Ryval V752 User manual

Ryval
Phoenix Gold
Class A/B 2 Channel Amplifi er Product Manual
V752
V1502
2 Channel Power Amplifi ers
Amplifi cateurs à 2 canaux
12dB per octave Variable Lowpass Crossovers
Croisements passe-bas variables 12dB
3 Position Confi guration Switch LP/Bypass/HP (Lowpass, By-Pass, Highpass)
Commutateur de confi guration LP/Bypass/HP (passe-bas, contournement, passe-haut)
Auxiliary Outputs
Sorties auxiliaires
Speaker Level Inputs
Entrées de niveau d’amplifi cateur
Remote Monitoring Display (RMD) Port
Port d’affi chage de contrôle à distance (RMD)
Extruded Aluminum Heat Sink
Extruded Aluminum Heat Sink
Drain thermique en aluminium extrudé
Drain thermique en aluminium extrudé
Congratulations on your purchase of high quality Phoenix Gold audio electronics. At Phoenix Gold our highest concern is musical reproduc-
tion. We appreciate that you chose our product. Through years of engineering expertise and critical testing procedures, we have created a
wide range of products to give your system all the clarity and richness you deserve.
Great product and competent installations are only one piece of the puzzle when it comes to your system. Make sure that your install is using
only the best installation accessories. Phoenix Gold manufactures everything from RCA cables and speaker wire to power/ground cable and
battery connectors. With proper installation and accessories your system will last for years and perform to peak audio standards.
Please read your warranty and retain your receipt and original carton for possible future use.
For more information about Phoenix Gold electronics, speakers and accessories please visit
Phoenix Gold - www.phoenixgold.com

Phoenix Gold - www.phoenixgold.com
Ryval ®Amplifi ers
2 CHANNEL POWER AMP OWNERS MANUAL
1. STATUS LED
Green- Amplifi er is powered “ON”
2. PROTECT LED
Red- If the internal heatsink reaches 80 degrees Celsius the amplifi er shuts down until the internal
temperature falls below 75 degrees. It also lights if a direct short is present on the speaker outputs.
If this occurs, check for shorted speakers and cycle power to resume operation.
3. REMOTE TURN-ON TERMINAL
Connect to a switched 12 Vdc source such as the headunit’s “remote” or power antenna wire.
4. B- TERMINAL (CHASSIS GROUND)
Connect to a clean, solid chassis ground. Remove all paint and dirt from the chassis connection point.
Minimum cable size is 8 gauge. Keep the cable as short as possible.
5. B+ TERMINAL (BATTERY POSITIVE)
Connect directly to the positive battery terminal. Minimum cable size is 8 gauge. Remember to properly
fuse this cable within 18 inches of the positive battery terminal.
6. SPEAKER OUTPUTS
Used to connect the amplifi er to speakers. Use the left (+) and right (–) terminals for bridged mode. Minimum speaker
cable size is 16 gauge (PG # SS162 or QS162). Use 12 gauge for bridged operation (SS122 or QS122). Minimum
impedance is 4 ohm bridged or 2 ohm stereo.
7. FUSES
Used to protect the amplifi er. If replacement is necessary, use the same size and type indicated on the
endpannel.
Never use a fuse with a higher amp rating.
8. REMOTE VOLTAGE DISPLAY INPUT (RMD)
Connect the optional RMD Voltage Display to this jack.
9. CROSSOVER CONFIG SWITCH
This switch controls the type of signal that reaches the speaker outputs. For a 100Hz highpass signal set
the switch to “100Hz HP”. For continuously variable lowpass signal set the switch to “VAR LP”. For a full
range signal set the switch to “BY”.
10. LP FREQ CONTROL
Adjusts the low pass crossover point for the speaker outputs. The crossover frequency is adjustable from
40 to 400Hz with a 12dB per octave low pass slope.
11. RCA INPUT
Connect preamp signal cables from the head unit to these terminals. To maximize noise rejection, we
recommend using Genuine Phoenix Gold RCA interconnects.
12. AUX OUT
Provides a full range signal for an additional amplifi er.
13. SENS CONTROL
This control is used to reach maximum amplifi er power with a wide variety of headunits. The amplifi er is
more sensitive to input signal when set to 0.1 and less sensitive when set to 8; turning the control
clockwise will increase speaker output volume.
14. SPEAKER LEVEL INPUT
Connect headunits speaker level outputs to these terminals using the supplied connector. The speaker
level input accepts a wide voltage range (200mV to 20Vdc) used with most headunit and OEM systems.
Operational Details

Phoenix Gold - www.phoenixgold.com
Ryval ®Amplifi ers
2 CHANNEL POWER AMP OWNERS MANUAL
SPEAKER
LL
L
R
R
L
L
R
R
R
B B RMD
REM
POWER
POWER
PROTECT
752
752
BRIDGED
SPEAKER
LEVEL INPUT LP FREQ
40 Hz 400
VAR
LP
100 Hz
HP
BY
CONFIG SENS
0.1
V
9
1
3
6
9
14
11
11
13
8
12
5
2
4
RCA
INPUT
AUX
Ryval Series
V752 and V1502
Class A/B 2 Channel Amplifi ers
Stereo High Pass System
Lowest recommended Load:
2 Ohm Stereo
100Hz
HP
VAR
LP
BY
CONFIG
INPUT WOOFER TWEETER INPUT WOOFER TWEETER
L R RL
SPEAKER
BRIDGED
100Hz
HP
VAR
LP
BY
CONFIG
L R RL
SPEAKER
BRIDGED
V65C
Bridged lowpass system
Lowest recommended load:
4 Ohm Bridged
V10S/V12S
FIG 1.
FIG 2.

Phoenix Gold - www.phoenixgold.com
Ryval ®Amplifi ers
2 CHANNEL POWER AMP OWNERS MANUAL
INSTALLATION
Note: Verify that your vehicle does not have a positive ground electrical system, this is very rare. A positive ground system is
the reverse of most standard vehicles in that the + battery terminal is connected to the vehicle chassis and is typically found in
some older European vehicles. If you have any questions do not proceed until you have verifi ed this. If it is a positive ground
electrical system please contact your dealer for assistance.
Caution: Please follow all the installation recommendations and instructions in this manual. Installation in any
manner not outlined in the manual will void your warranty and may possibly cause damage to the vehicle
and/or the amplifi er.
Warning: The battery ground should remain DISCONNECTED at all stages of installation.
LOCATION/MOUNTING
When selecting a location to mount your amplifi er, please keep in mind that electronics are sensitive to vibration, moisture, and
heat. Make sure the amplifi er is mounted in an area with ample ventilation and is not exposed to moisture or external heat.
For proper cooling, it is recommended to mount the amplifi er horizontal or vertical but not upside-down. Automobiles have a
certain level of normal vibration and we have designed the product with this in mind, but excessive vibration may cause dam-
age over time. Using the amplifi er for a template, mark the mounting holes in your selected area while following the preceding
guidelines. Verify that you are not going to damage sensitive vehicle systems by drilling where you have selected (look for the
gas tank, wires, etc…).
Remove the amplifi er and pre-drill the locations for the screws/bolts that you have selected that fi t the amplifi er and your new
installation purposes. Permanently mount the amplifi er to the selected location.
(Figure 3. shows a typical system confi guration).
Note: It is best to mount the amplifi er to some form of insulating surface, such as MDF, so that the chassis of the amplifi er
does not come in contact with the vehicle chassis (if a single screw makes contact with both the amplifi er and vehicle chassis,
it is not insulated). This will reduce the possibility of any ground related noises and will shield minor amounts of
radiated noises.
Head Unit
Remote Lead
Battery Alternator
FIG 3.

Phoenix Gold - www.phoenixgold.com
Ryval ®Amplifi ers
2 CHANNEL POWER AMP OWNERS MANUAL
Installation Tip!
Real Power creates Heat!
Ryval amplifi ers are designed to give you every bit of electrical energy possible as output power. Be sure to install the amplifi er
in an area that has good airfl ow to prevent un-intentional thermal shut down.
Installation Tip!
System Tuning
Warning! Practice “Safe Sound” and Use Hearing Protection When Listening To Extreme Sound Pressure Levels
.
1
. Set the CONFIG switch according to your system setup.
2
. Set the amplifi er SENS Control to minimum (full counterclockwise).
3
. If using the amplifi er in Lowpass mode, set the LP FREQ control to the 10 O’clock position. This is a
starting point for the crossover; you may need to fi ne tune this setting later.
4
. Turn the headunit on with the volume set to minimum.
5
. Set the headunit’s tone controls, balance and fader to the center (fl at) position and turn off any
loudness features or other processing effects.
6
.
Play a CD that represents what type of music you usually listen to. Set the volume control of the head
unit up to 90% of total volume or until you hear distortion if you are using the headunit’s internal amplifi er.
7
. I
ncrease (turn clockwise) the SENS Control for the amplifi er until you hear distortion then slightly
decrease the sensitivity control until the distortion is not audible. The volume level should still be very loud,
but free from nearly all distortion
.
8
. With all speakers in the car playing, listen to the CD at this same high volume and make sure all
channels blend properly. For example, if the front speakers overpower the subwoofer, then slowly
balance the system so all channels reach maximum output without distortion at this volume level.
9
. The volume level set in step 6 will be your maximum volume level for your system. If you exceed this
level, the onset of distortion will become very noticeable.
Common Specifi cations
Frequency Response…………………………………………..20Hz – 20 kHz
Signal to Noise Ratio (1% THD+N)………………………………..>100dBA
RCA Signal Input Sensitivity…………….……….100mV – 9V (RCA Inputs)
Speaker Level Input Sensitivity………….200mV – 18V (High Level Inputs)
DC Input Range………………………………………………………9V – 18V
Typical Current Draw at Idle……………………………………………….1 A
Crossover Slope…………………………………………………12dB/Octave
Crossover Range (Lowpass)………………………………….40Hz – 400Hz
Minimum Load Stability……………………..2 Ohm Stereo/4 Ohm Bridged
V1502
Maximum Output Power
Into 4 Ohms Stereo……………………………………………………..300 X 2
Into 2 Ohms Stereo……………………………………………………..450 X 2
Into 4 Ohms Bridged…………………………………………………..1000 X 1
Continuous Output Power (14.4VDC and 1% THD+N CEA-2006 METHOD)
Into 4 Ohms Stereo…………………………………………………….150 X 2
Into 2 Ohms Stereo…………………………………………………….225 X 2
Into 4 Ohms Bridged…………………………………………………...500 X 1
Recommended Fuse Size……………………………….…2 X 35 AMP ATO
Chassis Dimensions…………..13.15” X 9.30” X 2.25” (334 X 236 X55mm)
V752
Maximum Output Power
Into 4 Ohms Stereo……………………………………………………..150 X 2
Into 2 Ohms Stereo……………………………………………………..240 X 2
Into 4 Ohms Bridged……………………………………………………500 X 1
Continuous Output Power (14.4VDC and 1% THD+N CEA-2006 METHOD)
Into 4 Ohms Stereo……………………………………………………...75 X 2
Into 2 Ohms Stereo…………………………………………………….120 X 2
Into 4 Ohms Bridged…………………………………………………...250 X 1
Recommended Fuse Size………………………………..…1 X 35 AMP ATO
Chassis Dimensions…………..7.90” X 9.30” X 2.25” (201 X 236 X 55mm)

Phoenix Gold - www.phoenixgold.com
Ryval ®Amplifi ers
2 CHANNEL POWER AMP OWNERS MANUAL
TROUBLE-SHOOTING
SYMPTOM: POSSIBLE CAUSE
No power:
Check voltage at amplifi er with a DMM (volt meter), B+ and REM (with source unit on) the voltage should register
between 12.2V-14.6V when using the attached ground lead of the amplifi er. Check fuse at amplifi er and at the battery. Use a
meter to verify connection from one end of the fuse to the other, breaks may not always be visible. If fuse is blown, check the
power wire and also the amplifi er for a short. If the short is in the power wire, repair it. If the short is in the amplifi er itself, see your
Phoenix Gold dealer. If no short is present replace the fuse.
Power without sound:
Turn the amplifi er off and check all input and output signal cables and power connections. Check the
speakers for shorts with a DMM (volt meter) or by connecting them to another audio source. After making sure everything is
correct, turn the amplifi er on again.
Power without sound and status LED is lit red:
The continuous red light of the power indicator signals a high internal operating
temperature, which results in the amplifi er switching off temporarily. When the amplifi er cools down to a safe level, the amp will
automatically restart. The continuous red light of the power indicator can also indicate a shorted speaker lead or battery voltage
that is either too high or too low for proper operation.
No sound from one side:
Check balance control. Check speaker connections. Check signal input connection.
Very low output:
Check your source unit’s fader control, or the amplifi er’s Input Sensitivity Level.
Frequent automatic amplifi er shut down:
A indicates that the amplifi er is operating at a continually undesirable high internal
temperature. High operating temperature can be caused by inadequate ventilation: Refer to the sub-section titled LOCATION for
better amplifi er location. High operating temperature can also be caused by an excessively low impedance load. For instance be-
low 2 ohms stereo or 4 ohms bridged. Check for bad speakers or bad passive crossover components. If all else fails, try rewiring
the entire system. High operating temperature can be caused by an incorrect input sensitivity level, refer to sub-section titled
INPUT SENSITIVITY ADJUSTMENT.
“Motor Boating” - the power indicator going off repeatedly when the audio system is on:
Check the amplifi er’s connection
to the battery. Check battery voltage. If low, recharge or replace battery. Check all ground connections.
Whining noise when engine is running:
Reroute power cable from battery to source unit directly (include fuse), bypassing the
battery terminal in the fuse box. Check power connections to be sure they are clean. Check the battery ground making sure the
battery terminals and chassis ground are clean. Run a ground wire from the source unit to the ground point of the amplifi er and
remove old source ground.
CAUTION:
Do not disconnect the Power Amplifi er’s ground when the system is on. This could damage the amplifi er.

Phoenix Gold - www.phoenixgold.com
Ryval ®Amplifi ers
2 CHANNEL POWER AMP OWNERS MANUAL
WARRANTY
LIMITED WARRANTY ELECTRONICS (USA)
Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) year from the
original date of purchase. This warranty is extended to two (2) years from the original date of purchase if product is installed by
an authorized Phoenix Gold reseller. The limited warranty period for factory refurbished products expires after ninety (90) days
from the original date of purchase. This limited warranty applies only to purchases from authorized Phoenix Gold resellers in the
United States, and is extended only to the original purchaser of this product. (See paragraph below for information regarding
purchases made in other countries.)
This warranty is not transferable from the original purchaser to any other party. If service is necessary under this warranty
Phoenix Gold will (at its discretion), repair or replace the defective product with new or remanufactured product at no charge.
Damage caused by the following is not covered under warranty: accident, misuse, abuse, product modifi cation or neglect, failure
to follow installation instructions, unauthorized repair attempts, misrepresentations by the seller. This warranty does not cover
incidental or consequential damages and does not cover the cost of removing or reinstalling the unit(s). Cosmetic damage due
to accident or normal wear and tear is not covered under warranty.
Any applicable implied warranties are limited in duration to the period of the express warranty as provided herein beginning with
the date of the original purchase at retail, and no warranties, whether express or implied, shall apply to this product thereafter.
Some states do not allow limitations on implied warranties, therefore these exclusions may not apply to you. This warranty gives
you specifi c legal rights, and you may also have other rights which vary from state to state.
WARRANTY IS VOID IF THE PRODUCT’S SERIAL NUMBER HAS BEEN REMOVED OR DEFACED.
IF YOU NEED SERVICE ON YOUR PHOENIX GOLD PRODUCT:
Phoenix Gold encourages product owners to fi rst contact their original Phoenix Gold reseller to determine whether the issue can
be resolved without sending the product back to Phoenix Gold.
If a return is necessary, the reseller will contact Phoenix Gold to obtain authorization for the return. All returns require a Return
Authorization number from Phoenix Gold before shipping the product to Phoenix Gold’s service facility. If a product owner is
unable to return a product to the original reseller, the owner can contact Phoenix Gold directly to obtain a Return Authorization
number. Units returned to Phoenix Gold without an RA number may be subject to refusal or delays.
All warranty returns should be sent to Phoenix Gold’s Product Service facility freight-prepaid and must be accompanied by proof
of purchase (a copy of the original sales receipt and in original packaging).
Non-defective items received may be returned freight-collect. Customer is responsible for shipping charges and insurance when
sending the product to Phoenix Gold. Freight damage on returns is not covered under warranty.
FOR SERVICE INFORMATION IN THE U.S.A. PLEASE CALL:
Phoenix Gold Customer Service: [phone] or [phone] during normal business hours (8:30 AM – 5:00 PM Pacifi c
Standard Time).
INTERNATIONAL WARRANTIES:
Products purchased outside the United States of America are covered only by that country’s Authorized Phoenix Gold reseller
and not by Phoenix Gold International, Inc. Consumers needing service or warranty information for these products must contact
that country’s reseller for information.
Use the following area record basic information
about your purchase.
Model Number
Serial Number (if available)
Date of Purchase
Store/Reseller Purchased from

Phoenix Gold - www.phoenixgold.com
GARANTIE
GARANTIE LIMITÉE SUR LES ARTICLES ÉLECTRONIQUES (É.-U)
Phoenix Gold garantit que ce produit est exempt de défaut matériel et de main d’oeuvre pour une période d’une (1) année à
compter de la date d’achat originale. Cette garantie est prolongée de deux (2) années à compter de la date d’achat originale à la
condition que le produit soit installé par un revendeur autorisé Phoenix Gold. La période de garantie limitée pour les produits re-
mis à neuf en usine expire après quatre-vingt-dix (90) jours de la date d’achat originale. Cette garantie limitée n’est valable que
pour les achats effectués auprès de revendeurs autorisés Phoenix Gold aux États-Unis et ne s’applique qu’à l’acheteur original
de ce produit. (Voir le paragraphe ci-dessous pour des renseignements concernant les achats effectués dans d’autres pays.)
Cette garantie n’est pas transférable de l’acheteur original à toute autre personne. Si une réparation s’avère nécessaire en vertu
de cette garantie, Phoenix Gold fera réparer ou remplacera (à sa discrétion) sans frais le produit défectueux avec un nouveau
ou un produit remis à neuf. Les dommages découlant des situations suivantes ne sont pas couverts par cette garantie : ac-
cident, mauvais usage, abus, modifi cation du produit ou négligence, omission de suivre les directives d’installation, tentatives
non autorisées de le réparer, assertions inexactes du vendeur. Cette garantie ne couvre pas les dommages occasionnels ou
corrélatifs ni le coût d’enlèvement ou de réinstallation du/des produit/s. Les dommages esthétiques découlant d’un accident ou
d’une usure normale ne sont pas couverts en vertu de cette garantie.
La durée de toutes les garanties implicites applicables est limitée à la période de la garantie expresse énoncée aux présen-
tes, et ce, à compter de la date de l’achat original au détail, et aucune autre garantie, exprès ou implicite, ne s’appliquera à ce
produit par la suite. Certains États ou certaines provinces n’autorisent pas de limites aux garanties implicites. Par conséquent,
ces exclusions peuvent ne pas s’appliquer pour vous. Cette garantie vous accorde des droits légaux spécifi ques et vous pouvez
avoir également d’autres droits qui varient d’un/e État/province à un/e autre.
CETTE GARANTIE SERA NULLE ET SANS EFFET SI LE NUMÉRO DE SÉRIE DE CE PRODUIT A ÉTÉ ENLEVÉ OU EFFACÉ.
SI VOTRE PRODUIT PHOENIX GOLD REQUIERT UNE RÉPARATION :
Phoenix Gold invite les propriétaires de ce produit à communiquer en premier avec leur revendeur Phoenix Gold original afi n
d’établir si le problème peut être résolu avant de le retourner à Phoenix Gold.
S’il est nécessaire de le retourner, le revendeur communiquera avec Phoenix Gold pour obtenir une autorisation. Toutes les
marchandises retournées doivent avoir un numéro d’autorisation de Phoenix Gold avant d’être expédiées au centre de service
de la compagnie. Le propriétaire d’un produit dans l’impossibilité de retourner celui-ci au revendeur original devra communiquer
directement avec Phoenix Gold pour obtenir un numéro d’autorisation. Les articles retournés à Phoenix Gold sans un numéro
d’autorisation risquent d’être refusés ou retardés.
Tous les retours sous garantie doivent être expédiés prépayés au centre de service de Phoenix Gold et ils doivent être
accompagnés d’une preuve d’achat (un exemplaire du reçu de caisse original).
Les articles reçus et non défectueux seront retournés et le fret payable à destination. Les frais d’expédition et d’assurance sont
à la charge du client lorsque le produit est expédié à Phoenix Gold. Les dommages causés au produit lors du transport ne sont
pas couverts par cette garantie.
POUR TOUTE INFORMATION SUR LES SERVICES AUX ÉTATS-UNIS, VEUILLEZ APPELER :
Service à la clientèle Phoenix Gold : [phone] ou [phone] lors des heures normales de bureau
(8 h 30 à 17 h - Heure normale du Pacifi que)
GARANTIES INTERNATIONALES
Les produits achetés à l’extérieur des États-Unis d’Amérique sont uniquement couverts par le revendeur autorisé Phoenix Gold
du pays et non pas par Phoenix Gold International, Inc. Les clients qui requièrent des services de réparation ou de l’information
sur la garantie de ces produits doivent communiquer avec le revendeur de leur pays.
Ryval ®Amplifi ers
2 CHANNEL POWER AMP OWNERS MANUAL
8100.0348A
