Samsung SCC-B1091P User manual

User’s Manual
DIGITAL COLOR CAMERA
E
D
F
Sp
I
Pl
R
SCC-B1391(P)
SCC-B1091P
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`1

E
Important Safety Instructions
CAUTIO : TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE REAR
COVER. NO USER
SERVICEABLE PARTS INSIDE.
REFER TO QUALIFIED
SERVICE PERSONNEL.
To prevent damage which may result in fire or electric shock hazard,
do not expose this appliance to rain or moisture.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions.
1) This device may not cause harmful interference, and
2) This device must accept any interference that may cause undesired
operation.
CAUTION:
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
This symbo indicates
high vo tage is present
inside. It is dangerous to
make any kind of contact
with any inside part of this
product.
This symbo a erts you
that important iterature
concerning operation and
maintenance has been
inc uded with this product.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
2
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`2

3
E
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, or other apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being from being walked on or
pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a used,
caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-
over.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or been dropped.
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`3

4
E
Chapter 1 Introduction ........................................................ 5
Chapter 2 Specia Features ............................................. 6
Chapter 3 Insta ation ......................................................... 7
Checking the contents of the package .............. 7
Precautions in Insta ation and Use ................... 8
Connecting Auto Iris Lens Connector ................ 9
Lens Fixing ........................................................... 10
Setting Lens Se ection Switch .................... 11
Back Focus Adjustment ................................ 11
Connecting Cab es and Checking Operation .....13
Chapter 4 Part Names and Functions ............................... 15
Product Specification ........................................ 20
Contents
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`4

5
E
This camera is the high-reso ution monitoring camera of 540 TV Lines and can
provide the best monitoring function by connecting with the CCTV System.
❉ In the mechanica f uorescent ight environment, if you attach MANUAL IRIS
LENS and turn the ELC switch among FUNCTION switches on, co or may be
ro ed.
In this case, supp y AC power before you turn L/L switch among FUNCTION
switches on. (NTSC:60HZ , PAL:50HZ)
Chapter 1 Introduction
COLOR ROLLING is the prob em that coor on the
monitor screen changes non-periodica y.
This happens when White Ba ance is not fixed,
because a mechanica fuorescent ight f ickers
when it’s cyc e is the same to the cyce of the power
frequency.
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`5

6
E
High Sensitivity
It has an up-to-date 1/3" Super-HAD IT CCD for an image of high sensitivity.
Resolution
It rea izes high reso ution resu ting from fu digita image processing
supported by a state-of-art digita signa techno ogy.
Superior Back Light Adjustment Function
In case the object has a bright i umination or sun ight behind it, this camera
adjusts the image shaded by the back ight for c ear photographs.
Digital Power Supply Synchronization Method
The Fu Digita Method Line Lock is rea ized in this camera, which adjusts
the vertica camera synchronization direct y to improve contro abi ity and
re iabi ity of the camera.
Chapter 2 Special Features
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`6

7
E
This chapter describes what shou d be checked before insta ation, how to
set the insta ation environment, and what shou d be done during insta ation.
Then, it describes how to insta the camera and connect the cab e in actua
circumstances.
Chapter 3 Installation
Be sure to check if the fo owing items are inc uded in the package.
Checking the contents of the package
Camera
Ho der(Mount)
C Mount Adapter Auto Iris
Lens Connector
User's Manua
Camera
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`7

8
E
① Do not attempt to disassemb e the camera yourse f.
➁Be cautious in hand ing the camera. Avoid striking or shaking the
camera. Be cautious to avoid damage on the camera caused by improper
storage or operation.
➂Do not expose this camera to rain or moisture. Do not operate this
camera on a wet p ace.
➃ Do not use strong or abrasive detergents when c eaning the camera
body. Use a dry c oth to c ean the camera.
⑤ Keep the camera at a coo p ace away from the direct sun ight. Leaving it
under the direct sun ight may resu t in the ma function of the unit.
Precautions in Installation and Use
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`8

9
E
Connecting Auto Iris Lens Connector
Prepare the fo owing Auto Iris Lens Connector suppied with the camera.
Connect the cab e of the contro cab e, whose covering is stripped, to the
Auto Iris Lens Connector as shown be ow.
Rb
Pin3
Pin2
Pin4
Pin1
Pin No. DC Contro Type VIDEO Contro Type
1 Damp(-) Power (+12V)
2 Damp(+) N/A
3 Drive(+) VIDEO Signa
4 Drive(-) GROUND
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`9

In case of CS lenses
Turn the CS ens c ockwise unti it is fixed as shown as fo ows.
In case of C lenses
Turn the C-mount adapter c ockwise to fix it. Then turn the C ens
c ockwise unti it is fixed as fo ows.
Lens Fixing
CS lens
C lens
10
E
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`10

Back Focus Adjustment
Setting Lens Selection Switch
11
E
The camera back focus is adjusted at the p ant before de ivery, but some
enses are out of focus though the number differs in types. If it's the case,
you shou d make the back focus adjustment as fo ows. First, this is the back
focus adjustment procedure for fixed focus enses.
Lenses without zoom function
① Image an object with high reso ution( etticed) at more than 10m distance
and put the ens focus ring in the infinite(∞) position.
➁Rotate the BACK FOCUS contro bar unti the object is seen best.
➂Tighten the BACK FOCUS contro bar fixing screw.
When ens mounting is comp eted, set the Lens se ection Switch on the side
of the camera according to the mounted ens type. When the mounted ens
is an Auto Iris Lens of the DC contro type, set the Lens Se ection Switch to
"DC". When the mounted ens is an Auto Iris Lens of the Video contro type,
set the Lens Se ection Switch to "VIDEO".
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`11

12
E
Lenses with zoom function
① Image an object with high reso ution( etticed) at a distance of 3 to 5 m
and zoom in the ens as c ose to TELE as possib e. Then adjust the ens
focus bar unti the object is seen best.
➁Zoom in the ens as c ose to WIDE as possib e and adjust the BACK
FOCUS adjustment bar unti the object is seen best.
➂Repeat from ①to ➁above 2 or 3 times unti the focus on the ZOOM
TELE side is in ine with that on the ZOOM WIDE side.
BACK FOCUS
CONTROL BAR
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`12

Connecting Cables and Checking Operation
13
E
1 First, connect the connector of the BNC cab e to the Video Out termina
2 Second, connect the other connector of the BNC cab e to the Video In
termina .
BNC cab e
Video Out Termina
Video In Termina of
Monitor Rear Surface
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`13

14
E
3 Third, connect the power cab e.
①AC24V/DC12V Power Input Camera.
Connect 2 ines of the power adapter using a screwdriver to the power
IN Termina of the camera as shown be ow.
❉ Without the distinction of the po arity, connect to the AC24 or DC12V
power source.
➁AC230V Power Input Camera
Connect the power input cord to the AC230V power source.
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`14

15
E
Chapter 4 Part Names and Functions
Side View
① Mount Adapter Fixing Groove
This groove is used for screwing the mount adapter, a part of the bracket where the
camera wi be insta ed.
➁ Camera Lens(Option)
This ens is insta ed in the camera.
❉ A camera ens with a stained surface shoud be c eaned soft y with a ens
tissue or ethano painted cotton coth.
➂ Auto Iris Lens Connector
This connector provides the automatic shutter ens with power suppy, contro signa ,
video signa , or DC signa necessary for the contro of the ens shutter.
➃ Auto Iris Lens Control Cable
This cab e transmits signa which contro s the Iris.
⑤ ALC Lens Selection Switch
This Switch is used for se ect the type of Lens.
➅ Back Focus Control Bar
This bar is used for set back focus of the camera.
➃ Auto Iris Lens
Contro Cabe
⑤ ALC Lens
Se ection Switch
➂ Auto Iris Lens
Connector
① Mount Adapter Fixing
Groove
➅ Back Focus
Contro Bar
➁ Camera Lens
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`15

Rear View
16
E
AC24V/DC12V Camera (SCC-B1391(P))
AC230V Camera (SCC-1091P)
⑤
➁
➅
⑦
①
➂ ➃
⑤
①
➂ ➃ ⑦
➁
➅
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`16

17
E
①Power connection port
AC24V/DC12V Camera : It is a port connected to the power adaptor cab e.
AC230V Camera : It is Power cord.
➁POWER LED
If the power of a camera is supp ied norma y, the LED is ON.
➂➃I C and DEC Switch
Both switches increase or decrease the profit of RED and BLUE to fix a co or
temperature as you wish whi e AWB among the FUNCTION switches is
off(USER) and contro the vertica synchronous phase whi e both AWB and
L/L are on.
⑤FU CTIO Switch
1. L/L 2. ELC
3. FL 4. AWB
SW1 SW2 SW3 SW4
ON
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`17

18
E
1) SW1(L/L) :
Set to OFF, the camera activates the interna synchronization mode and set to ON, the power
synchronization mode. If you connect muti cameras to the sequentia switcher to enter the
automatic conversion mode, the screen wi bounce every screen whie the camera stays in
INT(interna synchronization). Such bouncing phenomena may be ceared and screen conversion
becomes smooth by setting the L/L switch to ON and using the INT/DEC switch to contro the
vertica synchronous phase.
❉ If you want to contro the vertica synchronous phase with the INT/DEC switch when L/L is set
to ON, you sha set SW4 to AWB ON.
❉ In case of DC12V, INT(interna synchronizer) wi be fixed without regard to ON/OFF of L/L.
2) SW2(ELC) :
Use this switch with the Manua Iris Lens. Whie this switch is ON, the speed of the e ectronic
shutter varies with the brightness of the subject from 1/60(50) to 1/100,000 sec for automatica y
contro ing the brightness of the screen. However, with the Auto Iris Lens (DC or Video Contro),
be sure to switch OFF.
Coor Ro ing may occur in this mode. In that case, input AC power source to the camera and
seect SW1 "ON".
(NTSC : 60HZ, PAL : 50HZ)
3) SW3(FL):
This is to prevent ficker on the screen when NTSC system is used in 50HZ power suppy region
and PAL system is used in 60HZ power suppy region. That is to prevent shaking on the
screen resuted from the discordance of the vertica sync frequency and the f icker frequency of
the i umination. Whie this switch is ON, the eectronic shutter is fixed to 1/100sec (NTSC) or
1/120 sec (PAL).
4) SW4(AWB):
When setting up ON, the coor of screen is adjusted automatica y in accordance with the change
of ighting coor temperature by the change of outer environment. (ATW) If the ighting condition is
steady, OFF setting is avaiabe. The camera memorizes the ighting coor temperature at the
time when the switch setting is changed from ON to OFF, and the camera coor is adjusted to the
memorized coor temperature. (AWC) If the ighting co or temperature is changed and you want
to make the camera be memorized/operated with the changed coor temperature, re-operate the
switch On/Off operation. However, be aware that an error may occur under the fo owing
conditions.
First, a case that the subject is big, singe coor of the high chroma, and in the center of
the screen or a case with amost no white coor on the screen.
Second, a case with a specific i umination such as a natrium amp
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`18

19
E
➅ DC IRIS Level Controller
When the ALC ens se ection switch is set to DC, use the same contro bar as the
driver to contro the IRIS eve .
⑦ Video Output Port
This port sha be connected to the monitor video input port or equiva ent. You
may output camera video signa s through this port.
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`19

20
E
Product Specification
SCC-B1391P/B1091P
ITEM Contents
Product Type CCTV Camera
Broadcasting System PAL STANDARD SYSTEM
CCD 1/3 Super-HAD CCD
Effective Pixe s 752(H) x 582(V)
Scanning Type 625 Line, 2:1 Inter ace
INTERNAL : 15,625Hz(H)
50 Hz(V)
LINE LOCK : 15,625Hz(H)
50 Hz(V)
INTERNAL
LINE LOCK(When AC Power source is used)
Reso ution(H) 540 TV Lines
S/N Ratio About 50dB
Frequency
Sync Type
Minimum I umination
of Object 0.3 Lux
(AB68-00512B)SCC-B1391-01Eng 2005.6.174:7PM ˘`20
