net) 17.5 kg
*FWHM average depending on model
RTI NEO SERIES USER‘S MANUAL
Edited: 2023-07
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
-19-
RTI NEO SERIES
USER‘S MANUAL
Edited: 2023-07
-19-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
Final statement
All our products and their packaging are individually checked and leave our facilities in a awless and
proper condition. If you notice any damage or defects when receiving the product, please contact your
dealer immediately. Damages caused by improper handling are not subject to the manufacturer’s or
dealer’s responsibility and no liability or warranty is assumed for it.The operator of the device must follow
the local safety regulations and the warnings in the manual. If changes are made to this manual, we cannot
inform you. Please contact your dealer for service and any other questions. Only use original spare parts.
Subject to change without notice. No warranty can be given for the correctness of the information.
LaserAnimation Sollinger GmbH
Crellestr. 19/20
10827 Berlin
Germany
Place of Business: Berlin, Germany | Registry Court:Amtsgericht Charlottenburg, HRB 45888 | Managing
Director: Martin Werner | VAT-ID: DE154202159
E-Mail: [email protected]
Internet: www.laseranimation.com
-20-
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
ISO 9001:2015
certified
LaserAnimation Sollinger GmbH | Crellestr. 19/20 | D-10827 Berlin
Phone +49 (30) 780 963 00 | Fax +49 (30) 780 963 25
Copyright © LaserAnimation Sollinger GmbH. All rights reserved
EU Declaration of Conformity
Manufacturer:
LaserAnimation Sollinger GmbH
Product Name:
RTI NEO 6
RTI NEO 12
Products covered by this declaration: Laser display systems
We here declare that the product described above is in conformity with the following directives:
—2014/35/EU LowVoltage Directive
—2014/30/EU Electromagnetic Compatibility Directive
—2014/53/EU Directive for harmonisation of the laws of the Member States relating to the making
available on the market of radio equipment
The following harmonized standards have been applied:
—DIN EN 61000-6-1 VDE 0839-6-1:2007-10
Electromagnetic compatibility (EMC)
Part 6-1: Generic standards - Immunity for residential, commercial and light-industrial environments
—DIN EN 61000-6-2 VDE 0839-6-2:2006-03
Electromagnetic compatibility (EMC)
Part 6-2: Generic standards - Immunity for industrial environments
—DIN EN 61000-6-3 VDE 0839-6-3:2011-09
Electromagnetic compatibility (EMC)
Part 6-3: Generic standards – Emission standard for residential, commercial and light-industrial environ-
ments
—DIN EN 61000-6-4 VDE 0839-6-4:2011-09
Electromagnetic compatibility (EMC)
Part 6-4: Generic standards – Emission standard industrial environments
—DIN EN 60825-1 VDE 0837-1:2015-07
Safety of laser products
Part 1: Equipment classication and requirements
—DIN EN 55032:2016-02 VDE 0878-32:2016-02
Electromagnetic compatibility of multimedia equipment - Emission Requirements
The included technical documents (les) demonstrate that the product has been produced according to the require-
ments of the abovementioned directives.
The EU declaration of conformity is available for inspection by the market surveillance authorities at any
time.
Berlin, 28.03.2023 Martin Werner
This manual suits for next models
2
Table of contents
Other RTI Projector manuals
