Rugged Interactive Ballistics User manual

©Rugged Interactive 2021
Ballistics
Order and Installation Manual
For models from July 2020 onwards
Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate , Bodmin
Cornwall, UK
PL231 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Updated: 03/02/2021

Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
©Rugged Interactive 2021
Contents
Section 1 – Ordering Process
1.1 Need to Know
1.2 Order and Installation Checklist
1.3 Product Overview
1.4 Ordering and Installation Timeline
1.5 Getting Started
1.6 Place Order
Section 2 – Safety Guidelines
2.1 Installation Safety Guidelines
2.2 In Play Safety Guidelines
Section 3 – Installation
3.1 Parts List
3.2 Tools and Components List
3.3 Installation Overview
3.4 Detailed Installation
Section 4 – How to Use
Section 5 – Programs Guide
Ballistics System Specifications
Ballistics Installation Checklist
Next Steps

Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Ballistics – Section 1 – Ordering Process
©Rugged Interactive 2021
Section 1 – Ordering Process
1.1 - Need to Know
Installation manual purpose and limitations
This manual is intended to provide guidance only, the installation of the Rugged Interactive product will be
under your control. You will be responsible for making sure, upon completion of the installation, it is safe to
use. As always, we are here to support you, please get in touch if you are in any doubt.
Regulations
Some countries and states have regulations which may be applicable to the Rugged Interactive products, it
is your responsibility to check that the product complies with such regulations. This should be conducted
during the planning phase for the installation location.

Rugged Interactive
Unit 1, Callywith Gate
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Ballistics – Section 1 – Ordering Process
©Rugged Interactive 2021
1.2 - Order and Installation Checklist
Contact the Rugged Interactive sales team or a partner / distributor to begin the process.
☐
Confirm the invoice and delivery address along with date required (lead time is at least 5 weeks),
VAT number required for export customers.
☐
Complete site survey.
☐
Send purchase order or confirm order.
☐
Make first payment.
☐
Discuss graphic requirements and provide logos and branding guidelines.
☐
Approve graphics.
☐
Make second payment (required a week before dispatch).
☐
Schedule time and team members for installation.
☐
Before install, confirm all tools and components are prepared.
☐
Organise shipment (Customer collection or delivery organised by Rugged Interactive).
☐
Receive your order.
☐
Install the product.
☐
Test and complete installation checklist.
☐
Train the team on how to use the product.
☐
Sounds can be heard when the targets are hit.
☐
Reveal your new Rugged Interactive product to your guests and customers!
☐

Rugged Interactive
Unit 1, Callywith Gate
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Ballistics – Section 1 - Ordering Process
©Rugged Interactive 2021
1.3 - Ballistics Overview
A unique and innovative team game that transforms your air cannon
arena. Work as a team to hit your opponent’s targets. Score points
for each successful hit, accuracy is key!
Brightly lit targets which flash when a hit is registered along with fun
sounds and a large scoreboard.
Ballistics consists of a series of targets and a Scorebox with all
cables supplied. It is quick and easy to install to any suitable
structure.
1.4 - Order and Installation Timeline
* We do our best to ensure orders are ready on a five-week lead time, however during busy periods
or for large orders, the lead time may be longer than outlined here. Lead time will also be affected
by graphics guidelines, approval and payment delays.

Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Ballistics – Section 1 – Ordering Process
©Rugged Interactive 2021
1.5 - Getting Started
New Parks
During the design process for the new park, incorporate the intended products into the design, product
specifications can be found within this manual for the relevant product and CAD files can be supplied upon
request.
Existing Parks
When retrofitting existing parks, all specifications can be found within this manual or CAD files are available
at request. If further information is required, please get in touch and we will be able to provide further
information and guidance.
1.6 - Place Order
To begin the order process with Rugged Interactive:
Email:
[e-mail]
Or call the Sales Office:
[phone]
Sales Office Address:
Rugged Interactive,
Future Space,
UWE North Gate,
Filton Road,
Bristol,
UK
BS34 8RB
HQ/Production Address:
Unit 1 Callywith Court
Callywith Ind. Estate,
Bodmin,
Cornwall
UK
PL31 2RQ

Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Ballistics– Section 2 - Safety Guidelines
©Rugged Interactive 2021
Section 2 - Safety Guidelines
2.1 Installation Safety Guidelines
Before installing any Rugged Interactive product, please read the following:
Dos:
§ Ensure that a Site Survey form has been completed prior to installation.
§ Have ready suitable equipment, tools and/or man power.
§ Observe correct manual handling techniques whilst moving and installing the equipment.
§ If being installed onto a wall, the product MUST be mounted onto a wall of a construction capable of
supporting its weight and gameplay. If possible, avoid stud walls or unsupported portal infills. If in
doubt always contact a suitably qualified surveyor to check.
§ Visually check the product for any signs of damage, component failure and/or missing parts.
§ To prevent electric shock, keep all electric components away from contact with water.
§ Ensure to take anti-static precautions.
§ Wear appropriate clothing: do not wear loose clothing or jewellery.
§ Long hair should be tied back.
§ Tidy back loose cables that could become a tripping hazard.
§ Ensure that the playing area is clear.
§ Immediately inform Rugged Interactive for maintenance advice if you have concerns.
Don’ts:
§ Do not wear shoes with leather soles or high heels.
§ Do not use any tools that are not specifically recommended by the manufacturer.
§ Do not use the surface of the trampoline to balance ladders or alike.
§ Do not distract others while they are installing the product.

Ballistics Installation and Instruction Manual: Safety Guidelines
Ballistics – Section 2 - Safety Guidelines
©Rugged Interactive 2021
2.2 In Play Safety Guidelines
Please ensure you read the following points before using the equipment:
This activity can be great fun, but it can also be dangerous. There is a risk of serious injury if care is
not taken when using the equipment. Use of this equipment is physically demanding: this is a high-
impact, full body activity which requires intense focus, awareness of your body’s strengths and
limitations, awareness of the environment around you and extreme caution.
Dos:
§ Before beginning any exercise program, it is recommended that you consult with your doctor.
§ Children under the age of 7 years must always be supervised by an adult (over 16 years) when
using the equipment and/or recommended accessories.
§ Visually check the equipment before using it for any signs of damage, component failure or loose
cables that could become a tripping hazard. Report any concerns, e.g. loose or damaged
equipment, to a member of staff immediately.
§ Ensure you familiarise yourself with any additional facility rules that may apply.
§ Ensure that the play area in front of the equipment is clear before attempting to participate.
§ Only participate if you are in good physical condition. Participate only within your capabilities /
recommended exercise level.
§ Wear appropriate clothing.
§ Remove all items from your pockets prior to participation.
§ Long hair should be tied back.
§ Before use, loosen up with warm up exercises and stretches.
§ Practice being in control of your bounce before using the equipment. Always remain in control.
Uncontrolled jumps or falls are likely to result in injuries to yourself and/or others.
§ Only those participating are allowed in the activity area. If waiting to participate, stand back at a safe
distance from the equipment.
§ Make sure you have control before leaving the trampolines, obstacles or activity equipment.
§ Report any unusual or inappropriate behaviour to a member of staff immediately.
§ If you get tired, leave the equipment / activity area and take a break.
§ If you feel any pain, dizziness, nausea or any other abnormal symptoms, STOP YOUR WORKOUT
IMMEDIATELY. Consult your doctor immediately. Incorrect or excessive training may lead to
injuries.

Ballistics Installation and Instruction Manual: Safety Guidelines
Ballistics – Section 2 - Safety Guidelines
©Rugged Interactive 2021
Don’ts:
§ No more than one active user on a single trampoline at any one time.
§ Do not attempt to use any of the equipment without undertaking instruction / training carried out by
an appropriate instructor.
§ Do not participate if you are unwell or have any pre-existing medical conditions including heart,
back, neck, bone and/or muscle conditions.
§ Do NOT work to exhaustion.
§ Do not participate if you are or maybe pregnant.
§ Do not wear loose clothing or jewellery (including studs and watches). Clothing should not have any
hard or sharp points (such as buckles, studs, toggles or alike).
§ Do not wear shoes with leather soles, high heels, sandals, boots or bare feet.
§ No food, drink or chewing gum during participation.
§ No phones or cameras in the activity area.
§ Do not leave clothing or personal belongings around the activity areas.
§ Do not participate under the influence of alcohol and/or drugs.
§ Do not attempt any move beyond your own skill level.
§ Never attempt flips or other extreme moves unless you know you are capable and have had the
appropriate training.
§ No double flips, triple flips, diving or gainers, even if you are capable.
§ Do not distract others while they are using the equipment.
§ Do not attempt to catch anyone who may fall.
§ Do not sit, lie, stand or rest under the activity equipment and/or surrounding padding/mats.
§ Never lean on, jump on, climb, grab, or lift any safety pads or safety nets.
§ Do not use any accessories that are not specifically recommended by the manufacturer. These
might cause injuries or cause the equipment to fail.

Rugged Interactive
Unit 1, Callywith Gate
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Ballistics – Section 2 - Installation
©Rugged Interactive 2021
Section 3 - Installation
3.1 - Parts List
Please check off the received parts for the installation and alert Rugged Interactive immediately if
anything is missing.
Targets (to the quantity ordered, up to 16).
☐
1 x Hub control box.
☐
4 x Control box mounting brackets including 12 x M5 x 12mm screws.
☐
Target connection cables.
☐
Set of Moulded 25mm target fixing screws.
☐
Manual.
☐
3.2 - Tools and Components List
Arrange the necessary tools and the team to install the product.
Ladder.
☐
Spirit level.
☐
Industrial vacuum cleaner.
☐
Dustpan and brush.
☐
SDS impact drill.
☐
Cordless drill – with torque adjuster to avoid over-tightening the screws.
☐
A set of No.2 Pozi bits.
☐
A set of screwdrivers.
☐
A set of Hex keys
☐

Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Ballistics – Section 2 - Installation
©Rugged Interactive 2021
3.3 - Installation Overview
Below is an overview of the steps needed to install Ballistics. More detail for the process is
provided in the following pages. Please read through ALL of this prior to beginning the installation
and if you are in any doubt, contact Rugged Interactive.
If you have any concerns on how or what the product is installed to, contact a structural engineer
prior to beginning the installation.
STEP 1: Mount scorebox.
STEP 2: Mount targets.
STEP 3: Attach cables between targets and scorebox.
STEP 4: Turn on Ballistics system.
STEP 5: Test.
STEP 6: Check all is secured.
STEP 7: Stress relief cables.
STEP 8: Enjoy Ballistics!

Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Ballistics – Section 3 - Installation
©Rugged Interactive 2021
3.4 – Detailed Installation
Read this manual before installing Ballistics.
Installation Guidelines:
§ Complete the Site Survey form prior to delivery and/or installation.
§ Send a completed Installation Checklist after any installation to Rugged Interactive.
§ A typical installation should take 2 people about 5 hours.
§ No obstructions or protrusions in the installation area: e.g. skirting boards, pipes, cables and wiring
conduits.
§ Avoid trapped and/or pinched cables.
§ Use good practice when running data cables to and from products, external pods and sensors.
Support long cables at least every 50 cm and provide adequate strain relief for connection points.
§ To prevent electric shock, keep all electric components away from contact with water.
§ IMPORTANT: Take anti-static precautions.
Structure:
§ Mount onto timber or steel framework.
§ The targets feature four mounting points.
§ The targets feature hanging cables to connect back to the HUB/score box via supplied cable.
§ The units must be mounted to a construction capable of supporting their weight and gameplay. Do
not fix to plasterboard faced partition, unsupported portal infills and stud walls. (Uneven walls and
structures make alignment and fitting very difficult.)
Fixings:
§ The manufacturer will supply fixings.
§ Use Rawl Plugs (plastic wall plugs) if mounted to a solid block or brick wall.
§ All fixings must be tight and secure.
Suggested Extras:
§ 3 m of self-adhesive ‘mini’ box trunking to secure the power cable.
§ Cleaning cloth and gentle cleaning spray.
Installation Heights:
§ Take into consideration the height and distance the air cannons can fire and install appropriately to
this.
§ Layout of Ballistics is at the discretion of the installer / park constructor.

Ballistics Order and Installation Manual: Installation
Ballistics – Section 3 - Installation
©Rugged Interactive 2021
Operating Environment:
§ Keep out of direct sunlight.
§ Keep indoors and dry.
§ Optimum ambient temperature: 5°C to 30°C. Avoid extreme fluctuations of temperature.
Other Recommendations:
§ Instruction / training carried out by an appropriate instructor to all new users.
§ A waiting / spectating area positioned nearby is advised.
IF YOU ARE IN ANY DOUBT, CALL RUGGED INTERACTIVE DIRECTLY ON [phone].

Ballistics Order and Installation Manual: Installation
Ballistics – Section 3 - Installation
©Rugged Interactive 2021
Ballistics Display / Score Box (HUB) Installation
Notes:
§ Fix HUB using any suitable self-tapping or wood screws into the surface material. The HUB can be
recessed to be flush with the surface or affixed on top of the foam-backed vinyl if necessary.
§ A central position is recommended for easy comparison of scores.
§ Note: Cables exit is at the rear of the display box.
01
02
Hold the main body in place, and ensure it is
level.
Use appropriate fixings and mount the display
box to the wall.
Note: Make sure everything is tight and secure
and that no cables are trapped.

Ballistics Order and Installation Manual: Installation
Ballistics – Section 3 - Installation
©Rugged Interactive 2021
Ballistics Target Installation
Notes:
§ Fix targets using any suitable self-tapping or wood screws into the surface material.
§ Note: Cables exit is at the base of the target box.
01
02
Hold the main body in place, and ensure it is
level.
Use appropriate fixings and mount the target
box to the wall.
Note: Make sure everything is tight and secure
and that no cables are trapped.

Ballistics Order and Installation Manual: Installation
Ballistics – Section 3 - Installation
©Rugged Interactive 2021
Ballistics Targets to Score Box (HUB) Installation
Notes:
§ Attach correctly the supplied CAT5 cables from the targets to the designated output cables from the
HUB.
§ Make sure the RJ45 connector is clear from dust and debris and do not force the CAT5 Cable into
it.
01
02
NOTE: Please use good practice when running data cables to and from products, targets and boxes.
Support long cables at least every 50 cm and provide adequate strain relief for connection points.
Team 1 Team 2
Score Box (HUB) (Back View)
Attach CAT5 cables from targets to the con-
nectors at the back of the Score Box (HUB).
Connect the CAT5 cables from the
targets to the Score Box (HUB). The
targets will have hanging cables to
connect the CAT5 Cables to.
The Hub will have hanging cables
labelled for the start button and for each
target.
Attach CAT5 cables from each target to
the connectors at the back of the Score
Box (HUB).
Connect CAT5 Cable

Ballistics Order and Installation Manual: Installation
Ballistics – Section 3 - Installation
©Rugged Interactive 2021
Score Box
(HUB)
CAT5 Cable Connections
Notes:'
• Cables come out the back of each unit. Cables need to be installed as shown in Figure 3.4.1
Team
1
Power
Team
2
Figure 3.4.1: Typical Ballistics Cable Connections

Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Ballistics – Section 4 - How to Use
©Rugged Interactive 2021
Section 4 - How to Use
On power up, Ballistics will sound a ‘laugh’ and will turn to its idle state.
Ballistics (Game / Program) – Battle, 2 minutes
Game Rules:
The objective of Ballistics is to score points by hitting the opposing team targets by using air cannons /
balls. One (1) point is earned for any target hit.
The targets are split into 2 even groups. Aim and shoot at the opponents’ coloured targets. They will flash
and a noise will sound upon a successful hit.
Each game lasts for 2 minutes. Try to hit as many of the opponents’ targets as possible to build up your
score.
The team to score the most points wins.
How to Use:
Hit any target to start the game
Aim and fire balls at your opponents’ targets to score points.
At the end of the game, the winning score will flash on the score box.
NOTE: At any time, if Ballistics behaves unexpectedly, wait for at least 1 minute for the unit to reset
to its idle state.

Rugged Interactive
Unit 1, Callywith Gate
Callywith Industrial Estate, Bodmin
Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Ballistics – Section 5 - Programs Guide
©Rugged Interactive 2021
Section 5 - Programs Guide
Ballistics
Summary: This game includes hand/eye coordination, teamwork, building quick reflexes,
and building a competitive spirit.
Gameplay: Upon hitting a target to start the game, all targets will illuminate, and the starting
sound is heard.
Every time a target is hit it flashes out, and the score box registers the hit. At the
end of the game the winning score flashes.
Aim: To hit as many opponent’s targets as possible within the given time limit.
Scoring system: +1 point for each target hit
Duration: 2 minutes

Rugged Interactive
Unit 1, Callywith Court
Callywith Industrial Estate,
Bodmin, Cornwall, UK
PL31 2RQ
[phone]
www.rugged-interactive.co.uk
[e-mail]
Ballistics - System Specifications
©Rugged Interactive 2021
Ballistics System Specifications
Dimensions and Weights:
Power Supply: AC: 110-230V, 50-60Hz, 13A
Warranty: 1 year on electronics. 3 years on all other parts.
Regulatory Requirements: CE Approved.
Operating Environment: Indoors: keep dry and out of direct sunlight.
Mount to a framework or structure of a suitable construction.
Optimum ambient temperature: 5°C to 30°C. Avoid extreme
temperature fluctuation.
Approx. Shipment Details
Fully Assembled Details
Size (mm)
Weight
Size (mm)
Weight
Ballistics Target (single)
-
-
355 x 355 x 60
2 kg
Display / Score Box (HUB) (single unit)
-
-
850 x 650 x 70
20 kg
Target (Dimensions in mm)
355
400
240
355
60
