Sabaj A10d User manual

使用说明书
深圳市大号科技有限公司
A10d

安全注意事项
请将本音响系统安装在通风良好、阴凉、干燥、干净的位置，远离直射阳光热源
、振 动 、灰 尘 、 潮湿或寒冷。
只能使用本机指定的电压。使用高于指定数值的电压很危险，而且可能导致火
灾，损坏本机或造成人身伤害。对于使用高于指定电压造成的任何损害，深圳
市大号科技有限公司将不负任何责任。
不要试图自行改造或修理本机。如果需要任何服务，请就近与有资格的深圳市
大号科技有限公司维修人员联系。不管有任何理由，都没有打开机壳的必要。
如果打算长时间不使用本机（比如度假时），请从墙壁交流电源插座上断开电
源线的连接。
A10d
保修条款
一、服务期限
深圳市大号科技有限公司承诺产品的良好品质，产品自售出之后7天内正常
使用情况下出现故障，客户可以选择退货或者保修（不影响二次销售才可退
货）。正常使用一年内出现故障可以免费保修。
二、购买日期以销售商开出的购机发票或收据日期为准，网购可以交易截图为准。
三、有以下情况都不能享受“三包”服务
1.一切人为因素损坏，包括非正常工作环境下使用或不按照说明书使用。
2.用户私自拆机、改装、维修。
3.使用非指定或许可的配件造成损坏的。
4.机身的QC或保修贴损毁。
5.不能出示有效购机凭证。
6.不属于本公司产品。
四、保修方式为送修
此条款只适于中国大陆，其它地区请参考当地销售代理商的规定和国家法规。
本说明书内容如有更新,恕不另行通知.若您使用的产品功能与说明书不一致
时,请以产品为准!

产品特点
A10d
全新系列的外观设计！
DAC使用AKM公司的旗舰音频解码芯片AK4497，配合精心设计的电路，使其性
能达到前所未有的0.00012%（-118dB）的 失 真 度 ！
第二代 XMOS方案，PCM采样率最高支持32bit/768kHz，DSD支持到DSD512，独
家定制支持Native DSD的驱动程序。
高通蓝牙5.0接收, 支持APTX，更 好 的 音 质 , 更远的传输距离。
时钟系统使用了独立的超低时钟抖动，超低相噪的晶振作为音频时钟。
内置高性能电源净化系统, 为DAC和LPF提供充足且低噪声的电源。
使用大量的音频专用发烧级低噪声电阻电容。
全平衡设计，并具备真正平衡输出。
使用高端双运放OPA1612。
大型的LED显示屏, 便于远距离操作!
全铝合金CNC精密加工机壳有效减少干扰。

技术参数
A10d
输入接口 .................................................................................USB、光纤、同轴、蓝牙
输出电平：
Fixed mode..........................................................................................RCA 2.0Vrms
Pre mode.............................................................................................RCA 3.0Vrms
THD+N(不计权)............................................................................
... 0.00012% (-118dB)
动态范围(A计权).........................................................................................RCA 127dB
信噪比(A计权).................................................................................................
..... 127dB
输出阻抗.................................................................................................................142Ω
蓝牙规格..................................................................................BT 5.0 (支持APT-X , SBC)
USB传输方式.....................................................................................................异步传输
USB兼容性.................................................
........ ................... .... Windows 7 / 8 / 8.1 / 10
Mac OS X10.6以上 、Linux
位深
USB ........................................................................................................1bit ~ 32bit
光纤/同轴..............................................................................................16bit ~ 24bit
采样率
USB................................................................................................44.1kHz~768kHz
DSD64, DSD128, DSD256, DSD512
光纤/同轴 ................................................................................................32~192kHz
消耗功率..................................................................................................................3.5W
待机功耗......................................................................
.. ............ ...................... .....<0.1W
体积.................................................
.. .......... ................. .. 100×32×165mm(W×H×D)
单机重量.......................................................
.......... .......... ............................ ...... 0.34Kg

关于遥控器
如果遥控器距离本机很近时操作仍无效，请用新电池更换。
如果要长时间不使用遥控器，请取出遥控器的电池。
按照电池处置的地方性法规处置废旧电池。
遥控器的使用
注 意
1. 遥控器请使用2节7号(AAA)电池
2. 第一次操作
A10d 时 ，先 按 C 键
开关机
输入选择
蓝牙
进入菜单/确认
进入二级菜单
返回
静音
音量加/向上
音量减/向下
无功能
切换至控制 A10d
A10d

A10d
显示界面和操作介绍
H IGH RE SO LUT IO N US B DA C
A10 d
O PT ICA L USB
LR COA XIAL
OUT
9-15 V
123
4 5 6 987
旋钮
红外接收窗
显示屏
线路输出
同轴输入
光纤输入
USB输入
蓝牙天线
电源输入（DC 9-15V）
6
7
8
9
1
2
3
4
5

1）长按旋钮：开机 / 关机
2）短按“旋钮”, 进入菜单, 长按返回主页面
3）顺时针或者逆时针旋转旋钮, 调节音量大小。

SABAJ A10d
输入
IN1 蓝牙
IN2 USB
IN3 光纤
IN4 同轴
FL1 ~ FL6
DSD滤波器
前级模式
音色
dF1 (DSD 滤波器1)
dF2 (DSD 滤波器2)
Pr0 (固定模式)
Pr1 (前级模式)
SC1~SC3(3种声音风格)
bL1~bL3(3级调节)
FL1(快速滚降)
FL2(慢速滚降)
FL3(短延时快速滚降)
FL4(短延时慢速滚降)
FL5(超级慢速滚降)
FL6(低分散短延时)
PCM滤波器
亮度

A10d
蓝牙说明操作
本产品配备了蓝牙按键, 就是遥控器上的FN按键,
这个按键的功能包括:
短按: 直接切换到蓝牙输入,如果蓝牙失去连接, 则为重新连接;
长按: 断开当前设备, 允许配对其它设备
连接: 将输入源切换至蓝牙，打开手机蓝牙功能，搜索 “SABAJ BLUETOOTH”, 搜索到后点击
配对连接，当手机显示“已连接”则已连接成功。
重连: 在使用蓝牙过程中, 如果失去连接, 例如: 外出, 然后回来, 有些手机不会自动重新连接,
在这个时候, 短按遥控器的蓝牙按键(FN)就可以重新连接.
连接新设备: 长按遥控器的蓝牙按键(FN)。在清除配对后，部分手机可能会出现无法再搜索到
"SABAJ BLUETOOTH"，此时需要将手机保存的蓝牙设备"SABAJ BLUETOOTH"删除掉，然后
再搜索配对。
恢复出厂设置
机器在未通电状态下，按住开机键再通电，直到显示屏显示logo之后，松开按键。

Shenzhen DaHao Technology Co.,Ltd.
USER MANUAL
A10d

Install this unit in a well ventilated, cool, dry, clean place-away from direct sunlight, heat
sources, vibration, dust, moisture, or cold..
Do not attempt to modify or fix this unit. Contact qualified Sabaj service personnel
when any service is needed. The cabinet should never be opened for any reason.
When not planning to use this unit for long periods of time ( i. e. when going
onvacation), disconnect the power cable from the AC wall outlet.
When not planning to use this unit for long periods of time (i.e. when going on vacation),
disconnect the power cable from the AC wall outlet.
A10d
Safety Notes
Warranty Terms
1. The term of service
Shenzhen Sabaj technology Co.,LTD promise good quality products. If product is
defective unit by normal use with in 7daysafterpurchasing. The customer can choose to
return or repair warranty( does not affect the secondary sales afterthey can return).
Faulty for free with in one year warranty normal use.
2. Date of purchase is in accordance with invoice date or receipt date issued by seller,
online shopping can cut trade shots.
3. Following situation can not enjoy“Three Guarantees service”
a. All damages by human factors, including use it under nonrmal workingenvironment
the and not following manual instruction.
b. User privately disassemble, modification, maintenance.
c. Use non-designated or approved accessories cause damage.
d. QC or warranty stickers damage on cabinet.
e. Can not provide a valid purchasing prove.
f. Not belong to Sabaj product.
4. How to warranty
This term is only suitable for china mainland, other regionplease refer to the policy of the
local sales agents and national regulations.
The contents of this manual are updated without prior notice. If the function of the product
you are using is inconsistent with the instructions,the function of the product shall prevail!

产品特点
A10d
Exterior design of the new series.
The unit uses AKM's flagship DAC chip the AK4497, with a well-designed
circuit that delivers an unprecedented 0.00012% (-118dB) distortion!
The 2nd XMOS solution, PCM supports up to 32bit/768kHz, and DSD
supports up to DSD512, custom driver for Native DSD.
Qualcomm Bluetooth 5.0 reception, support APTX, better sound quality, longer
transmission distance;
The clock system uses 2 independent ultra-low clock jitter and phase noise
crystal as the audio clock.
Built-in power purification system supplying very low noise power for DAC
and LPF circuits.
Lots of audio grade components, include low-noise resistors, Gold-plated
jacks.
Equipped with full-featured remote control.
With volume adjustment function, it can be used as a pre amplifier.
Use high-end dual op amp OPA1612.
Large LED display, convenient for remote operation.
The all-aluminum CNC precise chassis to reduce magnetic noise.

Specifications
A10d
Inputs ...............................................................USB / Optical / Coaxial / Bluetooth
Output Level:
Fixed mode...............................................................................RCA 2.0Vrms
Pre mode..................................................................................RCA 3.0Vrms
THD+N(UN-WTD).................................................................. 0.00012% (-118dB)
Dynamic range (A-WTD)...................................................................RCA 127dB
SNR (A-WTD)................................................................................................127dB
Output impedance..........................................................................................142Ω
Bluetooth...............................................................BT 5.0（support APT-X , SBC）
USB transmission ............................................................................Asynchronous
USB compatibility ...........................................................Windows 7 / 8 / 8.1 / 10
Mac OS X10.6 or Later / Linux
Bit depth
USB ..............................................................................................1bit ~ 32bit
Optical/coaxial ...........................................................................16bit ~ 24bit
Sampling rate:
USB .........................................................................................44.1 ~ 768kHz
DSD64, DSD128, DSD256, DSD512
Optical/coaxial ...........................................................................32 ~ 192kHz
Power Consumption ......................................................................................3.5W
Standby power ............................................................................................＜0.1W
Size ........................................................................100×32×165mm(W×H×D)
Weight ....................................................................................................... 0.34Kg

Install 2 x AAA batteries as instructions.
When using the remote control, point it toward the remote con-trol signal receiver on
the main unit from a distance of 5 m (16 ft) or less. Do not place obstructions between
the main unit and the remote control.
The remote control might not work if the remote control signal receiver on the unit is
exposed to direct sunlight or bright light. If this occurs, try moving the unit.
Beware that use of this remote control could cause the unin-tentional operation of
other devices that can be controlled by infra.
Remote Control
Operating the remote control
Note
1. This remote controller use 2 x R03/AAA battaries.
2. When you first operate A10d, press the C key first.
Power ON/OFF
Input select
Bluetooth
MENU/OK
Next level menu
Return
Mute
Volume
/up
Volume /down
Switch to control A10d
Invalid
A10d

A10d
Display interface and Instructions
Optical input
USB input
Bluebooth antenna
Power Supply(DC15V)
6
7
8
9
1
2
3
4
5
Knob
Remote window
Display
LINE OUT
Coaxial input
H IGH RE SO LUT IO N US B DA C
A10 d
O PT ICA L USB
LR COA XIAL
OUT
1 5V
123
4 5 6 987

USB Co axialOpticalBluetooth
2. INPUT SELECTION
When it is turned on, it will show
The display shows when there is no input signal or the sampling rate
exceed the range of the unit.
When switching input will be displayed (Press the "Input Select" key on the
remote control or press the "Power Function" key for input selection)
When adjusting the volume, the volume is displayed. The range is
maximum and minimum.
When muted, the current volume flashes.
Note: when playing music is DSD format, it will display .
1）Long press the knob: power OFF/ON
2）Short press the knob: enter the menu,Long press to return to the main page
3）Turn the knob clockwise or counter clock wise to adjust the volume.
2. SETUP MENU

SABAJ A10d
INPUT
PCM FILTER
IN1 BLUETHOOTH
IN2 USB
IN3 OPTICAL
IN3 COAXIAL
FL1 ~ FL6
DSD FILTER
PRE MODE
SOUND COLOR
BRIGHTNESS
dF1 (DSD filter 1)
dF2 (DSD filter 2)
Pr0 (Fixed Mode)
Pr1 (Volume Mode)
SC1 ~ SC3 (3 of sound style)
bL1 ~ bL3 (Brightness level)
FL1(Sharp Roll-off Filter)
FL2(Slow Roll-off Filter)
FL3(Short Delay sharp Roll-off Filter)
FL4(Short Delay Slow Roll-off Filter)
FL5(Super Slow Roll-off Filter)
FL6(Low Dispersion Short Delay Filter )

Factory Reset
Connect the power cord when pressing the power button, until screen shows logo.
Bluetooth operating instructionst
Connection:
Step 1: Switch the input source in the SETTING MENU or press the Bluetooth button
of the remote;
Step 2: Turn on the Bluetooth function of the mobile phone, search for
"SABAJ BLUETOOTH", and tap to pairing. When the mobile phone displays
"connected", it has been successfully connected.
Re-connection:
When you had lost the connection with the A10d, for example,going out, and back
home, some phones will not re-connect the A10d if the A10d has not been re-boot, so
you can press the Bluetooth button (FN) on the remote to Re-connect.
Clear pairing: Long press the "Bluetooth" button(FN) on the remote control. After clearing
the pairing, some phones may no longer be able to search for "SABAJ BLUETOOTH".
In this case, you need to delete the Bluetooth device "SABAJ BLUETOOTH" which
saved in the phone, and then search and pairing again.
This product is equipped with a Bluetooth button, which is the FN button on the
remote control,The functions of this button include:
Short press: Switch directly to Bluetooth input, if Bluetooth loses connection, it is a
reconnect;
Long press: Disconnect the current device and allow pairing with other devices.
A10d
