Safeaid TS350 User guide

TS350WIREDANEMOMETER
Installation&SetupManual
Version1
THE COMPLETE TS350 WIRELESS WIND SPEED SYSTEM HAS BEEN PRE-ASSEMBLED AND THE
FOLLOWING MANUAL WILL AID IN THE INSTALLATION & SETUP PROCESS
! WARNING !
THE PURPOSE OF THIS MANUAL IS TO PROVIDE THE CUSTOMER WITH THE OPERATING
PROCEDURES ESSENTIAL FOR THE PROMOTION OF PROPER MACHINE OPERATION FOR ITS
INTENDED USE. THE IMPORTANCE OF PROPER USAGE CANNOT BE OVERSTRESSED. ALL
INFORMATION IN THIS MANUAL SHOULD BE READ AND UNDERSTOOD BEFORE ANY
ATTEMPT IS MADE TO OPERATE THE MACHINE.
SINCE THE MANUFACTURER HAS NO DIRECT CONTROL OVER MACHINE APPLICATION AND
OPERATION, CONFORMANCE WITH GOOD SAFETY PRACTICE IN THIS AREA IS THE
RESPONSIBILITY OF THE USER AND HIS OPERATING PERSONNEL.
ALL PROCEDURES ARE BASED ON THE USE OF THE SYSTEM UNDER PROPER OPERATING
CONDITIONS, WITH NO DEVIATIONS FROM THE ORIGINAL DESIGN. ALTERATION AND OR
MODIFICATION OF THE EQUIPMENT IS STRICTLY FORBIDDEN WITHOUT PRIOR WRITTEN
APPROVAL.

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 2
Contents
SYSTEMCOMPONENTS:......................................................................................................................................3
DISPLAYMOUNTINGINSTRUCTIONS:.................................................................................................................3
DISPLAYBOARDPOWERSUPPLYWIRING...........................................................................................................3
CONNECTINGRELAYOUTPUTS............................................................................................................................5
MOUNTINGTHEANEMO4403ANEMOMETER...................................................................................................6
SYSTEMUSE.........................................................................................................................................................6
SYSTEMSTARTUP................................................................................................................................................7
ERRORMESSAGES&UTILISATION......................................................................................................................7
WINDSPEEDLIMIT&UNITSETUP.......................................................................................................................9
SYSTEMSETUP&TESTING.................................................................................................................................10
SETTINGSMENU................................................................................................................................................10
SETDATE&TIME...............................................................................................................................................11
CONTINUOUSLOGGING....................................................................................................................................11
RELOADFIRMWARE...........................................................................................................................................12
TESTMENU........................................................................................................................................................13
SYSTEMINFORMATION.....................................................................................................................................13
TS350TESTS.......................................................................................................................................................14
TOUCHSCREENCALIBRATION...........................................................................................................................15
DATALOGGERSOFTWARESETUPFORPC.........................................................................................................16
BASICSOFTHEPCLOGGINGSOFTWARE‐ccWINDSPEEDLOG..........................................................................17
UNITREGISTER‐ccWINDSPEEDLOG.................................................................................................................19
DOWNLOADINGLOGGEDFILES‐ccWINDSPEEDLOG........................................................................................20
DATABASEVIEWER‐ccWINDSPEEDLOG...........................................................................................................21
CLEARINGDATABASE‐ccWINDSPEEDLOG........................................................................................................23
LOADINGDATABASE‐ccWINDSPEEDLOG.........................................................................................................24


SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 3
SYSTEMCOMPONENTS:
 Anemo 4403 Anemometer
o Head unit (with vanes) & 20m Cable & 3 Pin AT series connecting Plug
o Stainless Steel bracket with oilon bush and washer
 Mounting pole (M10 threaded bar) with mounting foot, lock nuts & washers.
 TS350 Display Unit enclosed in anodized aluminium housing complete with buzzer,
external antenna, universal swivel mounting bracket & 5 meters of 2 core cable for
power supply.
DISPLAYMOUNTINGINSTRUCTIONS:
TOOLS REQUIRED:
1 x Power Hand Drill
1 x 7mm Drill Bit
1 x 5mm Hex Head Allen Key
1 x 10mm Spanner
PROCEDURE:
1. The display unit must be mounted in an easily viewable and accessible place. The display
can be mounted in virtually any suitable place by using the universal ball joint type bracket
which is attached to the back plate of the housing. To allow free movement of the display
on the bracket, turn the wing knob on the mounting bracket anti-clockwise enough to
loosen the bracket. Decide which position is best by turning the brackets to the desired
position and then “locking” the universal bracket by turning the wing knob clockwise until
the ball type bracket does not have any free movement.
2. Remove the two M6 x 30mm socket head cap screws and nuts supplied with the ball
mounting bracket round disc with 4 large (7mm) and 4 small (5mm) holes. Place the disc
where it is to be mounted and mark two mounting holes using 2 of the large holes. Drill
two 7mm holes and fasten the mounting ball bracket using two M6 screws and nuts.
Fasten the screws through the bracket using a 10mm spanner and 5mm Hex Head Allen
key.
3. Locate a suitable power source to power the display unit (2A for the display only). Route
the two-core cable to the power source and connect the numbered wires as indicated:
 Wire # 1 - + Supply (10-36VDC)
 Wire #2 - - Supply (Earth/Ground)
DISPLAYBOARDPOWERSUPPLYWIRING
Power supply cable for the TS350 display unit is prewired on delivery but the following
procedure is used to change the power supply wiring.
Great care should be taken when opening the display unit as wires from the main board are
connected to or running through the back plate and incorrect procedures could result in

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 4
damaging the wires. Please also ensure that the display power is OFF while the following
procedure is carried out.
TOOLS REQUIRED:
1 x 2.5mm Hex Head Allen key
1 x 2mm Flat Head Screwdriver
PROCEDURE:
1. Loosen the gland(s) on the back plate to allow the cable(s) to move freely through the
gland(s).
2. To remove the back plate, loosen and remove the 8 x M3 x 12mm socket head cap
screws completely using a 2,5mm Allen key. Support the plate at all times to ensure
that the plate does not fall.
3. Carefully lift the back plate approximately 130mm away from the aluminium housing
(do not hang back panel from wiring).
4. The buzzer is connected to the main board by red and black wires terminated with a
white Molex connector; this connects onto the receptacle connector on the main board.
To remove the back plate completely carefully unclip the connector from its receptacle.
5. The USB is connected to the main board by brown, blue, white & black wires
terminated with a USB A connector. To remove the back plate completely carefully
unplug the connector from its receptacle.
6. Remove the back plate completely.
7. Make sure the 2A blade fuse is not damaged and is inserted securely.
8. Connect the power wires to the following terminals using the 2mm flat head
screwdriver:
 Terminal ++ - Wire # 1 - + Supply (10-36VDC)
 Terminal -- - Wire #2 - - Supply (Earth/Ground)
9. To close the display:
 Ensure all power wires are securely in the terminals.
 Connect the buzzer’s Molex plug to the circuit boards reciprocal connector.
 Connect the USB A connector to the circuit boards reciprocal connector.
 Position back cover on display box making sure not to pinch any wires and
replace the 8 x M3 x 12mm socket head cap screws.
 Gently pull wire(s) back through glands until slack has been taken up and then
tighten gland(s).

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 5
CONNECTINGRELAYOUTPUTS
The TS350 display unit has provision for wiring up external lights and/or siren using the two
relays mounted on the display board.
 Relay 1 - equal to or exceeding the intermediate limit
 Relay 2 - equal to or exceeding the upper limit
To set up the relevant limits see Windspeed & Unit Setup.
The contact block is situated inside the display unit on the board and the contacts utilsed are
as follows:
RELAY 1 (Intermediate limit)
 NC1 – Normally Closed Contact
 COM – Common
 NO1 – Normally Open Contact
RELAY 2 (Upper limit)
 NC2 – Normally Closed Contact
 COM – Common
 NO2 – Normally Open Contact
TOOLS REQUIRED:
1 x 2.5mm Hex Head Allen key
1 x 2mm Flat Head Screwdriver
PROCEDURE:
Connection can be done to both outputs (intermediate and upper) or individually as required.
1. Open the display box as per the Display Board Power connector wiring.
2. Replace M12 blank-off(s) in back plate with M12 gland(s) as required for output wiring.
3. Establish the relay output required by the device – Maximum 10A @ 250VAC or 10A
@ 28VDC.
4. Connect the required output to the common on the contact block – Preferably use a
separate supply but if low power (less than 2 Amps) or ground feed is required connect
a wire directly from the supply or ground into the Common on the relevant relay.
5. Common signal will now be directed through the relevant relay as follows:
 Normally Open (NO) - Error will close contact
 Normally Closed (NC) - Error will open contact

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 6
MOUNTINGTHEANEMO4403ANEMOMETER
TOOLS REQUIRED:
1 x Welding Machine – Qualified welder to do welding
1 x Hacksaw
2 x 17mm Spanners
PROCEDURE:
1. The anemometer head unit will need to be mounted at the furthest point possible
ensuring that the “wind vanes” are ABOVE the highest obstructive point i.e. on mobile
cranes the unit should be mounted on the tip section above the level of the top of the
boom so that even when the boom is at its highest point, the wind speed meter head
is still above the boom head.
2. Find a suitable place to mount the anemometer. The mounting pole must be cut to the
correct length, we recommend as short as possible to eliminate the possibility of the
unit getting damaged or knocked off. The unit should be positioned correctly and have
complete freedom of movement when swinging. The anemometer has a green nylon
bush & washer where the pole slides through, this is fastened by using two M10 Nylock
nuts & washers on either side of the spacer using the two 17mm spanners. Ensure the
following:
a. DO NOT tighten the nuts together too tightly as the anemometer will not be able
to swing freely & self-level with the movement of the boom
b. Ensure that the threaded bar is flush (inline) with the inner nut so that the
threaded bar does not touch or interfere with the cable i.e. if the threaded bar
protrudes from the nut it will damage the cable.
3. Once a suitable mounting place has been identified, weld the mounting foot to the
crane’s boom. The anemometer is isolated and the bracket may be welded while the
wind speed meter is attached to the pole. If the anemometer has been removed from
the pole refit the anemometer as in point #2 above. 
SYSTEMUSE
The Safe-Aid TS350 unit is designed with ease of operation in mind.
Figure 1

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 7
The working screen (Figure 1) displays the following parameters:
 current wind speed
 wind speed limit (user adjustable maximum wind speed)
 the percentage utilisation – digital and bar graph
 buzzer activated or buzzer override activated
 graphical representation of anemometer
 USB flash drive inserted
The touch screen is sensitive to touch therefore it is not necessary to push hard on the screen
(if touch screen does not work or selects incorrectly see touch screen calibration).
SYSTEMSTARTUP
When powering up the TS350, the system runs through a complete set of internal system
diagnostics to make sure all inputs and outputs are working correctly (Figure 2). The TS350
system goes into the working screen once all the relevant checks have been completed. No
user entry is necessary when starting up.
Figure 2
ERRORMESSAGES&UTILISATION
The wind speed unit measures wind speed between the following parameters.
UNIT OF MEASURE MINIMUM WIND
SPEED
MAXIMUM WIND SPEED
KNOTS 1.0 97.1
MILES PER HOUR 1.1 111.8
KILOMETERS PER HOUR 1.8 180
METERS PER SECOND 0.5 50
The TS350 display unit will only start displaying the wind speed once the Minimum wind
speed has been reached.
If the TS350 display exceeds the user adjustable Maximum speed for the anemometer unit,
the unit will display 100% Windspeed (in red) underneath the “Limit” field and the buzzer will
sound continuously.

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 8
Figure 3
Utilisation: Utilisation is the actual wind speed utilised against the wind speed limits. This is
displayed graphically by the bar, proceeding from green (less than Intermediate Limit), then
amber (greater than or equal to Intermediate Limit but less than Upper Limit) and finally
red (greater than or equal to Upper Limit) increasing incrementally as a percentage.
If the wind speed is equal to or greater than the Windspeed Intermediate Limit (Figure 3) the
following will happen:
 The percentage utilisation bar graph will turn yellow
 Intermediate Windspeed will be displayed below the Limit block
 The display buzzer will sound intermittently
 Top robot type indication light on the top of the screen will change to yellow
 The buzzer symbol will be displayed after five seconds
If the wind speed is equal to or greater than the Windspeed Upper Limit (Figure 4) the
following will happen:
 The percentage utilisation bar graph will turn red
 100% Windspeed will be displayed below the Limit block
 The display buzzer will sound permanently until an intermediate condition or lower is
reached
 Top robot type indication light on the top of the screen will change to red
 The buzzer symbol will be displayed after five seconds
Figure 4 Figure 5

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 9
The display buzzer can be overridden (shut-off) by pressing the buzzer symbol if intermediate
or 100% windspeed is reached. Once the symbol has been pressed (Figure 5) a red cross
will be placed through the buzzer symbol.
WINDSPEEDLIMIT&UNITSETUP
To enter the Windspeed Limits setup, press the screen on the wind speed limit value. The
password screen will appear and a password will be requested (Figure 6). Enter the three-
digit password [___7___] [___9___] [___2___] followed by the Enter key. The Windspeed
Limits screen will now be displayed (Figure 7).
Select the required units by pressing Wind Speed Units. Wind Speed Units will now be
highlighted blue and by pressing the select button the units will change. Each time the Select
button is pressed the units will change sequentially as follows:
 kts - Knots
 mph - Miles per hour
 km/h - Kilometers per hour
 m/s - Meters per second
Figure 6 Figure 7
Once the correct units have been selected, highlight the desired limit and use the keypad to
enter the Intermediate (Figure 8) and Upper (Figure 9) wind speed limits. The system has a
pre-programmed conversion formula so the limits can be set in one unit of measure but shown
in another with no calculations needed by the operator. This can be done by just selecting
the correct unit, inputting the desired limits and then changing the units to the required units
to be displayed.
Figure 8 Figure 9

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 10
Once the limits and correct units have been set press the Back button, the system will return
to the working screen. 
SYSTEMSETUP&TESTING
To enter the Settings & Test Menu:
 Press the screen in the top left hand corner.
 The password screen will appear, and a password will be requested (Figure 10).
 Enter the 4-digit password [______] [______] [______] [______] followed by the Enter
key. Contact your authorized distributor or email the factory for password access.
 The Settings & Test Menu screen will now be displayed (Figure 11).
Figure 10 Figure 11
SETTINGSMENU
To enter the system setup of the TS350 display unit
 Press the Settings Menu button
 Settings Menu will be displayed (Figure 12).
Figure 12 Figure 13
From this menu you can setup all the parameters of the entire TS350 wind speed meter.
The following parameters can be set here:
 TS350 Configuration (Figure 13)
 Set Date & Time
 Continuous Logging

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 11
 Reload Firmware
SETDATE&TIME
To change the systems current date and time highlight the Set Date & Time and press the
select button (Figure 14). Select the date or time unit that needs to be changed by pressing
on the relevant value, all units will display a keypad where the required number should be
entered except for the month which will change incrementally on each selection.
Figure 14
CONTINUOUSLOGGING
For any logging of data to take place a USB flash drive (memory stick) must be inserted into
the TS350 display unit i.e. the USB symbol is displayed in the top left corner. The following
pre-set data is then logged to the USB with the TS350 display units date and time stamp:
 Over Intermediate Limit
 Under Intermediate Limit
 Over Upper Limit
 Under Upper Limit
 Peak Speed
 Powerup
 WindSpeed Password Entered
 System Password Entered
 UpperLimit Changed
 Intermediate Limit Changed
 Units of Measure Changed
There are two methods of logging used on the TS350 display unit:
 Continuous Logging – Option 1
 Error Logging – Option 2

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 12
Figure 15 Figure 16
Option 1: Continuous Logging - Logg Cycle Time (log interval) – Interval time to be set
 Highlight Continuous Logging
 Press Select
 Select Yes (Figure 15)
 Enter the required time interval (1-60 minutes) followed by the Enter key (Figure 16)
Option 2: Log pre-set data only - Continuous Logging – Disabled
 Highlight Continuous Logging
 Press Select
 Select No (Figure 15)
RELOADFIRMWARE
These are advanced options and should only be done by or under the supervision of an
authorized factory. These options have random code generation protection therefore require
a onetime password from the factory. Please contact your authorized distributor who will get
a factory representative to help with these features.
 Reload Firmware (Figure 17)
 Press Select
 Confirm Selection & enter Random Generated Password from factory (Figure 18)
Figure 17 Figure 18

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 13
TESTMENU
To enter the Test Menu for the TS350 display unit
 Press the Test Menu button (Figure 19)
 Test Menu will be displayed (Figure 20).
Figure 19 Figure 20
From this menu you can view and test the following parameters of TS350 wind speed meter.
 System Information
 TS350 Tests
 View Variables
 Test Inputs
 Test Outputs
SYSTEMINFORMATION
This screen (Figure 21) displays the following information:
 Display Serial no. – The last four digits are the serial number of the display unit
 Display Board FW. – This is the Firmware version of the board
 R400 Board FW. – If the R400 Board is connected via CAN Bus it will be displayed
with the relevant serial number, if not connected ‘Not connected’ will be displayed.
Figure 21

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 14
TS350TESTS
Select View Variables (Figure 22) to view the wind speed in all the different units of
measure:
Figure 22
Select Test Inputs to view the digital inputs on the TS350 display board (Figure 23). The
box next to the relevant input will as follows:
 Input present – green block e.g. Input 1
 No Input – clear block e.g. Input 2, 3 & 4
Figure 23
Select Test Outputs to test the two relay outputs on the TS350 display board (Figure 24).
Press the button next to the relevant relay to switch the relay on and off.
Figure 24

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 15
TOUCHSCREENCALIBRATION
If the screen is not responding correctly to touch, the touch screen may need to be calibrated.
Switch the TS350 display power off, power up the TS350 while pressing in the middle of the
screen.
Figure 25
While the splash screen is on keep pressing in the centre of the screen for a full five seconds
until the touch calibration is activated and loaded (Figure 25). Lift your finger and follow the
on-screen instructions (Figure 26).
Figure 26 Figure 27
If the calibration screen has been entered by accident and touch calibration is not necessary,
press the Exit button without pushing anywhere else on the screen to continue with normal
start up procedures.
If the touch screen calibration is required, follow the below procedure:
Press and hold finger where the two lines meet inside the small box at the top left-hand corner
(Figure 27). Calibration works fine when using a finger but for better results use a pen taking
care not to press too hard or the screen will be damaged.
Hold finger/pen in this area until prompted to lift (Figure 26). Prompts will then be given for
three more touch zones resulting in co-ordinates for all four corners of the screen.
Once calibration is complete the software automatically goes to the working screen.

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 16
DATALOGGERSOFTWARESETUPFORPC
All the data stored on the USB flash drive can be downloaded and stored on to a Windows
based PC. The software application setup can be found on the USB flash drive in the TS350
display unit.
Full software support is available for the following operating systems:
 Windows 10
Insert USB flash drive into the PC & double click on the setup executable file
WindspeedLoggerXXXX_fullsetup.exe. XXXX represents the software version number.
Once the application has started correctly a Welcome screen will appear (Figure 28), click
Next to continue to the Installation Folder screen (Figure 29). The application will
automatically create a folder Elec-Mech\\Windspeed Logger or select Change to select a
different folder. 8.0MB of space is required for installation and the available space is shown,
make sure there is enough space before continuing.
Figure 28 Figure 29
Click Next to continue to the Shortcut Folder screen (Figure 30). The shortcut will be placed
on the desktop and can be made available for the current user or all users; this is selectable
on this screen using one of the two options provided.
Figure 30 Figure 31
Before the installation begins all the selected information is displayed again on the Ready to
Install screen (Figure 31). Confirm all the selections made are correct and click Next to
continue.

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 17
Figure 32 Figure 33
The application will now install and a progress bar will be displayed (Figure 32), once
complete the Installation screen will be displayed (Figure 33). Click Finish to complete
installation and exit the Windspeed Logger Setup installation.
Once the ccWindSpeedLog program is installed open the program on the PC using the
shortcut on the desktop, remove the USB flash drive from the TS350 display unit and insert
the USB flash drive into the PC.
Any software problems contact your authorized distributor or email the factory at:
 [email protected]
BASICSOFTHEPCLOGGINGSOFTWARE‐ccWINDSPEEDLOG
All the data stored on the USB flash drive can be downloaded and stored directly from the
USB flash drive onto the PC using the ccWindSpeedLog software.
The following functions can be done or viewed with the ccWindSpeedLog application:
 Backup DataFile on Read - Download & backup windspeed data from USB flash drive
 Delete DataFile on Read - Download & delete windspeed data from USB flash drive
 Unit Register- Create a crane register with TS350 display serial number and a crane
identification or serial number therefore allowing multiple cranes data to be stored in
one place
 Delete event data from data base (date selection)
 Number of logged data entries – Viewed on the screen
 Printing of reports by data entry date – user selectable with a start date and an end
date.

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 18
Open the ccWindSpeedLog shortcut on the PC desktop (Figure 34).
Figure 34


SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 19
UNITREGISTER‐ccWINDSPEEDLOG
Each TS350 display unit is appointed a serial number at the factory i.e. the serial number
cannot be changed. This is used to identify all the displays in the logging software and
therefore can be given a customised description linking the display to the crane. Once a list
of TS350 display units and machines has been compiled add them to the logging software
as follows:
 Click on the Unit Register tab
 Click on the button, the Serial Number entry window will be displayed (Figure
35)
`
Figure 35
 Enter the TS350 display serial number and click Add.
 Click on the Unit Description box (Figure 36)
Figure 36
 Type a customised description of the machine the TS350 is installed into in the Unit
Description box i.e. this description can be the machine description, serial number,
fleet number or a combination.
 Click on the button once the description is complete to save. The description can
be edited at any time by clicking on the description editing the text and repeating the
save.
 Repeat the above steps to add all the TS350 display units with their relevant
descriptions.
 To delete a unit, click on the button and the Confirm Delete window will be displayed
(Figure 37). Click Ok to confirm deletion or Cancel to keep the record.
Figure 37

SAFE-AID TS350 WIRED WIND SPEED METER MANUAL - VERSION 1 Page 20
 Once completed the PC should have a list of all the TS350 serial numbers and
descriptions (Figure 38).
Figure 38
DOWNLOADINGLOGGEDFILES‐ccWINDSPEEDLOG
The logged data from the TS350 display unit is transferred from the USB flash drive to the
PC manually to allow the data to be managed. The following process will run through the
download of the files from the USB flash drive:
Figure 39
 Once the USB flash drive has been inserted the Log File List tab will be displayed
between the Database Viewer and the Unit Register tabs (Figure 39)
 Click on the Log File List tab to show the file path on the left as well as the log files
(.WSS) on the USB flash drive on the right of the screen (Figure 40).
Figure 40
