Saluki S1131 User manual

S1131 Signal Generator
User Manual
SalukiTechnology Inc.

Tel: [phone] Email: [e-mail]
www.salukitec.com
2
The manual applies to the signal generator of the following models:
S1131 Signal Generator (100kHz-3GHz).
Standard Accessories of S1131 Signal Generator:
Item Name Qty
1 Main Machine 1 Set
2 Power Cord 1 pcs
3 CD 1 pcs

Tel: [phone] Email: [e-mail]
www.salukitec.com
3
Preface
Thanks for choosing S1131 Signal Generator produced by Saluki Technology Inc. Please read this manual carefully for your
convenience.
Manual No.
S1131-03-01
Version
Rev01 2017.03 Saluki Technology
ManualAuthorization
The information contained in this Manual is subject to change without notice. The power to interpret the contents of and terms
used in this Manual rests with Saluki.
Saluki Tech owns the copyright of this Manual which should not be modified or tampered by any organization or individual, or
reproduced or transmittedfor the purpose of making profit without its prior permission,otherwise Saluki will reservethe right to
investigate and affix legal liability of infringement.
Product Quality Assurance
The warranty period of the product is 18 months from the date of delivery.
Product Quality Certificate
Theproductmeets theindicator requirementsofthemanual atthetime ofdelivery.Calibrationandmeasurementarecompleted
by the measuring organizationwith qualifications specified by the state, and relevant data areprovided for reference.
Quality/Environment Management
Research,development,manufacturingandtestingoftheproductcomplywiththerequirementsofthequalityandenvironmental
management system.

Tel: [phone] Email: [e-mail]
www.salukitec.com
4
Precautions
"Warning" indicates danger. It reminds the user to pay attention to a certain operation process, operation method or similar
situations. Noncompliance with the rules or improper operation may result in personal injuries. You must fully understand the
warning and all the conditions init shall be met before the next step
"Attention" indicates important prompts and no danger. It reminds the user to pay attention to a certain operation process,
operation method or similar situations. Noncompliance with the rules or improper operation may result in damage to the
instrument or loss of important data. You must fully understand the caution and all the conditions in it shall be met before the
next step.
Contacts
Service Tel:
886.2.2175 2930
Website:
www.salukitec.com
Email:
[e-mail]
Address:
No. 367 Fuxing N Road,Taipei 105
，
Taiwan (R.O.C.)

Tel: [phone] Email: [e-mail]
www.salukitec.com
5
Content
1Overview....................................................................................................................................................................7
1.1 Brief Introduction...................................................................................................................................................7
1.2 Key Feature...........................................................................................................................................................7
2Safety Instructions......................................................................................................................................................8
2.1 Device safety.........................................................................................................................................................8
2.2 Precautions on personal safety.............................................................................................................................9
3Brief Instruction........................................................................................................................................................10
3.1 Unpacking............................................................................................................................................................10
3.1.1 Model Confirmation......................................................................................................................................10
3.1.2Appearance Inspection.................................................................................................................................10
3.1.3 Operating Environment................................................................................................................................10
3.1.4 Electrostatic Protection.................................................................................................................................11
3.1.5 First Power Up..............................................................................................................................................11
3.2 Routine Maintenance...........................................................................................................................................12
4Front and Rear Panels...............................................................................................................................................8
4.1 Front Panel............................................................................................................................................................8
4.1.1 Function Keys.................................................................................................................................................8
4.1.2 Input Keys......................................................................................................................................................8
4.1.3 Output function switch keys............................................................................................................................9
4.1.4 Front Panel Interfaces..................................................................................................................................10
4.2 Rear Panel...........................................................................................................................................................11
4.3 UI.........................................................................................................................................................................11
5Typical Operation.....................................................................................................................................................13
5.1 Prepare................................................................................................................................................................13
5.2 Continuous Wave Output.....................................................................................................................................13
5.3 Step Sweep Output.............................................................................................................................................14
5.4 List Sweep Output...............................................................................................................................................15
5.5 Analog Modulation Signal....................................................................................................................................16
5.6 Digital Demodulation Signal.................................................................................................................................17
5.7 LF Output.............................................................................................................................................................18
6Menu Description .....................................................................................................................................................19
6.1 Menu Structure....................................................................................................................................................19

Tel: [phone] Email: [e-mail]
www.salukitec.com
6
6.2 FREQ...................................................................................................................................................................20
6.3 AMPTD................................................................................................................................................................21
6.4 Sweep..................................................................................................................................................................22
6.6 Fctn......................................................................................................................................................................24
6.7 Aux......................................................................................................................................................................25

Tel: [phone] Email: [e-mail]
www.salukitec.com
7
1Overview
1.1 Brief Introduction
S1131 is an economic signal generator for 3GHz span. It has good specification and multiple functions within a good looking
small box. S1131 provide analog modulation and digital modulation as standard functions and is a good solution for RF R&D,
test, maintenance and education.
1.2 Key Feature
Frequency range
S1131: 100kHz – 3.0GHz
Multi sweep mode, Step sweep, list sweep, frequency sweep and power sweep
Standard low frequency output function, sine, square, triangleand saw tooth wave forms are supported
Standard analog modulation functions,AM, FM, PM and Pulsemodulation.
Standard digital modulation functions, 2ASK, 2,4,8FSK, 2,4,8PSK supported.
Standard IF input port
SCPI supported.

Tel: [phone] Email: [e-mail]
www.salukitec.com
8
2Safety Instructions
Please read safety instructioncarefully and Strictly follow！
Saluki spares no efforts to ensure that production process comply with latest safety standards so as to safeguard the safety of
our users. The design and tests of our products and accessory equipment comply with relevant safety standards. We have
established quality assurance system so that we can better supervise product quality and ensure that all products accord with
standards in the system. To maintain the sound state of equipment and ensure safe operation,please comply with the following
instruction. Please feel free to contact us with any questions.
It is also customer’s responsibility to use this product in correct manner. Suitable for industrial, laboratory and education, this
equipment, however, must be used in correct manner so as to prevent personal injuries and property damages. For problems
causedbymisuses,liabilitiesrestonusers.Byproperuse,itmeansthatusersshouldusethisproductaccordingtoprescriptions
in the product document and in the required conditions. As sufficient expertise is required, only professional technicians and
people that have been strictly trained and have mastered necessary skills are qualified to use this product. Please keep safety
manual and product document in a proper manner, and deliver them to the end user. To forestall personal injuries and property
loss, please abide by these safety instructions. Prior to using this product, please read carefully and comply with these
instructions accordingly.
2.1 Device safety
1) Use designated packing container in shipping and avoid falling or violent collisions in moving, which may causedamages
to the device.
2) Use AC-DC adapter/ power cord shipped with the device to supply power/charge to the product. Using other power
adapters/power cord may cause damages to internal hardware.
3) Ensure that power supply is wellconnected to the ground to prevent damages tothe device caused by poor connection or
false connection.
4) Injection of DC signal into input end is prohibited. Signal power needs to be lower than 0.5W. If not, damageto the device
may occur.
5) Both insertions of objects into the gap of the device housing and dumping of liquids over device housing or into device are
prohibited, which may cause short circuit, electric shock, fire or personal injuries.
6) Notches or gaps in the device, designed to help internal ventilation and whereby prevent overheat, must not be covered.
The device must not be put oncouch, wrapped with carpet, or placed in airtight housing unless ventilation is good
7) This device must not be placed on radiator, dish heater and other heating devices.Ambient temperature must not surpass
the maximal temperature prescribed in this manual
8) Attention: Once this device is on fire, it may release toxic gases or liquids.
9) Please do not disassemble the instrument without permission
10) If any unusual phenomenon like smoke, smell, sparkle etc, occurs during start up, operation, please immediately turn off
the instrument, cut off the power and contact Saluki.
11) Keep good ventilation and do not block the vent holes on the instrument. Check and clean the vent holes during routine
maintenance.
12) Operate and store the instrument in the environment as required. Explosive matters are strictly forbidden
13) Pay more attention to ESD protection. Please use conductivemat and wrist ring during operation

Tel: [phone] Email: [e-mail]
www.salukitec.com
9
2.2 Precautions on personal safety.
1) Whenmovingthedevice, use propertoolsand movethedevicesoftlyso astoavoidpersonalinjuriescausedby thefalling
of the device.
2) Device should be proper grounded so as to prevent personal injuries caused by poor or false grounding
3) Whencleaningthedevice, pleaseunplugthedeviceto avoid electricshock.Usedry ormoistsoftcloth tocleanthedevice.
Do not clean the internal of thedevice.
4) Before using this device, personnel need to be trained. When using the device, concentration is required. Operation by
unqualified people may cause personal injuries and property losses.
5) Useofthisdevicewhenpowerlineisbrokenisprohibited. Regularcheckonpowerlineisnecessary. Propermeasures
should be taken to keep power line in good state and prevent stumble and electric shock.
6) Field use of the device when there is lightning is prohibited, which may cause personal injuries and property loss.

Tel: [phone] Email: [e-mail]
www.salukitec.com
10
3Brief Instruction
3.1 Unpacking
3.1.1 Model Confirmation
After opening the packing box,you will see the following items:
S1131 Signal Generator x1
Three-wire Power Cord x 1
CD x 1
Please check the above items against the Purchase Contract and the Packing List. If any problem, please contact Saluki and
we will deal with the problem assoon as possible.
3.1.2 Appearance Inspection
Inspect carefully whether the instrument has any damage during transportation. If the instrument has obvious damage, it is
strictly forbidden to be poweredon. Please contact Saluki and we will repair or exchange it be as soon as possible.
3.1.3 Operating Environment
Refer to the part of environment adaptability in the technical specifications of appendix 1. In addition, pay special attention to
the following requirements:
Power supply: 110 – 220V ±15%，50Hz – 60Hz ±5%，20W
Power socket: a three-wire supply socket that must be grounded reliably.
Instrument power cord: packed three-wire power cord
Before connecting the Signal Generator with the power supply, please carefully verify if the
power supply voltage. Otherwise, it is much possible to damage the instrument or even
cause personal injuries with wrong power supply.
To prevent or reduce the possible damage to the internal hardware of the signal generator
due to the mutual interference caused by multi equipment through the power supply,
especially the peak pulse interference caused by high-power equipment, it is best to use a
220V/110V AC stabilized-voltage power supply to supply power for the signal generator.

Tel: [phone] Email: [e-mail]
www.salukitec.com
11
Bad grounding or failure of the power supply may cause damage to the instrument, even
personal injury. Before connecting the power supply of signal generator, make sure ground
wires ofthe instrumentand its power supply are in good contact.
Use a power socketwith protective grounding and do not substitute the protective ground
wire with an external cable.
3.1.4 Electrostatic Protection
ESD can damage or destroy electronic components and equipment. Antistatic measures are usually taken to prevent ESD
damage: conductive table–mat and wrist–strap combination as well as conductive floor–mat and heel–strap combination. Both
types, when used together, provide a significant level of ESD protection. Among the two, only the table–mat and wrist–strap
combination provides adequate ESD protection when used alone. To ensure user safety, the static–safe accessories must
provide at least 1 MΩ resistance to ground.
Please use the following antistatic measures correctly to reduce the damage of electrostatics:
Ensure all the instruments are grounded correctly to prevent the electrostatics being generated.
Before touch the joint and corewire or do any assembly operation, do wear antistatic wrists or take other antistatic measures.
The above antistatic measures shall not be taken where the voltage is larger than 500V.
3.1.5 First Power Up
1) Connect the provided power cord instrument end to the power socket on rear panel.
2) Ensure theAC power is compliant to requirement.
3) Check the power switch on rearpanel and ensure it is off (“O”)
4) Connect the other end toAC power
5) Turn on the switch on rear panel (“|”)
6) Press the power button on front panel.
7) Screen lighted and the instrument is on.
8) For an accurate measurement, please warm up the signal generator for at least 30min before measurement.

Tel: [phone] Email: [e-mail]
www.salukitec.com
12
3.2 Routine Maintenance
It is required to check and cleanthe instrument after a period ofuse. Please proceed as the following procedures:
1) Shut down.
2) Unplug the power cord.
3) Use a clean and soft cloth withdetergent to wipe the keys gently.
4) Wipe up the display with a clean and soft cloth.
5) Check other sides of the instrument and ensure no damage
6) Clean other sides of the instrument with a soft cloth. Please pay attention to the ports and interfaces, do not clean them
and avoid any scratches which may impact themeasurement in future.
7) Plug in the power cord after thedisplay is dried out.
There is a layer of Anti Static Coatings (ASC) applied on the surface of the display screen, so
never use the cleaner containing fluoride, acidic cleaner or alkali cleaner. Never spray cleaner
over the display panel, otherwise the cleaner may seep into and damage the instrument.

Tel: [phone] Email: [e-mail]
www.salukitec.com
8
4Front and Rear Panels
4.1 Front Panel
Figure 4-1 S1131 Front Panel
No. Description No. Description
1 USB Port 7 Soft Keys
2 LCD Screen 8 Output function switch keys
3 Function Keys 9 External IF input
4 Number Keys 10 LF Output
5 Knob and navigation keys 11 RF Output
6 Power Button
4.1.1 Function Keys
Keys Function
Preset Preset the instrument to factory default status
FREQ Frequency settings. Include CW frequency, frequency reference, frequency offset
AMPTD Amplitude Settings. IncludeALC settings, reference amplitude, amplitude deviations and cable loss compensation.
Sweep Sweep settings. S1131 supports frequency sweep, power sweep, frequency + Power sweep. List sweep and step
sweep are supported.
Fctn All analog and digital modulation settings. LF output seetings
AUX System settings, include IP address settings, SCPI settings and language.
4.1.2 Input Keys
S1131 has numeric keys, knob and navigation keys to do the input.

Tel: [phone] Email: [e-mail]
www.salukitec.com
9
4.1.2.1 Knob and navigation keys
Knob functions:
When entering numbers, step up (clockwise) or down (anticlockwise) the instrument parameters as specified;
To move the selection bar in thefocus area (such as list)
When pressed, it has the same function with Enter key.
Navigation key functions
To increase or decrease instrument parameters in steps;
To move the selection bar in thetable;
4.1.2.2 Numeric Keyboard
Number 1 – 9
To input number parameters.
Decimal point
To inset one "." at cursor position.
“-“ key
To change symbols (+,-) of numeric parameters.
4.1.3 Output function switch keys
Mod On/Off key: when modulation function is enabled in [Fctn] key and all settings are done, user still need to press this
MODkey.WhenMODkeyispressed,thekeyis lighted greenandtheoutputsignalismodulatedasperthe settings. Need
to enable the RF on/off key first.
LF On/Off key: to enable/disable the LF output, when LF output is enabled, the key is lighted green.

Tel: [phone] Email: [e-mail]
www.salukitec.com
10
RF On/Off:to enable/disable RF output through the RF Output port. When it is enabled, it is lighted green.
4.1.4 Front Panel Interfaces
4.1.4.1 USB
Use for external storage, U disk.
4.1.4.2 IF IN
IF In port is a 50ohm SMAport.
4.1.4.3 LF Out
LF Out port is a 50ohm SMAport. It is used to output low frequency signals in different waveform.
4.1.4.4 RF Out
RF Out port is a 50ohm N type port. It is the main output port of S1131.

Tel: [phone] Email: [e-mail]
www.salukitec.com
11
4.2 Rear Panel
Figure 4-2 S1131 Signal Generator Rear Panel
No. Description No. Description
1 AC power plug 5 Fan
2 Power switch 6 USB port
3 10M Reference Input 7 LAN port
4 External Trigger Input 8 RS232 port
4.3 UI

Tel: [phone] Email: [e-mail]
www.salukitec.com
12
Figure 4-3 S1131 Signal Generator UI
1 Main configuration display
2 Setting input bar
3 Detail setting display
4 Soft menu

Tel: [phone] Email: [e-mail]
www.salukitec.com
13
5Typical Operation
This chapter will show how to use S1131 Signal Generator, following functions are included:
Continuous wave output
Step sweep output
List sweep output
AM signal output
Digital modulation signal output
LF internal modulation source output
5.1 Prepare
Press the power button to turn on S1131 signal generator.
ThischaptermeanstoshowthebasicoperationsofS1131SignalGenerator. Spectrumanalyzerisusedtosimulatethereceiver.
In this menu, S3331B spectrum analyzer is used for signalanalysis. For operation of S3331B please refer to document S3331-
03-02 ( S3331 series spectrumanalyzer user manual).
Before any test, please ensure damage level of the spectrum analyzer to avoid any damaged.
5.2 Continuous Wave Output
This case will show how to set S1131 signal generator to generate a 100MHz, -10dBm continuous sine signal.
1) Connect S1131 to S3331 via a N type cable.
2) Preset the S1131, S3331
Press【PRESET】key . The instrument will return to default settings.
3) Frequency settings
Press 【FREQ】key..
Use number keys, knob or up/down arrow key to set the center frequency to 100MHz
4) Amplitude settings
Press【AMPTD】key .
Use number keys, knob or up/down arrow key to set amplitude to -10dBm.
5) Press 【RF】to enable the output. The 【RF】lights.
6) Set the S3331 accordingly. Please see following screenshot

Tel: [phone] Email: [e-mail]
www.salukitec.com
14
Fig 5-1: Continuous signal Test result
5.3 Step Sweep Output
S1131 supports step sweep function. Step sweep is supported by frequency, amplitude and frequency+amplitude. Following
example will show how to set S1131 to enable the step sweep in frequency + amplitude mode.
Connect S1131 to S3331 via a N type cable
1) Preset the S1131, S3331
Press【PRESET】key . The instrument will return to default settings.
2) Sweep settings
Press 【Sweep】key.
3) Select [SWPMode], select [Freq&Ampl] in submenu, means frequency+amplitude mode
4) Select [SWPType]. Select [Step] in submenu, means step sweep
5) Select [SWPRepe], select [Cont] in submenu, means continuous sweep
6) Select [CFG Step], set the [start frequency] to 500MHz, [stop frequency] to 1GHz, [start amplitude] to -30dBm, [stop
amplitude] to -10dBm, set the [sweep point] to 50 and [dwell] time to 100ms.
7) Press 【RF】to enable the output. The 【RF】lights. Now S1131 is freq+ampl step sweep mode.
8) Set the S3331 accordingly. Please see following screenshot

Tel: [phone] Email: [e-mail]
www.salukitec.com
15
5.4 List Sweep Output
S1131 supports listsweepfunction.User can edit the pointfreelyand createa sweeplist.This examplecreates a4 pointsweep
list.
1) Connect S1131 to S3331 via a N type cable
2) Preset the S1131, S3331
Press【PRESET】key . The instrument will return to default settings.
3) Sweep settings
Press 【Sweep】key.
4) Select [SWPMode], select [Freq+Ampl] in submenu.
5) Select [SWPType]. Select [List] in submenu, means list sweep
6) Select [SWPRepe], select [Cont] in submenu, means continuous sweep
7) Select [CFG List], click [Insert Row], add to 4 rows. Click [Goto Row], and enter 1, click [Confirm]. The selection box move
to the first row [freq]. Click [Edit Item], Set the [freq] to 500MHz. Then click [Goto Row] again and use the knob to move
the selection box to [Ampl], click [Edit Item] and set to -10dBm. Click [Goto Row], use the knob to move the selection box
to [Dwell] and set to 50ms.
Note: Knob can move the selection box when [Goto Row] isselected.
8) Rotate the knob and the selection table will go to row 2. User can also use [Goto Row] to move the conversation box to
