RTS Digital Matrix Intercom RVON-8 User manual

RVON-8
RTS Voice Over Network
9350-7756-000 Rev M June 2006

PROPRIETARY NOTICE
The product information and design disclosed herein were originated by
and are the property of Telex Communications, Inc. Telex reserves all
patent, proprietary design, manufacturing, reproduction, use and sales
rights thereto, and to any article disclosed therein, except to the extent
rights are expressly granted to others.
COPYRIGHT NOTICE
Copyright 2006 by Telex Communications, Inc. All rights reserved.
Reproduction, in whole or in part, without prior written permission from
Telex is prohibited.
WARRANTY NOTICE
See the enclosed warranty card for further details.
CUSTOMER SUPPORT
Technical questions should be directed to:
Customer Service Department
RTS/Telex Communications, Inc.
12000 Portland Avenue South
Burnsville, MN 55337 USA
Telephone: [phone]
Fax: [phone]
Factory Service: 800-553-5992
RETURN SHIPPING INSTRUCTIONS
Customer Service Department
Telex Communications, Inc. (Lincoln, NE)
Telephone: [phone]
Fax: [phone]
Factory Service: 800-553-5992
Please include a note in the box which supplies the company name,
address, phone number, a person to contact regarding the repair, the type
and quantity of equipment, a description of the problem and the serial
number(s).
SHIPPING TO THE MANUFACTURER
All shipments of product should be made via UPS Ground, prepaid (you
may request from Factory Service a different shipment method). Any
shipment upgrades will be paid by the customer. The equipment should
be shipped in the original packing carton. If the original carton is not
available, use any suitable container that is rigid and of adequate size. If
a substitute container is used, the equipment should be wrapped in paper
and surrounded with at least four (4) inches of excelsior or similar
shock-absorbing material. All shipments must be sent to the following
address and must include the Proof of Purchase for warranty repair.
Upon completion of any repair the equipment will be returned via
United Parcel Service or specified shipper, collect.
Factory Service Department
Telex Communications, Inc.
8601 East Cornhusker Hwy.
Lincoln, NE 68507 U.S.A.
Attn.: Service
This package should include the following:
Qty Item Part Number
1 RVON-8 Front Card Final
Assembly
9020-7756-000
1 RVON-8 User Manual 9350-7756-000
1 Warranty Statement 38110-387

Table
of
Contents
Chapter 1
Introduction ..................................................................................................................................................... 1
Description of the RVON-8 Voice Over Network Card ................................................................................. 1
Features ........................................................................................................................................................... 2
Specifications .................................................................................................................................................. 2
Chapter 2
Installation ...................................................................................................................................................... 3
Installation of the RVON-8 Card into the ADAM System ............................................................................. 3
Color Key Code .............................................................................................................................................. 3
Addresses and the RVON-8 Card ................................................................................................................... 4
Switches and Connections 4
Configuring the RVON-8 Card with AZedit .................................................................................................. 5
RVON-8 Connection Status Screen ................................................................................................................ 8
Download RVON-8 Firmware through AZedit ............................................................................................ 14
RVON-8 Backcard ........................................................................................................................................ 16
Appendix A
Basic Network Configuration ....................................................................................................................... 21
Basic Network Configuration ....................................................................................................................... 21
LAN (local area network) vs. WAN (wide area network) ............................................................................ 21
LOCAL AREA NETWORK ........................................................................................................................ 21
WIDE AREA NETWORK ........................................................................................................................... 22
ACCESSING THE WIDE AREA NETWORK (WAN) .............................................................................. 23
NETWORK ADDRESS TRANSLATION (NAT) ...................................................................................... 23
PORTS .......................................................................................................................................................... 23
IP ADDRESSES ........................................................................................................................................... 25
Ping a Computer ........................................................................................................................................... 26
POSSIBLE PITFALL WITH ROUTERS, GATEWAYS, AND SWITCHES ............................................ 26
RVON Configuration .................................................................................................................................... 27
Network Terminology ................................................................................................................................... 28
Appendix B
RVON-8 Card Serial Port Programming ...................................................................................................... 31
RVON Serial and Telnet Commands Setup ................................................................................................. 31
RVON-8 Command Table ............................................................................................................................ 35
RVON-8 Default Setup ................................................................................................................................. 36

1
CHAPTER 1
Introduction
Description of the RVON-8 Voice Over Network Card
Installed directly into the ADAM Intercom frame, the RVON-8 provides voice over IP (Internet Protocol) communications for
the RTS®ADAM intercom family. In general, voice over IP means sending voice information in digital form using discrete
packets rather than the traditional telephone network. The RVON-8 delivers an integrated solution for connecting custom key-
panels to the Intercom Matrix over standard IP networks by supporting 8 channels (ports) of audio IN and OUT.
The RVON-8 card supports all standard, hot-swappable and configurable features through Telex’s AZedit configuration
software as well as support for remote keypanels and virtual keypanels via VOIP (voice over IP).
RVON-8 support Telex®Intelligent Trunking over IP. Trunking is a method of using relatively few audio paths for a large
number of potential users. Because it is flexible, a trunked system can expand along with your business, to accommodate a
growing number of users. RTS’ Intelligent Trunking is a proven technology, which provides the same capabilities and ease of
use for intercoms - seamless routing and path finding of communications between facilities regardless of distance - as does the
long distance telephone system for phone calls.
RVON-8 is fully compatible with internationally recognized standards and supports the following protocols: G.711, G.729AB,
and G.723 (2 speeds).

Introduction
2
Features
Specifications
DIGITAL
NOTE: The Playout Delay and Bandwidth depend on the configured amount of audio per packet.
CONNECTIONS
RJ-45 Ethernet via backcard
DB-9 Serial Port via backcard
High-Density keyed ADAM Compatible Backplane Connector
Power.........................................................................................................................................12.5w / 2.5 A at 5V
Physical .................................................................................................................................5.687” W x 11.024” L
Installation The RVON-8 card is hot-swappable and installs in any available slot in an ADAM
Intercom System. It provides a single RJ-45 Ethernet connection for use with a 10
BASE-T or 100 BASE-TX network. It also has a DB-9 connection for an RS-232 or
RS-485 pass-thru port.
8 Channels of Audio IN and OUT Expands the connectivity of the ADAM intercom by supporting 8 channels (ports) IN
and OUT. Each channel has configurable network and bandwidth parameters that can
tailored to individual network functions, as well as ancillary data for keypanels and
trunking control.
Ethernet Compatible Fully Ethernet capable. The RVON-8 card uses standard Ethernet protocols and is
compatible with 10 BASE-T or 100 BASE-TX Ethernet compliant devices and
networks.
AZedit Configurations Users have the ability to adjust the audio parameters of each RVON-8 channel to
optimize the available bandwidth on the network.
Trunk Capable The RVON-8 card supports ancillary data control for use with Telex®Intelligent
Trunking.
Addressing Eight individually addressable audio channels. The RVON-8 card can feed
simultaneously VOIP (voice over internet protocol) capable keypanels as well as
various other matrix intercom systems.
Pass-Through Serial Port Provides a virtual serial connection via an IP connection. Which, if used while
trunking, may eliminate the need for multiple IP resources.
COMPRESSION BIT RATE CODING DELAY PLAYOUT DELAY BANDWIDTH
G.711 64 K 125 μs 20-60 ms 160-224kbps
G728AB 8 K 10 ms 20-120 ms 32-112kbps
G.723 5.3 K / 6.3 K 30 ms 60-120 ms 29-45 kbps
*Data Rate Depends on Codec Selection

3
CHAPTER 2
Installation
Installation of the RVON-8 Card into the ADAM System
When inserting the RVON-8 card into the ADAM system, the following considerations need to be made:
•Gently insert the RVON-8 card into the correct slot. If the card is forced or twisted while inserting, a pin on the backplane
could short or break causing the card to become inoperable.
•When inserting the RVON-8 card into the ADAM system, make sure to insert it into a compatible backcard. If the card is
inserted into a incompatible backcard, undesirable results can occur.
NOTE: All cards are now shipped with a colored coding key in the middle of the connector. For more information, see “Color
Key Code” on page 3.
Color Key Code
On the RVON-8 card, Telex has provided a color key code and knock-outs for digits 1-8 to ensure a compatible connection
between cards. The RVON-8 card color is blue, and will only insert into a blue coded backcard.
NOTE: Only newer systems have the color coded backcards.
FIGURE 1. RVON-8 Color Key Code. This Key Code only allows the RVON-8 to plug into an RVON8 compatible
backcard.
Table 1. Key Code Colors for all ADAM Intercom Cards
CARD KEY CODE COLOR
AES-3 (7745) Yellow
RVON-8 (7763) Blue

Installation
4
NOTE: The RVON-8 connector is mechanically offset from the standard AIO-8 cards. DO NOT FORCE MATING THE
CARDS.
Addresses and the RVON-8 Card
Because the RVON-8 has an Ethernet interface, it is required to have a MAC (Media Access Control) address. This is a low
level address that contains 48 bits. Do not confuse this address with an IP (Internet Protocol) Address. In order to be IP com-
pliant, all cards must have a unique MAC ID when shipped from the manufacturer. Typically, the MAC ID of a piece of hard-
ware, such as the RVON-8 card, has a fixed or static address. Whereas, the RVON-8 card’s IP Address can change over time.
The MAC Address uniquely identifies each node of a network and interfaces directly with the network media. The RVON-8
card has a small 8-pin serial device on the board that the processor can read the unique MAC Address from. For more
information on MAC IDs, contact technical support.
Switches and Connections
IMPORTANT: You must remove the card from the frame in order to change any DIP switch settings.
DIP Switches
AIO-8 (7510) Orange
Master Controller Green
MCII-e System Controller Violet
Table 1. Key Code Colors for all ADAM Intercom Cards
CARD KEY CODE COLOR

5
Configuring the RVON-8 Card with AZedit
Configuring the RVON-8 Card with AZedit
Once the RVON-8 card is inserted into the Intercom, AZedit will automatically recognize the card.
NOTE: Requires intercom firmware and AZedit software that supports RVON cards.
DIP Switch 1 Closed: Configuration via AZedit is disabled
Open: (Default) Configuration via AZedit is enabled.
Description: Disables configuration changes via AZedit. AZedit will still be able to view the
card configuration and connection status. The configuration can still be changed
via the serial and Telnet connections.
DIP Switches 2&3 Unused - Keep in Open position.
DIP Switch 4 Closed: When enabled, the card is prevented from resetting after 30 seconds of
no communications with the system controller.
Open: When disabled, the card resets after 30 seconds of no communication
with the system controller.
Description: Allows pass-through serial data to continue when the intercom is otherwise
down (i.e., upgrades). Mainly used to keep trunking connections open when
disruptions in communications on the card occur.
DIP Switch 5 Closed: Resets the Telnet username and password to their default values:
User = telex
Password = password
Open: (Default) Uses current username and password
Description: Enables the user to reset the Telnet Username and Password.
DIP Switch 6 Closed: Enables a serial monitor on the backcard DB9 (J2).
Open: (Default) Enables a pass-through serial port via the backcard DB9 (J2)
Description: Selects DB9 (J2) serial configuration.
DIP Switch 7 Closed: Runs the Boot Download
Open: (Default) Runs the native flash program.
Description: Switches to the boot download flash program. This program is sent with the
RVON-8 card in case the native flash program becomes corrupt.
DIP Switch 8 DEBUG ONLY!
WARNING: DIP Switch 8 should always be left in the OFF position. It is
reserved for debugging and can have unintended consequences.
FIGURE 2. RVON-8 DIP Switch panel

Installation
6
To Configure the RVON-8 card, do the following:
1. From the Status menu, select I/O Cards.
The IO Card Status screen appears showing the types of installed cards.
2. Right -click on an RVON-8 card, and select RVON-8 Configuration.
The RVON-8 Configuration screen appears.
3. From the RVON-8 drop down list, select the slot in which the RVON-8 card resides, if it is not already selected.
4. In the IP Address field, enter the IP Address you have assign to the RVON-8 card.
5. In the Network Mask field, enter the Network Mask of the network to which the RVON-8 card is connected.
6. In the Default Gateway field, enter the Default Gateway Address (if applicable) of the network to which the RVON-8
card is connected.
A Default Gateway is only required if the RVON-8 connections are between LANs.
Under Settings for Pass-Through Serial via Ethernet
7. In the Target IP Addr field, enter the target IP Address of the device you want to connect to over Ethernet.
8. From the Serial Baud Rate drop down list, select the baud rate at which the data is transmitted.
Under Settings for Connected Devices
NOTE: You MUST configure the channel settings on each end of a connection and ensure the same codec and packet size are
selected at each end. Remember, the RVON-8 card has different channels which can be configured.

7
Configuring the RVON-8 Card with AZedit
9. In the RVON-8 Channel drop down list, select the channel you want to use to communicate to another device across the
network.
10. In the Device IP Addr: field, enter the IP Address of the device to which you want to connect.
11. From the Device Type drop down list, select the type of device to which the RVON-8 card is connecting.
12. From the Device Channel drop down list, select the channel on the device to which the RVON-8 card will communicate.
13. From the CODEC Type drop down list, select the CODEC type you want to use for this channel.
14. From the Packet Size drop down list, select the size of each audio packet.
NOTE: A CODEC is an algorithm used to compress audio. There are 5 Codices supported by Telex: G.711 μs law, G.711A
law, G.729AB, G.723 (5.3k), and G.723 (6.3k). The type of CODEC will dictate the quality of audio you hear and the network
bandwidth used. The packet size determines how much audio data is carried across the network in each transmitted packet.
The CODEC type and packet size chosen require different amounts of bandwidth from the network (see “Specifications” on
page 2). As with the CODEC type, the packet size you choose for the audio transfer will affect the audio you hear and the
bandwidth you use over the network. The larger the audio packet you choose to use, the lower the bandwidth used. However,
the larger packet size can result in a higher delay and longer gaps if the packet is lost. On the other hand, smaller packet sizes
result in larger bandwidth use, but lower delays and smaller gaps if the packet is lost. The Intercom System Engineer and the
Network Administrator may want to work together in choosing the CODEC type and packet size suitable for the size of the
network, so degradation of network resources does not happen.
15. Select Enable VAD (Voice Activity Detection), if you want to conserve bandwidth when the audio level is below a given
threshold.
NOTE: Voice Activity Detection saves network bandwidth by stopping the flow of audio packets when silence is detected.
VAD is similar to VOX.
At this point you may choose another channel to configure or choose another card to configure.
16. Once you are completely finished, click Apply.
Apply sends all of the changes to all the cards in the intercom, or click Cancel to discard all changes you make.

Installation
8
RVON-8 Connection Status Screen
The RVON-8 connection status screens display information pertaining to RVON-8 channel connection. You can only show
statistics for one channel on a card at a time.
NOTE: To view the RVON-8 Connection Status screens make sure both AZedit and the RVON-8 card are on the same
Ethernet network. The reason this is important is because the statistics are updated once per second. At this rate of dynamic
update, a serial port could not pass this much data effectively.
To get to the RVON Connection Status screen, do the following:
1. From the Status menu, select I/O Cards.
The IO Card Status screen appears showing the types of installed cards.
2. Right-click the card with which you want to work.
A context menu appears.
3. Select RVON Connection Status.
The RVON Connections screen appears. The Connection screen contains five pages of information about the selected
channel and are described in detail on the following pages.

9
RVON-8 Connection Status Screen
Screen Item Description
Select Local Card and Channel
RVON-8 Card The card for which you want to view the status.
From the RVON-8 drop down list, select the card you want to view.
IP Address Displays the IP (Internet Protocol) Address of the card you select.
Local Channel
One of eight audio channels supported by the RVON-8 card.
From the Channel drop down list, select the channel for which you want to view
the status.
Remote Connection Information
Device Type Displays the type of device the RVON-8 card is connected to on the other end of
the channel.
IP Address Displays the IP Address of the device connected at the other end of the channel.
Remote Channel Displays the channels at the other end of the connection that the device is using.

Installation
10
SCREEN ITEM DESCRIPTION
Attempts / Drops
The number of times a call attempt has been made and dropped.
NOTE: The number of attempts should always be one greater than the
number of drops.
Current Call State The state of the connection. There are two connection states: Connected or
Idle.
Origination / Termination
Displays which end of the connection originated or terminated the call.
Local: RVON-8 card
Remote: device at the other end of the connection.
Release Reason Displays why the connection was terminated, for example, congestion,
network error, local release, remote release.
Connection Duration Displays the duration of the connection. This is shown in hh/mm/ss.
Compression Algorithm Displays what type of configuration the connection is using. This can be
different than the original configuration if both ends the channel are not
configured the same. If the configuration is different, these fields will be in
red.
Audio Packet Size
Voice Activity Detect (VAD)

11
RVON-8 Connection Status Screen
SCREEN
ITEM DESCRIPTION
VOIP Playout Statistics
Playout Buffer
Size
Displays how much audio can be received from the network before packets are lost. This is four times
bigger than configured packet size. This is a static system setting.
Nominal
Playout Delay
Displays how much audio is collected before playout begins. Playout begins at half the Playout Buffer
Size, which is two times the configured packet size. This is a static system setting.
Average
Playout Delay
Displays the actual average audio collected before packets are played out. This is measured over the
length of the connection.
Vo i c e P l a y o u t
Buffer
Underrun
Displays the number of packet times that packets were not played because the Playout Buffer was empty.
NOTE: If VAD is enabled, there will be playout buffer runs because there are no packets being received
during silence.
Vo i c e P l a y o u t
Buffer Overrun Displays the number of packets that were discarded because the Playout Buffer was full.
Missing
Sequence
Packet
Displays how many audio packets were missed in the sequence.
Replayed
Packets Displays how many audio packets were replayed.
Average Frame
Jitter Displays the measure of consistency of packet arrival times. Lower jitter is better.

Installation
12
SCREEN ITEM DESCRIPTION
Network Statistics
Voice Playout Packets
(Tx/Rx) Displays the number of voice packets transmitted and received from the other side of the connection.
DTMF Relay Packets
(Tx/Rx)
Displays the number of DTMF (dual tone multiple frequency) relay packets transmitted and received.
DTMF relay packets are a bandwidth and quality saving feature within the
RVON-8 card.
Silence Detections
Packets (Tx/Rx)
Displays the number of times a silence detection packet has been sent or received. VAD (voice activity
detection) must be enabled.
Silence Suppressed
Packets (Tx) Displays the number of packets never sent because the packets contained silence.
Packet Interarrival Time
(Min/Max) Displays the minimum and maximum time elapsed between packets being sent.
Recent Bandwidth Use
(Tx/Rx)
Displays the amount of bandwidth used in Kbytes/sec over the length of the call.
This is calculated by the number of voice packets transmitted and received over the last 10 seconds.
Average Bandwidth Use
(Tx/ Rx)
Displays the amount of bandwidth used in Kbytes/sec over the length of the call.
This is calculated by the number of voice packets transmitted and received and the length of the
connection.

13
RVON-8 Connection Status Screen
SCREEN ITEM DESCRIPTION
Error Counts
Invalid Headers Displays how many IP packets could not be parsed.
Invalid MAC Address Displays how many invalid MAC addresses tried to connect.
Invalid SSRC Displays the number of packets with an invalid SSRC.
Invalid Payload Displays how many incorrectly formatted packets were received.
DSP to Micro Overrun Displays the number of packets that were lost because the Micro was too busy to receive.
Invalid Destination Displays how many invalid destinations were received.
Lost Packets Displays how many packets were lost.

Installation
14
Download RVON-8 Firmware through AZedit
NOTE: AZedit sends the program directly to the RVON-8 card over Ethernet. This is different from other I/O cards that
receive the firmware from the Master Controller. For this reason, verify the PC running AZedit is on the same network as the
RVON-8 card. If it is not, AZedit will not be able to find the RVON-8 card. To test the connection, ping the RVON-card from
a command line. For more information on testing for a connection see Appendix A.
1. Open AZedit.
2. From the Status menu, select Software Versions, then I/O Cards.
The I/O Card Version Information screen appears show the occupied slots in the system.
3. Highlight the Version to be updated.
You may select more than one version at a time by holding CTRL key down while you select.
4. Right-click the highlighted selections and select Download Firmware.
The Firmware Download Window appears.
5. Using the browse feature, browse to the file to be downloaded.
6. Click Open.
The Download Device Firmware window appears.

15
RVON-8 Backcard
7. Click Begin Download.
The download begins.
8. Click OK.
The RVON-8 firmware download is complete. This takes a minute of two to occur.
9. Verify the version upgrade in the I/O Card Version Information Window is correct.
WARNING!: Do NOT power down the frame or pull the RVON-8 card(s) from the frame until you have verified the new
version information from AZedit. If the card loses power while reprogramming the on-board flash memory, the card may
become unbootable, and my need to have its flash chips replaced.
RVON-8 Backcard
TABLE 2. RVON-8 Backcard

Installation
16
PIN # Signal
2*RS485_L or
RS232_RX
3
*RS485_H or
RS232_TX
5GND
*On jumpers J10, J11, and J12:
• if all 1 & 2 pins are covered, then RS-
485 is active
• if all 2 & 3 pins are covered, then RS-
232 is active.
Pinout positions on the RVON-8
backcard DB9 (J2) Connector.
TABLE 3. RVON-8 Backcard
