2.4 GHz Smart Spectrum®
Antenna Distribution Amplifier
Model SWA6SS
Operating Guide
for SWM7000 receiver models:
SW71-R, SW72-R, & SW72-NDR
Included with the SWA6SS
Antenna Distribution Amplifier System
Qty Item Description
12 RF Cables (40 cm, TNC)
8 RF Terminators
1 Operating Guide
1 Power cord

Notes about your system

LIT-SWA6SS-OP-050222.pmd-rr 3
Table of Contents
Connection Quick Setup ...................................................................................................... 4
Introduction .......................................................................................................................... 5
Components......................................................................................................................... 5
General Information on Antenna Placement ........................................................................ 5
Antenna Placement Cautions............................................................................................... 5
General Installation Cautions ............................................................................................... 6
Common Sources of RF Interference .................................................................................. 6
Coaxial Cable Attenuation Table .......................................................................................... 8
Cautions & Warranty ............................................................................................................ 9
Table of Contents

4
Connection Quick Setup
Antenna Distribution Amplifier Quick Setup
Connect receiver Antenna 1 input to any RF Output 1 connector on the SWA6SS. Remove the
RFTerminatorif necessary.
1
2
Connect any receiver Antenna 2 to any RF Output 2 connector on the SWA6SS.
Receiver Antenna Distribution Amplifier (SWA6SS)
4
To Extension Antennas
Continue with all remaining receivers. Follow this
diagram for cascading distribution amps.
SWM7000
Series
Receivers
5
Connect antennas (extension or standard from a receiver) to Antenna Inputs.
Antenna Distribution Amplifier (SWA6SS)
Receiver
SWA6SS
Antenna
Distribution
Amplifiers
3
Connect the supplied RF Terminators to all unused RF Outputs. These terminators are caps with a
green collar. Failure to do this may result in poor performance or drop-outs.
Examples show RFTerminators installed on unused Outputs

LIT-SWA6SS-OP-050222.pmd-rr 5
Introduction
The SWA6SS is designed to distribute and amplify the RF signal from a pair of antennas to up to 6 SWM7000
Series receivers.You can also cascade multiple SWA6SS units to distribute the RF to many more receivers (see
blockdiagram detail on page 4).
YourSabine Antenna DistributionAmp features very low inter-modulationdistortion, high dynamic range and low
noise components, and reduces multiple antenna interference in multiple system usage.
Please refer to your SWM7000 Operating Guide for important information about the correct setup of your re-
ceiver.
Components
This Antenna Distribution Amp will allow you to connect up to 6 Sabine SWM7000 receivers to one set of anten-
nas — thus alleviating the “antenna farm” of multiple-receiver antenna placement — and improving reception as
well.This setup can be combined with the Sabine Extension Antennas (SWASS-EXT) for additionally improved
reception.Extension antennas must be purchased separately.Or you can use the standard antennas from your
receiver.
Installation Connections
1. Connect receiver Antenna 1 input to any RF Output 1 connector on the SWA6SS. Likewise, connect any
receiver Antenna 2 to any RF Output 2 connector on the SWA6SS.
2. ConnectAntennas.Youmayusethesupplieddipoleantennasfrom your receiversandmountthemeitheron
thefrontorbackoftheAntennaDistributionAmp. Makesurethedipoles(smallrubberantennas)aremounted
so they can “see” the transmitters. To further maintain line of sight, replace the supplied antennas from your
receiverswith Sabine Extension Antennas (SWASS-EXT).
3. TerminateanyunusedRFoutputs. Failuretodothismayresultinpoorperformanceordroputs. YourAntenna
Distribution Amp comes with 8 RF Terminators. Remove these as necessary to connect receivers, but save
them in case you change your configuration later.
3. TurnonPower switch.
NOTE: Using the set up illustrated in step number 4 on page 4 of this operating guide, one pair of SWASS-EXT
antennas connected to seven Antenna Distribution Amplifiers will accommodate up to 35 receivers, or 70 audio
channels.
General Information on Antenna Placement
Antennas used with the Antenna Distribution Amp should be placed in an open area within visual range of the
intended microphone locations. Note that the range of a True Mobility transmitter is about 100 meters, but that
structural objects can reduce that range. Extension antennas are recommended to maintain good reception
when the antenna divider is located far from the transmitters.
Antenna Placement Cautions
Since the installation of the antennas influences the operating efficiency of the receiver, the most important
rule is to minimize the distance between receiving antenna and transmitter for better reception and perfor-
mance. Make sure the antennas can “see”the transmitters.
Placing Extension Antennas: Position the one marked
LEFT
at stage left (on the left hand side of a
performer facing the audience) and so on. When you mount the extension antennas on a stand or on a wall,
make sure the short end of the triangle is up.
Inorder for the system tobe effective,both extension antennas should be in a good pickup position at all
times butseparated by about ten orfifteen feet if the antennasare within 100 or sofeet. Separate them about
20 to 25 feet in very large rooms or fields. If you put the antennas too far apart, i.e., at opposite ends of the
room, or in separate rooms, to improve coverage, diversity is defeated and you will get dropouts. In other
Antenna Distribution Amplifier Installation Instructions

6
words, diversity is more important that coverage. If you mount the extension antennas in the ceiling, the
antennasmetallic backplane must be orientated parallel tothe floor and the antennas must notbe blocked by
pillars, lights or similar obstructions. Aim the hole in the plastic cover toward the podium.
Do not daisy-chain extension antennas togetherin series. Receivers andthe antenna distribution amp are
only designed to use one left and one right antenna.
Extension Antenna Cables: Use coaxcableto connect the extensionantennasto thereceiverorto the ADA.
See the chart on the previous page for cable specifications. Use the SWATNC-N step-down cable to connect
thicker RG8 cables to the extension antenna.
TheSWASS-EXT extension antennasadd between10and 18dB signal strength toovercome cableloss. Bad
crimp connections are a common cause of dropouts. Check them carefully!
Keep the system away from electrical-noise sources (electric motors, refrigerators, arc welders, etc.). Place
theAntenna DistributionAmp atleast 1.5meters abovefloorlevel.Keepalltransmitters atleast 3meters away
froma receiverantenna.
As a general precaution, keep 2.4 GHz cordless telephones, microwave ovens,WLAN antennas and 2.4 GHz
wirelessvideo cameratransmitters twice the distance fromyour Sabinewireless microphonesystem antennas
as that of your Sabine 2.4 GHz transmitters.
General Installation Cautions
1. Power Supply — Besure to plug your unit into an appropriate powersource.
2. AntennaShorting— Becarefulnottoallowtheantennatocomeincontactwithmetalsurfaces(antennadivider
case, other wires, cables, etc.).
3. Receiver to Antenna Distribution Amplifier cables —Keep these cables as short as possible. It is
recommended to use the cables supplied with your Antenna Distribution Amplifier.
4. Extension Antenna cables — For best results, use high quality coaxial cable with a 50 Ohm impedance.
Specifications will vary by cable manufacturer. See the chart for recommended cables on page 8. For best
results,usecablewithminimalattenuation.Thelongeryourcable,themoreyouwillreducethe100-meterrange
betweentransmitterandreceiverantenna.Awell-placedpairofextensionantennaswilleliminatetroublespots
andgenerallyimproveoverallperformanceofthewireless.
Common Sources of RF Interference
Since Marconi and others pioneered the first radio broadcasts, the radio spectrum has become increasingly
crowded with a huge diversity and variety of RF sources.The strength, frequency, location, and timing cycles of
theseRFsources createashifting patternofinterfering andoverlappingfrequencies andcoveragepatterns, which
can render the use of radio microphones a difficult and unpredictable business.
The typical sources of interference for conventional wireless mics can be high-powered broadcasters such as
radio stations and TV transmitters, or other short-range wireless devices, including multiple radio microphones
operating at the same location (either by design, or by coincidence), that operate in proximate (or harmonically
related) bands.Less commonly, interference may arise from spurious outputs emitted by electronic equipment
(notably computers, printers, or similar devices with digital clocks), faulty electrical equipment, neon signs, dim-
mers and lighting controllers, and so forth.
Many UHF andVHF mics are especially vulnerable because they share the RF spectrum with the very high-powered
transmittersfortelevision.Thecomingconversiontodigitalandhigh-definitionbroadcastwillincreasetheproblemsfor
UHF and VHF.
The 2.4 to 2.4835 GHz frequency band is not only well above the fundamental (nominal) transmission frequen-
ciesof such stronganalog anddigitalbroadcasts, butalso highenoughto escapeinterference problems occurring
at the strong first harmonic of even the highest digital television broadcast.The band is approved worldwide for a
Antenna Distribution Amplifier Installation Cautions

LIT-SWA6SS-OP-050222.pmd-rr 7
variety of uses, including such diverse transmitters as baby monitors, garage door openers, wireless LANs,
amateursatellite, cordlesstelephones, etc. Compared to RF broadcast sourceslike televisionand radiostations,
these low power devices produce very localized, short range interference; furthermore, many of the devices
working in the 2.4 GHz range use spread spectrum transmission and reception. Both of these facts mean such
uses of the RF spectrum are less likely to cause interference with, or suffer from interference from the use of,
Sabine’s systems.
Your first step in checking for interference should be utilizing the Scan function in the SWM7000 Remote Control
Software.RF scanningwill revealpotential RFsources inyour locationand allowyou tomake aninformed choice
ofchannels touse.Thescannercan scanfor long periods of time and will giveyou areport of RF activity over time
for each of the 70 channels available on your Smart Spectrum system. See Section 13.4.2.5 RF Scan of the
SWM7000 Operating Guide for more details on RF scanning.
1. Microwave ovens
In the vast majority of situations, interference from microwave ovens will not affect performance of your
SWM7000series microphonesystems.Since barrierssuch aswalls worktoblock interference,a microwave
oven will likely present a problem only when located in fairly close proximity within the same room as the
wireless receiver (or reception antenna). See caution below.
Commercial quality microwave ovens present a bigger potential problem. They sweep over a wider band of
frequencies than the limited band affected by consumer units, and use two magnetron tubes which alternate
toavoidinactivityduringapowercycle.Fortunately, Sabine systemsareonlyaffectedbysuchovensinclose
proximitytoreceiverantennas.Thatprotection,plustheavailabilityof70differentRFchannelstochoosefrom,
makes serious interference problems arising from microwave ovens avoidable and unlikely. See caution
below.
2. Wireless Local Area Networks (WLANS)
These computer network devices allow computers to connect via wireless devices that act as both receivers
and transmitters. These low-powered transceivers often have selectable channels and can utilize the entire
2.4GHzband.Ingeneral,SabinemicrophonesshouldnotbeaffectedbytheseWLANSbecausetheirspread
spectrumtechnologydoesnotpresentaproblemfortheSabineSmartSpectrumTM system.Seecautionbelow.
3. Cordless phones
These home telephones broadcast at very low power and should not present interference problems for your
Sabinewireless. Thisisespeciallytrueifthetelephoneusesspreadspectrumtechnology.Seecautionbelow.
4. WirelessVideo Cameras
Certain wireless video cameras (X10, for example) use the 2.4 GHz band. These devices are also very low
power and, in general, should not present a problem when using the SWM7000 system. See Section 5
Receiver Operation for methods of optimizing clear reception and minimizing interference. See caution
below.
As a general precaution, keep 2.4 GHz cordless telephones, microwave ovens, WLAN antennas and 2.4 GHz wireless video camera
transmitters twice the distance from your Sabine wireless microphone system antennas as that of your Sabine 2.4 GHz transmitters.
Antenna Placement Caution
Antenna Distribution Amplifier Installation Cautions

8
Coaxial Cable Attenuation Table
RG58 9203 Polyethylene #20 Stranded -16.29 14 TNC
RG58/AU 9311 Foam #20 Stranded -11.10 20 TNC
Polyethylene
RG212/U 9861 Polyethylene #15.5 solid, -6.11 36 N
silver plated
RG8/U 9913 Semi-solid #10 solid -2.50 88 N
Polyethylene
RG142 83242 Teflon #18 solid, -6.54 34 TNC
silver plated
Coaxial Cable Attenuation Table
Cable
Type Belden # Insulation Center Conductor
10 Meter
Attenuation
(in dB)
Maximum Practical
Distance
(using SWASS-EXT
in meters) Connector
Type

LIT-SWA6SS-OP-050222.pmd-rr 9
WARNING!
Warning! This equipment must be earthed.
Caution! Risk of electric shock. Do not open.
Caution! Shock hazard. Do not remove covers. No user serviceable
parts inside. Refer servicing to qualified service personnel.
Warning! To reduce the risk of fire or electric shock, do not expose
this product to rain or moisture.
Attention! Cet appareil doit être reliéàla terre.
Attention! Risque de choc électrique; ne pas ouvrir.
Attention! Risque de choc; ne pas oter les capots. Aucune pièce
accessible àl’intérieur. S’addresser àun technicien qualifié.
Attention! Pour réduire le risque d’incendie ou de choc électrique, ne
pas laisser l’appareil sous la plouie ou àl’humidité.
Achtung! Dieses Gerät muss schutzgeerdet sein.
Achtung! Gefar eines elektrischen Stormschlags. Gehause nicht
öffnen.
Achtung! Gefar eines elektrischen Stormschlags. Gehäuse nicht
öffnen.Keine con Benutzer zu bedienenden Teile im Geräteinneren.
Überlassen Sie das Gerät zu Servicezwecken nur geschultem
Fachpersonal.
Um Brandgefar oder das Risiko eines elektrischen Schlags
auszuschließen, das Gerät vor Nässe und Feuchtigkeit schützen.
Advertencia! Este equipo debe estar conectado a tierra.
Precaución! Reisgo de descarga eléctrica. No abrir.
Precaución! Riesgo de descarga eléctrica. No desmontar las tapas.
Piezas interiores no reparables por el usuario. Reparable sólo por
personal cualificado.
Advertencia! Parareducir elriesgodeincendio odedescarga eléctrica
no exponga este producto a la lluvia o humedad.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:(1) This device may not cause
harmful interference; and (2) This device must accept any interfer-
ence received, including interference that may cause undesired op-
eration. Warning: Changes or modifications to this unit not expressly
approved bythe party responsibleforcompliance couldvoidthe user’s
authority to operate the equipment.
NOTE:This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radioTV technician for help.
Japanese EMI Compliance Statement
Cautions & Warranty
Cautions & Warranty
Canadian Compliance Statement
This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus set out in the Radio Interfer-
ence Regulations of the Canadian Department of Communications.
Le present appareil numerique n’emet pas de bruits radioelectriques
depassantleslimitesapplicables auxappareils numeriquesdela class
Bprescrites dansleReglementsur lebrouillage radioelectriqueedicte
par le ministere des Communications du Canada.
The True Mobility Antenna Distribution Amp is designed to oper-
ate from standard AC power. Please be sure the power in your
area is compatible with the power requirements marked on the
rear of the unit. Using the wrong input voltage may cause perma-
nent damage to the unit and will void the warranty.
Operating Voltages:
100-130 VAC, 50/60Hz, 0.100A 250 Slow Blow Fuse
or
200-240VAC, 50/60Hz, 0.050A Type T Fuse
CAUTION - Implanted cardiac pacemakers or AICD devices:
Any source of RF (radio frequency) energy may interfere with normal functioning of the implanted device. All wireless microphones
have Iow-power transmitters (less than 0.05 watts output) that are unlikely to cause difficulty, especially if they are at least a few
inches away. However, since a beltpack transmitter typically is placed against the body, Sabine suggests attaching it at the belt,
rather than in a shirt pocket where it may be immediately adjacent to an implanted medical device. Note also that any medical-
device disruption will cease when the RF transmitting source is turned off.Please contact your physician or medical-device provider
if you have any questions, or experience any problems with the use of this or any other RF equipment.
1. Read all safety and operating instructions before using this prod-
uct.
2. All safety and operating instructions should be retained for future
reference.
3. Obey all cautions in the operating instructions and on the unit.
4. All operating instructions should be followed.
5. Use only shielded audio and data cables.
6. This product should not be used in the presence of moisture or
rain, or near any water, i.e., a bathtub, sink, swimming pool, wet
basement, etc.
7. This product should be located so that its position does not inter-
fere with proper ventilation. Do not use in direct sunlight. Do not
place flat against a wall or in a built-in enclosure that will impede
the flow of cooling air.
8. This product should not be placed near a source of heat such as
a stove or radiator.
9. Connect only to a power supply of the type marked on the unit
adjacent to the power entry module.
10. Never break off the ground pin on the power supply cord.
11. Power supply cords should always be handled carefully. Never
walkorplace equipmenton powersupply cords.Periodicallycheck
cords for cuts or signs of stress, especially at the plug and the
point where the cord exits the unit.
12. The power supply cord should be unplugged when the unit is to
be unused for long periods of time.
13. Care should be taken so that objects do not fall and liquids are
not spilled into the unit through the ventilation holes or any other
openings.
14. This unit should be checked by a qualified service technician if:
A.The power supply cord or plug has been damaged.
B. Anything has fallen or been spilled into the unit.
C.The unit does not operate correctly.
D. The unit has been dropped or the enclosure damaged.
15. The user should not attempt to service this equipment. All service
work should be done by a qualified service technician.
Japan 100 VAC
U.S./North America 120 VAC
Continental Europe 230 VAC
United Kingdom 240 VAC
Australia 240 VAC
The True Mobility Antenna Distribution Amplifier is supplied with one
of the following AC power cords:

10
property allegedly caused by Sabine’s negligence. Sabine does not
assume liability for personal injury or property damage arising out of
or caused by a non-Sabine alteration or attachment, nor does Sabine
assume any responsibility for damage to interconnected non-Sabine
equipment that may result from the normal functioning and mainte-
nance of the Sabine equipment.
UNDERNO CIRCUMSTANCESWILL SABINEBE LIABLEFORANY
LOSTPROFITS,LOST SAVINGS,ANY INCIDENTALDAMAGESOR
ANY CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE
OR INABILITY TO USE THE PRODUCT, EVEN IF SABINE HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
THESE LIMITED WARRANTIES ARE IN LIEU OF ANY AND ALL
WARRANTIES,EXPRESS ORIMPLIED,INCLUDING BUTNOTLIM-
ITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR USE;PROVIDED, HOWEVER,
THAT IFTHE OTHER TERMS AND CONDITIONS NECESSARYTO
THE EXISTENCE OF THE EXPRESS LIMITED WARRANTIES, AS
HEREINABOVE STATED, HAVE BEEN COMPLIED WITH, IMPLIED
WARRANTIES ARENOTDISCLAIMED DURINGTHEAPPLICABLE
ONE-YEAR PERIOD FROMDATE OF PURCHASE OFTHIS PROD-
UCT.
SOME STATES DO NOT ALLOW LIMITATION ON HOW LONG AN
IMPLIED WARRANTY LASTS, OR THE EXCLUSION OR LIMITA-
TION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SOTHE
ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLYTOYOU.
THESE LIMITED WARRANTIES GIVE YOU SPECIFIC LEGAL
RIGHTS,ANDYOUMAYALSO HAVEOTHERRIGHTSWHICHMAY
VARY FROM STATE TO STATE.
THESE LIMITED WARRANTIES ARE THE ONLY EXPRESS WAR-
RANTIESONTHIS PRODUCT,AND NOOTHERSTATEMENT,REP-
RESENTATION, WARRANTY OR AGREEMENT BY ANY PERSON
SHALL BE VALID OR BINDING UPON SABINE.
In the event of any modification or disclaimer of express or implied
warranties, or any limitation of remedies, contained herein conflicts
with applicable law, then such modification, disclaimer or limitation,
as the case may be, shall be deemed to be modified to the extent
necessary to comply with such law.
Your remedies for breach of these warranties are limited to those
remedies provided herein, and Sabine gives this limited warranty only
with respect to equipment purchased in the United States of America.
INSTRUCTIONS-WARRANTY REGISTRATION CARD
1. Mail the completed WARRANTY REGISTRATION CARD to:
SABINE, INC.
13301 NW US HIGHWAY 441
ALACHUA, FLORIDA 32615-8544 USA
OR: Register online at www.Sabine.com
a. Keep the PROOF OF PURCHASE. In the event warranty ser-
vice is required during the warranty period, you will need this
document.There will be no identification card issued by Sabine,
Inc.
2. IMPORTANCE OF WARRANTY REGISTRATION CARDS AND
NOTIFICATION OF CHANGES OF ADDRESS:
a.Completion and mailing of WARRANTY REGISTRATION
CARDS - Should notification become necessary for any condi-
tion that may require correction, the REGISTRATION CARD will
help ensure that you are contacted and properly notified.
b. Notice of addresschanges - Ifyou movefrom theaddress shown
on the WARRANTY REGISTRATION CARD, you should notify
Sabine of the change of address so as to facilitate your receipt of
any bulletins or other forms of notification which may become
necessary in connection with any condition that may require dis-
semination of information or correction.
3. You may contact Sabine directly by telephoning (386) 418-2000.
4. Please have the Sabine product name and serial number available
when communicating with Sabine Customer Service.
Manufactured by: Sabine, Inc.
13301 NW US Highway 441
Alachua, Florida 32615-8544 USA
Phone: +USA (386) 418-2000
Fax: +USA (386) 418-2001
THISLIMITEDWARRANTYVALIDONLYWHEN PURCHASEDAND
REGISTERED IN THE UNITED STATES OR CANADA. ALL EX-
PORTED PRODUCTS ARE SUBJECT TO WARRANTY AND SER-
VICESTO BE SPECIFIED AND PROVIDED BYTHE AUTHORIZED
DISTRIBUTOR FOR EACH COUNTRY.
Ces clauses de garantie ne sont vaiables qu’aux Etats-Unis et au
Canada. Dans tous les autres pays, les clauses de garantie et de
maintenance sont fixees par le distributeur national et assuree par lui
selon la legislation en vigueur.
Diese Garantie ist nur in den USA and Kanada gultig. Alle Export-
Produkte sind der Garantie und dem Service des Importeurs des
jewelligen Landes untervorfen.
Esta garantia es valida solamente cuando el producto es comprado
en E.U. continentales o en Canada. Todos los productos que sean
comprados en el extranjero, estan sujetos a las garantias y servicio
quecada distribuidorautorizado determiney otrezcaenlos diferentes
paises.
ONE-YEAR LIMITED WARRANTY/REMEDY
SABINE, INC. (“SABINE”) warrants this product to be free from
defects in material and workmanship for a period of one (1) year
from date of purchase PROVIDED, however, that this limited war-
ranty is extended only to the original retail purchaser and is sub-
ject to the conditions, exclusions and limitations hereinafter set
forth:
CONDITIONS, EXCLUSIONS AND LIMITA-
TIONS OF LIMITED WARRANTIES
These limited warranties shall be void and of no effect if:
a. The first purchase of the product is for the purpose of resale; or
b. The original retail purchase is not made from an AUTHORIZED
SABINE DEALER; or
c. The product has been damaged by accident or unreasonable use,
neglect, improper service or maintenance, or other causes not aris-
ing out of defects in material or workmanship; or
d. The serial number affixed to the product is altered, defaced or re-
moved; or
e. The power supply grounding pin is removed or otherwise defeated.
In the event of a defect in material and/or workmanship covered
by this limited warranty, Sabine will repair the defect in material or
workmanship or replace the product, at Sabine’s option; and pro-
vided, however, that, in any case, all costs of shipping, if neces-
sary, are paid by you, the purchaser.
THE WARRANTY REGISTRATION CARD SHOULD BE ACCU-
RATELY COMPLETED, MAILED TO AND RECEIVED BY SABINE
WITHIN FOURTEEN (14) DAYS FROM THE DATE OF YOUR PUR-
CHASE.
In order to obtain service under these warranties, you must:
a. Bring the defective item to any Authorized SABINE DEALER and
present therewith the ORIGINAL PROOF OF PURCHASE sup-
plied to you by the AUTHORIZED SABINE DEALER in connection
with your purchase from him of this product. If the DEALER is
unable to provide the necessary warranty service, you will be di-
rectedtothe nearestother SABINEAUTHORIZEDDEALER which
can provide such service. OR:
b. Ship the defective item, prepaid, to:
SABINE, INC.
13301 NW US HIGHWAY 441
ALACHUA, FL 32615-8544
Include therewith a complete, detailed description of the problem,
together with a legible copy of the original PROOF OF PURCHASE
and a complete return address.Upon Sabine’s receipt of these items:
If the defect is remedial under the limited warranties and the other
terms and conditions expressed have been complied with, Sabine will
provide the necessary warranty service to repair or replace the prod-
uct and will return it, FREIGHT COLLECT, to you, the purchaser.
Sabine’s liability to the purchaser for damages from any cause what-
soever and regardless of the form of action, including negligence, is
limitedtothe actualdamages uptothegreaterof $500.00or anamount
equal to the purchase price of the product that caused the damage or
that is the subject of or is directly related to the cause of action. Such
purchase price will be that in effect for the specific product when the
cause of action arose.This limitation of liability will not apply to claims
for personal injury or damage to real property or tangible personal
Cautions & Warranty
© Sabine, Inc. 2003MADE in USA

EC - DECLARATION OF CONFORMITY
CE MARKING
We, the Manufacturer
SABINE, INC.
13301 NW US HIGHWAY 441
ALACHUA, FLORIDA USA
declare that the product
ANTENNA DISTRIBUTION AMPLIFIER
SABINE MODEL SWA6SS
Is in conformity with
Council Directive: 73/23/EEC and 89/336/EEC
Standards to which conformity is declared:
EN 60065: 2001
EN 55022: 1998 Class B
EN 50082-1: 1998
Manufacturer Signature: __________________________
Date:_____________ Name:__________________________
28April, 2003 Doran Oster, President

Sabine,Inc.
13301 NW US Highway 441
Alachua, Florida 32615-8544 USA
Phone:(386) 418-2000
Fax:(386) 418-2001
MADE IN USA WWW.SABINE.COMCopyright 2004 Sabine, Inc. All rights reserved.
Register your Sabine products online at www.Sabine.com
Table of contents
Other SABINE Amplifier manuals
Popular Amplifier manuals by other brands

red lion
red lion IAMA Data Sheet / Manual

Taramp's
Taramp's MD8000.1 instruction manual

Bassinferno
Bassinferno BI4500.4 instruction manual

Audiodesign
Audiodesign Hifonics Zeus Street ZXS900/1 user manual

d & b audiotechnik
d & b audiotechnik preliminary XD 5D Startup manual

Triton Audio
Triton Audio Fethead Germanium user guide
