SAMITECH Heat Wrap Smart User manual

Versión 2. 2002
Smart Version
INSTRUCTIONS MANUAL
Portable and exible heat treatment solution
for wood ¡shape it as you ned!
Heat Wrap

Heat Wrap
Thank you for purchashing the SAMITECH Heat Wrap
Smart, the physical solution against xylophages in all stages
for any kind of wood. A modular set of six heating panels,
up to 2,4sqm of surface, that you can adapt to your needs:
beams, oors, walls, ceilings, furniture, the shape does not
matter.
Heat Wrap is based in SAMITECH far infrared intelligent
heating technology. The system allows you to control the
treatment temperature and duration and monitor conditions
at all times.
After the treatment you get a full PDF report that can be
shared by email with your costumer.
Please, read the instructions carefully before using this
device.
The operator must always respect the basic security
measures as detailed below.
Use this device only as described in the manual; Any other
use not recommended by the manufacturer may cause re,
electric shock, or injuries.
CONTENT
1. PRODUCT TECHNOLOGY DESCRIPTION
1.1. Far infrared heating technology
1.2 Components and accessories
2. OPERATION MODE
2.1 Assembly
2.2 ¡Shape it as you need!
2.3 Connections
2.4 Set Up
2.5 Touch-screen tablet
2.6 User Interface
3. SAFETY INSTRUCTIONS
4.REFERENCES FOR THE TREATMENT
DURATIONS
5. WARRANTY CERTIFICATES
2
2
3
4
4
5
6
7
8
9
13
18
20

Heat Wrap
1. PRODUCT TECHNOLOGY DESCRIPTION
1.1 Far infrared heating technology
Samitech’s Heat Wrap is the effective, practical, exible and portable solution to pest problems in
wood.
Heat Wrap technology is based on far infrared waves, emitted from heat panels. These waves
penetrate deeply into the wood surface or the surface of the object treated, directly attacking the
protein cells of the xylophages or insects that reside inside the wood, killing them by dehydration.
2
Heat Wrap from Samitech guarantees the effectiveness
in the elimination of the plague without damaging or
altering the state of the objects treated.
The objects to be treated with Heat Wrap can be of
any shape or size. The heat panels are made with a
material that uses textile nanotechnology, so they
can adapt to any shape, adhere to other panels and
cover different surface sizes without losing exibility,
resistance or treatment capacity.

Heat Wrap
1.2 Components and accessories
1. Heating panels
2. Smart Control Unit
3. Power Cord
4. Tablet (with user interface)
5. Data cables
6. Power cables
7. Temperature probes
Heat Wrap Smart consists of a set of six exible panels that allow the operator the possibility of adapting
them to any wood surface. The set is completed with the Smart Control Unit, that provides heat to each
panel and receives information from them, and the treatment is managed and controlled by the touch-
screen tablet.
3
1
5
2
6
3
7
4

Heat Wrap
2.1 Assembly
1. Each Heating Panel has a Velcro tape all around it, on the
upper side is the female Velcro, on the lower side is the male
Velcro. The panels can be united with this mechanism, it is
suitable for at surfaces, and it is even possible to wrap the
object to be treated with a single panel, uniting its male and
female Velcro straps.
2. Each Heating Panel has a total of 14 eyelets all around;
with the use of a stapler, the panels can be adhered to other
wooden surfaces, whether they are at or in any other shape.
The staples used in this procedure are so small that do not
cause any damage to the treated surface.
2. OPERATION MODE
This epigraph contains all the details required to set up the SAMITECH Heat Wrap Smart and get it ready
to carry out the treatment.
Before plugging in any part of the system, you must make sure you perform a full check of the cables for
any cuts or damages. If you nd any, then do not proceed with the treatment and inform us immediately.
4

Heat Wrap
2.2 ¡SHAPE IT AS YOU NEED IT!
No matter the shape or size of the surface or the object you want to treat with Heat Wrap Smart. Using one
or all of the panels, you can adapt the set to the surface in question. Using the Velcro tapes or the straps,
the operator can wrap or cover any surface.
5
To cover a big surface, the operator can place the
heating panels on top of it uniting them using the
Velcro tapes.
Wrap a beam or a column with a heating panel,
using the Velcro tapes.
The dust-guard (wood or carpet) of any wall can be
covered thanks to the exibility of the panels.

Heat Wrap
2.3 Connections
1. Once the surface or the object
to be treated is completely
covered up by the heating panels,
place the Control Box Unit close
to it and plug it to a power supply.
Make sure the cables reach to
cover the distance between the
object and the Smart Control
Unit and the socket.
Connect the data and power
cables to the Smart Control
Unit, each pair of cables must be
plugged in its number row.
2. If it is the rst time you connect the cables, you may have to shake
them into the connector to adjust the small parts.
6

Heat Wrap
7
2.4 Set Up
Smart Control Unit: Connect the Smart control Unit to the energy socket and switch the device on. The
green LED light will turn ON.
When the treatment starts the red the LED lights will light up indicating the connections status of the
Heating Panels.
Warning Light: If any connection problem is detected, the ‘Warning’ light ashes will show the row number
with an issue.
NUMBER OF FLASHES
WARNING
LIGHT ROW NUMBER
1
1
2
2
3
3
4
4
5
5
6
6
7
A

Heat Wrap
8
1. Turn on the Touch-screen Tablet
and tap the SAMITECH icon.
2. Manage and control all the
conditions and treatment
settings. Save the report les and
treatments pictures.
2.5 Touch-screen tablet
If the product you have purchased does not include an Android device or if you want to use another device,
you can download the application from the Google Play service.
As for many other personal and industrial devices power saving is a must for extending battery life in our
electronic equipment.
Keeping the tablet screen on during the whole treatment duration will drain the tablet battery too fast.
The solution is so simple as keeping the screen off most of the time and turning it on only when it is really
needed. The treatment control will continue running in the background.
In order to avoid the high
battery consumption of the
tablet, it’s very important
to turn OFF the screen, and
turn it ON for treatment update
details.

Heat Wrap
2.6 User interface
The application is simple and intuitive, it allows the operator to take pictures of the objects that will be
treated to guarantee their status before and after the treatment.
9
Img. 1
- New Treatment: Initiate a new treatment.
- Reports: File containing reports generated by the application.
- History: History of the treatments carried out by this device.
- Camera: Access to the camera.
- Devices: List of devices paired with this tablet.
- Settings: Application settings.
Img. 2
Form to fulll with basic treatment, client and operator data; these data
will appear exactly as they are typed in the nal report.
Img.3
Security warnings previous to the start of the treatment, the client must
read this information and accept the conditions.
Img. 4
The Heat Wrap operator checks and accepts the elements to be treated.
Similarly, he makes observations on the conditions of the state of the objects
previous to the start of the treatment.
By signing the form, the operator ofcially acknowledges that security
conditions are in order for the start of the treatment. At any time of the
treatment, the operator can take pictures of the objects being treated, or
abort the treatment.
1
3
2
4

Heat Wrap
10
The program performs a revision of the state of the heating panels, the connections and the basic conditions
of the treatment. The panels initiate their heating process: the treatment does not start until all the
panels reach the sufcient temperature to start the treatment.
At this point, the treatment times indicated by the operator, the time that the treatment has been running
and the time left till the end of the treatment are shown. At the end of the treatment, the app will give
you an estimation of the energy consumed during the process.

Heat Wrap
11
Once the treatment is over, a report is generated that can be completed by the operator with pictures of the objects
before and after the treatment. The operator can also include comments and nal observations on the treatment,
with any details that he considers important.
The Heat Bubble app gives you the possibility to share the nal PDF report (email, Bluetooth, etc.). The app also
allows for the modication of certain parameters, like the units of temperature, the symbol and format of the coin,
the kWh cost, and the logotype and the company’s contact info. All this information is included in the generated PDF
le.

Heat Wrap
12
Img. 5
It shows the history of the past
treatments carried out by the device and
whether they were completed (SUCCESS)
or aborted (ABORTED).
Img. 6
It shows a complete history of all the
PDF reports generated and allows you to
share them again.
Note: The default language is English. If you want another language, change it on the Android settings.
5 6

Heat Wrap
13
3. SAFETY INSTRUCTIONS
Please read these instructions carefully before using this equipment.
PCO should at all times comply with all safety measures described below. PCO will be entirely responsible
for any inadequate use of this equipment.
Use this device only as described in this manual. Any other use could result in re, explosion, electric
hazard, damage the device, treated objects or persons.
Never leave equipment in operation without supervision.
Warnings about re hazard
Do not treat objects that are composed of combustible, ammable or explosive materials nor objects that
could become combustible, ammable or explosive by raising their temperature. Keep any combustible,
ammable or explosive material away from the equipment.
Do not treat objects if you ignore their composition or if you have doubts about how they will react when
exposed to an increase in temperature.
Do not put at risk the safety of objects, equipment or the place where you plan to do the treatment.
Make sure you have adequate re detection and extinguishing equipment before you start any treatment.
Warnings about electrical hazard
This equipment is not designed to be used in bathrooms, laundry areas or similar rooms where it can get
in contact with water or high humidity. Never place the equipment anywhere where it could get in contact
with water or any other liquid.

Heat Wrap
14
Do not place wet or humid objects on the equipment.
Do not use this equipment in the open air.
Do not use this equipment in any place where inammable products such as petrol, dissolvent, paint or
other inammable liquids are stored.
Do not insert nor allow any object into the ventilation opening of the control unit as it may cause an
electric shock, re or harm the unit.
Do not use this equipment with a damaged cable, plug it into a damaged socket, after it has malfunctioned,
has fallen or is damaged in any way. Take the unit to an authorised repair centre for revision, repair or
adjustment.
Do not place the cable under rugs, carpets or similar covers. Try to place cables away from areas where
someone is likely to stumble.
Do not squeeze nor bend the cable nor use it if harmed.
This device has an overheating protection system that will turn off the heating units in case of overheating
or abnormal conditions. If this happens, turn off the device, disconnect it and let it cool down for a few
minutes. After you have done this, you can reconnect it and start using it again.
Do not try to open or repair this equipment yourself. By doing so, it could cause you personal harm or
damage.
When you nish each treatment, turn off the unit and disconnect the cables. Wait for about 10-15 minutes
before you open the enclosure to remove treated objects. Never let heating panels touch your skin
immediately after treatments.

Heat Wrap
15
After your last treatment carefully clean with a dry cloth those parts of the equipment that have been in
direct contact with the oor. After doing so, fold the equipment carefully and put everything back into its
carrying bag.
Do not allow children or animals to get in contact with this equipment.
Children under 8 should be kept away from equipment and should be kept under eye. Do not operate
equipment if there are children under 8 around that can access the area where device is operating.
Be specially careful when operating device having around children of any age, disabled people of any kind
or people that cannot be held responsible for their misuse. This device is not a toy and its cleaning and
maintenance should not be done by children with no supervision.
CAUTION: Some parts of this equipment can get very hot and cause skin burns. Be specially careful if
children or other vulnerable persons are around.
WARNING: To prevent overheating do not cover device. This device should not be placed below a power
socket.
Treatment Recommendations
Do not treat objects inside containers, paper, cardbox, foam or plastic enclosures as these materials can
act as insulators preventing any insect inside from reaching lethal temperature.
Do not place objects in direct contact with heating panels because this could cause damage. Plastic objects
should be placed away from the heating panels to prevent damage or deformation.
Avoid overlapping when placing the heating panels because this could cause overheating and cause damages.
This equipment is not recommended to treat electronic appliances such as computers, TV sets or any other
devices with screens, cameras, etc.

Heat Wrap
16
These objects should not be treated:
Note: Some objects are particularly sensitive to heat and could be damaged if exposed to the temperatures
reached during treatments. To minimise risk of any damage, these objects should not be treated and
should be kept apart during the duration of any treatment.
This list of objects is not exhaustive. All objects to be treated should be thoroughly inspected to conrm
Animals, plants or seeds.
Food and beverages
Medicines
Electronic, medical or lab appliances
Cosmetics and toiletries
Pressurised containers (aerosols, sprays, carbonic cartridges, re extinguishers, etc.).
Waxy objects (candles, paintings, etc.).
Fire arms and ammunitions.
Musical instruments.
Valuable and irreplaceable objects (photos, jewels, etc.)
Documents, money
Magnetic, optical, solid and mechanical media and storage devices (hard drives, SSD, USB pendrives,
video tapes, cassettes, etc.).
Stationery items (notebooks, pens, stickers, etc.)
Flammable or combustible materials (solvents, oils, glues, paints, lacquers, varnishes, etc.).
Printer toner or inks
Photographic materials (lms, negatives, paper, developers, etc.).
Corrosive or hazardous chemicals (bleach, cleaning chemicals, etc.).
Plastic objects such as tables, chairs, shelves, lampshades, photo frames, trophies, blinds, etc.).
Any type of objects that can be damaged or deteriorated by heat.

Heat Wrap
17
Thoroughly inspect and conrm that all objects are safe and suitable to be treated.
Move away any object that may be in direct contact with the heating panels, especially plastic, textile
or heat sensitive objects.
Review the objects and identify any existing damage and duly inform the client. It is recommended to
take photographs as proof of preexisting damage before starting any treatment.
All packaging, boxes, containers and bags should be placed open to minimise their insulating effect.
Covers and any bed linen should be removed from mattresses, cushions and pillows.
The client has been informed of any preexisting anomaly or damage to the objects and that the
treatment cannot be stopped once initiated.
that they are suitable.
Any other sensitive object that can be identied by the operator or the client during the inspection must
be removed. In case of doubt with any object, do not treat it.
Objects removed should be visually inspected for evidence of infestation. If they are infested, and those
objects are not suitable for heat treatment, a convenient alternative method should be used to treat them
before returning them to their place.
List of necessary checks prior to treatment:

Heat Wrap
4. REFERENCES FOR THE TREATMENTS DURATION
Each heat treatment in wood is different: duration times will depend on the object treated, the wood
(thickness, density and humidity) ; the type of plague to ght and where it is ubicated, and the results
that are expected.
The eggs of the insects are found in the interior of the wood, when they become larvae they seek the outer
layers of the wood, placing themselves in the rst layers of the inner cortex. In order to exterminate the
larvae the duration is normally less than when ghting the eggs, for which the duration of the treatment
can be increased thus preventing future plagues.
The reduction or increase of the treatment time must be made in a coherent way in order to avoid possible
damages in the wood.
18
TREATMENT OF BEAMS OR COLUMNS
THICKNESS
THICKNESS
HIGH DENSITYHIGH DENSITY
Humidity: 8-15%
Humidity: 2-6%
DURATION (in minutes)
DURATION (in minutes)
330
350
280
300
220
240
180
200
60
60
100
120
TEMPERATURE
TEMPERATURE
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
40cm (5.7in)
40cm (5.7in)
30cm (11.8in)
30cm (11.8in)
25cm (9.8in)
25cm (9.8in)
20cm (7.8in)
20cm (7.8in)
5cm (1.9in)
5cm (1.9in)
10cm (3.9in)
10cm (3.9in)

Heat Wrap
19
THICKNESS
THICKNESS
40cm (5.7in)
40cm (5.7in)
30cm (11.8in)
30cm (11.8in)
25cm (9.8in)
25cm (9.8in)
20cm (7.8in)
20cm (7.8in)
5cm (1.9in)
5cm (1.9in)
10cm (3.9in)
10cm (3.9in)
LOW DENSITY
LOW DENSITY
Humidity: 8-15%Humidity: 2-6%
DURATION (in minutes)
DURATION (in minutes)
330
300
280
260
220
200
180
160
60
60
100
80
TEMPERATURE
TEMPERATURE
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
100ºC (212ºF)
DENSITY
High
Low
DURATION (in minutes)
180
120
TEMPERATURE
100ºC (212ºF)
100ºC (212ºF)
TREATMENT OF FLOORS, PAVEMENTS, PARQUETS OR PALLETS
The thickness of the wood oors normally oscillates between 8 and 22mm. High density oors are normally those of
noble or tropical wood (they are normally harder)
