Safewatch QuickConnect Plus Operating instructions

Safewatch



QuickConnect Plus
Security System
Programming Guide
BYPASS
RECORD
TEST
FUNCTION
STATUS
VOLUME PLAY
CODE CHIME
ESCAPE
ADD
DELETE
SELECT
1 2
4 5
79
8
0
ARMED
READY
OFF
AWAY
STAY
3
6
AUX
800-03859-4V2 11/10 Rev. A

-2-
TABLE OF CONTENTS
Data Fields ................................................................................................................................................................3
✻56 Enhanced Zone Programming ........................................................................................................................11
✻56 Enhanced Zone Programming Worksheet......................................................................................................14
✻80 Device Programming.......................................................................................................................................16
✻81 Zone Lists ........................................................................................................................................................17
Powerline Carrier Device Worksheet for ✻80 and ✻81 ...........................................................................................18
✻83 Enhanced Sequential Mode ...........................................................................................................................19
✻84 Assign Zone Voice Descriptors .......................................................................................................................20
Vocabulary Index (for ✻84 Assign Zone Voice Descriptors)...................................................................................20
✻85 Record Custom Voice Descriptors ..................................................................................................................21
5800 Series Transmitter Loop Numbers Diagram ..................................................................................................22
Safewatch QuickConnect Plus Control Defaults.....................................................................................................23
Safewatch QuickConnect Plus Summary of Connections Diagram.......................................................................24
Refer to the Safewatch QuickConnect Plus Installation and Setup Guide P/N 800-03857-4 or later for
detailed information on programming the system. The Installation and Setup Guide contains full
descriptions for all data fields.
UL
Safewatch QuickConnect Plus is not intended for UL985 Household Fire applications unless a 24-
hour backup battery (P/N LYNXRCHKIT-HC or LYNXRCHKIT-SHA) is installed.
To Enter Programming Mode:
You may find it convenient to adjust the volume setting before entering the Programming Mode. This will allow
you to clearly hear feedback announcements or system beeps.
1. Power up, then depress [ ✻ ] and [#] both at once, within 50 seconds of powering up.
OR
Enter: Installer Code (6 + 3 + 2 + 1) plus 8 + 0 + 0. System will display “Entering Program Mode”.
Notes: 1. If a different Installer Code has been programmed, enter: the New Installer Code + 8 + 0 + 0.
2. If ✻ 98 was previously used to exit programming, the first method shown above must be used to re-
enter the program mode)
2. Upon entry into Program mode, data field “20 INSTALLER CODE” will be displayed (the first data field in
the system) and both keypad LEDs will flash.
To Program the Data Fields:
1. Press [ ✻ ] followed by the desired field number (e.g., ✻ 21), then make the required entry.
2. The keypad beeps three times after entering data, then displays the next data field in sequence.
3. For phone number and account number fields, press [ ✻ ] to end the entry if less than number maximum
number of digits is entered.
4. To view data entered in field, press [#] plus the field that you wish to view (e.g., #21). The system will beep
three times and data programmed for that field will be displayed to the right of the field number. The system
will scroll through the data for longer numbers and a beep will sound after each number is displayed or
three times after the final digit is displayed.
5. To delete an entry, simply press [ ✻ ] plus that field number and reenter the correct data. For phone number
and account number fields ✻ 40- ✻ 44, ✻ 88 and ✻ 94, press [ ✻ ] + field number + [ ✻ ].
Interactive Menu Modes:
There are six interactive menu modes as listed below. To enter these modes, first enter Program mode. While in
Program mode, press [ ✻ ] plus the mode number desired (e.g., ✻ 56).
✻ 56 Enhanced Zone Programming .............. For programming zone characteristics, report codes, etc.
✻ 80 Device Programming ............................. For programming Powerline Carrier Devices
✻ 81 Zone List Programming ......................... For programming zone lists for use with Powerline Carrier Devices
✻ 83 Enhanced Sequential Mode .................. For entering transmitter serial numbers
✻ 84 Assign Zone Voice Descriptors.............. For assigning voice descriptors to zones
✻ 85 Record Custom Voice Descriptors ........ For recording custom voice descriptors

- 3 -
To Initialize Download ID and Subscriber Account Number for Downloading:
✻ 96 Resets all subscriber account numbers and CSID in preparation for an initial download.
To Load a Default Set:
✻ 97 Enter a number 1-4 corresponding to the selected default table (See the Installation Instructions for the
default tables). Enter 0 if you are not selecting a default table.
To Exit Programming Mode:
✻ 98 Exits programming mode and prevents re-entry by: Installer Code + 8+ 0 + 0. If ✻98 is used to exit
programming mode, system must be powered down, then press [✻] and [#] within 50 seconds of power
up to re-enter programming mode.
✻99 Exits programming mode and allows re-entry by: Installer Code + 8 + 0 + 0 or: Power-up, then press [✻]
and [#] within 50 seconds of power up.
DATA FIELDS
Data Field Display Function& Programming Options [ ] = Programmed Table 1 Default Values
SYSTEM SETUP (✻20– ✻30) † Entering a number other than the one specified may give unpredictable results.
20
2020
20
INSTALLER
INSTALLER INSTALLER
INSTALLER CODE
CODECODE
CODE
Installer Code
[6321]
Enter 4 digits, 0–9
21
2121
21
QUICK
QUICK QUICK
QUICK ARM
ARM ARM
ARM ENABLE
ENABLEENABLE
ENABLE
Quick Arm Enable
† [1]
0 = no; 1 = yes
22
2222
22
KEYPAD
KEYPAD KEYPAD
KEYPAD BACKLIGHT
BACKLIGHTBACKLIGHT
BACKLIGHT
Keypad Backlight Timeout
[0]
0 = none (backlighting always on); 1 = backlight off after 10secs
23
2323
23
FORCED
FORCED FORCED
FORCED BYPASS
BYPASSBYPASS
BYPASS
Forced Bypass UL installations = 0
† [1]
0 = none; 1 = bypass open zones
24
2424
24
RF
RF RF
RF HOUSE
HOUSEHOUSE
HOUSE ID
ID ID
ID CODE
CODECODE
CODE
RF House ID Code
| [00]
00 = disable all wireless keypad usage; 01–31 = 5804BD/5804BDV house ID
25
2525
25
X10
X10 X10
X10 HOUSE
HOUSE HOUSE
HOUSE CODE
CODECODE
CODE
Powerline Carrier Device (X10) House ID
[0]
0 = A; 1 = B, 2 = C, 3 = D, 4 = E, 5 = F, 6 = G, 7 = H, 8 = I, 9 = J, #10 = K, #11 = L,
#12 = M, #13 = N, #14 = O, #15 = P
26
2626
26
CHIME
CHIME CHIME
CHIME BY
BY BY
BY ZONE
ZONEZONE
ZONE
Chime By Zone
† [0]
0 = no; 1 = yes (program zones to chime on zone list 3)
2
22
2
CLO
CLOCLO
CLOCK
CK CK
CK DISPLAY
DISPLAYDISPLAY
DISPLAY
Real Time Clock Display
† [1]
0 = no; 1 = yes, display time on keypad
29
2929
29
DST
DST DST
DST MNTH
MNTH MNTH
MNTH STR/END
STR/ENDSTR/END
STR/END
Daylight Saving Time Start/End Month
[3, 11]
Start End
1-9, #+10,#+11,#+12. Enter 0,0 if no daylight savings time used.
30
3030
30
DST WEEK STR/END
DST WEEK STR/ENDDST WEEK STR/END
DST WEEK STR/END
Daylight Saving Time Start/End Weekend
[2,1]
Start End
0=disable; 1=first; 2=second; 3=third; 4=fourth; 5=last; 6=next to last; 7=third from last

- 4 -
Data Field Display Function& Programming Options [ ] = Programmed Table 1 Default Values
ZONE SOUNDS AND TIMING (✻31– ✻39)
31
3131
31
SINGLE
SINGLE SINGLE
SINGLE ALARM
ALARM ALARM
ALARM SND
SNDSND
SND
Single Alarm Sounding/Zone UL installations = 0
† [0]
0 = Alarm Sounding Per Zone will be the same as the Swinger Shutdown” set in field *92;
1 = yes, limit once per arming period (also applies to long range radio output if “0” is
selected in ✻91 field)
32
3232
32
FIRE
FIRE FIRE
FIRE SND
SNDSND
SND TIMEOUT
TIMEOUT TIMEOUT
TIMEOUT
Sounder Timeout
† [0]
0=timeout; 1=no timeout
33
3333
33
ALRM
ALRM ALRM
ALRM SND
SND SND
SND TIMEOUT
TIMEOUTTIMEOUT
TIMEOUT
Alarm Bell Timeout UL installations = 1 (4 min) minimum
† [1]
0 = none; 1=4 min; 2=8 min; 3=12 min; 4 = 16 min
34
3434
34
EXIT
EXIT EXIT
EXIT DELAY
DELAYDELAY
DELAY TIME
TIME TIME
TIME
Exit Delay UL installations = 60 seconds max.
| †[60]
45-96 = exit delay time (in seconds)
97 = 120 seconds
Note: The control validates the data entered in this field. If the selection is not valid the control will
emit a single long beep indicating that the selection has been rejected. The control replaces
the selection with the default value “60”, which is displayed on the keypad, and advances to
the next field.
SIA: Must be set to a minimum of 45 seconds.
35
3535
35
ENTRY
ENTRY ENTRY
ENTRY DELAY
DELAYDELAY
DELAY 1
1 1
1
Entry Delay 1 (zone type 01) UL installations = 45 seconds max.
| † [30]
30-96 = entry delay 1 time (in seconds)
97 = 120 seconds
98 = 180 seconds
99 = 240 second
Note: The control validates the data entered in this field. If the selection is not valid the control will
emit a single long beep indicating that the selection has been rejected. The control replaces
the selection with the default value “30”, which is displayed on the keypad, and advances to
the next field.
SIA: The entry delay must be set to a minimum of 30 seconds. The sum of entry delay 1 entered in
Field *35 and the burglary abort window entered in *50 should not exceed 1 minute.
36
3636
36
ENTRY
ENTRY ENTRY
ENTRY DELAY
DELAY DELAY
DELAY 2
22
2
Entry Delay 2 (zone type 02) UL installations = 45 seconds max.
| † [30]
30-96 = entry delay 2 time (in seconds)
97 = 120 seconds
98 = 180 seconds
99 = 240 second
Note: The control validates the data entered in this field. If the selection is not valid the control will
emit a single long beep indicating that the selection has been rejected. The control replaces
the selection with the default value “30”, which is displayed on the keypad, and advances to
the next field.
SIA: The entry delay must be set to a minimum of 30 seconds. The sum of entry delay 2 entered in
Field *36 and the burglary abort window entered in *50 should not exceed 1 minute.
38
3838
38
CON
CONCON
CONF
FF
F ARM
ARMARM
ARM ING
INGING
ING DING
DINGDING
DING
Confirmation of Arming Ding
Note: Confirmation ding only sounds when Safewatch QuickConnect Plus is Armed Away or disarmed
after being Armed Away. If Safewatch QuickConnect Plus is armed by RF button (key fob), a
confirmation ding occurs immediately after arming regardless of field ✻ 38 settings. If Safewatch
QuickConnect Plus is disarmed by RF button (key fob), additional disarming confirmation ding occurs
immediately after disarming and is longer than arming confirmation ding.
† [0]
0 = no arming confirmation ding after arming system by Safewatch QuickConnect Plus keypad or RF
keypad ; 1 = arming confirmation ding after arming system by Safewatch QuickConnect Plus keypad
or RF keypad; 2 = arming confirmation ding after arming from RF keypad only
† Entering a number other than the one specified may give unpredictable results.

- 5 -
Data Field Display Function& Programming Options [ ] = Programmed Table 1 Default Values
39
3939
39
CROSS ZONE TIMER
CROSS ZONE TIMERCROSS ZONE TIMER
CROSS ZONE TIMER
Cross Zone Timer
† [0]
Value Time Window Value Time Window
0 = No Cross Zoning 8 = 2 minutes
1 = 15 seconds 9 = 2 minute, 15 seconds
2 = 30 seconds # + 10 = 2 minute, 30 seconds
3 = 45 seconds # + 11 = 2 minute, 45 seconds
4 = 60 seconds # + 12 = 3 minutes
5 = 1 minute, 15 seconds # + 13 = 3 minute, 15 seconds
6 = 1 minute, 30 seconds # + 14 = 3 minute, 30 seconds
7 = 1 minute, 45 seconds # + 15 = 3 minute, 45 seconds
Note: If option ✻39 is set to “0” Zone List 2 can be used for other purposes.
UL This option is not for use in UL installations.
DIALER PROGRAMMING (✻40– ✻53) In fields ✻40, ✻41, ✻42, enter up to the number of digits shown.
Enter 0–9; #+11 for ' ✻ '; #+12 for '#'; #+13 for a pause.
40
4040
40
PABX ACCESS CODE
PABX ACCESS CODEPABX ACCESS CODE
PABX ACCESS CODE
PABX/Call Waiting Disable
Enter up to 6 digits if PABX is needed to access an outside line. To clear entries from
field, press ✻40✻ OR
Enter“# + 11+ 7+ 0” to program touch-tone sequence “✻70” and cancel call waiting.
41
4141
41
PRIMARY
PRIMARY PRIMARY
PRIMARY TEL
TEL TEL
TEL NUM
NUMNUM
NUM
Primary Phone Number
Enter up to 20 digits; Do not fill unused spaces. If fewer than 20 digits entered, pressing
✻advances to the next field. To clear entries from field, press ✻41✻.
42
4242
42
SECOND
SECOND SECOND
SECOND TEL
TELTEL
TEL NUM
NUM NUM
NUM
Secondary Phone Number
Enter up to 24 digits; Do not fill unused spaces. If fewer than 24 digits entered, pressing
✻advances to the next field. To clear entries from field, press ✻42✻.
!
All four digits of the subscriber account number must be entered in Fields ✻
✻✻
✻ 43 and ✻
✻✻
✻ 44. If ten digit format is selected
in ✻
✻✻
✻ 48 (option 5), all ten digits of the Subscriber Account number must be entered.
In fields ✻43, ✻44, enter 4 to 10 digits. Enter 0–9; #+11 for B; #+12 for C; #+13 for D; #+14 for E; [#+15 for F].
Enter ✻ as 4th digit, if 3+1 dialer reporting is to be used. If only 3 digits used, pressing ✻advances to the next
field. Enter [✻] as the fifth digit if a 4-digit account number (for 4+1, 4+2, CID®) is used. To clear entries from
field, press ✻43✻ or ✻44✻.
Examples:
For Acct. 1234, enter: 1 | 2 | 3 | 4 ; For Acct. B234, enter: #+11| 2 | 3 | 4
For Acct. 1234567890, enter: 1| 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 0 ; For Acct. 123, enter: 1 | 2 | 3 | ✻
43
4343
43
PRIMARY
PRIMARY PRIMARY
PRIMARY ACCOUNT
ACCOUNTACCOUNT
ACCOUNT #
Primary Subscriber Account Number
See note above.
44
4444
44
SECNDRY
SECNDRYSECNDRY
SECNDRY A
AA
ACCOUNT
CCOUNTCCOUNT
CCOUNT #
Secondary Subscriber Account Number
See note above.
† Entering a number other than the one specified may give unpredictable results.

- 6 -
Data Field Display Function& Programming Options [ ] = Programmed Table 1 Default Values
46
4646
46
FOLLOW ME PHONE
FOLLOW ME PHONEFOLLOW ME PHONE
FOLLOW ME PHONE #
“Follow Me” Reminder Phone Number
Enter up to 24 digits; Do not fill unused spaces. If fewer than 24 digits entered, pressing ✻
advances to the next field. To clear entries from field, press ✻46✻.
Enter 0-9, #+11 for ‘✻’; #+12 for ‘#’; #+13 for a pause (two seconds).
4
44
4
PHONE SYS SELECT
PHONE SYS SELECTPHONE SYS SELECT
PHONE SYS SELECT
Phone System Select
† [5]
Central
Dialing
Mode
Station Pulse Tone Pulse Tone
No WATS 0 = No Speaker
Phone
1 = No
Speaker Phone
4 = With
Speaker
Phone
5 = With
Speaker Phone
WATS 2 = No Speaker
Phone
3 = No
Speaker Phone
6 = With
Speaker Phone
7 = With
Speaker Phone
48
4848
48
REP FRMT PRI/
REP FRMT PRI/REP FRMT PRI/
REP FRMT PRI/SEC
SECSEC
SEC
Report Format for Primary/Secondary
[7, 7]
Primary Secondary
0 = 3+1, 4+1 ADEMCO L/S STANDARD
1 = 3+1, 4+1 RADIONICS STANDARD
2 = 4+2 ADEMCO L/S STANDARD
3 = 4+2 RADIONICS STANDARD
5 = ADEMCO CONTACT ID® REPORTING
WITH 10-DIGIT SUBS ACCT NO.
6 or undefined = 4+2 ADEMCO EXPRESS
7 = ADEMCO CONTACT ID® REPORTING
WITH 4-DIGIT SUBS ACCT NO.
8 = 3+1, 4+1 ADEMCO L/S EXPANDED
9 = 3+1, 4+1 RADIONICS EXPANDED
49
4949
49
SPLIT/DUAL
SPLIT/DUAL SPLIT/DUAL
SPLIT/DUAL REP
REPREP
REP
Split/Dual Reporting
[0]
To Primary Phone No.
0 = All reports
1 = Alarms, Restore, Cancel
2 = All except Open/Close, Test
3 = Alarms, Restore, Cancel
4 = All except Open/Close, Test
5 = All
To Primary Phone No.
6 = All reports except Open/Close
7 = All reports
8 = All reports
9 = All reports except Open/Close
To Primary Phone No.
10 = All except Open/Close
11 = All reports
12 = All reports
13 = All except Open/Close
To Secondary Phone No.
None, unless primary fails, then all
Others
Open/Close, Test
All
All
All
To Paging Number
Alarms, Open/Close‡, Troubles
Alarms, Troubles
Alarms, Open/Close‡, Troubles
Alarms, Troubles
To Follow Me System Phone Number)
Alarms, Open/Close‡, Troubles
Alarms, Troubles
Alarms, Open/Close‡, Troubles
Open/Close‡
‡ Will report users 0, 5-8 or wireless arm/disarm button zones 26-33; all other zones and users do not
report.
50
5050
50
ABORT WINDOW
ABORT WINDOWABORT WINDOW
ABORT WINDOW
Burglary Abort Window
† [2]
1 = 15-second abort window
2 = 30-second abort window
3 = 45-second abort window
SIA The sum of the burglary abort window entered in ✻50 and the entry delays entered in either Field
✻35 or ✻36 should not exceed 1 minute.
Note: The control validates the data entered in this field. If the selection is not valid the control emits a
single long beep indicating that the selection has been rejected. The control replaces the selection
with the default value “2”, which is displayed on the keypad, and advances to the next field.
Note: If you are using Pulse (rotary) Dialing, you must enter the
numbers slowly to allow the pulse dialer time to operate.
Note: Option 5 or 7 (ADEMCO Contact ID®)
must be selected for AAV.

- 7 -
Data Field Display Function& Programming Options [ ] = Programmed Table 1 Default Values
51
5151
51
PERIOD
PERIOD PERIOD
PERIOD T
TT
TEST
ESTEST
EST REP
REP REP
REP
Periodic Test Report (enter Test Code in field ✻64)
† [0]
0 = none; 1 = 24 hours; 2 = weekly; 3 = 30 days
52
5252
52
TEST
TEST TEST
TEST REP
REP REP
REP OFFSET
OFFSETOFFSET
OFFSET
First Test Report Offset
† [2]
0 = 24 hour; 1 = 6 hours; 2 = 12 hours; 3 = 18 hours
53
5353
53
SESCOA/RADIONICS
SESCOA/RADIONICSSESCOA/RADIONICS
SESCOA/RADIONICS
SESCOA/Radionics Select
[0]
0 = Radionics (0–9, B–F reporting);
1 = SESCOA (0–9 only reporting). Select 0 for all other formats.
54
5454
54
LACK
LACK LACK
LACK OF
OF OF
OF USAGE
USAGEUSAGE
USAGE
Lack of Usage Notification
[0]
0 = Disabled
1 = 1 day
2 = 7 days
3 = 27 days
4 = 90 days
5 = 180 days
6 = 365 days
55
5555
55
REPORT
REPORT REPORT
REPORT CHANNELS
CHANNELSCHANNELS
CHANNELS
Reporting Channels
[0]
0 = Telco Line (no Radio)
1 = LRR/IP(Digital Communication only) and Telco Line
3 = LRR/IP (Digital Communication only) (no Telco Line)
5 = LRR/IP (Digital Communication with AAV) (Telco Line connections for 2-way voice
session only, if applicable)
5
55
5
FALSE AL
FALSE ALFALSE AL
FALSE ALA
AA
ARM OPTS
RM OPTSRM OPTS
RM OPTS
False Alarm Options
[7]
Value Cancel Alarm Display Auto Stay Arming Exit Time Restart/Reset
0 = Disabled Disabled Disabled
1 = Disabled Disabled Enabled
2 = Disabled Enabled Disabled
3 = Disabled Enabled Enabled
4 = Enabled Disabled Disabled
5 = Enabled Disabled Enabled
6 = Enabled Enabled Disabled
7 = Enabled Enabled Enabled
Note: The control validates the data entered in this field. If the selection is not valid it will emit a single
long beep indicating that the selection has been rejected. The control replaces the selection
with the default value “7”, which is displayed on the keypad, and advances to the next field.
58
5858
58
RF
RF RF
RF JAM
JAM JAM
JAM DETECTION
DETECTIONDETECTION
DETECTION
RF Jam Detection Note: For event logging option 2 must be selected.
[0]
0 = no RF Jam Detection; 1 = RF Jam Detect on, no CS report;
2 = RF Jam Detect on with CS report (if trouble/restore report is enabled in fields ✻ 60, ✻ 71)
† Entering a number other than the one specified may give unpredictable results.
TO PROGRAM SYSTEM STATUS, & RESTORE REPORT CODES (✻59–✻76, & ✻89):
With a 3+1 or 4+1 Standard Format: Enter a code in the first box: 1–9, 0, B, C, D, E, or F. Enter "#+10" for 0, "#+11" for B, "#+12" for C,
"#+13" for D, "#+14" for E, "#+15" for F.
A "0" (not "#+10") in the first box will disable a report.
A "0" (not "#+10") in the second box will result in automatic advance to the next field when programming.
With an Expanded or 4+2 Format: Enter codes in both boxes (1st and 2nd digits) for 1–9, 0, or B–F, as described above.
A "0" (not "#+10") in the second box will eliminate the expanded message for that report.
A "0" (not "#+10") in both boxes will disable the report.
With ADEMCO Contact ID Reporting: Enter any digit (other than "0") in the first box, to enable zone to report (entries in the second boxes
will be ignored). A "0" (not "#+10") in the first box will disable the report.
Examples: For Code 3(single digit), enter: 3 | 0
For Code 3 2 (two digits), enter: 3 | 2
For Code B 2 (Hexadecimal), enter: #+11 | 2

- 8 -
Data Field Display Function& Programming Options [ ] = Programmed Table 1 Default Values
SYSTEM STATUS REPORT CODES (✻59–✻68)
59
5959
59
EXIT
EXITEXIT
EXIT ERROR
ERROR ERROR
ERROR REP
REPREP
REP
Exit Error Report Code
[1]
60
6060
60
TROUBLE
TROUBLE TROUBLE
TROUBLE REP
REP REP
REP CODE
CODECODE
CODE
Trouble Report Code
| [1,0]
61
6161
61
BYPASS
BYPASS BYPASS
BYPASS REP
REP REP
REP CODE
CODECODE
CODE
Bypass Report Code
| [0,0]
62
6262
62
AC
ACAC
AC LOSS
LOSS LOSS
LOSS REP
REP REP
REP CODE
CODE CODE
CODE
AC Loss Report Code
| [0,0]
6
66
63
33
3
LOW
LOW LOW
LOW BAT
BAT BAT
BAT REP
REP REP
REP CODE
CODECODE
CODE
Low Bat Report Code
| [1,0]
6
66
64
44
4
TEST
TESTTEST
TEST REP
REPREP
REPORT
ORTORT
ORT CODE
CODE CODE
CODE
Test Report Code
| [1,0]
65
6565
65
OPEN
OPEN OPEN
OPEN REPORT
REPORT REPORT
REPORT CODE
CODECODE
CODE
Open Report Code
†† [0]
66
6666
66
AWAY/STAY
AWAY/STAY AWAY/STAY
AWAY/STAY REP
REPREP
REPORT
ORTORT
ORT
Arm Away/Stay Report Code
†† [0,0]
AWAY STAY
6
66
6
RF
RF RF
RF TRANS
TRANSTRANS
TRANS LB
LB LB
LB REP
REPREP
REP
RF Transmitter Low Battery Report Code
| [1,0]
68
6868
68
CANCEL
CANCEL CANCEL
CANCEL REP
REP REP
REP CODE
CODECODE
CODE
Cancel Report Code
| [1,0]
69
6969
69
RECENT CLOSE REP
RECENT CLOSE REPRECENT CLOSE REP
RECENT CLOSE REP
Recent Close Report Code
| [1]
Note: The control validates the data entered in this field. If the selection is not valid the control will
emit a single long beep indicating that the selection has been rejected. The control replaces
the selection with the default value “1”, which is displayed on the keypad, and advances to the
next field.
RESTORE REPORT CODES (✻70–✻76)
0
00
0
ALARM
ALARM ALARM
ALARM RES
RESRES
RES REPORT
REPORT REPORT
REPORT
Alarm Restore Report Code
[1]
1
11
1
TROUBLE RES REP
TROUBLE RES REPTROUBLE RES REP
TROUBLE RES REP
Trouble Restore Report Code
| [1,0]
2
22
2
BYPASS RES REP
BYPASS RES REPBYPASS RES REP
BYPASS RES REP
Bypass Restore Report Code
| [0,0]
3
33
3
AC R
AC RAC R
AC RESTORE REP
ESTORE REPESTORE REP
ESTORE REP
AC Restore Report Code
| [0,0]
(†† 2nd digit is automatically sent as the user
number if expanded or 4+2 reporting is selected.)
2nd digit is automatically sent as 2nd digit of the zone alarm report
code programmed in
✻
56, if expanded or 4+2 reporting is selected.
2nd digit is automatically sent as 2nd digit of the
zone alarm report code programmed in ✻ 56, if
expanded or 4+2 reporting is selected.

- 9 -
Data Field Display Function& Programming Options [ ] = Programmed Table 1 Default Values
4
44
4
LO
LO LO
LO BAT
BATBAT
BAT RES
RES RES
RES REP
REP REP
REP
Low Bat Restore Report Code
| [1,0]
5
55
5
RF
RFRF
RF LOBAT
LOBAT LOBAT
LOBAT R
RR
RES
ESES
ES REP
REP REP
REP
RF Transmitter Low Battery Restore Report Code
| [1,0]
6
66
6
TEST
TEST TEST
TEST RES
RES RES
RES REPORT
REPORTREPORT
REPORT
Test Restore Report Code
| [1,0]
DYNAMIC SIGNALING FIELD (✻77)
DYNAMIC SIG OPTS
DYNAMIC SIG OPTSDYNAMIC SIG OPTS
DYNAMIC SIG OPTS
Dynamic Signaling Options
| [0, 0]
1st Entry (delay before switch CS reporting path)
0 = Redundant
reporting on dialer
and LRR/IP device
1 = 15 seconds
2 = 30 seconds
3 = 45 seconds
4 = 60 seconds
5 = 75 seconds
6 = 90 seconds
7 = 105 seconds
8 = 120 seconds
9 = 135 seconds
#10 = 150 seconds
#11 = 165 seconds
#12 = 180 seconds
#13 = 195 seconds
#14 = 210 seconds
#15 = 225 seconds
2nd Entry
0 = Primary Dialer
Preferred Channel
1 = LRR/IP
Preferred Channel
2 = LRR/IP
reporting only
8
88
8
PROG TONE GEN TM
PROG TONE GEN TMPROG TONE GEN TM
PROG TONE GEN TM
Programmable Tone Generation Time
| [0, 0]
00 = Disabled
01-09 = 100-900 ms
10-99 = 1.0 – 9.9 secs
OUTPUT AND SYSTEM SETUP (✻80, ✻81, ✻83–✻85) See Procedures later in this manual.
86
8686
86
MULTI
MULTIMULTI
MULTI-
--
-MODE
MODE MODE
MODE EMAIL
EMAILEMAIL
EMAIL
Multi-Mode (E-Mail Notification) (RIS is always enabled)
[0]
0 = Disable multi-mode devices (RIS enabled)
1 = Enable multi-mode device address #6 only (RIS enabled)
2 = Enable multi-mode device address #7 only (RIS enabled)
3 = Enable multi-mode addresses (RIS enabled)
8
88
8
AUX
AUX AUX
AUX FUNC
FUNCFUNC
FUNC 1BTN
1BTN 1BTN
1BTN PG
PG PG
PG
Aux Function/ 1-Button Paging
[0]
0 = Aux key performs defined function (macro);
1 = Aux key sends message to pager or voice message to follow me system phone no.
If 1, you must also select an option 6-9 in field ✻49 for the pager or 10-13 for the follow me
system announcement.
88
8888
88
PAGER CHARACTERS
PAGER CHARACTERSPAGER CHARACTERS
PAGER CHARACTERS
Pager Characters
Up to 16 digits can be entered that will appear in front of the 7-digit pager message sent by
the control. Refer to the Installation Instructions (fields ✻87, ✻88 and ✻49) for full
descriptions of the paging feature. You do not need to fill all 16 digits (press [✻] to
advance to next field).
To clear entries, enter ✻88✻. To enter “✻” = [#] + [11]; To enter “#” = [#] + 12]; To
enter 2-second pause = [#] + [13] (some pagers require an additional delay [pause] in
order to receive the entire message)
89
8989
89
EVNT
EVNT EVNT
EVNT LOG
LOG LOG
LOG 80%
80% 80%
80% REP
REPREP
REP
Event Log 80% Full Report Code
| [0,0]

- 10 -
Data Field Display Function& Programming Options [ ] = Programmed Table 1 Default Values
90
9090
90
EVNT LOG OPTIONS
EVNT LOG OPTIONSEVNT LOG OPTIONS
EVNT LOG OPTIONS
Event Logging Note: System messages are logged when
any non-zero selection is made.
[3]
0 = None; 1 = Alarm/Alarm Restore; 2 = Trouble/Trouble Restore; 4 = Bypass/Bypass
Restore; 8 = Open/Close.
Example: To select “Alarm/Alarm Restore”, and “Open/Close”, enter 9 (1 + 8); To select
all, enter #15.
91
9191
91
AAV/REM
AAV/REMAAV/REM
AAV/REM PHN
PHN PHN
PHN CTRL
CTRLCTRL
CTRL
Alarm Audio Verification (AAV)/Remote Phone Control
[2]
0 = None
1 = AAV and remote phone control
2 = remote phone control only
4 = AAV only
Notes: (1) In order to activate the Remote Phone Control feature and defeat an answering machine,
ensure that the correct ring detection count (“15”) has been programmed in field ✻95.
(2) Remote phone session will be terminated if a report must be sent.
(3) Alarm Audio Verification will only function when Contact ID® is selected. AAV cannot be
used for UL installations.
(4) If an alarm will be reported to primary and secondary phone numbers, AAV can only
function via the secondary number.
(5) If an alarm will be reported to a follow me phone number (10-12 in field ✻49) AAV cannot
be used.
(6) If AAV is selected and LRR/IP communications device is enabled, you must enter "0"
(primary dialer preferred channel) as the second entry in Field ✻77.
92
9292
92
SWINGER SHUTDOWN
SWINGER SHUTDOWNSWINGER SHUTDOWN
SWINGER SHUTDOWN
Swinger Shutdown
[1]
1 = shutdown after one alarm; 2 = shutdown after two alarms
Note: The control validates the data entered in this field. If the selection is not valid the control will
emit a single long beep indicating that the selection has been rejected. The control replaces
the selection with the default value “1”, which is displayed on the keypad, and advances to
the next field.
DOWNLOAD INFORMATION (✻93–✻95)
93
9393
93
FLEXBLE
FLEXBLE FLEXBLE
FLEXBLE CALLBACK
CALLBACKCALLBACK
CALLBACK
Flexible Callback
[0]
0 = No flexible callback; 1 = Last digit flexible;
2 = Last 2 digits flexible; 3 = Last 3 digits flexible
94
9494
94
DOWNLOAD
DOWNLOAD DOWNLOAD
DOWNLOAD PHONE
PHONEPHONE
PHONE #
Download Phone Number
Note: In UL installations, downloading may only be performed if a technician is at the site.
Enter up to 20 digits, 0–9; #+11 for '✻'; #+12 for '#'; #+13 for a pause. Do not fill unused
spaces. If fewer than 20 digits entered, pressing ✻advances to the next field. To clear
entries from field, press ✻94✻.
95
9595
95
RING
RING RING
RING DET
DET DET
DET COUNT
COUNTCOUNT
COUNT
Ring Detection Count for Downloading/Remote Phone Control Mode
[15]
0 = Disable Station Initiated Download
1–14 = number of rings
(1–9, [#]+10 =10, [#] +11 =11, [#] +12 =12, [#] +13 =13, [#] +14 =14);
15 = answering machine defeat ([#] +15 =15)

- 11 -
✻
✻✻
✻56 ENHANCED ZONE PROGRAMMING PROCEDURE
This interactive menu mode is used to program zone numbers, zone types, alarm and report codes, and to
identify the type of loop input device and can be used for entering 5800 Series transmitter serial numbers. Press
✻56 while in programming mode.
Note: Entering a number other than the one specified may give unpredictable results.
A01
A01A01
A01
ZONE
ZONE ZONE
ZONE NUMBER
NUMBERNUMBER
NUMBER
Zone Number
Enter the 2-digit zone number to be programmed. The system will announce the Voice
Descriptor for the selected zone, if it is programmed.
00 = exit zone programming mode
01 = Hardwire Zone
2-25 = RF transmitter zones (only)
26-41 = RF button zones (only)
92 = Duress
95, 96, 99 = Panic zones
[ ✻ ] = Continue
b
ZONE
ZONE ZONE
ZONE TYPE
TYPETYPE
TYPE
Zone Type
Enter the 2-digit zone type (zt) for this zone. if 00 is entered, the system will skip to DELETE
ZONE PARAMETERS prompt (F)
00 = Not Used
01 = Entry/Exit #1
02 = Entry/Exit #2
03 = Perimeter
04 = Interior Follower
05 = Trouble Day/Alarm Night
06 = 24 Hr Silent
07 = 24 Hr Audible
08 = 24 Hr Aux
09 = Fire without Verification
10 = Interior with Delay
14 = Carbon Monoxide
20 = Arm–Stay
21 = Arm–Away
22 = Disarm
23 = No Alarm Response
24 = Silent Burglary
[ ✻ ] = Continue
[#] = Return to previous prompt
C
CC
C
REPORT
REPORTREPORT
REPORT CODE
CODE CODE
CODE
Report Code
Enter the Report Code (rc) for this zone. Report consists of 2 hexadecimal digits, each
composed of 2 numerical digits. (A = 10, B = 11, C = 12, D = 13, E = 14, F = 15) (see
Report Code description for explanation of codes).
[ ✻ ] = Continue; If this is zone 95, 96 or 99, the system skips to the VOICE DESCRIPTOR
prompt (1C)
[#] = Return to previous prompt
d
INPUT
INPUTINPUT
INPUT TYPE
TYPE TYPE
TYPE
Input Type
Enter the input type (i) for the transmitter assigned to this zone.
Note: Zones 2-25 should be assigned as Input Type 3 or 4 and Zones 26-41 should be
assigned as Type 5 only.
3 = Supervised RF (RF)
4 = Unsupervised RF (UR)
5 = Button type (BR)
[ ✻ ] = Continue
[#] = Return to previous prompt
E
EE
E
LOOP
LOOPLOOP
LOOP#/AUTO
AUTO AUTO
AUTO LEARN
LEARNLEARN
LEARN
Enroll Loop Number or Loop & Serial Number via RF Learning
For BR type devices (device type 5), two (2) transmissions (two key depressions at least
five seconds apart) are required. For RF and UR device types (device type 3 and 4), four
(4) transmissions are required (fault, restore and fault, restore). The device should be at
least 5 feet away from the control when enrolling via RF learning.
Note: There is a 52-second time-out for RF enrolling. At the end of the time-out, the system
returns to the INPUT TYPE prompt (d). If enrolled, loop number and “LEARNED” will
be displayed.
Depress the key of the BR type device two times (two transmissions) or fault and restore
the RF or UR type device two times (four transmissions).
E
EE
E2L LEARNED
2L LEARNED2L LEARNED
2L LEARNED
LOOP
LOOPLOOP
LOOP#/AUTO LEARN
AUTO LEARNAUTO LEARN
AUTO LEARN
Two beeps will sound after the second transmission of the BR type device or the fourth
transmission of the RF or UR type device confirming that the loop number and serial
number have been learned. The loop number that has been learned will be displayed
(loop 2 shown) and the system will announce the Voice Descriptor for the zone.
Press [✻] to continue.

- 12 -
✻
✻✻
✻56 ENHANCED ZONE PROGRAMMING PROCEDURE
1
11
1AL
AL AL
AL A094
A094A094
A094-
--
-4129
41294129
4129
ENROLL MODE
ENROLL MODEENROLL MODE
ENROLL MODE
Enroll Loop Number or Loop & Serial Number via RF Learning (Continued)
The serial number of the device that has been learned will be displayed. “1AL” will be
displayed in front of the serial number.
Fault and restore the sensor again to confirm the serial number.
1
11
1ALC
ALC ALC
ALC A094
A094A094
A094-
--
-4129
41294129
4129
ENROLL MODE
ENROLL MODEENROLL MODE
ENROLL MODE
The system will announce the Voice Descriptor for the zone and “1ALC” will be displayed
in front of the serial number.
Press [✻] to continue. System will advance to Prompt “1C”
E
EE
E
LOOP
LOOPLOOP
LOOP#/AUTO LEARN
AUTO LEARNAUTO LEARN
AUTO LEARN
Enter Loop Number or Loop & Serial Number via Manual Entry
Enter the desired loop number and press [✻] to continue (see the transmitter’s Installation
Instructions for specific loop designations). If “LEARNED” is displayed, the zone’s serial
number has already been enrolled.
Note: The loop number can be changed even if the zone has already been entered. Care
should be taken when using this feature. It is possible to make zones inoperable by
creating a mismatch of a working serial number/loop number combination. This
should be re-confirmed if the loop number is changed.
1-4 = Loop number for the zone of the transmitter being entered or learned
0 = Delete Serial Number prompt (F)
[ ✻ ] = Continue to the ENROLL MODE prompt (1A)
[#] = Return to previous prompt
F
FF
F
DELETE
DELETE DELETE
DELETE ZONE
ZONEZONE
ZONE
Delete Zone Parameters
If 00 was entered in the Zone Type field or if 0 was entered in the Loop Number field,
confirmation of the delete request will delete all information associated with zone currently
being programmed.
Note: 00 was entered as a zone type in prompt (b), 00 will be retained and system will
advance to prompt (1C).
0 = Discard the delete request.
1 = Confirm the requested delete.
1
11
1A
AA
A
ENROLL
ENROLLENROLL
ENROLL MODE
MODE MODE
MODE
Enroll Mode (this prompt applies to Manually enrollment only)
Confirm, delete or enter Serial Number
0 = Skip to the VOICE DESCRIPTOR prompt (1C). If zone type is “00”, then skips to
DELETE SERIAL NUMBER prompt instead.
1 = Enroll now and proceed to SERIAL NUMBER prompt (1b) (If “LEARNED” is not
displayed).
2 = Copy the last serial number from the local memory buffer (If “LEARNED” is not
displayed).
9 = Delete existing serial number. (Only if “LEARNED” is displayed).
[ ✻ ] = Advance to the VOICE DESCRIPTOR prompt (1C). This will save all zone
parameters.
[#] = Return to the loop number prompt (E).
1
11
1b
SERIAL
SERIALSERIAL
SERIAL NUMBER
NUMBERNUMBER
NUMBER
Serial Number (this prompt applies to Manually enrollment only)
Manually enter the 7-digit serial number printed on the transmitter. If an incorrect digit is
entered, press the [#] key to return to prompt (1A). When all 7 digits are entered, press
the [✻] key. The serial number will be copied into EEROM and the local memory buffer and
the system will return to the (1A) prompt and “LEARNED” will be displayed. If 52 seconds
pass and no entry is been made, the system will return to prompt (1A).
1AL
1AL 1AL
1AL A094
A094A094
A094-
--
-4129
41294129
4129
ENROLL MODE
ENROLL MODEENROLL MODE
ENROLL MODE
The serial number of the device that has been learned will be displayed. “L” will be
displayed in front of the serial number.
Fault and restore the sensor again to confirm the serial number.
1ALC
1ALC1ALC
1ALC A094
A094A094
A094-
--
-4129
41294129
4129
ENROLL MODE
ENROLL MODEENROLL MODE
ENROLL MODE
The system will announce the Voice Descriptor for the zone and “LC” will be displayed in
front of the serial number.
Press [✻] to continue. System will advance to Prompt “1C”
Note: In order for all parameters to be accepted, you must advance to prompt (1C).

- 13 -
✻
✻✻
✻56 ENHANCED ZONE PROGRAMMING PROCEDURE
1
11
1C
CC
C
ZONE DESCRIPTOR
ZONE DESCRIPTORZONE DESCRIPTOR
ZONE DESCRIPTOR
Voice Descriptor
0 = Skip to next zone (A)
1 = Enter descriptor mode (existing zone descriptor will be announced, then descriptor 1
will be repeated)
1
11
1d
Note: System displays 2-digit
selection & alpha
descriptor OR 99 “No
selection”
Descriptor 1
Enter [#] + 2-digit vocabulary index† number of first descriptor word for this zone.
To change the entered index number, press [#] + desired index number.
6 = accept word and advance to descriptor 2 (descriptor 2 will be announced)
8 = accept word and advance to next zone (prompt A) – zone descriptor will be
announced
Press any other key to repeat the selected word
1
11
1E
EE
E
Note: System displays 2-
digit selection & alpha
descriptor OR 99 “No
selection”
Descriptor 2
Enter [#] + 2-digit vocabulary index† number of second descriptor word for this zone.
To change the entered index number, press [#] + desired index number.
6 = accept word and advance to descriptor 3 (descriptor 3 will be announced)
8 = accept word and advance to next zone (prompt A) – zone descriptor will be
announced
Press any other key to repeat the selected word
1
11
1F
FF
F
Note: System displays 2-
digit selection & alpha
descriptor OR 99 “No
selection”
Descriptor 3
Enter [#] + 2-digit vocabulary index† number of third descriptor word for this zone.
To change the entered index number, press [#] + desired index number.
6 or 8 = accept word and advance to next zone (prompt A) – zone descriptor will be
announced
Press any other key to repeat the selected word
† See ✻ 84 ASSIGN ZONE VOICE DESCRIPTORS section for Vocabulary Index.

- 14 -
✻
✻✻
✻56 ENHANCED ZONE PROGRAMMING WORKSHEET
Fill in the required data on this worksheet, then follow the programming procedure.
ZONES ON CONTROL: See explanation of headings (defaults shown are for Table 1)
Zone Zone No. Zone Alarm rpt code Vocabulary
Description (A 01) Type (zt) (hex) (rc) Index
Wired Zone 1 01[00] [00 00] I I
Zone No. Zone Alarm Report Input Loop Transmitter Vocabulary
(A 01) Type (zt) Code in hex (rc) Type (i) No. (l) Serial Number Index
0|2 | [01] | | [01 00] [3] [2] | | [47-04-99]
0|3 | [01] | | [01 00] [3] [2] | | [33-04-99]
0|4 | [03] | | [01 00] [3] [2] | | [80-99-99]
0|5 | [10] | | [01 00] [3] [1] | | [56-99-99]
0|6 | | | | |
0|7 | | | | |
0|8 | | | | |
0|9 | | | | |
1|0 | | | | |
1|1 | | | | |
1|2 | | | | |
1|3 | | | | |
1|4 | | | | |
1|5 | | | | |
1|6 | | | | |
1|7 | | | | |
1|8 | | | | |
1|9 | | | | |
2|0 | | | | |
2|1 | | | | |
2|2 | | | | |
2|3 | | | | |
2|4 | | | | |
2|5 | | | | |
Duress 92—
— [00 00] I I
Keypad Panic (1 & ✻)95[09] [01 00] I I
Keypad Panic (3 & #) 96[00] [00 00] I I
Keypad Panic (✻& #) 99[07] [01 00] I I

- 15 -
✻
✻✻
✻56 ENHANCED ZONE PROGRAMMING WORKSHEET
Button Zones
Zone No. Zone Alarm Report Input Loop Transmitter Vocabulary
(A 01) Type (zt) Code in hex (rc) Type (i) No. (l) Serial Number Index
2|6 | [21] | | [01 00] [5] [3 | |
2|7 | [22] | | [01 00] [5] [2] | |
2|8 | [20] | | [01 00] [5] [4] | |
2|9 | [23] | | [00 00] [5] [1] | |
3|0 | [21] | | [01 00] [5] [3] | |
3|1 | [22] | | [01 00] [5] [2] | |
3|2 | [20] | | [01 00] [5] [4] | |
3|3 | [23] | | [00 00] [5] [1] | |
3|4 | | | | |
3|5 | | | | |
3|6 | | | | |
3|7 | | | | |
3|8 | | | | |
3|9 | | | | |
4|0 | | | | |
4|1 | | | | |
EXPLANATION OF ZONE ASSIGNMENT TABLE HEADINGS
A 01 = ZONE No. Zone Numbers are 01 (wired), 02-25 (RF) only, 26-41 (Button) only, 92 (duress), 95, 96, 99 (panic)
zt = ZONE TYPE 00 = Not Used
01 = Entry/Exit #1
02 = Entry/Exit #2
03 = Perimeter
04 = Interior Follower
05 = Trouble Day/Alarm Night
06 = 24 Hr Silent
07 = 24 Hr Audible
08 = 24 Hr Aux
09 = Fire without Verification
10 = Interior with Delay
14 = Carbon Monoxide
16 = Fire with verification
20 = Arm–Stay
21 = Arm–Away
22 = Disarm
23 = No Alarm Response
24 = Silent Burglary
rc = ALARM REPORT CODE Two Hex Digits. For each Hex Digit, enter: 00–09 for 0–9, 10 for A, 11 for B,12 for C, 13
for D, 14 for E, 15 for F. If "00" is entered as the first digit, there will be no report for that
zone.
For Contact ID reporting, this is enabling code only. Enter any hex digit (other than 00) in
the first pair of boxes. The second pair of boxes is ignored.
i = INPUT TYPE Enter 3 for RF: Supervised RF
Enter 4 for UR: Unsupervised RF
Enter 5 for BR: Button Type RF
l = LOOP NUMBER Used with 5800 RF Loop Input Devices. Record transmitter loop number. Entries are 1-4,
depending on device being used. Refer to the transmitter’s instructions for appropriate
loop numbers.
Zones 2-25 should be assigned as Input Type 3 or 4
and Zones 26-41 should be assigned as Type 5 only.

- 16 -
✻
✻✻
✻80 DEVICE PROGRAMMING
Use this mode to program Powerline Carrier Devices or zone lists for Chime by Zone feature. It is also used to
program the Remote Services Multi-mode (e-mail) event triggers. Press ✻80 while in programming mode.
Note: Entering a number other than the one specified may give unpredictable results.
80
8080
80
DEVICE
DEVICE DEVICE
DEVICE PROG
PROGPROG
PROG MENU
MENU MENU
MENU
Powerline Carrier Device Programming
0 = Exit mode, upon which this prompt blinks.
1 = Enter mode
A01
A01A01
A01
DEVICE
DEVICE DEVICE
DEVICE NUMBER
NUMBERNUMBER
NUMBER
Device Number
Enter the 2-digit device number to be programmed
01-08 = X10 device number
09-16 = Multimode (e-mail) event triggers
[✻] = Continue
00 = Exit Device Programming mode (displays blinking 80; enter ✻+ desired data field or
menu mode number)
b
DEVICE
DEVICE DEVICE
DEVICE ACTION
ACTIONACTION
ACTION
Device Action
Enter the 1-digit action, 0-3, for the device being programmed (current action is displayed).
0 = No response 3 = Pulse on and off
1 = Close for 2 seconds [✻] = Continue
2 = Close and stay closed [#] = Return to previous prompt
C
CC
C
START
STARTSTART
START EVENT
EVENT EVENT
EVENT TYPE
TYPETYPE
TYPE
Start Event Type (If applicable)
Enter the 1-digit start event type, 0-3, for the device being programmed.
0 = Not used 3 = Trouble
1 = Alarm [ ✻ ] = Continue
2 = Fault [#] = Return to previous prompt
d
START
STARTSTART
START ZONE
ZONE ZONE
ZONE LIST
LIST LIST
LIST
Start Zone List (If applicable)
Enter the 1-digit zone list number, 1-3, or 0 if not used, for the device being programmed.
[ ✻ ] = Continue
[#] = Return to previous prompt
E
EE
E
START
STARTSTART
START ZONE
ZONE ZONE
ZONE TYPE
TYPETYPE
TYPE
Start Zone Type (If applicable)
Enter the 2-digit start zone type for the device being programmed (see Powerline Carrier
Device Worksheet for zone type/system operation codes later in this manual).
[ ✻ ] = Continue
[#] = Return to previous prompt
F
FF
F
STOP
STOPSTOP
STOP ZONE
ZONE ZONE
ZONE LIST
LISTLIST
LIST
Stop Zone List (If applicable)
Enter the 1-digit zone list number, 1-3, or 0 if not used, for the device being programmed.
[ ✻ ] = Continue
[#] = Return to previous prompt
1A
1A1A
1A
STOP
STOP STOP
STOP ZONE
ZONEZONE
ZONE TYPE
TYPE TYPE
TYPE
Stop Zone Type (If applicable)
Enter the 2-digit stop zone type for the device being programmed (see Powerline Carrier
Device Worksheet for zone type/system operation codes later in this manual).
[ ✻ ] = Continue to Device Number prompt (A)
[#] = Return to previous prompt

- 17 -
✻
✻✻
✻81 ZONE LISTS
Use this mode to define zone lists for Powerline Carrier Devices and/or for the chime by zone feature. Press ✻81
while in programming mode.
Note: Entering a number other than the one specified may give unpredictable results.
81
8181
81
ZONE
ZONEZONE
ZONE LISTS
LISTS LISTS
LISTS MENU
MENU MENU
MENU
Zone List Programming
0 = Exit mode, upon which this prompt blinks.
1 = Enter mode
A01
A01A01
A01
ZONE
ZONEZONE
ZONE LIST
LIST LIST
LIST NUMBER
NUMBERNUMBER
NUMBER
Zone List Number
2-digit zone list number to be programmed (use zone list 03 for chime by zone feature).
00 = No zone list, exit zone list mode
01, 02 or 03 = Zone List Number
[✻] = Accept zone number and enter the next zone number
b
ZN
ZN ZN
ZN ENTRY
ENTRY ENTRY
ENTRY TO
TOTO
TO LIST
LIST LIST
LIST
Zone Entry To List
Enter the 2-digit zone number to be added to this zone list. The system will announce the
Voice Descriptor for the selected zone, if it is programmed.
[ ✻ ] = Accept zone number and enter the next zone number
00 = Accept zone number and continue to next prompt
C
CC
C
DEL
DEL DEL
DEL WHOLE
WHOLEWHOLE
WHOLE ZN
ZN ZN
ZN LST
LST LST
LST
Delete Entire Zone List
0 = Don’t delete; continue to next prompt
1 = Delete the current zone list
d
DEL
DEL DEL
DEL 1
11
1 ZN
ZN ZN
ZN FRM
FRM FRM
FRM LST
LSTLST
LST
Delete Zones From List?
0 = Don’t delete; continue to next zone list number (prompt A)
1 = Continue to delete zones prompt
E
EE
E
DELETE
DELETE DELETE
DELETE ZONES
ZONESZONES
ZONES
Delete Zones
Enter the 2-digit zone number to be deleted from the current zone list. When deleting a
zone(s) from the zone list, if the selected zone has a Voice Descriptor programmed, upon
deletion it will be announced as a confirmation that it has been deleted.
[✻] = Delete zone and enter next zone to be deleted
00 = Return to next zone list number (prompt A 01)

- 18 -
POWERLINE CARRIER DEVICES WORKSHEET FOR ✻
✻✻
✻80 and ✻
✻✻
✻81
Applicable only if Powerline Carrier Devices are to be used, or chime-by-zone feature is used.
UL
Powerline Carrier Devices have not been evaluated by UL.
✻80 OUTPUT DEVICES
Fill in the required data on the worksheet on below and follow the programming procedure in the Installation
Instructions as you enter the data during the displays and prompts that appear in sequence.
Note:If using P.C.L.D. (X10 devices), Field ✻25 must be programmed with a House Code.
START
either or both
STOP
either or both
DEVICE
NUMBER
ACTION
(aa)
EVENT ZONE
TYPE (et) LIST (zl)
ZONE TYPE
SYS OPERATION (zt)
RESTORE
ZONE LIST (zl)
ZONE TYPE/
SYS OPERATION (zt)
P.L.C.D.*†
01
P.L.C.D.*†
02
P.L.C.D.*
†
03
P.L.C.D.*
04
P.L.C.D.*
†
05
P.L.C.D.*†
06
SYS. P.L.C.D.*†
07
SYS. P.L.C.D.*†
08
[2]
[33]
[36]
E
-
mail event trigger
09
E
-
mail event trigger
10
E
-
mail event trigger
11
E
-
mail event trigger
12
E
-
mail event trigger
13
E
-
mail event trigger
14
E
-
mail ev
ent trigger
15
E
-
mail event trigger
16
[2]
[33]
[36]
Note: If using an X10 Powerhouse Security SH10A Siren as device 08, you must change the action default to “3” if using default table 4.
Where: A = DEVICE ACTION 0 = No Response; 1 = Close for 2 sec; 2 = Close and stay closed; 3 = Pulse on and off.
ET = EVENT TYPE 0 = Not used; 1 = Alarm; 2 = Fault; 3 = Trouble.
Z L = ZONE LIST 1, 2, or 3 (from Field ✻81) or 0 = Not Used.
"START" ZONE LIST: Upon alarm, fault, or trouble of ANY zone on this list, device action will START.
"STOP" RESTORE of ZONE LIST: Upon restore of ALL zones on this list, device action will STOP. It need
not be same list as used for START.
Note: Do not assign zones with types 20, 21, or 22 to a zone list.
ZT = ZONE TYPE/
SYSTEM OPERATION
Choices for Zone Types are:
00 = Not Used
01 = Entry/Exit#1
02 = Entry/Exit#2
03 = Perimeter
04 = Interior Follower
05 = Trouble Day/Alarm Night
06 = 24 Hour Silent
07 = 24 Hour Audible
08 = 24 Hour Aux
09 = Fire Zone without Verification
10 = Interior with Delay
14 = Carbon Monoxide
16 = Fire with verification
24= Silent Burglary
Choices for System Operation are:
20 = Arming–Stay
21 = Arming–Away
22 = Disarming (Code + FF)
31 = End of Exit Time
32 = Start of Entry Time
33 = Any Alarm (except ZT=08 or 09)
36 = *At Bell Timeout
38 = Chime
39 = Any Fire Alarm
* Or at Disarming, whichever occurs earlier.
40 = Bypassing
42 = System Battery Low
43 = Communication Failure
52 = Kissoff
58 = Duress
Note: In normal operation mode: For Devices 01-06:
Function + Lights On + NN
Function + Lights Off + NN
For Devices 07 and 08:
Code + Function + Lights On + NN
Code + Function + Lights Off + NN
NN = 2- digit device number
(Entry starts Device NN)
(Entry stops Device NN)
✻
✻✻
✻81 ZONE LISTS FOR OUTPUT DEVICES
Fill in the required data on the worksheet below and follow the procedure in the installation manual as you enter
the data during the displays and prompts that appear in sequence.
Zone List 1: Started or stopped by zone numbers (enter 00 to end entries).
.etc. [28][32]
Zone List 2: Started or stopped by zone numbers (enter 00 to end entries).
.etc. [29][33]
Zone List 3: Started or stopped by zone numbers AND/OR assignment of Chime zones (enter 00 to end entries)
. etc. [02][03]
Note: Any zone in "ZT" going into alarm, fault, or trouble will activate device with the exception of 01, 02
when the system is in alarm.
Any
zone that restores will stop device action.

- 19 -
✻
✻✻
✻83 ENHANCED SEQUENTIAL MODE
Use this mode to enter transmitter serial numbers. Press ✻83 while in programming mode.
83
8383
83
ENHANCD
ENHANCD ENHANCD
ENHANCD SEQ
SEQSEQ
SEQ MODE
MODE MODE
MODE
Enhanced Sequential Mode
0 = Exit mode, upon which this prompt blinks.
1 = Enter mode
A
AA
A
ZONE
ZONE ZONE
ZONE NUMBER
NUMBERNUMBER
NUMBER
Zone Number
Enter the 2-digit zone number of the first transmitter to have its serial number entered. The
system will announce the Voice Descriptor for the selected zone if it has been programmed.
[ ✻ ] = Continue; system searches for zones not yet entered, (for zones 2 to 25 a zone type
must be entered) then advances to SERIAL NUMBER prompt (1b).
00 = Exit Sequential mode, upon which the prompt “83” blinks .
1A
1A1A
1A
ENROLL
ENROLLENROLL
ENROLL M
M M
MOD
ODOD
ODE
EE
E
Enroll Mode
Enter, View or Confirm Serial Number.
0 = Advance to next unlearned zone.
1 = Enter now and proceed to SERIAL NUMER prompt (1b). For 4-button keys (zones 26-
29, 30-33, 34-37 and 38-41) the serial number will be learned to all four buttons.
2 = copy the previous serial number entry from the buffer.
Note: Before you can copy a serial number you must first enter a serial number. If no serial is stored
in the buffer and a copy is attempted the panel will emit a long beep indicating an invalid
operation.
3 = View existing serial number. (Only if “L” is displayed. If “L” is not displayed, panel will
emit a long beep. Each digit will be displayed and the keypad will beep once for digits 1-6
and three times for last digit.
4 = Copy the 4-button key template set for zones 26 - 29 (includes all zone parameters
except serial numbers). Only valid on 4-button key zones 30-33, 34-37 and 38-41 that do
not have serial numbers learned. (Template acceptance is indicated by two beeps after
copying. A single long beep emitted when copying templates indicates the template is not
valid.)
9 = Delete existing serial number. Go to the (1A) prompt. (For 4-button key zones 26-29,
30-33, 34-37 and 38-41, deletes all four at once.)
[ ✻ ] = Advance to the next unlearned zone.
[#] = Return to previous prompt (1A).
1
11
1b
SERIAL
SERIALSERIAL
SERIAL NUMBER
NUMBER NUMBER
NUMBER
Serial Number
Enroll transmitter serial number via RF transmission or manually.
RF Learning - Two (2) transmissions (two key depressions) at least five seconds apart will
be required for BR type or four (4) transmissions (fault, restore and fault, restore) for UR or
RF type.
If the learned serial number has a different loop number than that entered in ✻ 56 the
system will announce the Voice Descriptor, if it is programmed, followed by two beeps and
will return to Prompt (1A) and “LEARNED” will be displayed.
If the loop number captured by RF transmission and that entered in ✻ 56 mode match, the
system will announce the Voice Descriptor, if it is programmed, followed by three beeps
and return to Prompt (1A) and “LEARNED” will be displayed. No additional transmissions
are needed for confirmation.
Manual Entry - Enter the 7-digit serial number printed on the transmitter. If you enter an
incorrect digit, press the [#] key to backup to prompt (1A) and start over. When all 7 digits
are entered, press the [ ✻ ] key. If less than 7 digits are entered, the keypad will emit a
single long beep and return to the (1A) prompt without displaying “LEARNED”. If more
than 7 digits have been entered, the first 6 digits will be saved along with the last digit that
was entered (entering 123456789 yields the serial number 1234569).
Note: If 52 seconds passes and no entry has been made, the system returns to prompt (1A).
F
FF
F
DELETE
DELETEDELETE
DELETE ZONE
ZONE ZONE
ZONE CONF
CONF CONF
CONF
Delete Zone Parameters Confirmation
0 = Discard the delete request.
1 = Confirm requested delete .

- 20 -
✻
✻✻
✻84 ASSIGN ZONE VOICE DESCRIPTORS
Use this mode to assign voice descriptors for each zone. These are the descriptors that are announced when the
system announces any event involving a zone number. Press ✻84 while in programming mode.
Note: Entering a number other than the one specified may give unpredictable results.
84
8484
84
ZONE
ZONEZONE
ZONE VOICE
VOICE VOICE
VOICE DESC
DESCDESC
DESC
Assign Voice Descriptors
0 = Exit mode, upon which this prompt blinks.
1 = Enter mode
A
AA
A
ZONE
ZONE ZONE
ZONE NUMBER
NUMBERNUMBER
NUMBER
Zone Number
Enter the 2-digit zone number for which this descriptor is being assigned then press [✼].
The Voice Descriptor for the selected zone will be announced, if it has been programmed.
[ ✻ ] = Continue to next prompt (existing descriptors will be announced, then descriptor 1
will be repeated.)
00 = Exit Zone Voice Descriptor mode (displays blinking 84; enter ✻ + desired data field
or menu mode number)
b
DESCRIPTOR
DESCRIPTORDESCRIPTOR
DESCRIPTOR 1
1 1
1
Descriptor 1
Enter [#] + 2-digit vocabulary index number of first descriptor word for this zone.
To change the entered index number, press [#] + desired index number.
6 = accept word and advance to descriptor 2 (descriptor 2 will be announced)
8 = accept word and advance to next zone (prompt A) – zone descriptor will be
announced. Press any other key to repeat the selected word
C
CC
C
DESCRIPTOR
DESCRIPTOR DESCRIPTOR
DESCRIPTOR 2
22
2
Descriptor 2
Enter [#] + 2-digit vocabulary index number of second descriptor word for this zone.
To change the entered index number, press [#] + desired index number.
6 = accept word and advance to descriptor 3 (descriptor 3 will be announced)
8 = accept word and advance to next zone (prompt A) – zone descriptor will be
announced. Press any other key to repeat the selected word
d
DESCRIPTOR
DESCRIPTORDESCRIPTOR
DESCRIPTOR 3
3 3
3
Descriptor 3
Enter [#] + 2-digit vocabulary index number of third descriptor word for this zone.
To change the entered index number, press [#] + desired index number.
6 or 8 = accept word and advance to next zone (prompt A) – zone descriptor will be
announced. Press any other key to repeat the selected word
VOCABULARY INDEX
00 ½ sec pause
A
82 ALARM
32 ATTIC
B
01 BABY
33 BACK
34 BASEMENT
35 BATHROOM
36 BEDROOM
C
83 CHECK
D
37 DELAY DOOR
38 DEN
02 DETECTOR
03 DINING
39 DINING ROOM
04 DOOR
40 DOWNSTAIRS
05 DRIVEWAY
E
06 EAST
41 EIGHT
42 EMERGENCY
F
43 FAMILY ROOM
87 FIRE
44 FIRE DETECTION
07 FIRST FLOOR
45 FIVE
08 FLOOR
46 FOUR
47 FRONT
G
48 GARAGE
49 GUEST ROOM
09 GUN
H
50 HALL
I
10 INSIDE
K
51 KITCHEN
L
11 LAUNDRY
52 LAUNDRY ROOM
12 LIBRARY
13 LIVING
53 LIVING ROOM
M
14 MAIN
15 MASTER
54 MASTER
BEDROOM
55 MEDICAL
84 MESSAGE
56 MOTION DETECTOR
N
57 NINE
16 NORTH
58 NURSERY
O
59 OFFICE
60 ONE
17 OUTSIDE
P
61 PATIO
62 POLICE
18 POOL
R
63 REAR
19 ROOM
S
64 SECOND FLOOR
65 SEVEN
20 SHED
21 SHOP
66 SIDE
67 SILENT POLICE
68 SIX
69 SLIDING
22 SMOKE
23 SOUTH
24 STORAGE
85 SYSTEM
T
25 THIRD FLOOR
75 THREE
76 TRANSMITTER
77 TWO
U
78 UPSTAIRS
26 UTILITY
79 UTILITY ROOM
W
27 WEST
80 WINDOW
Y
28 YARD
Z
81 ZERO
86 ZONES
29 1st
30 2nd
31 3rd
70 Custom Word #1
71 Custom Word #2
72 Custom Word #3
73 Custom Word #4
74 Custom Word #5
99 Blank (to erase
previously
programmed word)
SYSTEM WORDS
(Announced by system –
not programmable)
AC LOSS
ARMED
AWAY
BYPASSED
CARBON MONOXIDE
CHIME
DISARMED
DISARM SYSTEM
NOW
EXIT NOW
FAULT
INSTANT
LOW BATTERY
NOT
READY TO ARM
STAY
Note: If a Wireless Keypad is being installed along with this system, not all the voice descriptors shown on this list can be announced
by keypad. (Refer to the Wireless Keypad documentation for further information).
