SAFARI Montage SD/HD MPEG Digital Encoder Assembly instructions

SAFARI MONTAGE®
SD/HD MPEG DIGITAL ENCODER™
INSTALLATION AND SETUP GUIDE
SD/HD MPEG Digital Encoder | G1571 Standalone
QUAD SD/HD MPEG Digital Encoder | G1572 Rack Mount

2

3
SAFETY PRECAUTIONS
The presence of this symbol is to alert the installer and user to the presence of uninsulated dangerous voltages
within the product’s enclosure that may be of sufficient magnitude to produce a risk of electric shock.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS DEVICE TO
RAIN OR MOISTURE, AND DO NOT OPEN THE DEVICE. REFER SERVICING TO QUALIFIED
PERSONNEL ONLY.
•DO NOT apply power to the device until all connections have been made, all components have been installed
and all wiring has been properly terminated.
•DO NOT terminate, change or uninstall any wiring without first disconnecting power from the device.
•Use only the supplied 12VDC power supply with the center pin positive or power cord. The use of any other
power supply or cord may cause damage and void the warranty.
•The device must be installed in an environment consistent with its operating temperature specifications.
Placement next to heating devices, ducts or areas of high humidity is to be avoided, as doing so may cause
damage and void the warranty.
•DO NOT cover any of the device’s ventilation openings.
•If the device has been in a cold environment, allow it to warm to room temperature for at least 2 hours before
connecting power.

4
Product Description
SAFARI Montage®SD/HD MPEG Digital Encoders™ provide a powerful and ultra-reliable, “out of the box”
solution for your entire IP Television, digital signage and digital media encoding and distribution requirements.
G1571 Standalone SD/HD MPEG Digital Encoder G1572 Quad SD/HD MPEG Digital Encoder
SAFARI Montage®SD/HD MPEG Digital Encoders™ encode incoming digital or analog video to deliver an
MPEG-4 H.264 or MPEG-2 network stream over the IP network to any SAFARI Montage®user, SAFARI
Montage®Digital Signage or Classroom Media Controller (CMC) and provide efficient remote management via
an integrated, password-protected, embedded web server.
Both the G1571 Standalone and G1572 Quad SD/HD MPEG Digital Encoders offer flexible video input options,
supporting HDMI, component and composite inputs, and SD through HD resolutions ranging from 480i to
1080p.
The compact G1571 standalone unit is ideal for single source server room, office or classroom use, while the
G1572 quad rack-mount encoder model is designed for server room or “head end” use.
This manual describes the setup and use of both the G1571 standalone and G1572 quad rack-mount models.

5
Unpacking and Inspection
Ensure that all items are removed and inspected prior to discarding any packing material.
Thoroughly inspect the unit and all contents to make certain all components are present and no damage has
occurred in shipping, paying particular attention to connectors. If there is any sign of damage to the unit or items
are missing, please contact SAFARI Montage Technical Support. SAFARI Montage Technical Support is
available Monday – Friday from 8 a.m. to 6 p.m. Eastern Time, and they may be contacted by telephone at 800-
782-7230 or online via http://www.safarimontage.com/support/.
Package Contents
•G1571 Standalone SD/HD MPEG Digital Encoder with:
o(1) 12V Power Adapter
o(1) 6’ RJ45 Cat-5E Patch Cable
o(1) 6’ YPbPr Component Video Cable
o(1) 6’ Video + Stereo Audio Composite Cable
o(1) 6’ HDMI Cable
•One G1572 Quad SD/HD MPEG Digital Encoder with:
o(1) Power Cord
o(4) 6’ RJ45 Cat-5E Patch Cable
o(4) 6’ YPbPr Component Video Cable
o(4) 6’ Video + Stereo Audio Composite Cable
o(4) 6’ HDMI Cable

6
SAFARI Montage®SD/HD MPEG Digital Encoder™Specifications
Video Input
HDMI 1.4 Digital – 480i to 1080p
Component YPbPr – 480i to 1080i
Composite CVBS – 480i
Video Encoding
H.264 SD - Supported bit rates 1 - 4 Mbps
H.264 HD - Supported bit rates 2 - 10 Mbps
MPEG-2 SD - Supported bit rates 2 - 8 Mbps
MPEG-2 HD - Supported bit rates 10 - 20 Mbps
Unicast, Multicast and DNLA Streams
Audio Input
HDMI, Digital Stereo Audio
Dual RCA, Analog Stereo Audio
G1571 Standalone only
Coaxial (S/PDIF RCA), Digital Stereo Audio
Optical (S/PDIF TOSLINK), Digital Stereo Audio
Audio Encoding MPEG-4 ACC; 128, 256 and 384 kbps
MPEG-1 Layer 2; 128, 256 and 384 kbps
Management Configuration/Remote Status Monitoring Via On-Board Web Server
Software Updates
Remotely Upgradeable Via Web Interface
G1571 Standalone only
USB Via Front Panel USB Port
PC
Windows Vista®
Windows 7®
Windows 8®
MAC OS X®v10.6 – 10.9
Network 10/100/1000 Base-T Ethernet
Power 12VDC @ 1.5 A – G1571 Standalone
12VDC @ 3A – G1572 Quad Rack-Mount
Dimensions 9.3" (W) x 6.1" (D) x 1.4" (H) – G1571 Standalone
17.5" (W) x 7.2" (D) x 1.75" (H) – G1572 Quad Rack-Mount
Included
6' RJ45 Cat-5e Patch Cable
6' YPbPr Component Video Cable
6' Dual RCA Audio Cable
6' HDMI Cable
Note: G1572 Quad Rack-Mount Contains Four (4) Sets
Warranty 3 Years

7
SAFARI Montage®SD/HD MPEG Digital Encoder™Front Panel
Buttons/LEDs
(Each encoder on the G1572 has one of the
following buttons/LEDs unless otherwise
noted)
Description
Reboot button Reboots the Device (Unsaved Settings Will be Lost)
RST / UPG button To Reset All the Settings of the Device to Factory Default:
1. Disconnect Power.
2. Press and Hold the RST/UPG Button, then Connect Power.
3. Hold the Button Until CFG LED Flashes 10 Times (about 10 seconds).
4. After the CFG LED Stops Flashing, Release the RST/UPG Button.
To Upgrade Firmware Using the USB Port (G1571 Only):
1. Disconnect Power.
2. Plug in the USB Drive Containing the Firmware Upgrade.
3. Press and Hold the RST/UPG Button, then Connect Power to Boot-Up the Encoder.
4. The USB LED Will Flash While Copying the Firmware Image from USB Drive (About
3-5 Seconds).
5. Wait Until the CFG LED Stops Flashing.
6. Release the RST/CFG Button, and Wait for the Device to Reboot and Upgrade the
Firmware (About 1 Minute).
7. Reset the Cache on your Browser After Upgrading the Firmware.
NOTE: The Firmware May Also be Upgraded by Uploading the Firmware Image Via the Web
UI Administration Page.
PWR Indicates that the Device is Powered
CFG Indicates that the Device is in Configuration Mode
USB Indicates that a USB Drive is Mounted (G1571 only)
MPEG-2 Indicates that the Device is Encoding Video in MPEG-2 Format
AVC Indicates that the Device is Encoding Video in H.264/MPEG-4 Part 10/AVC Format
MP2 Indicates that the Device is Encoding Audio in MPEG-1 Layer 2 Format
AAC Indicates that the Device is Encoding Audio in AAC Format
AC-3 Indicates that the Device is Encoding Audio in AC-3 Format

8
Installation and Configuration
Please read these instructions in their entirety before you begin:
•Review any questions with Technical Support in advance. Please note that SAFARI Montage Technical
Support is available Monday – Friday from 8 a.m. to 6 p.m. Eastern Time, and they may be contacted by
telephone at 800-782-7230 or online via http://www.safarimontage.com/support/.
SAFARI Montage®System Requirements:
•SAFARI Montage®v5.8.x
•SAFARI Montage® Media Player v5.9.x with VideoLAN VLC Media Player v2.03 32-bit
•SAFARI Montage® Digital Signage Controller Software v6.0.x
Before You Begin:
•Make all connections before powering the encoder.
•Note that all G1571 standalone encoders ship with a default static IP address of 191.53.51.207.
•Note that all G1572 quad encoders ship with the following default static IP addressing scheme.
o191.53.51.207 – 1st encoder
o191.53.51.208 – 2nd encoder
o191.53.51.209 – 3rd encoder
o191.53.51.210 – 4th encoder
•If using UPnP/DLNA, all devices, including the encoder, SmartTV and the configuration PC, should be
located within the same local network segment.
•SAFARI Montage strongly recommends that video sources be connected directly to the SD/HD MPEG
Digital Encoder with the supplied cabling. SAFARI Montage cannot provide support for third-party
distribution and/or switching equipment placed inline between the video source and the encoder.
•The encoder is designed to work with input sources set to 30 or 60 FPS. Please make certain your video
source equipment is set for 30 or 60 frames per second.

9
Initial Network Configuration:
1. Connect the encoder to an isolated network switch for configuration.
2. Connect a PC to the network switch, and configure the PC with an IP address in the 191.53.51.xxx subnet,
e.g., 191.53.51.10.
oBe certain to avoid assigning the PC the default encoder IP address (191.53.51.207).
3. Power the encoder via the supplied power adapter or cord.
4. Configure the network settings as required to conform to the local network addressing scheme.
a. All encoders ship with a default static IP address of 191.53.51.207.
b. Open a web browser and navigate to http://191.53.51.207:8888 to view the encoder
Overview page.

10
c. Click on Network Setup to configure the network settings and login with the
default credentials:
Username: admin
Password: Admin123
d. Set the encoder Hostname, IP address and network configuration as required to unique values that
conform to the local network address scheme.
5. If configuring multiple encoders, repeat the process for each unit, assigning a unique IP address and
hostname to each encoder.
6. Once networking configuration is complete, reconfigure the client PC to the local network addressing
scheme, confirm the encoder(s) may be reached via http://[New IP Address]:8888 and
continue configuration.

11
Encoding Configuration:
Once the encoder(s) have been configured for your network, you may proceed to configure the remaining
settings.
1. Power off the encoder.
2. Connect the media source (cable tuner or other device) to the encoder by using the HDMI, component
(YPbPr) or composite (CVBS) cables included.
3. Power on the encoder and continue encoder configuration.
Encoder Overview:
The encoder Overview page provides an overview of the current encoder settings and a preview of the encoder
output. The Overview page is accessible without a username and password.
Directly to the right of the “Welcome!” label is the unit identification link. Clicking on this link allows
administrators to easily identify a specific encoder by flashing the CFG LED on the encoder front panel. To
disable, simply click on the unit identification link again.

12
Encoder Setup:
Recommended initial configuration values for the encoder are depicted below.
It is recommended that you begin with the settings below and adjust as required, based on specific needs.
Note: The encoder will use the Video Bitrate set for SD Source or HD Source based on the resolution of the input
source, e.g., an input source of 480p will use the SD Source value while a 720p or 1080p source will use the HD
Source value.

13
Device Name and Program Name:
Set the Device Name and Program Name as desired. The encoder will appear with the configured Device
Name when browsing the local network segment via UPnP.
Closed Captioning:
The encoder supports the display of analog closed captioning via the Composite (CVBS) input when used
with a compatible display or media player.
Note that the encoder also supports closed captioning when using an HDMI or Component (YPbPr) source
that supports analog captioning and simultaneous output via Composite (CVBS).
Closed-captioning support is dependent on your video source equipment and display capabilities, and it is
recommended that equipment capabilities be verified and tested to confirm captioning support.
To enable closed captioning for display:
1. Enable closed captioning on the Encoder Setup page.
2. Connect a video source with analog closed-captioning support to the Composite (CVBS) port.
3. If using an HDMI or Component (YPbPr) video source, connect via HDMI or Component (YPbPr).

14
Streaming Setup:
The encoder supports flexible streaming configurations to meet various needs, including multicasting,
unicasting and DLNA/HTTP streaming.

15
Multicasting Configuration:
SAFARI Montage®typically utilizes a UDP multicast streaming configuration as described below. The
encoder also supports RTP multicast for applications where required.
Enable Multicast: Enables/Disables multicast
Group IP: Enter a multicasting address e.g. 239.xxx.xxx.xxx
Multicast Port: Enter a multicasting port ranging between 1024 and 65535
Multicast TTL: Enter a Time To Live (TTL) limit value ranging between 1 and 255
Enable RTP: Enables/Disables RTP
To verify the multicast streaming configuration:
1. Using the VLC media player, select Media > Open Network Stream.
2. Enter the encoder streaming URL in the following format:
udp://@[Multicast Group IP Address]:[Multicast Port]
Ex. udp://@ 239.21.230.200:1234
3. Click on the Play button to view the video stream.

16
Using With SAFARI Montage Products:
To configure in SAFARI Montage®Selective Video Streaming:
1. Login to SAFARI Montage as an administrator.
2. Navigate to Admin > Selective Video Streaming > Video Streaming.
3. Click on the New Stream link.
4. Select a school, enter a descriptive name and enter the streaming URL in the following format:
udp://@[Multicast Group IP Address]:[Multicast Port]
Ex. udp://@239.21.230.200:1234
5. Set Type (for recording) to SAFARI SD/HD Encoder.
6. Configure additional stream settings as desired, and click on Add to save the new stream.
7. Click on the stream name to navigate to the stream detail page.
8. Click on the Play icon to verify playback.

17
To configure for use with SAFARI Montage®Digital Signage Controller:
1. Access the SAFARI Montage Digital Signage Controller web UI.
2. Navigate to Control > Playlist.
3. Select Edit from the Action dropdown list.
4. Enter a descriptive name for the encoder stream and select New URL from the dropdown then click
the Add button.
5. Enter the streaming URL in the following format into the Media URL and click Save:
udp://@[Multicast Group IP Address]:[Multicast Port]
Ex. udp://@239.21.230.200:1234
6. Click Control > Current View to return to the Current Playlist view.

18
Unicast Configuration:
Note that SAFARI Montage®does not typically utilize a unicast streaming configuration; however, the
encoder supports TCP/UDP/RTP encoding for applications that require it.
Protocol: Select TCP, UDP or RTP
Destination IP: Enter the IP address of the client receiving the encoder stream
Destination Port: Enter a port ranging between 1024 and 65535
Add (button): Use to add clients to the Casting List
Casting List: List of clients, up to eight, that can receive the unicast stream
Remove (button): Use to remove clients from the casting list
To verify the multicast streaming configuration:
1. Using the VLC media player, select Media > Open Network Stream.
2. Enter the encoder streaming URL in the following format:
udp://@[Unicast Port]
Ex. udp://@1234
3. Press the Play button to view the video stream.

19
DLNA / HTTP Configuration:
Note that SAFARI Montage®does not typically utilize a DNLA/HTTP streaming configuration; however, the
encoder supports TCP/UDP/RTP encoding for applications that require it.
Enable HTTP: Enable/Disable HTTP streaming
Enable Auth.: Enable/Disable authentication
RADIUS IP: Enter a RADIUS IP if required
RADIUS Secret Enter RADIUS secret if required
1. To verify the HTTP streaming configuration:
2. Using the VLC media player, select Media > Open Network Stream
3. Enter the encoder streaming URL in the format:
http://[IP address]:[HTTP Port]/VideoInput/play.ts
Ex. http://172.21.230.200:8888/VideoInput/play.ts
4. Press the Play button to view the video stream.

20
Administration:
The Administration page
allows authorized users to:
•Reboot the encoder
remotely
•Reset the encoder to
factory defaults (use
with caution)
•Back up the current
encoder configuration
•Restore a backed-up
encoder configuration
•Upgrade the encoder
firmware by uploading a
new firmware image
•Change the password used to secure the encoder
