Samsung SCC-B1391 User manual

User’s Manual
DIGITAL COLOR CAMERA
E
D
F
Sp
I
Pl
R
SCC-B1391(P)
SCC-B1091P

E
Important Safety Instructions
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE REAR
COVER. NO USER
SERVICEABLE PARTS INSIDE.
REFER TO QUALIFIED
SERVICE PERSONNEL.
To prevent damage which may result in fire or electric shock hazard,
do not expose this appliance to rain or moisture.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions.
1) This device may not cause harmful interference, and
2) This device must accept any interference that may cause undesired
operation.
CAUTION:
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
This symbol indicates
high voltage is present
inside. It is dangerous to
make any kind of contact
with any inside part of this
product.
This symbol alerts you
that important literature
concerning operation and
maintenance has been
included with this product.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
2

3
E
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, or other apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being from being walked on or
pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a used,
caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-
over.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or been dropped.

4
E
Chapter 1 Introduction ........................................................ 5
Chapter 2 Special Features ............................................. 6
Chapter 3 Installation ......................................................... 7
Checking the contents of the package .............. 7
Precautions in Installation and Use ................... 8
Connecting Auto Iris Lens Connector ................ 9
Lens Fixing ........................................................... 10
Setting Lens Selection Switch .................... 11
Back Focus Adjustment ................................ 11
Connecting Cables and Checking Operation ..... 13
Chapter 4 Part Names and Functions ............................... 15
Product Specification ........................................ 20
Contents

5
E
This camera is the high-resolution monitoring camera of 540 TV Lines and can
provide the best monitoring function by connecting with the CCTV System.
❉ In the mechanical fluorescent light environment, if you attach MANUAL IRIS
LENS and turn the ELC switch among FUNCTION switches on, color may be
rolled.
In this case, supply AC power before you turn L/L switch among FUNCTION
switches on. (NTSC:60HZ , PAL:50HZ)
Chapter 1 Introduction
COLOR ROLLING is the problem that color on the
monitor screen changes non-periodically.
This happens when White Balance is not fixed,
because a mechanical fluorescent light flickers
when it’s cycle is the same to the cycle of the power
frequency.

6
E
High Sensitivity
It has an up-to-date 1/3" Super-HAD IT CCD for an image of high sensitivity.
Resolution
It realizes high resolution resulting from full digital image processing
supported by a state-of-art digital signal technology.
Superior Back Light Adjustment Function
In case the object has a bright illumination or sunlight behind it, this camera
adjusts the image shaded by the back light for clear photographs.
Digital Power Supply Synchronization Method
The Full Digital Method Line Lock is realized in this camera, which adjusts
the vertical camera synchronization directly to improve controllability and
reliability of the camera.
Chapter 2 Special Features

7
E
This chapter describes what should be checked before installation, how to
set the installation environment, and what should be done during installation.
Then, it describes how to install the camera and connect the cable in actual
circumstances.
Chapter 3 Installation
Be sure to check if the following items are included in the package.
Checking the contents of the package
Camera
Holder(Mount)
C Mount Adapter Auto Iris
Lens Connector
User's Manual
Camera

8
E
① Do not attempt to disassemble the camera yourself.
➁Be cautious in handling the camera. Avoid striking or shaking the
camera. Be cautious to avoid damage on the camera caused by improper
storage or operation.
➂Do not expose this camera to rain or moisture. Do not operate this
camera on a wet place.
➃ Do not use strong or abrasive detergents when cleaning the camera
body. Use a dry cloth to clean the camera.
⑤ Keep the camera at a cool place away from the direct sunlight. Leaving it
under the direct sunlight may result in the malfunction of the unit.
Precautions in Installation and Use

9
E
Connecting Auto Iris Lens Connector
Prepare the following Auto Iris Lens Connector supplied with the camera.
Connect the cable of the control cable, whose covering is stripped, to the
Auto Iris Lens Connector as shown below.
Rb
Pin3
Pin2
Pin4
Pin1
Pin No. DC Control Type VIDEO Control Type
1 Damp(-) Power (+12V)
2 Damp(+) N/A
3 Drive(+) VIDEO Signal
4 Drive(-) GROUND

In case of CS lenses
Turn the CS lens clockwise until it is fixed as shown as follows.
In case of C lenses
Turn the C-mount adapter clockwise to fix it. Then turn the C lens
clockwise until it is fixed as follows.
Lens Fixing
CS lens
C lens
10
E
