Safety precautions
Important to read and understand at all times
Warning This symbol indicates an extremely dangerous situation. If users ignore this symbol and handle the device with the
wrong way, serious injury or death could result.
Caution This symbol indicates that a dangerous situation might occur. If users ignore this symbol and handle the device with
the wrong way, serious damage to the product could result.
Important Important to read and understand at all times.
Caution Do not disassemble.
Note Note
Important
IF A SOFTWARE PROGRAM IS TO BE BUNDLED WITH THE OPTICAL DISC
DRIVE PROVIDED BY SAMSUNG, THEN YOU MUST HAVE A SEPARATE,
VALID LICENSE FOR SUCH BUNDLED SOFTWARE WITH RESPECT TO THE
MANUFACTURE, SALE OR DISTRIBUTION OF THE PRODUCT (SUCH AS A
PERSONAL COMPUTER) CONTAINING THE OPTICAL DISC DRIVE AND THE
BUNDLED SOFTWARE AS ITS COMPONENTS. OTHER THAN THOSE THIRD
PARTY LICENSES EXPRESSLY STATED TO BE INCLUDED, SAMSUNG
PROVIDES NO OTHER THIRD PARTY LICENSES, AND HEREBY DISCLAIMS
ANY AND ALL LIABILITY WITH RESPECT THERETO.
T
o
Safety precaution
Safety precautions
During installation
During operation
Others
RoHS and WEEE
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
A
ll Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 1/1SH-222AB : Safet
y
precautions - Safet
y
precautions
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
During Installation
Installation
Do not install the drive on the unstable
surface.
Do not place the drive in direct sunlight.
Avoid very low or high temperatures.
Avoid high humidity.
T
o
Safety precaution
Safety precautions
During installation
During operation
Others
RoHS and WEEE
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
A
ll Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 1/1SH-222AB : Safet
y
precautions - Durin
g
Installation
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
During Operation
Operation
Handle the drive carefully to prevent
damage from an external shock.
Do not drop the drive. Protect the drive from
severe shocks.
If you do not protect it, this can cause
damage to the drive.
Do not move the drive or attempt
to open the disc tray by force
while it is in operation.
If you cannot open the tray using
the Eject button, close all open
applications and then open the
tray by inserting a pin into the emergency hole.
Do not insert a pin into the emergency hole while the drive is in operation.
Keep your hand away from the tray while the drive is in operation.
This can result in damage to the product or human body.
Do not use cracked, distorted or damaged
discs.
A disc with a crack can break while you
use it, especially when the crack is near
the center of the disc.
Before you use the disc, always make
sure that it does not have a crack. If the disc has a crack, we recommend you
make a copy of the disc and use the copy. If you continue to use a cracked disc,
the size of the crack will increase and this will cause irreparable damage to the
disc.
Do not use low-quality discs (illegal, scratched, damaged, etc.).
If you use such discs, Samsung is not responsible for the damage that this
can cause.
Safety precaution
Safety precautions
During installation
During operation
Others
RoHS and WEEE
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
페이지 1/2SH-222AB : Safet
y
precautions - Durin
g
operation
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

T
o
A
ll Contents Copyright © 2001 - 2011
SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 2/2SH-222AB : Safet
y
precautions - Durin
g
operation
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
Others
Others
Make sure that no foreign material
enters the drive casing.
To protect against fire, do not use any
flammable liquids such as alcohol or
benzene on the drive.
Do not disassemble, repair or modify the
device without our approval.
To reduce the risk of damage, electric
shock and fire.
T
o
Safety precaution
Safety precautions
During installation
During operation
Others
RoHS and WEEE
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
A
ll Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 1/1SH-222AB : Safet
y
precautions - Others
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
RoHS and WEEE
RoHS
Planet First logo
This logo shows consumers that Samsung develops eco
-friendly products and demonstrates Samsung’s
continuous efforts to develop eco-friendly products.
RoHS(Restriction of the use of certain hazardous substances in electrical and
electronic equipment)
The RoHS, the environmental regulation announced by European Union, restricts the use
of lead, mercury, cadmium, hexavalent chromium, PBB, and PBDE in products put on the
market in the European Union after July 1, 2006.
WEEE
Correct Disposal of This Product (Waste Electrical & Electronic
Equipment)
(Applicable in the European Union and other European countries with
separate collection systems)
This marking on the product, accessories or literature indicates that the product and its
electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with
other household waste at the end of their working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, separate these items from
other types of waste and recycle them responsibly to promote the sustainable reuse of
material resources.
Household users should contact either the retailer where they purchased this product, or
their local government office, for details of where and how they can take this item for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial waste for
disposal.
T
o
Safety precaution
Safety precautions
During installation
During operation
Others
RoHS and WEEE
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
A
ll Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 1/1SH-222AB : Safet
y
precautions - RoHS and WEEE
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
Exterior
Front
Door tray1.
LED2.
Emergency hole3.
Eject button4.
Note
Design and specifications are subject to change without prior notice.
Back
S-ATA power port1.
S-ATA data port2.
Components
DVD writer
S-ATA data cable
Mounting screws
Quick installation guide
Application software & user manual CD
Features
Exterior
System requirements
Recommended discs
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
페이지 1/2SH-222BB : Features - Exterio
r
2011-07-11file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Note
If you need to return the purchased product, make sure to include all the
accessories provided with the product to receive a refund.
The type of accessories varies depending on a product model. Some
accessories are subject to change without notice.
T
o
A
ll Contents Copyright © 2001 - 2011
SAMSUNG Electronics Co., Ltd.
Optical Disc Drive
페이지 2/2SH-222BB : Features - Exterio
r
2011-07-11file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
System requirements
System requirements
Item Description
OS Microsoft Windows 2000 / XP / Vista / 7
CPU S-ATA supported PC (See our website for a list of compatible mainboards)
Pentium4 2.0GHz or above
RAM 256 MB or more
T
o
Features
Exterior
System requirements
Recommended discs
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
A
ll Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 1/1SH-222AB : Features - S
y
stem requirements
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
Recommended discs
Recommended DVD disc types
DVD-R Media
TAIYO-YUDEN, TDK, MKM(VERBATIM, MITSUBISHI), RITEK, CMC, SONY
DVD-RW Media
JVC, MKM(VERBATIM, MITSUBISHI), CMC, RITEK, TDK
DVD+R Media
RICOH, TAIYO-YUDEN, MKM(VERBATIM, MITSUBISHI), RiTEK, CMC, PRODISC,
OPTODISC
DVD+RW Media
RICOH, MKM(VERBATIM, MITSUBISHI), RiTEK, CMC
DVD±R DL
CMC, MKM(VERBATIM, MITSUBISHI), RITEK
DVD-RAM
RITEK, MKM(VERBATIM, MITSUBISHI)
T
o
Recommended CD disc types
CD-R Media
TAIYO-YUDEN,MKM(VERBATIM, MITSUBISHI), RITEK, CMC, SONY
CD-RW Media
CMC,MKM(VERBATIM, MITSUBISHI), RICOH, DAXON
HS CD-RW Media
CMC, MKM(VERBATIM, MITSUBISHI), RITEK
US CD-RW Media
MKM(VERBATIM, MITSUBISHI)
T
o
Features
Exterior
System requirements
Recommended discs
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
페이지 1/2SH-222AB : Features - Features
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

All Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 2/2SH-222AB : Features - Features
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
How to install the drive
Turn off the PC.1.
Open the cover.
See the pictures.
2.
If necessary, attach the support devices on
both sides of the drive.
3.
The support devices are PC
accessories. Purchase these items
separately if necessary.
(Screw: M3 x 6 x 4 )
Remove the plate. Insert the drive.4.
Make sure to use the screws (M3 x 6)
included with the drive.
If you use other screws, this can cause
damage.
Caution
If the screws are not securely tightened, this can increase the noise level and cause
vibrations.
T
o
How to install
How to install the drive
How to connect the cables
How to install the driver
How to update the Firmware
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
A
ll Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 1/1SH-222AB : How to install - How to install the drive
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
How to connect the cables
S-ATA power cable1.
S-ATA data cable2.
How to connect the S-ATA cable
When you use one S-ATA drive
Drive1.
Mainboard2.
Caution
If the screws are not securely tightened, this can increase the noise level and cause
vibrations.
T
o
How to install
How to install the drive
How to connect the cables
How to install the driver
How to update the Firmware
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
A
ll Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 1/1SH-222BB : How to install - How to connect the cables
2011-07-11file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
How to install the driver
How to use the Device Manager
Windows 2000
Click Start - Settings - Control Panel - System.1.
Click on the Hardware tab in the System Properties window. Click on the Device
Manager tab.
2.
Click the drive in the Device Manager window.3.
T
o
Windows XP
Click Start - Settings - Control Panel - Performance and Maintenance.1.
Click the Administrative Tools icon in the Performance and Maintenance window.2.
Click the Computer Management icon in the Administrative Tools window.3.
Click Device Manager icon in the Administrative Tools window and then click the
drive.
4.
T
o
Windows Vista
Click Start - Control Panel - System - Device Manager.1.
Click the drive in the Device Manager window.2.
T
o
Windows 7
Click Start - Control Panel - System and Security - System Device Manager.1.
Click the drive in the Device Manager window.2.
T
o
How to install
How to install the drive
How to connect the cables
How to install the driver
How to update the Firmware
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
A
ll Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 1/1SH-222AB : How to install - How to install the drive
r
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
How to update the Firmware
Go to www.samsung-ODD.com .1.
Click Firmware on the menu bar (in the upper right corner).2.
Click Firmware Downloads. Find your drive model and start the download.3.
T
o
How to install
How to install the drive
How to connect the cables
How to install the driver
How to update the Firmware
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
A
ll Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 1/1SH-222AB : How to install - How to update the Firmware
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
How to use the drive
Caution
Do not turn off the PC or disconnect the drive while the LED indicator blinks.
This can cause damage to the drive.
How to use a drive that is installed horizontally
You can use 3.15 inch or 4.72 inch (80 mm or
120 mm) discs.
The drive can only read the disc correctly if the
disc is placed inside the tray guiding line.
How to use a drive that is installed vertically
You can install and use this drive vertically.
You can only use 4.72 inch (120 mm) discs.
The drive can only read the disc correctly if the disc is
placed inside the tray guiding line.
T
o
How to use
How to use the drive
How to use DVD±R/RW and
other discs
How to use MAGIC SPEED
(Option)
When the LED blinks
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
A
ll Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 1/1SH-222AB : How to use - How to use the drive
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
How to use DVD±R/RW and other discs
Important
The DVD Writer lets you write DVD±RW discs with Nero Express and enables "packet
writing" (high-speed recording) with InCD.
The drive also lets you write DVD±R discs with Nero Express.
Caution
It is illegal to make unauthorized copies of DVD or software titles. A person who
makes illegal copies can be held responsible for copyright infringement.
If you use low-quality discs, this can increase the recording time or make it
impossible to use the disc.
How to use DVD±R/RW and other discs
After your computer recognizes the [CD-ROM] icon designated to the BD-ROM/DVD
writer as the 'E:' drive, insert a CD-ROM or a DVD-ROM disc and make sure that the
inserted disc is recognized.
(The assigned drive letter can be different in your specific system environment.)
You can use the drive to play commercial DVD titles:
Most DVD titles in the market use the Dolby sound system.
It is necessary to install software that supports Dolby decoding on your PC before
you can play a DVD title with this drive.
How to get commercial software that supports Dolby decoding.
Go to the website of Nero: http://www.nero.com
(You can also use other compliant software)
DVD Region Protection Coding (RPC)
DVD Region Protection Coding (RPC):
The RPC feature is supported on DVD players and is used with DVD-video discs (such as
movies). The motion picture industry has divided the world into different regions that
correspond to the regional markets into which the motion picture industry releases movies.
Movies worldwide have RPC codes, based on the region of the world in which they are
being sold. These RPC codes help to control and prevent pirating of new movies into
other motion picture regions before their release within those markets.
Therefore, this drive supports RPC phase II. In the RPC-2 mode, users can change the
local code. RPC-2 is selected by default for this drive.
You can change the region code up to five times via an MPEG application.
Please contact your dealer or local SAMSUNG representative if you need to change the
local code more than five times.
T
o
How to use
How to use the drive
How to use DVD±R/RW and
other discs
How to use MAGIC SPEED
(Option)
When the LED blinks
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
페이지 1/2SH-222AB : How to use - How to use DVD±R/RW and other discs
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

All Contents Copyright © 2001 - 2011 SAMSUNG Electronics Co., Ltd. Optical Disc Drive
페이지 2/2SH-222AB : How to use - How to use DVD±R/RW and other discs
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...

Samsung Optical Disc Drive Home Index
a
fety precautions Features How to install How to use How to store and clean Troubleshooting Specifications
How to use MAGIC SPEED (Option)
What is MAGIC SPEED?
MAGIC SPEED is a program that enables the user to select the reading speed of CD disc
between two modes offered by the drive: Maximum Speed Mode (Max Mode) and Silent
Mode.
Important
MAGIC SPEED may not be provided depending on the specifications.
Development background
Modern ODD products offer a high reading speed.
With the increased reading speed, faster data processing has become possible. However,
high rotation speed often causes more noise, and it is more probable that damaged discs
crash. To remedy this backdrop, we have developed a Speed-down algorithm and
applied this technology to newly-launched products to provide a safer and more
comfortable environment.
What is the Speed-down Algorithm?
The Speed-down Algorithm operates the device at a safer disc reading speed. This
prevents possible disc crashes when the disc has cracks. For customers who want
to play CDs at maximum speed, MAGIC SPEED lets customers choose the reading
speed. (The writing speed will not be limited)
T
o
What is MAGIC SPEED and how to use it?
MAGIC SPEED mode
Max Mode: Set the reading speed to the maximum level for the drive.
Silent Mode: Set the reading speed to a stable low speed.
When the PC restarts, all modes set by MAGIC SPEED will be reset to low noise mode.
If you want to use the maximum speed mode, change the settings as necessary.
Caution
A
disc with a crack can crash when you operate it in Max Mode. We recommend
that you use this type of disc in Silent Mode and make a copy of the disc to use.
How to use MAGIC SPEED
Get the MAGIC SPEED program from our website. Then install it on your computer.1.
How to use
How to use the drive
How to use DVD±R/RW and
other discs
How to use MAGIC SPEED
(Option)
When the LED blinks
Related links
http://www.samsung-ODD.com
http://www.samsung.com
Select language
Select your language
F
irmware Update
C
heck your firmware version.
W
arranty Statement
W
arranty statement for your product
페이지 1/2SH-222AB : How to use - How to use MAGIC SPEED (Option)
2011-07-08file://D:\HEARTSOME
_
WORK\00
_
PROJECT
_
LOCALIZATION\3
_
TOSHIBA
_
SA...
