Samson Mixer S62 User manual

• 6 balanced mic/line-input channels.
• Independent CD/tape input; signal is routed via
channel EQ.
• Power: 150 W into 4 ohms.
• Built-in 3-spring reverb.
• 2-band equalization on all channels.
• 5-band graphic master EQ.
• Master peak LED.
• 1 Aux send per channel.
• 1 Aux return with front-panel level control.
• 48 V phantom power selectable for mic input
connectors.
• Protection relay circuitry to prevent noise when
powering on.
• 2 speaker outputs.
• Extremely portable format with carry handle and
protective corners.
• Rackmountable with rack ears included.
• Rear-panel amp in and preamp output.
• Master reverb level control.
S62
AMPLIFIER
MIXER
The S62 Mixer Amplifier is a monophonic 6-input
mic/line mixer with a dedicated power amp producing
150 W into 4 ohms. Highly portable or easily installed
into a rack, the S62 is equipped with 2-band equalization
on each channel and a 5-band graphic EQ on the main
output. The S62 is an ideal all-in-one device for recording,
live concert and contracting applications. It also features
6 electronically balanced mic/line inputs (XLR-type and
1/4″connectors), a CD/tape input (phono connectors),
switchable 48 V phantom power, internal reverb, an Aux
send and return, along with amp in and preamp and
monitor out patch points.
FUSE
SAMSON
CAUTION
AVIS:
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
DO NOT EXPOSE THIS EQUIPMENT
TO RAIN OR MOISTURE
NOTICE:
ALL MIC INPUT XLR PHANTOM
POWERED.
AUX
SEND
AUX EFFECT
RETURN
PRE-OUTAMP IN
S62 MIXER AMPLIFIER 150 WATTS 4 Ω
CD/TAPE IN
L
R
(<75Ω+4dBu) (<75Ω+4dBu) (10KΩ-10dBu)
~AC INPUT
120V,60Hz
135W
SPEAKER
OUTPUT
MIN 4Ω
FUSE
5A/250V POWER
(10KΩ+4dBu)
S / N
RISK OF ELECTRIC SHOCK
DO NOT OPEN !
ON
OFF
(1oKΩ+4dBu)
•+10
0
-15 +15
•+10
0
-15 +15
•+10
0
-15 +15
•+10
0
-15 +15
AUX REVERB
LEVEL
HIGH
LOW
•+10
0
-15 +15
•+10
0
-15 +15
AUX REVERB HIGH
LOW
•+10
0
-15 +15
•+10
0
-15 +15
AUX REVERB
LEVEL
HIGH
LOW
•+10
0
-15 +15
•+10
0
-15 +15
AUX REVERB
LEVEL
HIGH
LOW
•+10
0
-15 +15
•+10
0
-15 +15
AUX REVERB
LEVEL
HIGH
LOW
•+10
0
•+10
0
•+10
0
CHANNEL 1 CHANNEL 2 CHANNEL 3 CHANNEL 4 CHANNEL 5 CHANNEL 6 SAMSON
RETURNS
S62 MIXER AMPLIFIER
MAIN LEVEL
AUX EFFECT
REVERB
AUX REVERB
LEVEL
HIGH
LOW
LINE
LINE
LINELINELINELINE
MIC MIC MIC MIC MIC MIC
+15db
-15db
0dB
30Hz 120Hz 480Hz 2Khz 8Khz
8Khz
2Khz
480Hz120Hz30Hz
+15db
-15db
0dB
TAPE IN
CH 6 PROTECT PEAK POWER
LEVEL
Contact:
Samson Technologies Corp., P.O. Box 9031, Syosset, NY 11791-9031 •Phone: [phone] •Fax: [phone] •www.samsontech.com

ARCHITECT’S & ENGINEER’S
SPECIFICATION
The mixer amplifier shall incorporate a 150 W
monophonic amplifier, a 5-band graphic equalizer and a
monophonic mixer with 6 microphone/line-input chan-
nels. Microphone inputs shall be on XLR-type connec-
tors and line inputs shall be on balanced 1/4″Tip-Ring-
Sleeve phone connectors. An independent line-level
CD/tape input (routed to channel 6) shall be on phono
connectors. Each channel shall have an aux/reverb send,
2-band equalization and a level control.
The mixer shall provide an effects output on a 1/4″
phone connector, as well as a preamp out and power
amp in for submix applications on 1/4″phone connec-
tors. An effects return shall be provided on a 1/4′′ phone
connector, and it shall have an independent level con-
trol. Phantom Power of +48 V shall be provided for
operation of condenser microphones. The amplifier shall
be passively cooled. Amplifier output shall be provided
on two 1/4″phone connectors. Indicators shall be pro-
vided for peak level (3 dB before clipping), power and
amplifier protection. The unit shall be of a rack-mount
type.The amplifier shall deliver maximum power equal
to or greater than 150 W into 4 ohms, signal-to-noise
equal to or greater than 95 dB, THD less than 0.1% and
frequency response of ±3 dB from 20 Hz to 50 kHz. The
mixer shall have residual noise of 70 dBu, signal-to-noise
equal to or greater than 70 dB and THD less than 0.03%.
Total power consumed at 1/8 audio power shall be 134
W (115 Vac). Dimensions shall be 19″(480 mm) wide,
9″(230 mm) deep and 3.5″(88 mm; 2 rack spaces)
high. Weight shall be 17.6 lb. (8 kg). The mixer amplifier
shall carry a three-year warranty.
The mixer amplifier shall be a SAMSON S62.
1
2
3
1
2
3
2
3
1
T
R
S
2
3
1
T
R
S
T
S
TN
T
S
TN
AUX SEND
REVERB
PEAK
PRE-OUT
MAIN
AMP IN
A
B
150 Wrms
Power Amp
AUX/REV MAIN
HIGH
AUX/REV
TAPE/CD L
TAPE/CD R
MIC PRE
MIC INPUT
LINE INPUT PAD (LINE)
LOW
AUX EFFECT RETURN
AUX/REV
-10db
HIGH
LEVEL
AUX.EFFECT
MIC PRE
MIC INPUT
LINE INPUT PAD (LINE)
AUX/REV
LOW
-10db
LEVEL
+/-15db
(INV)
TAPE IN CH6
AUX/REV MAIN +36
MAIN
+/-15db
+/-15db
(INV)
PEAK
DETECTOR
2 INPUT
CHANNELS 1-5
AUX
RETURN
CHANNEL 6
REVERB
5 BAND
GRAPHIC EQ
EQ2 BAND
EQ2 BAND
S62 SPECIFICATIONS
MIXER/PREAMP SECTION
Total harmonic distortion (with 30 kHz LPF):
Mic in to preamp out: < 0.05%
Line in to preamp out: < 0.03%
Aux return to preamp out: < 0.03%
Signal to noise ratio (with 30 kHz LPF, unity gain):
Mic input (-50 dBu): 67 dB
Line input (-10 dBu): 70 dB
Maximum voltage gain (1 kHz):
Mic in to preamp out: 54 dB
Line in to preamp out: 24 dB
Tape in to preamp out: 24 dB
Aux return to preamp out: 10 dB
Residual noise (with 30 kHz LPF, VR min):
Preamp out: 70 dBu
Tone controls:
High (10 kHz): ± 15 dB
Low (100 Hz): ± 15 dB
Graphic equalizer (30, 120, 480 Hz, 2, 8 kHz): ± 15 dB
Peak LED: 3 dB before clipping
Tape input sensitivity (-10 dB): 300 mV
Crosstalk (1 kHz, EQ flat):
Ch vs. Ch: 76 dB
Input vs. output: 78 dB
POWER AMP SECTION
Rated output power (1 kHz): 150 W into 4 Ω
Total harmonic distortion (with 30 kHz LPF): < 0.1%
Signal to noise ratio (with 30 kHz LPF): 95 dB
Frequency response (±3 dB): 20 Hz - 50 kHz
Maximum voltage gain (1 kHz): 36 dB
Residual noise (VR min): 70 dB typical
Idle current (across the 0.47Ωemitter resistor): < 20 mA
DC offset voltage: 0 ± 50 mV
GENERAL
Dimensions: 19″(w) x 9″(d) x 3.5″(h)
480 mm (w) x 230 mm (d) x 88 mm (h)
Weight: 17.6 lb. / 8 kg.
Power requirements: 115 Vac •50/60 Hz
Power consumption (1/8 power): 134 W (115 Vac)
Specifications subject to change without notice. © 1998 SAMSON
