Rockford Fosgate RFX-8115 Installation and operating manual

®®
Installation Reference Sheet
Páginas de Referencia para la Instalación
Schéma d’Installation
Installations Beiblatt
Istruzioni di Installation
RFX-8115

AM / FM ST / CD Player
Detachable Faceplate
RFX-8115 Specification
Reference
Sheet
GENERAL
•ISO Mountable – 178mm x 50.4mm (trim ring removed)
•SMART-On (Sequentially Managed Accessory Remote
Turn-On) Separate turn-on leads for amplifiers and signal proces-
sors that protect speakers and electronics from damaging transients
•Any Button Wake-Up
•Clock
•Cell Phone Mute
•Switchable Loudness – Enables bass response to be boosted
at low listening levels
•IR Remote Compatible w/ Pulse – Ability to operate
functions via remote control as well as trigger external devices
(amp racks, neon lights, etc.)
•Internal Amplifier – 4-channel speaker outputs
FEATURES
PREAMP
•Low Source Impedance – Enables multiple amplifiers to
be driven without signal loss
•2-ch Pre-Out – Front RCA
TUNER
•Gen 3.0 w/patented Digital Automatic Alignment
•MIR (Multipath Interference Rejection) – Improves
audio performance when radio reception is poor
•World Wide Tuner – America/Europe/Aust/Saudi
•24 Station Presets – 6AM/18FM Presets
•Auto Store – Auto programming of all 24 presets
COMPACT DISC
•5.0 Hologram laser w/multi-damping
•Dual 1 Bit D/A Converters w/8x Oversampling
•Digital Servo Control w/Auto Focus – Adjusts to CD
manufacturing tolerances for accurate tracking
SPECIFICATIONS
FM TUNER
Frequency Response ................................. 30Hz – 15kHz
Usable Sensitivity..........................................20dB @ 1uV
Alternate Ch. Selectivity ........................................... 90dB
Adjacent Ch. Selectivity ........................................... 50dB
50dB Quieting Sensitivity........................................ 18dBf
Signal-to-Noise Ratio ............................................... 72dB
Channel Separation ...................................≥25dB @ 1kHz
Capture Ratio ................................................ 2.6 @ 45dBf
CD PLAYER
Usable Discs ..................................................... 5” and 3”
Frequency Response ...................... 20Hz – 20kHz (±2dB)
Signal-to-Noise Ratio ............................................. >90dB
Channel Separation .................................................. 86dB
Dynamic Range ..................................................... 100dB
AM TUNER
Sensitivity.......................... 31dBf max. @ 10dB sensitivity
–6dB Bandwidth ....................... 5kHz min. – 12kHz max.
GENERAL
Operating Voltage ............................... +10.5 to +16V DC
Continuous Power Output ........................... 7.5 x 4 Watts
Dynamic Power Output ................................ 13 x 4 Watts
Pre-Out Voltage (vol. max.) ................................ 2.4 Vrms
Preamp Output Impedance ....................................... 50Ω
Equalization ....................................... Bass ±8dB @ 60Hz
Treble ±10dB @ 10kHz
Chassis Dimensions .......................... 7”W x 63⁄8”D x 2”H
(178mm x 162mm x 50.4mm)
Nosepiece Dimensions ................. 71⁄16”W x 7⁄8”D x 2”H
(179.7mm x 22.2mm x 50.4mm)
Weight ................................................... 3.48 lbs. (1578g)
®®
Specifications subject to change without notice
®
RFX-8115
®®
AUD SEL
6
RDMRPTSCAN PAUSE
43 521
P.SCN LOUDDSPL
CLOCK
PWR
AUTO
VOL TUNE
COMPACT
DIGITAL AUDIO

AM / FM ST / CD Player
Detachable Faceplate
Installation
Reference
Sheet
RFX-8115
Instrument Panel Thickness Tabs to Bend
ABCDE FG
1.2mm to 2.5mm x x x
2.4mm to 3.5mm x x x
3.6mm to 4.5mm x x
4.6mm to 5.5mm x x x
5.6mm to 7.0mm x x
7.0mm to 12mm x x x
12.0mm to 15mm x x
Left Side View Right Side ViewTop View
G G C
CC B F A D E E D AF B C
Antenna
N/C
N/C
3
4
5
6
7
8
9
10
1
2
(Looking into the Radio
Connector)
Front Right (–)
Front Right (+)
Front Left (–)
Front Left (+)
N/C
N/C
N/C
N/C
10
9
8
7
6
5
4
3
2
1
RCA Harness
Power Harness
(Looking into the Radio Connector)
22 21 20 19 18 17 16 15 14 13 12
1110987654321
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
N/C
Turn-On “B”
Turn-On “A”
Turn-On “C“
Audio Mute
Not Used
Rear (L–)
Rear (R–)
Front (L–)
Front (R–)
Chassis Ground
(Blue/White)
(Lt. Blue)
(Blue/Red)
(Brown)
(Green/White)
(Green/Black)
(Purple/Black)
(White/Black)
(Gray/Black)
(Black)
N/C
Not Used
Not Used
Ignition +12V
N/C
Not Used
Rear (L+)
Rear (R+)
Front (L+)
Front (R+)
Battery +12V
(Orange/White)
(Orange)
(Red)
(Dk. Blue)
(Green)
(Purple)
(White)
(Gray)
(Yellow)
Minimum & Maximum
Mounting Angle
20°
20°
Antenna
Input
1-6
+
–
White
White/Black
Gray
Gray/Black
Green
Green/Black
Purple
Purple/Black
Orange/White
Orange
Green/White
Brown
Yellow
Red
Lt. Blue
Audio Mute (GND to activate) (Input)
4 Speaker System
2 Speaker System
IR Remote
RFX-1110
Press “Diamond R”
Button to Pulse
Turn on “C”
Turn-On “C” (300mA Max) (Output)
(Pulsed 500ms)
Turn-On “B” (300mA Max) (Output)
(.5 sec DELAY ON – FAST OFF)
Turn-On “A” (2.0 Amp Max) (Output)
(FAST ON – .5 sec DELAY OFF)
Battery +12V (Input)
Ignition (switched +12V) (Input)
Chassis Ground (Input)
Battery Replacement
(2) CR2032
+
–
+
–
+
–
+
–
Blue/Red
Blue/White
Not Used
Dk. Blue
10A Fuse
Black
Turn-On “B” = Amplifier(s)
Turn-On “A” = Signal Processor(s)
®®
Not Used
Front (L+) (Speaker Output)
Front (L–) (Speaker Output)
Front (R+) (Speaker Output)
Front (R–) (Speaker Output)
Rear (L+) (Speaker Output)
Rear (L–) (Speaker Output)
Rear (R+) (Speaker Output)
Rear (R–) (Speaker Output)
Front Output White (Left)
Front Output Red (Right)
Not Used
Not Used
®
RESET
FA-1610-A
FA-1608-A

AM / FM ST / Reproductor de CD’s
Frontal Extraible con Mando a Distáncia
Páginas de Referencia
para la Instalación
RFX-8115
Amplitud del panel Lengüetas a doblar
ABCDE FG
1.2mm to 2.5mm x x x
2.4mm to 3.5mm x x x
3.6mm to 4.5mm x x
4.6mm to 5.5mm x x x
5.6mm to 7.0mm x x
7.0mm to 12mm x x x
12.0mm to 15mm x x
Vista lateral desde
la Izquierda Vista en planta
G G C
CC B F A D E E D AF B C
Antena
N/C
N/C
3
4
5
6
7
8
9
10
1
2
(Mirando hacia el
Conector de la Radio)
Derecha Frontal (–)
Derecha Frontal (+)
N/C
N/C
N/C
N/C
10
9
8
7
6
5
4
3
2
1
Conector RCA
Conector de Alimentación
22 21 20 19 18 17 16 15 14 13 12
1110987654321
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
N/C
Encendido “B”
Encendido “A”
Encendido “C“
Silenciador de Audio
No Utilizado
Posterior (L–)
Posterior (R–)
Frontal (L–)
Frontal (R–)
Toma de tierra del chasis
(Azul/Blanco)
(Azul Claro)
(Azul/Rojo)
(Marrón)
(Verde/Blanco)
(Verde/Negro)
(Viloeta/Negro)
(Blanco/Negro)
(Gris/Negro)
(Negro)
N/C
No Utilizado
No Utilizado
Alimentación +12V
N/C
No Utilizado
Posterior (L+)
Posterior (R+)
Frontal (L+)
Frontal (R+)
Batería +12V
(Naranja/Blanco)
(Naranja)
(Rojo)
(Azul Oscuro)
(Verde)
(Violeta)
(Blanco)
(Gris)
(Amarillo)
Ángulos Máximo y
Mínimo para montaje
20°
20°
Entrada de
Antena
Blanco
Blanco/Negro
Gris
Gris/Negro
Verde
Verde/Negro
Violeta
Violeta/Blanco
Naranja/Blanco
Naranja
Verde/Blanco
Marrón
Amarillo
Rojo
Azul Claro
Silenciador de Audio (GND para ser activado)
(Entrada)
Sistema de 4
altavoces
Encendido “C” (300mA Máx) (Salida)
(Pulsado 500ms)
Encendido “B” (300mA Máx) (Salida)
(Dealy de 0.5 segundos conectado apagado Rápido)
Encendido “A” (2.0 Amp Máx) (Salida)
(Encendido Rápido Delay de 0.5 segundos desconcectado)
Batería +12V (Entrada)
Ignition (switched +12V) (Entrada)
Toma de tierra del Chasis (Entrada)
+
–
+
–
+
–
+
–
Azul/Rojo
Azul/Blanco
No Utilizado
Azul Oscuro
Fusible de
10 Amperios
Negro
Encendido “B” = Amplificadores
Encendido “A” = Procesador de Señal
®®
Salida para el altavoz frontal (R–)
Salida para el altavoz posterior (R–)
Salida Frontal Rojo (Derecha)
No Utilizado
No Utilizado
No Utilizado
Salida para el altavoz posterior (R+)
Salida para el altavoz posterior (L–)
Salida para el altavoz posterior (L+)
Salida para el altavoz frontal (R+)
Salida para el altavoz frontal (L–)
Salida para el altavoz frontal (L+)
Izquierda Frontal (–)
Izquierda Frontal (+)
Salida Frontal Blanco (Izquierda)
(Mirando hacia el Conector de la Radio)
Mando a distancia
por Infrarrojos
RFX-1110
Pulse el botón R
Diamante para el
encendido “C”
Cambio de batería
(2) CR2032
1-6
+
–
®
Sistema de 2
altavoces
RESET
de instrumental
Vista lateral desde
la Derecha
FA-1610-A
FA-1608-A

OM / FM ST / Lecteur CD
Face détachable
Schéma
d’Installation
RFX-8115
Epaisseur du tableau de bord Languettes à plier
ABCDE FG
1.2mm to 2.5mm x x x
2.4mm to 3.5mm x x x
3.6mm to 4.5mm x x
4.6mm to 5.5mm x x x
5.6mm to 7.0mm x x
7.0mm to 12mm x x x
12.0mm to 15mm x x
Vue de gauche Vue de droitVue du haut
G G C
CC B F A D E E D AF B C
Antenne
N/C
N/C
3
4
5
6
7
8
9
10
1
2
(Vue sur le connecteur
de la radio)
Avant droite (–)
Avant droite (+)
Avant gauche (–)
Avant gauche (+)
N/C
N/C
N/C
N/C
10
9
8
7
6
5
4
3
2
1
Cablage RCA
Cablage Alimentation
(Vue sur le connecteur de la radio)
22 21 20 19 18 17 16 15 14 13 12
1110987654321
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
N/C
Commande “B”
Commande “A”
Commande “C“
Atténuateur audio
Pas utilisé
Arrière (G–)
Arrière (D–)
Avant (G–)
Avant (D–)
Masse chassis
(Bleu/Blanc)
(Bleu clair)
(Bleu/Rouge)
(Brun)
(Vert/Blanc)
(Vert/Noir)
(Violet/Noir)
(Blanc/Noir)
(Gris/Noir)
(Noir)
N/C
Pas utilisé
Pas utilisé
Après Contact +12V
N/C
Pas utilisé
Arrière (G+)
Arrière (D+)
Avant (G+)
Avant (D+)
Batterie +12V
(Orange/Blanc)
(Orange)
(Rouge)
(Bleu foncé)
(Vert)
(Violet)
(Blanc)
(Gris)
(Jaune)
Angle de montage
maximum et minimum
20°
20°
Fiche
Antenne
Blanc
Blanc/Noir
Gris
Gris/Noir
Vert
Vert/Noir
Violet
Violet/Noir
Orange/Blanc
Orange
Vert/Blanc
Brun
Jaune
Rouge
Bleu clair
Pas utilisé
Installation 4 HP
Installation 2 HP
Télécommande IR
RFX-1110
Appuyer sur le bouton
rouge “Losange R” pour
activer la commande “C.”
Commande “C” (300mA Max) (Sortie)
(Impulsion 500mA)
Commande “B” (300mA Max) (Sortie)
(Délai d'allumage 0,5s – coupure rapide)
Commande “A” (2,0A Max) (Sortie)
(Allumage rapide – Délai de coupure 0,5s)
Batterie +12V (Entrée)
Après Contact +12V (entrée)
Masse Chassis (Entrée)
Batterie de
remplacement
(2) CR2032
+
–
+
–
+
–
+
–
Bleu/Rouge
Bleu/Blanc
Pas utilisé
Bleu foncé
Fusible 10A
Noir
Commande “B” = Amplificateur(s)
Commande “A” = Processeur(s) de signal
®®
Pas utilisé
Avant (G+) (Sortie HP)
Avant (G–) (Sortie HP)
Avant (D+) (Sortie HP)
Avant (D–) (Sortie HP)
Arrière (G+) (Sortie HP)
Arrière (G–) (Sortie HP)
Arrière (D+) (Sortie HP)
Arrière (D–) (Sortie HP)
Sortie avant gauche (blanc)
Sortie avant droite (rouge)
Atténuateur audio (mute) – commande
par négatif (Entrée)
Pas utilisé
1-6
+
–
®
RESET
FA-1610-A
FA-1608-A

AM / FM ST / CD Spieler
Abnehmbares Bedienteil Installations
Beiblatt
RFX-8115
Dicke des Instrumenten-Panels Klammern zu biegen
ABCDE FG
1.2mm to 2.5mm x x x
2.4mm to 3.5mm x x x
3.6mm to 4.5mm x x
4.6mm to 5.5mm x x x
5.6mm to 7.0mm x x
7.0mm to 12mm x x x
12.0mm to 15mm x x
Linke
Seitenansicht
Rechte
Weitenansicht
Draufsicht
G G C
CC B F A D E E D AF B C
Antenne
N/C
N/C
3
4
5
6
7
8
9
10
1
2
N/C
N/C
N/C
N/C
10
9
8
7
6
5
4
3
2
1
22 21 20 19 18 17 16 15 14 13 12
1110987654321
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
20°
20°
Orange
+
–
+
–
+
–
+
–
®®
Nicht benutzt
Weiβ
Weiβ/Schwarz
Grau
Grau/Schwarz
Grün
Grün/Schwarz
Violett
Violett/Schwarz
Orange/Weiβ
Orange
Grün/Weiβ
Braun
Gelb
Rot
Hellblau
4 Lautsprecher System
2 Lautsprecher
System
Blau/Rot
Blau/Weiβ
Dunkelblau
Schwarz
Stummschaltung (GND zum aktivieren)
(Eingang)
Einschaltstrom “C” (300mA Max)(Ausgang)
(Pulsed 500ms)
Einschaltstrom “B” (300mA Max)(Ausgang)
(.5 sec Einschaltverzögerung-Schnelles Ausschalten)
Batterie +12V (Eingang)
Zündung (schaltbar +12V) (Eingang)
Karosserie Masse (Eingang)
10A Sicherung
Einschaltstrom “B” = Verstärker(s)
Einschaltstrom “A” = Signal Prozessor(s)
Vorne (L+) (Lautsprecherausgang)
Vorne (L–) (Lautsprecherausgang)
Vorne (R+) (Lautsprecherausgang)
Vorne (R–) (Lautsprecherausgang)
Hinten (L+) (Lautsprecherausgang)
Hinten (L–) (Lautsprecherausgang)
Hinten (R+) (Lautsprecherausgang)
Hinten (R–) (Lautsprecherausgang)
Einschaltstrom “A” (2.0 Amp Max) (Ausgang)
(Schnelles Einschalten – .5 sec Ausschaltverzögerung)
Nicht benutzt
Nicht benutzt
Nicht benutzt
Strom Stecker
(Blick in den Radio Anschluβ)
N/C
Einschaltstrom “B”
Einschaltstrom “A”
Einschaltstrom “C“
Stummschaltung
Nicht benutzt
Hinten (L–)
Hinten (R–)
Vorne (L–)
Vorne (R–)
Karosserie Masse
(Blau/Weiβ)
(Hellblau)
(Blau/Rot)
(Braun)
(Grün/Weiβ)
(Grün/Schwarz)
(Violett/Schwarz)
(Weiβ/Schwarz)
(Grau/Schwarz)
(Schwarz)
N/C
Nicht benutzt
Nicht benutzt
Ignition +12V
N/C
Nicht benutzt
Hinten (L+)
Hinten (R+)
Vorne (L+)
Vorne (R+)
Batterie +12V
(Orange/ Weiβ)
(Orange)
(Rot)
(Dunkelblau)
(Grün)
(Violett)
(
Weiβ) )
(Grau)
(Gelb)
IR Fernbedienung
RFX-1110
Drücke “Diamond R”
Taste, um auf “C”
Einschaltimpuls zu geben
Ersatzbatterien
(2) CR2032
1-6
+
–
®
(Blick in den Radio
Anschluβ)
Vorne rechts (–)
Vorne links (+)
RCA Adapter
Ausgang Vorne rot (rechts)
Ausgang Hinten weiβ(links)
Vorne rechts (–)
Vorne links (+)
Minimaler & Maximaler
Einbauwinkel
Antenneneigang
RESET
FA-1610-A
FA-1608-A

AM / FM ST / CD Player
Frontalino Estraibile
Istruzioni di
Installazione
RFX-8115
Spessore del pannello Alette da piegare
ABCDE FG
1.2mm to 2.5mm x x x
2.4mm to 3.5mm x x x
3.6mm to 4.5mm x x
4.6mm to 5.5mm x x x
5.6mm to 7.0mm x x
7.0mm to 12mm x x x
12.0mm to 15mm x x
Vista da sinistra Vista da destraVista dall’alto
G G C
CC B F A D E E D AF B C
Antenna
N/C
N/C
3
4
5
6
7
8
9
10
1
2
(Guardando il
connettore della radio)
Anteriori (R–)
Anteriori (R+)
Anteriori (L–)
Anteriori (L+)
N/C
N/C
N/C
N/C
10
9
8
7
6
5
4
3
2
1
Connettore RCA
Connettore di alimentazione
(Guardando il connettore della radio)
22 21 20 19 18 17 16 15 14 13 12
1110987654321
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
N/C
Consenso “B”
Consenso “A”
Consenso “C“
Audio Mute
Non impiegato
Posteriori (L–)
Posteriori (R–)
Anteriori (L–)
Anteriori (R–)
Massa del telaio
(Blu/Bianco)
(Azzurro)
(Blu/Rosso)
(Marrone)
(Verde/Bianco)
(Verde/Nero)
(Viola/Nero)
(Bianco/Nero)
(Grigio/Nero)
(Nero)
N/C
Non impiegato
Non impiegato
+12V sotto chiave
N/C
Non impiegato
Posteriori (L+)
Posteriori (R+)
Anteriori (L+)
Anteriori (R+)
+12V batteria
(Arancione/Bianco)
(Arancione)
(Rosso)
(Blu Scuro)
(Verde)
(Viola)
(Bianco)
(Grigio)
(Giallo)
Angolo minimo e
massimo di installazione
20°
20°
Ingresso
Antenna
Bianco
Bianco/Nero
Grigio
Grigio/Nero
Verde
Verde/Nero
Viola
Viola/Nero
Arancione/Bianco
Arancione
Verde/Bianco
Marrone
Giallo
Rosso
Azzurro
Audio Mute (Massa per attivare) (ingresso)
Sistema con 4
altoparlanti
Telecomando
infrarossi
RFX-1110
Premere il tasto
“DIAMOND R” per
il consenso “C”
Consenso “C” (300mA Max) (Uscita)
(Impulsi 500ms)
Consenso “B” (300mA Max) (Uscita)
(0,5 sec accensione ritardo – spegnimento immediato)
Consenso “A” (2.0 Amp Max) (Uscita)
(accensione immediata, ritardo 0,5 sec spegnimento)
+12V batteria (Ingresso)
Ignition (switched +12V) (ingresso)
Massa del telaio (ingresso)
Sostituzione batteria
(2) CR2032
+
–
+
–
+
–
+
–
Blu/Rosso
Blu/Bianco
Non impiegato
Blu scuro
Fusibile 10A
Nero
Consenso “B” = Amplificatore
Consenso “A” = Processore di Signale
®®
Non impiegato
Anteriori (L+) (Uscita altoparlanti)
Posteriori (L+) (Uscita altoparlanti)
Uscita Anteriori Bianco (sinistro)
Uscita Anteriori Rosso (destro)
Anteriori (L–) (Uscita altoparlanti)
Anteriori (R+) (Uscita altoparlanti)
Anteriori (R–) (Uscita altoparlanti)
Posteriori (L–) (Uscita altoparlanti)
Posteriori (R+) (Uscita altoparlanti)
Posteriori (R–) (Uscita altoparlanti)
1-6
+
–
®
Non impiegato
Non impiegato
Sistema con 2
altoparlanti
RESET
FA-1610-A
FA-1608-A

Rockford Fosgate
Rockford Corporation
546 South Rockford Drive
Tempe, Arizona 85281 U.S.A.
In U.S.A., [phone]
In Europe, Fax [phone]
In Japan, Fax [phone]
MAN-1604-A
3/97
Sintonizzatore a copertura mondiale
Le bande di frequenza del sintonizzatore possono
essere programmate per adeguarsi ai diversi sistemi
dei paesi (Giappone escluso).
1.Tenere premuto DSPL per 2 secondi
2.Premere il tasto Onda Sinusoidale (Tuner)
3.Premere piú volte SEL perselezionaretraAMERI-
CAS, EUR/AUST e SAUDI
Nota: per l'Italia selezionare EUR/AUST
Weltweiter Tuner
Das Frequenzband des Tuners kann programmiert
werden,uminden verschiedenen Ländern einwandfrei
zu funktionieren (ausgenommen Japan).
1.Drücken und halten Sie DSPL für zwei Sekunden
2.Drücken Sie SINE WAVE (Tuner)
3.Drücken Sie SEL, um zwischen AMERICAS, EUR/
AUST und SAUDI umzuschalten
DEUTSCH ITALIANO
Sintonizador Standard Mundial
La banda de frecuencias del sintonizador puede ser
programdaparasercompatibleconlosdiferentescódigos
de los países (excepto Japón)
1.Mantenga pulsado el botón DSPL durante dos
segundos
2.Pulse el botón con la onda senoidal (Radio)
3.Pulse SEL para cambiar secuencialmente entre
AMERICAS,EUROPA/AUSTRALIAyARABIASAUDI
ESPAÑOL
World Wide Tuner
The frequency band on the tuner can be programmed
toconform withdifferent country codes (except Japan)
1.Press and hold DSPL for two seconds
2. Press SINE WAVE (Tuner)
3. Press SEL to cycle through AMERICAS, EUR/
AUST and SAUDI
ENGLISH
World Wide Tuner
La bande de fréquence peut être programmé pour
convenir au codes des différent pays (excepté le Japon).
1.Enfoncez et tenez DSPL enfoncé durant deux
secondes
2. Enfoncez SINE WAVE (Tuner)
3. Enfoncez SEL pour parcourir AMERICAS, EUR/
AUST et SAUDI
FRANÇAIS
MADE IN MEXICO
Designed and Engineered in the USA
by Delco Electronics and Rockford Fosgate
This product was assembled by Delco Electronics at Deltronicos de Matamoros,
Mexico. Due to the global nature of their manufacturing facilities and the electronics
parts industry in general, some parts may be manufactured in other countries.
