Samsung SC-D363 Owner's manual

ENGLISH
Digital Video Camcorder
Owner’s Instruction Book
Before operating the unit, please read this Instruction
Book thoroughly, and retain it for future reference.
A Auto ocus
CCD Charge Coupled Device
LCD Liquid Crystal Display
SC-D263/D362/D363/D364/D365/D366
US PATENT 4415844
Use only approved battery packs.
Otherwise, there is a danger of overheating, fire or explosion.
Samsung is not responsible for problems occurring due to using unapproved batteries.
RoHS compliant
Our product complies with The
Restriction Of the use of certain
Hazardous Substances in electrical and
electronic equipment”, and we do not
use the 6 hazardous materials- Cadmium(Cd), Lead
(Pb), Mercury (Hg), Hexavalent Chromium (Cr+6), Poly
Brominated Biphenyls (PBBs), Poly Brominated
Diphenyl Ethers(PBDEs)- in our products.

ENGLISH
Notices and Safety Instructions
Safety Instructions
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
W RNING - To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This
pparatus To Rain Or Moisture.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnin s.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openin s. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
re isters, stoves, or other apparatus (includin amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or
roundin type plu . A polarized plu has two blades with
one wider than the other. A roundin type plu has two
blades and a third roundin pron . The wide blade or the
third pron are provided for your safety. If the provided plu
does not fit into your outlet. Consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from bein walked on or pinched
particularly at plu s, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with
the apparatus. When a cart is used, use
caution when movin the cart/apparatus
combination to avoid injury from tip-over.
13. Unplu this apparatus durin li htnin storms or when
unused for lon periods of time.
14. Refer all servicin to qualified service personnel. Servicin is
required when the apparatus has been dama ed in any way,
such as power-supply cord or plu is dama ed, moistened
does not operate normally, or has been dropped.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISK OF ELECTRIC SHOCK
DO NOT OPEN
C UTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR B CK).
NO USER-SERVICE BLE P RTS
INSIDE, REFER SERVICING TO
QU LIFIED SERVICE PERSONNEL.
CAUTION
Shock Hazard Markin and Associated Graphical Symbols
Explanation of Safety Related Symbols
00970A SCD363 USASAFETY 1/8/04 1:54 AM Page 100

ENGLISH
Notices and Safety Instructions
15. The apparatus should not be exposed to drippin or
splashin . No objects filled with liquids, such as vases,
should be placed on the apparatus.
16. VENTILATION:
Slots and openings in the cabinet are provided for ventilation to
ensure reliable operation of the C MCORDER and to protect it
from overheating. These openings must not be blocked or
covered. Never place your C MCORDER on a bed, sofa, rug,
or other similar surface: on or near a radiator or heat register.
This C MCORDER should not be placed in a built-in installation
such as a bookcase or rack unless proper ventilation is provided
or the manufacturer’s instructions have been adhered to.
17. POWER SOURCES:
The C MCORDER should be operated only from the type of
power source indicated on the label.
If you are not sure of the type of power supply at your home,
consult your appliance dealer or local power company.
C MCORDER is intended to be operated from battery power,
or other sources, refer to the operating instructions.
18. GROUNDING OR POLARIZATION:
This C MCORDER may be equipped with either a polarized
2-wire C line plug (a plug having one blade wider than the other)
or a 3-wire grounding type plug, a plug having a third (grounding)
pin. If you are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug still fails to fit, contact your
electrician to replace your outlet. Do not defeat the safety purpose
of the polarized plug.
19. POWER-CORD PROTECTION:
Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to cords or plugs, convenient
receptacles, and the point where they exit from the unit.
20. OUTDOOR ANTENNA GROUNDING:
If an outside antenna or cable system is connected to the
C MCORDER, be sure the antenna or cable system is grounded
to provide some protection against voltage surges and built-up
static charges, Section 810 of the National Electrical Code,
NSI/NFP No. 70-1984, provides information with respect to
proper grounding of the mast and supporting structure, grounding
of the lead-in wire and supporting structure, grounding of the mast
and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding to conductors, location
of antenna-discharge unit, connection to grounding electrodes
and requirements for the grounding electrode.
See figure below.
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CL MPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC RT 250, P RT H)
NEC N TION L ELECTRIC L CODE
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CL MP
NTENN
LE D IN
WIRE
NTENN
DISCH RGE UNIT
(NEC SECTION 810-20)
00970A SCD363 USASAFETY 1/8/04 1:54 AM Page 101

ENGLISH
Notices and Safety Instructions
21. LIGHTNING:
For added protection of this C MCORDER during a lightning
storm or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna or
cable system.
This will prevent damage to the C MCORDER due to lightning
and power-line surges.
22. POWER LINES:
n outside antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits where
it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep
from touching such power lines or circuits as contact with them
might be fatal.
23. OVERLOADING:
Do not overload wall outlets and extension cords as this can result
in a risk of fire or electric shock.
24. OBJECTS AND LIQUIDS:
Never push objects of any kind into this C MCORDER through
openings as they may touch dangerous voltage points or short out
a part that could result in a fire or electric shock.
Never spill liquids of any kind onto the C MCORDER. Should
spillage occur, unplug unit and have it checked by a technician
before use.
25. SERVICING:
Do not attempt to service this C MCORDER yourself. Opening or
removing covers may expose you to dangerous voltage or other
hazards.
Refer all servicing to qualified service personnel.
26. DAMAGE REQUIRING SERVICE:
Unplug this C MCORDER from the wall outlet and refer servicing
to qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If any liquid has been spilled onto, or objects have fallen into
the C MCORDER.
c. If the C MCORDER has been exposed to rain or water.
d. If the C MCORDER does not operate normally by following the
operating instructions, adjust only those controls that are
covered by the operating instructions. Improper adjustment of
other controls may result in damage and will often require
extensive work by a qualified technician to restore the
C MCORDER to its normal operation.
e. If the C MCORDER has been dropped or the cabinet has been
damaged.
f. When the C MCORDER exhibits a distinct change in
performance, this indicates a need for service.
27. REPLACEMENT PARTS:
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer and having the same characteristics as the original
part.
Unauthorized substitutions may result in fire, electric shock or
other hazards.
28. SAFETY CHECK:
Upon completion of any service or repairs to this C MCORDER,
ask the service technician to perform safety checks to determine
that the C MCORDER is in safe operating order.
00970A SCD363 USASAFETY 1/8/04 1:54 AM Page 102

ENGLISH
Notices and Safety Instructions
29. To prevent damage which may result in fire or shock hazard, do not
expose this appliance to rain or moisture.
30. If this power supply is used at 240V ac, a suitable plug adapter
should be used.
USER INSTALLER CAUTION:
Your authority to operate this FCC certified equipment could be voided
if you make changes or modifications not expressly approved by this
party responsible for compliance to part 15 FCC rules.
NOTE:
Hg L MP(S) INSIDE THIS PRODUCT CONT IN
MERCURY ND MUST BE RECYCLED OR
DISPOSED OF CCORDING TO LOC L, ST TE OR
FEDER L L WS. For details see lamprecycle.org,
eiae.org, or call 1-800-Samsung (7267864)
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help
and for additional suggestions.
The user may find the following booklet prepared by the Federal
Communications Commission helpful : “How to Identify and
Resolve Radio-TV Interference Problems.”
This Booklet is available from the U.S. Government Printing
Office, Washington, D.C. 20402, Stock No. 004-000-00345-4.
FCC Warnin
The user is cautioned that changes or modifications not expressly
approved by the manufacturer could void the user’s authority to
operate the equipment.
FCC ID : A3L05DRAGON2
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions;
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
00970A SCD363 USASAFETY 1/8/04 1:54 AM Page 103

ENGLISH
Contents
22
Features ....................................................................................7
Accessories Supplied with Camcorder ....................................8
Front & Left View ......................................................................9
Left Side View..........................................................................10
Right & Top View ....................................................................11
Rear & Bottom View................................................................12
Remote Control (SC-D364/D366 only) ..................................13
Using the Hand Strap & Lens Cover ......................................14
Lithium Battery Installation ......................................................15
Using the Lithium Ion Battery Pack ........................................16
Connecting a Power Source ..................................................19
About the Operating Modes ....................................................19
Using the QUICK MENU ........................................................20
OSD (On Screen Display) in Camera/Player Modes ............21
OSD (On Screen Display) in M.Cam/M.Player Modes
(SC-D363/D364/D365/D366 only) ..........................................22
Turning the OSD (On Screen Display) On/Off ......................22
Setting the Clock (Clock Set) ................................................23
Setting the Wireless Remote Control Acceptance
(Remote) (SC-D364/D366 only) ............................................24
Setting the Beep Sound (Beep Sound) ................................25
Setting the Shutter Sound (Shutter Sound)
(SC-D363/D364/D365/D366 only) ..........................................26
Selecting the OSD Language (Language) ............................27
Viewing the Demonstration (Demonstration)........................28
Adjusting the LCD Screen (LCD Bright/ LCD Color) ..........29
Displaying the Date/Time (Date/Time) ..................................30
Setting the TV Display (TV Display) ......................................31
Using the Viewfinder................................................................32
Inserting / Ejecting a Cassette ................................................32
Various Recording Techniques................................................33
Making your First Recording ..................................................34
Recording with Ease for Beginners (EASY.Q Mode) ............35
Reviewing and Searching a Recording (REC SEARCH) ........36
Searching a quickly for a desired scene
(Setting the Zero Memory) (SC-D364/D366 only) ..............37
Self Record using the Remote Control
(Setting the Self Timer) (SC-D364/D366 only) ....................38
Zooming In and Out ................................................................39
Using the Tele Macro ..............................................................39
Using the Fade In and Out......................................................40
Using Back Light Compensation Mode (BLC) ......................41
Using the COLOR NITE (COLOR NITE)................................42
Using the LIGHT (SC-D362/D364/D365/D366 only)..............43
Getting to Know Your Camcorder ......................................7
Initial Setting : System Menu Setting ................................23
Notes and Safety Instructions..............................................5
Basic Recording ................................................................32
Initial Setting : Display Menu Setting ................................29
Preparation ........................................................................14

ENGLISH
Contents
33
Selecting the Record Mode & Audio Mode ............................44
Cutting Off Wind Noise (WindCut Plus) ................................45
Selecting the Real Stereo Function ........................................46
Setting the Shutter Speed & Exposure ..................................47
Auto Focus / Manual Focus ....................................................48
Programed Automatic Exposure Modes (Program AE) ........49
Setting the White Balance ......................................................51
Applying Visual Effects............................................................52
Setting the 16:9 Wide mode....................................................54
Setting the Digital Image Stabilizer (DIS) ..............................55
Zooming In and Out with Digital Zoom (Digital Zoom) ........56
Still Image Recording ..............................................................57
Searching for a still image ..................................................57
Playing Back a Tape You have recorded on the LCD Screen..58
Various Functions while in Player Mode ................................59
Zooming during Playback (PB ZOOM) ..................................61
Audio Dubbing (SC-D364/D366 only) ....................................62
Dubbed Audio Playback ..........................................................63
Tape Playback ........................................................................64
Audio Effect ............................................................................66
Setting the AV In/Out (SC-D365/D366 only) ..........................67
Using a Memory Card (Usable Memory Card) (not supplied) ....68
Memory Card Functions......................................................68
Inserting a Memory Card ....................................................68
Ejecting a Memory Card ....................................................68
Structure of Folders and Files on the Memory Card ..............69
Selecting the Memory Type (SC-D366 only) ..........................70
Selecting the Photo Quality ....................................................71
Setting the File Number ..........................................................72
Taking a Photo Image (JPEG) on the Memory Card ............73
Viewing Photo Images (JPEG) ..............................................74
To view a Single Image ......................................................74
To view a Slide Show ........................................................74
To view the Multi Display ..................................................74
Protection from accidental Erasure ........................................75
Deleting Photo Images and Moving Images ..........................76
Formatting a Memory Card ....................................................78
Recording Moving Images (MPEG) on a Memory Card ..........79
Playing Moving Images (MPEG) on a Memory Card
(M.Play Select) ......................................................................80
Recording Still Images from a Cassette ................................81
Copying Still Images from a Cassette to a Memory Card
(Photo Copy) ..........................................................................82
Copying Files from a Memory Card to the Built-in
Memory (Copy to) (SC-D366 only) ........................................83
Marking Images for Printing (Print Mark) ..............................84
Removing the rint Mark ....................................................84
Printing Your Pictures – Using the PictBridgeTM ......................85
Advanced Recording..........................................................44
Playback ............................................................................58
PictBridgeTM (SC-D363/D364/D365/D366 only) ..............85
Digital Still Camera Mode (SC-D363/D364/D365 /D366 only) ..68

ENGLISH
Contents
44
Connecting To a rinter ......................................................85
Selecting Images ................................................................86
Setting the Number of rints ..............................................86
Setting the Date/Time Imprint Option ..................................86
rinting Images ..................................................................86
Canceling the rinting ........................................................86
Transferring IEEE1394 (i.LINK)-DV Standard Data
Connections ............................................................................87
Connecting to a DV Device (DVD Recorder, Camcorder, etc.) ..87
Connecting to a C ............................................................87
System Requirements..........................................................87
Recording with a DV Connection Cable ..............................88
Using USB Interface (SC-D362/D363/D364/D365/D366 only) ....89
Transferring a Digital Image through a USB Connection ........89
USB Connection Speed depending on the System ................89
System Requirements..........................................................89
Selecting the USB Device (USB Connect)
(SC-D363/D364/D365/D366 only) ..........................................90
Installing DV Media PRO Program ........................................91
Connecting to a PC ................................................................92
Disconnecting the USB Cable ............................................92
Using the C Camera Function............................................93
Using the USB Streaming Function ....................................94
Using the Removable Disk Function
(SC-D363/D364/D365/D366 only) ......................................94
After Finishing a Recording ....................................................95
Usable Cassette Tapes ..........................................................95
Cleaning and Maintaining the Camcorder ..............................96
Using Your Camcorder Abroad ..............................................97
Troubleshooting ......................................................................98
Self Diagnosis Display........................................................98
Self Diagnosis Display in M.Cam/M. layer Modes
(SC-D363/D364/D365/D366 only) ....................................99
Setting menu items................................................................101
IEEE 1394 Data Transfer ....................................................87
USB Interface (SC-D362/D363/D364/D365/D366 only) ..89
Maintenance ......................................................................95
Troubleshooting ......................................................98
Specifications ...................................................... 103
Index .................................................................... 104
Warranty (SEA users only) ....................................105

ENGLISH
55
Notes regarding the Video Head Cleaning
Notes regarding the LCD Screen, Viewfinder, Lens
Notes and Safety Instructions
Notes regarding the Rotation of the LCD Screen
Please rotate the LCD Screen carefully as illustrated.
Over rotation may cause damage to the inside of the hinge that connects the LCD Screen to the Camcorder.
1. Open the LCD Screen 90 degrees to the Camcorder
with your finger.
2. Rotate it to the best angle to record or play.
■If you rotate the LCD Screen 180 degrees so it is facing
forward, you can close the LCD Screen with the facing out.
■This is convenient during playback operations.
[Note]
Refer to page 29 to adjust brightness and color of the LCD Screen.
1. Direct sunlight can damage the LCD Screen, the inside of the Viewfinder or the Lens.
Take pictures of the sun only in low light conditions, such as at dusk.
2. The LCD Screen has been manufactured
using high precision technology.
However, there may be tiny dots (red, blue or green in color) that
appear on the LCD Screen. These dots are normal and do not
affect the recorded picture in any way.
3. Do not pick up the Camcorder by holding the Viewfinder, LCD
Screen or Battery Pack.
4. Applying excessive force to the Viewfinder may damage it.
■To ensure normal recording and a clear picture, clean the video heads regularly.
If a square block-shape distorts playback, or only a blue screen is displayed, the video heads may be dirty.
If this happens, clean the video heads with a dry type cleaning cassette.
■Do not use a wet-type cleaning cassette. It may damage the video heads.
LCD Open Knob
180 degrees (max.)
90 degrees (max.)
90 degrees
to the Camcorder
COLOR NITE
MENU

ENGLISH
66
Servicing & Replacement Parts
Notes and Safety Instructions
Notes regarding Camcorder
Notices regarding Copyright
■Do not leave the Camcorder exposed to high temperatures (above 60 °C or 140 °F).
For example, in a parked car in the sun or exposed to direct sunlight.
■Do not let the Camcorder get wet. Keep the Camcorder away from rain, sea water, and any other form of moisture.
If the Camcorder gets wet, it may get damaged. Sometimes a malfunction due to exposure to liquids cannot be
repaired.
■A sudden rise in atmospheric temperature may cause condensation to form inside the Camcorder.
- When you move the Camcorder from a cold location to a warm location (e.g. from outside to inside during the winter.)
- When you move the Camcorder from a cool location to a hot location (e.g. from inside to outside during the summer.)
■If the (DEW) protection feature is activated, leave the Camcorder for at least two hours in a dry, warm room with
the cassette compartment opened and the Battery Pack removed.
Television programs, video tapes, DVD titles, films, and other program materials may be copyrighted.
Unauthorized copying of copyrighted material may be against the law.
All the trade names and registered trademarks mentioned in this manual or other documentation provided with your
Samsung product are trademarks or registered trademarks of their respective holders.
■Do not attempt to service this Camcorder yourself.
■Opening or removing covers may expose you to dangerous voltage or other hazards.
■Refer all servicing to qualified service personnel.
■When replacement parts are required, be sure the service technician has used replacement parts specified by the
manufacturer and having the same characteristics as the original part.
■Unauthorized substitutions may result in fire, electric shock or other hazards.

ENGLISH
77
Getting to Know Your Camcorder
Features
■
Digital Data Transfer unction
with IEEE1394
By incorporating the IEEE 1394
(i.LINK™: i.LINK is a serial data
transfer protocol and
interconnectivity system, used to
transmit DV data) high speed data
transport port, both moving and
photo images can be transferred
to a PC, making it possible to
produce or edit various images.
■
USB Interface for Digital Image
Data Transfer (SC-D362/D363/
D364/D365/D366 only)
You can transfer images to a PC
using the USB interface without an
add-on card.
■
The PHOTO function lets you
capture an object as a still, while in
<Camera mode>.
■
1200x Digital Zoom
Allows you to magnify an image up
to 1200 times its original size.
■
Audio Enhancement
Provides more powerful sound by
with the Real Stereo and Audio
Effect features.
■
Color T T LCD
A high-resolution color TFT LCD
gives you clean, sharp images as
well as the ability to review your
recordings immediately. A high-
resolution color TFT LCD of 230K
pixels supports 16:9 aspect ratio.
(SC-D365/D366).
■
Digital Image Stabilizer (DIS)
The DIS compensates for any
handshake, reducing unstable
images particularly at high
magnification.
■
Various Visual Effects
The Visual Effects allow you to
give your films a special look by
adding various special effects.
■
Back Light Compensation (BLC)
The BLC function compensates for
a bright background behind a
subject you're recording.
■
Program AE
The Program AE enables you to
alter the shutter speed and
aperture to suit the type of
scene/action to be filmed.
■
High Power Zoom Lens
Power Zoom lens allows users to
magnify the subject clearly up to
x33 (x30 for SC-D263/D363).
■
Digital Still Camera unction
(SC-D363/D364/D365/D366 only)
- Using Memory Card, you can
easily record and playback
standard photo images.
- You can transfer standard photo
images on the Memory Card to
your PC using the USB interface.
■
Moving Image Recording
(SC-D363/D364/D365/D366 only)
Moving image recording makes it
possible to record video onto a
Memory Card.
■
Multi Memory Card Slot
(SC-D365/D366 only)
Multi Memory Card slot is able to
use Memory Stick (Duo),
Memory Stick PRO, MMC and SD.
■
Built-in Memory (SC-D366 only)
You can use digital still camera
functions without a separate
external Memory Card by using the
built-in memory installed in your
Camcorder. (SC-D366: 32MB)

Make sure that the following basic accessories are supplied with your digital video camera.
Basic Accessories
1. Lithium Ion Battery Pack
2. AC Power Adapter (AA-E8 TYPE)
3. AC Cord
4. Audio/Video Cable (SC-D263/D363)
5. Multi Cable (SC-D362/D364/D365/D366)
6. Instruction Book/Quick Guide
7. Lithium Battery for Remote Control
(SC-D364/D366 only) or Clock.
(TYPE: CR2025)
8. Remote Control (SC-D364/D366 only)
9. USB Cable (SC-D362/D363/D364/D365/D366 only)
10. Software CD (SC-D362/D363/D364/D365/D366 only)
11. Lens Cover
12. Lens Cover Strap
ENGLISH
88
Getting to Know Your Camcorder
Accessories Supplied with Camcorder
1. Lithium Ion Battery Pack
AD43-00136A
2. AC Power Adapter
(AA-E8 TYPE)
AD44-00090A
5. Multi Cable (SC-D362
/D364/D365/D366)
6. Instruction Book/
Quick Guide
7. Lithium Battery (CR2025)
AD43-10130H
AD46-00082A
8. Remote Control
(SC-D364/D366)
AD59-00085A
AD97-10686A
9. USB Cable (SC-D362
/D363/D364/D365/D366)
AD39-00073A
10. Software CD (SC-D362
/D363/D364/D365/D366)
11. Lens Cover 12. Lens Cover Strap
AD72-00049A
3. AC Cord
AD39-00076A
4. Audio/Video Cable
(SC-D263/D363)
AD39-00001A AD39-00119A

ENGLISH
99
Getting to Know Your Camcorder
Front & Left View
1. Lens
2. LIGHT ➥page 43
(SC-D362/D364/D365/D366 only)
3. Remote Sensor
(SC-D364/D366 only)
4. TAPE EJECT
5. Internal MIC
6. EASY.Q Button ➥page 35
7. unction Buttons
8. T T LCD Screen
1. Lens
2. LIGHT
(SC-D362/D364/D365
/D366 only)
3. Remote Sensor
(SC-D364/D366 only)
5. Internal MIC
8. T T LCD Screen
7. unction Buttons
6. EASY.Q Button
4. TAPE EJECT
MF/AF
MULTI DISP.
Button <Player> <Camera> <M.Player> (SC-D363/D364/D365/D366 only)
œœœœREW REC SEARCH – REV
√√√√FF REC SEARCH + FWD
√√/❙❙ PLAY/STILL FADE S.SHOW (SLIDE SHOW)
■STOP MF/AF MULTI DISP. (MULTI DISPLAY)

ENGLISH
1010
Getting to Know Your Camcorder
Left Side View
1. DISPLAY ➥page 21
2. MACRO/PB ZOOM ➥page 39 / ➥page 61
3. Speaker
4. Mode Switch (MEMORY/TAPE)
(SC-D363/D364/D365/D366 only)
5. Viewfinder
6. COLOR NITE ➥page 42
LIGHT (SC-D362/D364/D365/D366) ➥page 43
COLOR NITE
LIGHT
MENU
1. DISPLAY
2. MACRO/PB ZOOM
4. Mode Switch
(MEMORY/TAPE)
(SC-D363/D364/D365/D366 only)
3. Speaker
5. Viewfinder
6. COLOR NITE
LIGHT
(SC-D362/D364/D365/D366)

ENGLISH
1111
Getting to Know Your Camcorder
Right & Top View
QUICK
MENU
P
L
A
Y
E
R
C
A
M
E
R
A
MIC DV
USB
AV/ S
1. Zoom Lever (VOL/Menu Dial)
2. PHOTO Button ➥page 57
3. QUICK MENU Button
4. MENU Button
5. Start/Stop Button
6. Power Switch (CAMERA or PLAYER)
7. DC Jack
8. Jack Cover
9. Jacks
10. Cassette Door
11. Hand Strap Hook
4. MENU Button
5. Start/Stop Button
6. Power Switch
1. Zoom Lever
(VOL/Menu Dial)
2. PHOTO Button
3. QUICK MENU Button
7. DC Jack
8. Jack Cover
10. Cassette Door
9. Jacks (See below)
11. Hand Strap Hook
Jacks
SC-D263
SC-D363
External
MIC
IEEE1394 AV
Cable
External
MIC
IEEE1394 USB AV
Cable
External
MIC
IEEE1394 USB Multi
Cable
SC-
D362/D364/
D365/D366

ENGLISH
1212
Getting to Know Your Camcorder
Rear & Bottom View
1. Lithium Battery Cover
2. Charging Indicator
3. Memory Card Slot
(SC-D363/D364/D365/D366 only)
4. Tripod Receptacle
5. Battery Release
MENU
CHG
QUICK
MENU
4. Tripod Receptacle
3. Memory Card Slot
(SC-D363/D364/D365/D366 only)
BATTERY
RELEASE
1. Lithium Battery Cover
5. Battery Release
2. Charging Indicator
Memory Card Slot (Usable Memory Card)
SC-D363/D364 SC-D365/D366
Memory Stick
Memory Stick PRO
SD/MMC
SD/MMC

ENGLISH
1313
Getting to Know Your Camcorder
Remote Control (SC-D364/D366 only)
1. PHOTO Button ➥page 57
2. START/STOP Button
3. SEL TIMER Button ➥page 38
4. ZERO MEMORY Button ➥page 37
5. PHOTO SEARCH Button
6. A.DUB Button ➥page 62
7. √√√√ ( ) Button
8. œœœœ (REW) Button
9.
√√ (PLAY) Button
10. œœ
❙❙ / ❙❙ √√(Direction) Button ➥page 59
11. . ADV Button ➥page 60
12. ■ (STOP) Button
13.
❙❙ (STILL) Button
14. SLOW ( ❙ √√ ) Button
15. DATE/TIME Button
16. X2 Button ➥page 60
17. W/T (Zoom) Button
18. DISPLAY Button
1. PHOTO
2. START/STOP
3. SEL TIMER
4. ZERO MEMORY
5. PHOTO SEARCH
6. A.DUB
7. √√√√ ( )
9.
√√ (PLAY)
10. œœ❙❙ / ❙❙√√(Direction)
18. DISPLAY
17. W/T (Zoom)
16. X2
15. DATE/TIME
14. SLOW(
❙ √√ )
13.
❙❙ (STILL)
11. . ADV
12. ■ (STOP)
8. œœœœ(REW)

ENGLISH
1414
Preparation
Using the Hand Strap & Lens Cover
It is very important to ensure that the Hand Strap has been correctly adjusted before you begin your recording.
The Hand Strap enables you to:
- Hold the Camcorder in a stable, comfortable position.
- Press the [Zoom] and [Start/Stop] button without having to change the position of your hand.
Hand Strap
Adjusting the Hand Strap
1. Insert the Hand Strap into the Hand
Strap Hook on the front side of
the Camcorder and pull its end
through the hook.
2. Insert your hand into the Hand Strap and adjust its length for your convenience.
3. Close the Hand Strap.
Lens Cover
Attaching the Lens Cover
1. Hook up the Lens Cover with the Lens Cover Strap as illustrated.
2. Hook up the Lens Cover Strap to the Hand Strap, and adjust it following
the steps as described for the Hand Strap.
3. Close the Hand Strap.
Installing the Lens Cover after Operation
Press buttons on both sides of the Lens Cover, then attach it to the Camcorder Lens.
1 2 3
1 2
2 3

ENGLISH
1515
Preparation
Lithium Battery Installation
Lithium Battery Installation for the Internal Clock
1. Remove the Battery Pack from the rear of the Camcorder.
2. Open the Lithium Battery Cover on the rear of the Camcorder.
3. Position the Lithium Battery in the Lithium Battery Holder, with the positive
( ) terminal face up.
Be careful not to reverse the polarity of the Battery.
4. Close the Lithium Battery Cover.
Lithium Battery Installation for the Remote Control (SC-D364/D366 only)
1. Pull out the Lithium Battery Holder toward the direction of the arrow.
2. Position the Lithium Battery in the Lithium Battery Holder, with the positive
( ) terminal face up.
3. Reinsert the Lithium Battery Holder.
Precaution regarding the Lithium Battery
1. The Lithium Battery maintains the clock function and preset contents of the memory; even if the Battery Pack or
AC Power adapter is removed.
2. The Lithium Battery for the Camcorder lasts about 6 months under normal operation from time of installation.
3. When the Lithium Battery becomes weak or dead, the date/time indicator will display <12:00 AM JAN.1,2006> when
you set the <Date/Time> to <On>.
When this occurs, replace the Lithium Battery with a new one (type CR2025).
4. There is a danger of explosion if Battery is incorrectly replaced.
Replace only with the same or equivalent type.
Warning: Keep the Lithium Battery out of reach of children. Should a battery be swallowed, consult a doctor
immediately.
MENU
CHG
QUICK
MENU

ENGLISH
1616
Preparation
Using the Lithium Ion Battery Pack
✤Use SB-LSM80 or SB-LSM160 Battery Pack only.
✤The Battery Pack may be charged a little at the time of purchase.
Charging the Lithium Ion Battery Pack
1. Turn the [Power] switch to [Off].
2. Attach the Battery Pack to the Camcorder.
3. Connect the AC Power Adapter to an AC Cord and
connect the AC Cord to a wall socket.
4. Connect the DC cable to the DC jack on the
Camcorder. The charging indicator will start to blink,
showing that the Battery is charging.
5. Press and hold the DISPLAY button while charging and the charging status will be
displayed on the LCD for 7 seconds.
■As indicated the battery level is given as reference data for the user, it is the
approximate estimation. It may differ from Battery capacity and temperature.
6. When the Battery is fully charged, disconnect the Battery Pack and the AC Power Adapter
from the Camcorder.
Even with the Power switched Off, the Battery Pack will still discharge.
Charging/Recording Times based on
Model and Battery Type.
✤If you close the LCD Screen, it switches off and
the Viewfinder switches on automatically.
✤The continuous recording times given in the table
to the right are approximations.
Actual recording time depends on usage.
✤The continuous recording times in the operating
instructions are measured using a fully charged Battery Pack at 77 °F (25 °C).
✤Even when the Power switched Off, the Battery Pack will still discharge if it is left attached to the device.
Blinking time Charging rate
Once per second Less than 50%
Twice per second 50% ~ 75%
Three times per second 75% ~ 90%
Blinking stops and stays on 90% ~ 100%
On for a second and Error - Reset the Battery Pack and
off for a second the DC Cable
Battery
SB-LSM80
(AD43-00136A)
SB-LSM160
(Option)
Charging
time
Approx.
1hr 20min
Approx.
3hr
LCD On Viewfinder On
Recording time
Time
Approx.
1hr 20min
Approx.
2hr 40min
Approx.
1hr 30min
Approx.
3hr
Battery Info
BBaatttteerryy cchhaarrggeedd
0% 50% 100%
