Samsung Digimax U-CA User manual

Thank you for buying a Samsung Camera. This manual will guide you through using the camera,
including capturing images, downloading images and using the application software.
Please read this manual carefully before using your new camera.
User's Manual
ENGLISH

2
Instructions
Use this camera in the following order
Insert the
USB cable
Set up the
camera driver
Before connecting the camera to a PC, via the USB
cable, you will need to set up the camera driver.
Install the camera driver that is contained in the
Application S/W CD-ROM.(p.94)
Take a picture (p.21)
Insert the supplied USB cable into the PC’s USB port
and the camera’s USB connection terminal.(p.109)
Check the camera’s power
If the power is turned off, press the camera button to
power it on.(p.24)
Take a picture
Check the
camera’s power
Check
[Removable Disk]
Open Window s EXPLORER and search for
[Removable Disk].(p.110)
To play back a video shot with this camera, be sure to use the QuickTime player supplied on
the software CD-ROM. Applications that do not support the MPEG-4 codec
(e.g., Windows Media Player) may not be able to play back the video.
If you use a card reader to copy the images on the memory card to your PC, the images could be
damaged. When transferring the images taken with the camera to your PC, be sure to use the
supplied USB cable to connect the camera to your PC. Please note that the manufacturer holds no
responsibility for loss or damage of images on the memory card due to the use of a card reader.

3
Getting to know your camera 5
About the icons 5
Danger 6
Warning 6
Caution 7
An FCC warning 7
This digital camera can be used for 8
Manufacturer's contents 10
Identification of features 11
Front & Top 11
Back & Bottom 11
Side/ 5-function button 12
Mode switch 12
Lamp 13
Connecting to a Power Source 13
Using the AC power adapter (3.3V 2.0A) 14
Using the batteries 15
Removing the battery 15
Precautions on Using the Memory Stick Duo 16
Inserting the memory card 18
Removing the memory card 18
When Using the Camera for the First Time 19
LCD monitor indicator 20
Starting the recording mode 21
Things to watch out for when taking pictures 23
Using the camera buttons to
adjust the camera 24
POWER button 24
SHUTTER button 24
WIDE/TELE button 24
Voice memo/UP button 26
Recording a voice memo 26
Macro/Down button (Focusing) 27
Focus lock 28
FLASH/LEFT button 28
Self-timer/Right button 30
MENU/OK button 31
+/- button 31
LCD button 35
Using the LCD monitor to adjust the
camera settings 36
How to use the menu 37
Mode 38
Size 38
Quality 39
Metering 40
Effect 40
Sharpness 41
Starting play mode 42
Playing back a still image 42
Playing back a movie clip 43
Playing back a recorded voice 43
LCD monitor indicator 44
Using the camera buttons to
adjust the camera 45
Thumbnail/Enlargement button 45
Voice memo/Up button 46
Play & Pause/Down button 47
LEFT/RIGHT/MENU/OK button 48
LCD button 48
Contents
READY
RECORDING
PLAY

4
Delete button 49
Setting up the play back function using the
LCD monitor 50
Deleting all images 52
Protecting images 52
Starting the slide show 53
Resize 54
Rotating an image 55
DPOF: PRINT ORDER 55
DPOF: STANDARD 56
DPOF: INDEX 56
DPOF: PRINT SIZE 57
DPOF: CANCEL 57
PictBridge 58
PictBridge: Picture Selection 59
PictBridge: Print Setting 60
PictBridge: Picture Printing 61
PictBridge: DPOF AUTO PRINT 62
PictBridge: RESET 62
Setup menu 63
File name 64
Auto power off 65
Language 66
Formatting a memory card 66
Setting up the Date/Time/Date type 67
Imprinting the recording date 67
Function lamp 68
Sound 69
LCD brightness 69
Selecting Video out type 70
Quick view 71
Connecting an External Device(USB) 72
Initialization(RESET ALL) 72
Setting up the MYCAM menu 73
Avatar 73
Start up image 75
Start up sound 76
Shutter sound 76
List of camera functions 77
Important notes 83
Warning indicator 85
Before contacting a service center 86
Specifications 89
Software Notes 91
About the software 92
Setting up the application software 94
DigiStudio Installation guide 104
DigiStudio Installation 106
Starting PC mode 109
Removing the USB Driver for
Windows 98SE 112
Removable Disk 113
Removing the removable disk 114
Setting up the USB Driver for MAC 115
Using the USB Driver for MAC 115
Digimax Viewer 2.1 116
Using PhotoImpression 117
Using VideoImpression 119
FAQ 123
Contents
SOFTWARE
SETUP

5
Thank you for buying a Samsung Digital Camera.
Prior to using this camera, please read the user manual thoroughly.
When you require After Sales service, please bring the camera and the cause of the camera
malfunction (such as Batteries, Memory card etc.) to the A/S center.
Please check that the camera is operating properly prior to when you intend to use it (e.g. for a
trip or an important event) to avoid disappointment. Samsung camera takes no responsibility
for any loss or damages that may result from camera malfunction.
Keep the manual in a safe place.
Microsoft, Windows and Windows logo are registered trademarks of Microsoft Corporation
incorporated in the United States and/or other countries.
Apple, Mac and QuickTime logo are registered trademarks of Apple computer.
Memory Stick Duo is a registered trademark of Sony Corporation.
All brand and product names appearing in this manual are registered trademarks of their
respective companies.
Getting to know your camera
This manual contains instructions on using this camera that will help you to use this camera safely
and correctly. This will help prevent danger and injury to others.
About the icons
DANGER
DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation, which, if not avoided, may
result in a minor or moderate injury.

6
Do not attempt to modify this camera in any way. This may result in fire, injury, electric shock
or severe damage to you or your camera. Internal inspection, maintenance and repairs should
be carried out by your dealer or Samsung Camera Service Center.
Please do not use this product in close proximity to flammable or explosive gases, as this could
increase the risk of explosion.
Should any form of liquid or a foreign object enter the camera, do not use it. Switch off the
camera, and then disconnect the power source (batteries or AC Power Adapter). You must
contact your dealer or Samsung Camera Service Center. Do not continue to use the camera
as this may cause a fire or electric shock.
Do not insert or drop metallic or inflammable foreign objects into the camera through access
points e.g. the memory card slot and battery chamber. This may cause a fire or electric shock.
Do not operate this camera with wet hands. This could pose a risk of electric shock.
Danger
Do not use the flash in close proximity to people or animals. Positioning the flash too close to
your subject’s eyes, may cause eyesight damage.
When taking photographs, never point the lens of the camera directly into very strong light. This
may result in permanent damage to your eyesight.
For safety reasons keep this product and accessories out of reach of children or animals to
prevent accidents e.g.:
Swallowing batteries or small camera accessories. If an accident should occur, please
consult a doctor immediately.
There is the possibility of injury from the camera’s moving parts.
Batteries and camera may become hot during prolonged use and it may result in camera
malfunction. Should this be the case, allow the camera to sit idle for a few minutes to allow it
time to cool.
Do not recharge non rechargeable batteries. This may cause an explosion.
Do not leave this camera in places subject to extremely high temperatures, such as a sealed
vehicle, direct sunlight or other places of extreme variances in temperature. Exposure to
extreme temperatures may adversely affect the camera s internal components and could
cause a fire.
When in use, do not cover the camera or AC Power Adapter. This may cause heat to build up
and distort the camera body or cause a fire. Always use the camera and its accessories in a
well-ventilated area.
Warning

7
Leaking, overheating, or burst batteries could result in fire or injury.
Use batteries with the correct specification for the camera.
Do not short circuit, heat or dispose of batteries in fire.
Do not insert the batteries with the reverse polarities.
Remove the batteries when not planning to use the camera for a long period of time.
Batteries may leak corrosive electrolyte and irreparably damage the camera's components.
Do not fire the flash while it is in contact with hands or objects. Do not touch the flash after
using it continuously. It may cause burns.
Do not move the camera while it is switched on, if you are using the AC Power Adapter.
After use, always switch off the camera before unplugging the adapter from the wall socket.
Then make sure that any connector cords or cables to other devices are disconnected before
moving the camera. Failure to do so may damage the cords or cables and cause a fire or
electric shock.
Caution
An FCC warning
This device has been tested in accordance with the limits of a class B digital device under
item 15 of the FCC rules. These limits are designed to provide protection against harmful
interference in commercial installation. This equipment generates, absorbs and can emit
radio frequency energy. If it is not installed and used in accordance with the instructions, it
may cause harmful interference to radio communication. There is however, no guarantee
that interference will not occur in some situations. Should any interference occur when this
device is in operation, please try one or more of the following measures.
Change the location and direction of any aerial.
Increase distance between the camera and the affected device.
Use a different socket away from the affected device.
Please contact a Samsung agent or a radio/TV engineer.
This device complies with part 15 of the FCC Rules.
Changes or modifications not expressly approved by the party responsible for compliance
could void user's authority to operate the equipment.

8
This digital camera can be used for
Printing images using a dedicated printer,
DPOF and PictBridge compatible printer or a
DPOF-equipped photo lab.
(refer to page 55~62)
Down loading image files from
camera to computer.
(refer to page 110)
Editing images on a PC.
Viewing images on a TV.
(refer to page 70)
Taking a picture.
(refer to page 20~41)

9
This digital camera can be used for
Inserting images directly into any
electronic document.
Taking a self-portrait and using the image
to personalize calendar.
You can even create your own unique gift wrap
paper by using your digital images.
Creation of a digital photo album.
Recording your voice.
(refer to page 22) Recording a movie clip
(refer to page 21)

10
Manufacturer's contents
Please check that you have the correct contents before using this product.
marked contents are optional.
Digital Camera USB cableAV cablePouch Camera strap
Software CD DigiStudioProduct warrantyUser manual
Duracell CP-1
battery AC adapter (3.3V)
Memory Stick Duo/
Case/Adapter
Battery charger AC cord Rechargeable battery
Digimax Battery Pack : SLB-1037A KIT

11
Identification of features
Front & Top
Back & Bottom
Mode switch
Viewfinder
Auto Focus
lamp
Microphone
Strap eyelet
Speaker
Lens
Power button
Flash
Shutter button
Function lamp
LCD
monitor
Viewfinder Camera status lamp
WIDE/THUMBNAIL button
TELE/Digital zoom button
+&-/ DELETE button
USB/ AV
connection terminal
DC input
connection point
Tripod socket
LCD button
PLAY mode
button
* When using the digital zoom to take a picture, the composition of the picture may be different
depending on whether you are using the LCD monitor or the viewfinder. The picture will be taken
in the composition of the picture as it appears on the LCD monitor.

12
Identification of features
Voice recording mode
A movie clip can be recorded for as long as the available
recording time of the memory capacity allows.
Image size and type are listed below.
- Image size : 320X240, 160X120
- Movie clip file type : *.mov (MPEG4)
A voice recording can be recorded for as long as the
available recording time of the memory capacity allows.
(Max: 1 hour)
- File type : *.wav
Movie clip mode
You can select the desired working mode by using the mode switch located on the top of the
camera. This digital camera has 3 recording modes. These are listed below.
FLASH/
LEFT
button MENU/ OK
button
MACRO/PLAY&PAUSE/
DOWN button
SELF-TIMER/
RIGHT button
Voice memo/ UP button
Side/ 5-function button
Mode switch
Battery chamber
Battery holder
Memory card slot
Battery chamber cover

13
Identification of features
Still image mode
There are two ways in which to provide the camera with power. You can use batteries or
alternatively, you can use an AC(100 ~ 250V) Adapter (DC 3.3V 2.0A).
We recommend using batteries for a digital camera.
(use batteries that are within a year of their date of manufacture) The batteries are listed below.
Non rechargeable batteries : Duracell CP-1 battery
Rechargeable batteries : SLB-1037
Lamp
Connecting to a Power Source
You can select from Auto, Manual, or Night mode. In Manual
mode, any changes made to settings other than Self-Timer and
Voice Recording will be maintained even after the camera is
turned off.
Type Operation Lamp Camera Status Lamp LCD Monitor
When turning on the power
7 color lights blink and then turns off when
the camera is ready to take a picture
Blinks orange
X
When the camera is in focus (when the
SHUTTER button is pressed halfway)
X Green lamp lights up Autofocus mark
lights up green
When the camera is out of focus (when the
SHUTTER button is pressed halfway)
X Green lamp blinks Autofocus mark
lights up red
While the flash is charging X Red lamp blinks X
While saving an image X Green lamp blinks X
While shooting a video
Purple lamp blinks at a 1-second interval X Auto focus frame : White
During voice recording
Blue lamp blinks at a 1-second interval X X
While the camera is connected to a PC
X Green lamp lights up X
While transferring data between the camera and a PC X Green lamp blinks X
When shooting an image
Green Lamp Blinks once. X X
Flash is ready (when the SHUTTER
button is pressed halfway)
X Orange lamp lights up X
While the self-timer is running
Red lamp blinks for 7 seconds at a 1-second interval/blinks
for 3 seconds at a 0.25 second interval
X X
When the LCD monitor is
turned off in Still Image mode
Green lamp lights up XX

14
Connecting to a Power Source
Important information about battery usage
A non-rechargeable (disposable) battery can be used, but has a short lifespan because
of its relatively low battery capacity. We recommend the rechargeable battery, which
has a bigger capacity and longer lifespan than the non-rechargeable type.
(Rechargeable batteries may not be available everywhere).
Do not recharge the non rechargeable batteries. This may cause an explosion.
Please remove the batteries if the camera will not be used for long periods.
Batteries can lose power over time and are prone to leaking if kept inside the camera.
Low temperatures (below 0 ) can affect the performance of the batteries and you may
experience reduced battery life.
Batteries will usually recover at normal temperatures.
During extended use of the camera, the camera body may become warm.
This is perfectly normal.
If you are planning to use this camera for long periods of time, it is advisable to use an
AC adapter (3.3V 2.0A).
INFORMATION
If you have access to a mains supply, using an AC
Adapter (3.3V 2.0A) allows the camera to be used for
long periods of time.
Plug the adapter into the connection point (DC IN
3.3V) on the camera.
Remove the batteries from the camera when using an
AC adapter.
Using the AC power adapter (3.3V 2.0A)
Always turn off the power before taking the AC adapter out of the mains supply.
As with all mains powered devices, safety is important. Ensure that neither the camera
nor adapter comes into contact with water or metallic materials.
Please ensure that you use an AC adapter (3.3V 2.0A) with the correct specification for
the camera. Failure to do so may affect your warranty.
DANGER

15
Connecting to a Power Source
Using the batteries :
If the camera does not turn on after you have inserted batteries, please
check whether the batteries are inserted with the polarity(+ and-).
Battery status
Battery indicator
The batteries are fully
charged. Prepare new batteries. There is no battery
capacity. Replace with
new batteries.
There are 3 indicators for battery condition that are displayed on the LCD monitor.
Removing the battery
1. Turn off the camera power. Open the battery chamber cover
and move the battery holder aside. The battery will be
released.
2. Take out the battery and close the battery chamber cover.
1. Open the battery chamber
cover by pushing in the
direction of the arrow.
2. Insert the batteries according
to the polarity marks (+ and -)
on the back of the battery
chamber cover.
3. To close the battery
chamber cover, push it
until it clicks.

16
Precautions on Using the Memory Stick Duo
Do not insert the Memory Stick Duo on its own into a Memory Stick-compatible device.
Do not insert the Memory Stick Duo adapter into a Memory Stick-compatible device without
attaching the Memory Card Duo to the adapter. Using it without the Memory Stick Duo may
adversely affect the device into which it is inserted.
Be sure to check the proper direction of insertion before use .
Insert the Memory Stick Duo all the way into the Memory Stick Duo adapter.
If the Memory Stick Duo is not inserted correctly into the adapter, it may not operate properly.
Do not attach labels to any part of the Memory Stick Duo and Memory Stick Duo adapter. The
labels may come off as you insert the Memory Stick Duo into the adapter or into a Memory
Stick-compatible device.
When inserting the Memory Stick Duo into the slot, do not force or bend it.
Do not touch the Memory Stick Duo adapter's card pins with your fingers or with metal objects.
Do not allow dirt or foreign material to get into the Memory Stick Duo adapter slot.
Do not leave the Memory Stick Duo with its adapter in areas subject to high temperatures.
Those models with the write-protect switch on the back of the card prevents accidental erasure
of data from deletion or formatting. By sliding the switch to the top of the memory card, the data
will be protected. By sliding the switch to the bottom of the memory card, the data protection
ability will be canceled. Please use a pointed object to move the write-protect switch. Slide the
switch to the bottom of the memory card before taking a picture.
Card pins(A)
Write
protect
switch(B)
Label(C)
[ Memory Stick Duo ]
FrontBack
Some models of Memory Stick Duo media do not have the write-protect switch (B).
Do not touch the card pins (part A) with
your fingers or with metal objects.
Do not press hard when writing on the
label (part C).
If you insert the Memory Stick Duo into
the Memory Stick Duo adapter, you will
be able to use it with a Memory Stick-
compatible device.

17
Precautions on Using the Memory Stick Duo
Maintenance of the Memory Stick Duo
(Hereafter the Memory Stick Duo is referred to as the "Memory Card".)
Be sure to format the memory card (see p. 66) if you are using a newly
purchased memory for the first time, if it contains data that the camera
cannot recognize, or if it contains images captured with a different camera.
Turn off the camera power whenever the memory card is being inserted or removed.
Repeated use of the memory card will eventually reduce the memory card's performance.
Should this be the case, you will need to purchase a new memory card.
Wear and tear on the memory card is not covered by the Samsung warranty.
The memory card is an electronic precision device. Do not bend, drop or subject the memory
card to any heavy impact.
Do not store the memory card in an environment with strong electronic or magnetic fields, e.g.
near loud speakers or TV receivers.
Please do not use or store in an environment where there are extremes in temperature.
Do not allow the memory card to become dirty or to come into contact with any liquid. Should
this happen, clean the memory card with a soft cloth.
Please keep the memory card in its case when not in use.
During and after periods of extended use, you may notice that the memory card is warm.
This is perfectly normal.
Do not use a memory card that has been used in another digital camera or memory card reader.
Do not use a memory card formatted by another digital camera or memory card reader.
Preserving the memory card data
Do not remove the memory card while the camera status lamp (green) is blinking.
Doing so will corrupt the data on the memory card.
Samsung cannot be held responsible for lost data.
It is advisable to copy important data onto other media as back-up e.g. floppy disks, hard disks,
CD etc.
If there are no shots remaining
When you press the shutter button, a [CARD FULL !] message is displayed and the camera will
not operate. To optimize the amount of memory in the camera, replace the memory card or
delete unnecessary images stored in the memory.

18
Inserting the memory card
1. Turn off the camera’s power and pull the memory card
cover in the direction of the arrow to open.
2. Have the front of the memory card facing toward the front
of the camera (lens) and the card pins toward the back of
the camera (LCD monitor), and then push the memory
card into the card slot until you hear a click.
3. To close, push the card cover until you hear a click. If the
memory card does not slide in smoothly, do not attempt to
insert it by force. Check the direction of insertion, and then
insert it correctly.
1. Turn the power off using the power button.
Open the battery chamber cover and press the memory
card as shown in the image and release.
2. Remove the memory card and close the memory card
cover.
Do not insert the memory card the wrong way round . Doing so may damage the
memory card slot.
INFORMATION
Removing the memory card

19
When Using the Camera for the First Time
If the camera is turned on for the first time, a menu will be displayed to set date, time and
language in the LCD monitor. This menu will not be displayed after setting up the date, time
and language. Set up the date, time and language before using this camera.
Setting up the date, time and date type
1. Select the [DATE.TIME] menu by pressing the UP/DOWN
button and press the RIGHT button.
2. Select the desired sub menu by pressing the UP/ DOWN/
LEFT/ RIGHT button.
RIGHT button : selects YEAR/ MONTH/ DAY/ HOUR /
MINUTE/DATE TYPE
LEFT button : Moves the cursor to the [DATE/TIME]
main menu if the cursor is at the first
item of the date and time setup. In all other instances, the cursor will be
shifted to the left of its current position.
UP/ DOWN button : changes the value of each item.
Date setting range : 2004/01/01 ~ 2050/12/31
(Leap years and months are corrected automatically)
You will need to check and select the correct Date / Time when the batteries have been
removed for a period longer than 1 hour.
INFORMATION
You can select 17 languages. These are listed below:
English, Korean, French, German, Spanish, Italian, S. Chinese, T. Chinese, Japanese,
Russian, Portuguese, Dutch, Danish, Swedish, Finnish, Thai, and Malaysian.
Even if the camera is restarted, the language setting will be maintained.
INFORMATION
Setting up the language
1. Select the [LANGUAGE] menu by pressing the
UP/DOWN button and press the RIGHT button.
2. Select the desired sub menu by pressing the UP/ DOWN
button and press the OK button. When the settings are
complete, press the MENU button twice to exit the menu
screen.
DATE.TIME
LANGUAGE
SETUP
SETUP
MOVE: SET:OK
04/01/01 12:00
YY/MM/DD
DATE.TIME
LANGUAGE
MOVE: SET:OK
ENGLISH
FRANÇAIS

20
LCD monitor indicator
The LCD monitor displays information about the shooting functions and selections.
[ Image & Full Status ]
No. Description Icons Page
1 Battery p.15
2 Recording mode p.12~13
3 Camera shake warning p.23
4 Flash p.29
5 Self-timer p.30
6 Voice memo p.26
7 Macro p.27
8 Metering p.40
9 Auto focus frame
10 Time 01:00 PM p.19, 67
11 Date 2004/07/01 p.19, 67
12 Exposure compensation p.31
13 White Balance p.32
