OPERATING MANUAL
MODEL NO.
7583-50
7583-52
HAZARDOUS DUTY
PUMP DRIVES
Cole-Parmer Instrument Co.
625 East Bunker Court
Vernon Hills, Illinois U.S.A. 60061-1844
800-MASTERFLEX (627-8373)
[phone] (Fax)
www.masterflex.com
e-mail: [e-mail]
A-1299-0676
Edition 02
®
and
Untitled-1 2/17/04, 7:27 AM1

Untitled-1 2/17/04, 7:27 AM2

TABLE OF CONTENTS
Title Page
SAFETY PRECAUTIONS ................................................................. ii
INTRODUCTION AND GENERAL DESCRIPTION ......................... 1
SETUP AND DRIVE OPERATION ................................................... 2
Wiring ........................................................................................... 2
GENERAL INSTRUCTIONS ............................................................ 3
OPERATING INSTRUCTIONS ........................................................ 4
PUMP MOUNTING .......................................................................... 5
Add-On Head Capacity ................................................................. 6
MAINTENANCE ............................................................................... 6
Cleaning ........................................................................................ 6
Service Parts ................................................................................ 6
Lubrication .................................................................................... 6
SPECIFICATIONS ........................................................................... 7
WARRANTY ..................................................................................... 8
PRODUCT RETURN........................................................................ 8
TECHNICAL ASSISTANCE ............................................................. 8
i
Untitled-1 2/17/04, 7:27 AM3

Trademarks bearing the ® symbol in this publication are registered in the U.S. and in other countries.
SAFETY PRECAUTIONS
DANGER: The pump drive is intended for installation in a Class
1 Division 1 Group D hazardous (classified) locations
and must be installed by a qualified electrician per
the National Electrical Code ANSI/NFPA 70. Incorrect
installation of this product can result in the explo-
sive ignition of flammable vapors and liquids which
may be present.
WARNING: To prevent ignition of hazardous atmospheres, this
system must not be installed in an area where vapor
or gases having an ignition temperature less than
280°C are present.
CAUTION: Failure to wire the system in the manner prescribed
can result in premature failure of the mechanical
speed reduction system and will result in voiding
the warranty.
WARNING: PRODUCT USE LIMITATION
These products are not designed for, nor intended for use in
patient connected applications; including, but not limited to,
medical and dental use, and accordingly have not been sub-
mitted for FDA approval.
ii
Untitled-1 2/17/04, 7:27 AM4

INTRODUCTION AND GENERAL DESCRIPTION
The Hazardous Duty MASTERFLEX Drive System Model 7583-50 con-
sists of a fixed speed 120V, single phase, 60 Hz motor, a variable me-
chanical speed reducing control, and a pump mounting bracket with
the appropriate drive adapters for MASTERFLEX®L/S®and
MASTERFLEX®I/P®pumps.
Model 7583-52 is identical to Model 7583-50 except that the unit is
supplied without a motor, this allows the customer to furnish the motor
for a specific application.
The pump mounting plate will accept all MASTERFLEX®L/S®and
MASTERFLEX®I/P®Pump Heads with standard (short) shafts. Ad-
ditional MASTERFLEX Pump Heads with standard (short) shafts may
be used in tandem.The pump speed can be varied from 10 to 430 rpm.
The pump rotates in one direction only, clockwise.
For Model 7583-52 to be acceptable for use in a hazardous (classified)
location, the motor supplied by the customer must be UL listed for use
in Class 1 Group D locations. The system is set up to accept a NEMA
56 frame motor without requiring modification.
Couplings are supplied to connect the motor to the mechanical speed
reducer. The base is threaded to accept the 1/4-20 mounting hardware
supplied to fasten the motor to the base.
1
Untitled-1 2/17/04, 7:27 AM5

SETUP AND DRIVE OPERATION
Wiring
The Model 7583-50 drive is intended for hazardous (classified) loca-
tions requiring equipment with a Class 1 Group D rating where gases
or vapors that have an ignition temperature greater than 280°C are
present. Installation of the 7583-50 drive system must be made in ac-
cordance with the National Electrical Code ANSI/NFPA 70 and any
applicable local codes.
The motor must be wired such that the output shaft of the MOTOR
rotates in a clockwise direction when facing the motor shaft. See the
wiring diagram below.
2
WIRING DIAGRAM
For Model 7583-52, the motor which is supplied by the customer must
be wired so that the output shaft of the motor rotates in a clockwise
direction when facing the motor shaft.
CAUTION: Failure to wire the system in the manner prescribed
can result in premature failure of the mechanical
speed reduction system and will result in voiding
the warranty.
Untitled-1 2/17/04, 7:27 AM6

GENERAL INSTRUCTIONS
Two different coupling drive adapters are supplied with each drive, the
coupling with the narrow slot is for MASTERFLEX®L/S®pumps, the
coupling end with a wide slot is for MASTERFLEX®I/P®pumps (see
Figure 1).
3
FIGURE 1 — DRIVE ADAPTERS
To install the drive adapter on the drive, first install the rubber coupling
sleeve from the loose parts bag on the coupling end mounted on the
mechanical speed control by slipping it over the end of the coupling
through the pump mounting plate opening.Then select the appropriate
adapter for the pump you wish to drive and slip it into the rubber sleeve
and seat it firmly (see Figure 2). The pump mounting plate which is
mounted to the base has been centered at the factory for optimum
performance with both MASTERFLEX®L/S®and MASTERFLEX®I/P®
pumps, DO NOT CHANGE ITS LOCATION. The pump mounting plate
is threaded to accept all standard and optional mounting hardware for
MASTERFLEX®L/S®and MASTERFLEX®I/P®pumps. Orient the tang
of the pump you wish to drive with the drive adapter and install the
pump tang in the adapter. Fasten the pump to the mounting plate using
the pump mounting hardware.
Untitled-1 2/17/04, 7:27 AM7

4
OPERATING INSTRUCTIONS
The motor runs at a constant speed of 1725 rpm. The pump speed
setting is changed by using the lever on the mechanical speed control.
To increase the pump speed, move the lever away from the mechani-
cal gear box, to decrease pump speed, move the lever toward the gear
box.The pump speed can be varied from approximately 10 to 400 rpm.
The knob on the lever locks the setting and prevents accidental changes
in the pump speed (rotate the knob CW (clockwise) to lock the setting
and CCW (counterclockwise) to unlock).
To minimize the starting load, it is recommended that the system be at
approximately zero speed (lever fully CW) prior to starting the motor.
Once the motor has started, move the lever to increase speed to the
desired setting and lock in place.
Operating the system continuously at speeds approaching zero will
cause excessive wear on the mechanical speed control. Operating at
the maximum speed will result in minimum tubing life. If maximum sys-
tem life at a continuous speed is desired, the size of the pump head
should be chosen so that the desired flow is achieved at a pump speed
of approximately 60 to 200 rpm. For intermittent operation, any pump
head can be used at any speed setting without harm.
FIGURE 2
Untitled-1 2/17/04, 7:27 AM8

PUMP MOUNTING
The pump mounting plate supplied with the system is threaded to ac-
cept all standard and optional mounting hardware for MASTERFLEX®
L/S®and MASTERFLEX®I/P®pumps. All of the MASTERFLEX pumps
mount in a vertical orientation (See Figure 3). Orient the tang of the
pump you wish to drive with the drive adapter and install the pump tang
in the adapter. Fasten the pump to the mounting plate using the pump
mounting hardware supplied.
FIGURE 3
5
Untitled-1 2/17/04, 7:27 AM9

Add On Head Capacity
A maximum of two MASTERFLEX®L/S®or one MASTERFLEX®I/P®
add-on pump heads is recommended (for a total of 3 MASTERFLEX®
L/S®heads or 2 MASTERFLEX®I/P®heads). Additional pump heads
beyond the number recommended will cause excessive load and wear
on the motor, speed reducer and pump.
MAINTENANCE
Cleaning
The exterior surfaces of the unit may be cleaned using water and a
strong detergent. Do not immerse unit nor use excessive fluid.
Service Parts
Item Part Number
I/P Drive Adapter B-3435
L/S Drive Adapter B-3545
Rubber Coupling Sleeve B-3434
Coupling End 3/8 in Bore (Speed Reducer) B-3546
Coupling End 5/8 in Bore (Motor) B-3433
Coupling End 3/4 in Bore (Motor European) B-3676
Lubrication
The mechanical speed control is permanently lubricated at the factory.
The oil level should be periodically checked, however, as a safety pre-
caution, the case should be at least 1/2 full of lubricant.
Use any good quality SAE 40 detergent oil. A quantity of 14 ounces is
required to refill the drive. A drain and fill-hole is provided in the hous-
ing if additional oil is needed.
The motor has permanently lubricated, sealed bearings. No mainte-
nance or lubrication is required.
6
Untitled-1 2/17/04, 7:27 AM10

SPECIFICATIONS
Hazardous (classified) Location: Class 1
Group: D
Zone: 1
Operating Temperature: 0° to 40°C
Storage Temperature: −40° to 65°C
Humidity (non-condensing): 10 to 90%
Chemical Resistance: Painted steel
Operating Voltage/Frequency: 115V AC nominal 57–63 Hz
(90–130V AC) @ 4.7 A AC
Power Rating: 1/4 hp (190W)
Output Speed Range: 10 to 430 rpm
Direction of Rotation: Clockwise
Speed Regulation: ±10%
Altitude: Less than 6600 Ft (2000m)
Dimensions (L ×W ×H): 560 ×350 ×230 mm
(22 1/16 in ×13 5/8 in ×9 in)
Weight: 23.7 kg (52.25 pounds)
Maximum Torque Load: 25 lb-in
7
Untitled-1 2/17/04, 7:27 AM11

WARRANTY
Use only MASTERFLEX precision tubing with MASTERFLEX
pumps to ensure optimum performance. Use of other tubing may
void applicable warranties.
The Manufacturer warrants this product to be free from significant de-
viations from published specifications. If repair or adjustment is neces-
sary within the warranty period, the problem will be corrected at no
charge if it is not due to misuse or abuse on your part, as determined
by the Manufacturer. Repair costs outside the warranty period, or those
resulting from product misuse or abuse, may be invoiced to you.
The warranty period for this product is noted on the Warranty
Card.
PRODUCT RETURN
To limit charges and delays, contact the seller or Manufacturer for au-
thorization and shipping instructions before returning the product, ei-
ther within or outside the warranty period. When returning the product,
please state the reason for the return. For your protection, pack the
product carefully and insure it against possible damage or loss. Any
damages resulting from improper packaging are your responsibility.
TECHNICAL ASSISTANCE
If you have any questions about the use of this product, contact the
Manufacturer or authorized seller.
8Printed in U.S.A.
020599
