SAFE HOME NVR903 User manual

MANUAL – NVR903
UK - DK - SE - NO - FI
SafeHome®
Network Video Recorder
For expanded manual in English
– please visit www.SafeHome.dk

2
SafeHome®Network Video Recorder (NVR903)
www.safehome.dk
In the box / I kassen / I lådan / I boksen / laatikossa

MANUAL
www.safehome.dk
Table of Content / Indholdsfortegnelse/ Innehållsförteckning/
Innholdsfortegnelse/ Sisällysluettelo
Typical Application ..... 3
Typisk anvendelse / Typisk applikation / Typisk application / Tyypillisiä käyttökohteita
Specifications ..... 4
Specifikationer / Specifikationer / Spesifikasjoner / Tekniset tiedot
Installation of HDD ..... 6
Installation af HDD / Installation av HDD / Installasjon av HDD / Asennus HDD
Connections ..... 7
Tilslutninger / Anslutningar / Tilkoblinger / Liitännät
Setup ..... 7
Indstilling / Inställning / Setup / Perustaa
General Setup ..... 8
Generel opsætning / Allmän inställning / Generelt oppsett / Yleiset asetukset
Select Cameras ..... 10
Vælg kameraer / Välj kameror / Velg kameraer / Valitse Kamerat
Recording Plan ..... 12
Optagelsesplan / Inspelningsplan / Recording Plan / Tallennus Plan
Network Setup ..... 14
Netværksopsætning / Nätverksinställningar / Nettverksoppsett / Verkon asennus
System Setup ..... 16
Systemopsætning / Systeminstallation / Systemoppsett / Järjestelmän asetukset
View Recordings ..... 18
Se optagelser / Se inspelningar / Se opptak / Näytä tallenteet
Remote Access ..... 19
Fjernadgang / Fjärranslutning / Fjerntilgang / Etäkäyttö
APP ..... 20

4
SafeHome®Network Video Recorder (NVR903)
www.safehome.dk
The HD NVR is a stand-alone device for scheduled recording/surveillance of up to 4
SafeHome M- and X-series cameras. For compability with other cameras please see
our website.
The HD NVR has to be connected to your router by cable.
Network setup is done by connecting the NVR to a monitor or TV by use of a VGA
or HDMI cable (only HDMI included).
When the NVR is connected to the network, it can be accessed from any Windows
PC on the network, tablet and smartphone using our App, or through the Internet by
using the assigned local IP address or the router’s WAN IP address.
Cameras on local network are automatically detected. Recording, replay and
livestreaming is easily setup.
Harddisk Capacities (approx. recording time)
Cams /resolution 500 GB 1 TB 2 TB 4 TB
1 cam VGA res. 56 days 112 days 224 days 448 days
4 cams VGA res. 14 days 28 days 56 days 112 days
1 cam 1MP HD res. 14 days 28 days 56 days 112 days
4 cams 1MP HD res. 3.5 days 7 days 14 days 28 days
1 cam 2MP HD res. 6.5 days 13 days 26 days 52 days
4 cams 2MP HD res. 1.7 days 3.4 days 6.8 days 13.6 days
HDD must usually be purchased separately and installed
Typical Application / Typisk anvendelse / Typisk applikation /
Typisk application / Tyypillisiä käyttökohteita

5
MANUAL
www.safehome.dk
• Compatible with SafeHome M- and X-series IP camera. For compability with
other cameras please see our website.
• H.264 format storage
• Built-in software
• Setup connection: VGA /HDMI (VGA cable not incl., HDMI incl.)
• Access connection: VGA/HDMI/HTTP
• Network protocol: TCP/IP, UDP/IP, HTTP, NTP, UPnP, DDNS, P2P, ONVIF
• LAN connection (cable incl.): 10Base-T/100Base- TX(RJ-45)
• Harddisk: Up to 1 x 4 TB, 3.5” SATA.
• USB ports: 2 USB 2.0 (for mouse/backup/update)
• Audio input: 1 RCA port (Linear Level)
• Audio output: 1 RCA port (Linear Level)
• Operating temperatures: ÷10-40 °C
• Operating humidity: 10-90 % RH
• Dimensions, mm (L x W x H): 258 x 241 x 45
• Weight without harddisk: 1.050 g
• Power Supply (in/out): 100-240 V (50/60 Hz) / 12 V, Power cons. < 6 W
(Power supply incl.)
Specifications / Specifikationer / Specifikationer /
Spesifikasjoner / Tekniset tiedot

6
SafeHome®Network Video Recorder (NVR903)
www.safehome.dk
HDD – MAX 4TB SATA
Installation of HDD / Installation af HDD / Installation av HDD /
Installasjon av HDD / Asennus HDD
Requested but
not included

7
MANUAL
www.safehome.dk
PW: 123456
12
3
4
Connections / Tilslutninger / Anslutningar / Tilkoblinger / Liitännät
Setup / Indstilling / Inställning / Setup / Perustaa

8
SafeHome®Network Video Recorder (NVR903)
www.safehome.dk
Auto Logout: Max 60 min.
Pack Duration: Max 90 min.
1
2
DHCP
IP
DHCP
IP
192 .168 .3 .1
255 .255 .255 .0
8 .8 .8 .8
8 .8 .4 .4
192 .168 .3 .107
IP
Overwrite
10
90
General Setup / Generel opsætning / Allmän inställning /
Generelt oppsett / Yleiset asetukset

9
MANUAL
www.safehome.dk
3
192 .168 .3 .1
255 .255 .255 .0
8 .8 .8 .8
8 .8 .4 .4
192 .168 .3 .107
IP
Overwrite
10
90
4

10
SafeHome®Network Video Recorder (NVR903)
www.safehome.dk
1
HY_X_IPC: Serie X
HY_M_IPC: Serie M
ONVIF: ONVIF
3
2
4
1. 005faer 48:02:2B:44:6F 192.168.3.125 8082
1
2
Select Cameras / Vælg kameraer / Välj kameror /
Velg kameraer / Valitse Kamerat

11
MANUAL
www.safehome.dk
1. 005faer 48:02:2B:44:6F 192.168.3.125 8082
192 .168 .3 .125
8082
Connect Disconnect
4
3
5

12
SafeHome®Network Video Recorder (NVR903)
www.safehome.dk
Regular
Alarm
Channel
1 2 3 4
Sel All
Copy
OK Cancel
Recording Plan / Optagelsesplan / Inspelningsplan /
Recording Plan / Tallennus Plan

13
MANUAL
www.safehome.dk
1
2
Regular
Alarm
Alarm
Alarm

14
SafeHome®Network Video Recorder (NVR903)
www.safehome.dk
TCP Port 8000
HTTP Port 8080
Port
Cancel AppOK
UPNP
ROUTER
NAT:
Port: 8000 > 192.168.3.107
Port: 8080 > 192.168.3.107
O
Network Setup / Netværksopsætning / Nätverksinställningar /
Nettverksoppsett / Verkon asennus

15
MANUAL
www.safehome.dk
Active X
HTTP Port 8000
TCP Port 8080
Please conrm UPNP function
on the router have enabled.
UPNP port mapping
Cancel AppOK
UPNP
LAN (local)
WAN (remote)
P
http://192.168.3.107:8000
http://(WAN IP):8000
IE 9+
P

16
SafeHome®Network Video Recorder (NVR903)
www.safehome.dk
uu
System Setup / Systemopsætning / Systeminstallation /
Systemoppsett / Järjestelmän asetukset

17
MANUAL
www.safehome.dk
uu
uu

18
SafeHome®Network Video Recorder (NVR903)
www.safehome.dk
u
View Recordings / Se optagelser / Se inspelningar /
Se opptak / Näytä tallenteet

19
MANUAL
www.safehome.dk
IE 9+ EDGE
P
1
2
3
4
PW: 123456
http://123.456.23.45:8000 ~ (WAN IP):8000
Remote Access / Fjernadgang / Fjärranslutning /
Fjerntilgang / Etäkäyttö

20
SafeHome®Network Video Recorder (NVR903)
www.safehome.dk
App: SafeHomeSmartP2P
