Installation/QuickStart Guide

External Power Pack (ATVA408)

In the Box Tools Required

SAFETY INSTRUCTIONS:

Read these instructions carefully before installing and using the External

Power Pack and keep this guide in a safe place for future reference.

• Verify compatibility with the associated thermal radiator valve (TRV)

actuator before installation.

• Make sure there is at least 1-inch (25.4mm) clearance between the

External Power Pack and the existing radiator, piping and radiator

housing.

• Follow all applicable codes and regulations in the municipality where

this product is installed.

Salus accepts no responsibility for damage caused by not following these

instructions

INSTALLATION INSTRUCTIONS:

1. Remove External Power Pack assembly

from the carton (exploded view).

2. Remove the TRV battery door and 2 AA

batteries from the TRV housing.

3. Slide the battery contact door out of the

External Power Pack housing.

4. Insert the battery contact door into TRV

housing, snap into place.

5. Slide the Power Pack housing over the

TRV until the clips snap into place.

6. Position the assembly with 1-inch

clearance from any obstructions.

REMOVE AND REPLACE BATTERY:

1. Unscrew the battery compartment cover

using a 2mm hex wrench and set aside.

2. Remove the battery from Power Pack

housing.

3. Insert new battery (type ER34615 only),

observing polarity.

4. Replace battery compartment cover and

tighten hex screw.

The replacement battery MUST be

type ER34615 which is available

from several online resellers.

Observe battery polarity.

Caution! Do not short

circuit battery terminals.

Dispose of battery

responsibly.

External Power Pack for

Mini TRV (battery included)

Installation/

Quick-start Guide

2mm

Hex Wrench

TRV

TRV battery

door

Battery

contact

door

batteries

Hex Wrench

Battery

compartment screw

Battery

contact door

Power Pack

locking clips

1” (25.4mm)

clearance

Battery

Negative (-)

terminal on

bottom

Battery

Cover

Battery

contact

door

Power

Pack

Housing

Battery

Battery compartment cover

Hold battery

compartment

cover closed to

relieve tension

on the screw

Hold battery

compartment

cover closed to

relieve tension

on the screw.

Do Not over-

tighten screw.

FCC STATEMENTS

WARNING:

Changesormodificationsto thisunitnot expressly approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference,

and (2) this device must accept any interference received, including interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

•

Reorient or relocate the receivingantenna.

•

Increase the separation between the equipment and receiver.

•

from that to which the receiver isconnected.

•

Consult the dealer or an experienced radio/TV technician for help.

FCC AND INDUSTRY CANADA

RF Radiation Exposure statement: This equipment complies

with FCC and Industry Canada RF radiation exposure limits set forth for an uncontrolled

environment.This equipment should be installed and operated with a minimum distance of 20 centimeters between the antenna and all persons.

INDUSTRY CANADA

ThisdevicecomplieswithIndustry Canadalicence-exemptRSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause

interference, and (2) this device mustaccept any interference, including interference that may cause undesired operation of thedevice.

LeprésentappareilestconformeauxCNRd'IndustrieCanada applicables aux appareils radio exempts de licence. L'exploitationestautoriséeauxdeux

conditionssuivantes :(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d'en compromettre le fonctionnement.

SALUS WARRANTY

SALUS North America, Inc. (“Salus”) warrants that for a period of five (5) years (“Warranty Period”) from the date of purchase by the consumer (“Customer”),

this device, excluding batteries (“Product”), shall be free of defects in materials and workmanship under normal use and service in accordance with all

supplied instructions. During the warranty period, Salus shall, at its option, repair or replace any defective Products, at no charge for the device. Any

replacement and/or repaired devices are warranted for the remainder of the original Warranty Period or ninety (90) days, whichever is longer.

This warranty does not cover removal or reinstallation costs. This warranty does not apply to any Product (i) which has been modified, repaired, or altered,

except by Salus or an authorized Salus representative,(ii) whichhasnot beenmaintainedin accordance withany handling or operating instructions supplied

by Salus, or (iii) which has been subjected to unusual physical or electrical stress, misuses, abuse, negligence or accidents.

This warranty is the only express warranty Salus makes for the Product. Anyimpliedwarranties,includingwarrantiesofmerchantabilityorfitness for a

particular purpose, are limited to the Warranty Period or the shortest period allowed bylaw.

SALUSSHALLNOTBELIABLEFORANYLOSSORDAMAGEOFANYKIND,

INCLUDING ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES

RESULTING, DIRECTLY OR

INDIRECTLY, FROM ANY BREACH OF ANY WARRANTY, EXPRESS OR IMPLIED, OR ANY OTHER FAILURE OF THIS

PRODUCT. Some states and provinces do not allow the exclusion or limitation of incidental or consequential damages, or limitation on the duration

of implied warranties of merchantability or fitness, so these exclusions or limitations may not apply to you.

No oral or written information or advice given by Salus or a Salus- authorized representative shall modify or extend this warranty. If any term is held

to be illegal or unenforceable, the legality or enforceability of the remaining terms shall not be affected or impaired.

Customer’s sole and exclusive remedy under this limited warranty is product repair or replacement as provided herein. If a Product under warranty is

defective, the Customer may:

•

contact the party (“Seller”) from which the Customer purchased the Product to obtain an equivalent replacement product after the Seller has determined

that the Product is defective and the Customer is eligible for a replacement,or

•

contact Salus Service at support@salusinc.com, to determine whether the device qualifies for a replacement. If a replacement is warranted and is shipped

prior to the return of the device under warranty, a credit card is required and a hold may be placed on the Customer’s credit card for the value of the

replacement until the returned device is verified as eligible for replacement, in which case, the Customer’s credit card will not becharged.

This warranty gives you specific legal rights, and you may also have other rights that vary from jurisdiction to jurisdiction. If you have any questions
