Russound RSF-610T User manual

Product Brief
Woofer Technology
• 6.5” Polypropylene cone is well damped to accommodate
all program material, spoken and musical
• NBR rubber cone surround damps resonance and
provides exceptional durability in any humidity level
and over a wide temperature range
Tweeter Technology
• Pivoting, low-diffraction assembly focuses the high-
frequency sound in any direction independently of the
woofer to create direct or diffuse sound fields
• Twin 0.75” silk doms with Ferrofluid-cooling and ultra-wide
dispersion for clear and detailed high-frequencies
Magnetic Edgeless Grille
• Designer-inspired edgeless magnetic grilles conceal
loudspeaker elements yet allow high fidelity sound
through. Grille can be painted to match décor
6.5” Single Point Stereo
Acclaim™Wide Dispersion Speaker
Provides “stereo sound” from a single speaker
Wide dispersion design
provides uniform coverage
over a large area
Edgeless grille blends
discretely into the décor
RSF-610T
Speaker
Triple-dog mounting
system for quick and
efficient installations
25% faster than
4-dog models
Trusted reliability that
you can count on

Model Description Woofer Tweeter Recommended
Power
Frequency
Response Sensitivity Nominal Impedance
Magnet
Structure
Overall
Dimensions
Cut-out
Dimensions
Mounting
Depth
RSF-610T
Single Point Stereo
Speaker,
In-ceiling/in-wall
6.5”(20.32 cm)
IMPP Cone
2 x 0.75" (1.91 cm)
Pivoting Silk 5 - 120 watts 40Hz - 20kHz 90dB
@ 1w/1m 8 ohms
Ferrite
20 oz
(0.567 kg)
9.13”dia.
(23.19 cm)
8.375”dia.
(21.27 cm)
3.69”
(9.37 cm)
Technical Specifications
Product Specifications
Model Number Part Number Shipping Dimensions Shipping Weight
RSF-610T/each 3175-535116 10.5”L x 10.5”W x 6.1”H, (26.7 x 26.7 x 15.5 cm) 5lbs (2.3 kg)
3.19”
3.69”
0.5”
Drywall
In-wall placement
Russound | 1 Forbes Road Newmarket, NH 03857 | 603.659.5170 | www.russound.com
©2014 Russound/FMP, Inc. All rights reserved. Russound and the Russound logo are registered trademarks of Russound/FMP, Inc.
Acclaim is a trademark of Russound/FMP, Inc. All other trademarks are the property of their respective owners.
Russound reserves the right to change specifications without notice.
Optional Accessories
Sound Blocking Flexbox Back Box
FBC1-FR In-Ceiling
1 Hour
Fire Rating
Rough-In Bracket
SB-C67 - In-ceiling/In-wall
Square Grille
RSG-6S
