SAE Audio LexPro PKM Series User manual

CN/EN
Table of contents
目录表
重要安全事项和符号说明.................................................................1
前言......................................................................................................2
前板功能介绍.....................................................................................3
后板功能介绍.....................................................................................4
技术指标.............................................................................................5
故障排除.............................................................................................6
保修条例.............................................................................................7
产品物质拆分表.................................................................................7
Important Safety Instruction and symbol description......8
Foreword...........................................................................................9
Front panel functions..................................................................10
Rear panel functions....................................................................11
Specifications.................................................................................12
Troubleshooting............................................................................13
Warranty...........................................................................................14
User Manual's
用户使用手册

重要安全事项和符号说明
1/14
PKM系列功率放大器
重要安全事项
1. 阅读这些规定，注意所有警告，遵守这些规定。
2. 严禁在产品周围喷洒液体。请勿在产品上方放置液体容器，如花瓶等。可使用干布及风枪进行清洁。
3. 注意不要形成热风循环。 按建议方法进行安装。
4. 不将产品安装在热源附近，尽可能保证环境气温在35°C以下。
5. 接地保护，当产品接通电源时，应采取相应的接地保护措施。
6. 请保护好电源线，防止其受到踩踏或挤压，尤其要注意插头、电源插座及其连接设备处。
警告：电源插头/设备耦合器作为电路切断装置，应保持随时可用。
7. 必须按照以下开关次序来使用该产品：（开）前级-功放、（关）功放-前级。
8. 通电前必须确保供电电压符合该产品的要求。
9. 若输入信号并接超过三台功放，建议使用信号分配器，以确保输入信号不失真。
10. 不要将功放的某一个声道的输出接口接到另一个通道的输入接口。不要将功放的输出并联或串联到
另一台功放的输出接口。
11. 设计系统配置功放的时候，功放的功率应比音箱在相同阻抗下的标称功率大50%-100%，且小心使
用桥接模式。
12. 在维修功放的时候，禁止在桥接状态下将示波器的探头 连接到功放的输出端，以免损坏功放和示波
器。
13. 建议：1) 由于输出到音箱的电流较大，建议使用质量有保证的NL4型音箱螺旋插头。
2) 多台功放使用时应计算好合适的配电，以确 保达到合格的使用环境。
输入/输出 接 驳 线缆不可 堆 叠 在产品排 风 扇
口,请置于功放两侧捆扎好!
非水平堆叠时，建议机尾排风口向上或直向排
风口。
工作环境气温应<35℃。
在工程调试时验证机柜内气温，在极限条件
下，也应保持在35℃以下。
小心触电，非拥有相关资质的人员请勿擅自开
盖维修。
本产品仅适用于非热带气候条件下安全使用。
本产品仅适用于海拔2000m以下安全使用。
(仅限于本公司的开关电源设备)
需经专业回收的物料，不能放置入垃圾桶。
警告 为避免着火或电击，不要将产品暴露在雨中或潮湿的环境中。
安全说明

前言
2/14
欢迎
重要的安全注意事项
开箱
请在拆开包装后，确认功放的外观没有在运输途中遭到
损坏。确认功放的预设电压与使用地的交流电压额定值
匹配（详细信息见功放背板印刷），建议您保留包装箱，
以便在需要退还产品时使
支持与服务
请直接联系蜚声演出器材制造有限公司在当地的分销
商，以获得快速的售后服务和技术支持，如有技术问
题需要直接与制造商联系，可以通过以下方式：
电子邮件：[e-mail]
传真：[phone]
蜚声演出器材制造有限公司的产品在设计时已经考虑到
安全使用的要求，并遵照相关的国家的安全规定检验出
厂，只有合格的产品才能出厂销售。但由于本产品内部
有危险高电压和电量，因此请用户在使用前必须认真阅
读本手册的注意事项。如果产品跌落、凹入、浸湿或者
机体内部有部件松动，将会大大增加人被电击的危险。
当发生以上问题时，请马上切断电源 ，然后将本产品送
还指定的经销商进行检查维修！
PKM系列功率放大器
非常感谢您购买蜚声演出器材制造有限公司产品。
PKM系列专业功放，操作简单、工作稳定、性价比
高，用途广泛。专为卡拉OK包房、语言扩声、小型演
出、演讲等场合使用。为了更好的发挥产品性能，请
在使用前仔细阅读本手册。
参考不同型号产品的耗散功率与供电/AC进行配线
建议用户搭配不低于以下的配线径规格，以获得更佳
的综合性能。
标配电压：200~240V
型号 耗散功率 配线径规格
2
PKM6.5 1100W ≥1.5mm
2
PKM8.5 1500W ≥1.5mm
配线配电

前面板功能介绍
3/14
前面板
吸风口 机架安装孔
滤尘网 操作指引清洁
在工程建造完成时，应对滤网进行首次清洁。
在往后的时间，应根据实际的情况，建议每季度
定期进行清洁一次。
不允许拆除该滤网继续使用本产品，否则将影响
本机的使用寿命。
在此情况下产生的故障，将被认定为脱保！
PKM系列功率放大器
控制面板
电源开关
PROT 任何一种保护电路动作时亮起
CH1-CH2
-5dB 输出信号幅度距满功率约为-5dB
-10dB 输出信号幅度距满功率 -10dB约为
CLIP
-20dB 输出信号幅度距满功率 -20dB约为
ON 开机后亮起
削峰/失真 亮起压限电路动作时
增益控制器旋钮（调音量）
300°音量旋钮0/-80dB。
对于正常使用，将控制器保持在最大(0dB)。
SIG 信号指示灯

排风扇
后板功能介绍
4/14
后面板
PKM系列功率放大器
带保险管的
电源插座
信号线连接端
平衡XLR
接线方式
信号输入端 INPUT
信号连接端
信号输出端 LINK
黑色
红色
负极/黑色
CH1
CH2
正极/红色
负极/黑色
正极/红色
功率输出端
音箱连接端
产品正常工作范围
为4~16欧,
但不建议使用4欧
焊接质量很重要 !
虚焊或是焊接错误，
将可能影响到正常使用,
甚至产生故障。
音箱螺旋插头 Speakon（NL4）

5/14
技术指标
PKM系列功率放大器
功率
其他参数
20Hz-20KHz(+0/-0.8dB)
频率响应
型号
PKM6.5
总谐波失真
≤0.05%
信噪比
≥85dB
阻尼系数 ≥300
机箱尺寸（mm）
SAE保留对以上参数的解释权，参数有所变动恕不再另行通告，最后参数以产品说明书为准。
适用型号：PKM6.5/PKM8.5
使用功能
连接器
输出部分 SPEAKON（音箱螺旋座）
面板功能 电源开关/音量控制旋钮/电源指示/信号指示/ 削峰压限指示/保护指示
输入部分 平衡输入XLR母插座/平衡并接XLR公插座
保护功能 VHF、软启动、直流、短路、过载、削峰/失真压限、过热、开机音量渐大
冷却
从前到后抽风
输入阻抗(平衡/不平衡）
20kΩ/10kΩ
输入灵敏度
0.775V
电压增益 39dB
输出类别
转换速率 ≥10V/μs
TM
Class I
尺寸和重量
电源
产品外形尺寸(Wx Lx H) (mm)
毛重
外包装尺寸(Wx Lx H) (mm)
483x245x89
6A电源线
520x370x170
注意：1. *此功率是按照EIA标准测量得出;
3. **,此功率是使用20ms脉冲1kHz正弦波在1%总谐波失真下测量得出 。
12.1kg
8Ω单通道功率* 650W
8Ω立体声功率** 700Wx2
PKM8.5
800W
900Wx2
4Ω立体声功率** 1000Wx2 1200Wx2
40.2dB
483x245x89
6A电源线
520x370x170
13.3kg

故障排除
6/14
PKM系列功率放大器
功放保护指示灯（PROT）点亮
此指示灯点亮表明功放进入保护状态。形势不妙！
1、可能是温度过高、有高于4K的连续正弦波输出超过
1秒、输出短路或接近短路等。以上情况可恢复的。并非
故障。等恢复后可继续使用。但过热会等待较长时间才
可恢复。并且出现过热时就必须检查产品的风扇是否运
作正常，空间温度是否过高等，须排除问题后才
可继续运作。若怀疑音箱短路，可以用万用表测量音
箱线两端直流电阻是否低于2欧甚至1欧。（因电阻较小，
为保证测试精度，请校准万用表后再测量）
2、此灯常亮，不可恢复
此类情况一般为功放本身故障导致，请联系维修人员跟进。
有交流声（哼声或称之为电流声）
1、功放不插入任何信号就有交流声
请将功放搬离于系统电源地线隔离的位置继续测试，只
连接火零N/L，不连接地线。若输出还是有交流声，可判断
为产品本身有问题，请与维修人员联系。
2、连接系统后有交流声
此现象为系统各单元设备的地电位不同而产生的。多数出
现在供电为三相电时，各设备连接不同的相线，甚至不同
上庄电源，零线带电导致，并非功放故障。
解决办法超出本说明书叙述范围，这里附赠解决经验，
仅供参考，本厂不对此叙述负责！
A、梳理用电，尽可能使用同一配电箱的电源。
B、在必须接地的情况下，将不同的接地点强迫接为
一点，在此动作前，请判断地线电位必须为零，若地线
本身带电，则表明地线可能与零线相连。请先解决此问题。
C、我们不建议浮地使用设备。
以下情况表示放大器需要维修
1.产品冒烟或者发出严重烧焦味而不能使用时
2.机箱严重凹陷或者变形
3.产品浸入液体中
4.内部部件松动
5.加电时交流断路器自动跳开或保险管熔断
通电后，无任何反应
马上用万用表测量插座是否有电，在没有万用表时可用试
电笔，但必须灯泡显示明亮，否则可怀疑电压不正常。若
插座电压正常，供电无怀疑后，通电的功放仍然无任何反
应，则可判断该功放有故障，需要专业人员进行进一步故
障判断。
功放无声音输出
1、首先判断输入的信号是否正确
卡侬XLR的2/3脚有无反接的可能，地屏蔽线是否连接
可靠。跟据输入线路的设计不同，可能在以上有些产品会
表现正常，而有些则无声，请必须按照2+、3-的方式连
接。不可以采用比对其他功放（包括同厂产品）的方式
判断。
2、面板指示信号灯不亮
排除信号线问题后，若功放无输入信号反映，可判断功放
本身可能存在故障，需专业人员进行进一步故障判断。
3、输入信号正常但仍无声
正面的信号指示灯是否有闪动和根据音量大小而跳跃，若
正常，而无声音输出，立即检查连接的NL4插头是否连接
正确（±1，±2的连接问题）是否连接牢靠。若以上都无
问题，仍然无声，可以尝试其它通道观察是否有相同的现
象。若还是一样，请立即更换另一个NL4插头再作连接尝试。
跟据经验，可能有某些插头和该产品的插座接触不良
导致的。
功放输出声音失真
1、失真表现为小声音已经很明显能听出声音有破裂声在
排除信号本身和音箱的问题后，可判断为该功放可能存在
故障。需专业人员进行进一步故障判断。
2、某个频段失真
首先判断音箱本身是否能承受该功放的输出功率，一般在
95~105分贝时判断，再大的音量输出不作评论。本篇幅
只讨论功放自身问题的排除。若是在中频段声音有轻微破
裂尾音，并且在音量越小时表现为越明显，可判断为功放
可能有交越失真，此失真声音比较容易和音箱本身高频激
励器故障混淆，请做出判断前最好再连接其它判断为正常
性能的音箱比较测试一下。
3、大声压时失真
在小声压时表现正常的情况下，首先判断音箱对所播放音
乐信号的大动态时的承受能力。请在合适的音量下聆听判
断，若功放削峰指示灯（CLIP）时常亮起，请再降低音量
后判断。音箱和功放都有适用的范围，请在所能接受的范
围内使用，在超大音量下失真则可能功放及音箱都已经进
入饱和状况，请适当降低音量使用。

保修条例
7/14
PKM系列功率放大器
免责声明
蜚声演出器材制造有限公司对于因不当使用本产品而导致扬声器或其它设备损坏不承担任何责任！蜚声
演出器材制造有限公司对本产品提供2年有限质量保证。蜚声演出器材制造有限公司保证其产品自销售
之日起2年内不会发生材料和制造工艺缺陷；若在正常安装和使用条件下发生的损坏，蜚声演出器材制
造有限公司将按照质保协议无偿更换有缺陷的零件和维修故障产品。但客户必须将产品送回我们的工厂
或授权的维修点或指定经销商处，同时必须预付运费和附带购买证明（产品保修卡客户联及销售收据或
发票复印件）。
此质保协议规定，退回的产品必须经过我们检查判断存在质量缺陷。本质保不适应于任何误用、疏忽、
意外、不正确安装而导致损坏的产品或日期编码、序列号被去掉或破损致不能辨认的产品。蜚声演出器
材制造有限公司不对意外或间接发生的损害承担责任。此质保赋予您特定的法律权利。
通讯地址：
蜚声演出器材制造有限公司售后服务部
中华人民共和国，广东省，佛山市，南海区，和顺，文教路东段39号，蜚声工业园。
邮政编码：
528241
电话：
0757-8560-8331
传真：
0757-8568-8191
电子邮件：
[e-mail]
品牌网址：
www.lexpro.com.cn
制造商网址：
www.saeaudio.com
为满足中国《电子信息产品污染控制管理办法》（信息产业部第39号令）的相关规定和要求，现对产品中有害物质，按部件分类，
声明如下：
备注：
○：表示该有害物质在该部件所有均质材料中的含量均在SJ/T11363-2006规定的限量要求下
×：表示该有害物质至少在该部件的某一均质材料中的含量超出SJ/T11363-2006规定的限量
要求。
有毒有害物质或元素
部件名称
机箱
主板模块
电源模块
I/O板模块
控制模块
铅（Pb） 汞（Hg） 镉（Cd） 六价铬
（Cr(VI)）
多溴联苯
（PBB）
多溴二苯醚
（PBED）
灯板
在中华人民共和国境内销售的电子信息产品上将贴上有“环保使用期限”（EPuP）符号。
圆圈中的数字代表产品的正常环保使用年限。 图示：
产品物质拆分表

8/14
Important Safety Instruction and symbol description PKM Series Power Amplifier
1.Read these instructions.
2.Keep this user manual.
3.Pay attention to all the notice.
4.Comply with these instructions.
5.It is forbidden to spray liquid around the equipment. Please do not place liquid container above the
product, such as vases, etc.The dry cloth and air pressure gun can be used for cleaning.
6.Warning:Avoid the formation of hot air circulation. Installation as suggested way.
7.Do not install near heat, make sure the application temperature is °C.below 35
9.Protect the wire from being trampled or extruded, especially the plug, socket and the connector of it.
Warning: As a circuit to cut off the device, the power plug or equipment coupler should be kept
available at any time.
10.Make sure the startup and turnoff procedure: Pre-amp - Amplifier (Power on) Power amplifier (off)
-Pre-amp.
12.Signal distributor is advised to be used when the input signal paralleled with more than 3 amplifiers,
to ensure the input signal without distortion.
13.Don't connect the output interface of one channel to the input interface of another channel in the
power amplifier. Don't connect one power amplifier to another one by connecting their output in
series or parallel connection.
14.When equip the audio equipments, the power of the power amplifier should be 50%-100% more
than the loudspeaker power. Be careful when in bridged mode.
11.Power supply voltage must be in accord with the requirement of the equipment before use it.
16.Suggestions:
1) Good quality NL4 Speakers screw plug is advised.
2) Power distribution system should ensure the safety of applications of more than one amplifier.
15.When maintenance, don't connect the probe of the oscilloscope to the output interface under
bridge mode in case of damaging the power amplifier and the oscilloscope.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE.
8. Ground protection measures should be taken when the equipment is connected to the power outlet.
The lightning bolt triangle is used to alert the
user to the risk of electric shock.
Non-professional qualified technicians do not
open TOP OR BOTTOM COVERS for maintenance
The exclamation point triangle is
used to alert the user to important
operating or maintenance instructions.
This equipment is only to use safely in
the not tropical climate conditions

9/14
Welcome
Thank you for purchas our products.
The PKM series professional power amplifier,
simple to operate、stable、high performance-cost
rate. Special design for KARAOK ROOM、sound
reinforcement, small performances, lectures and
other places. Please take the time to study this
manual so that you can obtain the best possible
service from your amplifier.
ing
Important safety precautions
Our products has already taken the safe requirement
in to consideration and all the finished products have
been tested under the requirement of the government
before sale. Due to the inner dangerous high voltage
and electricity, we strongly recommend you read all
instructions, warnings and cautions contained in this
manual. It will increase the chance of getting shock by
the electricity if the product falls down, recess in the
appearance, soaked or there were some parts loose
internal. If there are problems above, please turn off
power immediately and send the defective units to
local distributor for service.
Unpacking
Please unpack and inspect your amplifier for any
damage that may have occurred during transit.
Confirm the preset voltage of the power amplifier
matches your local voltage rating ( Please refer to
the print on the rear panel for detailed information).
We also recommend that you save all packing
materials so you will have them when need to
return the power amplifier.
The Standard Voltage：200V-240V
Model
Dissipation Power Cable size
Referring to the power dissipation and power
supply/AC of different product for wiring
We suggest the users to match not less than the
following wiring size specifications, to obtain the
better comprehensive properties.
Power & Wiring distribution
PKM Series Power Amplifier
Foreword
2
PKM6.5 1100W ≥1.5mm
2
PKM8.5 1500W ≥1.5mm

10/14
Front panel functions PKM Series Power Amplifier
Front Panel
Mounting hole
Control panel
Cleaning guide of the dust filter
The first time cleaning of the strainer mesh
should be right after installation.
Recommend to clean the strainer mesh
quarterly.
Please do not run the product without the
dust filter, or it makes the service
life of the product shorten.
Such
no warranty.
condition will be considered as
Suction/
Dust filtering sponge Power switch
Illuminates when compressor / limiter is
protecting the amplifier from input overload.
CLIP
Illuminates when either protection
circuit action.
PROT
Illuminates when output signal around -5dB
than full power.
-5dB
Illuminates when output signal around -10dB
than full power.
-10dB
Illuminates when output signal around -20dB
than full power.
-20dB
The signal light
SIG
CH1-CH2
Gain Controller Knob
300°volume knob from 0 to -80dB.
ON Illuminates when the amplifier start.

FAN
Rear Panel
Signal
connector
Signal connection
Signal output LINK
Signal input INPUT
The speaker connector
The quality of your
soldering is very
important
Virtual welding or
soldering errors,
Would be likely to
affect the normal
Use or even failure
BLACK
RED
INPUT
Balanced
male XLR
CH1
CH2
negative/black/nero
positive/red/rosso
positive/red/rosso
negative/black/nero
Power cord
11/14
It can work from
4-16Ω in stereo or
parallel mode.
but not suggest to
use in 2ohm.
Speakon（NL4）
Amp output
PKM Series Power Amplifier
Rear panel functions

6A power cord
Power Supply
Dimensions/Weight
G.W.
Packaging Dimension(mm)
Product Dimension(mm)
1、*,The power is tested under EIA standard.
2、**,The power is tested under the condition of 20ms burst,1kHz sine wave and 1% THD
Remark：
483x245x89
12.1kg
560x420x170
Nl4 SPEAKON
Balance input XLR-F, Balance output XLR-M
Connection
Input
Output
Function
Front panel
Other Specifications
Frequency response
THD+N
S/N rate
Damping factor
20Hz-20KHz(+0/-0.8dB)
<0.05%
≥85dB
Slew rate
Input sensitivity
Cooling
Output circuitry
Voltage gain (8 ohm）
Protection
Input impedance(bal/unbal)
Soft start , short circuit over load clip limit over heat progressive volume, , , , , VHF
Air flow from front to rear
TM
Class I
20kΩ/10kΩ
0.775V
39dB
≥10V/μs
≥300
12/14
Suitable model:PKM6.5/ 8.5PKM
Specifications PKM Series Power Amplifier
Model
Output power
8Ω *
8Ω stereo**
4Ω stereo**
Product dimension(mm)
The manufacturer reserves the rights to make changes in specification without prior notice.
The final specification is subject to the user's manual.
PKM6.5
650W
700Wx2
1000Wx2
Front panel indicator: Working indicator Signal/Clip/Protection/Power on/-5db/-10db/
-20db / volume control knob
PKM8.5
800W
900Wx2
40.2dB
483x245x89
520x370x170
13.3kg
1200Wx2

13/14
Troubleshooting
PKM Series Power Amplifier
After powered without any response
Measure the outlet with a multimeter to check if there is power
available and when no multimeter, you can have a test pencil.
If the power supply is normal and the amplifier still no response
when powered then there is something wrong with the
amplifier, need professional person to check it.
No signal output
1.Frist check if the signal input is right.
Check the connect of XLR, if the 2 and 3 reverted or the
ground is reliable. Different circuitry design will have different
connect way of the XLR, please follow the 2+、3- to soldering.
It can not be judged by comparing with other amplifiers
(including other amplifiers in the same factory).
2.The signal light don't lights up
If all the signal input is fine and the signal light don't lights up
then may the amplifier has failure, you need to ask the
professional person to check it.
3.Signal input normal but no sound
The signal light will flash with the change of input Volume,
but now sound out, then you can check the connect of speakon
if it is connect good and the wires are connect right(some times
the problem of the wires connect, check its±1 and ±2 connect),
after the check above if still no sound out, please change a
speaker cable and check again. Because some times also caused
by the bad quality of the Speakon connector problem of the
amplifier.
Through experiences, it may caused by the bad connection
of some plugs and the socket.
Output sound distortion
1.After check the signal and loudspeaker they are fine and still
can hear distortion when small sound, then may the amplifier
has failure, need professional person to check it.
2.Some frequency band has distortion
First, check if the loudspeaker already overload, normally
judge it in 95~105dB for higher SPL we don't comment here.
Here we just think about the failure recovery of the amplifier.
If in the middle have some rupture sound and more smaller
volume more obvious, then it should be crossover distortion
of the amplifier and this kind of distortion is easy to confuse
with the failure of loudspeaker itself. If the amplifier have
problem then you should send back to the manufacture for
repair.
3.Distortion is High SPL
If the sound is normal when small volume and then you need
to check the limit SPL of the loudspeaker. You can listen it in
suitable volume and if clip light works, then you need reduce
the output. Both loudspeaker and amplifier have limit, you
should use them in their limit if in very high SPL they have
distortion you should take care of them and reduce the output
to the right position.
The protection light blinks
When the PROT light works, the amplifier into the
protection mode.
1.Maybe the temperature is too high or output short or near
short and they are not failure they can recovery after you can
use it normally. But over heat will take more time to recovery.
Also when over heat happened you should check the fan and
the temperature of the install environment, if does you should
solve the problem then can use amplifier. If you think the
speaker was short, you can with a multimeter to check if the
resist is lower than 2 ohm or 1 ohm with DC(Please calibrate
the multimeter to measure for accuracy because of the small
resistance).
2. If the PROT light always light up then it should be the
problem of amplifier, you should send it back to professional
person for repair.
Hum in the system
1. Hum exists even when there is no signal
Please keep the amplifier away from earth wire of power supply
cables, just connect the fire wire and zero wire, no ground wire.
If the hum is still existing, it can be judged that there are some
problems in the amplifier. Please get in touch with professionals.
2. Hum exists when the system is completely connected
This is caused by the different ground voltages in difference
devices in the system, mainly happens when the power supply
is under three-phase distribution condition, each device is
connected to different phase. This is not caused by amplifier.
Solution experiences, just for reference
A. Combing the electricity, the power distribution box using the
same one for all if possible.
B. Make sure the grounding wire potential is zero and force the
different grounding wire to the same level, if the grounding
wire Itself charged, indicates that the wire may be connected
with the zero line. Please solve this problem.
C. If unavailable above, then only to disconnect the ground
wires of all devices, which helps to reduce the AC. But this is
not meet the safe use of electricity, users must know what
will happen if to do in this way. We do not recommend the
floating use.
The amplifier is required maintenance in the
condition below:
1. If the amplifier smokes or smells burning.
2. If the cabinet has severe indentation and deformation
3. If the amplifier are dipped into the water
4. If the internal components loosen
5. If AC breaker skips out when current increases.

14/14
Disclaimer
SAE Audio Co., Ltd. is not responsible for any damage of loudspeakers or other equipments caused by
SAE Audio Co., Ltd. limited
SAE Audio Co., Ltd.
SAE Audio Co., Ltd.
SAE Audio Co., Ltd.
SAE Audio Co., Ltd.
Brand website
offers 2 years warranty for this product.
Guarantees that this product has no material defect during two years from the sales
date; if the damage caused under the normal installation and operation, shall change t
he defective component and repair faulty product for free according to this Quality Guarantee Agreement.
However, users must send the product to our factory or any authorized maintenance points or designated
distributors, affording the re-paid freight, together with buying proof (including customer copy of product
warranty card and payment receipt or invoice copy).
As per this Quality Guarantee Agreement, the returned product must be judged having manufacturing
defect it self after our inspection. This agreement doesn't apply for products with damage caused by any
wrong operation negligence, accident, inappropriate installation or products with no date code and
sequence no or damaged ones beyond recognition.
shall not afford responsibility for any damage caused by accident or indirect factors.
The agreement authorized you specific legal rights.
Address:
After Sale Department
PC:
528241
Tel:
0757-8560-8331
Fax:
0757-8568-8191
Email:
suppor[email protected]
Website:
www.saeaudio.com
negligence or improper installation.
No.39,East,Wenjiao Road,Heshun,Lishui,Nanhai,Foshan,Guangdong,China.
：
www.lexpro.com.cn
Warranty
PKM Series Power Amplifier

Manufacturer:Sae Audio Co.,LTD.
Sae reserves the right to make changes in specifications
and products without prior notice.
制造商：蜚声演出器材制造有限公司
蜚声演出器材制造有限公司版权所有
www.lexpro.com.cn
