1. Introduction
The SCLO 200M is a Self-contained range light with a 14 NM Range. The lantern includes solar panels, battery
and charge controller. This lantern is designed for harsh marine environments and for long uninterrupted
operation.
Features
Range up to 14 NM (Tc=0,74), 22 NM (Tc=0,85) depending on geographical location
Standard IALA colours Red, Green, White, Yellow
Rugged injection moulded aluminium housing and UV resistant polyethylene body
Programmable with all SABIK wireless programmers, Bluetooth® Control mobile app up to
50m radius
Integrated flasher with day-light switch and solar charger
Integrated event log for 365 days
Standard VRLA battery and ventilated battery compartment
Solar modules covered with tempered glass
Adjustable intensity and range
Light horizontally and vertically adjustable in the field
Optionally integrated GPS Synchronization
Optionally integrated GSM Remote Monitoring
Technical specifications table
Specification Value
Lens visual/Mechanical diameter 203mm
Lens material UV stabilized Polycarbonate
Light Source High power Light Emitting Diodes (LEDs)
Unit Life Time Up to 10 years
Operating temperature range -20° – +55°C
Solar modules 3 x 11W
Battery VRLA GEL-Type, 60Ah/12V
Solar panel charger Integrated 16 Ampere PWM charger
Power consumption LO 200 4W at full intensity
Horizontal divergence 8° @ 50% (±1°) of peak intensity
Optical centre height above mounting surface 610mm
Height x Width 669mm x 500mm
Weight (including 60Ah Gel-type battery) 39 kg
Degree of protection IP 66
Installation 3 x M12 on 330mm diameter

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

5
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
1.1. Optical performance
Optical performance
Optical Performance 5° @ 50% peak intensity FWHM
Colour White Red Yellow Green
Maximum Peak intensity 13000 cd 7000 cd 7000 cd 7000 cd
Power Consumption 4W 4W 4W 4W
2. Product Identification and Options
Every Sabik unit is supplied with a product label.
(The picture is only an example)
Option matrix for SCLO 200M
.
Order Code Beam Colour
SCLO 200M MW White
SCLO 200M MR Red
SCLO 200M MG Green
SCLO 200M MY Yellow
Product Options
included Description
OPT 4: GPS sync GPS sync GPS sync including external GPS antenna
OPT 9: LightGuard GSM + GPS
LightGuard GSM +
GPS
Integrated GSM/GPS based monitoring including internal GSM/GPS
antennas
OPT 10: LightGuard GSM Integrated GSM based monitoring including GSM antenna
OPT 12: Aux card with I/O Optical feedback Integrated LED performance measurement
OPT 13: Aux card with RS485 and
I/O
Aux card including RS 485 and I/O port
Shock & Tilt Sensor Integrated 3-axis G sensor for tilt and shock sensing
Product label

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

6
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
3. Mechanical
The optical lens is made of UV-resistant Polycarbonate and light module is made of epoxy painted marine grade
corrosion resistant aluminium. The beam is horizontally and vertically
adjustable in the field. The ventilated body with solar panels is of UV resistant polyethylene.
There are no serviceable parts inside the light module. If the lantern is equipped with Sabik LightGuard, and you
must install/change the SIM card or service parts inside the lantern – please contact Sabik for instructions.
The light module is fully waterproof and pressure tested at factory before shipment.
Pressure equalisation is arranged through a PTFE membrane, mounted on the black lid of the optical unit.
3.1. Dimensions and Mounting
The SCLO 200M unit is suitable for fixed installations. The mounting flange supports installation on structures
using 3 x M12 bolts on a 330mm diameter.
PLEASE NOTE! The optical head unit in the SCLO200 lantern is delivered unconnected to the battery!
Please follow the description for Installing and or replacing the light unit.
The mounting bolt holes are isolated to prevent galvanic contact with the mounting platform. One of the holes
provides earthing connection (PE).
A separate bracket is available for a standard 200mm installation.
3.2. Dimensions
Bottom view

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

7
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
4. Electrical
The SCLO 200M lantern is operated using built in solar panels, charger and battery. The integrated lantern
(LO200M) is protected against reverse polarity and short-circuit protected.
4.1. Solar Charger
A programmable solar panel regulator is integrated in the lantern. The charger is pre-configured by Sabik.
Recommended charging parameters Value Description
Cut-in Voltage 13.8 V Start charging voltage.
Cut-out Voltage 14.2 V Stop charging voltage
Minimum Battery Voltage 10.0 V
Re-connecting Hysteresis 1.0 V Re-start charging when voltage
dropped by this amount.
Temperature Compensation 30 mV/°C
Charging Mode PWM Pulse Width Modulated charging.
4.2. Battery
Battery Specification Value
Type VRLA AGM Lead-Acid
Nominal Battery Voltage 12 V
Nominal Battery Capacity 60 Ah
Minimum Discharge Voltage 10.0 V

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

8
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
5. Programming
Programming the lantern can be done using Bluetooth application for Android or iPhone, Sabik easyProgrammer,
or Programmer Lite (USB).
IR port and photocell
The combined infrared communication port and
Photocell (ambient light sensor) is located in the
base of the light unit.
Programming is done by pointing the programmer
at the IR port.
The photocell senses daylight and starts/stops the
flashing cycle accordingly.
In the following chapters, you will find programming
instructions.
PLEASE NOTE! The optical head unit in the SCLO200 lantern is delivered unconnected to the battery!
Please follow the description for Installing and or replacing the light unit.

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

9
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
5.1. Bluetooth Control App
The Product is designed for programming and controlling Sabik Bluetooth®enabled lanterns using a simple user-
friendly interface. The Android or iPhone app can be downloaded and installed to Bluetooth®4.0 (Bluetooth®
Smart) capable smart phone. The useable range between lantern and phone is usually more than 10m (the range
is depending on type of lantern) and maximum up to 50m. The energy consumption of the Bluetooth®chip is very
low. These instructions are for Android devices but the instructions for iPhone are very similar.
Standard Features and requirements
The lantern settings can be read to your phone for monitoring purposes. If you have the access rights you also
can make changes and send them to the lantern. You cannot store the settings on your phone.
The app requires a minimum of iPhone 4s or a Bluetooth®4.0 (Bluetooth® Smart) capable Android phone with
operating system 4.3 or higher.
5.1.1. Installation Download
The app can be downloaded from Apple (http://store.apple.com ) or Google ( https://play.google.com ) for free.
Observe, that you may have to register yourself before downloading. The app is free of charge.
Installation
Follow the instructions on Google Play or Apple Store.
Registration
For the application to be able to work, you have to register your application using a valid user name and a
password. Please contact your dealer to obtain these. This procedure has only to be done once.
5.1.2. Launching the application
After the installation, you should find an icon for the Bluetooth®app. You
may relocate it if necessary.

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

10
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
5.1.3. Login and selecting lantern
Fill in your user name and password and tap “Login”.
-if you don’t have a user name and password, please contact your dealer
to obtain these.
This information is stored in your device so the next time you will be
logged in just by tapping the “Login” button
Now the app will search for Sabik lanterns within Bluetooth®range and
display them in a list. Any lantern which is connected to another user will
not be shown in the list. The lantern serial number is the default Bluetooth®
name. This name can be changed using the application. This default serial
number is also printed on the lantern. Tap on the name to select it.

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

11
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
5.1.4. User interfaceThe interface labels are loaded from the lantern, so only the parameters
relevant to this lantern are displayed.
For instance, if there is no GPS function in the lantern, none are displayed
in the application. The pages shows the standard settings.
The user interface is divided into screens. (DEVICE STATUS,
CONFIGURATION, COMMANDS and ABOUT) To select a screen, swipe
the screen to the right or left or tap a screen tab.
The Screens are divided into expandable blocks (Light, Power,
Temperature etc.).
For advanced settings, you have to expand the blocks. To expand a block
just tap the symbol near the right edge
Expanded view for advanced settings. Tap the symbol to collapse.

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

12
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
On the CONFIGURATION page, you can change the lanterns
configuration by tapping the small >-shaped symbol on the right side of the
setting’s name. If needed, expand the block to see the advanced settings.
When, for example, LED Intensity is selected, you will be able to adjust the
intensity by writing the range (in NM) or adjusting the intensity in percent.
You can write the percentage or select it by swiping the numbers up or
down.
Tap Cancel to cancel or Write to send the updated value to lantern. The
edited parameter is immediately stored in the lantern and the new value
flashes briefly after it has verified by the lantern.
If the set value is too high or low, a warning message is shown and the
value cannot be stored.

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

13
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
5.1.5. Pages
On the pages you will find information about the lantern, change settings and send commands. Observe that if
your lantern do not have a specific module installed, then there is no information about that module.
DEVICE STATUS
Here you will find information about the Light, Power, Temperature, Position, Counters and Engineering values.
You cannot make any changes to the lantern from this page. Observe, that some values/settings may not be
available in your lantern.
Light
Light Status: Shows the current light status, Active/Idle
Lantern Health Status: Any possible error or warning is shown in the health status
Photocell Value: Shows the real-time photocell value
Day-to-Night: Latest transition time from day mode to night mode
Night-to-Day: Latest transition time from night mode to day mode
Power
Battery Voltage Real time battery voltage
Battery Voltage Max Maximum battery voltage during the last 24h
Battery Voltage Min Minimum battery voltage during the last 24h
Battery Voltage Avg Average battery voltage during the last 24h
Power Consumption: Real time power consumption (measured only when light is lit)
Temperature
Temperature Real time temperature
Max. Temp. 24h Maximum temperature during the last 24h
Min. Temp. 24h Minimum temperature during the last 24h
Avg. Temp 24h Average temperature during the last 24h
Position (If GPS module installed)
GPS Latitude Latest measured latitude position
GPS Longitude Latest measured longitude position
GPS Time Time of last fix
GPS Accuracy GPS horizontal dilution of precision
Counters
Operating Hours Total illumination time
Power Cycle Counter: Indicates the number of times power has been removed from lantern
System Reset Counter: Number of reboots
Engineering
Measured LED Current
Measured LED Voltage
Lantern Tilt Angle
LED Max Intensity

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

14
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
5.1.6. CONFIGURATION
On this page you can review and change the values of the Flasher, Charger, GPS & Sync, Tilt and Impact, Dated
Shutdown and Bluetooth®Settings. Tap Write button to send new values to the lantern. The advanced settings
are shown in italics
Flasher
Flash Character: Select a standard flash character or create a custom flash character.
LED Intensity: Change LED Intensity based on intensity percent value or distance (NM)
Photocell Threshold: Lantern operating ambient light threshold in lux
Light Mode: Lantern operating mode (Photocell, Forced Idle, Forced Active or Day
Lantern)
Advanced Settings
LED Current: Product specific setting that must not be changed!
Photocell Hysteresis: Hysteresis setting for turning off the lantern (lux)
Astro Offset Sunrise: Offset for turning lantern off when in Astro mode (min)
Astro Offset Sunset: Offset for turning lantern on when in Astro mode (min)
Lantern Type: Lantern Installation Type (Stand alone, Primary or Standby)
Event log: Enable (Yes) or disable (No) the Event log
Charger Settings
Minimum Battery Voltage: Minimum Voltage level for light operation.
Advanced Settings
Cut In Voltage: Set minimum voltage for start charging.
Cut Out Voltage: Set voltage for charger to stop charging.
Charging Mode: Set charging mode (On/Off or PWM charging)
Battery Hysteresis: Battery reconnecting hysteresis (V)
Battery Temp. Compensation: Charging temperature compensation (-mV/°C)
Boost Charge Hysteresis: Set boost charge compensation (V)
GPS & Sync
Max Distance from fixed: Max drift distance from GPS fix (meters)
Fixed Latitude: Set fix Latitude
Fixed Longitude: Set fix Longitude
GPS Check-up Interval: Set position check-up interval (min).
GPS Check-up Duration: Set position check-up duration (min)
Sync Setting: Set lantern Sync mode (Off, Cable, GPS or Cable and GPS)
Advanced Setting
Sync Delay: Set Sync Delay (sec)
Tilt and Impact
Tilt angle Limit: Set maximum allowed tilt angle (deg) before shutdown occurs.
Advanced Setting
Shutdown if tilted: Set lantern to shut down if tilted (Yes or No)
Dated Shutdown
Dated Shutdown Enabled: Enable or disable dated shut down (Yes or No)
Advanced Settings
Shutdown Date: Set date to shut down lantern
Startup Date: Set date to start up lantern

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

15
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
Bluetooth Settings
Bluetooth Device name: Set lantern’s Bluetooth name
Advanced settings
PIN Code Enabled: Enable or disable lantern PIN code (give PIN code to change setting)
PIN Code: Set new PIN Code
5.1.7. COMMANDS
On the COMMANDS page you can do a lantern test and download the event log.
Test Lantern
The Test command runs the lantern for 3 minutes.
Download event log
This command will download the full event log to your phone. You can now save it or share it.
5.1.8. About
Device
Product Code
Serial number
Advanced settings
Bluetooth Firmware
Lantern Software Version
GPS Software Version
GPS Hardware Version

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

16
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
5.1.9. Create a custom Flash Character; Step by Step
Instructions
1. Select CONFIGURATION page
2. Tap on > symbol to the right of Flash Character
3. Select an existing Character from the list as a starting point
and
4. tap “Edit Flash Signal” to customize the character.

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

17
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
5. Change the On/Off timing. If needed add a new On/Off Pair or delete
an existing pair by tapping the gray X. Tap Save, when done.
6. The new character will be saved as Custom.

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

18
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
5.2. Other programming options
5.2.1. Sabik easyProgrammer
Sabik easyProgrammer is a stand-alone simple programmer for
lanterns with an infrared-Interface.
With the aid of Sabik easyProgrammer PC software, you can
download/upload information to/from the handheld programmer to a
Windows based personal computer. This is done using the SABIK
Infrared USB interface (sold separately).
Refer to the separate easyProgrammer user guide for more
information.
5.2.2. PC USB-interface and SABIK Programmer Lite
Refer to the separate user guide for more information

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

19
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
6. Periodic Maintenance
The SCLO200M is a robust lantern, which requires no maintenance, except for periodical lens and solar panel
cleaning. To maintain a good light output and achieve a long service life, it is advisable to visually inspect the
lantern whenever visiting the site.
Mechanical inspection and maintenance:
Clean the metal parts on the lantern
Check the lens and clean it with a damp cloth (Do NOT use any solvents!)
Check the mounting bolts and the plastic washers for damage and replace if necessary.
Check and clean the solar panels
Check the lantern for leakage (condensation through the lens)
Functional inspection and maintenance:
Check that the lantern turns on by covering the ambient light photocell
Read controller values with a programmer and check the status (note that values can also be saved in
the PDA programmer)
Check battery voltage with the programmer. If battery voltage is low, replace the battery
7. Installing and or replacing the light unit
PLEASE NOTE! The optical head unit in the SCLO200 lantern is delivered unconnected to the battery! Please
follow the description below in order to connect the battery.
Attn: There are no user serviceable parts inside the light unit. For servicing/changing of the light source, SIM card
or GPS/GSM unit – please contact Sabik or distributor near you.
First unscrew the four M8 bolts using an 13mm wrench.
Lift up and connect/disconnect the cable to the light unit (LO200M).
3 x M8 bolts
Replace the light unit and re-assemble the lantern in reverse order.

SCLO 200M
Date: Dec 2
3
.2020 Version 1.0
3

Public version

Product
Manual

20
of
24
SABIK Oy
·
BOX
19 · FI 06151 Porvoo · Telephone +358
-
19
-
560 1100 · www.sabik.com
7.1. Replacing the
battery and/or solar
panel
1. First unscrew the four M10 bolts
using an 13mm wrench.
2. Lift up and disconnect the cable
to the light unit (LO200M).
3. Unscrew the 6 M8 bolts, using a
13mm wrench, to separate the lantern.
4. Remove the protective plastic
cover.
5. Unscrew the 3
6. Unscrew the 4 M8 hex bolts,
using a 8mm Allen (hex) key.
7. Lift the battery unit from the
lantern
8. Disconnect and replace the
battery
Carefully pull out the inside contents.
Use a 12mm wrench to disconnect
the battery (+ and -) leads.
To change the solar panel, open the
junction box and disconnect the leads.
Replace the panel(s) and re assemble
the lantern.
Unscrew the four bottom plate screws
holding the battery bracket using a
3mm Allen key and a 12mm wrench.
Replace the battery and re-assemble
the lantern in reverse order.
