Samsung digimax U-CA 501 User manual

Thank you for buying a Samsung Camera.
This manual will guide you through using the camera, including capturing images, downloading images and
using the application software. Please read this manual carefully before using your new camera.
Figures (Images) used for the manual are based on model Digimax U-CA 501.
ENGLISH
Digimax U-CA 505
User's Manual

2
Instructions
Use this camera in the following order
Insert the
USB cable
Set up the
camera driver
Before connecting the camera to a PC, via the
USB cable, you will need to set up the camera
driver. Install the camera driver that is contained in
the Application S/W CD-ROM.(p.90)
Take a picture (p.19)
Insert the supplied USB cable into the PC’s USB
port and the camera’s USB connection
terminal.(p.98)
Check the camera’s power. If the power is turned
off, press the camera button to turn on.
Take a picture
Check the
camera’s power
Check
[Removable Disk]
Open Window s EXPLORER and search for
[Removable Disk].(p.99)
If you use a card reader to copy the images on the memory card to your PC, the images
could be damaged. When transferring the images taken with the camera to your PC, be sure
to use the supplied USB cable to connect the camera to your PC. Please note that the
manufacturer holds no responsibility for loss or damage of images on the memory card due
to the use of a card reader.

3
Contents
Getting to know your camera 5
About the icons 5
Danger 6
Warning 6
Caution 7
An FCC warning 7
System chart 8
Identification of features 10
Front & Top 10
Back & Bottom 10
Side/ 5-function button 11
Mode switch 11
Connecting to a Power Source 13
Using the batteries 14
Removing the battery 14
Instructions on how to use the memory card 15
Inserting the memory card 17
Removing the memory card 17
LCD monitor indicator 18
Starting the recording mode 19
Things to Watch Out for When Taking
Pictures 21
Using the camera buttons to adjust the
camera 22
POWER button 22
SHUTTER button 22
ZOOM W/T button 22
Voice memo/ UP button 24
Recording a voice memo 24
Macro / Down button (Focusing) 24
Focus lock 25
FLASH/ LEFT button 26
Self-timer/ Right button 28
MENU/ OK button 29
+/- button 29
LCD button 33
Using the LCD monitor to adjust the
camera settings 34
How to use the menu 36
Mode 36
Size 37
Quality 38
Metering 39
Continuous shot 39
Effect 40
Photo Frame 41
Sharpness 42
Save / Load the camera configuration
(MYSET) 43
Starting play mode 44
Playing back a still image 44
Playing back a movie clip 45
Playing back a recorded voice 45
LCD monitor indicator 46
Using the camera buttons to adjust the
camera 47
Thumbnail/ Enlargement button 47
Voice memo/ Up button 48
Play & Pause/ Down button 49
LEFT/ RIGHT/ MENU/ OK button 50
LCD button 50
Delete button 51
Setting up the play back function using
the LCD monitor 52
Starting the slide show 55
Rotating an image 56
RECORDING
PLAY
READY

4
Contents
Resize 57
Protecting images 58
Deleting all images 59
DPOF 59
DPOF : STANDARD 60
DPOF : INDEX 60
DPOF : PRINT SIZE 61
DPOF : CANCEL 61
COPY TO CARD 62
PictBridge 63
PictBridge: Picture Selection 64
PictBridge: Printing 65
PictBridge: Print Setting 66
PictBridge : RESET 67
Setup menu 68
File name 69
Auto power off 70
Language 71
Formatting a memory card 72
Setting up the Date 73
Setting up the Time 73
Date type 74
Imprinting the recording date 74
Sound 75
Selecting an External Device (USB) 75
Selecting Video out type 76
Quick view 77
Initialization(RESET ALL) 77
Setting up the MYCAM menu 78
Start up image 78
Start up sound 79
Shutter sound 79
Important notes 80
Warning indicator 82
Before contacting a service center 83
Specifications 86
Software Notes 88
System Requirements 88
About the software 89
Setting up the application software 90
Starting PC Mode 98
Removing the USB Driver for Windows
98SE 101
Removable Disk 102
Removing the removable disk 103
Setting up the USB Driver for MAC 104
Using the USB Driver for MAC 104
Digimax Viewer 2.1 105
Using PhotoImpression 106
Digimax Reader 107
FAQ 109
SETUP
SOFTWARE

5
Getting to know your camera
Thank you for buying a Samsung Digital Camera.
Prior to using this camera, please read the user manual thoroughly.
When you require After Sales service, please bring the camera and the cause of the camera
malfunction (such as Batteries, Memory card etc.) to the A/S center.
Please check that the camera is operating properly prior to when you intend to use it
(e.g. for a trip or an important event) to avoid disappointment. Samsung camera takes no
responsibility for any loss or damages that may result from camera malfunction.
Keep the manual in a safe place.
Microsoft, Windows and Windows logo are registered trademarks of Microsoft Corporation
incorporated in the United States and/or other countries.
All brand and product names appearing in this manual are registered trademarks of their
respective companies.
This manual contains instructions on using this camera that will help you to use this camera
safely and correctly. This will help prevent danger and injury to others.
About the icons
DANGER
DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation, which, if not avoided, may
result in a minor or moderate injury.

6
Danger
Do not attempt to modify this camera in any way. This may result in fire, injury, electric shock
or severe damage to you or your camera. Internal inspection, maintenance and repairs
should be carried out by your dealer or Samsung Camera Service Center.
Please do not use this product in close proximity to flammable or explosive gases, as this
could increase the risk of explosion.
Should any form of liquid or a foreign object enter the camera, do not use it. Switch off the
camera, and then disconnect the power source.
You must contact your dealer or Samsung Camera Service Center.
Do not continue to use the camera as this may cause a fire or electric shock.
Do not insert or drop metallic or inflammable foreign objects into the camera through access
points e.g. the memory card slot and battery chamber.
This may cause a fire or electric shock.
Do not operate this camera with wet hands. This could pose a risk of electric shock.
Do not use the flash in close proximity to people or animals.
Positioning the flash too close to your subject’s eyes, may cause eyesight damage.
When taking photographs, never point the lens of the camera directly into very strong light.
This may result in permanent damage to your eyesight.
For safety reasons keep this product and accessories out of reach of children or animals to
prevent accidents e.g.:
Swallowing batteries or small camera accessories. If an accident should occur, please
consult a doctor immediately.
There is the possibility of injury from the camera’s moving parts.
Batteries and camera may become hot during prolonged use and it may result in camera
malfunction. Should this be the case, allow the camera to sit idle for a few minutes to allow it
time to cool.
Do not recharge non rechargeable batteries. This may cause an explosion.
Do not leave this camera in places subject to extremely high temperatures, such as a sealed
vehicle, direct sunlight or other places of extreme variances in temperature.
Exposure to extreme temperatures may adversely affect the camera s internal components
and could cause a fire.
When in use, do not cover the camera.
This may cause heat to build up and distort the camera body or cause a fire.
Always use the camera and its accessories in a well-ventilated area.
Warning

7
Caution
Leaking, overheating, or burst batteries could result in fire or injury.
Use batteries with the correct specification for the camera.
Do not short circuit, heat or dispose of batteries in fire.
Do not insert the batteries with the reverse polarities.
Remove the batteries when not planning to use the camera for a long period of time.
Batteries may leak corrosive electrolyte and irreparably damage the camera's components.
Do not fire the flash while it is in contact with hands or objects.
Do not touch the flash after using it continuously. It may cause burns.
Do not move the camera while it is switched on, if you are using the AC Power Adapter.
After use, always switch off the camera before unplugging the adapter from the wall socket.
Then make sure that any connector cords or cables to other devices are disconnected before
moving the camera. Failure to do so may damage the cords or cables and cause a fire or
electric shock.
An FCC warning
This device has been tested in accordance with the limits of a class B digital device
under item 15 of the FCC rules. These limits are designed to provide protection
against harmful interference in commercial installation. This equipment generates,
absorbs and can emit radio frequency energy. If it is not installed and used in
accordance with the instructions, it may cause harmful interference to radio
communication.
There is however, no guarantee that interference will not occur in some situations.
Should any interference occur when this device is in operation, please try one or
more of the following measures.
Change the location and direction of any aerial.
Increase distance between the camera and the affected device.
Use a different socket away from the affected device.
Please contact a Samsung agent or a radio/TV engineer.
This device complies with part 15 of the FCC Rules.
Changes or modifications not expressly approved by the party responsible for
compliance could void user's authority to operate the equipment.

8
System chart
Please check that you have the correct contents before using this product. To buy the optional
equipment, contact your nearest Samsung dealer or Samsung service centre.
PouchUser manual Camera strap Software CD
( see p.90 )
SD memory card
(see p.15)
DPOF compatible
printer(see p.59)
Rechargeable
battery(SLB-1137)
Battery charger
CHARGE
AC cord
Duracell
CP-1 battery
< Included items >

9
System chart
USB /Video cable
PictBridge compatible
printer(see p.63)
Computer
External monitor
Yellow cable – Video
(see p.76)
For Windows
PC with processor better than MMX
Pentium 233MHz (XP : Pentium II 300MHz)
Windows 98/ 98SE/ 2000/ ME/ XP
Minimum 32MB RAM (XP : 128MB)
140MB of available hard-disk space
USB port
CD-ROM drive
800x600 pixels, 16-bit colour display
compatible monitor (24-bit colour display
recommended)
For Macintosh
Power Mac G3 or later
Mac OS 9.0 ~ 10.2
Minimum 64MB RAM
110MB of available hard-disk space
USB port
CD-ROM drive
QuickTime 6.01 or later for Movie Clip
System Requirements
When you connect the camera to a
computer, printer or external monitor, you
have to use the USB/ Video cable supplied
with the camera, or the external devices
can't recognize the camera.
CAUTION

10
Identification of features
Front & Top
Back & Bottom
Shutter button
Flash
Lens
USB connection port/
Video connection
terminal
Mode switch
Microphone
Speaker
Self-timer lamp/
Auto Focus lamp
Power button
LCD monitor
Camera status lamp
Strap eyelet
Zoom T button (Digital zoom)
Zoom W button (Thumbnail)
Play mode button
Tripod socket LCD button
+/-, DELETE
button
5-function button
Mirror for self portrait

11
Identification of features
Voice recording mode
A movie clip can be recorded for as long as the available
recording time of the memory capacity allows.
Image size and type are listed below.
- Image size : 640X480, 320X240 (user selectable)
- Movie clip file type : *. avi(MJPEG)
A voice recording can be recorded for as long as the
available recording time of the memory capacity allows.
(Max: 1 hour)
- File type : *.wav
Movie clip mode
You can select the desired working mode by using the mode switch located on the top of the
camera. This digital camera has 3 recording modes. These are listed below.
Battery holder
Memory card slot
Battery chamber
Battery chamber cover
FLASH/
LEFT button
MENU/ OK
button
MACRO/ DOWN button
PLAY&PAUSE button
SELF-TIMER/
RIGHT button
Voice memo/ UP button
Side/ 5-function button
Mode switch

12
Identification of features
Still image mode
You can select from AUTO( ), PROGRAM( ) or
SCENE mode.
In SCENE mode, you can select the NIGHT, PORTRAIT,
LANDSCAPE, TEXT RECOGNITION and FIREWORKS
scene menu.
Self-timer lamp
Icon Status Description
For the 2 seconds, the lamp blinks quickly at 0.25-second intervals.
For the first 7 seconds, the lamp blinks at 1 second intervals.
For the final 3 seconds, the lamp blinks quickly at 0.25-second intervals.
A picture will be taken after about 10 seconds and 2 seconds later a
second picture will be taken.
Camera Status Lamp
Function Description
The lamp turns on and off when the camera is ready to take a
The lamp blinks while saving the image data and turns off
when the camera is ready to take a picture
While movie recording The lamp blinks at a 1-second interval
While voice recording The lamp blinks at a 1-second interval
When the USB cable is inserted The lamp lights up (LCD monitor turns off)
Transmitting Data The lamp blinks (LCD monitor turns off)
Mode icons
MODE MOVIE CLIP VOICE RECORDING AUTO PROGRAM PLAY
Icon
NIGHT PORTRAIT LANDSCAPE TEXT FIREWORKS
Icon
MODE SCENE
Blinking
Blinking
Blinking
Power on
After taking a picture

13
Connecting to a Power Source
Important information about battery usage
When the camera is not used, turn off the camera power.
Do not recharge the non rechargeable batteries. It may cause an explosion.
Please remove the batteries if the camera will not be used for long periods.
Batteries can lose power over time and are prone to leaking if kept inside the camera.
Low temperatures (below 0°C) can affect the performance of the batteries and you may
experience reduced battery life.
Batteries will usually recover at normal temperatures.
During extended use of the camera, the camera body may become warm.
This is perfectly normal.
INFORMATION
We recommend using batteries for a digital camera (Within a year from the date of
manufacture). The batteries are listed below.
Non rechargeable batteries : CP1
Rechargeable batteries : SLB-1137

14
Connecting to a Power Source
Using the batteries
Battery status
Battery indicator
The batteries are fully
charged Prepare new batteries
There is no battery capacity.
Replace with new batteries.
There are 3 indicators for battery condition that are displayed on the LCD monitor.
Removing the battery
1. Turn off the camera power. Open the battery chamber
cover and move the battery holder aside. The battery will
be released.
2. Take out the battery and close the battery chamber cover.
:
If the camera does not turn on after you have inserted batteries, please
check whether the batteries are inserted with the correct polarity(+/-).
1. Open the battery chamber
cover by pushing in the
direction of the arrow.
2. Insert the batteries taking
note of the polarity (+ / -). 3. To close the battery chamber cover, push it
until it clicks.
When the battery chamber cover is opened, do not press the battery chamber cover by
force. This may cause the battery chamber cover modification or breakage.
INFORMATION

15
Instructions on how to use the memory card
Be sure to format the memory card (see p. 72) if you are using a newly purchased memory
for the first time, if it contains data that the camera cannot recognize, or if it contains images
captured with a different camera.
Turn off the camera power whenever the memory card is being inserted or removed.
Repeated use of the memory card will eventually reduce the memory card’s performance.
Should this be the case, you will need to purchase a new memory card.
Wear and tear on the memory card is not covered by the Samsung warranty.
The memory card is an electronic precision device.
Do not bend, drop or subject the memory card to any heavy impact.
Do not store the memory card in an environment with strong electronic or magnetic fields,
e.g. near loud speakers or TV receivers.
Please do not use or store in an environment where there are extremes in temperature.
Do not allow the memory card to become dirty or to come into contact with any liquid.
Should this happen, clean the memory card with a soft cloth.
Please keep the memory card in its case when not in use.
During and after periods of extended use, you may notice that the memory card is warm.
This is perfectly normal.
Do not use a memory card that is used in another digital camera or memory card reader.
Do not use a memory card formatted by another digital camera or memory card reader.
Maintenance of the memory card
Preserving the memory card data
If the memory card is subjected to any of the following, the recorded data may become
corrupted :
- When the memory card is used incorrectly.
- If the power is switched off or the memory card is removed while recording, deleting
(formatting) or reading.
Samsung cannot be held responsible for lost data.
It is advisable to copy important data onto other media as back-up e.g. floppy disks, hard
disks, CD etc.
If there is insufficient memory available : If you press the shutter button for the shot, a
[CARD FULL !] message will appear and the camera will not operate. To optimize the
amount of memory in the camera, replace the memory card or delete unnecessary images
stored on the memory.

16
Instructions on how to use the memory card
Don’t remove the memory card when the camera status lamp(Green) is blinking as this
may cause damage to data in the memory card.
INFORMATION
[ SD(Secure Digital) memory card ]
Write
protect
switch
Label
Card
pins
The camera can use SD Memory Cards and MMC (Multi Media Card).
The SD memory card has a write protect switch
that prevents image files from being deleted or
formatted. By sliding the switch to the bottom of
the SD memory card, the data will be protected.
By sliding the switch to the top of the SD
memory card, the data protection will be
canceled. Slide the switch to the top of the SD
memory card before taking a picture.
As this camera has a 16MB internal memory, you do not need to insert the memory card. To
expand memory capacity, insert a memory card. If the memory card is not inserted, an
image will be stored in the internal memory.
When using a 16MB internal memory, the specified shooting capacity will be as follows.
These figures are approximate as image capacities can be affected by variables such as
subject matter.
SUPER FINE FINE NORMAL 15FPS 24FPS
2560x1920 9 18 29 - -
2048x1536 10 24 38 - -
1600X1200 16 36 58 - -
1024X768 36 67 117 - -
640X480 72 121 214 - -
640X480 - - - 35SEC 20SEC
320X240 - - - 1MIN 25SEC 44SEC
STILL
Recorded image size
MOVIE
CLIP

17
Inserting the memory card
1. Turn the power off using the power button.
Open the battery chamber cover and press the memory
card as shown in the image and release.
2. Remove the memory card and close the battery chamber
cover.
3. To close, push the battery chamber cover until you hear a
click. If the memory card does not slide in smoothly, do not
attempt to insert it by force. Check the direction of insertion,
and then insert it correctly. Do not insert the memory card
the wrong way round. Doing so may damage the memory
card slot.
2. Have the front of the memory card facing toward the front
ofthe camera (lens) and the card pins toward the back of the
camera (LCD monitor), and then push the memory card into
the card slot until you hear a click.
1. Turn off the camera’s power and pull the battery chamber
cover in the direction of the arrow to open.
Removing the memory card

18
LCD monitor indicator
No. Description Icons Page
1 Battery p.14
2 Recording mode p.11~12,p.36
3 Continuous shot p.39
4 Flash p.27
5 Self-timer p.28
6 Macro p.25
7 Metering p.39
8 Card inserted indicator
9 Auto focus frame
10 Camera shake warning p.27
11 Date/ Time 2004/10/01 01:00 PM p.73 ~ 74
12 Exposure compensation LT p.29, p.32
13 White Balance p.30
14 ISO p.31
The LCD monitor displays information about the shooting functions and selections.
[ Image & Full Status ]

19
LCD monitor indicator
15 Sharpness p.42
16 Image quality p.38
17 Image size 2560, 2048, 1600, 1024, 640 p.37
Number of available shots remaining 18
Remaining time ( Movie clip/ Voice recording) 00:01:25 / 00:24:52 p.19~21
19 Digital zoom rate X5.0 p.23
20 Digital zoom bar
21 Voice memo p.24
Starting the recording mode
If the memory card is inserted in the camera, all the camera functions apply only to the
memory card.
If the memory card is not inserted in the camera, all the camera functions apply only to the
internal memory.
Recording a Movie clip
1. Insert the batteries (p.14). Insert the batteries taking note
of the polarity (+ / -).
2. Insert the memory card. (p.17) As this camera has a
16MB internal memory, you do not need to insert the
memory card. If the memory card is not inserted, an image
will be stored in the internal memory. To expand memory
capacity, insert a memory card. If the memory card is
inserted, an image will be stored on the memory card.
3. Close the battery chamber cover.
4. Press the power button to turn on the camera.
5. Select the MOVIE CLIP( ) mode by sliding the
mode switch.
6. Point the camera towards the subject and compose the
image by using the LCD monitor.
7. Press the shutter button to take a movie clip.
Press the shutter button once and movie clips are recorded for as long as the available
recording time allows. Movie clips will still be recorded if the shutter button is released. If
you wish to stop recording, press the shutter button again.
Image size and type are listed below.
- Image size : 640X480, 320X240 (Selectable)
- File type : *. avi(MJPEG)
[ MOVIE CLIP mode ]
18

20
Starting recording mode
Recording a still image
Steps from 1-4 are the same as those for recording a
movie clip.
5. Select the STILL IMAGE( ) mode by sliding the
mode switch.
6. Point the camera towards the subject and compose the
image by using the LCD monitor.
7. Press the shutter button to capture an image.
Recording Voice
Steps from 1-4 are the same as those for recording a
movie clip.
5. Select the VOICE RECORDING( ) mode by sliding
the mode switch.
6. Press the shutter button to record a voice.
- Press the shutter button once and voice is recorded for
as long as the available recording time(Max : 1 hour)
allows. The recording time will be displayed on the LCD
monitor.
- Voice will still be recorded if the shutter button is
released.
- If you wish to stop recording, press the shutter button
again.
- File type : *.wav
A distance of 40cm between you and the camera (microphone) is the best distance to
record sound.
INFORMATION
[ VOICE RECORDING mode ]
[ ]
If the auto focus frame turns to red when you press the shutter button down half way, it
means that the camera cannot focus on the subject. Should this be the case, the camera
is unable to capture an image clearly.
INFORMATION
START:SHUTTER
