PRODUCT SPECIFICATION SHEET
MONITORS
TYPE:
STUDIO
MONITORS
PRODUCT DESCRIPTION
RESOLV A6 ACTIVE STUDIO REFERENCE MONITORS
SERIES CATEGORY
RESOLV MONITORS
FEATURES
> Two-way, active studio reference monitor with ported
tuned enclosure
> 6.5-inch woven carbon fiber woofer
> 1.25-inch silk dome tweeter with neodymium magnets,
heatsink and ferro-fluid cooling
> Low diffraction waveguide
> Bi-amp power with 75 watts on LF driver and 25 watts
on HF driver
> Active crossover utilizing multi-pole design for linear
response from bottom to top
> Four-position high frequency lift control
> XLR and 1/4-inch balanced inputs and unbalanced
RCA inputs
> AV shielded for multimedia applications
> Solid medium density fiberboard construction
©2008 Samson v1.0 6/08
GENERAL DESCRIPTION
With a complete redesign of the Resolv reference monitors,
Samson has combined precise engineering and high-quality
components with an elegant new cabinet design, providing
extremely accurate monitoring for any recording studio,
post-production suite or multimedia application.
Starting with the cabinet, we used a piano black lacquer
finish on the front panel. Inset into this panel is a sleek,
time-aligned waveguide for the speaker components,
allowing minimum diffraction. We also rounded the inner
edge of the tuned low frequency port to reduce turbulence
at high listening levels.
Professional features are abundant on our new Resolv
series. Their new woven carbon fiber woofers provide
tight and controlled low frequency response, while their
silk dome tweeters deliver smooth, sweet highs. Cooler
operation means no harmonic distortion, so Resolv
includes an external heatsink, ferro-fluid cooling and a
ventilated ceramic motor structure. We’ve also included a
four-position high frequency lift control for customizing to
your mixing room. And of course, Resolv monitors are AV
shielded for operation near computers.
The Resolv A6 delivers 100 watts with 75 watts used on
the low frequency driver and 25 watts on the tweeter. Its
6.5-inch woven carbon fiber woofer reduces inner cabinet
reflections from passing through the cone material and
mixing with the waveform coming off the front of the
speaker. The absence of acoustic transfer results in a clean
low frequency sound without low frequency smear. The
Resolv A6 also employs a 1.25-inch silk dome ferro-fluid
tweeter, which gives the high frequencies a true, natural
sound without false harmonics that can be created by other
types of tweeters.

RESOLV A6
ARCHITECT’S & ENGINEER’S SPECIFICATIONS
The Resolv active studio monitors from Samson shall come
in 3 sizes. The A5, A6, and A8. The Resolv A5 shall be
bi-amped with 50 watts on the low frequency driver and
20 watts on the high frequency amplifier. The A6 and A8
shall be bi-amped with 75 watts on the low frequency driver
and 25 watts on the high frequency driver. All three models
shall have a front panel power LED indicators. All three
models shall use a 1.25 inch silk dome ferro-fluid cooled
tweeter with neodymium magnets. All 3 models shall use
a low diffraction waveguide. The Resolv series uses a multi
pole active crossover design. The A5, A6, and A8 shall use
custom designed woven carbon fiber 5-inch, 6-inch and
8-inch woofers respectively. The rear panels shall have
power on/off switches, RCA inputs, balanced ¼ inch inputs,
and balanced XLR inputs, volume control, 4 position high
frequency adjustment, and power AC input. All three models
shall be AV shielded for multimedia use. All three models
shall have a piano black lacquer finish.
PRODUCT SPECIFICATION SHEET
SERIES DESCRIPTION CATEGORY
RESOLV ACTIVE STUDIO REFERENCE MONITORS MONITORS
RESOLV A6 SPECIFICATIONS
Frequency Response......................... 40 Hz - 27 kHz ± 3 dB
Power Rating ................................... Low Frequency: 75 watts RMS
High Frequency: 25 watts RMS
Crossover Frequency ........................ 2.3 kHz, multi-pole filter
Inputs..... ........................................ Unbalanced: -10 dBv line level;
Connector: RCA
Balanced: +4 dBu line level;
Connector: 1/4-inch phone TRS,
Female XLR
Enclosure........................................ Construction: MDF
(Medium Density Fiberboard)
Finish: Black textured vinyl covering
Dimensions...................................... 9.25” (w) x 12.75” (h) x 9.85” (d)
236mm x 324mm x 251mm
Weight..... ....................................... 18 lbs • 8.2 kg
