Owner's Manual
1000-WATT PORTABLE PA SYSTEM
XP1
000
E PEDITION

Copyright 2014
v2
Samson Technologies Corp.
45 Gilpin Avenue
Hauppauge, New York 11788-8816
Phone: 1-800-3-SAMSON (1-800-372-6766)
Fax: [phone]
www.samsontech.com
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Samson Technologies is under license. Other
trademarks and trade names are those of their respective owners.”

3
XP1000 • Portable PA System
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
Important Safety Information
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK) AS THERE ARE NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning flash with arrowhead symbol within an equilateral triangle
is intended to alert the user to the presence of non-insulated “dangerous
voltage” within the product’s enclosure that may be of sufficient magni-
tude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance in-
structions in the literature accompanying the appliance.
AVIS
RISQUE DE CHOC ÉLECTRONIQUE -
NE PAS OUVRIR
If you want to dispose this product, do not mix it with general household waste. There is a
separate collection system for used electronic products in accordance with legislation that
requires proper treatment, recovery and recycling.
Private household in the 28 member states of the EU, in Switzerland and Norway may return their
used electronic products free of charge to designated collection facilities or to a retailer (if you
purchase a similar new one).
For Countries not mentioned above, please contact your local authorities for a correct method of
disposal.
By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery
and recycling and thus prevent potential negative effects on the environment and human health.

4
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manu-
facturer’s instructions.
8. Do not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of
the polarized or grounding type plug.
A polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or
the third prong are provided for your
safety. If the provided plug does not
fit into your outlet, consult an electri-
cian for replacement of the obsolete
outlet.
10. Protect the power cord from being
walked on or pinched particularly at
the plugs, convenience receptacles,
and at the point where they exit from
the apparatus.
11. Only use attachments/accessories
specified by the manufacturer.
12. Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the appa-
ratus. When a cart is used,
use caution when moving the
cart/apparatus combination
to avoid injury from tip-over.
13. Unplug the apparatus during lighten-
ing storms or when unused for long
periods of time.
14. Refer all servicing to qualified
personnel. Service is required when
the apparatus has been damaged in
any way, such as power supply cord
or plug is damaged, liquid has been
spilled or objects have fallen into the
apparatus has been exposed to rain or
moisture, does not operate normally,
or has been dropped.
15. This appliance shall not be exposed
to dripping or splashing water and
that no object filled with liquid such
as vases shall be placed on the appa-
ratus.
16. Caution-to prevent electrical shock,
match wide blade plug wide slot fully
insert.
17. Please keep a good ventilation envi-
ronment around the entire unit.
18. To prevent injury, this apparatus must
be securely attached to the stand
in accordance with the installation
instructions.
19. WARNING: The battery (battery or
batteries or battery pack) shall not
be exposed to excessive heat such as
sunshine, fire or the like.
20. CAUTION: Danger of explosion if bat-
tery is incorrectly replaced. Replace
only with the same or equivalent type.
Important Safety Information

5
XP1000 • Portable PA System
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
Important Safety Information
FCC Notice
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the follow-
ing two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
RF Warning Statement
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
This device complies with RSS-310 of Industry Canada. Operation is subject to the
condition that this device does not cause harmful interference.

6
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
XP1000 Mixer Layout . . . . . . . . . . . . . . . . . . . . . . . .9
Pairing with a Bluetooth® device . . . . . . . . . . . . . . . . . . 12
Setting Up the XP1000. . . . . . . . . . . . . . . . . . . . . . .13
Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Applying Effects . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Avoiding Feedback . . . . . . . . . . . . . . . . . . . . . . . . . 17
Stage XPD1 Wireless System (Optional) . . . . . . . . . . . . . . . 18
XP1000 Connections . . . . . . . . . . . . . . . . . . . . . . . .20
Wiring Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

7
XP1000 • Portable PA System
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
Thank you for purchasing the Expedition XP1000 PORTABLE PA SYSTEM from
Samson! The XP1000 delivers the optimum balance between huge, awesome sound
and portability. The system is light enough for one person to carry, and packs togeth-
er into a single unit, making it amazingly easy to transport even in the trunk of a
compact car.
The XP1000 system is comprised of two 10” 2-way speaker cabinets, a 10-channel,
1000 watt powered mixer, and two speakers cables. The powered mixer packs neatly
into the back of one of the speaker cabinets and there is a accessory compartment
behind the second cabinet to hold the speaker and power cables. The two speakers
feature our unique slide and lock design to join together, allowing the entire system
to pack up into a single unit about the size of a carry-on piece of luggage.
The 10-channel mixer can be used while it is stored in the back of the speaker
or removed from the speaker for desktop use. It features 4 inputs for connecting
microphones, plus three inputs for connecting stereo signals, like those from a key-
board or MP3 player. There’s also a built-in, 24-bit digital effects processor to add
studio quality effects to your voice or instruments. For music playback, the XP1000
features wireless Bluetooth®connectivity, to stream audio from your smart phone,
tablet, or computer. The mixer also provides a robust output, with 1000 watts of total
power from the highly-efficient, lightweight, Class D amplifier section.
The XP1000 employs a matched speaker system with dual 2-way enclosures that
have proprietary 10” woofers and 1” high frequency drivers loaded in a 90° x 60°
horn for wide vertical coverage. To project the sound to a larger audience, the
XP1000 speakers can be mounted on standard speaker stands, thanks to the integral
pole mount receptacles. The XP1000 is constructed using durable ABS, high impact
plastic, making it super road tough, and at the same time, lightweight.
The XP1000 is the perfect tool for your solo performance, garage band rehearsal,
cocktail hour act, boardroom presentation, or classroom lecture. In this manual,
you’ll find a detailed description of the features of the XP1000 PA system, as well as
step-by-step instructions for its setup and use, and full specifications.
We recommend you keep the following records for reference, as well as a copy of your
sales receipt.
Serial number: ____________________________________________
Date of purchase: __________________________________________
Dealer name: _____________________________________________
With proper care and maintenance, your XP1000 will operate trouble-free for many
years. Should your XP1000 ever require servicing, a Return Authorization (RA) num-
ber must be obtained before shipping your unit to Samson. Without this number,
the unit will not be accepted. Please call Samson at 1-800-3SAMSON (1-800-372-
6766) for an RA number prior to shipping your unit. Please retain the original pack-
ing materials and, if possible, return the unit in its original carton. If your XP1000
was purchased outside of the United States, contact your local distributor for warran-
ty details and service information.
Introduction

8
The Samson Expedition XP1000 is a compact portable PA system with dual 2-way
speakers, onboard mixer and 1000 watt power amplifier. Here are some of the main
features:
• Lightweight and designed to allow you to connect all the pieces together into a sin-
gle, easy to move case.
• The mixer is stored in one of the speaker cabinets; the other cabinet has an acces-
sory compartment for storing the speaker cables, microphones, etc.
• The speakers are tuned, 2-way vented enclosures with 10-inch woofers for deep
bass, complimented by a 1-inch high frequency driver, set in a custom horn with a
60 x 90 degree coverage pattern producing a clean, clear sound.
• Internal 2 x 500 watt lightweight power amplifier produces a powerful stereo sound.
• The XP1000’s mixer can be removed from the speaker for tabletop placement and
you can use the kick stand to set the mixer at an ergonomically correct angle. You
can also use the optional SMS510 adapter to mount the mixer to a microphone
stand.
• The 10-channel mixer features four Mic/Line inputs allowing you to connect micro-
phones or line level signals, plus three stereo inputs for connecting line signals
from keyboards, drum machines and MP3 players.
• Each channel features bass and treble controls allowing you to tailor the sound of
each input.
• To create a lush sound on the first four channels, you can select from the sixteen
on-board, 24-bit digital effects.
• Bluetooth® connectivity allows you to stream wireless audio from your smartphone,
tablet, or computer.
• For added flexibility, the XP1000’s mixer has a Monitor Out, allowing you to con-
nect external powered speakers or active subwoofer to expand the system.
Features

9
XP1000 • Portable PA System
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
XP1000 Mixer Layout
1
3
4
5
6
7
82 9 11 12
13
14
15
16
22
20 21 23
10
19
17
18
1. Channel Input Jacks (channels 1 - 4)
MIC – XLR connector – Use these XLR jacks to connect low impedance microphones
to the XP1000’s built-in mic preamps.
LINE - ¼” phone connector – Use these ¼” jacks to connect instrument or audio
sources with line-level signals to the XP1000. You can connect the outputs from
acoustic guitar active pickups, keyboards, drum machines, CD/MP3/TAPE players
and other units with line level outputs here.
2. USB WIRELESS Input* – Connect the optional Samson Stage XPD1 digital wireless
USB receiver to this input. The wireless receiver gets its power from the XP1000,
so no additional power supply is needed. The WIRELESS input is routed to the
channel 4 LEVEL control.
3. MIC/LINE switch (channels 1 - 4) -The MIC position changes the gain of both input
jacks to MIC level. The LINE position reduces the gain of both jacks by 26dB to
line level.
4. LIMIT/COMP switch - Set the LIMIT/COMP switch to the COMP position to apply
compression or set it to the LIMIT position to apply limiting.
Compressors are used to control the dynamic range of a signal, which offers
a variety of benefits including leveling a signal and increasing the loudness
of a sound system to name.
A Limiter is a specific form of a compressor configured to prevent peaks and for
general overload protection.
* The USB connector is for the Stage XPD1 receiver only. The connector is not designed
to charge smartphones, tablets, or similar devices.

10
XP1000 Mixer Layout
5. Equalizer control knobs
HIGH Frequency – The HIGH knob controls the amount of treble applied to each
channel. The channel’s high frequency response is flat when the knob is in the cen-
ter detent (12:00) position. Rotating the knob to the right will boost the channel’s
high frequency response above 10 kHz by 15 dB, and rotating it towards the left
will cut the high frequency response by 15 dB.
LOW Frequency – The LOW knob controls the amount of bass applied to each chan-
nel. The channel’s low frequency response is flat when the knob is in the center
detent (12:00) position. Rotating the knob to the right will boost the channel’s low
frequency response below 100 Hz by 15 dB, and rotating it towards the left will cut
the low frequency response by 15 dB.
6. EFFECTS switch - Use the EFFECTS switch to add an effect to a Mic or Line input on
any of the first four input channels. The EFFECTS indicator lights GREEN when the
channel EFFECTS switch is ON.
7. LEVEL knobs - This knob sets the overall level for the input channel.
NOTE: To reduce noise, set the LEVEL controls on any unused channels to the mini-
mum setting.
8. Stereo Channel Input Jacks (channels 5/6, 7/8, 9/10) - For stereo inputs, use the L
input to connect the left channel and the R input to connect the right channel.
Use these inputs to connect high impedance microphones, synthesizers, drum
machines, MP3, CD, tape players or any other line level device. The XP1000 fea-
tures ¼” phone, ¹ / 8 ” phone, and RCA connectors.
9. MONITOR OUT jacks - The signal present at the MONITOR OUT jacks is sent from the
MONITOR level control knob, which is fed from the input channels. The MASTER
control does not affect the MONITOR OUT signal. This output can be used to send
the mix to powered speaker cabinets to use a stage monitors, or as additional front
of house speakers to expand the coverage of the system.
10. REC OUT jacks - This output is used to send the main mix to an external recorder.
The signal present at this connector is the L/R bus signal before it has passed
through the MASTER level control. The nominal output level is -10 dBV and the
impedance is 600 Ohms.
11. SPEAKER OUT jacks - Two ¼” phone powered output jacks used to connect the left
and right speakers. Use the included speaker cables to connect the speakers.
CAUTION: The total impedance load for each side of the amplifier must not be less
than 4 Ohms. Do not connect additional speakers to the XP1000 mixer/amplifier.
12. AC Input – Connect the supplied heavy-gauge 3-pin “IEC” power cable here.
13. POWER switch - Use the POWER switch to turn power to the XP1000 on or off. The
switch illuminates red when the unit is in the ON position and receiving power.
14. SPEECH/MUSIC switch - The SPEECH/MUSIC switch is used to change the overall

11
XP1000 • Portable PA System
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
XP1000 Mixer Layout
frequency response, or tone contour, for the XP1000 sound system. If your appli-
cation is mainly for music, press the switch down to select the MUSIC response
curve. If your application is mainly for spoken word, leave the switch up to select
the SPEECH response curve.
15. Pairing Indicator - Displays the Bluetooth status of the XP1000 system.
16. Pairing Button - Press this button to enable discoverable mode in order to pair with a
Bluetooth audio device.
17. MONITOR level knob - The MONITOR level control is used to control the overall level
sent to the MONITOR OUT.
18. Effects Program (PROG) selector - This control knob is used to select one of 16,
24-bit DSP effects programs.
19. Effects SEND knob - The SEND knob is used to adjust the total amount of effects
added to any channel that has its EFFECTS switch (see #6) pressed down.
20. MASTER knob - The MASTER volume knob controls the overall output level. This
knob determines the final output signal level. Signals from all ten channels are
routed here just before being routed to the built-in power amplifiers and Left and
Right speaker output jacks (see #11).
21. METER LED indicators - This six-segment bar meter shows the XP1000’s output level.
For optimum signal-to-noise ratio, set the VOLUME control so that program material
is usually at or around +3 to +6 VU, with occasional, but not steady excursions to
the red “LIMITER” segment.
22. READY indicator - The indicator will illuminate when the power switch is turned on
and the unit is ready to pass audio.
23. PHANTOM switch - The XP1000 features an onboard phantom power supply to oper-
ate condenser microphones. When the switch is engaged, the LED will illuminate
indicating that phantom power is now available on the microphone pre-amps.
IMPORTANT NOTE: To avoid a loud pop, be sure to turn down the MASTER level
control before plugging and unplugging the mic cables when the phantom power is
active.

12
Bluetooth®is a wireless communication technology that allows for connectivity between a
wide range of devices. The XP1000 uses Bluetooth to stream high quality audio from your
Bluetooth enabled device without the need for connecting any cables. In order for your
device to work with the XP1000 it must first be paired.
1. Turn all channel LEVEL controls down counterclockwise to 0.
2. With the XP1000 and your Bluetooth device powered on; press the PAIR button on
the top panel of the XP1000 mixer to make the speaker discoverable. The Blue-
tooth indicator will slowly flash blue.
3. In the settings of your Bluetooth device, set it to “discover” available devices.
4. From the Bluetooth device list, select the "Samson XP1000" device.
5. If your device asks for a passkey, enter digits 0000 (four zeros) and press OK.
Some devices may also ask you to accept the connection.
6. As the XP1000 is connecting to your device, the Bluetooth indicator will quickly
flash blue.
7. The XP1000 speaker indicates that pairing is complete when the indicator turns
steady blue. You can now stream audio from your device to the XP1000 speakers.
8. With the volume control on your Bluetooth device turned up, play some music, and
slowly raise the XP1000 BLUETOOTH channel 9/10 LEVEL control until you have
reached the desired level.
Pairing with a Bluetooth® device

13
XP1000 • Portable PA System
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
Setting Up the XP1000
Unpack all the system components from the shipping carton and save all packing
materials in the event your unit ever needs to be returned for service.
Remove the mixer by turning the quarter turn screw counterclockwise towards the
RELEASE position.
LOCK
RELEASE
Carefully hold the mixer to remove it from the speaker.
Remove the accessory compartment cover
by turning the quarter turn screw counter-
clockwise towards the RELEASE position,
and remove the included speaker cables.
Replace the accessory panel by aligning
the bottom of the panel with the slots.
Make sure the quarter turn screw is in the
RELEASE position; then close the panel
and turn the quarter turn screw clockwise
to LOCK.

14
Position the speakers on the floor or on stands.
Setting Up the XP1000
Using one of the included speaker cables, connect the mixer’s LEFT SPEAKER OUT to
the left speaker’s input connector. Next, use the second included speaker cable to con-
nect the RIGHT SPEAKER OUT to the right speaker’s input connector.
For maximum sound coverage the XP1000 can
be used with a standard 13⁄8” speaker stand.
The speaker should be raised above the heads
of the listening audience. Take care when
placing the speaker on a stand, to ensure that
it is on a level, steady surface and will not tip
over. When using the speaker on the floor, or
when the speaker is below the listener, the
XP1000 features a monitor angle position to
project the sound up, towards the audience.

15
XP1000 • Portable PA System
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
Quick Start
1. Be sure that the XP1000’s POWER switch is set to the OFF position.
2. If the speakers are not connected, connect the speaker wires as described in the
previous section.
3. Turn each of the channel LEVEL and MASTER volume controls fully counterclock-
wise, to the “0” position.
4. Next, connect one side of the included power cable to the XP1000 mixer’s power
inlet and the other to a grounded AC power outlet.
5. Connect your microphones using standard XLR cables, instruments using ¼” phone
cables, and MP3 player using ¹ / 8 ” cable, into the appropriate jacks on the mixer.
SIGNAL
SIGNAL
SIGNAL
SIGNAL
SIGNAL SIGNAL
Electric Acoustic
Guitar KeyboardDynamic Microphone
6. Switch on all equipment connected to the XP1000, then switch the XP1000’s
POWER switch to the ON position.
7. Turn the MASTER level control up halfway, to the “5” position.
8. Start talking or playing into channel 1 while slowly adjusting the
LEVEL control until you have reached the desired level. Do the same
for each channel you are using.

16
XP1000 Quick Start
9. If you notice that the LIMITER indicator is lighting constantly, turn the MASTER
volume down so that the indicator only lights occasionally during loud hits.
10. To add depth to the mix or smooth out the vocals, you can apply effects such as
reverb to channels 1–4. To do this, press the EFFECTS button on the channel(s) to
which you would like to add the effect.
11. Slowly turn up the effects SEND knob until the desired sound is reached.
12. To alter the tonal characteristic of the signal, you can adjust the LOW
(bass) and HIGH (treble) controls. If you find the audio too muddy, you
may want to reduce the LOW control. If you find that the audio sounds
dull, you can increase the HIGH control. There is no right or wrong way
to EQ a sound. You should listen to how the mix sounds in the room and
fine-tune to your liking.

17
XP1000 • Portable PA System
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
Applying Effects
The XP1000 features built-in, high quality, 24-bit digital effects that you can add to
channels 1 through 4. You can use effects like delay or reverb to enhance vocals or
ambiance to the mix by following the steps below:
1. Connect a mic or instrument to the desired channel, and adjust the volume and
equalizer to your liking.
2. Use the Reverb Program selector to choose one of the ten built-in digital effects.
3. Press the EFFECTS switch down on the chan-
nel to which you want to add the digital effect.
4. Once you have selected the channel(s) for effects by using the channel
EFFECTS switch, raise the effects SEND main level control to apply the
amount of effect desired.
Feedback is the annoying howling and squealing that can heard when the microphone
picks up sound from the speaker. The sound is then re-amplified back through the
speaker again, creating a feedback loop. Follow these steps to minimize the likelihood
of feedback:
• Avoid pointing the microphone directly at the speakers. In general it is
recommended that the microphone be positioned behind the speaker enclosure.
This uses the directional characteristics of the speaker and microphone to your
advantage.
• Keep the microphone as far from the speakers as possible. This will help achieve
isolation between the speaker and the microphone, and allow you to increase the
output of the XP10000.
• Position the microphone as close to the sound source as possible. This will
enable the microphone to pick up more direct sound, and allow you to reduce the
microphone input gain control.
• Reduce the MASTER LEVEL of the XP1000 system.
Avoiding Feedback

18
Plug the RXD1 USB receiver into
the Channel 4 USB jack labeled
WIRELESS.
On the wireless handheld transmitter,
unscrew the bottom section of
the microphone by turning it
counterclockwise and then slide it off.
Place a fresh set of AA (LR6) batteries
in the transmitter battery holder,
taking care to observe the polarity
markings, then replace the cover.
Turn the channel 4 LEVEL knob
on the XP1000 completely
counterclockwise to 0, then turn the
POWER siwtch on the XP1000 to the
ON position.
Turn on the power to the transmitter
by pressing and holding Power switch;
the indicator LED will light amber.
Stage XPD1 Wireless System (Optional)

19
XP1000 • Portable PA System
ENGLISH
FRANÇAISDEUTSCHEESPAÑOLITALIANO
If the handheld transmitter and
receiver have not been previously
paired, press and hold the button on
the RXD1 receiver for >5 seconds,
until it begins to flash.
Press and hold the Power button on
the handheld transmitter >5 seconds.
This will put both components into
pairing modes. Once the receiver and
transmitter communicate and sync,
the LEDs on both units will light
steady and will be ready for operation.
Raise the MASTER LEVEL control and
speak or sing into the mic at a normal
performance level while raising the
Channel 4 LEVEL control until the
desired level is reached.
If you hear distortion check the
LIMITER LED. If it is lit red, turn
down the channel 4 LEVEL on
the XP1000 until it lights only
occasionally during loud sounds. If
you still hear distortion, unscrew the
microphone body and use the supplied
plastic screwdriver to turn the Gain
control in the HXD1 transmitter slowly
counterclockwise until the distortion
disappears.
Conversely, if you hear a weak, noisy
signal at the desired volume level
(and with the WIRELESS control of
the XP1000 turned fully clockwise),
use the supplied plastic screwdriver
to turn the Gain control in the HXD1
transmitter slowly clockwise until the
signal reaches an acceptable level.
Stage XPD1 Wireless System (Optional)

20
There are several ways to interface the XP1000 to support a variety of applications.
The XP1000 features balanced inputs and outputs, so connecting balanced and
unbalanced signals is possible.
XP1000 Connections
Bass Preamp
