Samsung 5 Series User manual

Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.
Country Customer Care Centre Web Site
AUSTRIA 0800-SAMSUNG (726-7864) www.samsung.com/at
BELGIUM 0032 (0)2 201 24 18 www.samsung.com/be
CZECH REPUBLIC
844 000 844 www.samsung.com/cz
Distributor pro Českou republiku:
Samsung Zrt., česka organizační složka Vyskočilova 4, 14000 Praha 4
DENMARK 70 70 19 70 www.samsung.com/dk
EIRE 0818 717 100 www.samsung.com/ie
FINLAND 030-6227 515 www.samsung.com/
FRANCE 3260 SAMSUNG (€ 0,15/Min)
08 25 08 65 65 (€ 0,15/Min) www.samsung.com
GERMANY 01805 - SAMSUNG (726-7864) (€ 0,14/Min) www.samsung.com
HUNGARY 06-80-SAMSUNG (726-7864) www.samsung.com
ITALIA 800-SAMSUNG (726-7864) www.samsung.com
LUXEMBURG 0035 (0)2 261 03 710 www.samsung.com/be
NETHERLANDS 0900-SAMSUNG (726-7864) (€ 0,10/Min) www.samsung.com/nl
NORWAY 815-56 480 www.samsung.com/no
POLAND 0 801 801 881
022-607-93-33 www.samsung.com/pl
PORTUGAL 80820-SAMSUNG (726-7864) www.samsung.com/pt
SLOVAKIA 0800-SAMSUNG (726-7864) www.samsung.com/sk
SPAIN 902 10 11 30 www.samsung.com
SWEDEN 0771-400 200 www.samsung.com/se
SWITZERLAND 0800-SAMSUNG (726-7864) www.samsung.com/ch
U.K 0845 SAMSUNG (7267864) www.samsung.com
TURKEY 444 77 11 www.samsung.com
ESTONIA 800-7267 www.samsung.ee
LATVIA 800-7267 www.samsung.com/lv
LITHUANIA 8-800-77777 www.samsung.lt
KAZAHSTAN 8-10-800-500-55-500 www.samsung.kz
KYRGYZSTAN 00-800-500-55-500 -
RUSSIA 8-800-555-55-55 www.samsung.ru
TADJIKISTAN 8-10-800-500-55-500 -
UKRAINE 8-800-502-0000 www.samsung.com
UZBEKISTAN 8-10-800-500-55-500 www.samsung.uz
LCD TV
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/global/register
Model Serial No.
BN68-01409H-01
BN68-01409H-00ENG.indb 1 2008-04-28 �� 5:18:08

Precautions When Displaying a Still Image
A still image may cause permanent damage to the TV screen
Do not display a still image on the LCD panel for more than 2 hours as it can cause screen image retention. This image
retention is also known as “screen burn”. To avoid such image retention, reduce the degree of brightness and contrast of the
screen when displaying a still image.
Watching the LCD TV in 4:3 format for a long period of time may leave traces of borders displayed on the left,
right and center of the screen caused by the difference of light emission on the screen.
Playing a DVD or a game console may cause a similar effect to the screen.
Damages caused by the above effect are not covered by the Warranty.
Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images.
To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images.
•
•
•
© 2008 Samsung Electronics Co., Ltd. All rights reserved.
Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.
(See back cover for more informations.)
BN68-01409H-00ENG.indb 2 2008-04-28 �� 5:18:09

Connecting and Preparing Your TV
List of Parts........................................................................2
Installing the Stand ............................................................2
Installing the Wall Mount Kit ..............................................2
Viewing the Control Panel .................................................3
Viewing the Connection Panel...........................................4
Remote Control .................................................................7
Installing Batteries in the Remote Control .........................8
Switching On and Off.........................................................8
Placing Your Television in Standby Mode..........................8
Viewing the Menus ............................................................9
Using the TOOLS Button...................................................9
Plug & Play Feature...........................................................9
Channel Control
Storing Channels Automatically.......................................11
Storing Channels Manually..............................................11
Viewing the EPG (Electronic Programme Guide)
Information.......................................................................13
Setting the Default Guide ................................................14
Managing Channels.........................................................15
Setting the Channel Mode ...............................................22
Activating the Child Lock .................................................22
Fine Tuning Analogue Channels......................................23
Checking the Digital-Signal Information ..........................23
LNA (Low Noise Amplier)...............................................24
Picture Control
Changing the Picture Standard .......................................25
Customizing the Picture Settings.....................................25
Adjusting the Detailed Settings........................................26
Conguring Picture Options.............................................27
Resetting the Picture Settings to the Factory Defaults ....28
Viewing Picture-in-Picture ...............................................29
Sound Control
Changing the Sound Standard ........................................30
Selecting the Sound Mode ..............................................32
Connecting Headphones (Sold separately).....................32
Time Setting
Setting the Clock .............................................................33
Setting the Sleep Timer ...................................................34
Switching the Television On and Off Automatically..........35
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
Function Description
Selecting a Menu Language............................................36
Setting Up Your Personal ID Number (PIN).....................36
Setting up the Parental Lock ...........................................37
Setting the Subtitle ..........................................................38
Selecting a Teletext Language ........................................39
Selecting a Preference Language ...................................39
Setting the Light Effect (depending on the model) ..........39
Melody/Entertainment/Energy Saving .............................40
Upgrading the Software...................................................41
Viewing Common Interface .............................................42
Selecting the CI (Common Interface) Menu ....................42
To Select the Source .......................................................43
To Edit the Input Source Name........................................43
PC Display
Using Your TV as a Computer (PC) Display....................44
Display Modes .................................................................44
Setting up the TV with your PC .......................................45
WISELINK
Using the WISELINK Function ........................................46
Using the Photo List ........................................................47
Sorting Photo List ............................................................49
Viewing a Photo or Slide Show ......................................53
Using the Music List ........................................................57
Sorting Music List ............................................................58
Playing a Music File.........................................................62
Using the Setup Menu .....................................................64
About Anynet+
What is Anynet+?.............................................................65
Connecting Anynet+Devices...........................................65
Setting Up Anynet+.........................................................66
Scanning and Switching between Anynet+Devices........66
Recording ........................................................................67
Listening through a Receiver (Home theater)..................68
Troubleshooting for Anynet+...........................................68
Recommendations for Use
Teletext Feature...............................................................69
Auto Wall-Mount Adjustment (Sold separately) ..............70
Using the Anti-Theft Kensington Lock (depending on the
model)..............................................................................72
Securing the TV to the Wall .............................................73
Troubleshooting: Before Contacting Service Personnel..74
Specications ..................................................................75
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
English - 1
English
Contents
Symbol Press Note One-Touch Button
BN68-01409H-00ENG.indb 1 2008-04-28 �� 5:18:09

English - 2
List of Parts
Please make sure the following items are included with your LCD TV. If any items are missing, contact your dealer.
Remote Control &
Batteries (AAA x 2) Power Cord Cover-Bottom Stand Screw
(M4xL 16) Stand Cleaning Cloth
Owner’s Instructions • Warranty card • Safety Guide • Registration Cards •
Warranty card / Safety Guide / Registration Cards (Not available in all locations)
The stand and stand screw may not be included depending on the model.
➣
➣
Connecting and Preparing Your TV
Installing the Stand
1. Connect your LCD TV and the stand.
Two or more people should carry the TV.
Make sure to distinguish between the front and back of the stand when assembling them.
2. Fasten two screws at position 1and then fasten two screw at position 2.
Stand the product up and fasten the screws. If you fasten the screws with the LCD TV placed down, it may lean to
one side.
The stand is installed for models with the screen size of 37 inch and above.
➣
➣
➣
➣
Installing the Wall Mount Kit
Wall mount items (sold separately) allow you to mount the TV on the wall.
For detailed information on installing the wall mount, see the instructions
provided with the Wall Mount items. Contact a technician for assistance when
installing the wall mounted bracket.
Samsung Electronics is not responsible for any damage to the product or injury
to yourself or others if you elect to install the TV on your own.
Do not install your Wall Mount Kit while your TV is turned on. It may
result in personal injury due to electric shock.
Remove the stand and cover the bottom hole with a cap and fasten with
two screws.
➣
BN68-01409H-00ENG.indb 2 2008-04-28 �� 5:18:11

English - 3
Viewing the Control Panel
8 8
4
1
2
3
5
6
7
1
2
3
4
6
7
58 8
The product colour and shape may vary depending on the model. ➣
Front Panel buttons
Touch each button to
operate.
1 SOURCE
Toggles between all the available input sources
(TV, Ext.1, Ext.2, AV, S-Video, Component, PC, HDMI1,
HDMI2/DVI, HDMI3). In the on-screen menu, use this
button as you would use the ENTER button on the
remote control.
2 MENU
Press to see an on-screen menu of your TV’s features.
3 – +
Press to increase or decrease the volume.
In the on-screen menu, use the – + buttons as you
would use the ◄ and ► buttons on the remote control.
4 C/P.
Press to change channels. In the on-screen menu, use
the C/P. buttons as you would use the ▼ and ▲
buttons on the remote control.
5 POWER INDICATOR
Blinks and turns off when the power is on and lights up
in stand-by mode.
6 (Power)
Press to turn the TV on and off.
7 REMOTE CONTROL SENSOR
Aim the remote control towards this spot on the TV.
8 SPEAKERS
Side Panel Buttons
BN68-01409H-00ENG.indb 3 2008-04-28 �� 5:18:12

English - 4
Viewing the Connection Panel
Whenever you connect an external device to your TV, make sure that power on the unit is turned off.
When connecting an external device, match the colour of the connection terminal to the cable.
1 PC IN [PC] / [AUDIO]
Connect to the video and audio output jack on your PC.
2 COMPONENT IN
- Connect component video cables (optional) to component connector (“PR”, “PB”, “Y”) on the rear of your set and the
other ends to corresponding component video out connectors on the DTV or DVD.
- If you wish to connect both the Set-Top Box and DTV (or DVD), you should connect the Set-Top Box to the DTV
(or DVD) and connect the DTV (or DVD) to component connector (“PR”, “PB”, “Y”) on your set.
- The PR, PB and Y connectors on your component devices (DTV or DVD) are sometimes labeled Y, B-Y and R-Y or Y,
Cb and Cr.
- Connect RCA audio cables (optional) to “R - AUDIO - L” on the rear of your set and the other ends to corresponding
audio out connectors on the DTV or DVD.
3 HDMI IN 1, HDMI IN 2, HDMI IN 3
- Supports connections between HDMI-connection-enabled AV devices (Set-Top Boxes, DVD players)
- No additional Audio connection is needed for an HDMI to HDMI connection.
- When using an HDMI/DVI cable connection, you must use the HDMI IN 2 jack.
➣
➣
1 2 3 4
0!@#
5
6
3
7
8
9
[TV Side Panel]
[TV Rear Panel]
The product colour and shape may vary depending on the model.
➣
Power Input
BN68-01409H-00ENG.indb 4 2008-04-28 �� 5:18:12

English - 5
What is HDMI?
- “High Denition Multimedia interface” allows the transmission of high denition digital video data and multiple channels
of digital audio.
- The HDMI/DVI terminal supports DVI connection to an extended device with the appropriate cable (not supplied).
The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP (High Bandwidth
Digital Copy Protection) coding feature installed, and supports multi - channel digital audio.
The TV may not output sound and pictures may be displayed with abnormal colour when DVD players/Cable Boxes/
Satellite receivers supporting HDMI versions older than 1.3 are connected. When connecting an older HDMI cable
and there is no sound, connect the HDMI cable to the HDMI IN 2 jack and the audio cables to the DVI IN (HDMI2)
[R-AUDIO-L] jacks on the back of the TV. If this happens, contact the company that provided the DVD player/Cable
Box/Satellite receiver to conrm the HDMI version, then request a rmware update. HDMI cables that are not 1.3 may
cause annoying icker or no screen display.
DVI IN(HDMI2) [R-AUDIO-L]
- DVI audio outputs for external devices.
Supported modes for HDMI/DVI and Component.
480i 480p 576i 576p 720p 1080i 1080p
HDMI/DVI 50Hz X X X O O O O
HDMI/DVI 60Hz X O X X O O O
Component O O O O O O O
4 ANT IN
To view television channels correctly, a signal must be received by the set from one of the following sources:
- An outdoor aerial / A cable television network / A satellite network
5 SERVICE
- Connector for SERVICE only.
- Connect this to the jack on the optional wall mount bracket. This will allow you to adjust the TV viewing angle using
your remote control.
6 COMMON INTERFACE Slot
- When not inserting “CI CARD” in some channels,”Scrambled Signal” is displayed on the screen.
- The pairing information containing a telephone number, CI CARD ID, Host ID and other information will be displayed in
about 2~3 minutes. If an error message is displayed, please contact your service provider.
- When the channel information conguration has nished, the message “Updating Completed” is displayed, indicating
that the channel list is now updated.
You must obtain a CI CARD from a local cable service provider. Remove the CI
CARD by carefully pulling it out with your hands since dropping the CI CARD
may cause damage to it.
Insert the CI-Card in the direction marked on it.
The place of the COMMON INTERFACE Slot may be different depending on its
model.
7 WISELINK
Connect a USB mass storage device to view photo les (JPEG) and play audio les (MP3).
8 S-VIDEO or VIDEO / R-AUDIO-L
- Connect RCA or S-VIDEO cable to an appropriate external A/V device such as VCR, DVD or Camcorder.
- Connect RCA audio cables to “R-AUDIO-L” on your set and the other ends to corresponding audio out connectors on
the A/V device.
9 HEADPHONES JACK
Headphone may be connected to the headphone output on your set. While the head phone is connected, the sound
from the built-in speakers will be disabled.
0 AUDIO OUT [R-AUDIO-L]
Connect RCA audio cables to AUDIO OUT [R-AUDIO-L] on the rear of your set and the other ends to corresponding
audio in connectors on the Amplier or DVD Home Theatre.
➣
➣
➣
➣
➣
➣
BN68-01409H-00ENG.indb 5 2008-04-28 �� 5:18:12

English - 6
! DIGITAL AUDIO OUT (OPTICAL)
- Connects a set of external headphones for private listening.
When the HDMI IN jacks are connected, the DIGITAL AUDIO OUT (OPTICAL) jack on the TV outputs 2 channel
audio only. If you want to hear 5.1 channel audio, connect the Optical jack on the DVD player or Cable/Satellite Box
directly to an Amplier or Home Theater, not the TV.
@ EXT 1, EXT 2
Connector Input Output
Video Audio (L/R) RGB Video + Audio (L/R)
EXT 1 O O O Only TV or DTV output is available.
EXT 2 O O Output you can choose.
- Inputs or outputs for external devices, such as VCR, DVD, video game device or video disc players.
# KENSINGTON LOCK (depending on the model)
- The Kensington Lock (optional) is a device used to physically x the system when used in a public place.
- If you want to use a locking device, contact the dealer where you purchased the TV.
- The location of the Kensington Lock may be different depending on its model.
➣
BN68-01409H-00ENG.indb 6 2008-04-28 �� 5:18:13

English - 7
Remote Control
You can use the remote control up to a distance of about 23 feet from the TV.
1Television Standby button
2Selects the TV mode
directly
3Number buttons for directNumber buttons for direct
channel access
4One/Two-digit channel
selection
5+: Volume increase
-: Volume decrease
6Temporary sound switch-Temporary sound switch-
off
7Electronic Program GuideElectronic Program Guide
(EPG) display
8Use to quickly selectUse to quickly select
frequently used functions.
9Use to see information onUse to see information on
the current broadcast
0Colour buttons :Colour buttons :
Use these buttons in
the Channel list and
WISELINK, etc.
@Press to select the optionalPress to select the optional
display and sound modes
for sports, cinema and
games.
#Use these buttons in theUse these buttons in the
DMA, WISELINK, and
Anynet+.
( : This remote can be
used to control recording
on Samsung recorders
with the Anynet+feature)
$Available source selectionAvailable source selection
% Previous channel
^P<: Next channel
P>: Previous channel
&Displays the main on-Displays the main on-
screen menu
*This function enables youThis function enables you
to view and play photo
and music files from an
external device.
(Returns to the previousReturns to the previous
menu
)Control the cursor in theControl the cursor in the
menu
aExit the on-screen menuExit the on-screen menu
bUse this when connecting
a SAMSUNG DMA
(Digital Media Adapter)
device through an HDMI
interface and switching
to DMA mode. (The DMA
button is optional.) For
more information on the
operating procedures,
refer to the user manual
of the DMA. This button
is available when
“Anynet+(HDMI-CEC)" is
“On” (see page 66)
cPicture size selectionPicture size selection
dDigital subtitle displayDigital subtitle display
eIt display "Channel List"It display "Channel List"
on the screen.
Teletext Functions
2 Exit from the teletext
display
7 Teletext store
8 Teletext size selection
9 Teletext reveal
0 Fastext topic selection
! Alternately select Teletext,
Double, or Mix.
$ Teletext mode selection
(LIST/FLOF)
% Teletext sub page
^ P<: Teletext next page
P>: Teletext previous
page
& Teletext index
( Teletext hold
a Teletext cancel
The performance of the remote control may be affected by bright light.
➣
1_BN68-01409H-Eng.indd 7 2008-04-29 �� 3:03:41

English - 8
Installing Batteries in the Remote Control
1. Lift the cover at the back of the remote control upward as shown in the gure.
2. Install two AAA size batteries.
Make sure to match the “+” and “–” ends of the batteries with the diagram inside the
compartment.
3. Replace the cover.
Remove the batteries and store them in a cool, dry place if you won’t be using the remote
control for a long time.
If the remote control doesn’t work, check the following:
1. Is the TV power on?
2. Are the plus and minus ends of the batteries reversed?
3. Are the batteries drained?
4. Is there a power outage or is the power cord unplugged?
5. Is there a special uorescent light or neon sign nearby?
➣
➣
➣
Switching On and Off
The mains lead is attached to the rear of your set.
1. Plug the mains lead into an appropriate socket.
The standby indicator lights up on your set.
2. Press the button on your set.
You also can press the POWER button or the TV/DTV button on the remote control to turn the TV on.
The programme that you were watching last is reselected automatically.
3. Press the numeric button (0~9) or channel up/down ( / ) button on the remote control or C/P. button on
your set.
When you switch the set on for the very rst time, you will be asked to choose language in which the menus are to
be displayed.
4. To switch your set off, press the POWER button again.
Placing Your Television in Standby Mode
Your set can be placed in standby mode in order to reduce the power consumption. The standby mode can be useful when
you wish to interrupt viewing temporarily (during a meal, for example).
1. Press the POWER button on the remote control.
The screen is turned off and a red standby indicator appears on your set.
2. To switch your set back on, simply press the POWER , numeric buttons (0~9), TV/DTV button or channel up/down
( / ) button again.
Do not leave your set in standby mode for long periods of time (when you are away on holiday, for example). It is
best to unplug the set from the mains and aerial.
➣
➣
➣
➣
➣
➣
BN68-01409H-00ENG.indb 8 2008-04-28 �� 5:18:13

English - 9
Viewing the Menus
1. With the power on, press the MENU button.
The main menu appears on the screen.
The menu’s left side has icons: Picture, Sound, Channel, Setup, Input,
Application.
2. Press the ▲ or ▼ button to select one of the icons.
Then press the ENTER button to access the icon’s sub-menu.
3. Press the EXIT button to exit.
The on-screen menus disappear from the screen after about one minute.
➣
Using the TOOLS Button
You can use the TOOLS button to select your frequently used functions quickly and easily. The “TOOLS” menu changes
depending on which external input mode you are viewing.
1. Press the TOOLS button.
The “Tools” menu will appear.
2. Press the ▲ or ▼ button to select a menu.
3. Press the ▲/▼/◄/►/ENTER buttons to display, change, or use the
selected items. For a more detailed description of each function, refer to the
corresponding page.
Device List: see page 66
Picture Mode: see page 25
Sound Mode: see page 30
Sleep Timer: see page 34
SRS TS XT: see page 30
Energy Saving: see page 40
Dual l ll: see page 32
PIP: see page 29
Auto Adjustment: see page 45
•
•
•
•
•
•
•
•
•
Plug & Play Feature
When the TV is initially powered on, basic settings proceed automatically and subsequently.
1. Press the POWER button on the remote control.
The message “Les menus Langue, Enr. démo, Canaux et Heure seront
dénis.” is displayed.
2. Press the ENTER button, then “Sélectionnez la langue de l'OSD.” menu is
automatically displayed. Press the ENTER button.
3. Select the appropriate language by pressing the ▲ or ▼ button. Press the
ENTER button to conrm your choice.
Mode : Standard
Backlight : 7
Contrast : 95
Brightness : 45
Sharpness : 50
Colour : 50
Tint (G/R) : G50/R50
Detailed Settings
Tools
Device List
Picture Mode : Standard
Sound Mode : Custom
Sleep Timer : Off
SRS TS XT : Off
Energy Saving : Off
Dual l ll : Mono
e Exit
EnterMove
Plug & Play
Les menus Langue, Enr. démo, Canaux et Heure seront définis.
Entrer
OK
Plug & Play
Sélectionnez la langue de l’OSD.
Langue : Français ►
Entrer
BN68-01409H-00ENG.indb 9 2008-04-28 �� 5:18:14

English - 10
4. Press the ◄ or ► button to select “Store Demo” or “Home Use”, then the
ENTER button.
We recommend setting the TV to “Home Use” mode for the best picture in
your home environment.
“Store Demo” mode is only intended for use in retail environments.
If the unit is accidentally set to “Store Demo” mode and you want to return
to “Home Use” (Standard): Press the Volume button on the TV. When the
volume OSD is displayed, press and hold the MENU button on the TV for
5 seconds.
5. Press the ▲ or ▼ button to select the channel source to memorize. Press the
ENTER button to select “Start”.
Digital & Analogue: “Digital” and “Analogue” channels.
Digital: “Digital” channels.
Analogue: “Analogue” channels.
The channel search will start and end automatically.
Press the ENTER button at any time to interrupt the memorization
process.
After all the available channels are stored, the message “Set the Clock
Mode.” is displayed.
6. Press the ENTER button to select the “Clock Mode”.
Press the ▲ or ▼ button to select “Manual”, then Press the ENTER
button.
If you select “Auto”, The message “Enjoy your viewing” is displayed.
If you have received a digital signal, the time will be set automatically.
7. Select the “Day”, “Month”, “Year”, “Hour”, or “Minute” by pressing the ◄ or ►
button. Set the “Day”, “Month”, “Year”, “Hour”, or “Minute” by pressing the
▲ or ▼ button.
You can also set the “Month”, “Day”, “Year”, “Hour” and “Minute” by
pressing the number buttons on the remote control.
8. The message “Enjoy your viewing” is displayed.
When you have nished, press the ENTER button.
If you want to reset this feature...
1. Press the MENU button to display the menu.
Press the ▲ or ▼ button to select “Setup”, then press the ENTER button.
2. Press the ENTER button again to select “Plug & Play”.
3. Enter your 4 digit PIN number. The default PIN number of a new TV set is
“0-0-0-0”.
If you want to change PIN number, refer to 37 page.
For further details on setting up options, refer to the pages 9~10.
The “Plug & Play” feature is only available in the TV mode.
➣
➣
➣
➣
➣
➣
➣
➣
➣
➣
➣
➣
Setup
Plug & Play  ►
Language : English
Time
Change PIN
Parental Lock
Subtitle
Teletext Language : ----
Preference
Plug & Play
Select ‘Home Use’ when installing this TV in your home.
Home Use
Store Demo
EnterMove
Plug & Play
Auto Store is completed.
Digital Channels : 45
Analogue Channels : 32
OK
Skip
Enter
Plug & Play
Auto Store in progress. Channel 69
Digital Channels: 29
Analogue Channels: 0
Stop
20%
Skip
Enter
Plug & Play
Set the Clock Mode.
Clock Mode : Auto
Auto
Manual
EnterMove Skip
Plug & Play
Enjoy your viewing
OK
Plug & Play
01
Day
01
Month
2008
Year
00
Hour
00
Minute
Enter
Adjust
Move Skip
Set current date and time
Plug & Play
Select the channel source to memorize.
Digital & Analogue
Digital
Analogue
Start
SkipEnter
Move
Start
Start
Plug & Play
The Menu Language, Store Demo, Channels, and Time will
be set.
Return
0~9 Enter PIN
BN68-01409H-00ENG.indb 10 2008-04-28 �� 5:18:15

English - 11
Channel Control
Storing Channels Automatically
You can scan for the frequency ranges available to you (and availability depends on your country). Automatically allocated
programme numbers may not correspond to actual or desired programme numbers. However, you can sort numbers
manually and clear any channels you do not wish to watch.
1. Press the MENU button to display the menu.
Press the ▲ or ▼ button to select “Channel”, then press the ENTER
button.
2. Press the ▲ or ▼ button to select “Auto Store”, then press the ENTER
button.
3. Press the ▲ or ▼ button to select the channel source to memorize.
Press the ENTER button to select “Start”.
Digital & Analogue: “Digital” and “Analogue” channels.
Digital: “Digital” channels.
Analogue: “Analogue” channels.
Scans for all channels with active broadcast stations and stores them in
the TV’s memory.
If you want to stop Auto Store, press the ENTER button.
The “Stop Auto Store?” message will be displayed.
Select “Yes” by pressing the ◄ or ► button, then press the ENTER button.
4. Press the EXIT button to exit.
If a channel is locked using the “Child Lock” function, the PIN input window appears (refer to page 22).
Storing Channels Manually
You can store television channels, including those received via cable networks. When storing channels manually, you can
choose:
Whether or not to store each of the channels found.
The programme number of each stored channel which you wish to identify.
1. Press the MENU button to display the menu.
Press the ▲ or ▼ button to select “Channel”, then press the ENTER
button.
2. Press the ▲ or ▼ button to select “Manual Store”, then press the ENTER
button.
Digital Channel
3. Press the ▲ or ▼ button to select “Digital Channel”, then press the
ENTER button.
If a channel is locked using the “Child Lock” function, the PIN input
window appears (refer to page 22).
4. Press the ◄ or ► button to select the required option.
− Channel : Set the Channel number using the ▲, ▼ or number buttons.
− Frequency : Set the frequency using the number buttons.
− Bandwidth : Set the bandwidth using the ▲, ▼ or number buttons.
5. Press the ENTER button to start the scan for digital services.
When it has nished, channels are updated in the channel list.
6. When it has nished, the number of scanned services will be displayed.
7. Press the EXIT button to exit.
➣
➣
➣
➣
•
•
➣
➣
Channel
Auto Store  ►
Manual Store
Full Guide
Mini Guide
Default Guide : Mini Guide
Channel List
Channel Mode : Added Ch.
Child Lock : On
Channel
Auto Store
Manual Store  ►
Full Guide
Mini Guide
Default Guide : Mini Guide
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Channel
Auto Store
ManualStore  ►
Full Guide
Mini Guide
Default Guide : Mini Guide
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Digital Channel
Analogue Channel
Manual Store
Move Adjust ReturnSearch
31
Channel
554000 KHz
Frequency
8MHz
Bandwidth
BN68-01409H-00ENG.indb 11 2008-04-28 �� 5:18:15

English - 12
Analogue Channel
3. Press the ▲ or ▼ button to select “Analogue Channel”, then press the
ENTER button.
If a channel is locked using the “Child Lock” function, the PIN input
window appears (refer to page 22).
4. Press the ◄ or ► button to select the required item below.
Press the ▲ or ▼ button to adjust to the setting satised.
5. Press the EXIT button to exit.
Programme (Programme number to be assigned to a channel)
Press the ▲ or ▼ button until you nd the correct number.
You can also select the channel number directly by pressing the numeric
buttons (0~9).
Colour System: Auto/PAL/SECAM/NTSC4.43
Press the ▲ or ▼ button to select the required colour standard.
Sound System: BG/DK/I/L
Press the ▲ or ▼ button to select the required sound standard.
Channel (When you know the number of the channel to be stored)
Press the ▲ or ▼ button to select C(Air channel) or S(Cable channel).
Press the ► button, then press the ▲ or ▼ button to select the required
number.
You can also select the channel number directly by pressing the numeric
buttons (0~9).
If there is abnormal sound or no sound, reselect the sound standard
required.
Search (When you do not know the channel numbers)
Press the ▲ or ▼ button to start the search.
The tuner scans the frequency range until the rst channel or the channel
that you selected is received on the screen.
Store (When you store the channel and associated programme number)
Set to OK by pressing the ENTER button.
Channel mode
- P (Programme mode): When completing tuning, the broadcasting stations
in your area have been assigned to position numbers from P00 to P99. You
can select a channel by entering the position number in this mode.
- C (Air channel mode): You can select a channel by entering the assigned
number to each air broadcasting station in this mode.
- S (Cable channel mode): You can select a channel by entering the assigned
number for each cable channel in this mode.
➣

➣



➣
➣


➣
Channel
Auto Store
ManualStore  ►
Full Guide
Mini Guide
Default Guide : Mini Guide
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Digital Channel
Analogue Channel
Manual Store
1
Programme
Auto
Colour System
BG
Sound System
Move Adjust Return
C --
Channel
62 MHz
Search
?
Store
BN68-01409H-00ENG.indb 12 2008-04-28 �� 5:18:15

English - 13
Viewing the EPG (Electronic Programme Guide) Information
The EPG (Electronic Programme Guide) information is provided by the broadcasters. Programme entries may appear blank
or out of date as a result of the information broadcast on a given channel. The display will dynamically update as soon as
new information becomes available.
1. Press the MENU button to display the menu.
2. Press the ▲ or ▼ button to select “Channel”, then press the ENTER
button.
3. Press the ▲ or ▼ button to select “Full Guide” or “Mini Guide” then press the
ENTER button.
Mini Guide
The information of each program is displayed by each line on the current
channel Mini Guide screen from the current program onwards according to
the program starting time order.
Full Guide
Displays the programme information as time ordered One hour segments.
Two hours of programme information is displayed which may be scrolled
forwards or backwards in time.
To... Then...
Watch a programme in the
EPG list
Select a programme by pressing the
▲, ▼, ◄, ► button.
Exit the guide Press the blue button
If the next program is selected, it is scheduled with the clock
icon displayed. If the ENTER button is pressed again, press
the ◄, ► button to select Cancel Schedules, the scheduling is
canceled with the clock icon gone. For details about scheduling
programmes, refer to the next page.
➣
View programme
information
Select a programme of your choice by
pressing the ▲, ▼, ◄, ► button.
Then press the INFO button when the
programme of your choice is highlighted.
The programme title is on the upper part
of the screen center.
•
•
•
Please click on INFO button for the detailed information. Channel
Number, Running Time, Status Bar, Parental Level, Video
Quality Information (HD/SD), Sound Modes, Subtitle or Teletext,
languages of Subtitle or Teletext and brief summary of the
highlighted programme are included on the detailed information.
“...” will be appeared if the summary is long.
➣
Toggle between the “Mini
Guide” or “Full Guide”
Press the red button repeatedly.
In Full Guide
Scrolls backwards
quickly (24 hours).
Scrolls forwards quickly
(24 hours).
•
•
Press the green button repeatedly.
Press the yellow button repeatedly.
•
•
In Mini Guide
Display next page
quickly.
Display previous page
quickly.
•
•
Press the green button.
Press the yellow button.
•
•
You can also display the guide menu simply by pressing the GUIDE button.
(To congure the “Default Guide”, refer to the descriptions on page 14.)


O
Channel
Auto Store
Manual Store
Full Guide
Mini Guide
Default Guide : Mini Guide
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Signal Information
Channel
Manual Store
Full Guide
Mini Guide
Default Guide : Mini Guide
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Signal Information
LNA : Off
Full Guide
DTV Cable 900 f tn 2:10 Tue 1 Jun
Freshmen On Campus
2:00 - 2:30
No Detailed Information
Today 2:00 - 3:00 3:00 - 4:00
Mint Extra
Loaded
Fresh 40 with Dynamite MC
The Distillery
Smash Hits! Sunday
900 f tn
901 ITV Play
902 Kerrang!
903 Kiss
903 oneword
903 Smash Hits!
▼
Street Hypn..
Kisstory
No Information
No Information
No Information
Freshmen O..
Watch
Information
 Mini Guide  +24 Hours  Exit
Mini Guide DTV Cable 900 f tn
Street Hypnosis
Booze Britain
2:00
2:30
5:00
▼
Freshmen On Campus
Watch
Information
 Full Guide  Next Page  Exit
BN68-01409H-00ENG.indb 13 2008-04-28 �� 5:18:16

English - 14
Setting the Default Guide
You can decide whether to display either the “Mini Guide” or the “Full Guide” when the GUIDE button on the remote control
is pressed.
1. Press the MENU button to display the menu.
Press the ▲ or ▼ button to select “Channel”, then press the ENTER
button.
2. Press the ▲ or ▼ button to select “Default Guide”, then press the ENTER
button.
3. Select “Mini Guide” or “Full Guide” using the ▲ or ▼ button, and press the
ENTER button.
4. Press the EXIT button to exit.
You can select these options by simply pressing the GUIDE button on the
remote control.
O
Channel
Full Guide
Mini Guide
Default Guide : Mini Guide ►
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Signal Information
LNA : Off
Channel
Full Guide
Mini Guide
DefaultGuide :MiniGuide ►
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Signal Information
LNA : Off
Mini Guide
Full Guide
BN68-01409H-00ENG.indb 14 2008-04-28 �� 5:18:16

English - 15
Managing Channels
Using this menu, you can Add/Delete or set Favourite channels and use the program guide for digital broadcasts.
Viewing All Channels
Show all currently available channels.
To use the Channel List function, operate the “Auto Store” rst.
1. Press the MENU button.
Press the ▲ or ▼ button to select “Channel”, then press the ENTER
button.
Press the ▲ or ▼ button to select “Channel List”, then press the ENTER
button.
2. Press the ◄ button to select “Added Ch.”.
3. Press the ▲ or ▼ button to select “All Channels”.
Shows all currently available channels.
Press the ENTER button.
4. Press the ▲ or ▼ button to select a channel to view, then press the
ENTER button. You can watch the selected channel.
Press the CH LIST button on the remote control to bring up the channel lists.
Using the Colour buttons on the Remote with the Channel List
Red (Channel Type): Toggle between your “TV”, “Radio”, “Data/Other” and
“All”.
Green (Zoom): Enlarges or shrinks a channel number.
Yellow (Select): Selects multiple channel lists.
TOOLS (Option): Displays the “Delete”(or “Add”), “Add to Favourite”(or
“Delete from Favourite”), “Lock”, “Timer Viewing”, “Edit Channel Name”,
“Sort”, “Edit Channel Number”, “Select All”, “Deselect All” or “Auto Store”
menu. (The Options menus may differ depending on the situation.)
•
•
•
•
A gray-coloured channel indicates the channel has been deleted.
The “Add” menu only appears for deleted channels.
A channel marked with the “♥” mark means the channel has been set as a Favourite.
The “Delete from Favourite” menu only appears for channels with the “♥” mark.
➣
O
➣
➣
824 UKTV Gold
825 UKTV style
A
1 C --
A
2 C --
A
3 ♥ C --
A
4 C --
A
5 C --
A
6 C --
A
7 C --
A
8 C --
All Channels
All
 Channel Type  Zoom  Select
Option
Channel
Mini Guide
Default Guide : Mini Guide
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Signal Information
LNA : Off
824 UKTV Gold
825 UKTV style
A
1 C --
A
2 C --
A
3 ♥ C --
A
4 C --
A
5 C --
A
6 C --
A
7 C --
A
8 C --
Added Ch.
All
 Channel Type  Zoom  Select
Option
BN68-01409H-00ENG.indb 15 2008-04-28 �� 5:18:17

English - 16
Erasing and Adding Channels
You can delete or add a channel to display the channels you want.
1. Press the MENU button.
Press the ▲ or ▼ button to select “Channel”, then press the ENTER
button. Press the ▲ or ▼ button to select “Channel List”, then press the
ENTER button.
2. Press the ◄ button to select “Added Ch.”.
3. Press the ▲ or ▼ button to select “All Channels”.
Shows all currently available channels.
Press the ENTER button.
4. Press the ▲ or ▼ button to select a channel to delete, then press the
TOOLS button.
5. Press the ENTER button to select “Delete”.
All deleted channels will be shown on “All Channels” menu.
6. Press the EXIT button to exit.
You can also add a channel to the “Added Ch.” menu in the same manner.
A channel must be deleted before it can be added back to the “Added Ch.”
list.
To Add (Restore) a channel back to the Added Channel List, follow steps
1-3 above, press the ▲ or ▼ button to select a channel to add, the press
the TOOLS button. Press the ENTER button to select Add.
Press the CH LIST button on the remote control to bring up the channel
lists.
➣
➣
➣
➣
➣
O
Setting Your Favourite Ch.
You can set channels you watch frequently as favorites.
1. Press the MENU button.
Press the ▲ or ▼ button to select “Channel”, then press the ENTER
button. Press the ▲ or ▼ button to select “Channel List”, then press the
ENTER button.
2. Press the ◄ button to select “Added Ch.”.
3. Press the ▲ or ▼ button to select “All Channels”.
Shows all currently available channels.
Press the ENTER button.
4. Press the ▲ or ▼ button to select a channel as a favorite channel.
Adding multiple channels to Favourites
Press the ▲ or ▼ button to select the desired channel in the channel
list. Then press the yellow button. Repeat the above operation to select
multiple channels. The mark appears to the left of the selected
channels.
5. Press the TOOLS button.
6. Press the ▲ or ▼ button to select “Add to Favourite”, then press the
ENTER button. The “♥” symbol will be displayed and the channel will be
set as a favorite.
7. To cancel your favorite channel selection, press the TOOLS button when a
favorite channel is selected.
Press the ▲ or ▼ button to select “Delete from Favourite”, then press the
ENTER button.
The channel is deleted from “Favourites” and the “♥” mark also disappears.
Press the EXIT button to exit.
You can also Add or Delete a channel from Favourites in the “Added Ch.”
menu in the same manner.
All favorite channels will be shown on “Favourite” menu.
Press the CH LIST button on the remote control to bring up the channel
lists.
➣
➣
➣
➣
O
Channel
Mini Guide
Default Guide : Mini Guide
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Signal Information
LNA : Off
Channel
Mini Guide
Default Guide : Mini Guide
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Signal Information
LNA : Off
824 UKTV Gold
825 UKTV style
A
1 C --
A
2 C --
A
3 C --
A
4 C --
A
5 C --
A
6 C --
A
7 C --
A
8 C --
All Channels
All
 Channel Type  Zoom  Select
Option
Delete
Add to Favourite
Lock
Timer Viewing
Edit Channel Name
Sort
▼
824 UKTV Gold
825 UKTV style
A
1 C --
A
2 C --
A
3 ♥ C --
A
4 C --
A
5 C --
A
6 C --
A
7 C --
A
8 C --
All Channels
All
 Channel Type  Zoom  Select
Option
Delete
Add to Favourite
Lock
Timer Viewing
Edit Channel Name
Sort
▼
BN68-01409H-00ENG.indb 16 2008-04-28 �� 5:18:17

English - 17
Locking and Unlocking Channels
This function is available only when the “Child Lock” is set to “on”. (see page22)
1. Press the MENU button.
Press the ▲ or ▼ button to select “Channel”, then press the ENTER
button.
Press the ▲ or ▼ button to select “Channel List”, then press the
ENTER button.
2. Press the ◄ button to select “Added Ch.”.
3. Press the ▲ or ▼ button to select “All Channels”.
Shows all currently available channels.
Press the ENTER button.
Locking channels
4. Press the ▲ or ▼ button to select the channels you want to lock, then
press the TOOLS button.
5. Press the ▲ or ▼ button to select “Lock”, then press the ENTER button.
6. Enter your 4 digit PIN number.
The “ ” symbol will be displayed and the channel will be locked.
The default PIN number of a new TV set is “0-0-0-0”.
If you want to change PIN number, refer to 36 page.
Unlocking channels
7. Press the ▲ or ▼ button to select the channels you want to Unlock, then
press the TOOLS button.
8. Press the ▲ or ▼ button to select “Unlock”, then press the ENTER
button.
9. Enter your 4 digit PIN number.
The channel is unlocked and the “ ” mark also disappears.
The default PIN number of a new TV set is “0-0-0-0”.
If you want to change PIN number, refer to 36 page.
10. Press the EXIT button to exit.
➣
➣
➣
➣
➣
➣
➣
Channel
Mini Guide
Default Guide : Mini Guide
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Signal Information
LNA : Off
824 UKTV Gold
825 UKTV style
A
1 C --
A
2 C --
A
3 C --
A
4 C --
A
5 C --
A
6 C --
A
7 C --
A
8 C --
All Channels
All
 Channel Type  Zoom  Select
Option
Delete
Add to Favourite
Lock
Timer Viewing
Edit Channel Name
Sort
▼
824 UKTV Gold
825 UKTV style
A
1 C --
A
2 C --
A
3 C --
A
4 C --
A
5 C --
A
6 C --
A
7 C --
A
8 C --
All Channels
All
 Channel Type  Zoom  Select
Option
Delete
Add to Favourite
Unlock
Timer Viewing
Edit Channel Name
Sort
▼
BN68-01409H-00ENG.indb 17 2008-04-28 �� 5:18:18

English - 18
Reserving a Program (Timer Viewing)
If you reserve a program you want to watch, the channel is automatically switched to the reserved channel in the Channel
List; even when you are watching another channel. To reserve a program, set the current time rst. See pages 33~34.
1. Press the MENU button.
Press the ▲ or ▼ button to select “Channel”, then press the ENTER
button.
Press the ▲ or ▼ button to select “Channel List”, then press the ENTER
button.
2. Press the ▲ or ▼ button to select a channel, then press the TOOLS button.
3. Press the ▲ or ▼ button to select “Timer Viewing”, then press the ENTER
button. The Reserve a Program (Timer Viewing) screen appears.
4. Press the ▲/▼/◄/► buttons to reserve a program and then press the
ENTER button. Reserving a program has been completed.
Press the EXIT button to exit.
You can also reserve a program in the “All Channels” or “Favourite” menus
using the same procedures.
For information on how to conrm a viewing reservation, refer to page 19.
Only memorized channels can be reserved.
You can set the channel, month, day, year, hour and minute directly by
pressing the number buttons on the remote control.
Press the CH LIST button on the remote control to bring up the channel lists.
Digital Program Guide and Viewing Reservation
When a digital channel is selected, and you press the ► button, the Program
Guide for the channel appears. You can reserve a program according to the
procedures described above.
: A program currently being broadcast.
: A reserved program
➣
➣
➣
O
Timer Viewing
DTV
Antenna
800
Channel
Once
01 - 01 - 2008
Date
ReturnEnter
Adjust
Move
10:00
Start Time
Repeat
Channel
Mini Guide
Default Guide : Mini Guide
Channel List
Channel Mode : Added Ch.
Child Lock : On
Fine Tune
Signal Information
LNA : Off
1/1/2008
1:59 LA ROSE DES ....
2:59 WS MUSIC
3:21 Gralness de stars
824
825
908
A
2 C --
A
3 ♥ C --
A
4 C --
A
5 C --
A
6 C --
A
7 C --
A
8 C --
All
 Channel Type  Zoom
Option Watch
Added Ch.
All
 Channel Type  Zoom  Select
Option
824 UKTV Gold
825 UKTV style
A
1 C --
A
2 C --
A
3 ♥ C --
A
4 C --
A
5 C --
A
6 C --
A
7 C --
A
8 C --
Added Ch.
Delete
Add to Favourite
Lock
Timer Viewing
Edit Channel Name
Sort
▼
BN68-01409H-00ENG.indb 18 2008-04-28 �� 5:18:18
