Samsung DVG52M7750V User manual

Dryer
User manual
DVE(G)52M775**
DC68-03170Y-10_IB_DV7750M_EN_R.indd 1DC68-03170Y-10_IB_DV7750M_EN_R.indd 1 2023-06-30  3:25:282023-06-30  3:25:28

Contents
English2
Contents
Safety information 4
What you need to know about the safety instructions 4
Important safety symbols 4
CALIFORNIA PROPOSITION 65 WARNING 9
Important safety precautions 9
Warnings 11
Cautions 11
Installation requirements 13
Key installation requirements 13
Location considerations 13
Ducting requirements 14
Exhausting requirements 15
Gas requirements 16
Electrical requirements 17
Installation 20
What’s included 20
Step-by-step installation 22
Vent blockage test 28
Exhaust ducting guide 30
Switching the door position 30
Before you start 33
Sort and load 33
Functional prerequisite 33
Operations 34
Feature panel 34
Simple steps to start 37
Cycle overview 38
Cycle guide 39
Special features 40
DC68-03170Y-10_IB_DV7750M_EN_R.indd 2DC68-03170Y-10_IB_DV7750M_EN_R.indd 2 2023-06-30  3:25:312023-06-30  3:25:31

Contents
English 3
Maintenance 42
Vent sensor (applicable models only) 42
Cleaning 43
Troubleshooting 44
Checkpoints 44
Information codes 46
Specications 48
Fabric care chart 48
Protecting the environment 49
Specication sheet 50
Cycle chart 51
DC68-03170Y-10_IB_DV7750M_EN_R.indd 3DC68-03170Y-10_IB_DV7750M_EN_R.indd 3 2023-06-30  3:25:312023-06-30  3:25:31

Safety information
SAVE THESE INSTRUCTIONS
English4
Safety information
Congratulations on your new Samsung dryer. This manual contains important information
on the installation, use and care of your appliance. Please take some time to read this
manual to take full advantage of your dryer’s many benets and features.
What you need to know about the safety instructions
Please read this manual thoroughly to ensure that you know how to safely and efciently
operate the extensive features and functions of your new appliance. Please store the
manual in a safe location close to the appliance for future reference. Use this appliance
only for its intended purpose as described in this instruction manual.
Warnings and Important Safety Instructions in this manual do not cover all possible
conditions and situations that may occur. It is your responsibility to use common sense,
caution and care when installing, maintaining and operating your dryer.
Because the following operating instructions cover various models, the characteristics of
your dryer may differ slightly from those described in this manual and not all warning
signs may be applicable. If you have any questions or concerns, contact your nearest
service center or nd help and information online at www.samsung.com.
Important safety symbols
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury, death and/or
property damage.
CAUTION
Hazards or unsafe practices that may result in personal injury and/or property damage.
NOTE
Indicates that a risk of personal injury or material damage exists.
These warning signs are here to prevent injury to yourself and others.
Please follow them explicitly.
After reading this manual, store it in a safe place for future reference.
DC68-03170Y-10_IB_DV7750M_EN_R.indd 4DC68-03170Y-10_IB_DV7750M_EN_R.indd 4 2023-06-30  3:25:312023-06-30  3:25:31

Safety information
SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS
English 5
Read all instructions before using the appliance.
As with any equipment that uses electricity and moving parts, potential hazards exist.
To safely operate this appliance, familiarize yourself with its operation and exercise care
when using it.
WARNING - Risk of Fire
• Clothes dryer installation must be performed by
a qualied installer.
• Install the clothes dryer according to the
manufacturer’s instructions and local codes.
• Do not install a clothes dryer with exible plastic
venting materials. If exible metal (foil type) duct
is installed, it must be of a specic type identied
by the appliance manufacturer as suitable for use
with clothes dryers. Flexible venting materials
are known to collapse, be easily crushed, and
trap lint. These conditions will obstruct clothes
dryer airow and increase the risk of re.
• Do not install a booster fan in the exhaust duct.
• To reduce the risk of severe injury or death,
follow all installation instructions.
• Save these instructions.
DC68-03170Y-10_IB_DV7750M_EN_R.indd 5DC68-03170Y-10_IB_DV7750M_EN_R.indd 5 2023-06-30  3:25:312023-06-30  3:25:31

Safety information
SAVE THESE INSTRUCTIONS
Safety information
SAVE THESE INSTRUCTIONS
English6
WARNING - To reduce the risk of re or
explosion:
• Do not dry items that have been previously
cleaned, washed, soaked, or spotted with
gasoline, dry cleaning solvents, or other
ammable or explosive substances. They emit
vapors that could ignite or explode. Any material
that has been in contact with a cleaning solvent
or ammable liquids or solids should not be
placed in the dryer until all traces of these
ammable liquids or solids and their fumes
have been removed. There are many highly
ammable items used in homes, such as acetone,
denatured alcohol, gasoline, kerosene, some
liquid household cleaners, some spot removers,
turpentine, waxes, and wax removers.
• Items containing foam rubber (which may
be labeled latex foam) or similarly textured
rubberlike materials must not be dried on a heat
setting. Heated foam rubber materials can, under
certain circumstances, ignite spontaneously.
DC68-03170Y-10_IB_DV7750M_EN_R.indd 6DC68-03170Y-10_IB_DV7750M_EN_R.indd 6 2023-06-30  3:25:312023-06-30  3:25:31

Safety information
SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS
English 7
WARNING - Fire or explosion hazard
• Failure to follow safety warnings exactly could
result in serious injury, death or property
damage.
• Do not store or use gasoline or other ammable
vapors and liquids near this or any other
appliance.
• Installation and service must be performed by
a qualied installer, service agency, or the gas
supplier.
• Do not install a booster fan in the exhaust duct.
DC68-03170Y-10_IB_DV7750M_EN_R.indd 7DC68-03170Y-10_IB_DV7750M_EN_R.indd 7 2023-06-30  3:25:322023-06-30  3:25:32

Safety information
SAVE THESE INSTRUCTIONS
Safety information
SAVE THESE INSTRUCTIONS
English8
WARNING - What to do if you smell gas:
• Do not try to light any appliance.
• Do not turn on the appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Clear the room, building or area of all occupants.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
re department.
DC68-03170Y-10_IB_DV7750M_EN_R.indd 8DC68-03170Y-10_IB_DV7750M_EN_R.indd 8 2023-06-30  3:25:322023-06-30  3:25:32

Safety information
SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS
English 9
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Important safety precautions
WARNING
To reduce the risk of re, electric shock, or injury to persons when using your appliance,
follow basic precautions, including the following:
1. Read all instructions before using this appliance.
2. Do not dry articles that have been previously cleaned in, washed in, soaked in,
or spotted with gasoline, dry-cleaning solvents, or other ammable or explosive
substances, as they give off vapors that could ignite or explode.
3. Do not use the dryer to dry clothes which have traces of any ammable substance,
such as vegetable oil, cooking oil, machine oil, ammable chemicals, paint thinner,
etc., or anything containing wax or chemicals, such as mops and cleaning cloths.
Flammable substances may cause the fabric to catch re by itself.
4. Do not store or use gasoline or other ammable vapors and liquids near this or any
other appliance.
5. Do not allow children to play on or in the appliance. Close supervision of children is
necessary when the appliance is used near children.
6. Before the appliance is removed from service or discarded, remove the door to the
drying compartment.
7. Do not reach into the appliance if the drum is moving.
8. Do not install or store this appliance where it will be exposed to the weather.
9. Do not tamper with internal controls.
10. Do not repair or replace any part of the appliance or attempt any service unless
specically recommended in the user-maintenance instructions or in published user-
repair instructions that you understand and have the skills to carry out.
11. Do not use fabric softeners or products to eliminate static unless recommended by the
manufacturer of the fabric softener or product.
12. Clean the lint screen before or after each load.
DC68-03170Y-10_IB_DV7750M_EN_R.indd 9DC68-03170Y-10_IB_DV7750M_EN_R.indd 9 2023-06-30  3:25:322023-06-30  3:25:32

Safety information
SAVE THESE INSTRUCTIONS
Safety information
SAVE THESE INSTRUCTIONS
English10
13. Do not use heat to dry articles containing foam rubber or similarly textured rubber-
like materials.
14. Keep area around the exhaust opening and adjacent surrounding areas free from the
accumulation of lint, dust, and dirt.
15. The interior of the appliance and exhaust duct should be cleaned periodically by
qualied service personnel.
16. Do not place items exposed to cooking oils in your dryer. Items contaminated with
cooking oils may contribute to a chemical reaction that could cause a load to catch
re. To reduce the risk of re due to contaminated loads, the nal part of a tumble
dryer cycle occurs without heat (cool down period). Avoid stopping a tumble dryer
before the end of the drying cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
17. This appliance must be grounded. See “Electrical requirements” and “Grounding” in
“Installation” section.
18. Do not allow children to play on or in the appliance. Close supervision of children is
necessary when the appliance is used near children.
19. Do not insert your hand under the dryer.
– This may result in injury.
20. Take care that children’s ngers are not caught in the door when closing it.
– This may result in injury.
21. The control board and inlet valve are intentionally not grounded and may present a
risk of electric shock only during servicing.
– Do not contact these parts while the appliance is energized.
DC68-03170Y-10_IB_DV7750M_EN_R.indd 10DC68-03170Y-10_IB_DV7750M_EN_R.indd 10 2023-06-30  3:25:322023-06-30  3:25:32
