Samsung P560 User manual

P560
OXFORD
SERVICE
Manual
P560 Contents
1. High Performance Note PC
- Intel Core2 Duo Processor
- Intel Turbo Memory
- Fingerprint recognition (Optional)
- Wireless LAN Bluetooth
2. Convenient Function
- Internal Camera
- ALS Light Sensor
- AMT 4.0 (Optional)
If there are the contents not included in this book, please refer to K-zone service manual
SENS

Contents
1. Precautions
1-1. General After-Sales Service Precautions........................................................................................................1-1
1-2. Safety Precautions ..........................................................................................................................................1-2
1-3. Ground.............................................................................................................................................................1-2
1-4. Static Electricity Precautions...........................................................................................................................1-2
2. 2. Introduction and Specication
2-1. Instroduction....................................................................................................................................................2-1
2-2. Specication ....................................................................................................................................................2-2
2-3. Comparing product specications ...................................................................................................................2-9
2-4. Comparing product specications jatasa.......................................................................................................2-10
2-5. Option Material List........................................................................................................................................2-11
2-6. Function of Product .......................................................................................................................................2-14
2-7. SW List..........................................................................................................................................................2-23
2-8. System Setup (BIOS Setup)..........................................................................................................................2-24
2-9. Mainboard Part Description...........................................................................................................................2-31
3. Disassembly and Reassembly
3-1. Disassembly and Reassembly P560...............................................................................................................3-1
4. Troubleshooting
4-1. General............................................................................................................................................................4-1
4-2. Debugging Flow Chart.....................................................................................................................................4-2
4-3. System Diagnosis............................................................................................................................................4-5
4-4. Diagnosis application.....................................................................................................................................4-14
4-5. Hardware Troubleshooting ............................................................................................................................4-17
4-6. CPU Fan Control...........................................................................................................................................4-24
4-7. Battery Use Time...........................................................................................................................................4-26
4-8. Etc ................................................................................................................................................................4-31
4-9. Adding a Memory Module..............................................................................................................................4-32
5. Exploded View
5-1. SYSTEM MAIN................................................................................................................................................5-1
5-2. SYSTEM MAIN LIST.......................................................................................................................................5-2
5-3. LCD ASSY.......................................................................................................................................................5-3
5-4. LCD ASSY LIST ..............................................................................................................................................5-4
5-5. LCD BACK ASSY............................................................................................................................................5-5
5-6. LCD BACK ASSY LIST....................................................................................................................................5-6
5-7. BOTTOM ASSY...............................................................................................................................................5-7
5-8. BOTTOM ASSY LIST ......................................................................................................................................5-8
5-9. TOPASSY.......................................................................................................................................................5-9
5-10. TOPASSY LIST ..........................................................................................................................................5-10
5-11. ODD ASSY ..................................................................................................................................................5-11
5-12. ODD ASSY LIST..........................................................................................................................................5-12
6. Material List
7. System Wire Diagram
7-1. View.................................................................................................................................................................7-1
7-2. Bottom.............................................................................................................................................................7-2
7-3. LCD .................................................................................................................................................................7-3
8. Block Diagram and Schematic

Contents

2-1
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
2. Introduction and Specication
2-1. Instroduction
 HighPerformanceNotePC
High Performance with Intel Core 2 Duo / Celeron Processor and DDR III Memory
Intel Turbo Memory (Option)
Fingerprint recognition (Optional), TPM(Trusted Platform Module) (Optional)
Wireless LAN (Optional), Bluetooth (Optional)
 ConvenientFunction
Camera Module Installed (Optional)
 PrudentDesignforeasyuse.
Various shortcut keys on the keyboard
Multi-card slot
Luxurious design with increased usability
•
•
•
•
•
•
•
•

2-2
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
2-2. Specication
Processor and Motherboard Description
Processor Intel® Core™2 Duo Processor T9600 (2.8 GHz, 1066 MHz, 6 MB, 35 W)
Intel® Core™2 Duo Processor T9400 (2.53 GHz, 1066 MHz, 6 MB, 35 W)
Intel® Core™2 Duo Processor P9500 (2.53 GHz, 1066 MHz, 6 MB, 25 W)
Intel® Core™2 Duo Processor P8600 (2.4 GHz, 1066 MHz, 3 MB, 25 W)
Intel® Core™2 Duo Processor P8400 (2.26 GHz, 1066 MHz, 3 MB, 25 W)
Intel® Core™2 Duo Processor P7350 (2.00 GHz, 1066 MHz, 3 MB, 25 W, Tj)
Intel® Core™2 Duo Processor T5870 (2.00 GHz, 800 MHz, 2 MB, 35 W)
Intel® Core™2 Duo Processor T5670 (1.8 GHz, 800 MHz, 2 MB, 35 W)
Chipset (MCH + ICH) Intel PM45 + ICH9M, GM45 + ICH9M, PM45 + ICH9ME, GM45 + ICH9ME
Memory
Memory capacity Min. 1 GB ~ Max. 4 GB
Memory type DDR3 (1066MHz)
Memory modules 1 GB SODIMM
Sockets 2-slot SODIMMs
Display
LCD 1 15.4” WSXGA+ Non Glare
Vendor Samsung LCD
Resolution 1,680 x 1050 pixel
Colors 262,144 colors
Viewing angle Left 65° / Right 65° / Up 50° / Down 50°
Dot pitch 0.1972 x 0.1972mm (Horizontal x Vertical)
Contrast ratio Typical 300 CR
Brightness Typical 200 cd/m2
Response time Typical 16 ms / max.25 ms
Polarizer Non Glare
Weight Max. 590 g
LCD 2 15.4” WXGA Non Glare
Vendor Samsung LCD
Resolution 1,280 x 800 pixel
Colors 262,144 colors
Viewing angle Left 40° / Right 40° / Up 15° / Down 30°
Dot pitch 0.25875 x 0.25875 mm (Horizontal x Vertical)
Contrast ratio Typical 500 CR
Brightness Typical 200 cd/m2
Response time Typical 16 ms / max.25 ms
Polarizer Non Glare
Weight Max. 570 g
LCD 3 15.4” WXGA Non Glare
Vendor Samsung LCD
Resolution 1,280 x 800 pixel
Colors 262,144 colors
Viewing angle Left 40° / Right 40° / Up 10° / Down 30°
Dot pitch 0.25875 x 0.25875 mm (Horizontal x Vertical)
Contrast ratio Typical 500 CR
Brightness Typical 220 cd/m2

2-3
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
Processor and Motherboard Description
Response time Typical 8 ms / max.16 ms
Polarizer Non glare
Weight Max. 565 g
Graphics
Interface PCI Express 16x, DirectX 10 support
Graphic Controller
[ Internal Graphic ]
Cantiga-GM
[ External Graphic ]
NB9P GE - GeForce 9600M GS (In case of intel PM45)
Video Memory
[Internal Graphic ]
Shared Memory 32MB ~ Max 256MB
[ External Graphic ]
GDDR3 256MB, GDDR3 512MB (In case of intel PM45)
Ext. Port VGA (Dual Independent Display)
HDMI (DVI Supported with HDMIto DVI Cable)
HDCP (High Bandwidth Digital Content Protection)
Ext. CRT Resolution Upto 1,920x1,440 : 32-bit true color
EDID (Extended Display Identity Data,
Accrding to support output ratio of monitor 4:3
and 16:10 etc.
)
Audio
Sound
Codec Intel® HD (High Denition) audio codec
Chipset REALTEK ALC262-VC2-GR
Conversion Built-in high performance 20 bit ADC & 24 bit DAC
Sound effect EDS (Enhanced Digital Sound)
Internal interfaces Embedded stereo speakers & integrated mono microphone
Speaker power rating 2 speakers x 1.5 W with enclosure
External interfaces Headphone-out, microphone-in
Controls Keyboard volume control
Microphone
Type 1 integrated mono microphone
Sensitivity -40±3 dB
Output impedance Max. 2,200 Ohm
Noise supression Noise supression
Storage
Hard disk drive 1
Vendor HGST, Fujitsu, Samsung Storage, Toshiba , WD
Type 9.5 mm Height 2.5” S-ATA
Speed 5,400 rpm
Average seek time Read max. 14 ms, write max. 15 ms
Supports SATA II 3.0Gbit , SataI 1.5Gbit/s
Capacity 80 GB
120 GB
160 GB
200 GB
250 GB
320 GB

2-4
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
Processor and Motherboard Description
Hard disk drive 2
Vendor HGST, Fujitsu
Type 9.5 mm Height 2.5” S-ATA
Speed 7,200 rpm
Average seek time Read max. 16 ms, write max. 17 ms
Supports SATA II 3.0Gbit , SataI 1.5Gbit/s
Security 80 GB
120 GB
160 GB
200 GB
Type NAND ash
Memory capacity 2 GB
Feature ReadyDrive/ReadyBoost Support, AHCI Mode, Intel® Turbo Memory driver
Interface Mini card (PCI-Express)
Optical disk drive
DVD-rom 1 Factory Option
Vendor TSST
Module type Fixed 12.7mm Slim
Speed 8x DVD-ROM, 24x RW, 24x CD-R, 24x CD : TSST, TS-L333A
Average Access Time DVD 130ms Typ, CD 130ms Typ
Weight 176g or less
S/W Supplied Cyberlink DVD Solution
Security RPC-II Regional Encoding
DVD-rom 2 Factory Option
Vendor TEAC
Module type Fixed 12.7mm Slim
Speed 8x DVD-ROM, 24x RW, 24x CD-R, 24x CD : TSST, DV-28S-V
Average Access Time DVD 130ms Typ, CD 130ms Typ,.
Weight 176g or less
S/W supplied Cyberlink DVD Solution
Security RPC-II Regional Encoding
Software supplied CyberLink DVD Suite
Security RPC-II regional encoding
Super multi dual layer 1
Vendor TSST
Type 12.7 mm, S-ATA, Fixed type
Speed 5 x DVD-RAM, 8 x DVD±R, 6 x DVD±R DL, 8 x DVD+RW, 6 x DVD-RW, 24 x CD-R/RW,
8 x DVD, 24 x CD
Average access time DVD 130 ms Typ., CD 130 ms Typ.
Weight Max. 165 g
Software supplied CyberLink DVD Suite
Security RPC-II regional encoding
Super multi dual layer 2
Vendor TEAC
Type Fixed 12.7mm

2-5
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
Processor and Motherboard Description
Speed 5 x DVD-RAM, 8 x DVD±R, 6 x DVD±R DL, 8 x DVD+RW, 6 x DVD-RW, 24 x CD-R/RW,
8 x DVD, 24 x CD
Average access time DVD 150 ms Typ., CD 140 ms Typ.
Weight Max. 180 g
Software supplied CyberLink DVD Suite
Security RPC-II regional encoding
Super multi light scribe 1
Vendor TSST
Type 12.7 mm, S-ATA, Fixed type
Speed 5 x DVD-RAM, 8 x DVD±R, 6 x DVD±R DL, 8 x DVD+RW, 6 x DVD-RW, 24 x CD-R/RW,
8 x DVD, 24 x CD
Average access time DVD 130 ms Typ., CD 130 ms Typ.
Weight Max. 165 g
Software supplied CyberLink DVD Suite
Security RPC-II regional encoding
Network communication
Fax / Modem
Type 56 Kbps / V.92 Modem (F.Option)
Chipset SV92A3
Interface RJ11 output
LAN
Type 10/100/1000 Ethernet
Chipset Boazman(82567V, 82567LM)
Interface RJ45 output
Feature
Wireless LAN 1
Type Intel® 802.11a/b/g/n
Interface Mini card type
Chipset Intel® WiFi Link 5300
Antenna 3 integrated (Main, AUX, MIMO)
Feature
Wireless LAN 2
Type Intel® 802.11a/b/g/n (11a/b/g for Russia, Ukraine, Pakistan)
Interface Mini card type
Chipset Intel® WiFi Link 5100
Antenna 2 integrated (Main, AUX)
Feature
Bluetooth
Type Bluetooth V2.0 + EDR (Enhanced Data Rate)
Interface USB daughter card type with integrated PIFA (Plane Inverted F Antenna)
Chipset Broadcom BCM2045
Ports and interfaces ( Input / output )
PC card slot 1
Type PCMCIA
Chipset Ricoh R5C847

2-6
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
Processor and Motherboard Description
Support PCMCIA I, II type
Memory card slot YES
Type 3-in-1 Multi-memory Card Slot
Support SD / SDHC / MMC
Dock port YES
Type P-Dock port
[P-Dock Option Product ]
Model Code AA-RD0NDOC
Feature USB2.0 x 5, PS/2, DVI, VGA, RJ45, SIO, E-SATA, Display Port(option), Mic-in jack,
Headphone jack
Input / output ports
VGA Yes (15 pin)
S-Video (TV-out) No
HDMI Yes
Headphone-out Yes
Microphone-in Yes
USB 4 x USB 2.0
SIO Yes
IEEE1394 No
RJ11 (Modem) Yes (F.Option)
RJ45 (LAN) Yes
TV antenna No
DC-In (power port) Yes (5 pie)
Input devices
Keyboard Yes
- Amount of keys 88 (KOR, RUS, UKR, US)
89 (UK, FR, GM, SP)
- Feature Travel length 2.6 mm, key pitch 19.05 mm
- Silver Nano Technology Yes
- Fast function keys (EZ BLU) F7 (Magic Doctor), F8 (SpeedUp Manager)
Touchpad Synaptics touchpad (plat type with scroll area)
Button Power On
LED indicator Power, AC-in / battery, HDD, num-lock, caps-lock, scroll-lock, wireless antenna
Multimedia
Integrated digital camera
Type 1.3M Web-Cam
Chipset GD-5931A/B (D-MAX)
Image sensor Color CMOS SXGA (1.3 Mpixel)
SCAN mode Progressive
Still image capture resolution SXGA (1,280 x 1,024), VGA (640 x 480), CIF (352 x 288)
Video capture resolution VGA (640 x 480)
Digital video capture speed Max. 30 frame
Focus Min. 50 cm ~ innity
UVC support USB video class 1.0 standard compliant
Power and power management

2-7
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
Processor and Motherboard Description
System power management
Power management features ACPI 1.0b support, standby (S3), hibernate (S4)
Standard battery
Model code BA43-00150A Sanyo (1’st)
BA43-00149A SDI (2’nd)
Details of cell 6 cells
Battery capacity 5,200 mAh
Voltage 11.1 V
Battery rating 57.72 Wh
Color Black
Dimension 204 x 48.05 x 21.4 mm (W x H x D)
Weight Max. 350 g
Recharge time Approx. 2 hours
Battery life (DVD play mode) Typ. 2.6 hours
- Test program PowerDVD(Max Batttery Mode)
- Test condition Multimedia MOde, LCD Brightness-Level 4, WLAN R/F Off, discharged by 3%
T9400(2.53GHz), DDR3 1GB, 15.4” WXGA(200nits), NB9P-GS(512MB), 80GB,
DVD-Multi, Vista Home Premium
Battery life (Bench mark mode) Max. 3.7 hours
- Test program BatteryMark v.4.0.1
- Test condition Samsung Optimized mode, LCD Brightness-Minimum, WLAN R/F Off, discharged by 3%
T9400(2.53GHz), DDR3 1GB, 15.4” WXGA(200nits), NB9P-GS(512MB), 80GB,
DVD-Multi, Vista Home Premium
Long-life battery
Model code AA-PL2NC9B
Details of cell 9 cells
Battery capacity 7,800 mAh
Voltage 11.1 V
Battery rating 86.58 Wh
Color Black
Dimension 204 x 67 x 21.4 mm (W x H x D)
Weight Max. 470 g
Recharge time Approx. 3.2 hours
Battery life (DVD play mode) Typ. 4.0 hours
- Test program PowerDVD (Max Batttery Mode)
- Test condition Mutimedia Mode, LCD Brightness-Level 4, WLAN R/F Off, discharged by 3%
T9400(2.53GHz), DDR3 1GB, 15.4” WXGA(200nits), NB9P-GS(512MB), 80GB,
DVD-Multi, Vista Home Premium
Battery life (Bench mark mode) Max. 5.7 hours
- Test program BatteryMark v.4.0.1
- Test condition Samsung Optimized mode, LCD Brightness-Minimum, WLAN R/F Off, discharged by 3%
T9400(2.53GHz), DDR3 1GB, 15.4” WXGA(200nits), NB9P-GS(512MB), 80GB,
DVD-Multi, Vista Home Premium
AC adapter 1
Model code AD6016
Output power 60 W
Dimension 107.9 x 46.5 x 28 mm (W x H x D)

2-8
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
Processor and Motherboard Description
Weight (AC Adapter) Max. 295 g
Worldwide compatibility Auto-sensing 100-240 VAC
Line frequency 50 Hz / 60 Hz
Adapter rating (input) 100 VAC ~ 240 VAC, 1.8 A
Adapter rating (output) 19.0 VDC, 3.16 A
AC Adapter 2
Model Code AA-PA1N90W
Output Power 90 W
Dimension 126 x 50 x 30 mm (W x H x D)
Weight (AC Adapter) 430g (Max.)
Worldwide Compatibility Auto-sensing 100 - 240 VAC
Line Frequency 50 Hz / 60Hz
Adapter Rating - Input 100 VAC ~ 240 VAC, 1.5A
Adapter Rating - Output 19.0 VDC, 4.74 A
System dimensions
Dimensions (W x D x H) 358.3 x 269.2 x30.8 (min) ~ 36.5 (max.) mm
(14.1" x 10.6" x 1.21" (min) ~ 1.44" (max.) inch)
Weight 2.67Kg (5.89lbs) (With Weight saver : 2.53Kg (5.58lbs))
- Condition (with battery)
Package dimensions (W x D x H) 425 x 110 x 405 mm
Package weight 4.34 Kg
- Condition Status : supermulti , 6cell battery, 2.5” 80GB 2 platter HDD with Bundle items
Materials & Design
- LCD Back PC/ABS
- LCD Front PC/ABS
- System Top PC/ABS
- System Bottom PC/ABS
Installed software
Operating system Genuine Windows Vista® Home Premium SP1
Software Samsung Recovery Solution III (optional), Samsung Magic Doctor, Samsung Update Plus
Easy Display Manger, Easy Battery Manager, Easy Network Manager, Easy SpeedUp
Manager McAfee SecurityCenter, Adobe Acrobat Reader, Microsoft® Ofce Professional
2007 (free 60-day trial)

2-9
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
2-3. Comparing product specications
Lisbon(StandardModel) P560(Developmentmodel)
Feature
CPU 667/800MHz Intel Core 2 Duo Processor
(Merom) 800MHz/1066MHz Intel Core 2 Duo Processor (Penryn)
Chipset GM965 Intel GM45 / PM45
Memory DDR2 512MB ~ 4G DDR3 1G ~ 4G
Graphic Nvidia GF Go 8400 w/ 128MB
Nvidia GF Go 8600 w/ 256MB nVIDIA NB9P Series w/ 256MB & 512MB
LCD 15” SXGA+, Non-Glare 15.4” WXGA / WSXGA+, Glare / Non-Glare
HDD SATA SATA
ODD PATA 12.7mm SATA 12.7mm
Port VGA, PCMCIA, 6-in-1 VGA, HDMI, PCMCIA, 3-in-1

2-10
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
2-4. Comparing product specications jatasa
Model Toshiba Tecra S5 HP Compaq 6710b Sony VAIO FZ21Z Dell Latitude D830 Lenovo ThinkPad
T61
Feature
CPU Intel Core 2 Duo Intel Core 2 Duo Intel Core 2 Duo Intel Core 2 Duo Intel Core 2 Duo
Memory 2 GB 1 GB 2 GB 2 GB 2 GB
HDD 160 GB SATA
5400rpm 120 GB SATA 5400rpm 300 GBSATA 4200rpm 120 GB SATA 5400rpm 160 GB SATA 5400rpm
ODD DVD-Multi DVD-Multi BluRay-RE DVD-Multi DVD-Multi
Display 1680 x 1050
(WSXGA+) 1680 x 1050 (WSXGA+) 1280 x 800 (WXGA) 1920 x 1200(WUXGA) 1680 x 1050 (WSXGA+)
Graphic NVIDIA Quadro NVS
130M (256MB) Intel GMA X3100 NVIDIA GeForce 8600M GS (256MB) nVidia Quadro NVS 140M NVIDIA Quadro NVS 140M (128MB)
Network 802.11abgnBluetooth
2.0+EDR 802.11abgBluetooth 2.0+EDR 802.11abgnBluetooth 2.0 802.11abg Bluetooth 2.0+EDR 802.11abgn
Security Fingerprint
recognition
TPM, Fingerprint
recognition - - TPM, Fingerprint recognition
Battery -5.2 Cell -5 Cell 5.5 Cell

2-11
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
2-5. Option Material List
HDD
BA59-02355A HM320JI 5400RPM, 160G/P, 320G, SATA, 8M
BA59-02354A HM251JI 5400RPM, 160G/P, 250G, SATA, 8M
BA59-02347A MHZ2320BH-G2 5400RPM, 160G/P, 320G , SATA,8M
BA59-02346A MHZ2250BH-G2 5400RPM, 160G/P, 250G, SATA,8M
BA59-02345A MHZ2200BH-G2 5400RPM, 160G/P, 200G, SATA, 8M
BA59-02344A MHZ2160BH-G2 5400RPM, 160G/P, 160G, SATA, 8M
BA59-02343A MHZ2120BH-G2 5400RPM, 160G/P, 120G, SATA, 8M
BA59-02286A MK1246GSX 5400RPM, 125G/P, 120G, SATA, 8M
BA59-02226A WD1200BEVS-22UST0 5400RPM, 125G/P, 120G ,SATA,8M
BA59-02202A HTS542512K9A300 5400RPM, 125G/P, 120G, SATA,8M
BA59-02189A HM121HI 5400RPM, 160G/P, 120G, SATA, 8M
BA59-02208A MHY2120BH 5400RPM, 125G/P, 120G, SATA, 8M
BA59-02287A MK1646GSX 5400RPM, 125G/P, 160G, SATA, 8M
BA59-02279A WDC-WD1600BEVT-22ZCT0 5400RPM, 160G/P, 160G, SATA, 8M
BA59-02227A WD1600BEVS-22RST0 5400RPM, 80G/P, 160G, SATA, 8M
BA59-02187A HM160HI 5400RPM, 160G/P, 160G, SATA, 8M
BA59-02203A HTS542516K9A300 5400RPM, 125G/P, 160G, SATA, 8M
BA59-02209A MHY2160BH 5400RPM, 125G/P, 160G, SATA, 8M
BA59-02290A MK2046GSX 5400RPM ,125G/P, 200G , SATA,8M
BA59-02210A MHY2200BH 5400RPM, 125G/P, 200G, SATA, 8M
BA59-02210A MHY2200BH 5400RPM, 125G/P, 200G, SATA, 8M
BA59-02204A HTS542520K9A300 5400RPM, 125G/P, 200G, SATA, 8M
BA59-02204A HTS542520K9A300 5400RPM, 125G/P, 200G, SATA, 8M
BA59-02288A MK2546GSX 5400RPM, 125G/P, 250G, SATA, 8M
BA59-02228A WD2500BEVS-22UST0 5400RPM, 125G/P, 250G, SATA, 8M
BA59-02211A MHY2250BH 5400RPM, 125G/P, 250G, SATA, 8M
BA59-02205A HTS542525K9A300 5400RPM, 125G/P, 250G, SATA, 8M
BA59-02190A HM250JI 5400RPM, 160G/P, 250G, SATA, 8M
BA59-02280A WDC-WD3200BEVT-22ZCT0 5400RPM, 160G/P, 320G, SATA, 8M

2-12
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
LCD
BA59-02170A LTN154P4-L02-0 15.4”WSXGA+(High Bright, 200nit Gloss)
BA59-02276A LTN154P3-L04-0 15.4” WSXGA+(High Bright, 200nit Gloss)
BA59-02275A LTN154AT07-8 15.4” WXGA(High Bright, 200nit Gloss)
BA59-02350A LTN154AT10-8 15.4” WXGA(High Bright, 220nit Gloss)
MEMORY
1105-001923 M471B2874DZ1-CF8 1GB (DDR3 1066MHz/1G*1)
1105-001921 M471B5673DZ1-CF8 2GB (DDR3 1066MHz/2G*1)
CPU
0902-002337 T2_P8600 2.4 GHz, 1066 MHz, 3 MB, 25 W
0902-002336 T2_T9400 2.53 GHz, 1066 MHz, 6 MB, 35 W
0902-002342 T2_T9600 2.8 GHz, 1066 MHz, 6 MB, 35 W
0902-002341 T2_P8400 2.26 GHz, 1066 MHz, 3 MB, 25 W
0902-002340 T2_P9500 2.53 GHz, 1066 MHz, 6 MB, 25 W
0902-002331 T2_T5870 2.0 GHz, 800 MHz, 2 MB, 35 W
0902-002330 T2_T5670 1.8 GHz, 800 MHz, 2 MB, 35 W
0902-002356 T2_P7350 2.0 GHz, 90 MHz, 3 MB, 25 W

2-13
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
ODD
BA96-03666A TEAC DVD-ROM
BA96-03667A TSST DVD-ROM
BA96-03665A TSST Super Mul
BA96-03670A TEAC Super Mul
BA96-03671A TSST Super Mul
WLAN
BA59-02273A Intel Shirley Peak 3x3 AGN
BA59-02297A Intel Shirley Peak 1x2 AGN
BLUE TOOTH
BA59-01691A T60H928.01 Bluetooth V2.0, FOXCONN
BA59-01916A BTO2P0B2SA Bluetooth V2.0, SEM

2-14
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
2-6. Function of Product
2-6-1. Overview
FrontView
LCD
The screen images are
displayed here.
PowerButton
Turns the computer on and off.
Touchpad/TouchpadButtons
The touchpad and touchpad buttons provide
functions similar to the mouse ball and buttons.
MultiCardSlot
A card slot that supports SD
Card, SDHC, MMC.
CameraLens(Optional)
Using this lens, you can take still pictures and
record video.
Keyboard
A device to enter data by
pressing the keys.
StatusIndicators
Shows the operating status of the computer.
The corresponding operating LED is lit when
the corresponding function operates.
Speaker
A device used to generate
sound.
Speaker
A device used to generate
sound.
Microphone
FingerprintSensor(Optional)
You can turn the computer on
with your fingerprint or login to
Windows. For more information,
refer to the additionally supplied
manual. (Only for models with the
fingerprint identification system.)
AmbientLightSensor
A light-sensitive electronic
component used to adjust the
brightness of a LCD display’s
backlight.

2-15
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
StatusIndicators
ChargeStatus
This shows the power source
and the battery charge status.
Green: When the battery is fully
charged or the battery is
not installed.
Amber: When the battery is
being charged.
Off: When the computer is
running on battery power
without being connected to
AC adapter.
Power
This shows the computer
operating status.
On: When the computer is
operating
Blinks: When the computer is
in Sleep mode.
CapsLock
This turns on when the Caps
Lock key is pressed allowing
capital letters to be typed
without holding the Shift
button down.
HDD
This turns on when the hard disk
is being accessed.
WirelessLAN
This turns on when the wireless
LAN is operating.
NumLock
This turns on when the Num
Lock key is pressed and numeric
keypad is activated.
ScrollLock
This turns on when the Scroll
Lock key is pressed and screen
scroll is locked.

2-16
2. Introduction and Specication
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
RightView
ModemPort(Optional)
A port to which a telephone cable is connected to in order to
dial up to the Internet. To use the modem port, open up the
rubber cap on the port.
CDDrive(ODD)(Optional)
Plays CD or DVD titles.Since an ODD(Optical
Disk Drive) is optional, the installed drive
depends on the computer model.
USBPort
You can connect USB devices to the
USB port such as a keyboard/mouse,
digital camera, etc.
