RVi Tire Patrol User manual

Tire Patrol
Tire Pressure Monitoring Sensors
QUICK START GUIDE
Tire Patrol
Tire Pressure Monitoring Sensors
QUICK START GUIDE

Welcome to Tire Patrol tire pressure monitoring system, an “Official Command
Center” product. Here at RVi, we exist to provide innovative, quality products that
keep the fun and safety in RVing. We strive for this existence because it’s what we
want as customers of products, too.
If there are any questions while installing or using this product, please call Customer
Service at 800-815-2159.
Thank you for letting us be a part of your journey.
Happy RVing!
-The RVi Crew
1
1
WELCOME
SETUP
Pairing Steps
Tire Patrol sensors do not come paired with Command Center tablet and hub. The
following steps will walk you through the pairing process. Before you start, make
sure all sensors are unthreaded.
Welcome to Tire Patrol tire pressure monitoring system, an “Official Command
Center” product. Here at RVi, we exist to provide innovative, quality products that
keep the fun and safety in RVing. We strive for this existence because it’s what we
want as customers of products, too.
If there are any questions while installing or using this product, please call Customer
Service at 800-815-2159.
Thank you for letting us be a part of your journey.
Happy RVing!
-The RVi Crew
WELCOME
SETUP
Pairing Steps
Tire Patrol sensors do not come paired with Command Center tablet and hub. The
following steps will walk you through the pairing process. Before you start, make
sure all sensors are unthreaded.

2
2
1) Power on the Command Center tablet and hub. You may
have to connect one or the other to a Dual USB AC/DC
charger if battery is low.
2) On the tablet, navigate to the products settings
SETTINGS>PRODUCTS Enable Tire Patrol with the pill slider.
3) Navigate back to the Dashboard and enter the Tire Patrol
app.
4) Select START to begin the pairing process.
Tire Patrol
1) Power on the Command Center tablet and hub. You may
have to connect one or the other to a Dual USB AC/DC
charger if battery is low.
2) On the tablet, navigate to the products settings
SETTINGS>PRODUCTS Enable Tire Patrol with the pill slider.
3) Navigate back to the Dashboard and enter the Tire Patrol
app.
4) Select START to begin the pairing process.
Tire Patrol

WARNING: Threading on sensors before Command Center tablet and hub are
powered on will result in a failure to pair.
NOTE: If a sensor(s) fails to pair, the tablet will walk you through the pairing
process again for the failed sensor(s).
3
3
5) Choose which vehicle(s) and the number of tires you will be
monitoring, then select PAIR.
6) When the tablet prompts, thread sensors onto valve stems
until they are snug. There is a 10 minute pairing window to
thread on the sensors. Each sensor is labeled according to the
tire it should be threaded onto (ie. LF6 is for Left Front on the
vehicle with 6 tires.). As each sensor pairs, the tire’s air
pressure will appear.
7) After all sensors have been paired, you’ll be asked to choose
your HIGH PSI and LOW PSI warning levels for each vehicle.
We recommend 5-10 PSI above and below your recommended
pressures for each vehicle. You can change these at any time.
Once completed, select DONE.
NOTE: If you don’t know the recommended tire pressure for
your vehicles, then your local dealer or tire manufacturer.
WARNING: Threading on sensors before Command Center tablet and hub are
powered on will result in a failure to pair.
NOTE: If a sensor(s) fails to pair, the tablet will walk you through the pairing
process again for the failed sensor(s).
5) Choose which vehicle(s) and the number of tires you will be
monitoring, then select PAIR.
6) When the tablet prompts, thread sensors onto valve stems
until they are snug. There is a 10 minute pairing window to
thread on the sensors. Each sensor is labeled according to the
tire it should be threaded onto (ie. LF6 is for Left Front on the
vehicle with 6 tires.). As each sensor pairs, the tire’s air
pressure will appear.
7) After all sensors have been paired, you’ll be asked to choose
your HIGH PSI and LOW PSI warning levels for each vehicle.
We recommend 5-10 PSI above and below your recommended
pressures for each vehicle. You can change these at any time.
Once completed, select DONE.
NOTE: If you don’t know the recommended tire pressure for
your vehicles, contact your local dealer or tire manufacturer.

Standard transmissions:
•When the sensor is first threaded on for pairing and giving initial reading.
•When pressure has increased or decreased by 3 PSI or every XX min.,
whichever comes first, but only if the vehicle is going down the road.
Communication
Each sensor is powered by a small coin cell battery. To prolong battery life, the
sensors will only communicate at the following times:
4
4
Keeping a close eye on tire pressure is about your safety as well as your wallet.
Under-inflated tires flex excessively under load, producing heat and increasing rolling
resistance which wastes fuel. Tires inflated 10 PSI below recommended levels can
reduce truck fuel economy up to 1%. In addition, stress from flexing causes fast and
uneven wear, shortening the life of the tire. Alternatively, over-inflation can lead to
uneven wear and premature tire failure.
WARNING: Remove sensors if taking vehicle through car wash.
Boom! You’re a genius!
OPERATION
Standard transmissions:
•When the sensor is first threaded on for pairing and giving initial reading.
•When pressure has increased or decreased by 3 PSI or every XX min.,
whichever comes first, but only if the vehicle is going down the road.
Communication
Each sensor is powered by a small coin cell battery. To prolong battery life, the
sensors will only communicate at the following times:
Keeping a close eye on tire pressure is about your safety as well as your wallet.
Under-inflated tires flex excessively under load, producing heat and increasing rolling
resistance which wastes fuel. Tires inflated 10 PSI below recommended levels can
reduce truck fuel economy up to 1%. In addition, stress from flexing causes fast and
uneven wear, shortening the life of the tire. Alternatively, over-inflation can lead to
uneven wear and premature tire failure.
WARNING: Remove sensors if taking vehicle through car wash.
Boom! You’re a genius!
OPERATION

Low level alerts:
The tablet will give audible, as well as visual alerts for Low level alerts. These
can be muted on the tablet.
•If LOW PSI or HIGH PSI threshold has been reached.
•BATTERY LOW, if a sensor’s battery is low.
•COMM LOST, if the Command Center tablet or hub hasn’t received
transmission from sensor for XX min.
High level alerts:
The tablet will give audible, as well as visual alerts for High level alerts.
•If HIGH TEMP threshold has been reached. High temperature threshold is
(175˚F).
•FLAT TIRE, if a tire is going flat based on accelerated decrease in tire
pressure.
5
5
Remove sensors
To remove sensors, unthread the sensors from the valve stems.
NOTE: To prolong the life of the batteries, remove the sensors when not in use
and store safely. This reduces the number of transmissions. If possible, store in a
climate controlled environment.
Low level alerts:
The tablet will give audible, as well as visual alerts for Low level alerts. These
can be muted on the tablet.
•If LOW PSI or HIGH PSI threshold has been reached.
•BATTERY LOW, if a sensor’s battery is low.
•COMM LOST, if the Command Center tablet or hub hasn’t received
transmission from sensor for XX min.
High level alerts:
The tablet will give audible, as well as visual alerts for High level alerts.
•If HIGH TEMP threshold has been reached. High temperature threshold is
(175˚F).
•FLAT TIRE, if a tire is going flat based on accelerated decrease in tire
pressure.
Remove sensors
To remove sensors, unthread the sensors from the valve stems.
NOTE: To prolong the life of the batteries, remove the sensors when not in use
and store safely. This reduces the number of transmissions. If possible, store in a
climate controlled environment.

6
6
Antenna Usage
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. FCC
radiation Exposure Statement to comply with FCC RV exposure requirements in section 1.1307, a minimum separation distance
of 0.81 cm (0.3 inches) is required between the antenna and all persons. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiver antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The Installer of this radio equipment must ensure that the antenna is located or pointes such that it does not emit RV field in
excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s website
http://www.hc-sc.gc.ca/rpb
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement
IMPORTANT: Changes or modifications not expressly approved by Danko Manufacturing LLC could void the user’s authority
to operate the equipment.
COMPLIANCE
Antenna Usage
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. FCC
radiation Exposure Statement to comply with FCC RV exposure requirements in section 1.1307, a minimum separation distance
of 0.81 cm (0.3 inches) is required between the antenna and all persons. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiver antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The Installer of this radio equipment must ensure that the antenna is located or pointes such that it does not emit RV field in
excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s website
http://www.hc-sc.gc.ca/rpb
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement
IMPORTANT: Changes or modifications not expressly approved by Danko Manufacturing LLC could void the user’s authority
to operate the equipment.
COMPLIANCE

7
7
Limited Warranty
How long is the warranty?
Tire Patrol sensors have a one year limited warranty from the original purchase date.
What is covered?
It warrants your product to be free of mechanical and electrical defects in material and workmanship.
Where or how do I get assistance for my RVi product?
During the warranty period, RVi will repair or replace the product (at RVi’s discretion), which will be your
exclusive solution under this warranty.
Do NOT return the product, doing so may delay the processing of your claim and the repair or
replacement of the product. For return instructions, please call RVi Customer Service.
What is not covered?
The warranty will not cover damage resulting from neglect or misuse of the product, use contrary to
operating instructions, or disassembly, repair, or alteration by any person other than RVi’s repair
department. RVi is not liable for any incidental or consequential damages for breach of any expressed
or implied warranty on the product.
How state laws may apply
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation
of incidental or consequential damages, so the above limitation may NOT apply. This warranty gives
specific legal rights, and you may also have other rights, which vary from state to state.
“This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.”
WARRANTY
Limited Warranty
How long is the warranty?
Tire Patrol sensors have a one year limited warranty from the original purchase date.
What is covered?
It warrants your product to be free of mechanical and electrical defects in material and workmanship.
Where or how do I get assistance for my RVi product?
During the warranty period, RVi will repair or replace the product (at RVi’s discretion), which will be your
exclusive solution under this warranty.
Do NOT return the product, doing so may delay the processing of your claim and the repair or
replacement of the product. For return instructions, please call RVi Customer Service.
What is not covered?
The warranty will not cover damage resulting from neglect or misuse of the product, use contrary to
operating instructions, or disassembly, repair, or alteration by any person other than RVi’s repair
department. RVi is not liable for any incidental or consequential damages for breach of any expressed
or implied warranty on the product.
How state laws may apply
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation
of incidental or consequential damages, so the above limitation may NOT apply. This warranty gives
specific legal rights, and you may also have other rights, which vary from state to state.
“This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.”
WARRANTY

tirepatrol.com
tirepatrol.com
RVi
624 Atchison Way #101!
Castle Rock, CO!80109
800-815-2159
rvibrake.com
[email protected]
CONTACT
RVi
624 Atchison Way #101!
Castle Rock, CO!80109
800-815-2159
rvibrake.com
[email protected]
CONTACT
