Ryobi PCL265 User manual

General Power Tool
Safety Warnings..............................2-3
Impact Wrench Safety Warnings........4
Symbols..............................................5
Features..............................................5
Assembly............................................6
Operation.........................................6-7
Maintenance.......................................8
Illustrations .........................................9
Parts Ordering and
Service ................................Back page
Avertissements de sécurité générales
relatives aux outils électriques........2-3
Avertissements de sécurité relatifs
au clé à chocs....................................4
Symboles............................................5
Caractéristiques .................................5
Assemblage........................................6
Utilisation ........................................6-7
Entretien .............................................8
Illustrations .........................................9
Commande de pièces et
dépannage ........................Page arrière
Advertencias de seguridad
para herramientas eléctrica........... 2-3
Advertencias de seguridad
destornillador de impacto..................4
Símbolos............................................5
Características...................................5
Armado..............................................6
Funcionamiento............................. 6-7
Mantenimiento...................................8
Illustraciones......................................9
Pedidos de piezas y
servicio .........................Pág. posterior
WARNING:
To reduce the risk of injury, the user
must read and understand the opera-
tor’s manual before using this product.
AVERTISSEMENT :
Pour réduire les risques de blessures,
l’utilisateur doit lire et veiller à bien com-
prendre le manuel d’utilisation avant
d’utiliser ce produit.
ADVERTENCIA:
Para reducir el riesgo de lesiones, el
usuario debe leer y comprender el
manual del operador antes de usar este
producto.
TABLE OF CONTENTS TABLE DES MATIÈRES ÍNDICE DE CONTENIDO
SAVE THIS MANUAL
FOR FUTURE REFERENCE
GUARDE ESTE MANUAL
PARA FUTURAS CONSULTAS
CONSERVER CE MANUEL
POUR FUTURE RÉFÉRENCE
OPERATOR’S MANUAL
MANUEL D’UTILISATION
MANUAL DEL OPERADOR
1/2 in. 18 VOLT
IMPACT WRENCH
CLÉ À CHOCS
13 mm (1/2 po) 18 V
LLAVE DE IMPACTO
13 mm (1/2 pulg.) 18 V
PCL265

2 - English
WARNING
Read all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated(corded)power tool or battery-operated (cordless)
power tool.
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric
shock.
Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk
of electric shock.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
If operating a power tool in a damp location is
unavoidable, use a ground fault circuit interrupter
(GFCI) protected supply. Use of a GFCI reduces the
risk of electric shock.
Use this product only with batteries and chargers
listed in tool/appliance/battery pack/charger
correlation supplement 987000-432.
PERSONAL SAFETY
Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while operating
power tools may result in serious personal injury.
Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites
accidents.
Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewelry.
Keep your hair and clothing away from moving parts.
Loose clothes, jewelry or long hair can be caught in
moving parts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
Do not wear loose clothing or jewelry. Contain long hair.
Looseclothes,jewelry,orlonghaircanbedrawnintoairvents.
Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of the
power tool in unexpected situations.
GENERAL POWER TOOL SAFETY WARNINGS

3 - English
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool
for your application. The correct power tool will do the
job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from the
power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power
tool accidentally.
Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of
the tool in unexpected situations.
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or a fire.
Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from
the battery may cause irritation or burns.
Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion, or risk
of injury.
Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or temperature
above 265°F may cause explosion.
Follow all charging instructions and do not charge the
battery pack or tool outside the temperature range
specified in the instructions. Charging improperly or at
temperatures outside the specified range may damage
the battery and increase the risk of fire.
SERVICE
Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service provider.
GENERAL POWER TOOL SAFETY WARNINGS

4 - English
Hold the power tool by insulated gripping surfaces,
when performing an operation where the fastener may
contact hidden wiring. Fasteners contacting a “live” wire
may make exposed metal parts of the power tool “live”
and could give the operator an electric shock.
Know your power tool. Read operator’s manual care-
fully. Learn its applications and limitations, as well as
the specific potential hazards related to this power
tool. Following this rule will reduce the risk of electric
shock, fire, or serious injury.
Always wear eye protection with side shields marked
to comply with ANSI Z87.1 when assembling parts,
operating the tool, or performing maintenance. Fol-
lowing this rule will reduce the risk of serious personal
injury.
Protect your lungs. Wear a face or dust mask if the
operation is dusty. Following this rule will reduce the risk
of serious personal injury.
Wear ear protectors with impact wrench. Exposure to
noise can cause hearing loss.
Protect your hearing. Wear hearing protection espe-
cially during extended periods of operation. Following
this rule will reduce the risk of serious personal injury. If
at any time you become uncomfortable or the length of
your task is long, hearing protection is recommended.
Battery tools do not have to be plugged into an elec-
trical outlet; therefore, they are always in operating
condition. Be aware of possible hazards when not
using your battery tool or when changing accessories.
Following this rule will reduce the risk of electric shock,
fire, or serious personal injury.
Do not place battery tools or their batteries near fire
or heat. This will reduce the risk of explosion and possibly
injury.
Do not crush, drop or damage battery pack. Do not
use a battery pack or charger that has been dropped
or received a sharp blow. A damaged battery is subject
to explosion. Properly dispose of a dropped or damaged
battery immediately.
Batteries can explode in the presence of a source
of ignition, such as a pilot light. To reduce the risk of
serious personal injury, never use any cordless product
in the presence of open flame. An exploded battery can
propel debris and chemicals. If exposed, flush with water
immediately.
Under extreme usage or temperature conditions, bat-
tery leakage may occur. If liquid comes in contact with
your skin, wash immediately with soap and water. If
liquid gets into your eyes, flush them with clean water
for at least 10 minutes, then seek immediate medical
attention. Following this rule will reduce the risk of seri-
ous personal injury.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this tool. If you
loan someone this tool, loan them these instructions also.
IMPACT WRENCH SAFETY WARNINGS

5 - English
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Indicates a potential personal injury hazard.
Read Operator’s Manual To reducethe riskofinjury, usermustreadandunderstand operator’s
manual before using this product.
Eye Protection Always wear eye protection with side shields marked to comply
with ANSI Z87.1.
Wet Conditions Alert
Do not expose battery, battery compartment, or electronic
components to rain, water, or liquids. Do not charge battery or
expose product to rain or damp locations.
Recycle Symbol
This product uses lithium-ion (Li-ion) batteries. Local, state, or
federal laws may prohibit disposal of batteries in ordinary trash.
Consult your local waste authority for information regarding
available recycling and/or disposal options.
V Volts Voltage
min Minutes Time
Direct Current Type or a characteristic of current
n
o
No Load Speed Rotational speed, at no load
.../min Per Minute Revolutions, strokes, surface speed, orbits etc., per minute
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicates a hazardous situation, which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a hazardous situation, which, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a hazardous situation, that, if not avoided, may result in minor or
moderate injury.
NOTICE: (Without Safety Alert Symbol) Indicates information considered important, but
not related to a potential injury (e.g. messages relating to property damage).
SYMBOLS
PRODUCT SPECIFICATIONS
Speed ..................................................0-2,700/min. (RPM)
Anvil..........................................................................1/2 in.
Impacts per minute ........................................0-3,100/min
Torque.................................................................375 ft-lbs.
FEATURES

6 - English
WARNING:
Do not allow familiarity with this product to make you
careless. Remember that a careless fraction of a second
is sufficient to inflict serious injury.
WARNING:
Always remove battery pack from the tool when you are
assembling parts, making adjustments, cleaning, or when
not in use. Removing battery pack will prevent accidental
starting that could cause serious personal injury.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes and other possible
serious injuries.
WARNING:
Do not use any attachments or accessories not
recommended by the manufacturer of this product. The
use of attachments or accessories not recommended
can result in serious personal injury.
APPLICATIONS
You may use this tool for the purposes listed below:
Driving nuts and bolts using an impact socket
INSTALLING/REMOVING BELT HOOK
(NOT INCLUDED)
See Figure 1, page 9.
The belt hook may be installed on either side of the housing.
Align hole in belt hook with hole in the housing.
Install screw to secure belt hook in place.
To uninstall, remove screw then remove belt hook.
VARIABLE SPEED SWITCH TRIGGER
See Figure 2, page 9.
The variable speed switch trigger delivers higher speed with
increased trigger pressure and lower speed with decreased
trigger pressure.
To turn the tool ON, depress the switch trigger. To turn it
OFF, release the switch trigger and allow the anvil to come
to a complete stop.
NOTE: A whistling or ringing noise coming from the switch
during use is a normal part of the switch function.
DIRECTION OF ROTATION SELECTOR
(FORWARD/REVERSE/ CENTER LOCK)
See Figure 2, page 9.
Set the direction of rotation selector in the OFF (center lock)
positiontolocktheswitchtriggerand help preventaccidental
starting when not in use.
Position the direction of rotation selector to the left of the
switch trigger for forward operation. Position the selector to
the right of the switch trigger to reverse the direction.
NOTE: The tool will not run unless the direction of rotation
selector is pushed fully to the left or right.
WARNING:
Do not use this product if it is not completely assembled
or if any parts appear to be missing or damaged. Use of
a product that is not properly and completely assembled
or with damaged or missing parts could result in serious
personal injury.
WARNING:
Do not attempt to modify this product or create
accessories or attachments not recommended for use
with this product. Any such alteration or modification is
misuse and could result in a hazardous condition leading
to possible serious personal injury.
If any parts are damaged or missing, please call 1-800-525-2579 for assistance.
ASSEMBLY
OPERATION

7 - English
OPERATION
NOTICE:
To prevent gear damage, always allow the anvil to come
to a complete stop before changing the direction of
rotation.
WARNING:
Battery tools are always in operating condition. Lock the
switch when not in use or carrying at your side, when in-
stalling or removing the battery pack, and when installing
or removing sockets.
INSTALLING/ REMOVING BATTERY PACK
See Figure 3, page 9.
 Locktheswitchtrigger.
 Insertthebatterypackintotheproductasshown.
Make sure the latches on each side of the battery pack
snap into place and that battery pack is secured in the
product before beginning operation.
Depress the latches to remove the battery pack.
Forcompletecharginginstructions,seetheoperator’s manu-
als for your battery pack and charger.
INSTALLING AND REMOVING SOCKETS
See Figure 4, page 9.
Use only sockets designed for impact wrenches. Always
select the correct size impact socket for nuts and bolts.
CAUTION:
Using the wrong size socket may damage the nut or
bolt and cause the fastening torque to be inaccurate or
inconsistent.
Remove the battery pack.
Push the socket onto the anvil until the friction ring locks
it into place.
To remove the socket, pull it away from the anvil.
LED LIGHT
See Figure 5, page 9.
The LED light at the base of the tool illuminates when the
switch trigger is depressed.
The LED light illuminates only when there is a charged bat-
tery pack in the tool.
OPERATING THE IMPACT WRENCH
See Figures 6 - 7, page 9.
CAUTION:
The metal surface may become hot during use. Avoid
contact with it to avoid possible burn injury.
Proper fastening torque may be determined by the kind of
bolt, the size of the bolt or the material or the workpiece. It
is helpful to perform a test operation to determine the proper
fastening time for the nut or bolt you are using.
Hold the tool with one hand and pointed straight at the
nut or bolt.
Depress the switch and fasten for the proper fastening
time.
Remove the impact wrench from the nut or bolt.
Check the torque with a torque wrench.
NOTICE:
Do not use this tool to install lug nuts on wheels without
a torque limiting device. Doing so could result in galled
or broken lugs.
IMPACT TIME
Many variables exist that will cause the maximum torque
to the fastener to vary considerably, including the size and
threading of the fastener, lubrication, material hardness, and
environmental conditions.
NOTE: Using a universal joint or extension bar may reduce
the fastening force of the impact wrench and require longer
fastening time.
NOTICE:
After the head of a nut or bolt has seated, additional im-
pacting will increase the chance of shearing bolts, nuts,
sockets or tearing into wood.
ELECTRIC BRAKE
The electric brake will stop the socket rotation after the
operator releases the switch trigger.
NOTE: MAINTENANCE INSTRUCTIONS BEGIN ON PAGE 8
FOLLOWING FRENCH AND SPANISH LANGUAGE SECTIONS.
ILLUSTRATIONS START ON PAGE 9.
