SAIKYO SCOM3216 User manual

SKTVDOMV01
English
Français
The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing LLC in the United States and
other countries.
Enabling certain features and functionality in this product (e.g.
Picture Mode, Volume) may increase its energy consumption,
possibly beyond the limits required for ENERGY STAR
qualification.
This product has earned the ENERGY STAR qualification
meeting US Federal Energy efficiency guidelines as
established by the Department of Energy and Environmental
Protection Agency. The ENERGY STAR program exists to
provide energy saving guidelines and help promote energy
efficient products and practices.
Power Saving Mode is the mode in which the product qualifies
for ENERGY STAR .
L'activation de certaines fonctions et fonctionnalités sur ce
produit (p. ex. Mode image, Volume) peut augmenter sa
consommation d'énergie, probablement au-delà des limites
requises pour la qualification ENERGY STAR .
L'homologation ENERGY STAR a été conférée à ce produit
en conformité aux normes d'efficacité de la Commission
fédérale de régulation de l'énergie (É.-U) établies par le
Ministère de l'énergie et l'Agence pour la protection de
l'environnement. Le programme ENERGY STAR existe pour
fournir des directives relatives aux économies d'énergie et
pour contribuer à la promotion de produits et de pratiques
efficaces du point de vue énergétique.
LED TV / DVD
/ DVD
SAIK YO

TABLE OF CONTENTS
Instructions
DVD
DVD 33-34
35
36
37

FCC Declaration or Conformity Compliance statement
(Part 15):
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions: (1)
this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that may
cause undesired operation. The party responsible for
compliance to these rules is:
ORION SALES,INC.
3471 N.UNION DR. OLNEY,ILLINOIS
62450,U.S.A
Ph:1-800-289-0980

Instruc tions

Instruc tions
27) Explanation of symbol, marking, signal lamp or similar means indicate that apparatus
is completely disconnected from the mains. This equipment is a Class II or double
insulated electrical appliance. It has been designed in such a way that it does not require a
safety connection to electrical earth.
28) Correct Disposal of this product. This marking indicates that this product should
not be disposed with other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste disposal, recycle it responsibly
to promote the sustainable reuse of material resources. To return your used device, please
use the return and collection systems or contact the retailer where the product was purchased.
EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE
ANTENNALEADIN WIR E
ANTENNA
DISCHAGRE UNIT
(NEC SECTIO N 810-20)
GROUNDIN G CONDUCTORS
(NEC SECTIO N 810-21)
GROUND CLAMPS
POWER SERVIC E GROUNDING
ELECTRODE SYSTEM
(NEC ART 250,RARTH)
GROUND
CLAMP
ELEC TRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
26) Where the mains plug is used as the disconnect device, the disconnect device shall
remain readily operable.

Warning: batteries(pack or batteries installed) should not be exposed to excessive heat
such as sunshine, fire or other heat sources.
Instruc tions

Instruc tions

10cm
10cm
below
Instruc tions
Note: Drawing is a representative example only

TV Buttons and Connections
TV Buttons
Note: The following is only a representation of the buttons on your unit. The actual
position and arrangement of the buttons may differ by model.
:Turn ON/OFF Power.
SOURCE:External Signal Input Selection.
MENU:Display Main MENU And Confirm MENU Item Selection.
CH+/-:Select Channel.
VOL+/-:Adjust Volume.
Connections
AV input
External AV Signal Input and
Right/Left Audio Inputs.
AV Output
Right/Left Audio Outputs.
External AV Signal Output and
Component Input
Connect to a component output
connection on your external device.
HDMI Input
Connect to a HDMI output
connection on your external device.
ANT 75/RF Connection
Connect to the antenna/cable TV
output of your device or wall plate.
VGA Input
Connect to your PC using a VGA
cable(not provided).
PC Audio Input
Connect to your PC Audio Out
using 1/8 line cord.
HEADPHONE JACK
Plug earphones into jack for private
listening. Overrides speakers.
USB Input
This input is for service personnel
only.
COAXIAL Output
Connect to your SPDIF device
Output
Audio Out Right/Left
Connect to your external device.
OPTICAL
Digital Audio Output.
Y Pb Pr
INPUT
VIDEO R L
OUTPUT
VIDEO R L
INPUT
OPTICAL
OUTPUT
RL
COAXIAL
HDMI
8
HEADPHONE

5V 0.5A

1
3
2
4
Install and Connect TV
TV AN T
FM AN T
TV signal output
Set your TV
1.Put your TV in a place that can bear the
weight of the TV.
To avoid danger, please do not assemble
the TV near water or extreme heat(such
as a furnace, light source,or candle.)
Do not block the ventilation on the back
of the TV.
Connect antenna and power
2.Connect the antenna cable to the RF
connection on the back of the TV.
Plug the TV into the wall power outlet(
AC120~ 60Hz).
1
3
Turn on the TV
3.While in standby mode the power indication
light will be red.Press the power button on
the TV or remote control.The light will change
to green.
Note:
Picture for reference purposes only.
2
TV Stand Installation Instructions
TV Stand Installation Instructions
1. Open the carton and remove the TV,
accessories, and base.
2. To avoid injury to the TV, place the TV
face down on a firm surface, covered
with a soft cloth. Attach the neck to the
TV with the supplied screws.
3. Attach the base to the neck with the
supplied screws.
4. Note: Insufficient tightening or incorrect
installation of the stand will not support
your unit correctly, and could result in
damage or injury from a tip-over.

Select TV Location
TV Location
If your preferred language is French or Spanish, exit this Setup Wizard by pressing the Menu
button, and follow the instruction on page 19 to make your language selection and re-enter the
Setup Wizard from that Menu screen.
Setup Wizard

/ Power saving
Power saving Produces a lower power consumption mode.

the default
