GE-C351 Gigabit Ethernet 1000Mbps
Single Fiber WDM Media Converter
1000Base-T (RJ-45) to 1000Base-X (SC)
User's Manual (620−0691−010)
1. Overview
GE-C351 is a Gigabit Ethernet 1000Base-T to 1000Base-X
converter. It supports conversion of Gigabit Ethernet
1000Base-T signal to 1000Base-X. The single fiber converter
is designed with an optic Wavelength Division Multiplexing
(WDM) technology that transports bi-directional full-duplex
signal over a single fiber simultaneously. The
GE-C351 can be installed as a standalone unit or as a slide-in
module to the 19" converter rack (up to 10 units) for use at a
central wiring closet.
2. Model Description
Model TX, RX Wavelength
TX
(
Tr
a
n
s
mi
t)
1
3
1
0
n
m
GE-C351S3.S20/∗S40/∗S60 RX(Receive) 1550nm
TX
(
Tr
a
n
s
mi
t)
1
550
n
m
GE-C351S5.S20/∗S40/∗S60 RX(Receive) 1310nm
∗: GE-C351S3.S40/S60 or GE-C351S5.S40/S60 models
are option
Note: GE-C351S3 and GE-C351S5 must be installed in
pairs, i.e. GE-C351S3 at one end and GE-C351S5
at the other one.
3. Checklist
Before you start installing the Converter, verify that the
package contains the following:
⎯ The TP-Fiber WDM Converter
⎯ AC-DC Power Adapter
⎯ This User's Manual
Please notify your sales representative immediately if any of
the aforementioned items is missing or damaged.
4. LED Description
LED Color Function
FX LINK Green Lit when fiber connection is good
FX FDX Green Lit when fiber full-duplex is active
TP LINK Green Lit when TP connection is good
TP FDX Green Lit when TP full-duplex is active
ACT Green Lit when any traffic is present
PWR Green Lit when +5V power is coming up
5. Connecting to Gigabit Device
Converter
TP Port 1000FDX with NWay
Converter
Fiber Port AUTO: 1000FDX with NWay
FORCE(Default): 1000FDX
Fig. 2 1000Mbps TP-to-Fiber Converter Front Panel
Fig. 3 1000Mbps TP- to- Fiber Converter Rear Panel
5VDC
Fiber Mode
A
UTO FORCE
Fig. k Connection4 Basic Networ
1000 TP-to-1000LX
WDM Single Fiber
TP
TX-1550/RX-1310
Single Fiber
10/100/1000
NWay Network 10/100/1000
NWay Network
TX-1310/RX-1550
1000 TP-to-1000LX
WDM Single Fiber
TP
Fig. 1 The View of 1000Mbps TP-to-Fiber Converter
1550nm Single-Mode FX TP
LINK
FDX
Gigabit Ethernet Converter
1000Base-T to 1000Base-X
Single Fiber ACT PWR

6. Installing the Converter
Note: The Media Converter is hot-swappable.
⇒ Wear a grounding device for electrostatic discharge
For as a standalone unit:
4 5 6
⇒ Verify the AC-DC adapter conforms to your country
AC power requirement and insert the power plug
For as a slide-in unit:
⇒ Verify the media converter is the right model and conforms
to the chassis slot. The Media Converter and Rack are built
to match in dimensions, DC jack, DC receptacle and power
safety
⇒ Locate +5VDC power jack on converter back, and
carefully slide in and plug to 19" rack +5VDC power
receptacle
Attach the single fiber cable. Install 1310nm and
1550nm models at the ends of single fiber cable.
Fiber
Port Default: AUTO. The "Fiber Mode" must be set to
"FORCE" when you intend to connect a pair of
GE-C351, or GE-C351 to GM-C351 via fiber
optic cable at both ends of a fiber connection.
Attach TP Cat. 5 cable to TP port.
TP
Port The 1000 TP port supports AUTO MDI-X sensing
(e.g. either MDI-X or MDI-II).
7. Cable Connection Parameter
• TP Cable Limitations: Cat. 5 and up to 100m
• Fiber Cable Limitations:
Single-mode Fiber 9/125μm
Single-mode transceiver 1310nm 20, 40, 60Km1000LX Single-mode transceiver 1550nm 20, 40, 60Km
8. DC Jack and AC-DC Power Adapter
The DC jack's central post is 2.5mm wide; it conforms to the
DC receptacle (2.5mm) on the 19-inch Converter Rack slot.
Keep the AC-DC adapter as spare parts when Media Converter
is installed in a 19-inch Media Converter Rack.
Warning:
⎯ The "Fiber Mode" must be set to "FORCE" when you
intend to connect a pair of GM-C351, or GM-C351 to
GE-C351 via fiber optic cable at both ends of a fiber
connection. It does not work if "Fiber Mode" is set to
"AUTO" in this connection.
⎯ For other/different model converter fiber connection,
both local and remote fiber mode must be set to an
identical mode ("AUTO or FORCE") according to their
operation/configuration. Refer to the corresponding
device/converter's Technical Manual for proper setting.
GM/GE-C351 Fiber
FORCE To
⇔
GM/GE-C351 Fiber
FORCE
⎯ This converter operates at 1000FDX only.
"AUTO/FORCE" mode is used for Gigabit Ethernet
NWay protocol and multi venders compatibility.
9. TP-Fiber Technical Specifications
• Standards : IEEE802.3z/AB 1000Base-T,
1000Base-LX
• Models : GE-C351
DC Jack : 2.5mm
DC Input : +5V
(Converter DC Current Consumption: 2A
when operation at full load)
Model TX, RX Wavelength
TX
(
Tr
a
n
s
mi
t)
1
3
1
0
n
m
GE-C351S3.S20/∗S40/∗S60 RX(Receive) 1550nm
TX(Transmit) 1550nm
GE-C351S5.S20/∗S40/∗S60 RX(Receive) 1310nm
Fig. 5 DC+5V Input Jack and Dimension
∗: GE-C351S3.S40/S60 or GE-C351S5.S40/S60 models
are option
Note: GE-C351S3 and GE-C351S5 must be installed in
pairs, i.e. GE-C351S3 at one end and GE-C351S5
at the other one.
• UTP Cable : Cat. 5 cable and up to100m
Fiber Cable: 9/125
μ m single-mode
• LED Indicators :
PWR, ACT, FX LINK, FDX, TP LINK, FDX
• Data Transfer Rate: PPS (Packet Per Second)
Speed Data Transfer Rate
1000Mbps 148,8000 PPS
• TP : 1000FDX with NWay auto-negotiation
Fiber : 1000FDX at AUTO or FORCE mode
• Power Requirement : 2A@+5VDC
• Ambient Temperature : 0°to 50°C
• Humidity :5% to 90%
• Dimensions : 26.2(H) ×70.3(W) ×94(D) mm
• Complies with FCC Part 15 Class A and CE Mark
Note: For connecting this device to Router, Bridge or Switch,
please refer to the corresponding device's Technical
Manual.
Remote Side: Force
Single Fiber
Local Side: Force
For GM/GE-C351 fiber to GM/GE-C351 fiber
Fiber Mode
A
UTO FORCE
Fiber Mode
A
UTO FORCE
