Samsung BD-D5500 User manual

B u-rayTM Disc
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsung.com/register

Key features
Blu-ray Disc Features
Blu-ray Discs support the highest quality HD video
available in the industry - Large capacity means
no compromise on video quality.
The following Blu-ray Disc features are disc
dependant
and will vary.
Appearance and navigation of features will also
vary from disc to disc.
Not all discs will have the features described
below.
Video highlights
The BD-ROM format supports three highly advanced
video codecs, including AVC, VC-1 and MPEG-2.
HD video resolutions are also supported:
•1920 x1080
High Definition
•1280 x 720 High Definition
For High-Definition Playback
To view high-definition contents on a Blu-ray Disc,
you need an HDTV (High Definition Television).
Some Blu-ray Discs may require you to use the
player's HDMI OUT to view high-definition content.
The ability to view high-definition content on
Blu-ray Discs may be limited depending on the
resolution of your TV.
SO-LIVE
You can use a Blu-ray Disc that supports BD-
LIVE to download content provided by the disc
manufacturer
through anetwork connection.
2 English
Blu-ray Disc Player Features
3D
This player can play 3D contents through an HDMI
cable.
To implement the 3D effect, connect a 3D device
(3D-compliant AV receiver, 3D-compliant TV) to
the player using an HDMI cable, and play the 3D
content while wearing 3D vision glasses.
Smart Hub
You can download various for payor free-
of-charge applications through anetwork
connection.
These applications provide a range
of Internet services and content including news,
weather forecasts, stock market quotes, games,
movies, and music.
AIIShare
You can play videos, music, and photos saved on
your devices (such as your PC, mobile phones, or
NAS) through anetwork connection.
Playing multimedia files
You can use the USB connection to play various
kinds of multimedia files (MP3, JPEG, DivX, etc.)
downloaded from a USB storage device.

Safety Information
CLASS 1 LASER PRODUCT
LASER PRODUCT
LASER PRODUKT
LASER LAITE
LASER APPARAT
LASER CLASE 1
The explanation point within the triangle
is a warning sign alerting you of important
instructions accompanying the product.
CLASS 1
KLASSE 1
LUOKAN 1
KLASS 1
PRODUCTO
~ NOTE
• If the Region number of a Blu-ray Disc/DVD disc
does not correspond to the Region number of this
player, the player cannot play the disc.
This Compact Disc player is classified as a CLASS
1 LASER product. Use of controls, adjustments
or performance of procedures other than those
specified herein may result in hazardous radiation
exposure.
Complies with 21 CFR 1040.10 except for
deviations pursuant to Laser Notice No. 50, dated
June 24,2007.
DANGER:
• VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN. AVOID DIRECT EXPOSURE TO
BEAM. (FDA 21 CFR)
CAUTION:
• CLASS 3B VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN. AVOID EXPOSURE
TO THE BEAM (IEC 60825-1)
•
THIS PRODUCT UTILIZES A LASER. USE
OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE. DO NOT OPEN COVER AND DO
NOT REPAIR YOURSELF. REFER SERVICING
TO QUALIFIED PERSONNEL.
Warning
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lighting flash and Arrowhead within the
triangle is a warning sign alerting you of
dangerous voltage inside the product.
WARNING
• To reduce the risk of fire or electric shock, do
not expose this appliance to rain or moisture.
FCC NOTE (for U.S.A)
This equipment has been tested and found to
comply
with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and on.
The user is encouraged to try to correct the
interference by one or more of the following measures.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
•Connect this equipment into an outlet on a
circuit different
from that to which the receiver is
connected.
•Consult
the dealer or an experienced radiofTV
technician for help.
• This class B digital product meets all
requirements of the Canadian Interference -
Causing Equipment Regulations.
Note to CATV system installer
This reminder is provided to call CATV system
installer's attention to Article 820-40 of the
National Electrical Code (Section 54 of Canadian
Electrical Code, Part I) that provides guidelines
for proper grounding and, in particular, specifies
that
the cable ground shall be connected to the
grounding system ofthe building as close to the
point of cable entry as practical.
English 3

Safety Information
Precautions
Important Safety Instructions
Read these operating instructions carefully before
using the unit. Follow all the safety instructions
listed below.
Keep these operating instructions handy for future
reference.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install
in accordance with the manufacturer's
instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including AV Receivers) that
produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Use only with the cart,
stand, tripod, bracket,
or table specified by the
manufacturer, or sold with
the apparatus. When acart
is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
4 English
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
Viewing using 3D function
IMPORTANT HEALTH AND SAFE1Y
INFORMATION FOR 3D PICTURES.
Read and understand the following safety
information before using the 3D function.
• Some viewers may experience discomfort while
viewing 3D TV such as dizziness, nausea, and
headaches.
If you experience any such symptom, stop
viewing 3D TV, remove the 3D Active Glasses,
and rest.
• Watching 3D images for an extended period of
time may cause eye strain. If you feel eye strain,
stop viewing 3D TV, remove your 3D Active
Glasses, and rest.
• A responsible adult should frequently check on
children who are using the 3D function.
If there are any reports of tired eyes, headaches,
dizziness, or nausea, have the child stop viewing
3D TV and rest.
• Do not use the 3D Active Glasses for other
purposes (such as general eyeglasses,
sunglasses, protective goggles, etc.)
• Do not use the 3D function or 3D Active Glasses
while walking or moving around. Using the 3D
function or 3D Active Glasses while moving
around may cause you to bump into objects,
trip, and/or fall, and cause serious injury.

Disc Storage & Management
Disc Handling
Disc Shape
• Use discs with regular 0
shapes. If you use an irregular 0
disc (a disc with a special
shape), you can damage the player.
Holding discs
• Avoid touching the surface of
adisc where data has been
recorded.
Blu-ray Discs
• Do not leave a Blu-ray Disc in the player for long
periods of time. Remove the Blu-ray Disc from
the player and store it in its case.
• Be careful not to scratch or leave fingerprints on
the surface of the Blu-ray Disc.
DVD-VIDEO, Audio CD (CD-DA)
• Wipe off dirt or contamination on the disc with a
soft cloth.
Disc Storage
Be careful not to damage the disc because the
data on these discs is highly vulnerable to the
environment.
• Do not keep under direct sunlight.
• Keep in a cool ventilated area.
• Store vertically.
• Keep in a clean protection jacket.
•
If you move your player suddenly from a cold
place to a warm place, condensation may occur
on the operating parts and lens and cause
abnormal disc playback. If this occurs, unplug
the player, wait for two hours, and then connect
the plug to the power outlet. Then, insert the
disc, and try to play back again.
Handling Cautions
• Do not write on the printed side with aball-point
pen or pencil.
• Do not use record cleaning sprays or antistatic
sprays to clean discs. Also, do not use volatile
chemicals, such as benzene or thinner.
• Do not apply labels or stickers to discs. (Do not
use discs fixed with exposed tape adhesive or
leftover peeled-off stickers.)
• Do not use scratch-proof protectors or covers.
• Do not use discs printed with label printers
available on the market.
• Do not load warped or cracked discs.
• Before connecting other components to this
player, be sure to turn them off.
• Do not move the player while it is playing a disc.
The disc can be scratched or damaged and the
player's internal parts can be damaged.
• Do not put aflower vase filled with water or any
small metal objects on the player.
• Be careful not to put your hand into the disc
tray.
• Do not place anything other than the disc in the
disc tray.
• Interference from exterior sources such as
lightening and static electricity can affect
the normal operation of this player. If this
occurs, turn the player off and on again with
the POWER button, or disconnect and then
reconnect the AC power cord to the AC power
outlet. The player will operate normally.
• Be sure to remove the disc and turn off the
player after use.
•Disconnect the AC power cord from the AC
outlet when you don't intend to use the player
for long periods of time.
• To clean a disc, wipe it in astraight ~
line from the inside to the outside of '.
the disc.
• Do not expose the player to any '.
liquid.
• When the AC plug is connected to a wall outlet,
the player will still draw power (standby mode)
when it is turned off.
English 5

Safety Information
• Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such
as vases, shall be placed on the apparatus.
• The main plug is used as adisconnect device
and shall stay readily operable at any time.
Maintenance of Cabinet
Before you clean the Blu-ray's cabinet, be sure to
disconnect the AC power cord from the AC outlet.
• Do not use benzene, thinner, or other solvents
for cleaning.
• Wipe the cabinet with a soft cloth.
Restrictions on Playback
• This player may not respond to all operating
commands because some Blu-ray, DVD, and
CD discs allow specific or limited operation and
provide only certain features during playback.
Please note that this is not adefect in the
player.
• Samsung cannot guarantee that this player
will play every disc bearing the Blu-ray Disc,
DVD or CD logo because disc formats evolve,
and problems and errors may occur during the
creation of Blu-ray Disc, DVD, and CD software
and/or the manufacture of discs.
Please contact the SAMSUNG customer care
center if you have questions or encounter
difficulty in playing Blu-ray, DVD, or CD discs
in this player. Also, refer to rest of this user
manual for additional information on playback
restrictions.
6 English

Contents
:,K~~l" F~TUR~$'
..; . ". .:} ';, --~:~; -
.- .. "lie· . .",-0","
2
2
Blu-ray Disc Features
Blu-ray Disc Player Features
"1'
·z
~:
CJ)
.;:t.
3 Warning
4 Precautions
4Important Safety Instructions
4 Viewing using 3D function
5 Disc Storage &Management
5Disc Handling
11 Before using the User Manual
11 Disc Types and Contents your player can play
11 Disc types your player cannot play
12 Blu-ray Disc Compatibility
12 Disc Types
13 Region Code
13 Copyright
14 Supported File Formats
15 Logos of Discs the player can play
15 Accessories
16 Front Panel
17 Rear Panel
18 Remote Control
18 Tour of the Remote Control
19 Setting the Remote Control to Operate Your TV
20 Connecting to a TV
20 Case 1 : Connecting to a TV with an HDMI Cable
-Best Quality (Recommended)
21 Case 2 : Connecting to a TV with an HDMI-DVI
Cable - Best Quality (Also recommended)
22 Case 3 : Connecting to a TV with aComponent
Cable -Better Quality
23 Case 4 : Connecting to a TV with an AudioNideo
cable -Good Quality
English 7

Contents
CONNECTIONS
.SETUP
8 English
24 Connecting to an Audio System
24 Case 1 :Connecting to an Audio System
(HDMI supported AV receiver) - Best Quality
(Recommended)
25 Case 2 : Connecting to an Audio System
(A V receiver with Dolby Digital or DTS decoder)
- Better Quality
25 Case 3 : Connecting to an Audio System
(2 Channel Amplifier) - Good Quality
26 Connecting to the Network
26 Cable Network
27 Wireless Network
28 Initial Settings
29 Accessing the Settings Menu
30 Display
30 3D Settings
31 TV Aspect
31 Smart Hub Screen Size
31 BD Wise (Samsung Players only)
31 Resolution
33 HDMI Color Format
33 Movie Frame (24Fs)
34 HDMI Deep Color
34 Still Mode
34 Progressive Mode
34 Audio
34 Digital Output
36 PCM Downsampling
36 Dynamic Range Control
36 Downmixing Mode
37 Network
37 Network Settings
40 Network Status
40 SO-LIVE Internet Connection

:: .BASIC FUNCTIONS
41 System
41 Initial Settings
41 Anynet+(HDMI-CEC)
41 SD Data Management
41 Time Zone
41 DivX® Video On Demand
41 Reset
42 Language
42 Security
42 SO Parental Rating
42 DVD Parental Rating
42 Change Password
42
General
42 Front Display
42 Network Remote Control
43 Support
43 Software Upgrade
44 Contact Samsung
45 Playing a Video
45 Playback
45 Disc Structure
45
Using the Disc MenufTitle Menu/Popup Menu
45 Using the Disc Menu
46 Using the Title Menu
46 Playing the Title List
46 Using the Popup Menu
46 Using the Search and Skip Functions
46 Searching for a Desired Scene
46 Skipping Chapters
47
Slow Motion Play/Step Motion Play
47 Slow Motion Play
47 Step Motion Play
English 9

Contents
BASIC FUNCTIONS
NETWORKSERVICES
APPENDIX
10 English
47 Using the TOOLS button
47 Moving to a Desired Scene Directly
47 Repeating the Title or Chapter
48 Repeating aSection
48 Changing to Full Screen
48 Selecting the Picture Settings
48 Selecting the Audio Language
49 Selecting the Subtitle Language
49 Changing the Camera Angle
49 Setting BONUSVIEW
50 Listening to Music
50 Buttons on the Remote Control used for Music
Playback
50 Playing an Audio CD (CD-DA)/MP3
51 Repeat an Audio CD (CD-DA)/MP3
51 Playlist
52 Playing back Pictures
52 Playing a JPEG files
52 Using the TOOLS button
53 Playing back a USB Storage Device
54 Using Smart Hub
54 Starting Smart Hub the First Time
57 The Settings Menu - BLUE (D)
59 The Edit Mode Menu - YELLOW (C)
61 The Sort Menu - GREEN (B)
61 Samsung Apps
61 For Pay Apps
63 BD-L1VETM
63 Using the AIIShare Function
64 Troubleshooting
66 Repairs
67 Index
68 Specifications

Getting Started
Before using the User Manual
Disc Types and Contents your player can play
Definition
Indicates a function available in a CD-RW/-R, DVD-RW/-R, BD-REI-R disc or a USB
storage media containing JPEG contents.
Indicates a function available in a CD-RW/-R, DVD-RW/-R, BD-REI-R disc or a USB
storage media containing MP3 or WMA contents.
Indicates a function available on an audio CD-RW/-R (CD-DA format).
Indicates a function available in a CD-RW/-R, DVD-RW/-R, BD-REI-R disc or a USB
storage media containing DivX, MKV, MP4 contents.
Indicates a function available on a BD-ROM or BD-REI-R disc recorded in the BD-RE
format.
Indicates a function available on a DVD-VIDEO or recorded DVD+RW/
DVD-RW(V)/DVD-R!+R discs that have been recorded and finalized.
Icon
~
VIDEO
~
RW
~
R
mm
--
mJ
~
&l!!I
~
logo
Btu-rag
~~
Term
VIDEO
MUSIC
~ NOTE
• The player may not play certain CD-RW/-R and DVD-R because of the disc type or recording conditions.
• If a DVD-RW/-R disc has not been recorded properly in DVD video format, it will not be playable.
• Your player will not play content that has been recorded on a DVD-R at a bit-rate that exceeds 10 Mbps.
• Your player will not play content that has been recorded on a BD-R or USB device at a bit rate that exceeds 30 Mbps.
Disc types your player cannot play
•HD DVD
•DVD-ROM/PD/MV-
Disc, etc
•DVD-RAM
•Super Audio CD
(except CD layer)
•DVD-RW(VR mode)
•CVD/CD-ROM/CDV/
CD-G/CD-I/LD
(CD-Gs play audio only,
not graphics.)
•3.9 GB DVD-R Disc for
Authoring.
English 11

Getting Started
~ NOTE
• Some commercial discs and DVD discs purchased
outside your region may not play on this player.
• Playback may not work for some types of discs, or
when you use specific operations, such as angle
change and aspect ratio adjustment. Information
about the discs is written in detail on the disc box.
Please refer to this if necessary.
• Do not allow the disc to become dirty or scratched.
Fingerprints, dirt, dust, scratches or deposits of
cigarette smoke on the recording surface may make
it impossible to use the disc for playback.
• Discs with PAL programs recorded on them cannot
be played using this player.
• This player is compatible with the NTSC color system
only.
• When you playa BD-J title, loading may take longer
than a normal title or some functions may perform
slowly.
• This player may not respond to all operating
commands because some Blu-ray, DVD, and CD
discs allow specific or limited operation and provide
only certain features during playback.
Please note that this is not a defect in the player.
• Samsung cannot guarantee that this player will play
every disc bearing the Blu-ray Disc, DVD or CD logo
because disc formats evolve, and problems and
errors may occur during the creation of Blu-ray Disc,
DVD, and CD software and/or the manufacture of
discs.
Please contact the SAM SUNG customer care center
if you have questions or encounter difficulty when
playing Blu-ray, DVD, or CD discs in this player.
Also, refer to rest of this user manual for additional
information on playback restrictions.
Blu-ray Disc Compatibility
Blu-ray Disc is a new and evolving format.
Accordingly, disc compatibility issues are possible.
Not all discs are compatible and not every disc will
play back. For additional information, refer to the
Compliance and Compatibility Notice section of
this user manual.
12 English
Disc Types
BD-ROM
Blu-ray ROM discs can only be played back.
This player can play back pre-recorded
commercial BD-ROM discs.
BD-REI-R
Blu-ray RE/-R discs can be recorded on and
played back.
This player can play back a BD-RE/-R disc
recorded by other compatible Blu-ray disc
recorders.
DVD-VIDEO
• This player can play back pre-recorded
commercial DVD discs (DVD-VIDEO discs) with
movies.
• When switching from the first layer to the
second layer of a dual-layered DVD-VIDEO disc,
there may be momentary distortion in the image
and sound. This is not amalfunction of the
player.
DVD-RW/-R/+R
This player can play back a DVD-RW/-R/+R disc
recorded and finalized with a DVD video recorder.
The ability to play back may depend on recording
conditions.
DVD+RW
• This player can play back a DVD+RW disc
recorded with a DVD Video recorder. The
ability to play back may depend on recording
conditions.
Audio CD (CD-DA)
• This player can play back CD-DA format audio
CD-RW/-R discs.
• The player may not be able to play some
CD-RW/-R discs due to the condition of the
recording.

CD-RW/-R
• Use a700MB (80 minute) CD-RW/-R disc.
If possible, do not use an 800MB (90 minute) or
larger disc, as the disc may not play back.
• If the CD-RW/-R disc was not recorded as a
closed session, you may experience delays
when playing back the beginning of the disc or
all recorded files may not play.
• Some CD-RW/-R discs may not play on this
player, depending on the device which was
used to burn them. For contents recorded on
CD-RW/-R media from CDs for your personal
use, playability may vary depending on the
contents and discs.
AVCHD (Advanced Video Codec High
Definition)
• This player can playback AVCHD format discs.
These discs are normally recorded and used in
camcorders.
•
The AVCHD format is a high definition digital
video camera format.
• The MPEG-4 AVC/H.264 format compresses
images with greater efficiency than the
conventional image compressing format.
• Some AVCHD discs use the "x.v.Color" format.
This player can playback AVCHD discs that use
"x.v.Color" format.
•"x.v.Color" is atrademark of Sony Corporation.
•
"AVCHD" and the AVCHD logo are trademarks
of Matsushita Electronic Industrial Co., Ltd. and
Sony Corporation.
~ NOTE
• Some AVCHD format discs may not play, depending
on the recording condition.
AVCHD format discs need to be finalized.
• "x.v.Color" offers a wider color range than normal
DVD camcorder discs.
• Some DivX, MKVand MP4 format discs may not
play, depending on the video resolution and frame
rate condition.
Region Code
Both players and discs are coded by region.
These regional codes must match for adisc to
play. If the codes do not match, the disc will not
play.
The Region Number for this player is displayed on
the rear panel of the player.
Disc Type
'Region
Area
<iii,"
Code
North America, Central America,
@J
South America, Korea, Japan,
Taiwan, Hong Kong and South
East Asia.
Blu-ray
@l
Europe, Greenland, French
territories, Middle East, Africa,
Australia and New Zealand.
~
India, China, Russia, Central
~
and South Asia.
-----
•
The U.S., U.S. territories and
Canada
I)
Europe, Japan, the Middle East,
Egypt, South Africa, Greenland
I)
Taiwan, Korea, the Philippines,
Indonesia, Hong Kong
DVD-VIDEO
Mexico, South America,
I)
Central America, Australia,
New Zealand, Pacific Islands,
Caribbean
I)
Russia, Eastern Europe, India,
most of Africa, North Korea,
Mongolia
I)
China
Copyright
© 2011 Samsung Electronics CO.,Ud.
All rights reserved; No part or whole of this user's
manual may be reproduced or copied without the
prior written permission of Samsung Electronics
Co.,Ud.
English 13

Getting Started
Supported File Formats
Notes on the USB connection
• Your player supports USB storage media, MP3 players, digital cameras, and USB card readers.
• The player does not support folder or file names longer than 128 characters.
• Some USB/digital camera devices may not be compatible with the player.
• Your player supports the FAT16, FAT32 , and NTFS files systems.
• Connect USB devices directly to the player's USB port. Connecting through a USB cable may cause
compatibility problems.
• Inserting more than one memory device into amulti-card reader may cause the reader to operate
improperly.
• The player does not support the PTP protocol.
•
Do not disconnect a USB device during a "loading" process.
• The bigger the image resolution, the longer the image takes to display.
• This player cannot play MP3 files with DRM (Digital Rights Management) downloaded from commercial
sites.
• External HDD device is not supported.
•
Your player only supports the video that is under 30fps (frame rate).
Video File Support
File Extension
Container Video Cadec Audio Codec Resolution
DivX 3.11 14.x15.1 16.0
MP3
1920x1080
Xvi 0
AC3
1920x1080
*.avi
AVI
MP4v3
DTS
1920x1080
WMA
H.264 BP/MP/HP
PCM
1920x1080
VC-1 AP
1920x1080
DivX 5.1/6.0
MP3
1920x1080
*.mkv
MKV
XviD
AC3
1920x1080
DTS
H.264 BP/MP/HP 1920x1080
*.wmv WMV(wmv9)
VC-1 AP
WMA
1920x1080
VC-1 SM 1920x1080
*.mp4
MP4 MP4
(mp4v)
MC
1920x1080
H.264 BP/MP/HP 1920x1080
MPEG1
MP1,2
1920x1080
*.mpg
PS MPEG2
AC3 1920x1080
*.mpeg
H.264 BP/MP/HP
DTS
1920x1080
Music File Support
File Extension
Container AudioCodec
Support Range
*.mp3
MP3
MP3
-
Compliant with WMA version 10
*.wma WMA WMA
* Sampling rates (in kHz) - 8, 11, 16, 22, 32, 44.1, 48
* Bit rates - All bit-rates in the range 5kbps to 384kbps
14 English

Batteries for Remote Control
(AM Size)
(AC43-12002H)
Accessories
AudioNideo cable
(AC39~00073A)
Logos of Discs the player can play
0
(,,)
G)
~
B/u-rag
~dts-flD
DIVX_
!
lI/u-'8gD/§c
au
Master Audio
HD
:i"
TM
(Q
.. ,~ ,
en
Blu-ray'Oisc
3D Blu-ray Disc
DTS-HD Master Audio DivX
-
C)
~
~
BD~
II] DOLBY
it
I NTSC I
\.;LIVETM
TRUEI!E I
~
Java"
POWERED
BO-lIVE Dolby TrueHD
NTSC broadcast system in
Java
U.SA Canada, Korea, Japan
Check for the supplied accessories below.
,User Manual
(AK68-01995A)
Quick Guide
(AK68"01996A)
Remote Control
(AK59-00123A)
English 15

Getting Started
Front Panel
'IIM'IIN'
1
1
DISC TRAY
Opens to accept a disc.
2
POWER BUnON
Turns the player on and off.
3
DISPLAY
Displays the playing status, time, etc.
4
STOP BUnON
Stops disc playback.
S
PLAY/PAUSE BUnON Plays a disc or pauses playback.
6
ENTER BUnON Selects menu items or starts a Blu-ray disc. (It will not start a DVD disc.)
7
OPEN/CLOSE BUnON Opens and closes the disc tray.
8
REMOTE CONTROL SENSOR Detects signals from the remote control.
9
You can connect a USB memory flash stick here and use it as storage when
USB HOST
the player is connected to BD-L1VE. You can also use the USB Host for software
upgrades and MP3/JPEG/DivXlMKV/MP4 playback.
~ NOTE
• You can perform software upgrades using the USB Host jack with a USB memory flash stick only.
• When the player displays the Blu-ray disc menu, you cannot start the movie by pressing the Play button on the player
or the remote. To play the movie, you must select Play Movie or Start in the disc menu, and then press the ENTER
button.
16 English

Rear Panel
,,---_I-_, __
3
1J _
.. 11111111111 ~TI<~ (.~.,.J.a
-.=IUI!
A -
o
cw
1
2
WIRELESS LAN ADAPTER
LAN
Connect the optional Wireless LAN Adapter (WIS09ASGN) here to use a Wireless
network.
Use for network based services (See pages 54-63), SO-LIVE, and software
upgrades using a network connection.
3
HDMIOUT
-4
COMPONENT OUT
5
VIDEO OUT
6
AUDIO OUT
7
DIGITAL AUDIO OUT
Using an HOMI cable, connect this HOM I output terminal to the HOMI input terminal
on your 1V for the best quality picture or to your AV Receiver for the best quality
sound.
Connects to external devices that have Component video input.
Connects to the video input of external devices using a video cable.
Connects to the audio input of external devices using audio cables.
Connects to an AV Receiver.
English 17

Getting Started
Remote Control
Tour of the Remote Control
Press to search contents.
I--f----i Turn the N on and off.
(To operate your N, please refer to page
19)
,---",.--r--"""1 Use to access various audio functions on a
disc
(Blu-ray Disc/DVD).
Press to use Tools menu. 1-+~==:fH
Press to stop adisc. 1-+-+
Use to enter the disc menu . .----.- ......
+--1--; Use to display the playback information
during
playing aBlu-ray/DVD disc.
11-1--1 Use to select menu items and change
==~ menu value.
Return to the previous menu. t---t--+ +-+--1 Press to exit the menu.
'---==----, '"--~' '----'
N volume adjustment. 1--~'11
Turn the player on and off. I--t-'><:f
To open and close the disc tray. I--+-"""':::::'::;:=-:---.
(f";~G~~=nfn'1i)..-+--1 These buttons are used both for menus
Press to use Netflix. r---r, ... --' ...... ---~-~=' on the player and also several Blu-ray Disc
functions.
Press to use Smart Hub. 1---r1F=~
Mutes the speakers of your N. I-r-:-E~immrB L..----il---l Use to select aN channel.
Press to move to the home menu. I--rt===::=;-;:::--,r=,
Press to use the bonusview function. 1--+-....;;;;;;;;;;;;;;....;;;;;;;;;;;....,,;;;;;;;;;~-t----1 After setup, allows you to set the input
source
on your N.
Press to skip backwards or forwards. 1--+-fI;;TT:;;~(~if;:;)I--J---i Press to search adisc backwards or
forwards.
+- ......... -1 Press to pause adisc.
~-"':==~-f---1 Press to playa disc.
+--1--; Use to enter the popup menu/title menu.
Press to switch the Blu-ray Disc/DVD's r---r- ........ -~
subtitle language.
Press numeric buttons to operate options. 1--+--1
Installing batteries
..........
.. - -.
•••
••
••
••
• •
ri:
••
••
••
••
.... ".. .
..
"'--_:.... ·,~ ••••• I .
-. .-
-. .-
••••••••
~ NOTE
• If the remote does not operate properly:
• Check the polarity +/- of the batteries.
• Check if the batteries are drained.
• Check if the remote sensor is blocked by
obstacles .
•
Check if there is any fluorescent lighting nearby.
18 English

You can control certain functions of your 1V with
this remote control.
Setting the Remote Control to
Operate Your TV
~ NOTE
• The functions listed above will not necessarily work
on all televisions. If you encounter problems, use the
TV remote control.
Brand
Code
NOBLEX
TV POWER+66
NOKIA TV POWER+74
NORDMENDE
TV POWER+ 72, + 73,
+75
PANASONIC
TV POWER+53, +54,
+74,
+75
PHILIPS
TV POWER+06, +55,
+56,+57
PHONOLA
TV POWER+06, +56,
+57
PIONEER
TV POWER+58, +59,
+73,
+74
RADIOLA TV POWER+06, +56
RADIOMARELLI
TV POWER+57
RCA
TV POWER+45, +46
REX
TV POWER+74
SABA
TV POWER+57, +72,
+73, +74, +75
SALORA TV POWER+74
SANYO
TV POWER+41, +42,
+43,
+44, +48
SCHNEIDER TV POWER+06
SELECO TV POWER+74
SHARP
TV POWER+36, +37,
+38,+39,+48
SIEMENS TV POWER+71
SINGER TVPOWER+57
SINUDYNE TV POWER+57
SONY
TV POWER+35, +48
TELEAVA TV POWER+73
TELEFUNKEN
TV POWER+67, +73,
+75,
+76
THOMSON
TV POWER+72, +73,
+75
THOMSON ASIA
TV POWER+80, +81
TOSHIBA
TV POWER+47, +48,
+49, +50,+51, +52
WEGA TV POWER+57
YOKO TV POWER+06
ZENITH
TV POWER+63
Brand Code
TV POWER+Ol, +02,
SAMSUNG
+03, +04, +05,
+06,+07,+08, +09
AIWA
TV POWER+82
TV POWER+ 10, +11,
ANAM
+12, +13, +14,
+15,
+16,+17,+18
BANG & OLUFSEN
TV POWER+57
BLAUPUNKT
TV POWER+71
BRANDT TV POWER+73
BRIONVEGA TV POWER+57
CGE TV POWER+52
CONTINENTAL
TV POWER+75
EDISON
TV POWER+ 19, +20,
+23, +24, +25,
DAEWOO +26, +27, +28,
+29, +30, +31,
+32, +33, +34
EMERSON TV POWER+64
FERGUSON TV POWER+73
FINLUX
TV POWER+06, +49,
+57
FORMENTI TV POWER+57
FUJITSU TV POWER+84
GRADIENTE
TV POWER+70
GRUNDIG
TV POWER+49, +52,
+71
HITACHI
TV POWER+60, +72,
+73,+75
IMPERIAL TV POWER+52
JVC TV POWER+61, +79
LG
TV POWER+06, + 19,
+20, +21, +22, +78
LOEWE TV POWER+06, +69
LOEWE OPTA TV POWER+06, +57
MAGNAVOX TV POWER+40
METZ TV POWER+57
MITSUBISHI
TV POWER+06, +48,
+62,
+65
MIVAR
TV POWER+52, +77
NEC TVPOWER+83
NEWSAN
TVPOWER+68
TV Control Codes
Function
Used to toggle the sound on and off.
Used to adjust the volume of the television.
Used to select the desired channel.
Used to switch the television on and off.
Used to select an external source
connected to the TV.
Button
TV VOL (+/-)
TV MUTE
TV CH (A/V)
TV SOURCE
TV POWER
To determine whether your television is
compatible, follow the instructions below.
1. Switch your television on.
2. Point the remote control towards the
television.
3. Press and hold the TV POWER button, and
then enter the two-figure code
in the table
to the right that corresponds to the brand
of
your television by pressing the appropriate
number buttons.
If your television is compatible with the remote
control,
it will switch off.
The remote
is now programmed to operate
the 1V.
~ NOTE
•
If several codes are listed for your television brand,
try each one in turn until you find one that works.
• If you replace the remote control's batteries, you
must set the brand code again.
English 19

Connections
Connecting to aTV
Case 1 : Connecting to a TV with an HOMI Cable - Best Quality
(Recommended)
1. Using an HDMI cable, connect the HOMI OUT terminal on the rear of the player to the HOMI IN
terminal of your 1V.
2. Turn on the player and 1V.
3. Press the input selector on your 1V remote control until the HDMI signal from the player appears on
your 1V screen.
• If you have set the remote control to operate your 1V (See page 19), press the TV SOURCE
button on the remote control and select HDMI as the external source of the 1V.
-
HDMIIN
~ NOTE
• An HOMI cable outputs digital video/audio, so you don't need to connect an audio cable.
• If the player is connected to your TV in the HOM Inop, 1 080i, or 1 080p output mode, you must use a High speed
(category 2) HOMI cable.
• HOM I outputs only a pure digital signal to the TV.
If your TV does not support HOCP (High-bandwidth Digital Content Protection), random noise appears on the screen.
• Depending on your TV, certain HOMI output resolutions may not work. Please refer to the user manual of your TV.
• When you connect tQe player to the TV using the HOM I cable for the first time or to a new TV, the HOMI output
resolution will be automatically set to the highest supported by the TV.
• You must have an HOMI connection to enjoy videos with 3D technology.
• A long HOM I cable may cause a screen noise. If this occurs, set Deep Color to Off in the menu.
20 English
