Samsung R408 plus User manual

R408 plus
User Guide

3
Contents
Chapter 1. Getting Started
Cautions Regarding OS Support 6
Before You Start 7
Safety Precautions 9
Proper Posture During Computer Use 23
Important Safety Information 26
Replacement Parts and Accessories 28
Regulatory Compliance Statements 30
WEEE SYMBOL INFORMATION 42
Basic Items 43
Overview 44
Front View 44
Status Indicators 45
Right View 46
Left View 47
Back View 48
Bottom View 49
Turn on the computer 50
Attaching the Battery 50
Connect the AC adapter 50
Turn on the computer 51
Using Sleep Mode 52
Chapter 2. Using the computer
Keyboard 54
Touchpad 58
CD Drive (ODD, Optional) 59
Inserting and Ejecting a CD 59
Multi Card Slot 61
ExpressCard Slot 63
Adjusting the Volume 64
Chapter 3. Settings and Upgrade
LCD Brightness Control 66
BIOS Setup 67
Entering the BIOS Setup 67
The BIOS Setup Screen 68
Setting a Boot Password 70
Changing the Boot Priority 72
Upgrading Memory 73
Battery 75
Installing/Removing the Battery 75
Charging the Battery 76
Measuring the Remaining Battery Charge 76
Extending the Battery Usage Time 77
Using the Security Lock Port 78
Chapter 4. Appendix
Product Specications 80

4

5
Chapter 1.
Getting Started
Contents 3
Cautions Regarding OS Support 6
Before You Start 7
Safety Precautions 9
Proper Posture During Computer Use 23
Important Safety Information 26
Replacement Parts and Accessories 28
Regulatory Compliance Statements 30
WEEE SYMBOL INFORMATION 42
Basic Items 43
Overview 44
Front View 44
Status Indicators 45
Right View 46
Left View 47
Back View 48
Bottom View 49
Turn on the computer 50
Attaching the Battery 50
Connect the AC adapter 50
Turn on the computer 51
Using Sleep Mode 52

6
Cautions Regarding OS Support
zWindows is neither installed nor supplied with this computer.
xTherefore, customers should purchase a Windows XP or Windows Vista software license and install the
software. Do not install an illegal copy or a copy that has already been installed on another PC.
cFor the installation procedures and any issues with the operating systems or applications not supplied by
Samsung Computer, contact the corresponding software company.
vThe company will not provide a replacement or refund due to the reason x, c and if our service engineer
visits you due to this problem, a service charge will be applied.
Charge the battery fully when using the computer for the rst time.

7
Before You Start
Before reading the User Guide, rst check the following information.
Safety Precaution Notations
Icon Notation Description
Warning
Failing to follow instructions marked with this symbol, may cause personal
injury and or fatality.
Caution
Failing to follow instructions marked with this symbol, may cause slight
injury to yourself or damage your property.
Text Notations
Icon Notation Description
Before You Start
Content included in this section includes information required before using
a function.
Caution
Content included in this section includes information required about the
function.
Note
Content included in this section includes helpful information to use the
function.
Copyright
© Samsung Electronics Co., Ltd., 2008
Samsung Electronics Co., Ltd. owns the copyright of this manual.
No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical,
without the consent of Samsung Electronics Co., Ltd.
The information in this document is subject to change without notice due to improving the performance of the product.
Samsung Electronics shall not be liable for any data loss. Please take care to avoid losing any important data and
backup your data to prevent any such data loss.

8
About the Product Capacity Representation Standard
About HDD Capacity Representation
The capacity of the storage device (HDD, SSD) of the manufacturer is calculated assuming that 1KB=1,000 Bytes.
However, the operating system (Windows) calculates the storage device capacity assuming that 1KB=1,024 Bytes,
and therefore the capacity representation of the HDD in Windows is smaller than the actual capacity due to the
difference in capacity calculation.
(E.g. For a 80GB HDD, Windows represents the capacity as 74.5GB, 80x1,000x1,000x1,000 byte/
(1,024x1,024x1,024)byte = 74.505GB)
In addition, the capacity representation in Windows may be even smaller because some programs such as Recovery
Solution may reside in a hidden area of the HDD.
About Memory Capacity Representation
The memory capacity reported in Windows is lesser than the actual capacity of memory.
This is because BIOS or a video adapter uses a portion of memory or claims it for further use.
(E.g. For 1GB(=1,024MB) memory installed, Windows may report the capacity as 1,022MB or less)

9
Installation Related
Do not install the product in
places exposed to humidity such
as a bathrooms.
There is a danger of electric
shock. Use the product within the
operating conditions specied in
the Manufacturers User Guide.
Keep the plastic bags out of the
reach of children.
There is a danger of suffocation.
Keep a distance of 15cm or more
between the computer and the
wall and do not place any objects
between them.
This may increase the internal
temperature of the computer and
may cause an injury.
Do not install the computer
on a slant or a place prone to
vibrations, or avoid using the
computer in that location for a
long time.
This increases the risk that a
malfunction or damage to the
product will occur.
Avoid exposing any part of
your body to the heat from the
computer vent for a long time
when it is on.
Exposing a part of your body to the
heat from the vent for long periods
of time may cause a burn.
Avoid blocking the vent at the
bottom or side of the computer
when using it on a bed or cushion.
If the vent is blocked, there is a
danger of damaging the computer
or overheating the inside of the
computer.
Safety Precautions
For your security and to prevent damage, please read the following safety instructions carefully.
Since this is commonly applied to Samsung Computers, some pictures may differ from actual product.
N/P Ver 1.4
Warning
Failing to follow instructions marked with this symbol may cause personal injury and even fatality.

10
Power Related
The power plug and wall outlet gures may differ depending on the country specications and the product model.
Do not touch the mains plug or
power cord with wet hands.
There is a danger of electric shock.
Do not exceed the standard
capacity (voltage/current) of
a multiplug or power outlet
extension when using it for the
product.
There is a danger of electric shock
or re hazard.
If the power cord or power outlet
makes a noise, disconnect the
power cord from the wall outlet
and contact a service center.
There is a danger of electric shock
or re hazard.
Do not use a damaged or loose
mains plug or power cord or power
outlet.
There is a danger of electric shock
or re hazard.
Plug the power cord rmly into the
power outlet and AC adapter.
Failing to do so may cause re
hazard.
Do not unplug the power cord out
by pulling the cable only.
If the cord is damaged, it may
cause electric shock.

11
Do not bend the power cord
excessively or do not place a
heavy object over the power cord.
It is especially important to keep
the power cord out of reach of
infants and pets.
If the cord is damaged, it may
cause electric shock or re.
If water or another substance
enters the power input jack,
AC adapter or the computer,
disconnect the power cord and
contact the service center.
Damage to the device within the
computer may cause electric
shock or re hazard.
Do not place heavy objects or
step onto the power cord or AC
adapter to avoid damaging the
power cord or AC adapter.
If the cord is damaged, there is a
danger of electric shock or re.
Use only the AC adapter
supplied with the product.
Using another adapter may cause
the screen to icker.
AC Adapter Usage
Precautions

12
Connect the power cord to the
AC adapter rmly.
Otherwise, there is a danger of
re due to an incomplete contact.
Battery Usage Related
Keep the battery out of the reach
of infants and pets, as they could
put the battery into their mouths.
There is a danger of electric shock
or choking.
Use an authorized battery and AC
adapter only.
Please use an authorized
battery and adapter approved by
Samsung Electronics.
Unauthorized batteries and
adapters may not meet the proper
safety requirements and may
cause problems or malfunctions
and result in an explosion or re.
Authorized
Parts

13
Do not use the computer in a
badly ventilated location such
as on bedding, on a pillow or
cushion, etc, and do not use it
in a location such as room with
oor heating as it may cause the
computer to overheat.
Take care that the computer
vents (on the side or the bottom)
are not blocked especially in
these environments. If the vents
are blocked, the computer may
overheat and it may cause a
computer problem, or even
explosion.
Do not use the computer in
a humid location such as a
bathroom or sauna.
Please use the computer within the
recommended temperature and
humidity range (10~32ºC, 20~80%
RH).
Do not close the LCD panel and
put the computer into your bag to
move it when it is still turned on.
If you put the computer into
your bag without turning it off,
the computer may overheat and
there is a danger of re. Shut the
computer down properly before
moving it.
Never heat the battery or put the
battery into a re. Do not put or
use the battery in a hot location
such as a sauna, inside a vehicle
exposed to the heat, and so on.
There is a danger of an explosion
or re.
Power Off

14
Take care not to allow metal
objects such as a key or clip to
touch the battery terminal (metal
parts).
If a metal object touches the battery
terminals, it may cause excessive
current ow and it may damage the
battery, or result in a re.
If liquid leaks out of the battery or
there is a funny smell coming from
the battery, remove the battery
from the computer and contact a
service center.
There is a danger of an explosion
or re.
To use the computer safely,
replace a dead battery with a new,
authorized battery.
Please charge the battery
fully before using the
computer for the rst time.

15
Disconnect all cables connected
to the computer before cleaning
it. If you are using a notebook
computer, remove the battery.
There is a danger of electric shock
or damage to the product.
Do not connect a phone line
connected to a digital phone to the
modem.
There is a danger of a electric
shock, re or damage to the
product.
Do not place any container lled
with water or chemicals over or
near the computer.
If water or chemicals enter the
computer, this may cause re or
electric shock.
If the computer is broken or
dropped, disconnect the power
cord and contact a service center
for a safety check.
Using a broken computer may
cause electric shock or re hazard.
Avoid direct sunlight when
the computer is in an air-tight
location such as inside a vehicle.
There is a danger of a re hazard.
The computer may overheat and
also present opportunity to thieves.
Usage Related

16
Never disassemble the power
supply or AC adapter.
There is a danger of electric
shock.
When removing the RTC (Real
Time Clock) battery, keep it out
of the reach of children as they
could touch and/or swallow it.
There is a danger of choking. If a
child has swallowed it, contact a
doctor immediately.
Use only authorized parts
(multiplug, battery and memory)
and never disassemble parts.
There is a danger of damaging
the product, electric shock or re
hazard.
Shut down the computer and
disconnect all cables before
disassembling the computer. If
there is a modem, disconnect
the phone line. If you are using a
notebook computer, make sure to
remove the battery.
Failing to do so, may cause
electric shock.
Upgrade Related

17
Custody and Movement Related
Follow the instructions for the
relevant location (e.g. airplane,
hospital, etc.) when using a
wireless communication device
(wireless LAN, Bluetooth, etc.).
When carrying the notebook
computer with other items, such
as the adapter, mouse, books etc,
take care not to press anything
against the notebook computer.
If a heavy object is pressed
against the notebook computer,
a white stop or stain may appear
on the LCD. Therefore, take care
not to apply any pressure to the
notebook.
In this case, place the notebook
computer in a separate
compartment away from the other
objects.

18
Caution
Failing to follow instructions marked with this symbol may cause slight injury or damage to the product.
Installation Related
Do not block the ports (holes),
vents, etc. of the product and do
not insert objects.
Damage to a component within
the computer may cause electric
shock or re.
When using the computer with it
lying on its side, place it so that
the vents face upwards.
Failing to do so, may cause
the internal temperature of the
computer to rise and the computer
to malfunction or halt.
Do not place a heavy object over
the product.
This may cause a problem with
the computer. In addition, the
object may fall and cause injury, or
damage the computer.
Dispose of worn-out batteries
properly.
- There is a danger of re or
explosion.
- The battery disposal method
may differ depending on your
country and region. Dispose
of the used battery in an
appropriate way.
Do not throw or disassemble
the battery and do not put it into
water.
This may cause an injury, re or
explosion.
Use only a battery authorized by
Samsung Electronics.
Failing to do so may cause an
explosion.
Battery Usage Related

19
Usage Related
Do not place a candle, lighted
cigar, etc. over or on the product.
There is a danger of re.
Use a wall outlet or multi-plug
with a grounding part.
Failing to do so may cause electric
shock hazard.
Make sure to have the product
tested by a safety service
engineer after repairing the
product.
Authorized Samsung Repair
Centers will carry out safety checks
after a repair. Using a repaired
product without testing it for safety
may cause an electric shock or re.
In case of lightning, immediately
turn the system off, disconnect
the power cord from the wall
outlet and line do not use a
modem or phone.
There is a danger of electric shock
or re.
Do not use your computer and
AC Adapter on your lap or soft
surfaces.
If the computer temperature
increases, there is a danger of
burning yourself.
Connect only permitted devices
to the connectors or ports of the
computer.
Failing to do so, may cause electric
shock and re.
Close the LCD panel only
after checking if the notebook
computer is turned off.
The temperature may rise and
it may cause overheating and
deformation of the product.
Avoid contact with metal objects
such as car keys or clips when
keeping or carrying a battery.
Contact with a metal may cause
excessive current and a high
temperature and may damage the
battery or cause a re.
Charge the battery according to
the instructions in the manual.
Failing to do so, may cause an
explosion or re from damage to
the product.
Do not heat the battery or expose
it to heat (e.g. inside a vehicle
during the summer).
There is a danger of explosion or
re.

20
Do not press the Eject Button
while the Floppy Disk/CD-ROM
drive is in operation.
You might lose data and the disk
might be suddenly ejected and
could cause an injury.
Take care not to drop the product
while using it.
This may cause personal injury or
loss of data.
Do not contact the antenna with
electricity facility such as the
power outlet.
There is a danger of electric shock.
When handling computer parts,
follow the instructions on the
manual supplied with the parts.
Failing to do so, may cause
damage to the product.
If the computer emits smoke,
or there is a burning smell,
disconnect the power plug from
the wall outlet and contact a
service center. If your computer is
a notebook computer, make sure
to remove the battery.
There is a danger of re.
Do not use a damaged or modied
CD/Floppy Disk.
There is a danger of damaging the
product or personal injury.
Do not insert your ngers into the
PC Card Slot.
There is a danger of injury or
electric shock.
Use recommended computer
cleansing solution when cleaning
the product and only use the
computer when it is completely
dried.
Failing to do so may cause electric
shock or re.
Emergency disk eject method
using paperclip should not be
used while the disk is in motion.
Make sure to use the emergency
disk eject method only when the
Optical Disk Drive is stopped.
There is a danger of injury.
Do not place your face close to
the Optical Disk Drive tray when it
is operating.
There is a danger of injury due to
an abrupt ejection.
Check CDs for cracks and damage
prior to use.
It may damage the disc and cause
disorder of device and injury of
user.
