Samsung DW60M6055 Series User manual

DW60M6055**
DW60M6045**
Dishwasher
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
DW5500M-02437 -00_EN.indd 1DW5500M-02437D-0 _EN.indd 1 3/14/2017 5:30:18 PM3/14/2017 5:30:18 PM1j

2_ Safety information
Safety instructions
Congratulations on your new Samsung dishwasher. This manual contains
important information on the installation, use and care of your appliance. Please
take time to read this manual to take full advantage of your dishwasher’s many
benefits and features.
WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS
Please read this manual thoroughly to ensure that you know how to safely and eciently operate the
extensive features and functions of your new appliance and retain it at a safe place near the appliance for
your future reference. Use this appliance only for its intended purpose as described in this user manual.
Warning and important safety instructions in this manual do not cover all possible conditions and
situations that may occur. It is your responsibility to use common sense, caution, and care when installing,
maintaining, and operating your dishwasher.
Because the following operating instructions cover various models, the characteristics of your dishwasher
may dier slightly from those described in this manual and not all warning signs may be applicable. If you
have any questions or concerns, contact your nearest service center or find help and information online at
www.samsung.com.
IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS
Important safety symbols
WARNING
Hazards or unsafe practices that may result in severe personal injury and/or property
damage.
CAUTION
Hazards or unsafe practices that may result in personal injury and/or property
damage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or personal injury when using your
dishwasher, follow these basic safety precautions:
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the appliance is grounded to prevent electric shock.
Call the service centre for help.
Note
These warning symbols are here to prevent injury to you and others.
Please follow them explicitly.
Keep these instructions in a safe place and ensure that new users are familiar with the content.
Pass them on to any future owner.
DW5500M-02437D-00_EN.indd 2DW5500M-02437D-0 _EN.indd 2 3/14/2017 5:30:26 PM3/14/2017 5:30:26 PM1
To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic
precautions, including the following:
WARNING

Safety information _3
1. This appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
2. For use in Europe: This appliance can be used by
children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
3. Children should be supervised to ensure that they do not
play with the appliance.
4. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
5. The new hose-sets supplied with the appliance are to be
used and that old hose-sets should not be reused.
6. For appliances with ventilation openings in the base, that
a carpet must not obstruct the openings.
7. For use in Europe: Children of less than 3 years should
be kept away unless continuously supervised.
DW5500M-02437D-00_EN.indd 3DW5500M-02437D-01_EN.indd 3 3/14/2017 5:30:27 PM3/14/2017 5:30:27 PM

4_ Safety information
8. CAUTION: In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not
be supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly
switched on and o by the utility.
9. This appliance is intended to be used in household and
similar applications such as:
– sta kitchen areas in shops, oces and other working
environments;
– farm houses;
– by clients in hotels, motels and other residential type
environments;
– bed and breakfast type environments.
10.The door should not be left in the open position since
this could present a tripping hazard.
11.WARNING: Knives and other utensils with sharp points
must be loaded in the basket with their points down or
placed in a horizontal position.
Safety instructions
DW5500M-02437D-00_EN.indd 4DW5500M-02437D-01_EN.indd 4 3/14/2017 5:30:27 PM3/14/2017 5:30:27 PM
They can be extremely dangerous if swallowed.
contact with the skin and eyes and keep children
from the dishwasher when the door is open.Check
the detergent receptacle is empty after completion
ash cycle.
1 .WARNING: Some dishwasher detergents are strongly
alkaline.
2
Avoid
away
that
of the w

Safety information _5
INSTRUCTIONS WHEN USING YOUR DISHWASHER
This dishwasher is not designed for commercial use. It is intended for use in domestic households and
in similar working and residential environments such as:
• Shops
• Oces and showrooms
and by residents in establishments such as:
• Hostels and guest houses.
It must only be used as a domestic appliance as specified in these user manual, for cleaning domestic
crockery and cutlery.
Any other usage is not supported by the manufacturer and could be dangerous.
The manufacturer cannot be held liable for damage resulting from incorrect or improper use or
operation.
Do not use solvents in the dishwasher. Danger of explosion.
Do not inhale or ingest dishwasher detergent. Dishwasher detergents contain irritant or corrosive
ingredients which can cause burning in the nose, mouth and throat if swallowed, or inhibit breathing.
Consult a doctor immediately if detergent has been swallowed or inhaled.
Avoid leaving the door open unnecessarily, as you could trip over it.
Do not sit or lean on the opened door. This could cause the dishwasher to tip and be damaged, and
you could get injured.
Only use detergent and rinse aid formulated for domestic dishwashers.
Do not use washing‐up liquid.
Do not use the strong acid cleaning agent.
Do not fill the rinse aid reservoir with powder or liquid detergent. This will cause serious damage to the
reservoir.
Inadvertently filling the salt reservoir with powder or liquid dishwasher detergent will damage the water
softener. Make sure you have picked up the correct packet of dishwasher salt before filling the salt
reservoir.
Please only use special coarse grained dishwasher salt for reactivation, as other salts may contain
insoluble additives which can impair the functioning of the softener.
In an appliance with a cutlery basket (depending on model), cutlery is cleaned and dried more if placed
in eciently the basket with the handles downwards. However, to avoid the risk of injury, place knives
and forks etc. with the handles upwards.
Plastic items which cannot withstand being washed in hot water, such as disposable plastic
containers, or plastic cutlery and crockery should not be cleaned in the dishwasher.
The high temperatures in the dishwasher may cause them to melt or lose shape.
On models with Delay Start function, make sure that the dispenser is dry before adding detergent.
Wipe dry if necessary. Detergent will clog if poured into a damp dispenser and may not be thoroughly
dispersed.
WARNING
WARNING
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
DW5500M-02437D-00_EN.indd 5DW5500M-02437D-01_EN.indd 5 3/14/2017 5:30:27 PM3/14/2017 5:30:27 PM

6_ Safety information
Knives and other utensils with sharp points must be loaded in the basket with their points down or
placed in a horizontal position.
INSTRUCTIONS FOR PROTECTING YOUR CHILDREN
This appliance is not a toy! To avoid the risk of injury, keep children well away and do not allow them to
play in or around the dishwasher or to use the controls. They will not understand the potential dangers
posed by it. They should be supervised whenever you are working in the kitchen.
There is also a danger that children playing might shut themselves in the dishwasher.
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Older children may only use the dishwasher when its operation has been clearly explained to them and
they are able to use it safely, recognising the dangers of misuse.
KEEP CHILDREN AWAY FROM DETERGENTS! Dishwasher detergents contain irritant and corrosive
ingredients which can cause burning in the mouth, nose and throat if swallowed, or inhibit breathing.
Keep children away from the dishwasher when the door is open.
There could still be detergent residues in the cabinet.
Consult a doctor immediately if your child has swallowed or inhaled detergent.
INSTRUCTIONS FOR INSTALLING YOUR DISHWASHER
Before setting up the appliance, check it for any externally visible damage. Under no circumstances
should you use a damaged appliance. A damaged appliance could be dangerous.
The dishwasher must only be plugged into the electricity supply via a suitable switched socket.
The electrical socket must be easily accessible after the dishwasher is installed so that it can be
disconnected from the electricity supply at any time. (Refer to the “Parts and features” section on
page 1.)
There must be no electrical sockets behind the dishwasher. Danger of overheating and fire risk if the
dishwasher were to be pushed up against a plug.
The dishwasher must not be installed under a hob. The high radiant temperatures which are
sometimes generated by a hob could damage the dishwasher. For the same reason it should not be
installed next to open fires or other appliances which give o heat, such as heaters etc.
Do not connect the dishwasher to the mains supply until it has been fully installed and any adjustment
has been made to the door springs.
Before connecting the appliance, check that the connection data on the data plate (voltage and
connected load) match the mains electricity supply. If in any doubt, consult a qualified electrician.
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
CAUTION
WARNING
WARNING
CAUTION
Safety instructions
DW5500M-02437D-00_EN.indd 6DW5500M-02437D-01_EN.indd 6 3/14/2017 5:30:27 PM3/14/2017 5:30:27 PM
0

Safety information _7
The electrical safety of this appliance can only be guaranteed when continuity is complete between it
and an eective grounding system. It is most important that this basic safety requirement is present
and regularly tested and where there is any doubt the electrical system in the house should be
checked by a qualified electrician.
The manufacturer cannot be held liable for the consequences of an inadequate grounding system (e.g.
electric shock).
Do not connect the appliance to the mains electricity supply by a multi‐socket unit or an extension
lead. These do not guarantee the required safety of the appliance (e.g. danger of overheating).
This appliance may only be installed in mobile installations such as ships if a risk assessment of the
installation has been carried out by a suitably qualified engineer.
The plastic housing of the water connection contains an electrical component. The housing must not
be submerged in water.
There are electrical wires in the hose of Aqua-Stop. Never cut the water inlet hose, even if it is too long.
Installation, maintenance and repairs may only be carried out by a suitably qualified and competent
person in strict accordance with current national and local safety regulations. Repairs and other work
by unqualified persons can be dangerous. The manufacturer cannot be held liable for unauthorised
work.
The integrated waterproof system oers protection from water damage, provided the following
conditions are met:
• The dishwasher is correctly installed and plumbed in.
• The dishwasher is properly maintained and parts are replaced where it can be seen that this is
necessary.
• The stopcock has been turned o when the appliance is not used for a longer period of time (e.g.
during holidays).
• The waterproof system will work even if the appliance is switched o. However, the appliance must
remain connected to the electricity supply.
A damaged appliance can be dangerous. If the dishwasher gets damaged, switch it o at the mains
and call your dealer or the service department.
Unauthorised repairs could result in unforeseen dangers for the user, for which the manufacturer
cannot accept liability. Repairs should only be undertaken by an approved service technician.
Faulty components must only be replaced by original spare parts. Only when these parts are fitted can
the safety of the appliance can be guaranteed.
Always disconnect the dishwasher from the electrical supply for maintenance work (switch o at the
wall socket and remove the plug).
If the connection cable is damaged it must be replaced with a special cable, available from the
manufacturer. For safety reasons, this must only be fitted by the service department or an authorised
service technician.
CAUTION
CAUTION
CAUTION
WARNING
CAUTION
DW5500M-02437D-00_EN.indd 7DW5500M-02437D-01_EN.indd 7 3/14/2017 5:30:28 PM3/14/2017 5:30:28 PM

8_ Safety information
In countries where there are areas which may be subject to infestation by cockroaches or other
vermin, pay particular attention to keeping the appliance and its surroundings in a clean condition at all
times. Any damage which may be caused by cockroaches or other vermin will not be covered by the
guarantee.
In the event of a fault or for cleaning purposes, the appliance is only completely isolated from the
electiricity supply when:
• it is switched o at the wall socket and the plug is withdrawn, or
• it is switched o at the mains, or
• the mains fuse is disconnected, or
• the screw-out fuse is removed (in countries where this is applicable).
Do not make any alterations to the appliance, unless authorised to do so by the manufacturer.
Never open the casing/housing of the appliance.
Tempering with electrical connections or components and mechanical parts is highly dangerous and
can cause operational faults or electric shock.
While the appliance is under guarantee, repairs should only be undertaken by a service technician
authorised by the manufacturer. Otherwise the guarantee will be invalidated.
When installing the product, make sure there is space at the top, left, right and back of the product to
ensure proper ventilation.
If there is insucient space between the product and the sink, it may damage the sink or allow mold to
grow.
For information on Samsung’s environmental commitments and product specific regulatory obligations e.g.
REACH visit: samsung.com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/data_corner.html
WARNING
CAUTION
CAUTION
CAUTION
Safety instructions
DW5500M-02437D-00_EN.indd 8DW5500M-02437D-01_EN.indd 8 3/14/2017 5:30:28 PM3/14/2017 5:30:28 PM

Contents
Contents
PARTS AND FEATURES
10
10 Dishwasher features
12 Control panel
15 Displays
USING THE DETERGENT AND RINSE
LOADING THE DISHWASHER RACKS
20
20 Loading the upper basket
22 Loading the lower basket
22 Folding spikes of lower basket
23 Cutlery(silverware) tray
25 For washing in the dishwasher the following
cutlery/dishes
WASHING PROGRAMMES
CLEANING AND CARE
30 Cleaning the spray arms
30 Cleaning the door
30 Caring for the dishwasher
30 Protect against freezing
31 How to maintain your dishwasher
SETTING UP YOUR DISHWASHER
32
32 Water supply and drain
34 Connection of drain hoses
34 Position the appliance
34 Start of dishwasher
TROUBLESHOOTING
codes
APPENDIX
Product dimension
DW5500M-02437D-00_EN.indd 10DW5500M-02437D-0 _EN.indd 10 3/14/2017 5:30:29 PM3/14/2017 5:30:29 PM1
AID
9_
17 Using detergent
26
26 Turning on the appliance
26 Change the programme
27 At the end of the wash cycle
27 Wash cycle table
29
29 Cleaning the filters
4
17
Information
3
35 Before calling for service
38
39
39 Specifications
0
5
19 How to use the Multi tap option
18 Using rinse aid

Part and features
01 PART AND FEATURES
Parts and features
DISHWASHER FEATURES
Front & Rear view (DW60M605 **)
Accessory parts - User manual, Salt funnel, cutlery basket.
DW5500M-02437D-00_EN.indd 11DW5500M-02437D-0 _EN.indd 11 3/14/2017 5:30:29 PM3/14/2017 5:30:29 PM1
5
10_
4
9
7
10
8
13rd Rack
2Upper Basket
3Lower Basket
4Duct Nozzle
5Dispenser
6Cup Shelf
7Spray arms
8Filter assembly
9Inlet hose
10 Drain hose
1
2
3
5
6
8
7
4
