VM600 AC Drive
User Manual
Verion Code 6.0004.0538-00-VM600-E-V03-202107

VM600
- 1 -
Preface
Thank you for choosing VM600 Series AC Drive.
This user manual introduces the technical specifications, installation
instructions, functions and performance of VM600 Series AC Drive properly.
Please read this user manual carefully before carrying out works such as
installation, commissioning, maintenance, etc.
You are specially warned to read and understand safety precaution items of
this manual before using this product, and to ensure that relevant electrical
installation testers’ professional qualification shall be in line with the provisions
of the labor supervision department, and the electrical and environmental
conditions for product use shall bein conformity with relevant national standards.
Be sure to verify that the wiring is correct before powering on the product.
Before starting the product, it is necessary to debug to ensure correct motor
rotating direction.
During the installation, use and maintenance of the product, if you need to
consult the product's function, performance, other technical problems and safety
precautions, please contact the company's customer service center according to the
service hotline in this manual (please See the cover page of the manual).
Due to the continuous upgrade of the company's products, the content changes
without notice.
Guangzhou Sanjing Electric Co., Ltd.

VM600
- 2 -
CONTENTS
PREFACE......................................................................................... - 1 -
SAFETY PRECAUTIONS ............................................................... - 3 -
CHAPTER 1 PRODUCT INFORMATION..................................... - 6 -
1.1 TECHNICAL SPECIFICATIONS........................................................................ - 6-
1.2 PRODUCT NAMEPLATE ................................................................................. - 7-
1.3 MODEL DESCRIPTION................................................................................... - 7-
1.4 PRODUCT MODEL......................................................................................... - 8-
CHAPTER 2 INSTALLATION........................................................ - 9 -
2.1 OVERALL STRUCTURAL DRAWING（UNIT：MM）...................................... - 9-
2.2 TERMINAL CONNECTION............................................................................ - 10 -
CHAPTER 3 DISPLAYAND OPERATION.................................. - 12 -
3.1 KEYPAD..................................................................................................... - 12 -
3.2 DESCRIPTION OF INDICATORS AND KEYS.................................................... - 12 -
CHAPTER 4 PARAMETER FUNCTION..................................... - 13 -
4.1 FUNCTIONAL PARAMETER.......................................................................... - 13 -
4.2 MONITORING PARAMETERS ....................................................................... - 20 -
4.3 ERROR RECORDS....................................................................................... - 21 -
CHAPTER5 COMMUNICATION PROTOCOL.......................... - 22 -
5.1 COMMUNICATION CONTROL ADDRESS ...................................................... - 22 -
5.2 EEPROMADDRESSES INTRODUCTION...................................................... - 23 -
CHAPTER 6 TROUBLESHOOTING & COUNTERMEASURES - 24
-
6.1 FAULTS AND SOLUTIONS ............................................................................ - 24 -
6.2 COMMON FAULTS AND SOLUTIONS............................................................. - 26 -
CHAPTER 7 CONTECT SAJ........................................................ - 27 -
WARRANTY CARD............................................................................. - 28 -

VM600
- 3 -
Safety precautions
■ Warning sign
DANGER: Indicates that failure to comply with the notice will result in
severe personal injure or even death.
WARNING: Indicates that failure to comply with the notice will result in
moderate personal injury, property damage or equipment damage.
WARNING
◎Do not install or operate any AC Drive that is damaged or with missing parts.
Failing to follow this rule can result in facility damage or severe injury.
◎When installing or handling the AC Drive, please hold the bottom of the
product rather than the case only, to prevent its falling and being damaged.
◎Install the AC Drive on nonflammable material like metal, and keep away from
flammable or explosive object, heat source, and similar environment. Otherwise,
fire may be caused.
◎When AC Drive is installed inside an electrical cabinet or other kind of
enclosure, please install fans or other cooling devices, and keep ventilation well
enough to ensure the enclosure temperature below 40℃, or the AC Drive may be
damaged due to extreme high temperature.
◎Before wiring, ensure the AC Drive rated input voltage and phases are
compatible with the input power source, or fire or personal injury may be caused.
◎Never connect the AC power supply to output terminals U, V and W.
Otherwise, the AC Drive will be damaged and the warranty is invalid.
◎Never carry out withstand voltage test to the AC Drive, for example by a
megohmmeter. Otherwise, it may cause damage to the AC Drive.
◎The connecting cable of the main circuit terminal should use an insulating
sleeve.
◎When the cable length between the AC Drive and the motor exceeds 50
meters, an output reactor is recommended to be used.

VM600
- 4 -
◎Do not use a circuit breaker to control the start and stop of the AC Drive.
Otherwise, the AC Drive may be damaged.
◎Since the AC Drive makes the motor running speed from low to high in a short
time, please confirm that the motor and equipment are in the allowed running
range before running.
◎Do not touch due to high temperature of the heat sink and braking resistor.
◎The factory parameters of the AC Drive can meet the requirments of most
equipment operation. Under normal circumstances, please do not modify the AC
Drive parameters at will. Even if there is some special applications need to change
the AC Drive parameters, only necessary parameters could be changed.
Otherwise, AC Drive damage may be caused.
◎The PCB board has a CMOS integrated circuit. Do not touch it with your hands,
otherwise, static electricity will damage the PCB board.
DANGER
◎Wiring must be completed by qualified professional electricians, otherwise,
there may be electric shock or damage to the AC Drive.
◎The power must be disconnected during wiring; otherwise, it may cause electric
shock or fire.
◎The grounding terminal should be effectively grounded; otherwise, the outer
casing of the AC Drive may be energized.
◎Do not touch the main circuit terminals, otherwise, it may cause electric shock.
◎Terminals for brake resistor are (+) and PB. Do not wire to other terminals,
otherwise, fire may be caused.
◎It is only allowed to power on the AC Drive after the wiring is finished and its
cover is reinstalled. It is strictly prohibited to remove the cover of AC Drive while
power is on. Otherwise, it may cause electric shock.
◎Before programming the AC Drive with fault auto reset or restart option after
power off, the mechanical device need to be implemented with safety protection
measures first. Otherwise, personal injury will be caused.

VM600
- 5 -
◎“ STOP/RESET” key may become invalid as a result of some function setting.
It is recommended to install an independent emergency circuit breaker for the
AC Drive control system, otherwise, or personal injury may be caused.
◎When the power is on, there may be electricity in the AC Drive’s terminals
even if it is in stop mode. Do not touch U, V, W terminals and motor connection
terminals, or electrical shock may be caused.
◎Never touch the AC Drive connection terminals when power is on. Otherwise,
it may cause an electrical shock.
◎Only qualified electricians can be authorized to do the jobs of maintenance,
checking, or parts replacement.
◎After the power supply is OFF, make sure the charge LED is OFF and the
residual voltage does not exist, or wait for at least 10 minutes before carrying out
maintenance or inspection. Otherwise, damage or injury may be caused.
◎Modification to the AC Drive without permission is strictly prohibited,
otherwise, severe injury may be caused. Arbitrarily modification of AC Drive
will result in service warranty invalid.

VM600
- 6 -
Chapter 1 Product information
1.1 Technical specifications
Item
Specifications
Control
features
Control mode
V/F control
Startup torque
0.5Hz/100%
Speed range
1：50
Speed stability accuracy
±1%
Carrier frequency
1kHz ～6kHz；
Overload capacity
60s for 150% of the rated current, 1s for 180% of the rated
current.
Torque boost
0.0% ～30.0%
Input and
Output
Input voltage range
220V/380V; fluctuation range :±15%
Input frequency range
50/60Hz；fluctuation range :±5%
Output voltage range
0-input voltage; the error is less than 5%
Output frequency range
0-400Hz
Basic
function
Running command source
Three command source：keypad; control terminals; serial
communication port.
Frequency source
such as digital setting, analog voltage setting, analog current
setting, serial communication port setting.
DC braking
Braking time: 0.0s ～50.0s;
Braking action current value: 0.0% ～100.0%
Simple PLC/Multiple
speeds
It implements up to 8 speeds via the simple PLC function or
combination of DI terminal states.
Protection mode
Motor short-circuit detection at power-on, input/output phase
loss protection, overcurrent protection, overvoltageprotection,
undervoltage protection, overheat protection, overload
protection and so on.
Display
and Key
operation
LED display
It displays the parameters.
Parameters locking
function
It can lock the parameters to prevent malfunction.
Environ
ment
Installation location
Indoor, free from direct sunlight, dust, corrosive gas,
combustible gas, oil smoke, vapour, drip or salt.
Altitude
Lower than 1000m. When it is higher than 1000m, for every

VM600
- 7 -
Item
Specifications
100m, it needs to reduce power by 1%, and the maximum
altitude is 3000m.
Ambient temperature
-10℃～50℃. When it is higher than 40℃, for every 1℃, it
needs to reduce power by 1%, and the maximum ambient
temperature is 50℃
Humidity
≤95%RH, without condensing
Vibration
Less than 5.9m/s2 (0.6g)
Storage temperature
-25℃～+60℃
Table 1-1-1 Technical specification shee
1.2 Product nameplate
IP20
Product model
Power
Input specification
Output specification
Product barcode
Certification /
protection level
MODEL: VM600-2S1R5-E
POWER: 1.5kW
INPUT: 1PH AC 220V±15% 14A 50/60Hz
OUTPUT: 3PH AC 0-220V 7A 0-400Hz
S/N：
Figure 1-2-1 Product nameplate
1.3 Model description
VM600 –2 S 1R5GB
①②③④
Field
No.
Identification
Description
Product series
①
Product series
VM600 series
Voltagegrade
②
Voltagegrade
2：220VAC；4：380VAC
The input power
③
Power phase
identification
S: single ；T: three-phase
Rated power
④
Power range
1R5-1.5kW，R is the decimal point
Table 1-3-1 VM600 series model field comment

VM600
- 8 -
1.4 Product model
AC Drive Model
Rated
power
Power
capacity
Input
current
Output
current
Motor G/P
kW
kVA
A
A
kW
HP
VM600-2SR75
0.75
1.5
8.2
4
0.75
1
VM600-2S1R5
1.5
3
14.2
7
1.5
2
VM600-2S2R2
2.2
4
23
9.6
2.2
3
VM600-4TR75
0.75
1.5
3.4
2.5
0.75
1
VM600-4T1R5
1.5
3
5
3.8
1.5
2
VM600-4T2R2
2.2
4
5.8
5.1
2.2
3
VM600-4T004
4
5.9
10.5
9
4/
5.5
VM600-4T5R5
5.5
8.9
14.6
13
5.5
7.5
VM600-4T7R5
7.5
11
20.5
17
7.5
10
VM600-4T011
11
17
26
25
11
15
VM600-4T015
15
21
35
32
15
20
Table 1-4-1 Product model table

VM600
- 9 -
Chapter 2 Installation
2.1 Overall structural drawing（unit：mm）
W
W1 dD
H
H1
Figure 2-1-1 Outline dimension diagram
AC Drive Model
Overall Dimensions
Mounting Hole
Mounting
Hole
Diameter
H
W
D
H1
W1
d
VM600-2SR75
134
69
104
123
55
5
VM600-2S1R5
VM600-2S2R2
142
72
116
130
59
5
VM600-4TR75
VM600-4T1R5
VM600-4T2R2
VM600-4T004
196
95
132
179
79
5.5
VM600-4T5R5
225
115
154
208
99
5.5
VM600-4T7R5
VM600-4T011
-
-
-
-
-
-
VM600-4T015
-
-
-
-
-
-
Table 2-1-1 outline dimension

VM600
- 10 -
2.2 Terminal connection
+10V
AI
GND
DI1
DI2
DI3
DI4
Forward
Reverse
Fault reseting
Multi-speed terminal 1
RC
RA
Relay output
S+
S-
RS485
communication
terminal
I
AI
V
R/L
S
T/N
U
V
W
PE
MCCB
Power input
terminal L1
L2
L3
Out ternimal
PE
RJ45
Analog input terminal
Figure 2-2-1 Terminal connection

VM600
- 11 -
Main circuit connection
Terminal mark
Name
Description
R、S、T
Power supply input terminals
Connect to the AC power supply
U、V、W
AC drive output terminals
Connect the three-phasemotor.
Grounding terminal
Must be grounded.
Table 2-2-1 Main circuit terminals and function
Control circuit connection
Category
Terminal symbol
Terminal name
Function description
Power
supply
+10V-GND
＋10V power supply
Provide +10V power supply to external unit.
Maximum output current: 20 mA.
+24V-COM
＋24V power supply
Provide +24V power supply to external unit.
Analog
input
AI-GND
Analog input terminal 1
Input voltage range: 0-10V
Digital
input
DI1
Digital input 1
DI2
Digital input 2
DI3
Digital input 3
DI4
Digital input 4
Relay
output
RA-RC
NO terminal
NO terminal
Communication port and socket
S+
RS485 signal positive terminal
S-
RS485 signal negative terminal
Table 2-2-2 Control terminal instruction

VM600
- 12 -
Chapter 3 Display and operation
3.1 Keypad
You can modify the parameters, monitor the working status and start or stop the AC Drive by
operating the keypad, as shown in the following figure.
Figure 3-1-1 Keypad diagram
3.2 Description of indicators and keys
Item
Name
Function
Indicator
Status
RUN：ON/Running；OFF/Stop.
REMOTE ：ON/Terminal control ；Blinking/Communication ；
OFF/keypad control.
FWD/REV ：ON/Forward rotation ；OFF/Reverse rotation ；
Blinking/Forward and reverse switching.
ALARM：Blinking /Fault state.
按键
PRG
(Programming)
Enter or exit the first menu.
ENT (Confirm)
Enter the menu interfaces and confirm the parameter setting.
△（Increment）
Increase date or function code.
▽（Decrement）
Decrease data or function code.
<<（Shift）
Select the displayed parameters in the stop or running state and select the
digit to be modified when modifying parameters.
RUN/STOP
Control drive start and stop in keypad control mode.
Perform the reset operation when it is in the fault state.
potentiometer
Resistance potentiometer
Frequency adjustment in keyboard operation mode
Table 3-2-1 Description of Indicators and key

VM600
- 13 -
Chapter 4 Parameter function
“○”: the parameter can be modified in both standby and operating state；
“●”: the parameter can’t be modified in operating state；
“◎”:the parameter is the actual detected and recorded value which can’t be modified；
Note: the communication address is hexadecimal.
4.1 Functional parameter
Parameter
Name
Setting Range
Default
Property
Address
F0.00
Reserved
Reserved
0
●
0000
F0.01
Command source selection
0：Operation panel control（LED off）
1：Terminal control（LED on）
2：Communication LED (LED
blinking）
0
●
0001
F0.02
Setting main frequency
sourceX
0：Digital setting (non-retentive at power
failure)
1：Digital setting (retentive at power
failure)
2：Keypad Knob
3：AI
4：Multi-stage speed
5：Simple PLC
6：Communication
2
●
0002
F0.03
Keypad setting frequency
0.00Hz～F0.05
50.0Hz
○
0003
F0.04
Runningdirection selection
0：Forward
1：Reverse
0
○
0004
F0.05
Maximum Output
Frequency
50.00Hz～400.00Hz
50.0Hz
●
0005
F0.06
Upper Limit of Frequency
F0.07～F0.05
50.0Hz
○
0006
F0.07
Lower Limit of Frequency
0.00Hz～F0.06
0.0Hz
○
0007
F0.08
The option of frequency
lower limit
0：Running at frequency lower limit
1：Stop
2：Standby
0
○
0008
F0.09
Carrier Frequency
1kHz～6.0kHz
6.0kHz
●
0009
F0.10
Acceleration Time 1
0.0s～100.0s
10.0s
○
000A
F0.11
Deceleration Time 1
0.0s～100.0s
10.0s
○
000B
F0.12
Stop Mode
0：Decelerate to stop
1：Free stop
0
○
000C

VM600
- 14 -
Parameter
Name
Setting Range
Default
Property
Address
F0.13
Retentive of digital setting
frequency
0：No retentive
1：retentive
1
●
000D
F0.14
Fan operating mode
0：Run when motor is running
1：Keep run when power on
0
○
000E
F0.15
AI1 Input Option
0：0-10V
1：4-20mA
2: 0-20mA
3：0-5V
4：0.5-4.5V
0
○
000F
F1.00
Default Setting Restoring
0：No Operation
1：Restore to factory default setting (not
including F2 parameters)
2：Clear error records
0
●
0100
F1.01
Parameters Lockup
0：Invalid
1：Valid
0
○
0101
F1.02
User Password
0～65000
0
○
0102
F2.00
Motor Rated Power
0.1kW～2.2kW
Determined
by Drive
Model
●
0200
F2.01
Motor Rated Voltage
0-380V
Determined
by Drive
Model
●
0201
F2.02
Motor Rated Frequency
0- F0.05
Determined
by Drive
Model 定
●
0202
F2.03
Motor Rated Current
1.00-10.00
Determined
by Drive
Model
●
0203
F2.05
Type of Motor
0：Single Phase
1：Three Phase
0
●
0205
F2.06
Single-phase motor main
and auxiliary winding turns
ratio
10 ～200
80
○
0206
F2.07
Single-phase motor current
correction factor
50 ～200
130
○
0207
F3.00
V/F Curve Setting
0：Linear
1：Multi-Point
0
●
0300
F3.01
Multi-Point Frequency 1
0.00Hz~F3.03
3
●
0301
F3.02
Multi-Point Voltage 1
0.0%~100.0%
8
●
0302
F3.03
Multi-Point Frequency 2
F3.03~F3.05
5
●
0303
F3.04
Multi-Point Voltage 2
0.0%~100.0%
15
●
0304

VM600
- 15 -
Parameter
Name
Setting Range
Default
Property
Address
F3.05
Multi-Point Frequency 3
F3.05~F2.02（Motor Rated Frequency）
8
●
0305
F3.06
Multi-Point Voltage 3
0.0%~100.0%
22
●
0306
F4.00
Torque Boost
0.0%～30.0%
4.0%
○
0400
F4.01
Cut-off frequency of torque
boost
0.00Hz～F0.05
50.00Hz
●
0401
F4.02
Trigging frequency of DC
braking at stop
0.00Hz～F0.05
0.00Hz
○
0402
F4.03
Delay time of DC braking at
stop
0.0s～50.0s
0.0s
○
0403
F4.04
The current of DC braking
at stop
0～100%
0
○
0404
F4.05
The time of DC braking at
stop
0.0s～50.0s
0.0s
○
0405
F4.06
Automatic adjustment of
carrier Frequency
0:Invalid; 1:Valid
0
●
0406
F4.07
0 frequency output option
0:Valid; 1:Invalid
1
●
0407
F5.00
DI1 terminal function
selection
0: No function
1: Forward running (FWD)
2: Reverse running (REV)
3: Three-wire operationcontrol
4: Forward point movement (FJOG)
5: Reverse point movement (RJOG)
6:Error Reset
7:Terminal UP
8:Terminal Down
9:UP/DOWN Setting Clear
10:External error input(Normally Open)
11：PLC Status reset
12:Multi stage speed terminal 1
13: Multi stage speed terminal 2
14:Reserved
1
●
0500
F5.01
DI2 terminal function
selection
2
●
0501
F5.02
DI3 terminal function
selection
6
●
0502
F5.03
DI4 terminal function
selection
0
●
0503
F5.04
DI filter time
0.000s～1.000s
0.010s
○
0504
F5.05
Terminal Command Option
0: Two-line mode 1
1: Two-line mode 2
2: Three-line mode 1
3: Three-line mode 2
0
●
0505
F5.06
UP/DOWN change rate
range
0.01Hz～50.00Hz
0.50Hz
○
0506
F5.07
AI minimum input
0.00V～F5.09
0.00V
○
0507
F5.08
Percentage rate of AI
minimum input
-100.0%～+100.0%
0.0%
○
0508
F5.09
AI maximum input
F5.07～+10.00V
10.00V
○
0509
F5.10
Percentage rate of AI
maximum input
-100.0%～+100.0%
100.0%
○
050A
F5.11
AI filter time
0.00s～10.00s
0.10s
○
050B
F5.12
DI1 Enable Delay Time
0.0s～100.0s
0.0s
○
050C
F5.13
DI2 Enable Delay Time
0.0s～100.0s
0.0s
○
050D

VM600
- 16 -
Parameter
Name
Setting Range
Default
Property
Address
F5.14
DI1 Disable Delay Time
0.0s～100.0s
0.0s
○
050E
F5.15
DI2 Disable Delay Time
0.0s～100.0s
0.0s
○
050F
F5.16
AI Input Digital Functional
Option
0: No function
1: Forward running (FWD)
2: Reverse running (REV)
3: Three-wire operationcontrol
4: Forward point movement (FJOG)
5: Reverse point movement (RJOG)
6:Error Reset
7:Terminal UP
8:Terminal Down
9:UP/DOWN Setting Clear
10:External error input(Normally Open)
11：PLC Status reset
12:Multi stage speed terminal 1
13: Multi stage speed terminal 2
14:Reserved
0
●
0510
F5.17
AI Input Valid Level Option
0：Low Level Valid
1：High Level Valid
1
○
0511
F6.00
Relay Output Option
0：No Output
1：VFD Running
2：Error Output(Output is valid only after
VFD stops)
3：Ready for Running
4：Communication Setting
5: User Defined Output
0
○
0600
F6.01
Relay1 Closed Delay Time
0.0s～100.0s
0.0s
○
0601
F6.02
Relay1 Open Delay Time
0.0s～100.0s
0.0s
○
0602
F6.03
User defined output
Variability option（EX）
0：Running Frequency
1：Set Frequency
2：Bus Voltage
3：Output Voltage
4：Output Current
0
○
0603
F6.04
User defined comparison
method
Units digit：comparisontest method
0: Equal (EX==X1)
1: Equal or greaterthan
2: Equal or lessthan
3 Intervalcomparison (X1≤EX≤X2)
4:Units digit test (EX&X1=X2)
Tens digit: output method
0: False valueoutput
1: Real valueoutput
0
○
0604
F6.05
User defined output dead
0～65535
0
○
0605

VM600
- 17 -
Parameter
Name
Setting Range
Default
Property
Address
zone
F6.06
User-definedoutput
comparison value 1
0～65535
0
○
0606
F6.07
User-defined output
comparison value 2
0～65535
0
○
0607
F6.08
AO1 Output Option
0：Running Frequency（0～F0.05）
1：Set Frequency（0～F0.05）
2：Output Current（0～Double Rated
Current of VFD）
3：Output Voltage（0～1.2times of VFD
Rated Output Voltage）
4：AI（0～10V）
5：Bus Voltage（0～500.0/1000.0V）
0
○
0608
F6.09
AO2 Output Option
0
○
0609
F6.10
AO1 offset coefficient
-100.0%～+100.0%
0.0%
○
060A
F6.11
AO1 gain
-10.00～+10.00
1.00
○
060B
F6.12
AO2 offset coefficient
-100.0%～+100.0%
0.0%
○
060C
F6.13
AO2 offset coefficient
-10.00～+10.00
1.00
○
060D
F7.00
Reserved
Reserved
0
○
0700
F7.01
STOP Button Function
0：Valid only at keypad control mode
1：Valid at all control modes
1
○
0701
F7.02
LED display parameters at
running status
Bit0：Running Frequency(Hz)
Bit1：Set Frequency(Hz)
Bit2：Bus Voltage(V)
Bit3：Output Voltage(V)
Bit4：Output Current(A)
Bit5：DI Input Status
Bit6：DO Output Status
Bit7：Keypad Knob Voltage(V)
Bit8：AIVoltage(V)
Bit9：Load Speed
Bit10：PID Set Value
Bit11：PID Feedback Value
Bit12：PLC Stage
Bit13：Feedback Frequency （Unit ：
0.1Hz)
Bit14：Communication Set Value
Bit15：Main Frequency Source X
0x1F
○
0702
F7.03
LED display parameters at
stop status
0x06
○
0703
F7.04
Load speed display
coefficient
0.0001～6.5000
3.000
○
0704
F7.05
Software Version
-
-
◎
0705
F8.00
Jog Running Frequency
0.00Hz～F0.05
2.00Hz
○
0800
F8.01
Jog Acceleration Time
0.0s～100.0s
10.0s
○
0801

VM600
- 18 -
Parameter
Name
Setting Range
Default
Property
Address
F8.02
Jog Deceleration Time
0.0s～100.0s
10.0s
○
0802
F8.03
FWD/REV dead zone time
0.0s～100.0s
0.0s
○
0803
F8.04
Reverse control
0：valid
1：invalid
0
○
0804
F8.05
Reserved
0
0
●
0805
F8.06
Startup Protection Option
0：Invalid
1：Valid
0
○
0806
F8.07
Terminal jogging priority
0：Invalid 1：Valid
1
○
0807
FC.00
Local Addresse
1～30，0 for broadcast addresse
1
○
0C00
FC.01
Baud Rate
0：4800bPS
1：9600bPS
2：19200bPS
1
○
0C01
FC.02
Data format
0：No check, data format (8.N.1)
1：Odd Parity check, data format (8.O.1)
2：Even paritycheck, data format (8.E.1)
0
○
0C02
FC.03
Respond Delay
0ms～20ms
2
○
0C03
FC.04
Reserved
0
0
●
0C04
FD.00
Multistage speed0
-100.0%～100.0%(100.0% as F0.05)
0.00%
○
0D00
FD.01
Multistage speed1
-100.0%～100.0%
0.00%
○
0D01
FD.02
Multistage speed 2
-100.0%～100.0%
0.00%
○
0D02
FD.03
Multistage speed3
-100.0%～100.0%
0.00%
○
0D03
FD.04
Simple PLC running mode
0:Stop after the AC Drive runs one cycle
1:Keep final values after the AC Drive
runs one cycle
2:Repeat after the AC Drive runs one
cycle
0
○
0D04
FD.05
Simple PLC retentive
option
Units Digit：Reserved
Tens Digit：
0：Invalid
1：Valid
0
○
0D05
FD.06
Running time of simple
PLC reference 0
0.0s(h)～100.0s(h)
0.0s(h)
○
0D06
FD.07
Acceleration/deceleration
time of simple PLC
reference 0
0～3
0
○
0D07
FD.08
Running time of simple
PLC reference 1
0.0 ～100.0
0.0s(h)
○
0D08
FD.09
Acceleration/deceleration
time of simple PLC
reference 1
0 ～3
0
○
0D09
FD.10
Running time of simple
PLC reference 2
0.0 ～100.0
0.0s(h)
○
0D0A
FD.11
Acceleration/deceleration
time of simple PLC
reference 2
0 ～3
0
○
0D0B
FD.12
Running time of simple
PLC reference 3
0.0 ～100.0
0.0s(h)
○
0D0C

VM600
- 19 -
Parameter
Name
Setting Range
Default
Property
Address
FD.13
Acceleration/deceleration
time of simple PLC
reference 3
0 ～3
0
○
0D0D
FD.14
Time unit of simple PLC
running
0：s（second）
1：h（hour）
2：min（minute）
0
○
0D0E
FD.15
The source of multistage
speed0
0：Set by FD.00
1：AI
0
○
0D0F
