S.M.S.L DO300EX User manual

本書の内容は予告なく変更されることがあります
The contents of this manual may be changed with the edition, and are subject to change without notice.
使用说明书/USER MANUAL/取扱説明書
本说明书的内容可能会随版本更改如有变动, 恕不另行通知
Ver 1.0

安全注意事项
请将本音响系统安装在通风良好、阴凉、干燥、干净的位置，远离直射阳光热源、振动、灰尘、 潮
湿或寒冷。
只能使用本机指定的电压。使用高于指定数值的电压很危险，而且可能导致火灾，损坏本机或
造成人身伤害。对于使用高于指定电压造成的任何损害，
我司将不负任何责任。
不要试图自行改造或修理本机。如果需要任何服务，请与销售或者我司客服人员联系。不管有
任何理由，都没有打开机壳的必要。
如果打算长时间不使用本机（比如度假时），请从墙壁交流电源插座上断开电源线的连接。
重要提示：
本说明书所提到的产品规格和资讯仅供参考。如有内容更新，恕不另行通知。
保修条款
一、服务期限
佛山双木三林科技有限公司承诺产品的良好品质，产品自售出之后7天内正常使用情况下出现
故障，客户可以选择退货或者保修（不影响二次销售才可退货）。正常使用一年内出现故障可以
免费保修。
二、购买日期以销售商开出的购机发票或收据日期为准，网购可以交易截图为准。
三、有以下情况都不能享受“三包”服务
1.一切人为因素损坏，包括非正常工作环境下使用或不按照说明书使用。
2.用户私自拆机、改装、维修。
3.使用非指定或许可的配件造成损坏的。
4.机身的QC或保修贴损毁。
5.不能出示有效购机凭证。
6.不属于本公司产品。
四、保修方式为送修
此条款只适于中国大陆，其它地区请参考当地销售代理商的规定和国家法规。

特点
支持MQA解码，支持MQA-CD ;
全新第三代XMOS XU-316，PCM支持到32bit/768kHz，DSD支持到DSD512；
旗舰DAC芯片AK4191+AK4499EX,失真度低至0.00006%(-124dB)；
使用5片高端双运放及大量发烧元器件；
支持DOP独立显示功能,准确判断当前解码格式;
U S B 、光 纤 、同 轴 、I 2S支持DSD传输，同轴和光纤支持DOP64；
使用钢化玻璃全贴合彩色IPS显示屏；
内置低噪声电源处理，同时提高电源效率，功耗更低；
搭配多个低噪声稳压电源，提供稳定可靠高效低噪声的供电系统;
高通高端蓝牙芯片,支持LDAC(24bit/96kHz)，APTX/HD，SBC，AAC；
高品质全铝合金外壳,支持高品质镀金输入输出连接端子；
日本音频协会(JAS)Hi-Res认证；
配备遥控器和全功能遥控。

技术参数
SMSL保留在不另行通知的情况下进行可能导致规格或特性更改的改进的权利。
输入方式..............................................................................................................USB/光纤/同轴/蓝牙/I2S
输出方式......................................................................................................单端耳放/单端线路/平衡线路
THD+N..........................................................................................................0.00006%(-124dB)(UN-WTD)
HPA THD+N....................................................................................................0.0001%(-120dB)(UN-WTD)
线路输出幅度.............................................................................................................................5Vrms(XLR)
........................................................................................................................................2.5Vrms(RCA)
耳放输出功率..............................................................................................................................2Wx2(16Ω)
......................................................................................................................................................1Wx2(32Ω)
输出阻抗...................................................................................................线路XLR 200Ω
...................................................................................................................RCA 100Ω
...................................................................................................................耳放 接近0Ω
耳放增益控制...........................................................................................低增益 0dB
...................................................................................................................高增益 +7dB
动态范围....................................................................................................XLR 132dB
....................................................................................................................HPA 127dB
信噪比........................................................................................................XLR 132dB
....................................................................................................................HPA 127dB
USB传输方式..................................................................................................................................异步传输
USB兼容性...................................................................................Windows 7 / 8 / 8.1 / 10 / 11(需要驱动)
Mac OSX10.6以上、 Linux(不需要驱动)
MQA decoder....................................................................................................................USB / 光纤 / 同轴
采样率与位深 USB PCM 44.1~768kHz(32bit)
DSD 2.8224~22.5792MHz(1bit)
DoP DoP64~DoP256
光纤/同轴 44.1~192kHz(24bit)
DoP DoP64
蓝牙规格...............................................................5.1(支持SBC,AAC,aptX,aptX HD,LDAC(24bit/96kHz))
消耗功率................................................................................................................................................<20W
待机功耗..............................................................................................................................................<0.5W
体积......................................................................................................................
222x39x207mm (WxHxD)
重量........................................................................................................................................1.54
kg/3.40lbs

关于遥控器
如果遥控器距离本机很近时操作仍无效，请用新电池更换。
如果要长时间不使用遥控器，请取出遥控器的电池。
按照电池处置的地方性法规处置废旧电池。
遥控器的使用
遥控器请使用2节7号(AAA)电池 。
开关机
音量加
音量减
进入二级菜单
向上
返回
向下
静音
FN按键（在菜单中定义）
输入选择
进入菜单/确认

部件介绍
41 2 3 56
9
8
13 14
121110
7
4.4mm耳机插口 6.35mm耳机插口
5 6
单端线路输出 9
78
指示灯显示屏 红外接收窗
功能旋钮
12 3
4
蓝牙天线 平衡线路输出
10 11 I2S输入
12
光纤输入
13 14
同轴输入
USB输入 电源开关
DO300EX包装清单
1 x SMSL DO300EX 1 x 遥控器 1 x 蓝牙天线
1 x USB线 1 x AC电源线 1 x 说明书
1 x 保修卡

功能介绍
INPUTS (输入方式)
OUTPUTS (输出方式)
PCM FILTER (PCM滤波器)
HPA GAIN(耳放增益)
LOW (低增益)
HIGH (高增益)
USB (USB输入)
BLUETOOTH (蓝牙输入)
OPTICAL (光纤输入)
COAXIAL (同轴输入)
I2S(HDMI) (I2S输入)
SHARP ROLL-OFF (快速滚降)
SLOW ROLL-OFF (慢速滚降)
SHORT SHARP (短延时快速滚降)
SHORT SLOW (短延时慢速滚降)
SUPER SLOW (超级慢速滚降)
LOW DISPERSION (低分散延时)
ALL LINE OUT (全部输出)
HEADPHONE OUT (耳机输出)
BALANCED (平衡输出)
UNBALANCED (非平衡输出)
DSD FILTER (DSD滤波器)
SOUND COLOR(音色菜单)
SOUND 1(5.6M)
SOUND 2(5.6M)
SOUND 3(11M)
SOUND 4(11M)
AK4499EX工作采样率为5.6MHz。
AK4499EX工作采样率为11.2896MHz。
WIDE (宽模式)
NARROW (窄模式)

功能介绍
FN KEY FOR (FN按键作用)
SWITCH LINE/HPA OUTPUTS (输出选择)
BLUETOOTH (切换到蓝牙输入)PHASE (切换到输出相位)
注: 这个选项用于匹配不同的I2S接口标准, 使用前请检查信号源的接口定义。
I2S MODE(I2S模式)
NORMAL (正常，PS AUDIO格式)
NORMAL
I2S DATA +
I2S DATA -
I2S LRCLK +
I2S LRCLK -
GND
NC
DSD FLAG
NC
GND
GND
GND
GND
I2S MCLK +
I2S MCLK -
NC
MUTE
NC
I2S BCK +
I2S BCK -
21
18
19
REVERSED
GND
GND
I2S MCLK +
I2S MCLK -
NC
MUTE
NC
I2S BCK +
I2S BCK -
I2S DATA -
I2S DATA +
I2S LRCLK -
I2S LRCLK +
GND
NC
DSD FLAG
NC
GND
GND
21
18
19
REVERSED (反相，DATA和LRCK反相)
PRE MODE(前级模式)
PRE MODE为输出接口的音量调节功能开关：
VARIABLE : 输出接口音量是受控的。
FIXED : 禁用音量调节功能, 使音量保持在当前的值。
FIXED DSD BYPASS : 打开DSD直通功能, 此时播放PCM或者DSD音量都不可调, 输出幅度固定为3.7
Vrms左右, 此功能打开时,DSD完全没有经过处理, 直接输出。

AUDIO PHASE
正常 (2+,3-) 反相 (2-,3+)
1 2+
3-
正常
1 2-
3+
反相
功能介绍
I2S DSD CHANNEL(DSD声道设置)
DSDL = PCM DATA (DSD左声道和PCM的数据引脚共用)(默认)
DSDL = PCM LRCK (DSD左声道和PCM的LRCK引脚共用)
注: 在使用I2S接口播放DSD音频时, 如果发现左右声道不正确, 则可以使用这个选项
来纠正。

(范围5秒 - 60秒, 设置后, 屏会在这个时间内自动熄灭, 遥控或者旋钮任意操作屏幕会重新点亮。这样可以很
大程度减少光污染, 提升听音环境的舒适性!)
功能介绍
BRIGHTNESS (显示屏亮度设置)
DIMMER (自动熄屏)
5秒 ~ 60秒
LEVEL 1 ~ LEVEL 6（亮度1~6）
RESET (系统复位)
在蓝牙输入时, 长按旋钮中键 , 系统只会重置蓝牙配对状态;
在其它输入时, 长按旋钮中键 , 系统清除所有设定, 包括蓝牙。

此机的USB、光纤、同轴支持MQA解码！
此机的MQA播放不要求使用特殊的播放软件, 例如foobar2000，Audirvanaplus只要 支持ASIO
或者WASAPI的音频输出就可以了, 并且在播放MQA音频时, 最好将电脑的音量调到最大, 以使
得电脑的音频输出是最佳状态。
在播放MQA文件时, 显示屏显示的采样率为音频原始采样率。
和声波标志是MQA Limited的注册商标。©2016
关于MQA
MQA（Master Quality Authenticated）是一项屡获殊荣的英国技术, 是一种兼有极高的采样率和
足够小的文件体积的高解析音频编码技术。 此机采用MQA技术, 可以接收并解码MQA音频, 提供
母带级别的声音。
有关更多信息, 请访问https://www.mqa.co.uk/how-it-works
重要提示：
本说明书所提到的产品规格和资讯仅供参考。如有内容更新，恕不另行通知。
如何播放MQA
播放MQA-CD注意事项
必须确认所播放的是一张真正的MQA-CD ;
确认CD播放器所输出的光纤或者同轴信号是未经处理的源码 。

USER MANUAL
Ver 1.0

Safety Notes
Warranty Terms
Install this unit in a well ventilated, cool, dry, clean place-away from direct sunlight, heat sources, vibration,
dust, moisture, or cold.
Use the voltage specified on this unit Only. Using this unit with a higher voltage than specified is dangerous
and may cause fire, damage to this unit, or personal injury. Our company will not be held responsible for any
damage resulting from the use of this unit with a voltage other than that specified.
Do not attempt to modify or fix this unit by yourself. Contact salesperson or customer service when any
service is needed. The cabinet should never be opened for any reason.
When not planning to use this unit for long periods of time (i.e. when going on vacation), disconnect the
power cable from the AC wall outlet.
Important note:
The product specifications and information mentioned in this manual are for reference only. The content of
this manual is subject to change without notice.
1. The Term of Service
Foshan Shuangmusanlin Technology Co., Ltd promises to offer good-quality products. If the product is
broken in 7 days after purchasing when you use it normally, you can choose to send it back for return,
replacement or repairing (only the product does not affect the second sales can be returned ). Repairing for
free in one year if you use it normall.
2. Date of purchase is in accordance with the date on invoice or receipt uesd by seller, and if you buy it on line,
you can show the screenshot of trade.
3. If an inappropriate usage causes the unit damaged, the warranty will be void. As below:
4. Sending it back to our company for repairing.
5. Contact your S.M.S.L Audio reseller for a return or replacement.
All damages by inappropriate use, including using it under non-normal working environment or without
following the instructions.
Dismantling, refitting, repairing by user in private.
Causing damage by using some fittings instead of the designative or accredited ones.
Cannot provide credible proof of purchase.

Features
Support MQA decoding, support MQA-CD;
New 3rd generation XMOS XU-316, PCM support up to 32bit/768kHz, DSD support to DSD512;
Flagship DAC chip AK4191+ AK4499EX, tap all the potential of the chip;
Distortion as low as a staggering 0.00006% (-124dB);
Use 5 high-end dual op amps and a large number of audiophile components;
Adopt 2nd PLL to eliminate JITTER during SPDIF transmission;
The new self-developed CK-03 clock processing circuit greatly reduces clock jitter;
Support DOP independent display function, accurately determine the current decoding format;
USB, optical fiber, coaxial , AES, I2S support DSD transmission, coaxial and optical fiber support
DOP64;
Use tempered glass to fully fit the color IPS display;
Built-in low-noise power processing, while improving power efficiency,
lower power consumption;
Combined with multiple low-noise regulated power supplies, it provides a stable, reliable,
efficient, and low-noise power supply system.
Qualcomm high-end Bluetooth chip, support LDAC (24bit/96kHz), APTX/HD, SBC, AAC;
High quality all-aluminum alloy shell, support high quality gold plated input and output
connection terminals;
Japan Audio Association (JAS) Hi-Res certification;
Equipped with remote control and full-featured remote control.

Input .................................................................................................................... USB/Optical/Coaxial/Bluetooth/I2S
Output
..................................................................................................... RCA/XLR/4.4mm+6.35 Headphone Jack
THD+N.........................................................................................................................0.00006%(-124dB)(UN-WTD)
HPA THD+N...................................................................................................................0.0001%(-120dB)(UN-WTD)
Line output amplitude.....................................................XLR 5Vrms
...............................................................................................RCA 2.5Vrms
Headphome output power
. ......................................................................................................................2Wx2(16Ω)
.........................................................................................................................................................................1Wx2(32Ω)
Output Impedance...........................................................XLR 200Ω
..............................................................................................RCA 100Ω
...............................................................................................HPA near 0Ω
HPA gain control ...............................................................low 0dB
high +7dB
Dynamic range..................................................................XLR 132dB
HPA 127dB
SNR
....... ................................................................................XLR 132dB
HPA 127dB
USB transmission... .......................................................................................................................... Asynchronization
USB compatibility.................................................................................
Windows 7 / 8 / 8.1 / 10 / 11(Needs Driver)
Mac OSX10.6 or Later、Linux(Driverless)
MQA decoder............................................................................................................................. USB/Optical/Coaxial
Sampling rate & Bit Width: USB PCM 44.1~768kHz(32bit)
2.8224~22.5792MHz(1bit)
DoP DoP64~DoP256
Optical / Coaxial 44.1~192kHz(24bit)
DoP DoP64
Bluetooth specification...........................................5.1(Supports SBC,AAC,aptX,apt HD,LDAC(24bit/96kHz))
Power Consumption...........................................................................................................................................<20W
Standby power....................................................................................................................................................<0.5W
Size.......................................................................................................................................
222x39x207mm (WxHxD)
Weight.....................................................................................................................................................1.54
kg/3.40lbs
Specifications
SMSL reserves the right to make improvements which may result in specification or feature
changes without notice.

If the remote control is still ineffective when it is close to the machine, replace it with a new
battery.
If the user does not use the remote control for a long time, remove the battery of the remote
control.
Dispose of used batteries in accordance with local regulations on battery disposal.
Operating The Remote
Control
This remote controller use 2 x R03/AAA batteries.
Remote Control
Power ON/OFF
Input select
MENU/OK
Next level menu
Return
Mute
Volume +
D
own
Up
FN(Define in the menu)
Volume -

Parts
DO300EX Accessories
1* SMSL DO300EX 1* Remote Control 1* Bluetooth Antenna
1* USB Cable 1* AC Cable 1* User Manual
1* Warranty Card
Coaxial input
5 6
Bluetooth input 9
7
USB input
8
6.35mm headphone jack4.4mm headphone jack
AC input
1 2 3
4
XLR output
RCA output
10 Optical input 12
11 I2S input
13 14
Display Indicator lightRemote window
Knob
41 2 3 5 6
9
8
13 14
12
1110
7

INPUTS
USB
BLUETOOTH
OPTICAL
COAXIAL
I2S(HDMI)
PCM FILTER
OUTPUTS
ALL LINE OUT
HEADPHONE OUT
BALANCED
UNBALANCED
SHARP ROLL-OFF
SLOW ROLL-OFF
SHORT SHARP
SHORT SLOW
SUPER SLOW
LOW DISPERSION
Instructions
DSD FILTER
SOUND COLOR
SOUND 1(5.6M)
SOUND 2(5.6M)
SOUND 3(11M)
SOUND 4(11M)
HPA GAIN
LOW
HIGH
WIDE
NARROW
The AK4499EX operates at a sampling rate of 5.6448MHz.
The AK4499EX operates at a sampling rate of 11.2896MHz.

PRE MODE
PRE MODE is the volume adjustment function switch for the output.
VARIABLE : The output volume is controlled.
FIXED : Disable the volume adjustment function to keep the volume at the current value.
FIXED DSD BYPASS : Open the DSD direct access function. At this time, the volume of PCM or DSD is not
adjusted. The output amplitude is fixed to about 3.7VRMS. When this function is opened, the DSD is not
processed at all, and the output is directly output.
Instructions
FN KEY FOR
SWITCH LINE/HPA OUTPUTS
BLUETOOTH PHASE
Note: This option is used to match different I2S interface standards, please
check the interface definition of the signal source before use.
I2S MODE
NORMAL
NORMAL
I2S DATA +
I2S DATA -
I2S LRCLK +
I2S LRCLK -
GND
NC
DSD FLAG
NC
GND
GND
GND
GND
I2S MCLK +
I2S MCLK -
NC
MUTE
NC
I2S BCK +
I2S BCK -
21
18
19
REVERSED
GND
GND
I2S MCLK +
I2S MCLK -
NC
MUTE
NC
I2S BCK +
I2S BCK -
I2S DATA -
I2S DATA +
I2S LRCLK -
I2S LRCLK +
GND
NC
DSD FLAG
NC
GND
GND
21
18
19
REVERSED

Instructions
AUDIO PHASE
NORMAL (2+,3-)
1 2-
3+
INVERTED
1 2+
3-
NORMAL
INVERTED (2-,3+)
I2S DSD CHANNEL
DSDL=PCM DATA (The DSD left channel using the PCM DATA pin)
DSDL=PCM LRCK (The DSD left channel using the PCM LRCK pin)
Note: When using the I2S input to streaming DSD audio, if you find that the left and right channels
are incorrect, you can use this option to correct it.
