Samsung LA32B650T1R User manual

SERVICEManual
TFT-LCD TV Contents
Refer to the service manual in the GSPN (see the rear cover) for the more information.
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Exploded View & Part List
6. Wiring Diagram
LCD-TV
Chassis : N69A
Model : LA32B650T1R
LA40B650T1R
LA46B650T1R
LA55B650T1R
LA32B650T1R/LA40B650T1R/
LA46B650T1R/LA55B650T1R

Contents
1. Precautions.............................................................................................................. 1-1
1-1. Safety Precautions ......................................................................................................... 1-1
1-2. Servicing Precautions..................................................................................................... 1-2
1-3. Electrostatically Sensitive Devices (ESD) Precautions .................................................. 1-2
1-4. Installation Precautions .................................................................................................. 1-3
2. Product specications............................................................................................ 2-1
2-1. Feature & Specications................................................................................................. 2-1
2-2. Auto Motion Plus (FRC + MJC) .................................................................................... 2-12
2-3. Internet@TV ................................................................................................................. 2-14
2-3. Using the Content Library............................................................................................. 2-15
2-4. Using the TV Memory Contents.................................................................................... 2-16
2-5. Using the Content Management................................................................................... 2-17
2-6. Media Play.................................................................................................................... 2-18
2-7. Home Network Center .................................................................................................. 2-21
2-8. Specication Comparison to Old Models...................................................................... 2-23
2-9. Accessories .................................................................................................................. 2-24
3. Disassembly and Reassembly ............................................................................... 3-1
3-1. Disassembly and Reassembly ....................................................................................... 3-1
4. Troubleshooting ...................................................................................................... 4-1
4-1. Troubleshooting .............................................................................................................. 4-1
4-2. Alignments and Adjustments ........................................................................................ 4-20
4-3. Factory Mode Adjustments ........................................................................................... 4-21
4-4. White Balance - Calibration .......................................................................................... 4-26
4-5. White Ratio (Balance) Adjustment................................................................................ 4-28
4-6. Servicing Information.................................................................................................... 4-29
4-7. Sub Micom Update ....................................................................................................... 4-41
5. Exploded View & Part List ...................................................................................... 5-1
5-1. LA32B650T1R Exploded View ....................................................................................... 5-1
5-2. LA40B650T1R Exploded View ....................................................................................... 5-3
5-3. LA46B650T1R Exploded View ....................................................................................... 5-5
5-4. LA55B650T1R Exploded View ....................................................................................... 5-7
5-5. LA32B650T1R Parts List ................................................................................................ 5-9
5-6. LA40B650T1R Parts List .............................................................................................. 5-36
5-7. LA46B650T1R Parts List .............................................................................................. 5-63
5-8. LA55B650T1R Parts List .............................................................................................. 5-90
6. Wiring Diagram........................................................................................................ 6-1
6-1. Wiring Diagram 32”/40” .................................................................................................. 6-1
6-2. Wiring Diagram 46”/55” .................................................................................................. 6-2
6-3. Connector Functions ...................................................................................................... 6-5
6-4. Cables ............................................................................................................................ 6-5

GSPN (Global Service Partner Network)
Area Web Site
North America http://service.samsungportal.com
Latin America http://latin.samsungportal.com
CIS http://cis.samsungportal.com
Europe http://europe.samsungportal.com
China http://china.samsungportal.com
Asia http://asia.samsungportal.com
Mideast & Africa http://mea.samsungportal.com
This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2009 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea
P/N: BN82-00552A-00

3-1
3. Disassembly and Reassembly
3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LA46B650T1R LCD TV.
WARNING: This LCD TV contains electrostatically sensitive devices. Use caution when handling these components.
3-1. Disassembly and Reassembly
Cautions: 1. Disconnect the LCD TV from the power source before disassembly.
2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.
Description Picture Description Screws
1. Place monitor face down on cushioned table.
Remove screws from the Stand.
Remove stand.
* Screw size used in manual

3-2
3. Disassembly and Reassembly
Description Picture Description Screws
2. Remove the screws of rear-cover.
3. Lift up and remove the rear-cover.
* Rear view of 32” / 40”
* Rear view of 46” / 55”

3-3
3. Disassembly and Reassembly
Description Picture Description Screws
4. Remove the screws of main board.
4-1. Remove the screws of IP board.
Remove the IP board. (32” / 40”)
4-2. Remove the screws of IP board.
Remove the IP board. (46” / 55”)

3-4
3. Disassembly and Reassembly
Description Picture Description Screws
5. Remove the speakers. (R/L)
6. Remove the screws of Stand BKLT.
Lift up the Stand BKLT.
7. Remove the screw of panel top.

3-5
3. Disassembly and Reassembly
Description Picture Description Screws
7-1. Remove the screw of wall bracket.
(46” / 55” only)
8-1. Front
8-2. Panel
Reassembly procedures are in the reverse order of disassembly procedures.※

5-1
5. Exploded View & Part List
5. Exploded View & Part List
5-1. LA32B650T1R Exploded View
T0003
T0175
M0215
M0115
M0174
M0146
M0014
M0254
M0027
T0920
M0013

5-2
5. Exploded View & Part List
5-1-1. LA32B650T1R Parts List
Location No. Code No. Description & Specication Q’ty S.A/S.N.A Remark
T0003 BN96-09486D ASSY COVER P-FRONT;32,LB650,SO,PMMA(CLR) 1 S.A
M0215 BN07-00641A LCD-PANEL;T315HW02 V3,AU31H23,8bit,31.5i 1 S.A
M0115 BN61-04820A BRACKET-STAND LINK;B650-32,SECC,T1.2 1 S.A
T0175 BN96-09463A ASSY SPEAKER P;8ohm,4pin,10W,R:200 / L:4 1 S.A
M0254 BN61-04800E HOLDER-SIDE AV;SO,LO,ABS+PMMA,HB,BK23,2U 1 S.N.A
M0014 BN94-03117Z ASSY PCB MAIN;LA32B650T1RXXT 1 S.A
M0146 BN61-04818A BRACKET-PANEL TOP;B650-32,SECC,T1.2 2 S.N.A
M0174 BN44-00261B IP BOARD;H32F1_9DY,H32F1_9DY,0.12mA,12.5 1 S.A
T0920 BN61-04812A GUIDE-STAND;32,PET+PC+G/F (15%) V2,BK500 1 S.A
M0013 BN96-09502C ASSY COVER P-REAR;32,LB650,SO,ABS+PMMA,H 1 S.A
M0027 BN96-09497A ASSY STAND P-BASE;32,LB650,TEMPERED GLAS 1 S.A

5-3
5. Exploded View & Part List
5-2. LA32B650T1R Parts List
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
LA32B650T1RXXL
0.1 BN90-01892D ASSY COVER FRONT;32,LB650,SO,ROSE BLACK, 1 S.N.A
..2 T0175 BN96-09463A ASSY SPEAKER P;8ohm,4pin,10W,R:200 / L:4 1 S.A
..2 T0003 BN96-09486D ASSY COVER P-FRONT;32,LB650,SO,PMMA(CLR) 1 S.A
...3 M0081 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 T0069 BN60-00027N SPACER-FELT;L650 32,FELT,383,0.5,20 2 S.N.A
...3 T0069 BN60-00027T SPACER-FELT;L650 32,FELT,700,0.5,20 2 S.N.A
...3 AB326 BN61-04661A BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H 6 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.04,900mm,20 0.74 S.N.A
...3 CCM1 BN63-05199B COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL 2.4 S.A
...3 CCM1 BN63-05199G COVER-SHEET;AMBER,PE,T0.08,W115mm,200M,C 1 S.A
...3 M0112 BN63-05273D COVER-FRONT;32,LB650,SO,PMMA(CLR)+PMMA(R 1 S.N.A
...3 BN96-09505C ASSY HOLDER P-BOSS SIDE RIGHT;32,LB650,P 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
....4 BN61-04731A BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE 0.03 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.26 S.N.A
....4 BN61-04842C HOLDER-BOSS SIDE R;32,LB650,ABS+PMMA,HB, 1 S.N.A
...3 BN96-09505D ASSY HOLDER P-BOSS SIDE LEFT;32,LB650,PM 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
....4 BN61-04731A BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE 0.03 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.26 S.N.A
....4 BN61-04842D HOLDER-BOSS SIDE L;32,LB650,ABS+PMMA,HB, 1 S.N.A
...3 BN96-09517B ASSY HOLDER P-BOSS BOTTOM;32,LB650,ABS,H 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.3 S.N.A
....4 BN61-04731B BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE 0.52 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.06 S.N.A
....4 BN61-04825B HOLDER-BOSS BOTTOM;32,LB650,ABS,HB,WH12, 1 S.N.A
...3 M0125 BN96-12111C ASSY BOARD P-TOUCH FUNCTION&IR;LA40B650T 1 S.A
...3 BN74-00052A TAPE-PAPER;LB530,Crepe Paper,0.17mm, 10m 0.05 S.N.A
0.1 M0216 BN90-01903A ASSY STAND;32,LB650,ROSE BLACK 1 S.N.A
..2 M0027 BN96-09497A ASSY STAND P-BASE;32,LB650,TEMPERED GLAS 1 S.A
...3 M0081 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 3 S.A
...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
...3 BN61-04855A BRACKET-SWIVEL BOTTOM;B650 40,SECC,T2.0 1 S.N.A
...3 GSN01 BN61-05248C GUIDE-STAND NECK;PETG,Clear,Pi 50X96 1 S.N.A
....4 AH506 BN61-05271C HOLDER-INSERT;PETG,Clear,Pi 40X81 1 S.N.A
...3 BN61-05254A HOLDER-SWIVEL RING BOTTOM;LB700 40,POM H 1 S.N.A
...3 BN63-05530B COVER-STAND GLASS;32,LB650,GLASS,T8.0,RO 1 S.N.A
...3 T0056 BN63-05537A COVER-DECORATION;UB7000 40inch,ABS,PMMA, 1 S.N.A
...3 T0527 BN68-01648B LABEL WARNING;WW,PET,T0.05,40,25,EXPORT 1 S.N.A
...3 CCM1 BN63-04755A COVER-SHEET;AMBER,PE,T0.05,W150mm,200M,6 1.1 S.A
...3 M0126 BN73-00215A RUBBER-FOOT;40LB650,RUBBER,15*25,60,4.0, 4 S.N.A
...3 M0126 BN73-00217A RUBBER-FOOT;LB650,RUBBER,DIA30,7.5,Dark 4 S.N.A
...3 BN74-00031A GREASE;kanto-kasei FL-955,grease,wht 0.4 S.N.A
...3 BN61-05653A BRACKET-STAND BOTTOM;B650 32,SECC,T2.0 1 S.N.A
...3 BN61-05826A BOSS-BOND;#760,Poly urethane,Black 2.4 S.N.A
...3 BN61-05238A HOLDER-SWIVEL RING TOP;LB700 40,POM HB,A 1 S.N.A

5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...3 BN61-04731C BOSS-TAPE;AMBER,ACRYL,T1.1,W16.0mm,WHITE 0.29 S.N.A
..2 M0523 BN96-10598A ASSY STAND P-GUIDE;32,LB650,PC+G/F,20%,B 1 S.A
...3 T0524 6902-001048 BAG PE;LDPE,T0.05,W160,L300,TRP,4g 1 S.N.A
...3 T0920 BN61-04812A GUIDE-STAND;32,PET+PC+G/F (15%) V2,BK500 1 S.A
0.1 M0002 BN90-01908C ASSY COVER REAR;32,LB650,SO 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 10 S.A
..2 M0013 BN96-09502C ASSY COVER P-REAR;32,LB650,SO,ABS+PMMA,H 1 S.A
...3 T0069 AA63-60131N SPACER-FELT;L2,FELT,280*10,BLK,T0.5 2 S.N.A
...3 T0101 BN61-04816A BRACKET-WALL;40, B610,SECC,T1.2 4 S.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.04,900mm,20 0.7 S.N.A
...3 M0006 BN63-05344C COVER-REAR;32,LB650,SO,ABS+PMMA,HB,BK23, 1 S.N.A
...3 T0071 BN64-01034G INLAY-TERMINAL;LB650/750,SO,PS SHEET,T0. 1 S.N.A
...3 T0139 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,BLK 1 S.N.A
0.1 BN91-03829A ASSY LCD-AUO;LE32B653T5WXXC 1 S.N.A
..2 M0215 BN07-00641A LCD-PANEL;T315HW02 V3,AU31H23,8bit,31.5i 1 S.A
...3 BN81-02346A A/S-T CON T315HW02_V3;T315HW02_V3 1 S.N.A
0.1 M0017 BN91-03988A ASSY CHASSIS;LA32B650T1RXXT,LB6T 1 S.N.A
..2 M0014 BN94-03117Z ASSY PCB MAIN;LA32B650T1RXXT 1 S.A
...3 0202-001463 SOLDER-WIRE;LFC2-W3.0,-,D3,99.79Sn/0.2Cu 1.219 S.N.A
...3 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.25 S.N.A
...3 0204-002420 SOLVENT;1M-1000,C3H70H,96 5.38 S.N.A
...3 0204-002607 FLUX;DF-234U,13%,14KG,Gravity 0.82 3.503 S.N.A
...3 3701-001388 CONNECTOR-HDMI;20P,Phosphor Bronze,ANGLE 1 S.A
...3 3701-001480 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN 1 S.A
...3 3711-003847 HEADER-BOARD TO CABLE;BOX,12P,1R,2mm,ANG 1 S.N.A
...3 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 3711-006715 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 S.N.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 4 S.A
...3 3722-002426 JACK-MODULAR;8P/8C,N,STRAIGHT,GRN/YEL,AU 1 S.A
...3 AJACK4 3722-002546 JACK-USB;4P/1C,AU,BLK,ANGLE,A type 2 S.A
...3 JA333 3722-002691 JACK-PIN;2P,Ni,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002699 JACK-PIN;3P,Ni,YEL/WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002704 JACK-PIN;3P,Sn,YEL/WHT/RED,ANGLE 1 S.A
...3 JA333 3722-002711 JACK-PIN;10P,Ni,GRN/BLU/RED/WHT/RED,STRA 1 S.N.A
...3 CIS3 BN40-00142B TUNER;TCPS3001PD11S(H),TCPS3001PD11S(H), 1 S.A
...3 T0174 BN97-03738Z ASSY SMD;LA32B650T1R 1 S.N.A
....4 0202-001477 SOLDER-CREAM;LST309-M,D20~45um,96.5Sn/3A 0.003 S.N.A
....4 0401-001049 DIODE-SWITCHING;LS4148,75V,150mA,SOD-80, 7 S.A
....4 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 36 S.A
....4 D1 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 3 S.A
....4 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 18 S.A
....4 0403-001425 DIODE-ZENER;BZX84C33,31-35V,350mW,SOT-23 1 S.A
....4 D0254 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 4 S.A
....4 Q101 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 9 S.A
....4 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 3 S.A
....4 PQ02 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 CQ3 0501-002184 TR-SMALL SIGNAL;KTD1304,NPN,200mW,SOT-23 4 S.A
....4 1001-000164 IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16 1 S.A
....4 IC106 1001-001579 IC-VIDEO SWITCH;TMDS461PZT,QFN,100P,14x1 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm 2 S.A

5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 IC112 1103-001310 IC-EEPROM;24LC02B,256X8BIT,SOIC,8P,3.91X 4 S.N.A
....4 IC112 1103-001385 IC-EEPROM;AT24C256,256Kbit,32Kx8,SOP,8P, 1 S.A
....4 IC112 1103-001415 IC-EEPROM;AT93C46D,1Kbit,128x8/64x16,SOP 1 S.N.A
....4 1105-002012 IC-DDR2 SDRAM;NT5TU64M16DG-AC,DDR2 SDRAM 4 S.N.A
....4 T0124 1201-002796 IC-POWER AMP;STA339BWS,PSSO,36P,10.3x7.5 1 S.A
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,PLAST 1 S.A
....4 T0087 1203-002835 IC-POSI.FIXED REG.;KIA7805AF,DPAK,3P,6.6 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33,TO-252,3P, 2 S.A
....4 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 T0087 1203-005134 IC-POSI.FIXED REG.;RT9167A-33PB,SOT-23-5 1 S.N.A
....4 1203-005538 IC-DC/DC CONVERTER;AOZ1021HAIL,SOP,8P,4. 1 S.A
....4 1203-005603 IC-DC/DC CONVERTER;AOZ1024DI,DFN,8P,5x4m 1 S.A
....4 IC118 1204-003010 IC-VIDEO PROCESS;SDP84,PBGA,324P,23x23mm 1 S.A
....4 1204-003011 IC-DECODER;SDP83,PBGA,729P,34x34mm,PLAST 1 S.A
....4 1205-002941 IC-ETHERNET CONTROLLER;RTL8100CSL-LF,LQF 1 S.N.A
....4 1205-003201 IC-BUS SWITCH;TC7WB125FK,SSOP,8P,2x2.3mm 2 S.A
....4 1205-003352 IC-CODEC;WM8593SEFT/V,TQFP,64P,10x10mm,P 1 S.A
....4 1205-003733 IC-SWITCH;AP2191MPG-13,MSOP-8L-EP,8P,2.9 1 S.A
....4 1205-003735 IC-SWITCH;AP2151WG-7,SOT25,5P,2.9x1.6mm, 1 S.A
....4 1209-001830 IC-PLL;IDT6V10012PGG,TSSOP,20P,6.5x4.4mm 1 S.A
....4 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 23 S.A
....4 PR4 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 KR24 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 S.A
....4 PR6 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 4 S.A
....4 R105 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 2 S.A
....4 AR49 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 3 S.A
....4 MR306 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 11 S.A
....4 AVR73 2007-000142 R-CHIP;2.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R319 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 58 S.A
....4 R104 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 30 S.A
....4 MR36 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 AR43 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 MR13 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 18 S.A
....4 DR39 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R111 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 15 S.A
....4 HDR17 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 3 S.A
....4 R338 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 50 S.A
....4 UR23 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 15 S.A
....4 R2136 2007-000239 R-CHIP;1.5Kohm,1%,1/10W,TP,1608 2 S.A
....4 R1035 2007-000287 R-CHIP;100ohm,1%,1/10W,TP,1608 2 S.A
....4 R414 2007-000362 R-CHIP;12ohm,5%,1/10W,TP,1608 8 S.N.A
....4 KR7 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608 1 S.A
....4 R3A06 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 1 S.A
....4 2007-000563 R-CHIP;220Kohm,1%,1/10W,TP,1608 1 S.A
....4 R726 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 2 S.N.A
....4 AR61 2007-000869 R-CHIP;4.7Kohm,1%,1/10W,TP,1608 1 S.A
....4 DR37 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 15 S.A
....4 R509 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 OTR1 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 6 S.A
....4 DR1 2007-001301 R-CHIP;68ohm,5%,1/16W,TP,1005 1 S.A

5-6
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 CER07 2007-001308 R-CHIP;200ohm,5%,1/16W,TP,1005 5 S.A
....4 R16 2007-001313 R-CHIP;330ohm,5%,1/16W,TP,1005 1 S.A
....4 R326 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 1 S.A
....4 R1 2007-002425 R-CHIP;1ohm,5%,1/10W,TP,1608 6 S.A
....4 2007-002900 R-CHIP;11Kohm,1%,1/10W,TP,1608 1 S.N.A
....4 2007-007008 R-CHIP;300ohm,5%,1/16W,TP,1005 2 S.A
....4 TR30 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 2 S.A
....4 R365 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 1 S.A
....4 DR4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 9 S.A
....4 2007-007222 R-CHIP;6.04Kohm,1%,1/10W,TP,1608 1 S.A
....4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 19 S.A
....4 2007-007316 R-CHIP;3.3Kohm,1%,1/16W,TP,1005 4 S.N.A
....4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 28 S.N.A
....4 2007-007698 R-CHIP;5.1Kohm,1%,1/16W,TP,1005 2 S.N.A
....4 2007-007797 R-CHIP;44.2ohm,1%,1/10W,TP,1608 2 S.A
....4 MR11 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 28 S.A
....4 2007-008298 R-CHIP;49.9ohm,1%,1/16W,TP,1005 4 S.A
....4 2007-008593 R-CHIP;750ohm,1%,1/16W,TP,1005 1 S.A
....4 DRP29 2011-000515 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP, 8 S.A
....4 DAR09 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 32 S.A
....4 2011-001264 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,2. 8 S.N.A
....4 HRP2 2011-001344 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,2 2 S.A
....4 2011-001448 R-NETWORK;10ohm,5%,1/16W,L,4P,T,1010 1 S.A
....4 2011-001586 R-NETWORK;1Kohm,5%,1/16W,L,CHIP-V,4P,TP, 1 S.N.A
....4 2011-001590 R-NETWORK;47Kohm,5%,1/16W,L,CHIP-V,4P,TP 1 S.N.A
....4 AC1 2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,- 4 S.A
....4 PC43 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 9 S.A
....4 C134 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,TP,1608 2 S.A
....4 RC34 2203-000280 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,1608 1 S.A
....4 DC2 2203-000330 C-CER,CHIP;.012nF,5%,50V,C0G,TP,1005 3 S.A
....4 C304 2203-000405 C-CER,CHIP;0.18nF,5%,50V,C0G,1608 1 S.A
....4 C254 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 15 S.A
....4 C507 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 2 S.A
....4 AD480 2203-000550 C-CER,CHIP;0.02nF,5%,50V,C0G,1005 2 S.N.A
....4 V1233 2203-000575 C-CER,CHIP;220nF,10%,25V,X7R,TP,2012 6 S.A
....4 AD480 2203-000679 C-CER,CHIP;0.027nF,5%,50V,C0G,1005 2 S.A
....4 C1101 2203-000697 C-CER,CHIP;0.002NF,0.25PF,50V,C0G,TP,160 2 S.A
....4 AD480 2203-000761 C-CER,CHIP;330nF,10%,16V,X7R,TP,2012,- 1 S.N.A
....4 DC25 2203-000812 C-CER,CHIP;.033nF,5%,50V,C0G,1005 6 S.A
....4 C263 2203-000972 C-CER,CHIP;47nF,10%,16V,X7R,1608 1 S.A
....4 AC124 2203-000998 C-CER,CHIP;0.047nF,5%,50V,C0G,1608 3 S.A
....4 KAC5 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,1608 1 S.A
....4 AD480 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 4 S.N.A
....4 C3A21A 2203-001554 C-CER,CHIP;1.8nF,10%,50V,X7R,1608 3 S.A
....4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 19 S.N.A
....4 AAC1 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 26 S.A
....4 AD480 2203-005344 C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,- 16 S.N.A
....4 PC8 2203-005642 C-CER,CHIP;0.22nF,5%,50V,NP0,1005 1 S.A
....4 EC9 2203-005834 C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216 8 S.A
....4 PPE3 2203-005929 C-CER,CHIP;10000nF,10%,16V,X7R,3225 2 S.A
....4 AD480 2203-005968 C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005 4 S.N.A

5-7
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 AD480 2203-006039 C-CER,CHIP;1nF,10%,2000V,X7R,3216 2 S.A
....4 AD480 2203-006104 C-CER,CHIP;1000nF,10%,50V,X7R,3225 1 S.A
....4 AD480 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 2 S.N.A
....4 PC11 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 4 S.N.A
....4 C102 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 192 S.A
....4 AD480 2203-006307 C-CER,CHIP;1000nF,10%,25V,X5R,2012 3 S.N.A
....4 AD480 2203-006336 C-CER,CHIP;10000nF,10%,25V,X5R,3216 8 S.A
....4 C125 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 60 S.C
....4 HDC11 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 37 S.A
....4 AD480 2203-006992 C-CER,CHIP;0.33nF,5%,50V,C0G,TP,1005 15 S.N.A
....4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 ( 1 S.N.A
....4 C 2402-001128 C-AL,SMD;100#F,20%,16V,-,TP,6.3X5.7mm 2 S.A
....4 2601-001056 TRANS-SMD,PULSE;350UH,-,1:1,1:1,12.7X6.7 1 S.A
....4 VL6 2703-000398 INDUCTOR-SMD;10uH,10%,3225 18 S.A
....4 T0052 2703-000417 INDUCTOR-SMD;220uH,5%,3225 1 S.A
....4 T0052 2703-001239 INDUCTOR-SMD;3.3uH,10%,1608 2 S.A
....4 T0052 2703-001426 INDUCTOR-SMD;680uH,20%,7070 1 S.A
....4 T0052 2703-003559 INDUCTOR-SMD;4.7uH,20%,8080 2 S.N.A
....4 T0052 2704-000018 INDUCTOR-SMD-ARRAY;15uH,2000mA,2,0.124oh 2 S.A
....4 X202 2801-003326 CRYSTAL-SMD;24MHZ,30PPM,28-ABX,20PF,50OH 1 S.A
....4 X202 2801-003773 CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50oh 1 S.A
....4 X202 2801-004629 CRYSTAL-SMD;27MHz,20ppm,12pF,50ohm,TP 1 S.N.A
....4 X202 2801-004734 CRYSTAL-SMD;25.000000MHz,20ppm,28-AAN,12 1 S.A
....4 F103 2901-001506 FILTER-EMI SMD;5V,0.13A,0pF,2x1x0.5mm,TP 2 S.A
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608 7 S.N.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 32 S.A
....4 3701-001591 CONNECTOR-HDMI;19P,2ROW,FEMALE,SMD-S,AU 3 S.N.A
....4 3711-005925 HEADER-BOARD TO CABLE;BOX,51P,1R,0.5mm,S 1 S.N.A
....4 T0077 BN41-01156B PCB MAIN;B650 Ready,FR-4,4,1.0,1.2,192*1 1 S.N.A
....4 BN97-03367A ASSY MICOM-SUB;T-CHEAEUS-1005,2009.04.09 1 S.N.A
.....5 IC520 0903-001552 IC-MICROCONTROLLER;WT61P8-RG480WT,LQFP,4 1 S.N.A
....4 BN97-03366A ASSY MICOM-MAIN;T-CHEAEAC-2006.0,2009.11 1 S.N.A
.....5 1107-001740 IC-NAND FLASH;KFH8GH6U4M-DIB6,8Gbit,512M 1 S.N.A
...3 T0066 BP62-00016B HEAT SINK-ES;SUNRAY,A6063,T2.0,36.2,36.2 1 S.N.A
...3 T0066 BP62-00017A HEAT SINK-ES;SP-50L2HX,A6063S,T2.0,26.2, 1 S.N.A
...3 BN97-03864A ASSY HDCP;(IC601),1107-001740 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
0.1 BN91-03989A ASSY SHIELD;LA32B650T1RXXT,LB6T 1 S.N.A
..2 CIS1 0203-001586 TAPE-FILAMENT;#893,0.15,25,55 0.3 S.N.A
..2 M0081 6003-000337 SCREW-TAPTYPE;BH,+,S,M4,L10,ZPC(BLK),SWR 4 S.A
..2 M0081 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 5 S.N.A
..2 M0081 6003-001439 SCREW-TAPTYPE;BH,+,S,M4,L8,ZPC(WHT),SWRC 1 S.N.A
..2 M0174 BN44-00261B IP BOARD;H32F1_9DY,H32F1_9DY,0.12mA,12.5 1 S.A
..2 M0254 BN61-04800E HOLDER-SIDE AV;SO,LO,ABS+PMMA,HB,BK23,2U 1 S.N.A
..2 M0146 BN61-04818A BRACKET-PANEL TOP;B650-32,SECC,T1.2 2 S.N.A
..2 M0115 BN61-04820A BRACKET-STAND LINK;B650-32,SECC,T1.2 1 S.A
..2 BN96-10077A ASSY CABLE P-FPCB LVDS;LA46A650A1,FPCB L 1 S.A
..2 T0081 6001-002284 SCREW-MACHINE;BH,+,M4,L8,ZPC(WHT),SWRCH1 10 S.A
..2 BN61-05281A HOLDER-CLAMP;LCD,NYLON 66,WHT 2 S.N.A
..2 M2893 BN39-01208B LEAD CONNECTOR;UL1007#26,500MM,SMH200-30 1 S.A
0.1 BN92-04608A ASSY P/MATERIAL;32,LB650 1 S.N.A

5-8
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
..2 6902-000061 BAG AIR;LDPE,T0.2,W500,L1000,TRP,370.000 1 S.N.A
..2 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0 1 S.N.A
..2 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 4.3 S.N.A
..2 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,30.0 0.08 S.N.A
..2 T0527 BH68-40364A LABEL-SUMMARY;G52,G72,ART,100G,WHT,BLK,W 1 S.N.A
..2 BH69-00457C PACKING INNER-00,PAD;COMM,T3.0,880,1320, 1 S.N.A
..2 BH69-40383A PACKING INNER-00,PAD;COMM,CB-SW4,729,709 1 S.N.A
..2 T0527 BN68-00129A LABEL SHIPPING-00;LABEL SHIPPING,ART-PAP 1 S.N.A
..2 BN69-00391D PAD-ANGLE;DI19PS,T4,50,2000,YEL,357.000g 1 S.N.A
..2 BN69-00617Z PALLET-WOODEN;BE46PS,WOOD-WoodEN,1250,91 1 S.N.A
..2 T0246 BN69-03212A CUSHION-SET;32LB650,EPS,16.7g/l 1 S.N.A
..2 T0214 BN74-00008A TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M, 2.08 S.N.A
..2 T0524 6902-000738 BAG PE;HDPE/HDPE/NITRON,T0.015/T0.015/T1 1 S.N.A
0.1 BN92-04726A ASSY LABEL;LA32B650T1RXXT,LB6T 1 S.N.A
..2 CCM1 BN68-01176A LABEL RATING;W/W,SS,PET POLYESTER,T0.05, 1 S.N.A
..2 T0527 AA68-03752B LABEL-STICKER;WW,ALL,Art Paper(90g),25,3 1 S.N.A
..2 BN68-01958X LABEL-01,POP LCD TV;650(32/27"),PET(7005 1 S.N.A
0.1 BN92-05463E ASSY BOX;32,LB650,XL(SIEL) 1 S.N.A
..2 T0077 BH68-00329D LABEL BAR CODE-02;NO CE,NO WT`Y,MPRII,LA 2 S.N.A
..2 BN69-03514X BOX-SET;32LB650,CB,A-01, DW3, AB,YEL,W88 1 S.N.A
0.1 M0045 BN92-05519H ASSY ACCESSORY;LA32B650T1RXXL 1 S.N.A
..2 BN96-10558N ASSY ACCESSORY-MANUAL;INDIA,LB6T 1 S.A
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2,9.2 1 S.N.A
...3 AA68-00487D MANUAL FLYER-WARRANTY CARD;comm,ALL,Engl 1 S.N.A
...3 AA68-03242M MANUAL FLYER-MANUAL FLYER-06,SAFETY GUID 1 S.N.A
...3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, 1 S.N.A
...3 T0511 BN68-02017A MANUAL USERS-03;B650,SAMSUNG,Eng,ASIA,W/ 1 S.N.A
...3 BN59-00726D S/W DRIVER-CD;LN40B650T1F,DLNA,WorldWide 1 S.N.A
...3 BN68-02186A MANUAL FLYER-TOC GUIDE;COMM,SAMSUNG,10 L 1 S.N.A
..2 M0045 BN96-12703B ASSY ACCESSORY-CABLE;LA32B650T1RXXL 1 S.A
...3 T0268 3903-000441 CBF-POWER CORD;DT,IN,DP3/Y(A),IEC320 C13 1 S.A
...3 T0685 4301-000103 BATTERY-ALKALINE;1.5V,750mAH,LR03,10.5x4 2 S.N.A
...3 T0524 6902-001107 BAG PE;LDPE,T0.05,W450,L400,TRP,0,3Separ 1 S.N.A
...3 T0074 BN59-00873A REMOCON;L650,P680,P650,TM960,IDTV-READY, 1 S.A
...3 BN61-05596A HOLDER-WIRE CABLE;LED TV,LDPE,T0.8,L150, 1 S.N.A
...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC 1 S.N.A
...3 T0531 BN63-05284B COVER-BOTTOM;B650 32,HIPS,HB,BK500 1 S.A
...3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, 1 S.N.A
...3 BN96-01800E ASSY ACCESSORY-SCREW ZIPPER;32,LB650,GUI 1 S.N.A
....4 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 8 S.A
....4 BN69-04420A PACKING-BAG PE;LB650,LDPE,60,60 1 S.N.A

5-1
5. Exploded View & Part List
5. Exploded View & Part List
5-1. LA32B650T1R Exploded View
T0003
T0175
M0215
M0115
M0174
M0146
M0014
M0254
M0027
M0013

5-2
5. Exploded View & Part List
5-1-1. LA32B650T1R Parts List
Location No. Code No. Description & Specication Q’ty S.A/S.N.A Remark
T0003 BN96-09486Q ASSY COVER P-FRONT;32LB650,PMMA(CLR)+PMM 1 S.A
M0215 BN07-00641A LCD-PANEL;T315HW02 V3,AU31H23,8bit,31.5i 1 S.A
M0115 BN61-04820A BRACKET-STAND LINK;B650-32,SECC,T1.2 1 S.A
T0175 BN96-09463A ASSY SPEAKER P;8ohm,4pin,10W,R:200 / L:4 1 S.A
M0254 BN61-04800E HOLDER-SIDE AV;SO,LO,ABS+PMMA,HB,BK23,2U 1 S.N.A
M0014 BN94-03117Z ASSY PCB MAIN;LA32B650T1RXXT 1 S.A
M0146 BN61-04818A BRACKET-PANEL TOP;B650-32,SECC,T1.2 2 S.N.A
M0174 BN44-00261B IP BOARD;H32F1_9DY,H32F1_9DY,0.12mA,12.5 1 S.A
M0013 BN96-09502G ASSY COVER P-REAR;32LB650,TSE,PC+ABS+REC 1 S.A
M0027 BN96-09497A ASSY STAND P-BASE;32,LB650,TEMPERED GLAS 1 S.A

5-3
5. Exploded View & Part List
5-2. LA32B650T1R Parts List
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
LA32B650T1RXXL
0.1 BN90-01892P ASSY COVER FRONT;32B650T1RXHC,XA,LABEL P 1 S.N.A
..2 T0175 BN96-09463A ASSY SPEAKER P;8ohm,4pin,10W,R:200 / L:4 1 S.A
..2 T0003 BN96-09486Q ASSY COVER P-FRONT;32LB650,PMMA(CLR)+PMM 1 S.A
...3 M0081 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 T0069 BN60-00027N SPACER-FELT;L650 32,FELT,383,0.5,20 2 S.N.A
...3 T0069 BN60-00027T SPACER-FELT;L650 32,FELT,700,0.5,20 2 S.N.A
...3 AB326 BN61-04661A BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H 6 S.N.A
...3 BN61-04731A BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE 0.06 S.N.A
...3 BN61-04731B BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE 0.52 S.N.A
...3 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.06 S.N.A
...3 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.52 S.N.A
...3 CCM1 BN63-05199B COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL 2.4 S.N.A
...3 CCM1 BN63-05199G COVER-SHEET;AMBER,PE,T0.08,W115mm,200M,C 1 S.N.A
...3 F001 BN63-05273K COVER-FRONT;32LB650,PMMA(CLR)+PMMA(ROSE 1 S.N.A
...3 BN68-01958X LABEL-01,POP LCD TV;650(32/27"),PET(7005 1 S.N.A
...3 BN96-09505C ASSY HOLDER P-BOSS SIDE RIGHT;32,LB650,P 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
....4 BN61-04731A BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE 0.03 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.26 S.N.A
....4 BN61-04842C HOLDER-BOSS SIDE R;32,LB650,ABS+PMMA,HB, 1 S.N.A
...3 BN96-09505D ASSY HOLDER P-BOSS SIDE LEFT;32,LB650,PM 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
....4 BN61-04731A BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE 0.03 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.26 S.N.A
....4 BN61-04842D HOLDER-BOSS SIDE L;32,LB650,ABS+PMMA,HB, 1 S.N.A
...3 BN96-09517B ASSY HOLDER P-BOSS BOTTOM;32,LB650,ABS,H 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.3 S.N.A
....4 BN61-04731B BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE 0.52 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.06 S.N.A
....4 BN61-04825B HOLDER-BOSS BOTTOM;32,LB650,ABS,HB,WH12, 1 S.N.A
...3 M0125 BN96-12111C ASSY BOARD P-TOUCH FUNCTION&IR;LA40B650T 1 S.A
...3 BN74-00052A TAPE-PAPER;LB530,Crepe Paper,0.17mm, 10m 0.05 S.N.A
0.1 M0216 BN90-01903A ASSY STAND;32,LB650,ROSE BLACK 1 S.N.A
..2 M0027 BN96-09497A ASSY STAND P-BASE;32,LB650,TEMPERED GLAS 1 S.A
...3 M0081 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 3 S.A
...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
...3 BN61-04855A BRACKET-SWIVEL BOTTOM;B650 40,SECC,T2.0 1 S.N.A
...3 BN61-05254A HOLDER-SWIVEL RING BOTTOM;LB700 40,POM H 1 S.N.A
...3 BN63-05530B COVER-STAND GLASS;32,LB650,GLASS,T8.0,RO 1 S.N.A
...3 T0056 BN63-05537A COVER-DECORATION;UB7000 40inch,ABS+PMMA, 1 S.N.A
...3 T0527 BN68-01648B LABEL WARNING;WW,PET,T0.05,40,25,EXPORT 1 S.N.A
...3 CCM1 BN63-04755A COVER-SHEET;AMBER,PE,T0.05,W150mm,200M,6 1.1 S.N.A
...3 M0126 BN73-00215A RUBBER-FOOT;40LB650,RUBBER,15*25,60,4.0, 4 S.N.A
...3 M0126 BN73-00217A RUBBER-FOOT;LB650,RUBBER,DIA30,7.5,Dark 4 S.N.A
...3 BN74-00031A GREASE;kanto-kasei FL-955,grease,wht 0.4 S.N.A
...3 BN61-05653A BRACKET-STAND BOTTOM;B650 32,SECC,T2.0 1 S.N.A

5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...3 BN61-05826A BOSS-BOND;#760,Poly urethane,Black 2.4 S.N.A
...3 BN61-05238A HOLDER-SWIVEL RING TOP;LB700 40,POM HB,A 1 S.N.A
...3 BN61-04731C BOSS-TAPE;AMBER,ACRYL,T1.1,W16.0mm,WHITE 0.29 S.N.A
...3 GSN01 BN61-05248C GUIDE-STAND NECK;PETG,Clear,Pi 50X96 1 S.N.A
....4 AH506 BN61-05271C HOLDER-INSERT;PETG,Clear,Pi 40X81 1 S.N.A
..2 T0920 BN61-04812A GUIDE-STAND;32,PC+G/F (20%) V2,BK500 1 S.A
0.1 M0002 BN90-01908C ASSY COVER REAR;32,LB650,SO 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 9 S.N.A
..2 M0013 BN96-09502G ASSY COVER P-REAR;32LB650,TSE,PC+ABS+REC 1 S.A
...3 T0069 AA63-60131N SPACER-FELT;L2,FELT,280*10,BLK,T0.5 2 S.N.A
...3 T0101 BN61-04816A BRACKET-WALL;40, B610,SECC,T1.2 4 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.04,900mm,20 0.7 S.N.A
...3 T0071 BN64-01034G INLAY-TERMINAL;LB650/750,SO,PS SHEET,T0. 1 S.N.A
...3 T0139 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,BLK 1 S.N.A
...3 M0006 BN63-05344E COVER-REAR;32LB650,PC+ABS+RECYCLE,V0,TSE 1 S.N.A
..2 M0081 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 1 S.A
0.1 BN91-03829A ASSY LCD-AUO;LE32B653T5WXXC 1 S.N.A
..2 M0215 BN07-00641A LCD-PANEL;T315HW02 V3,AU31H23,8bit,31.5i 1 S.A
...3 M0590 BN81-02346A A/S-T CON T315HW02_V3;T315HW02_V3 1 S.A
0.1 M0017 BN91-03988A ASSY CHASSIS;LA32B650T1RXXT,LB6T 1 S.N.A
..2 AA02-00012A TAPE ETC-RIBBON;54CM,250MT 0.03 S.N.A
..2 T0527 AA68-01203A LABEL-SERIAL;ALL MODEL,23MM,70MM 1 S.N.A
..2 M0014 BN94-03117Z ASSY PCB MAIN;LA32B650T1RXXT 1 S.A
...3 0202-001463 SOLDER-WIRE;LFC2-W3.0,-,D3,99.79Sn/0.2Cu 1.219 S.N.A
...3 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.25 S.N.A
...3 0204-002420 SOLVENT;1M-1000,C3H70H,96 5.38 S.N.A
...3 0204-002606 FLUX;LF-715K,14%,16kg,Gravity 0.82 3.503 S.N.A
...3 3701-001388 CONNECTOR-HDMI;20P,Phosphor Bronze,ANGLE 1 S.A
...3 3701-001480 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN 1 S.A
...3 HB01A 3711-003847 HEADER-BOARD TO CABLE;BOX,12P,1R,2mm,ANG 1 S.N.A
...3 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 HB01A 3711-006715 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 S.N.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 4 S.A
...3 3722-002426 JACK-MODULAR;8P/8C,N,STRAIGHT,GRN/YEL,AU 1 S.A
...3 AJACK4 3722-002546 JACK-USB;4P/1C,AU,BLK,ANGLE,A type 2 S.A
...3 JA332 3722-002691 JACK-PIN;2P,Ni,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002699 JACK-PIN;3P,Ni,YEL/WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002704 JACK-PIN;3P,Sn,YEL/WHT/RED,ANGLE 1 S.A
...3 JA333 3722-002711 JACK-PIN;10P,Ni,GRN/BLU/RED/WHT/RED,STRA 1 S.N.A
...3 AA02-00012A TAPE ETC-RIBBON;54CM,250MT 0.02 S.N.A
...3 T0527 AA68-03528A LABEL BAR CODE;ALL,MOJO,90G,45,15,WHITE 1 S.N.A
...3 CIS3 BN40-00142B TUNER;TCPS3001PD11S(H),TCPS3001PD11S(H), 1 S.A
...3 T0174 BN97-03738Z ASSY SMD;LA32B650T1R 1 S.N.A
....4 0202-001477 SOLDER-CREAM;LST309-M,D20~45um,96.5Sn/3A 2.35 S.N.A
....4 DS01A 0401-001049 DIODE-SWITCHING;LS4148,75V,150mA,SOD-80, 7 S.A
....4 DS01A 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 36 S.A
....4 D1 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 3 S.N.A
....4 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 18 S.A
....4 0403-001425 DIODE-ZENER;BZX84C33,31-35V,350mW,SOT-23 1 S.A
....4 D0254 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 4 S.A
