Subject:
Sampo
LM
-
24S6P V1.0
Service Manual
Revision:
1.0
Project Code: N.A. Doc. No.:
Model Name: LM-24S6P Released Date: 2010-3-25 Pages: 8 of 34
This document contains confidential information that is proprietary to Eternal Asia Display Technology Co., No part of its contents may be used, copied, disclosed or conveyed to any party in any
manner whatsoever without prior written permission from Eternal Asia Display Technology Co. All contents are subject to change without prior notice.
3. LM-24S6P 結構爆炸圖與物料清單

Confidential
Subject:
Sampo
LM
-
24S6P V1.0
Service Manual
Revision:
1.0
Project Code: N.A. Doc. No.:
Model Name: LM-24S6P Released Date: 2010-3-25 Pages: 9 of 34
This document contains confidential information that is proprietary to Eternal Asia Display Technology Co., No part of its contents may be used, copied, disclosed or conveyed to any party in any
manner whatsoever without prior written permission from Eternal Asia Display Technology Co. All contents are subject to change without prior notice.

Confidential
Subject:
Sampo
LM
-
24S6P V1.0
Service Manual
Revision:
1.0
Project Code: N.A. Doc. No.:
Model Name: LM-24S6P Released Date: 2010-3-25 Pages: 25 of 34
This document contains confidential information that is proprietary to Eternal Asia Display Technology Co., No part of its contents may be used, copied, disclosed or conveyed to any party in any
manner whatsoever without prior written permission from Eternal Asia Display Technology Co. All contents are subject to change without prior notice.
8. 零件清單
當提出零件需求時, 每一樣零件都必須依照下表填入下列訊息
(1). 料號
(2). 品名
(3). 規格
8.1 SKD 零件清單
ID
料号 品名 规格型号 单机用量
单位 备注
1 PH12000100164
零件组模组 MATERIAL,SAMPO PLH240BAT BLACK,均和 PACKAGE FOR SAMPO,
1 PCS
2 ER08000001000
遥控器 40KEYS,BLACK,繁体中文,PLH-2418,XY-3030,RC-C2418-010,协
宜, 1 PCS
3 CM01000100125
说明书 TUNER,繁体中文,A5,SAMPO PLH240BAT BLACK,MT-P, 1 PCS
4 CP01700000282
纸箱 L232*W50*H166mm,SAMPO PLH240BAT BLACK,MT-P, 1 PCS 视讯盒
5 CP01700000283
纸箱 TUNER,L527*W480*H357mm,SAMPO PLH240BAT, 0 PCS
6 CP03100000125
标示贴 电视,L40*W12mm,黑底银字, 1 PCS

Confidential
Subject:
Sampo
LM
-
24S6P V1.0
Service Manual
Revision:
1.0
Project Code: N.A. Doc. No.:
Model Name: LM-24S6P Released Date: 2010-3-25 Pages: 26 of 34
This document contains confidential information that is proprietary to Eternal Asia Display Technology Co., No part of its contents may be used, copied, disclosed or conveyed to any party in any
manner whatsoever without prior written permission from Eternal Asia Display Technology Co. All contents are subject to change without prior notice.
7 PH12000100165
零件组模组 SAMPO PLH240BAT BLACK,VENDOR PACKAGE FOR SAMPO, 1 PCS
8 EN00202400311
显示屏 24" TFT,1920*1080,LVDS,M240HW01 V2,AUO, 1 pcs
9 EP00040100805
主板 MST6M16,NTSC,SAMPO PLH240BAT,均和, 1 PCS
10
PH12000100162
零件组模组 SAMPO PLH240BAT BLACK,ES PACKAGE FOR SAMPO, 1 PCS
11
PH12000100167
零件组模组 ASSEMBLY,SAMPO PLH240BAT BLACK,ES PACKAGE FOR SAMPO, 1 PCS
12
PH04000100260
后装模组 SAMPO PLH240BAT BLACK,M240HW01 V5,AUO,MST6M16,均和,SKD,
1 PCS
13
EP00040505400
IR 板 ALD PLK18518D BLACK,SP7050,LED RED/BLUE,2L,T1.6mm,V1.0,
1 PCS 红蓝灯
14
EP00040205200
KEY 板 TV,ALD PLH18518D BLACK,SP7050,7KEYS,双面板,T1.6mm,V1.0,
1 pcs
15
ES05000003004
喇叭 8Ω 10W,L71*W41*H25.6mm,YDT4070-16,本源, 2 PCS
16
EL02034050000
屏线 UL1571 #28,CORE 14.2*23.5*8.0mm,FI-X30HL 30P<->P2.0
2*17P,L=500mm, 1 PCS 屏线
17
EL02008030004
线材组 UL1007 #24,P2.0 8P<->P2.0 8P,L=300mm, 1 PCS 按键板线

Confidential
Subject:
Sampo
LM
-
24S6P V1.0
Service Manual
Revision:
1.0
Project Code: N.A. Doc. No.:
Model Name: LM-24S6P Released Date: 2010-3-25 Pages: 27 of 34
This document contains confidential information that is proprietary to Eternal Asia Display Technology Co., No part of its contents may be used, copied, disclosed or conveyed to any party in any
manner whatsoever without prior written permission from Eternal Asia Display Technology Co. All contents are subject to change without prior notice.
18
EL02009035004
线材组 UL1007 #24,UL1185 #26,P2.0 9P<->P2.0 5P,L=350mm, 1 PCS 遥控板线
19
EL02012040006
线材组 UL1185 #26,UL1007 #24,P2.0 2*6P<->P2.0 2*6P,L=400mm, 1 PCS 高频头连接线
20
EL10001040000
同轴线 RCA 1P<->RCA1P,L=400mm,BLACK, 1 PCS 高频头连接线
21
EL02003055002
线材组 UL1007 #24,P2.5 3P<->TIN 2P,L=550mm,BLACK/WHITE, 1 pcs 喇叭线
22
EL02002035001
线材组 UK1007 #22,P2.5 2P<->TIN 2P,L=350mm,BLACK/RED, 1 pcs 喇叭线
23
EL02001012000
线材组 UL1015 #18,φ4.2 1P<->187 端子 1P,L=120mm,黄滚绿, 1 pcs 电源地线
24
EL02003030003
线材组 UL1672 #18,CORE 25*15*15mm,P3.96 3P<->187 端子
2P,L=300mm,BROWN/BLUE, 1 PCS
25
EL02002012000
线材组 UL3239 #22,AM3500H P3.5 2P<->AM3500HM P2.5
2P,L=120mm,RED/WHITE, 4 pcs 灯管延长线
26
EP00011200105
转接板 TUNER,MST6M19,AMOI PLM2206T,745-6M19C0-00,均和, 1 pcs
27
EP00041101103
POWER 板 P+I,72W,AYL240412,奥源, 1 PCS
28
EL02016035002
线材组 UL1007 #24,UL1571 #22,P2.5 12P P2.0 4P<->P2.0
12P,L=350/250mm, 1 pcs

Confidential
Subject:
Sampo
LM
-
24S6P V1.0
Service Manual
Revision:
1.0
Project Code: N.A. Doc. No.:
Model Name: LM-24S6P Released Date: 2010-3-25 Pages: 28 of 34
This document contains confidential information that is proprietary to Eternal Asia Display Technology Co., No part of its contents may be used, copied, disclosed or conveyed to any party in any
manner whatsoever without prior written permission from Eternal Asia Display Technology Co. All contents are subject to change without prior notice.
29
EL02001013000
线材组 UL1015 #18,φ3.2 1P<->φ3.2 1P,L=130mm,黄滚绿, 1 pcs 接电源两端
30
OG00500000103
泡棉 导电泡棉,L60*W20*H20mm, 1 PCS 贴在屏和滑块固定板之间
31
OG00800000100
醋酸布 黑色醋酸布,W20*T0.22mm,透明胶带, 0.3 M
32
EJ00100300201
插座 AC 电源插座,L49.0*W22.2*H27.2mm,3P,15A 250V,带耳,佳易达,
1 pcs
33
PH11000100213
机构模组 SAMPO PLH240BAT BLACK,M240HW01 V5,AUO,MST6M16,均和,SKD,
1 PCS
34
PC00500010301
底座 椭圆形,ABS 黑色罩光,SWA PLH1918D,HYT4-220AA-01A,浩业, 1 pcs
35
PC02500010300
立柱 ABS 黑色罩光,SWA PLH1918D,HYT4-220AA-03A,惠鼎, 1 pcs
36
PC00300010307
前壳 ABS 黑色罩光,SAMPO PLH240BAT,HYT4-240BA-07A,浩业, 1 PCS
37
PC00100010309
后壳 ABS 普黑,SAMPO PLH240BAT,HYT4-240BA-08A,浩业, 1 PCS
38
PC00600010303
按键 TV 按键,ABS 普黑,7KEYS,SWA PLH1918D,HYT4-220AA-09A,浩业,
1 pcs
39
PC00800010302
导光件 ABS 透明色,SWA PLH1918D,HYT4-220BA-10A,浩业, 1 pcs

Confidential
Subject:
Sampo
LM
-
24S6P V1.0
Service Manual
Revision:
1.0
Project Code: N.A. Doc. No.:
Model Name: LM-24S6P Released Date: 2010-3-25 Pages: 29 of 34
This document contains confidential information that is proprietary to Eternal Asia Display Technology Co., No part of its contents may be used, copied, disclosed or conveyed to any party in any
manner whatsoever without prior written permission from Eternal Asia Display Technology Co. All contents are subject to change without prior notice.
40
PC01000010304
装饰条 ABS 红色,SAMPO PLH240BAT,HYT4-240BA-13B,浩业, 1 PCS 红色
41
PC00900010300
挡板 USB 挡板,ABS 黑色罩光,丝印端口,SWA
PLH1918D,HYT4-220AA-15A,浩业, 1 pcs
42
ME00602100130
金属平板 立柱五金,SGCC T1.5mm,SWA PLH1918D,HYT4-220AA-21A,浩业,
1 pcs
43
ME00400000133
转轴组件 左,SGCC T2.0mm,SWA PLH1918D,HYT4-220AA-26A,浩业, 1 pcs
44
ME00400000132
转轴组件 右,SGCC T2.0mm,SWA PLH1918D,HYT4-220AA-27A,浩业, 1 pcs
45
CP01400000119
标牌 SAMPO,L30*W13.6mm, 1 PCS
46
MS04013008100
螺丝 RH(+),A TYPE,BA3*8,镀镍, 36 pcs
底座固定板与底座支架（4PCS);后壳与按键
（2PCS);后壳与喇叭（8PCS）;后壳与边条（8PCS)；
遥控板与面壳（2PCS）；后壳与背板（9PCS）；电
源板与后壳（2PCS)
47
MS02014010100
螺丝 RH(+),A TYPE,BA4*10,镀镍, 8 pcs 后壳与左右转轴组件（8PCS)
48
MS02003006100
螺丝 BH(+),M/M,PWM3*6,镀镍, 7 pcs 滑块固定片 与背板 （4pcs）；转接小板与滑块固
定片 4；背板与电源板（2PCS）；
49
MS00004010500
螺丝 PH(+),M/M,PM4*10,镀黑锌, 3 pcs
50
MS02004006101
螺丝 BH(+),M/M,4*6,镀镍,止滑, 1 pcs 电源接地线

Confidential
Subject:
Sampo
LM
-
24S6P V1.0
Service Manual
Revision:
1.0
Project Code: N.A. Doc. No.:
Model Name: LM-24S6P Released Date: 2010-3-25 Pages: 30 of 34
This document contains confidential information that is proprietary to Eternal Asia Display Technology Co., No part of its contents may be used, copied, disclosed or conveyed to any party in any
manner whatsoever without prior written permission from Eternal Asia Display Technology Co. All contents are subject to change without prior notice.
51
MS01003008500
螺丝 FH(+),M/M,KM3*8,镀黑锌, 4 pcs AC 座 2；背板与后壳*2
52
ME00200200139
固定条 屏左固定条,SGCC T1.0mm,SAMPO PLH240BAT,HYT4-240AA-31A,浩
业, 1 PCS
53
ME00200200230
固定条 屏右固定条,SGCC T1.0mm,SAMPO PLH240BAT,HYT4-240AA-31A,浩
业, 1 PCS
54
ME00602000137
背板 SGCC T0.6mm,SAMPO PLH240BAT,HYT4-220AA-23M,浩业, 1 PCS
55
PC01500010301
橡胶垫 φ15.8*T3.0mm,单面背 3M 胶,BLACK,HY-220AA-60A,浩业, 7 pcs
56
ME00000202031
支架 TUNER 支架,SGCC T0.6mm,SAMPO PLH240BAT,HYT4-220AA-40A,
浩业, 1 PCS
57
OG01000000108
网布 喇叭网布,SAMPO PLH240BAT,HYT4-240BA-07B,浩业, 1 PCS
58
PC02300010024
EVA 垫 L15*W13*H8mm,BLACK,单面背胶, 6 PCS 贴于屏固定条与屏之间；左右各 3 个
59
MS00003006102
螺丝 PH(+),M/M,PM3*6 ,弹片+平垫,镀镍, 4 PCS
60
PC01500100012
麦拉片 主板 ,L230*W105*T0.4mm,PET,透明,6M16, 1 长怡
61
PH13000100149
附件模组 SAMPO PLH240BAT BLACK,LM-24S6,SKD, 1 PCS

Confidential
Subject:
Sampo
LM
-
24S6P V1.0
Service Manual
Revision:
1.0
Project Code: N.A. Doc. No.:
Model Name: LM-24S6P Released Date: 2010-3-25 Pages: 31 of 34
This document contains confidential information that is proprietary to Eternal Asia Display Technology Co., No part of its contents may be used, copied, disclosed or conveyed to any party in any
manner whatsoever without prior written permission from Eternal Asia Display Technology Co. All contents are subject to change without prior notice.
62
EO00621200014
电源线 TAIWAN,3P PLUG,WIRE 3G0.75mm,L=1200mm,BLACK,HNS20090422,
宏能盛， 1 pcs
63
CM01000100124
说明书 MONITOR,繁体中文,L197*W168mm,SAMPO PLH240BAT
BLACK,LM-24S6P,MST6M16, 1 PCS
64
CP00100000900
包装袋 PE 袋,自封袋,L330*W230*T0.26mm,EPE,一国语言,英
语,PE-LD06, 1 pcs
65
PH19000100168
包装模组 SAMPO PLH240BAT BLACK,LM-24S6,SKD, 1 PCS
66
CP03600000100
手提扣 L160*W35mm,PE,03C, 1 PCS
67
CP01500000262
珍珠棉保护物
左,L234*W120*H463mm,EPE,SAMPO PLH240BAT, 1 PCS
68
CP01500000263
珍珠棉保护物
右,L234*W120*H463mm,EPE,SAMPO PLH240BAT, 1 PCS
69
CP01700000284
纸箱 L615*W240*H475mm,SAMPO PLH240BAT BLACK,LM-24S6P, 1 PCS
70
CP00100000141
包装袋 珍珠棉袋,L580*W700*T0.5mm,一国语言+回收标示, 1 pcs
71
PH12000100168
零件组模组 MATERIAL,SAMPO PLH240BAT BLACK,ES PACKAGE FOR SAMPO, 1 PCS
72
MS04003005100
螺丝 RH(+),M/M,BM3*5,镀镍, 4 pcs 主板与背板*4,

Confidential
Subject:
Sampo
LM
-
24S6P V1.0
Service Manual
Revision:
1.0
Project Code: N.A. Doc. No.:
Model Name: LM-24S6P Released Date: 2010-3-25 Pages: 32 of 34
This document contains confidential information that is proprietary to Eternal Asia Display Technology Co., No part of its contents may be used, copied, disclosed or conveyed to any party in any
manner whatsoever without prior written permission from Eternal Asia Display Technology Co. All contents are subject to change without prior notice.
73
MS04013008100
螺丝 RH(+),A TYPE,BA3*8,镀镍, 5 pcs 端子板与主板 5
74
MS04013010500
螺丝 RH(+),A TYPE,BA3*10,镀黑锌, 7 pcs 前后壳 7
75
CP00600000482
后铭牌 L79.6*W39.6*T0.1mm,黑底银字,繁体中文,SAMPO PLH240BAT
BLACK,LM-24S6P, 1 PCS
76
CP03100000126
标示贴 国别,L80*W12mm, 2 PCS
77
MS00004010500
螺丝 PH(+),M/M,PM4*10,镀黑锌, 2 pcs
78
MS10003008500
螺丝 3*8mm,φ10mm,一般机械牙,手动螺丝,镀黑锌, 2 pcs
79
ME00600900130
挡板 TUNER,SGCC T0.6mm,SAMPO PLH240BAT,HYT4-220AA-40C,浩业,
1 PCS
80
MS00003006102
螺丝 PH(+),M/M,PM3*6 ,弹片+平垫,镀镍, 4 PCS
81
PC02300010027
EVA 垫 L13*W18*H11mm, 2 PCS
82
PC02300010028
EVA 垫 L30*W30*H43mm, 1 PCS
83
OG00500000104
泡棉 导电泡棉,L140*W37*H0.5mm, 1 pcs

Confidential
Subject:
Sampo
LM
-
24S6P V1.0
Service Manual
Revision:
1.0
Project Code: N.A. Doc. No.:
Model Name: LM-24S6P Released Date: 2010-3-25 Pages: 33 of 34
This document contains confidential information that is proprietary to Eternal Asia Display Technology Co., No part of its contents may be used, copied, disclosed or conveyed to any party in any
manner whatsoever without prior written permission from Eternal Asia Display Technology Co. All contents are subject to change without prior notice.
84
PH12000100166
零件组模组 ASSEMBLY TUNER,SAMPO PLH240BAT BLACK,均和 PACKAGE FOR
SAMPO, 1 PCS
85
EP00010800605
TUNER 板 NTSC,东森 PLM3710T,745-6M19T0-02,均和, 1 pcs
86
ME00602100131
金属平板 TUNER 滑块,SGCC T0.8mm,SAMPO PLH240BAT,HYT4-220AA-40B,
浩业, 1 PCS
87
MS02003006100
螺丝 BH(+),M/M,PWM3*6,镀镍, 4 pcs 金属固定板与 TUNER 板 4
88
CP00100000173
包装袋 PE 自封袋 ,L255*W175*T0.04mm,一国语言+回收标志, 1 PCS
8.2 AD 板零件清單
