SAMCOM FPCN10A User manual
FPCN10A WITH APP Operation manual
A、Base Function
1、16 Group Memory Channel
2、Group Button Function
3、Scrambler
4、Voice Compression
5、Power Saving Function；
6、Keypad Tone；
7、Battery Capacity Indication；
8、Lock The Keyboard
9、Scan Function；
10、VOX OFF 1-9
11、Wide/Narrow Band Selection；
12、Squelch Level Selection 1-9
13、Monitor Function
14、APP function
B,LCD Display
No. Icon Description
1
Key lock
3 Voice Operated Transmission
4 Battery capacity indication
5 Group Group Number
6 Channel Channel Number
C、Menu
a．Using method
1.Press the [MENU] key，enter into the menu selecting mode
2. Press the [EXIT] key to exit setting.
FPCN10A WITH APP Operation manual
b. Selecting List
Item Display Description Setting content
1 GRP Group channel
setting
1-20
2 APP Mapping software
tool in Mobile
ON/OFF
3 VOX Voice Operation OFF 1-9
4 SQL Squelch Level
Selection
ON/OFF
5 BEP Keypad Tone ON/OFF
6 CMP Voice
Compression
ON/OFF
7 SCA Scrambler
Function
ON/OFF
c. Selecting Function
1、GRP (Group Channel) Setting
After pressing MENU into function menu and GRP will be shown on display, press OK key then
you can select 0-19 through by ▲or ▼, then press OK key again the new GRP channel is fix.
press the EXIT key to give up setting
2、VOX Setting
After pressing MENU into function menu and choice VOX, press OK key then you can
select 1-9 and off through by ▲or ▼, then press OK key again, press the EXIT key to give up
setting
3、SQL ( Squelch Level Selection ) Setting
After pressing MENU into function menu and choice SQL, press OK key then you can select
1-9 through by ▲or ▼, then press OK key again, press the EXIT key to give up setting
4、BEP ( Keypad Tone ) Setting
After pressing MENU into function menu and choice BEP, press OK key then you can select
on/off through by ▲or ▼, then press OK key again press the EXIT key to give up setting
5、CMP ( Voice Compression Function ) Setting
After pressing MENU into function menu and choice CMP, press OK key then you can select
on/off through by ▲or ▼, then press OK key again press the EXIT key to give up setting
6. SCA ( Scrambler Function ) Setting
After pressing MENU into function menu and choice SCA, press OK key then you can select
on/off through by ▲or ▼, then press OK key again press the EXIT key to give up setting
FPCN10A WITH APP Operation manual
7. APP (Mapping software tool in mobile) Setting
After pressing MENU into function menu and choice APP, press OK key then you can select
on/off through by ▲or ▼, then press OK key again press the EXIT key to give up setting
The Smartphone should download Samcom Talk about App, the app shall provide functionally
to control radio, include radio settings change channel
The App shall provide message functionality include send/receive text message
The App shall provide location functionality include display generic map (like google map) with
own/friends coordinates/trail and geofencing ( out of boundary alert)
D、Key
E、Get Acquaint
Press the MENU
key ，enter into the
menu selecting mode
Press the EXIT key to
exit setting.
Press ▲ or ▼
key choice the function.
Keep press 3 seconds
the key to lock
/open the key
Press the GROUP key
to speak to all channel ,
press the OK key to
confirm the function
FPCN10A WITH APP Operation manual
Antenna
PTT
Transmitting
Monitor
B
u
tt
o
n
Scan Button
Channel Selection
Knob
Power / Volume
Switch
Earphone Cap
LCD Display
Key
Microphone
Status Indicator
FPCN10A WITH APP Operation manual
Removal of the battery
Hold down the two side
keys and push the battery
down
FCCWarningStatement
Changesormodificationsnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser’sauthoritytooperatetheequipment.
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigital
device,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.This
equipmentgeneratesusesandcanradiateradiofrequencyenergyand,ifnotinstalled
andusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterferencewillnotoccurina
particularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor
televisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,the
userisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing
measures:
‐‐Reorientorrelocatethereceivingantenna.
‐‐Increasetheseparationbetweentheequipmentandreceiver.
‐‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe
receiverisconnected.
‐‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
This radio has been tested and complies with the FCC RF exposure limits for
“General population.” In addition, your SAMCON radio complies with the following
Standards and Guidelines with regard to RF energy and electromagnetic energy levels
and evaluation of such levels for exposure to humans:
Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields.
• American National Standards Institute (C95.1–1992), IEEE Standard for Safety Levels
with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to
300 GHz.
• American National Standards Institute (C95.3–1992), IEEE Recommended Practice for
the Measurement of Potential y Hazardous Electromagnetic Fields— RF and Microwave.
To ensure that your exposure to RF electromagnetic energy is
within the FCC allowable limits for general population use, always adhere
to the following CAUTION guidelines:
• DO NOT operate the radio without a proper antenna attached, as
this may damage the radio and may also cause you to exceed FCC
RF exposure limits. A proper antenna is the antenna supplied with
KDB 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r03, Evaluating Compliance with FCC
this radio by the manufacturer or an antenna specifically authorized by the manufacturer
for use with this radio.
• DO NOT transmit for more than 50% of total radio use time (“50% duty cycle”).
Transmitting more than 50% of the time can cause FCC RF exposure compliance
requirements to be exceeded. The radio is transmitting when the “TX indicator” lights red.
You can cause the radio to transmit by pressing the “PTT” switch.
• ALWAYS use SAMCOM authorized accessories (antennas, batteries, belt clips,
speaker/mics, etc). Use of unauthorized accessories can cause the FCC RF exposure
compliance requirements to be exceeded. Body-worn operations are restricted to
belt-clips, holsters or similar accessories that have no metallic component in the assembly
and that provide at least 1.5 cm separation between the device, including its antenna, and
the user's body. To provide the recipients of your transmission the best sound quality, hold
the antenna at least 5 cm (2 inches) from mouth, and slightly off to one side. The
information listed above provides the user with the information needed to make him or her
aware of RF exposure, and what to do to assure that this radio operates within the FCC
RF exposure limits of this radio.
Electromagnetic Interference/Compatibility
During transmissions, your SAMCOM radio generates RF energy that can possibly cause
interference with other devices or systems. To avoid such interference, turn off the radio in
areas where signs are posted to do so. DO NOT operate the transmitter in areas that are
sensitive to electromagnetic radiation such as hospitals, aircraft, and blasting sites.
This device complies with Part 90of the FCC rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and
(2) this device must except any interference received, including interference that may cause
undesired operation.
Changesormodificationsnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser’sauthoritytooperatetheequipment.
Important: Do not hold down CALL for more than 10 seconds. The FCC does not allow you to
send a continuous tone for more than 10 seconds at a time.
The highest SAR (1g) values for the 16 channel walkie talkie as reported to the FCC when
Body: 7.539W/kg
tested for use on the body are:
