Acclaim 7 Series Fixed Tilt Loudspeakers
Product Brief
Russound’s new Acclaim 7 Series Fixed Tilt speakers provide
a high-performance solution for installations where space is
limited and clarity is required. Featuring a small footprint and
quality materials, the Acclaim 7 Series Fixed Tilt speakers
provide widely dispersed sound from any location.
Designed for the demands of architectural installations, the
Acclaim 7 Series Fixed Tilt speakers have been designed
for either in-wall or in-ceiling use. The removable fixed tilt
speaker baffle can be positioned in 90 degree increments,
allowing the speaker to be aimed to deliver even coverage
when ideal installation positions are unavailable.
Acclaim 7 Series
7W51SFT and 7W52FT Fixed Tilt speakers are suitable
for installation in close quarters, such as in a stud bay with
an amplified keypad, a bathroom ceiling, or home theater
applications such as rear surround or Dolby Pro Logic IIz
height speakers.
Magnetic Speaker Grilles
Makes for easy install, baffle adjustment, and fewer rattles.
To further increase clarity, the Fixed Tilt speakers implement
Russound’s Iso-Mount®technology, a proprietary
thermopolymer isolation gasket that reduces vibration
transmission into structural cavities. For improved off-axis
listening, the speakers utilize pivoting tweeters to deliver truly
“blended” sound in any environment. Magnetic grills and
twist lock mounting tabs make the Acclaim 7 Series Fixed Tilt
speakers easy to install, anywhere.
For performance and clarity from an easily integrated
loudspeaker, Russound’s Acclaim 7 Series Fixed Tilt speakers
deliver superb sound through innovative design and materials.
Features Benefits
Iso-mount chassis reduces unwanted vibration and increases clarity, definition, and accuracy of the sound
Pivoting tweeters delivers additional off-axis frequency response and better dispersion throughout a room
Small foot print can be installed in walls or ceiling, fits in stud bays
Magnetic grilles makes for easy install, baffle adjustment, and fewer rattles
Angled baffle allows sound to be directed in 90 degree increments, provides better coverage from off center placement
Fixed-Tilt Single Point Stereo
7W51SFT
Fixed-Tilt 2-way
7W52FT

Specifications
Since 1967, innovation, quality and reliability have been the core of the Russound product tradition. Today, Russound offers everything for enjoying multiroom audio-video in your
home. All audio-video distributed solutions are built to high standards and designed with the unique consideration of making products that are a pleasure to live with and enjoy.
©2009 Russound. All rights reserved. All trademarks are the property of their respective owners. Specifications are subject to change without notice.
Russound is not responsible for typographical errors or omissions. iPhone and iPod touch are registered trademarks of Apple, Inc.
5 Forbes Road, Newmarket, New Hampshire 03857 USA 603.659.5170 www.russound.com
LR3155-0003 08/09
Fixed Tilt Single Point Stereo Loudspeaker
7W51SFT
Woofer 5.25” (13.33 cm) Polypropylene
Tweeter (2) 0.5” (1.27 cm) PEI
Cutout 7.4” x 7.4” (18.7 x 18.7 cm)
Mounting Depth 3.8” (9.65 cm)
Dimensions 8.6” x 8.6” (21.85 x 21.85 cm)
Terminals 12 gauge guillotine
Grille Aluminum with magnetic frame
Recommended Power 10 - 75 watts
Sensitivity 88 dB SPL (2.83V @ 1m)
Frequency Response 65 Hz - 20 kHz ± 3 dB
Frequency Range 50 Hz - 20 kHz -6/+3 dB
Nominal Impedance 6/6 ohms
Weight 3.07 lbs. ( 1.38 kg)
Fixed Tilt 2-way Loudspeaker
7W52FT
Woofer 5.25” (13.33 cm) Polypropylene
Tweeter Pivoting 1” (25 mm) Silk
Cutout 7.4” x 7.4” (18.7 x 18.7 cm)
Mounting Depth 3.8” (9.65 cm)
Dimensions 8.6” x 8.6” (21.85 x 21.85 cm)
Terminals 12 gauge guillotine
Grille Aluminum with magnetic frame
Recommended Power 10 - 85 watts
Sensitivity 88 dB SPL (2.83V @ 1m)
Frequency Response 63 Hz - 20 kHz ± 3 dB
Frequency Range 51 Hz - 20 kHz -6/+3 dB
Nominal Impedance 6 ohms
Weight 3.01 lbs. ( 1.38 kg)
Speaker Placement
The advantage of the 7W51SFT and 7W52FT models’ fixed tilt design is
that they can be mounted in less than perfect locations and still be directed
towards the listener.
Vertical Placement
In installations where the only available mounting
area is above the ideal listening height, the
Acclaim 7 Series Fixed Tilt Loudspeakers can
be aimed downward. Conversely, in installations
where the speaker is below the ideal listening
height, the speakers can be aimed upwards.
Horizontal Placement
The Acclaim 7 Fixed Tilt Loudspeakers also provide excellent sound dispersion
horizontally. Speakers can be mounted close to each other and aimed outward,
or mounted far apart and aimed inward to fill a room with sound.
