SAIC RTR-4 User manual

RTR-4 Portable Digital X-Ray
Imaging System
Operator’s Manual
120300 Rev. D
15 February 2003

RTR-4 Operator’s Manual
ii SAIC Proprietary 120300 Rev. D
SAIC
16701 W. Bernardo Dr.
San Diego, CA 92127-1903
U.S.A.
Copyright © 2001-2003 SAIC
All rights reserved. Printed in the United States of America.
All data and information contained in or disclosed by this document are confidential
and proprietary information of SAIC and its affiliates and all rights herein are
expressly reserved. By accepting this material, the recipient agrees that this material
and the information contained herein are held in confidence and in trust and will not
be used, copied, or reproduced in whole or in part, nor its contents revealed in any
manner to others without the express written permission of SAIC. The recipient also
agrees not to allow the use of this document by others without the express written
consent of SAIC. This technology is controlled by the U.S. Government. Diversion
contrary to U.S. law is prohibited. SAIC reserves the right to change or revise this
information without notice. Reasonable effort has been made to ensure that the
information in this manual is accurate; however, SAIC assumes no responsibility for
inaccuracies or omissions of any kind. SAIC makes no warranty for the use of its
product.
SAIC is a registered trademark of Science Applications International Corporation.
RTR-4™ is a trademark of SAIC
RTR-4 Portable Digital X-Ray Imaging System Operator’s Manual
120300 Rev. D

RTR-4 Operator’s Manual
120300 Rev. D SAIC Proprietary iii
FCC Declaration of Conformity
We SAIC
16701 W. Bernardo Dr.
San Diego, CA 92127-1903 U.S.A.
declare under our sole responsibility that the product
RTR-4 Portable Digital X-Ray Imaging System
complies with Part 15 of FCC Rules. Operation is subject to the following of two
conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance
with this instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference, in which case the user will be required to correct the
interference at his own expense. Changes or modifications not expressly approved by
Science Applications International Corporation could void the user’s authority to
operate the equipment.

RTR-4 Operator’s Manual
iv SAIC Proprietary 120300 Rev. D
Declaration Of CE Conformity
We SAIC
16701 W. Bernardo Dr.
San Diego, CA 92127-1903 U.S.A.
declare under our sole responsibility that the product
RTR-4 Portable Digital X-Ray Imaging System
to which this declaration relates is in conformance with the applicable provisions of
the following directives:
• 73/23;EEC governing product safety.
• 89/336/EEC governing electromagnetic compatibility.
• 99/5/EC governing radio and telecommunication terminal
equipment.
Using the following standards:
• EN61010-1
• EN 61326:1997 +A1:1998 +A2:2001
• EN300 220-3:2000
• EN 301 489-3:2001
15 February 2003
San Diego, CA
Richard Amiton
Director of Engineering

RTR-4 Operator’s Manual
120300 Rev. D SAIC Proprietary v
Revision History
VERSION COPY FREEZE DATE NOTES
— 15 June 1999 Initial release.
A 16 April 1999 Minor revision.
B 28 February 2001 Wireless Option removed from Operator’s Guide
and transformed into a separate supplemental
document.Battery Charger chapter and CU-4
Modem chapter deleted.
C 20 October 2001 Minor text changes.
D 15 February 2003 Incorporate information for Wireless operation
and optional equipment; document new database
software. Word count is 19,926.

RTR-4 Operator’s Manual
vi SAIC Proprietary 120300 Rev. D
Table of Contents
Introduction................................................................................................... 1-1
About this Manual..................................................................................................... 1-1
Purpose and Scope.................................................................................................... 1-1
Document Revisions................................................................................................. 1-1
RTR-4 Technical Support......................................................................................... 1-1
Component Returns............................................................................................ 1-2
Acronyms and Abbreviations ................................................................................... 1-2
Safety Summary ........................................................................................... 2-1
Introduction............................................................................................................... 2-1
Follow all warnings and instructions.................................................................. 2-1
Qualified and Trained personnel only ................................................................ 2-1
Symbols .............................................................................................................. 2-1
Safety Procedures...................................................................................................... 2-2
General Safety Procedures.................................................................................. 2-3
Safe Operating Environment ............................................................................... 2-4
Outdoor Use........................................................................................................ 2-4
System Description, Setup, and Quick Start ......................................... 3-1
Introduction................................................................................................................ 3-1
Hardware Description............................................................................................... 3-1
RTR-4 System Standard Wired Configuration Components.............................. 3-1
Portable Notebook Controller............................................................................. 3-2
Integrated Imager................................................................................................ 3-3
XR200 X-Ray Source......................................................................................... 3-8
Interconnecting Cables ....................................................................................... 3-8
Transport Case.................................................................................................... 3-9
RTR-4 Standard Wireless Configuration.......................................................... 3-10
Setting up the RTR-4 .............................................................................................. 3-12
Distance Adjustments....................................................................................... 3-12
Position Adjustments........................................................................................ 3-12
Standard Wired Configuration.......................................................................... 3-13
Setting Up the Wired Configuration................................................................. 3-13
Standard Wireless Configuration...................................................................... 3-15
Setting Up the Wireless Configuration............................................................. 3-15
Quick Start .............................................................................................................. 3-18
System Initialization......................................................................................... 3-18
Acquiring an X-Ray Image............................................................................... 3-18
System Operation ........................................................................................ 4-1
Introduction................................................................................................................ 4-1
Operating the RTR-4................................................................................................. 4-1
Acquiring an X-Ray Image................................................................................. 4-1
Using the Sum Command................................................................................... 4-3
Using the Add Images Feature ........................................................................... 4-4
Using the Subtract Images Command ................................................................ 4-7
Image Processing ...................................................................................................... 4-9

RTR-4 Operator’s Manual
120300 Rev. D SAIC Proprietary vii
Retrieving an Image............................................................................................ 4-9
Showing Image Information............................................................................. 4-10
Using Multiple Image Display.......................................................................... 4-10
Using the Grid Overlay..................................................................................... 4-11
Measuring Distance in an Image ...................................................................... 4-12
Adding Lines and Text ..................................................................................... 4-13
Using Contrast Stretch...................................................................................... 4-14
Using Automatic Stretch................................................................................... 4-16
Using the Color Palettes ................................................................................... 4-16
Using Saturation Suppression........................................................................... 4-17
Sharpening an Image ........................................................................................ 4-18
Smoothing an Image......................................................................................... 4-19
Reducing Image Noise...................................................................................... 4-20
Using Edge Detection....................................................................................... 4-21
Embossing an Image......................................................................................... 4-22
Using Histogram Equalization.......................................................................... 4-23
Image Preservation.................................................................................................. 4-23
QuickSaving an Image...................................................................................... 4-24
Saving an Image ............................................................................................... 4-25
Print an Image................................................................................................... 4-25
Software Description .............................................................................................. 4-26
RTR-4 Functions .............................................................................................. 4-26
The Acquire Menu............................................................................................. 4-27
The File Menu ................................................................................................... 4-31
The Display Menu ............................................................................................ 4-32
The Modify Menu............................................................................................. 4-35
The Preferences Menu...................................................................................... 4-39
The Window Menu........................................................................................... 4-43
The Help Menu................................................................................................. 4-44
The Icon Toolbar ............................................................................................... 4-45
The Database Function ..................................................................................... 4-48
Shutting Down and Stowing the RTR-4................................................................. 4-56
Shutdown and Stow the RTR-4 (Wired or Wireless Configurations).............. 4-56
Operator Maintenance............................................................................................. 4-57
RTR-4 Care and Cleaning ................................................................................ 4-57
Disk Space........................................................................................................ 4-58
Charging Batteries............................................................................................ 4-58
Imager Battery Replacement ............................................................................ 4-59
Optional External X-Ray Receiver Battery Replacement................................. 4-60
Wireless Signal Strength Test Utility ............................................................... 4-61
Ancillary Equipment................................................................................... 5-1
Introduction............................................................................................................... 5-1
Previous Model Wireless Option.............................................................................. 5-1
Previous Model Controllers...................................................................................... 5-4
Introduction......................................................................................................... 5-4
Standard CU-4 Components............................................................................... 5-4

RTR-4 Operator’s Manual
viii SAIC Proprietary 120300 Rev. D
Power Supply Options........................................................................................ 5-7
Notebook Controller with Battery Box............................................................... 5-8
Previous Model Imagers ......................................................................................... 5-10
Introduction....................................................................................................... 5-10
Standard-View Imager...................................................................................... 5-10
Alternate X-Ray Sources ........................................................................................ 5-12
Introduction........................................................................................................ 5-12
Miscellaneous Accessories ..................................................................................... 5-13
Introduction....................................................................................................... 5-13
Wireless Option Backpack ............................................................................... 5-13
Notebook PC Configuration Accessories......................................................... 5-14
Index .................................................................................................................I-1
List of Figures
Figure 4-1 Main Menu Screen.............................................................................. 4-27
Figure 4-2 Attach Associated Data Window........................................................ 4-52

120300 Rev. D SAIC Proprietary 1-1
1 Introduction
About this Manual
This manual provides information on the setup and use of the
various options and configurations of the Real Time Radioscopy
(RTR-4) Imaging System and is comprised of the following
chapters:
Chapter 1 - Introduction
Chapter 2 - Safety Summary
Chapter 3 - System Description, Setup, and Quick Start
Chapter 4 - System Operation
Chapter 5 - Ancillary Equipment
Purpose and Scope
This manual describes the RTR-4 hardware and software and
provides instructions on its use, including setup of the equipment,
acquisition and processing of X-ray images, and some
troubleshooting. The information in this document is to be used
only by technicians and operators who have been trained to use
the RTR-4 system.
Document Revisions
This manual is revised periodically, based on the amount and
substance of equipment changes and resulting changes to the
manual. When changes to this manual are required, a new
manual incorporating the changes is released.
RTR-4 Technical Support
Technical support is available using the following methods:
• By phone: [phone] (in the US) or 858-826-9831 (outside
of the US) from 0730 to 1630 PDT.
• By fax: [phone].
• By e-mail: Security[email protected].
More information may be found on our website at
http://www.saic.com.

Introduction RTR-4 Operator’s Manual
1-2 SAIC Proprietary 120300 Rev. D
Component Returns
Contact us at the above numbers or e-mail to receive a Return
Material Authorization (RMA) number. Return damaged, failed,
or defective systems or components to the address below. When
shipping components, include a description of the problem and
the RMA number.
SAIC
Attn: RTR-4 Manufacturing Mgr.
16701 W. Bernardo Dr.
San Diego, CA 92127-1903 USA
The Golden Engineering X-ray sources may be handled
separately for customer convenience. Follow the instructions in
the Golden operator’s manual for repair of the Golden
Engineering XR200 X-ray source or visit their website at
http://www.goldenengineering.com.
Acronyms and Abbreviations
The acronyms and abbreviations listed in the table below are used
throughout this manual.
TERM DEFINITION
ALARA As Low As Reasonably Achievable
CU-4 Control Unit 4 (original controller)
ESD Electrostatic Discharge
GUI Graphical User Interface
HERO Hazards of Electromagnetic Radiation to
Ordnance
LED Light Emitting Diode
MB Megabyte (one million bytes)
NCU Notebook Control Unit
NIC Network Interface Card
PC Personal Computer
PCMCIA Personal Computer Memory Card
International Association
PIC Pocket Ionization Chamber

RTR-4 Operator’s Manual Introduction
120300 Rev. D SAIC Proprietary 1-3
RF Radio Frequency
RMA Return Material Authorization
ROI Region Of Interest
RTR Real Time Radiography
SNR Signal-to-Noise Ratio
.tif Tagged Image Format (a filename extension)
TLD Thermoluminescent Dosimeters
Vac Volts alternating current
Vdc Volts direct current
WiFi Wireless Fidelity, a wireless ethernet
communications standard.
TERM DEFINITION

Introduction RTR-4 Operator’s Manual
1-4 SAIC Proprietary 120300 Rev. D

120300 Rev. D SAIC Proprietary 2-1
2 Safety Summary
Introduction
This chapter lists and describes the safety issues applicable to the
standard configurations of the RTR-4. The summaries listed here
apply at all times and shall be strictly followed by all operators,
technicians, and observers.
Follow all warnings and instructions
The equipment and the procedures in this manual have warning
and caution labels and their relevant hazard type symbols.
Observe all warnings, cautions, and instructions marked on the
equipment and included in this manual and in all supporting
manufacturer documentation at all times.
Qualified and Trained personnel only
The RTR-4 should only be operated by technically qualified and
trained personnel. It is the responsibility of the RTR-4 user to
ensure only trained personnel are permitted to configure, operate,
and maintain RTR-4 equipment. It is the responsibility of the user
to verify that all regulations have been met before operating this
equipment.
Symbols
In procedural steps, specific warnings and cautions are placed
immediately prior to the step(s) to which they apply. Specific
warnings and cautions have three parts:
• The specific hazard is stated.
• The correct action to be followed or performed is given.
• The consequences if the correct action is not followed are
stated.
The following warning symbols and the caution symbol are used
in this manual when warnings and cautions are placed into
procedural steps.

Safety Summary RTR-4 Operator’s Manual
2-2 SAIC Proprietary 120300 Rev. D
Safety Procedures
The X-ray source used with the RTR-4 system generates x-rays
that can be harmful to personnel. It is the responsibility of the
operator to ensure that the RTR-4 is properly used by trained
personnel who follow recommended operating procedures and
SYMBOL DEFINITION OF USE
The generic Warning symbol precedes a procedural
step or process which could lead to personnel injury
if not followed correctly. This symbol is used when
multiple hazard conditions may be present or one of
the symbols below does not specifically apply.
The Electrical, High Voltage, or High Current
hazard warning symbol is used where the potential
for electrical shock may exist while performing a
specific task.
The X-Ray Radiation hazard warning symbol is
used whenever emitted x-ray radiation may exceed
background levels during a specific procedure or
process.
The Microwave Radiation hazard warning
symbol is used whenever emitted microwave/rf
radiation is present during a specific procedure or
process.
The generic Caution symbol precedes a procedural
step or process which could lead to equipment
damage if not followed correctly.
The ESD caution symbol precedes a procedural
step or process requiring use of standard approved
ESD damage control procedures to avoid harming
electronic components and circuit card assemblies.
The Note symbol indicates where additional or
clarifying information, commentary, sidelights, or
points of interest have been added to a procedure
either before or after the step to which it applies.

RTR-4 Operator’s Manual Safety Summary
120300 Rev. D SAIC Proprietary 2-3
applicable regulations, and the X-ray Source supplier guidelines,
such as the Golden Engineering XR200 X-Ray Source Operator’s
Manual.
General Safety Procedures
The following are general safety precautions for using X-ray
generating devices:
• As Low As Reasonably Achievable (ALARA) principles of
radiation exposure are applicable whenever the RTR-4 system
is being used. Personnel exposure to X-rays shall be kept to the
absolute minimum possible.
• Users shall establish appropriate exclusion zones to limit
access to the radiation field. This information can be found in
the Users’s Manual for the applicable X-ray source or on the
manufacturer’s webpage. When two or more exclusion zones
apply, such as using the RTR-4 in the presence (or suspected
presence) of explosives, the larger exclusion zone perimeter
shall apply.
• Operating personnel shall review and follow applicable
regulations.
• In order to meet the FCC RF safety regulations when using the
wireless configuration, personnel shall maintain a distance of
at least 20cm (8in) from the WiFi antennas when the system
is operational.
• Personnel in the vicinity when the RTR-4 system is being
operated may be required to wear an approved X-ray radiation
monitoring device in accordance with local regulations or
administrative procedures.
• Personnel shall remain at a safe distance from the X-ray
source, and always remain outside the direct beam during
image acquisition if possible.
• Personnel shall remain at a distance of at least 20cm (7.9in)
from the antennas whenever the RTR-4 wireless option is
being used.
• When using the optional Notebook Safety Lock, the controller
key shall be turned to the OFF position when not acquiring
images. The X-ray source cannot fire when its controller key is
in the OFF position.
• The power key for the X-ray source should be turned to the
OFF position when the system is not acquiring images. The
X-ray Source cannot fire when its key is in the OFF position.

Safety Summary RTR-4 Operator’s Manual
2-4 SAIC Proprietary 120300 Rev. D
• The system operator shall remove the controller key and X-ray
Source keys when not operating the system, to ensure that the
system is not accidentally or improperly operated.
• All reasonable efforts shall be made to reduce doses to ALARA
levels.
Safe Operating Environment
The following environmental conditions affect the safe operating
conditions of the RTR-4:
• Maximum external voltage fluctuation of ± 10%.
• Maximum altitude 2000m (6562ft).
• Operating temperature range 5°C (41°F) to 40°C (104°F).
• Maximum relative humidity of 80%.
Outdoor Use
All parts of the RTR-4 system are intended for the outdoor use
except for the external ac power adapters. If external power
adapters must be used outdoors, ensure they are protected from
adverse weather conditions such as rain or moisture. Failure to
use adequate precautions may result in equipment damage or
personnel hazard.

120300 Rev. D SAIC Proprietary 3-1
3 System Description, Setup, and Quick
Start
Introduction
This chapter describes the standard configuration of the RTR-4
system and contains the following sections:
• Hardware Description.
• Setting up the RTR-4
•QuickStart
The basic system design of the RTR-4 consists of an imager unit,
a controller unit, an X-ray source unit, and the interconnecting
cables or optional wireless components. This chapter covers the
standard wired configuration and the standard wireless
configuration only. Alternate components are covered in later
chapters.
Hardware Description
RTR-4 System Standard Wired Configuration Components
The standard wired RTR-4 configuration includes the following
components:
• Portable Notebook Controller.
• Notebook ac power adapter.
• 30cm (1ft) Notebook to cable reel adapter.
• 50m (164ft) cable reel.
• Integrated Imager.
• Imager ac power adapter and spare battery.
• Imager battery external battery charger.
• RTR-4 Operating Software
• Golden Engineering XR200 X-Ray Source with operator’s
manual.
• 3m (10ft) imager to source cable.
• Source battery charger and spare battery.

System Description, Setup, and Quick Start RTR-4 Operator’s Manual
3-2 SAIC Proprietary 120300 Rev. D
• RTR-4 Portable Digital X-Ray Imaging Set Operator’s
Manual, SAIC document 120300 (this document).
• Transport case.
Portable Notebook Controller
The standard configuration of the RTR-4 system uses a standard
commercial notebook Personal Computer (PC). Functioning as
the controller, the notebook PC contains specific SAIC software
that provides for operator interface with the RTR-4 system and
displays images as they are captured. A special adapter cable is
provided to connect the PC modem RJ45 connector to the RTR-4
system cable reel when the system is setup in the wired
configuration. A WiFi Network Interface Card (NIC) is provided
for connecting in the wireless configuration.
The notebook PC has the following current features:
• A Pentium- series processor.
• A 12.1 in (30.7cm) or larger active matrix color flat panel
display.
•CustomSAICsoftware.
• A 30 GB or greater internal hard drive.
• A 1.44 MB floppy disk drive.
• DVD/CD-RW drive.
• Two CardBus slots.
• 56 kbaud internal modem.
• Internal rechargeable Lithium Ion battery with an external
100-240Vac power adapter and battery charger.
• Current Dimensions: 36.6cm x 25.9cm x 2.55cm (14.1in W x
10.2in D x 1.46in H).
NOTEBOOK PC
AC POWER
ADAPTER
RJ45 CABLE
ADAPTER
WiFi NIC

RTR-4 Operator’s Manual System Description, Setup, and Quick Start
120300 Rev. D SAIC Proprietary 3-3
• Weight: 2.9 kg (6.39lbs).
Storage Medium
Images are stored on disk in an industry-standard format, and
may be manipulated and annotated with third-party software.
The following list shows the RTR-4 Notebook options for storage,
and their capacities. Some differences between notebook
manufacturers will occur.
RJ45 Cable Adapter
This adapter is provided to connect the modem connection on the
controller PC to the 50m cable reel when the RTR-4 is setup in the
wired configuration.
Controller AC Power Adapter
This adapter connects the notebook PC to ac power and provides
19Vdc to the PC for operation or internal battery charging.
Integrated Imager
The Integrated Imager uses a compact solid-state camera with a
20cm x 27cm (8.0in x 10.7in) field-of-view. An electro-optical
system records images formed on the imager's X-ray conversion
screen and transmits the images to the controller PC for display.
Imager features include:
• Dimensions: 30cm x 34cm x 18cm (11.75in W x 13.25in H x
7.0in D).
• Weight: 4.5kg (10.0lbs).
• DR35S NiMH 10.8Vdc battery and an optimal ac power
adapter.
STORAGE MEDIUM MAXIMUM CAPACITY
Internal hard disk
drive.
Over 80,000 images,
depending on size of disk
drive.
1.44 MB floppy disk. Four images per disk.
Optional CardBus
disk drive.
System-defined; up to
thousands of images.
Optional USB flash
disk.
Up to thousands of images.
CD-ROM Up to thousands of images.

System Description, Setup, and Quick Start RTR-4 Operator’s Manual
3-4 SAIC Proprietary 120300 Rev. D
• The imager may use other external power sources between
12Vdc and 24Vdc such as vehicle power.
Image Target Area
The active image area is indicated on the face of the imager. This
is the area that will be displayed on the controller PC.
Orientation Indicator
A triangle in one corner of the image target area is shown as a ball
in a circle on the controller PC image and indicates the lower edge
of the image. This ball is free floating and will always indicate the
downward edge of the image as the imager is positioned on its
sides or other orientations. Rubber feet and standard threaded
tripod mounting holes are provided on three sides to permit
placement of the imager in different orientations.
RTR010 TARGET AREA
ORIENTATION
INDICATOR
ORIENTATION
INDICATOR
