Samsung DIGIMAX 3000 User manual

Thank you for buying a Samsung Camera.
This manual will guide you through using the camera, including capturing images, downloading images and
using the application software. Please read this manual carefully before using your new camera.
ENGLISH
Digimax 3000
Digimax 3100

2
Use this camera in the following order
Instructions
Insert the
USB cable
Set up the
camera driver
Before connecting the camera to a PC, via the
USB cable, you will need to set up the camera
driver. Install the camera driver that is contained in
the Application S/W CD-ROM.(p.85)
Take a picture (p.20)
Insert the supplied USB cable into the PC’s USB
port and the camera’s USB connection
terminal.(p.91)
Check the camera’s power
If the power is turned off, press the camera button
to power it on.
Take a picture
Check the
camera’s power
Check
[Removable Disk]
Open Window s EXPLORER and search for
[Removable Disk].(p.92)
If you use a card reader to copy the images on the memory card to your PC, the images
could be damaged. When transferring the images taken with the camera to your PC, be sure
to use the supplied USB cable to connect the camera to your PC. Please note that the
manufacturer holds no responsibility for loss or damage of images on the memory card due
to the use of a card reader.

3
Getting to know your camera 5
About the icons 5
Danger 6
Warning 6
Caution 7
An FCC warning 7
This digital camera can be used for 8
Manufacturer's contents 10
Identification of features 11
Front & Top 11
Back & Bottom 11
Side/ 5-function button 12
Mode dial 12
Connecting to a Power Source 14
Using the AC power adapter
(3.3V 2.0A) 15
Using the batteries 16
Instructions on how to use the
memory card 17
Inserting the memory card 19
Removing the memory card 19
LCD monitor indicator 20
Starting the recording mode 21
Things to Watch Out for When Taking
Pictures 25
Using the camera buttons to adjust the
camera 26
POWER button 26
SHUTTER button 26
ZOOM W/ T button 26
TELE Zoom 27
WIDE Zoom 27
Voice memo/ UP button 28
Recording a voice memo 28
Macro/ Down button (Focusing) 29
Focus lock 30
FLASH/ LEFT button 31
Self-timer/ Right button 33
MENU/ OK button 34
+/- button 34
LCD button 38
Using the LCD monitor to adjust the camera
settings 39
How to use the menu 40
Size 41
Quality 41
Metering 42
Continuous shot 43
Effect 43
Sharpness 44
Scene 44
Starting play mode 45
Playing back a still image 45
Playing back a movie clip 46
Playing back a recorded voice 46
LCD monitor indicator 47
Using the camera buttons to adjust the
camera 48
Thumbnail/ Enlargement button 48
Voice memo/ Up button 49
Play & Pause/ Down button 50
LEFT/ RIGHT/ MENU/ OK button 51
Contents
READY
RECORDING
PLAY

4
LCD button 51
Delete button 52
Setting up the play back function using the
LCD monitor 53
Starting the slide show 54
Protecting images 55
Deleting images 56
Resize 57
Rotating an image 58
DPOF 58
DPOF : STANDARD 59
DPOF : INDEX 59
DPOF : PRINT SIZE 60
Copy Picture 61
PictBridge 62
Setup menu 64
File name 65
Auto power off 66
Language 67
Formatting a memory card 67
Setting up the Date/ Time/ Date type 68
Imprinting the recording date 68
Sound 69
LCD brightness 69
Selecting Video out type 70
Quick view 71
Initialization(RESET ALL) 71
Select card 72
Connecting an External Device (USB) 72
Setting up the MYCAM menu 73
Start up image 73
Start up sound 74
Shutter sound 74
Important notes 75
Warning indicator 77
Before contacting a service center 78
Specifications 81
Software Notes 83
System Requirements 83
About the software 84
Setting up the application software 85
Starting PC Mode 91
Removing the USB Driver for
Windows 98SE 94
Removable Disk 95
Removing the removable disk 96
Setting up the USB Driver for MAC 97
Using the USB Driver for MAC 97
Using PhotoImpression 98
Digimax Viewer 2.1 99
FAQ 100
Contents
SOFTWARE
SETUP

5
Getting to know your camera
Thank you for buying a Samsung Digital Camera.
Prior to using this camera, please read the user manual thoroughly.
When you require After Sales service, please bring the camera and the cause of the camera
malfunction (such as Batteries, Memory card etc.) to the A/S center.
Please check that the camera is operating properly prior to when you intend to use it
(e.g. for a trip or an important event) to avoid disappointment. Samsung camera takes no
responsibility for any loss or damages that may result from camera malfunction.
Keep the manual in a safe place.
Microsoft, Windows and Windows logo are registered trademarks of Microsoft Corporation
incorporated in the United States and/or other countries.
All brand and product names appearing in this manual are registered trademarks of their
respective companies.
This manual contains instructions on using this camera that will help you to use this camera
safely and correctly. This will help prevent danger and injury to others.
About the icons
DANGER
DANGER indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation, which, if not avoided,
may result in a minor or moderate injury.

6
Danger
Do not attempt to modify this camera in any way. This may result in fire, injury, electric shock
or severe damage to you or your camera. Internal inspection, maintenance and repairs
should be carried out by your dealer or Samsung Camera Service Center.
Please do not use this product in close proximity to flammable or explosive gases, as this
could increase the risk of explosion.
Should any form of liquid or a foreign object enter the camera, do not use it. Switch off the
camera, and then disconnect the power source (batteries or AC Power Adapter).
You must contact your dealer or Samsung Camera Service Center.
Do not continue to use the camera as this may cause a fire or electric shock.
Do not insert or drop metallic or inflammable foreign objects into the camera through access
points e.g. the memory card slot and battery chamber.
This may cause a fire or electric shock.
Do not operate this camera with wet hands. This could pose a risk of electric shock.
Do not use the flash in close proximity to people or animals.
Positioning the flash too close to your subject’s eyes, may cause eyesight damage.
When taking photographs, never point the lens of the camera directly into very strong light.
This may result in permanent damage to your eyesight.
For safety reasons keep this product and accessories out of reach of children or animals to
prevent accidents e.g.:
Swallowing batteries or small camera accessories. If an accident should occur, please
consult a doctor immediately.
There is the possibility of injury from the camera’s moving parts.
Batteries and camera may become hot during prolonged use and it may result in camera
malfunction. Should this be the case, allow the camera to sit idle for a few minutes to allow it
time to cool.
Do not recharge non rechargeable batteries. This may cause an explosion.
Do not leave this camera in places subject to extremely high temperatures, such as a sealed
vehicle, direct sunlight or other places of extreme variances in temperature.
Exposure to extreme temperatures may adversely affect the camera s internal components
and could cause a fire.
When in use, do not cover the camera or AC Power Adapter.
This may cause heat to build up and distort the camera body or cause a fire.
Always use the camera and its accessories in a well-ventilated area.
Warning

7
Caution
Leaking, overheating, or burst batteries could result in fire or injury.
Use batteries with the correct specification for the camera.
Do not short circuit, heat or dispose of batteries in fire.
Do not insert the batteries with the reverse polarities.
Remove the batteries when not planning to use the camera for a long period of time.
Batteries may leak corrosive electrolyte and irreparably damage the camera's components.
Do not fire the flash while it is in contact with hands or objects.
Do not touch the flash after using it continuously. It may cause burns.
Do not move the camera while it is switched on, if you are using the AC Power Adapter.
After use, always switch off the camera before unplugging the adapter from the wall socket.
Then make sure that any connector cords or cables to other devices are disconnected before
moving the camera. Failure to do so may damage the cords or cables and cause a fire or
electric shock.
An FCC warning
This device has been tested in accordance with the limits of a class B digital device
under item 15 of the FCC rules. These limits are designed to provide protection against
harmful interference in commercial installation. This equipment generates, absorbs and
can emit radio frequency energy. If it is not installed and used in accordance with the
instructions, it may cause harmful interference to radio communication.
There is however, no guarantee that interference will not occur in some situations.
Should any interference occur when this device is in operation, please try one or more of
the following measures.
Change the location and direction of any aerial.
Increase distance between the camera and the affected device.
Use a different socket away from the affected device.
Please contact a Samsung agent or a radio/TV engineer.
This device complies with part 15 of the FCC Rules.
Changes or modifications not expressly approved by the party responsible for
compliance could void user's authority to operate the equipment.

8
This digital camera can be used for
Printing images using a dedicated printer,
DPOF and PictBridge compatible printer or a
DPOF-equipped photo lab.
(refer to page 58~60, 62~63)
Down loading image files from
camera to computer.
(refer to page 92)
Editing images on a PC.
(refer to page 98)
Viewing images on a TV.
(refer to page 70)
Taking a picture.
(refer to page 20)

9
This digital camera can be used for
Inserting images directly into any
electronic document.
Taking a self-portrait and using the image
to personalize calendar.
You can even create your own unique gift
wrap paper by using your digital images.
Creation of a digital photo album.
Recording your voice.
(refer to page 23) Recording a movie clip.
(refer to page 23)

10
Manufacturer's contents
Please check that you have the correct contents before using this product.
marked contents are optional.
Digital Camera USB cableAV cablePouch
Camera strap Software CDProduct warrantyUser manual
SD memory card 2 AA Alkaline
Batteries
Memory Stick Duo AC adapter (3.3V)
Battery
charger
Rechargeable
battery
AC adapter(5V) Battery
charger
Rechargeable
battery
AC cord
Digimax Battery I-Pack : SBP-1103 KIT Digimax Battery I-Pack : SBP-1303 KIT

11
Identification of features
Front & Top
Back & Bottom
Shutter button
Self-timer lamp
Flash light
amount sensor
Viewfinder
DC input
connection point
USB/ AV
connection terminal
Lens
Microphone
Flash
Power button
LCD monitor
Mode dial
Viewfinder
Autofocus indicator lamp(Green)
Flash indicator lamp(Red)
Zoom W button (Thumbnail)
Zoom T button (Digital zoom)
LCD button
Tripod socket
+&-/ DELETE button Play mode button
5-function
button
* When using the digital zoom to take a picture, the composition of the picture may be different
depending on whether you are using the LCD monitor or the viewfinder.
The picture will be taken in the composition of the picture as it appears on the LCD monitor.
Strap eyelet
Speaker

12
Identification of features
MANUAL mode
Please select this mode for quick and easy picture taking
with minimal user interaction.
Selecting the automatic mode will configure the camera with
optimal settings. You can still manually configure all
functions except the iris and shutter speed.
AUTO mode
You can select the desired working mode by using the mode dial located on the back of the
camera. This digital camera has 8 recording modes. These are listed below.
SD memory
card slot
Memory Stick
DUO slot
Battery chamber
Battery chamber cover
FLASH/
LEFT button
MENU/ OK button
Macro / DOWN
Play & Pause button
SELF-TIMER/
RIGHT button
Voice memo/ UP button
Side/ 5-function button
Mode dial

13
Identification of features
This mode allows users to save frequently used shooting
settings for later use.
MySET mode
A movie clip can be recorded for as long as the available
recording time of the memory capacity allows.
- Image size : 640X480, 320X240(user selectable)
- Movie clip file type : *.avi
MOVIE CLIP mode
A voice recording can be recorded for as long as the available
recording time of the memory capacity allows.(Max : 1 hour)
- Voice recording file type : *.wav
VOICE RECORDING mode
Use the menu to easily configure optimal settings for a variety
of shooting situations including children, landscape, close-up,
sunset, dawn, backlight, fireworks, beach scenes, and
snowscape.
SCENE mode
This mode is used at night or against a dark background.
NIGHT SCENE mode
This is used for just portrait or both portrait and landscape
shots.
PORTRAIT mode

14
Identification of features
Self-timer lamp(Based on 10-second Self-timer; see p. 33)
Color Status Camera Status
Blinking For the first 7 seconds, the LED blinks at 1 second intervals.
For the final 3 seconds, the LED blinks quickly at 0.25-
second intervals.
Red
Color Status Camera Status
Blinking
Recording Mode (lightly press the shutter button): Not focused
PC Mode: Transmitting Data
Recording Mode (lightly press the shutter button): Focused.
Turned off the LCD with the LCD button.
PC Mode: When the USB cable is inserted.
On
Green
Color Status Camera Status
Blinking Flash in the process of charging
Flash ready
On
Red
MODE
Icon
Icon
MODE SCENE
AUTO MANUAL MySET
MOVIE CLIP
VOICE RECORDING
NIGHT SCENE PORTRAIT PLAY
CHILDREN LANDSCAPE
CLOSE-UP
SUNSET DAWN BACKLIGHT FIREWORKS BEACH&SNOW
Auto focus indicator lamp(Green)
Flash indicator lamp(Red)
Mode icons
Connecting to a Power Source
There are two ways in which to provide the camera with power. You can use batteries or
alternatively, you can use an AC(100 ~ 250V) Adapter (DC 3.3V 2.0A).
We recommend using batteries for a digital camera. (Within a year from the date of
manufacture) The batteries are listed below.
Non rechargeable batteries : AA type –Alkaline, Ni-Mn, Ni-Zn, Lithium
CR-V3 type –Lithium
Rechargeable batteries : AA type –Ni-MH, Ni-Cd (over 1000mA)
CR-V3 type –Digimax Battery I-Pack(SBP-1103, SBP-1303)

15
Connecting to a Power Source
Important information about battery usage
It is easy to buy alkaline batteries. However, the duration for using batteries varies in
accordance with the battery manufacturer or the photographic conditions.
When the camera is not used, turn off the camera power.
Do not recharge the non rechargeable batteries. It may cause an explosion.
Please remove the batteries if the camera will not be used for long periods.
Batteries can lose power over time and are prone to leaking if kept inside the camera.
We recommend high capacity ALKALINE batteries as manganese batteries cannot
deliver sufficient power.
Low temperatures (below 0 ) can affect the performance of the batteries and you may
experience reduced battery life.
Batteries will usually recover at normal temperatures.
Do not use old and new batteries at the same time.
During extended use of the camera, the camera body may become warm.
This is perfectly normal.
Always turn off the power before taking the AC adapter out of the mains supply.
As with all mains powered devices, safety is important. Ensure that neither the camera
nor adapter comes into contact with water or metallic materials.
Please ensure that you use an AC adapter (3.3V 2.0A) with the correct specification for
the camera. Failure to do so may affect your warranty.
INFORMATION
DANGER
If you have access to a mains supply, using an AC
Adapter (3.3V 2.0A) allows the camera to be used for
long periods of time.
Plug the adapter into the connection point
(DC IN 3.3V) on the camera.
Remove the batteries from the camera when using an
AC adapter.
Using the AC power adapter (3.3V 2.0A)

16
Connecting to a Power Source
Battery status
Battery indicator
The batteries are fully
charged. Prepare new batteries.
There is no battery capacity.
Replace with new batteries.
There are 3 indicators for battery condition that are displayed on the LCD monitor.
3. To close the battery chamber cover, push it until it clicks.
2. Insert the batteries taking note of the
polarity (+ / -).
1. Open the battery chamber cover by pushing in the direction of the
arrow.
: If the camera does not turn on after you have inserted batteries,
please check whether the batteries are inserted with the correct
polarity(+ and-).
Using the batteries
[ Inserting the AA type battery ][ Inserting the CR-V3 type battery ]

17
Instructions on how to use the memory card
Be sure to format the memory card (see p. 67) if you are using a newly purchased memory
for the first time, if it contains data that the camera cannot recognize, or if it contains images
captured with a different camera.
Turn off the camera power whenever the memory card is being inserted or removed.
Repeated use of the memory card will eventually reduce the memory card’s performance.
Should this be the case, you will need to purchase a new memory card.
Wear and tear on the memory card is not covered by the Samsung warranty.
The memory card is an electronic precision device.
Do not bend, drop or subject the memory card to any heavy impact.
Do not store the memory card in an environment with strong electronic or magnetic fields,
e.g. near loud speakers or TV receivers.
Please do not use or store in an environment where there are extremes in temperature.
Do not allow the memory card to become dirty or to come into contact with any liquid.
Should this happen, clean the memory card with a soft cloth.
Please keep the memory card in its case when not in use.
During and after periods of extended use, you may notice that the memory card is warm.
This is perfectly normal.
Do not use a memory card that is used in another digital camera or memory card reader.
Do not use a memory card formatted by another digital camera or memory card reader.
Maintenance of the memory card
If the memory card is subjected to any of the following, the recorded data may become
corrupted :
- When the memory card is used incorrectly.
- If the power is switched off or the memory card is removed while recording, deleting
(formatting) or reading.
Samsung cannot be held responsible for lost data.
It is advisable to copy important data onto other media as back-up e.g. floppy disks, hard
disks, CD etc.
If there is insufficient memory available : If you press the shutter button for the shot, a [CARD
FULL !] message will appear and the camera will not operate. To optimize the amount of
memory in the camera, replace the memory card or delete unnecessary images stored on
the memory.
Preserving the memory card data

18
Instructions on how to use the memory card
If you open the battery chamber cover when the camera power is turned on, the power
will turn off automatically.
Don't remove the memory card when the Auto focus lamp(Green) is blinking as this
may cause damage to data in the memory card.
INFORMATION
[ SD(Secure Digital) memory card ]
Write protect
switch
Label
Card pins
Recorded image size Super fine Fine Normal
2048x1536 17 33 49
1600x1200 28 53 75
1024x768 64 106 139
640x480 129 201 227
The camera can use SD Memory Cards, MMC (Multi Media Card), and Memory Stick Duo.
Please consult the enclosed manual for using the MMC and Memory Stick Duo.
The SD memory card has a write protect
switch that prevents image files from being
deleted or formatted.
By sliding the switch to the bottom of the SD
memory card, the data will be protected. By
sliding the switch to the top of the SD memory
card, the data protection will be canceled.
Slide the switch to the top of the SD memory
card before taking a picture.
When using a 32MB SD memory card, the specified shooting capacity will be as follows.
(These figures are intended as an indication of expected performance). These figures are
approximate as image capacities can be affected by variables such as subject matter.

19
Inserting the memory card
1. Turn the power off using the power button.
Open the battery chamber cover and press the memory
card as shown in the image and release.
2. Remove the memory card and close the battery chamber
cover.
3. To close, push the battery chamber cover until you hear a
click. If the memory card does not slide in smoothly, do not
attempt to insert it by force. Check the direction of insertion,
and then insert it correctly. Do not insert the memory card
the wrong way round. Doing so may damage the memory
card slot.
* When inserting the Memory Stick Duo, please have the label
side facing down (toward the LCD) and the other side up
(toward the lens).
Be careful not to insert the Memory Stick Duo into the SD
memory card slot.
2. Have the front of the memory card facing toward the front of
the camera (lens) and the card pins toward the back of the
camera (LCD monitor), and then push the memory card
into the card slot until you hear a click.
1. Turn off the camera’s power and pull the battery chamber
cover in the direction of the arrow to open.
Removing the memory card

20
LCD monitor indicator
No. Description Icons Page
1 Battery p.16
3 Camera shake warning p.25
4 Flash p.31
5 Self-timer p.33
6 Voice memo p.28
7 Macro p.29
8 Metering p.42
9 SD card/ MS DUO indicator
10 Sharpness p.44
11 Auto focus frame
12 Date/ Time 2004/01/01 01:00 PM p.68
13 Exposure compensation p.36
The LCD monitor displays information about the shooting functions and selections.
Recording mode2p.12~13
[ Image & Full Status ]
