RunCam New Swift 2 User manual

RunCam Swift 2
USER MANUAL

Connection
UP
DOWN
L R
Transmitter
5D-OSD menu cable
2 pin extension cord
Power in
GND
To VBAT+
* Unplug the 5D-OSD menu cable after OSD setting.
5-36V in
GND
Video out
Audio out
VBAT+

1
Nylon Gaskets
2
M2*4 Screws
3
M3*5 Screws
4
M3 Non-slip Nuts
26mm
28.5mm
26mm
1 1
11
44
2
2
2
33
2
Dimensions & Installation

OSD Menu
OSD Setting: Press and hold the UP button for 2 seconds to enter OSD setup menu.
· PILOT: ON/OFF
· TIMER: ON/OFF
· VOLTAGE: ON/OFF
· BASELINE: OFF/1-9
· EXIT: Save the current settings and exit
Customize the PILOT name: Use the UP, DOWN,
LEFT and RIGHT buttons to navigate through the
letters and confirm with the CENTER button.
Quick settings:
Long press the LEFT/DOWN/RIGHT button
for 2 seconds to activate the VOLTAGE/PILOT
/TIMER, then you can use the UP, DOWN,
LEFT and RIGHT buttons to move it to the
appropriate location on the screen, and press
the CENTER button to exit.
RunCam
ON
ON
ON
OFF
VOLTAGE
PILOT
TIMER
EXIT
BASELINE
DEFAULT
1234567890ABCDEFG
HIJKLMNOPQRSTUVWX
YZabcdefghijklmno
pqrstuvwxyz.-:/@
The OSD displays by default the input voltage
of the camera. If the VBAT + cable is
connected to the battery's positive side, it
displays the battery voltage instead.

Camera Menu
· CAM TITLE (ON/OFF)
· LANGUAGE (English/中文)
· DPC (Cover the lens then press enter key)
· SHUTTER
(AUTO / 50-100000 / FLK)
· BRIGHTNESS (50 / 0-255)
· AGC (OFF / LOW / MIDDLE / HIGH)
·
EXPOSURE · MAIN MENU
· WHITE BAL (ATW1 / ATW2 / AWC→SET /
MANUAL: MANUAL, INDOOR, OUTDOOR) · DWDR (ON: 63 0-63 / OFF)
EXPOSURE
SHUTTER
BRIGHTNESS 050
AGC
DWDR
RETURN
AUTO
OFF
RET
ON
SETUP
CAM TITLE
EXPOSURE
WHITE BAL
BACKLIGHT
DAY＆NIGHT
DPC
IMAGE ADJ
LANGUAGE
RESET
EXIT
AT W1
ENGLISH
OFF
COLOR

IMAGE ADJ
LENS SHAD
2DNR
MIRROR
FONT COLOR
CONTRAST
SHARPNESS
DISPLAY
NEG IMAGE
RETURN
OFF
OFF
OFF
110
026
USER
OFF
· IMAGE ADJ
· LENS SHAD (OFF/ ON:22 0-255)
· CONTRAST (110 / 0-255)
· SHARPNESS (26 / 0-31)
· DISPLAY (CRT/LCD/USER)
· GAMMA
(0.5 / 0.05-1.0)
· PED LEVEL (28/ 0-63)
Camera Menu
USER ADJ.
RETURN
GAMMA
PED LEVEL
COLOR GAIN
0.50
028
RET
176
· COLOR GAIN (176 / 0-255)

Camera Menu
· AREA SEL (AREA1/AREA2)
· BACKLIGHT (BLC / HLC / OFF)
· GAIN (168 / 0-255 )
· HEIGHT (5 / 0-10)
· LEVEL
(200 / 0-255)
· MODE (ALL DAY / NIGHT ONLY )
· WIDTH (5 / 0-9)
· LEFT/RIGHT (4 / 0-6)
· TOP/BOTTOM (4 / 0-10)
168
005
005
004
004
AREA SEL
AREA STATE
GAIN
HEIGHT
WIDTH
LEFT/RIGHT
TOP/BOTTOM
RETURN
AREA1
ON
BLC
RET
200
HLC
LEVEL
MODE
RETURN
ALL DAY
RET

· DAY NIGHT LEVEL (114 / 0-176)
· DAY NIGHT DELAY (3 / 1-30)
· NIGHT DAY LEVEL (112 / 0-255)
· NIGHT DAY DELAY (1 / 1-30)
Camera Menu
· BURST (OFF/ON)
· IR SMART (OFF/ON)
· IR LEVEL (HIGH/LOW)
·
DAY ＆NIGHT（AUTO / COLOR / B&W / EXT)
D＆N AUTO
144
SEC
112
SEC
3
1
D N LEVEL
D N DELAY
N D LEVEL
N D DELAY
RETURN RET
D＆N B＆W
BURST
IR SMART
IR LEVEL
RETURN
OFF
OFF
HIGH
RET

Model
Image Sensor
Horizontal Resolution
Lens
Signal System
Integrated OSD
S/N Ratio
Electronic Shutter Speed
Auto Gain Control (AGC)
Back Light Compensation (BLC)
Min. Illumination
WDR
DNR
Day/Night
Power
Net Weight
Dimensions
RunCam Swift 2
1/3″SONY SUPER HAD II CCD
600TVL
2.3mm
PAL
Yes
Yes
>60dB (AGC OFF)
Yes
Yes
[email protected]
1/50~100,000
D-WDR
2DNR
Color/Auto/B&W
DC 5-36V
14g
28.5mm*26mm*26mm
Integrated MIC
