Samsung LE19C450E1W User manual

BN68-03043G
BN68-03043G-00
Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.
Country Customer Care Centre Web Site
EIRE 0818 717 100 www.samsung.com
U.K 0845 SAMSUNG(7267864) www.samsung.com
LCD TV
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model Serial No.
[430(19)-UK]BN68-03043G-Eng.indb 1 2010-04-12 �� 9:35:47

2
English
Information on Use
Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance.
Product design and specifications may be changed without notice.
Precautions When Displaying a Still Image
A still image may cause permanent damage to the TV screen.
Do not display a still image and partially still image on the LCD panel for more than 2 hours as it can cause screen
image retention. This image retention is also known as screen burn. To avoid such image retention, reduce the degree of
brightness and contrast of the screen when displaying a still image.
Watching the LCD TV in 4:3 format for a long period of time may leave traces of borders displayed on the
left, right and centre of the screen caused by the difference of light emission on the screen.
Playing a DVD or a game console may cause a similar effect to the screen.
Damages caused by the above effect are not covered by the Warranty.
Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images.
To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images.
WARNINGS:■
Image retention, commonly known as screen burn-in, can occur on most types of television if the same image is displayed continuously.
The most common causes of image retention are logos that remain stationary on the TV screen. These logos are common on many
programmes received via a Set-top Box.
To reduce this risk, avoid displaying still images for long durations and lower the brightness or contrast settings to decrease the
intensity of the picture. Extended viewing of movies and programs in aspect ratios that are different from the aspect ratio of the TV may
cause image retention. Always endeavour to avoid black borders top or bottom by using the zoom function. This will help eliminate the
black borders and fit the picture to the entire area of the screen. Using a video game console may cause image retention and is not
recommended. When using a PC input, avoid displaying still images for long durations and reduce the brightness or contrast settings to
decrease the intensity of the picture.
IMPORTANT:■
Image retention issues are not covered by your Samsung® warranty.
Digital TV Notice
Functionalities related to Digital TV(DVB) are only available in countries/areas where DVB-T (MPEG2 and MPEG4 AVC)■
digital terrestrial signals are broadcasted or where you are able to access to a compatible DVB-C(MPEG2 and MPEG4
AAC) cable- TV service. Please check with your local dealer the possibility to receive DVB-T or DVB-C signal.
DVB-T is the DVB European consortium standard for the broadcast transmission of digital terrestrial television and■
DVBC is that for the broadcast transmission of digital TV over cable. However, some differentiated features like EPG
(Electric Programme Guide), VOD (Video on Demand) and so on, are not included in this specification. So, they cannot be
workable at this moment.
Although this TV set meets the latest DVB-T and DVB-C standards, as of [August, 2008], the compatibility with future■
DVB-T digital terrestrial and DVB-C digital cable broadcasts cannot be guaranteed.
Depending on the countries/areas where this TV set is used some cable-TV providers may charge an additional fee for■
such a service and you may be required to agree to terms and conditions of their business.
Some Digital TV functions might be unavailable in some countries or regions and DVB-C might not work correctly with■
some cable service providers.
For more information, please contact your local Samsung customer care centre.■
[430(19)-UK]BN68-03043G-Eng.indb 2 2010-04-12 �� 9:35:47

3
English
Trademark & Label License Notice
TruSurround HD, SRS and symbol are trademarks of SRS Labs, Inc. TruSurround HD technology is
incorporated under license from SRS Labs, Inc.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
Symbol
Note
One-Touch Button
TOOLS Button
Press
© 2009 Samsung Electronics Co., Ltd. All rights reserved.
[430(19)-UK]BN68-03043G-Eng.indb 3 2010-04-12 �� 9:35:47

4
English
Contents
Getting Started
5 How to Adjust the Stand (19inch model only)
5 How to Adjust the Angle of the TV
(19inch model only)
6 Installing VESA Compliant Mounting Devices
(19inch model only)
6 Using the Decoration Covers
(19inch model only)
7 Installing the Stand
7 Installing the Wall Mount Kit
7 Anti-Theft Kensington Lock
8 Securing the Installation Space
9 Securing the TV to the Wall
10 Accessories
10 Viewing the Control Panel
11 Viewing the Connection Panel
13 Connections
14 Installing Batteries in the Remote Control
15 Viewing the Remote Control
Basic Operation
16 Placing Your Television in Standby Mode
16 Plug & Play Feature
17 Viewing the Display
Using the Menus
18 Viewing the Menus
18 Channel Menu
18 Country
Auto Store
19 Manual Store
Cable Search Option
20 Now & Next Guide / Full Guide /
Default Guide
21 Channel List
22 Channel Mode
Fine Tune
23 Picture Menu
23 Mode
Backlight / Contrast / Brightness /
Sharpness / Colour / Tint (G/R)
Advanced Settings
24 Picture Options
25 Picture Reset
26 Auto Adjustment
Screen
27 Sound Menu
27 Mode
Equalizer
SRS TruSurround HD
Audio Language
Audio Format
Audio Description
Auto Volume
Speaker Select
28 Sound Reset
29 Setup Menu
29 Menu Language
Time
30 Broadcast
31 Security
32 General
32 Input Menu
32 Source List
Edit Name
33 Support menu
33 Self Diagnosis
Software Upgrade
34 HD Connection Guide
Contact Samsung
Other Information
35 Teletext Feature
37 Using Your TV as a Computer (PC) Display
38 Troubleshooting
41 Specications
Warning! Important Safety Instructions
Wiring the Mains Power Supply Plug (UK Only)
Warranty Card
[430(19)-UK]BN68-03043G-Eng.indb 4 2010-04-12 �� 9:35:48

5
English Getting Started
Getting Started
How to Adjust the Stand (19inch model only)
1Place the front of the TV onto a soft cloth or cushion on a table as in Figure
1 .
Align the TV bottom along the table edge.■
2Press on the center of the TV back. Adjust the stand as in Figure
2 while pressing the button on the back of the stand.
3Place the TV on the table so that the TV sits safely on the table.
How to Adjust the Angle of the TV
(19inch model only)
When you adjust the stand, press the button on the back of the stand.
1Figure
1 shows the adjustment angle (-2°~14°) when you use the LCD on its stand.
Excessive tilting can turn the LCD TV over which may cause damage.■
2Figure
2 shows the adjustment angle (14°~80°) when you convert the LCD from stand-based use to wall-mount.
3Figure
3 shows the adjustment angle (0°~10°) when you mount the LCD TV to a wall.
You will hear a “Click” sound when changing the angle from 1 to 2 or 3 to 2.■
1 2
1 Angle adjustment when using
the TV on its stand.
2 Angle adjustment when
converting from Stand to Wall
mount (1→3, 3→1)
3 Angle adjustment when LCD
TV is wall-mounted
[430(19)-UK]BN68-03043G-Eng.indb 5 2010-04-12 �� 9:35:48

6
English Getting Started
Installing VESA Compliant Mounting Devices
(19inch model only)
1Place the TV face down on a soft cloth or cushion on a table.
2Adjust the stand, pressing the button on the back of the stand.
3Align the mounting interface pad (not supplied) with the holes in the stand bottom and secure it with the four screws that come with the arm-type base, wall mount hanger or other bases (not supplied).
Using the Decoration Covers
(19inch model only)
1When installing the TV on the wall without using the stand, insert decoration covers into the holes as described in the picture 1 .
2After inserting the decoration covers, fasten them with 4 screws as described in the picture
2 .
2
1
Button
Mounting pad
(Sold separately)
1 2
[430(19)-UK]BN68-03043G-Eng.indb 6 2010-04-12 �� 9:35:49

7
English Getting Started
Installing the Stand
1Attach your LCD TV to the stand.
Two or more people should carry the TV.■
Make sure to distinguish between the front and back of the stand when assembling■them.
To make sure the TV is installed on the stand at a proper level, do not apply excess■downward pressure to the upper left of right sides of the TV.
2Fasten two screws at position
1 and then fasten two screw at position 2 .
Stand the product up and fasten the screws. If you fasten the screws with the LCD■TV placed down, it may lean to one side.
Installing the Wall Mount Kit
Wall mount items (sold separately) allow you to mount the TV on the wall.
For detailed information on installing the wall mount, see the instructions provided with the Wall
Mount items. Contact a technician for assistance when installing the wall mounted bracket.
Samsung Electronics is not responsible for any damage to the product or injury to yourself or others
if you elect to install the TV on your own.
Do not install your Wall Mount Kit while your TV is turned on. It may result in personal
injury due to electric shock.
Anti-Theft Kensington Lock
The Kensington Lock is a device used to physically fix the system when using it in a public
place. The appearance and locking method may differ from the illustration depending on the
manufacturer. Refer to the manual provided with the Kensington Lock for proper use.
Please find a “■K” icon on the rear of the TV. A kensington slot is beside the “K” icon.
These are general instructions. For exact instructions, see the User manual supplied with the■locking device.
The locking device has to be purchased separately.■The location of the Kensington Lock may be different depending on its model.■
To lock the product, follow these steps:
1Wrap the Kensington lock cable around a large, stationary object such as desk or chair.
2Slide the end of the cable with the lock attached through the looped end of the Kensington.
3Insert the locking device into the Kensington slot on the product (
1 ).
4Lock the lock.
1
<Optional>
[430(19)-UK]BN68-03043G-Eng.indb 7 2010-04-12 �� 9:35:50

8
English Getting Started
Securing the Installation Space
Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation.
Failing to do so may result in fire or a problem with the product due to an increase in the internal temperature of the product.
Install the product so the required distances shown in the figure are kept.
When using a stand or wall-mount, use parts provided by Samsung Electronics only.■
If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the
product falling.
If you use parts provided by another manufacturer, it may result in a problem with the product or fire due to an increase in
the internal temperature of the product due to poor ventilation.
The appearance may differ depending on the product.■
When installing the product with a stand When installing the product with a wall-mount
10 cm
10 cm
10 cm
10 cm
10 cm
10 cm
10 cm
[430(19)-UK]BN68-03043G-Eng.indb 8 2010-04-12 �� 9:35:50

9
English Getting Started
Securing the TV to the Wall
Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In
particular, ensure your children do not hang over or destabilize the TV; doing
so may cause the TV to tip over, causing serious injuries or death. For added
stability, install the anti-fall device for safety purposes, as follows.
To avoid the TV from falling:
1Put the screws into the clamps and firmly fasten them onto the wall. Confirm that the screws have been firmly installed onto the wall.
You may need additional material such as an anchor depending on the type of■wall.
Since the necessary clamps, screws, and string are not supplied, please■purchase these additionally.
2Remove the screws from the centre back of the TV, put the screws into the clamps, and then fasten the screws onto the TV again.
Screws may not be supplied with the product. In this case, please purchase the■screws of the following specifications.
Screw Specifications:■
For a 17 ~ 29 Inch LCD TV: M4 X L15
For a 32 ~ 40 Inch LCD TV: M6 X L15
3Connect the clamps fixed onto the TV and the clamps fixed onto the wall with a strong string and then tie the string tightly.
Install the TV near to the wall so that it does not fall backwards.■
It is safe to connect the string so that the clamps fixed on the wall are equal to or■lower than the clamps fixed on the TV.
Untie the string before moving the TV.■
4Verify all connections are properly secured. Periodically check connections for any sign of fatigue for failure. If you have any doubt about the security of your connections,
contact a professional installer.
Wall
Wall
[430(19)-UK]BN68-03043G-Eng.indb 9 2010-04-12 �� 9:35:51

10
English Getting Started
Speakers
Accessories
Please make sure the following items are included with your LCD TV. If any items are missing, contact your dealer.■
Remote Control & Batteries
(AAA x 2) Power Cords Cover-Bottom (22 inch model only) Cleaning Cloth
(M4 X L16)
User Manual /
Quick Setup Guide
Wall Mount kit
(19 inch model only)
Decoration Cover
(19 inch model only)
Stand Screw X 4
(22 inch model only)
Viewing the Control Panel
The product colour and shape may vary depending on the model.■
The front panel buttons can be activated by touching it with your finger.■
Blinks and turns off when the
power is on and lights up in
stand-by mode.
Toggles between all the available
input sources. In the on-screen menu,
use this button as you would use
the ENTEREbutton on the remote
control.
Press to see an on-screen menu of
your TV’s features.
Press to increase or decrease the
volume. In the on-screen menu, use the
Y buttons as you would use the
◄ and ► buttons on the remote control.
Press to turn the TV on and off.
Press to change channels. In the on-
screen menu, use the Y buttons
as you would use the ▼ and ▲ buttons
on the remote control.
The items colour and shape may vary depending on the model.■
Aim the remote control towards
this spot on the TV.
[430(19)-UK]BN68-03043G-Eng.indb 10 2010-04-12 �� 9:35:53

11
English Getting Started
Viewing the Connection Panel
The product colour and shape may vary depending on the model.■
1 DIGITAL AUDIO OUT (OPTICAL)
Connects to a Digital Audio component such as a Home theatre receiver.
When the HDMI IN jacks are connected, the■DIGITAL AUDIO OUT (OPTICAL) jack on the TV outputs 2 channel audio only.
If you want to hear 5.1 channel audio, connect the Optical jack on the DVD / Blu-ray player or Cable / Satellite Box directly to
an Amplifier or Home Theatre, not the TV.
2 SERVICE
Connector for software upgrades.
3 HDMI / PC IN [HDMI (DVI), AUDIO, PC]
Connects to the HDMI jack of a device with an HDMI output.
No additional Audio connection is needed for an HDMI to HDMI connection.■
What is HDMI?■
HDMI(High-Definition Multimedia Interface), is an interface that enables the transmission of digital audio and video signals
using a single cable.
The difference between HDMI and DVI is that the HDMI device is smaller in size, has the HDCP (High Bandwidth Digital Copy
Protection) coding feature installed, and supports multi - channel digital audio.
Use the■HDMI / PC IN [HDMI (DVI)] jack for DVI connection to an external device. Use a DVI to HDMI cable or DVI-
HDMI adapter (DVI to HDMI) for video connection and the HDMI / PC IN [AUDIO] jacks for audio. When using an HDMI
/ DVI cable connection, you must use the HDMI / PC IN [HDMI (DVI)] jack.
HDMI / PC IN [AUDIO]
Connect to the audio output jack on your PC.
DVI audio outputs for external devices.
HDMI / PC IN [PC]
Connect to the video output jack on your PC.
If your PC supports an HDMI connection, you can connect this to the■HDMI / PC IN [HDMI (DVI)] terminal.
If your PC supports a DVI connection, you can connect this to the■HDMI / PC IN [HDMI (DVI)] / [AUDIO] terminal.
4 AV IN [R-AUDIO-L] / [VIDEO]
Connect RCA cable to an appropriate external A/V device such as VCR, DVD or Camcorder.■
Connect RCA audio cables to■[R-AUDIO-L] on your set and the other ends to corresponding audio out connectors on the A/V
device.
5 ANT IN
Connects to an antenna or cable TV system.
6 COMMON INTERFACE Slot
When not inserting ‘CI CARD’ in some channels, ‘Scrambled Signal’ is displayed on the screen.■
The pairing information containing a telephone number, CI CARD ID, Host ID and other information will be displayed in about■2~3 minutes. If an error message is displayed, please contact your service provider.
When the channel information configuration has finished, the message ‘Updating Completed’ is displayed, indicating that the■channel list is now updated.
You must obtain a CI CARD from a local cable service provider. Remove the CI CARD by carefully pulling it out with your
hands since dropping the CI CARD may cause damage to it.
Insert the CI-Card in the direction marked on it.
The place of theCOMMON INTERFACE Slot may be different depending on its model.
CAM is not supported in some countries and regions, check with your authorized dealer.
6
7
1 2 3 4
890
5
[430(19)-UK]BN68-03043G-Eng.indb 11 2010-04-12 �� 9:35:53

12
English Getting Started
7 KENSINGTON LOCK (depending on the model)
The Kensington Lock (optional) is a device used to physically fix the system when used in a public place.
If you want to use a locking device, contact the dealer where you purchased the TV.
The location of the Kensington Lock may be different depending on its model.■
8 Headphones jack
Headphone may be connected to the headphone output on your set. While the head phone is connected, the sound from the built-
in speakers will be disabled.
9 COMPONENT IN
Connect component video cables (optional) to component connector (PR, PB, Y) on the rear of your set and the other ends to
corresponding component video out connectors on the DTV or DVD.
If you wish to connect both the Set-Top Box and DTV (or DVD), you should connect the Set-Top Box to the DTV (or DVD) and
connect the DTV (or DVD) to component connector (PR, PB, Y) on your set.
The PR, PBand Y connectors on your component devices (DTV or DVD) are sometimes labeled Y, B-Y and R-Y or Y, Cb and Cr.
Connect RCA audio cables (optional) to [R-AUDIO-L] on the rear of your set and the other ends to corresponding audio out
connectors on the DTV or DVD.
0 EXT
Connector Input Output
Video Audio (L / R) RGB Video + Audio (L / R)
EXT O O O Only TV or DTV output is available.
Inputs or outputs for external devices, such as VCR, DVD, video game device or video disc players.■
[430(19)-UK]BN68-03043G-Eng.indb 12 2010-04-12 �� 9:35:54

13
English Getting Started
Connections
Digital Audio connection
Digital Audio System
Using an Optical Cable
OPTICAL
Analogue Audio connection
Amplier / DVD Home Theatre
Using a Audio Cable
AUDIO IN
OPTICAL (Digital)
AUDIO (Analogue)
Best
Normal
HD connection
Using a D-Sub Cable
Using an HDMI Cable
HDMI OUT
Using a D-Sub Cable
Using a D-Sub Cable
PC OUT
AUDIO OUT
HD connection
Using an HDMI/DVI Cable
DVI OUTAUDIO OUT
[430(19)-UK]BN68-03043G-Eng.indb 13 2010-04-12 �� 9:35:55

14
English Getting Started
Installing Batteries in the Remote Control
1Lift the cover at the back of the remote control upward as shown in the figure.
2Install two AAA size batteries.
Make sure to match the ‘+’ and ‘–’ ends of the batteries with the diagram inside■the compartment.
3Replace the cover.
Remove the batteries and store them in a cool, dry place if you won’t be using■the remote control for a long time.
If the remote control doesn’t work, check the following:■
Is the TV power on?
Are the plus and minus ends of the batteries reversed?
Are the batteries drained?
Is there a power outage or is the power cord unplugged?
Is there a special fluorescent light or neon sign nearby? OPERATION
[430(19)-UK]BN68-03043G-Eng.indb 14 2010-04-12 �� 9:35:56

15
English Getting Started
Turns the TV on and off.
Press to change the channel.
Used to display Favourites
Channel Lists on the screen.
(p. 21)
Press to increase or decrease
the volume.
Press to display information
on the TV screen. (p. 17)
Use to quickly select frequently
used functions.
Use to select on-screen menu
items and change menu values.
(p. 18)
Displays the Channel List on
screen. (p. 21)
Use these buttons in the Channel
list menus etc.
Alternately select Teletext,
Double, or Mix. (p. 35)
Selects the TV mode directly.
(p. 36)
Enables you to return to the
previous channel you were
watching.
Press to temporarily cut off the
sound. (p. 27)
Press to display and select the
available video sources. (p. 32)
Press to change channels.
Displays the Electronic
Programme Guide (EPG).
(p. 20)
Displays the main on-screen
menu. (p. 18)
Returns to the previous menu.
Press to exit the menu. (p. 18)
Displays the Digital subtitle.
(p. 30)
Audio Description selection.
(p. 27)
Teletext Functions (p. 35)
0
Teletext mode selection
(LIST / FLOF)
5
Teletext reveal 3Teletext previous page
8
Teletext store
:Exit from the Teletext display 6
Teletext index
4
Teletext size selection 1 Teletext sub page 9 Teletext hold
Colour buttons Fastext topic selection 2 Teletext next page 7 Teletext cancel
Viewing the Remote Control
You can use the remote control up to a distance of about 23 feet from the TV.■
The performance of the remote control may be affected by bright light.■
The product colour and shape may vary depending on the model.■
[430(19)-UK]BN68-03043G-Eng.indb 15 2010-04-12 �� 9:35:56

16
English Basic Operation
Plug & Play Feature
When the TV is initially powered on, basic settings proceed automatically and
subsequently.
1Press the POWER button.
You can also use the■POWERPbutton on the TV.
The message■You can set the menu language. is displayed.
2 Select the appropriate language by pressing the ▲ or ▼ button. Press the ENTER E button to confirm your choice.
3 Press the ◄ or ► button to select Store Demo or Home Use, then the ENTER E button.
We recommend setting the TV to■Home Use mode for the best picture in your
home environment.
Store Demo■mode is only intended for use in retail environments.
If the unit is accidentally set to■Store Demo mode and you want to return to
Home Use (Standard): Press the volume button on the TV. When the volume
OSD is displayed, press and hold the MENU button on the TV for 5 seconds.
4Press the ENTER
E button. Select the appropriate country by pressing the ▲ or
▼ button. Press the ENTER E button to confirm your choice.
5 Press the ▲ or ▼ button to select Air or Cable, then press the ENTER
E button.
Air■: Air antenna signal.
Cable■: Cable antenna signal.
6 Press the ▲ or ▼ button to select the channel source to memorize. Press the ENTER E button to select Start.
When setting the antenna source to■Cable, a step appears allowing you to set
a value for the digital channel search. For more information, refer to Channel
→ Auto Store.
Digital & Analogue■: Digital and Analogue channels.
Digital■: Digital channels.
Analogue■: Analogue channels.
The channel search will start and end automatically.■
After all the available channels are stored, the message■Set the Clock Mode.
is displayed.
7Press the ENTER
E button. Press the ▲ or ▼ button to select Auto, then press
the ENTER E button.
If you select■Manual, Set current date and time is displayed.
If you have received a digital signal, the time will be set automatically.■If not, select Manual to set the clock. (Refer to page 29)
8The connection method to provide the best quality HD is offered. After confirming the method, press the ENTER E button.
9
The message Enjoy your TV. is displayed. When you have finished, press the
ENTER E button.
Press the■ENTER E button
at any time to interrupt the
memorization process.
Basic Operation
Placing Your Television in Standby Mode
Your set can be placed in standby mode in order to reduce the power consumption. The standby mode can be useful when
you wish to interrupt viewing temporarily (during a meal, for example).
1Press the POWERPbutton on the remote control.
The screen is turned off and a standby indicator appears on your set.■
2To switch your set back on, simply press the POWERPbutton again.
Do not leave your set in standby mode for long periods of time (when you are■away on holiday, for example). It is best to unplug the set from the mains and
aerial.
Plug & Play
You can set the menu language.
Menu Language : English ►
E Enter
[430(19)-UK]BN68-03043G-Eng.indb 16 2010-04-12 �� 9:35:56

17
English Basic Operation
The■Plug & Play feature is only
available in the TV mode.
If you want to reset this feature...
1Press the MENU button. Press the ▲ or ▼ button to select Setup, then press the ENTER E button.
2Press the ENTER
E button again to select Plug & Play.
3Enter your 4 digit PIN number.
The default PIN number of a new TV set is■0-0-0-0.
If you want to change PIN number, use the■Change PIN function.
Viewing the Display
The display identifies the current channel and the status of certain audio-video
settings.
1Press the INFO button on the remote control. The TV will display the channel, the type of sound, and the status of certain picture
and sound settings.
▲, ▼: You can view other channel’s information. If you want to move to 
the currently selected channel, press ENTER E button.
◄, ►: You can view the desired program’s information at the current 
channel.
Press the■INFO button once more or wait approximately 10 seconds and the
display disappears automatically.
Press the■INFO button to viewing
the information.
DTV Air
15
abc1
18:00 ~ 6:00
18:11 Thu 6 Jan
Life On Venus Avenue
Unclassified
No Detaild Information
Y
INFO
[430(19)-UK]BN68-03043G-Eng.indb 17 2010-04-12 �� 9:35:57

18
English Using the Menus
Using the Menus
Viewing the Menus
Menu provides one button access for controlling your TV. It enables you to perform a variety of tasks intuitively with a control
panel on the screen rather than a variety of remote control button presses.
Operation the Menu
The access step may differ depending on the selected menu.
1Press the MENU button.
The menu is displayed on the screen.■
2 Press the ▲ or ▼ button to select one of the icons. Press the ENTER E button to access the icon’s sub-menu.
3Press the ▲ or ▼ button to move to items in the menu. Press the ENTER E button to enter items in the menu.
4Press the ▲/▼/◄/► button to change the selected items. Press the RETURN R button to return to the previous menu.
5Press the EXIT
e button to exit from the menu.
Channel Menu
Channel
Option Description
Country The PIN number input screen appears.
Enter your 4 digit PIN number.
Analogue Channel❑
You can change the country for analogue channels.
Digital Channel❑
You can change the country for digital channels.
Auto Store You can scan for the frequency ranges available to you
(and availability depends on your country).
Automatically allocated programme numbers may not
correspond to actual or desired programme numbers.
Scans for all channels with active broadcast stations and
stores them in the TV’s memory.
If a channel is locked using the■Child Lock function, the PIN
input window appears.
MENU button
Display the main on-screen menu.
ENTER E / DIRECTION button
Move the cursor and select an item.
Select the currently selected item.
Confirm the setting.
RETURN button
Return to the previous menu.
EXIT button
Exit the on-screen menu.
Country ►
Auto Store
Manual Store
Cable Search Option
Now & Next Guide
Full Guide
Default Guide : Now & Next Guide
Channel
[430(19)-UK]BN68-03043G-Eng.indb 18 2010-04-12 �� 9:35:57

19
English Using the Menus
Channel
Option Description
Auto Store Air❑/ Cable
Antenna source to memorize.
Digital & Analogue■: Digital and Analogue
channels.
Digital■: Digital channels.
Analogue■: Analogue channels.
When selecting ‘Cable → Digital & Analogue’
or ‘Cable → Digital’:
Provide a value to scan for cable channels.
Search Mode■ → Full / Network /Quick
Quick■
Network ID: Displays the network
identification code.
Frequency: Displays the frequency
for the channel.
Modulation: Displays available
modulation values.
Symbol Rate: Displays available
symbol rates.
Manual Store Scans for a channel manually and stores it in the TV’s
memory.
Digital Channel❑
Manual store for digital channels.
Channel■ : Set the Channel number using the ▲, ▼ or
number (0~9) buttons.
Frequency■: Set the frequency using the number buttons.
Bandwidth■ : Set the bandwidth using the ▲, ▼ or
number (0~9) buttons.
When it has finished, channels are updated in the channel
list.
Analogue Channel❑
Manual store for analogue channel.
Programme■(Programme number to be assigned to a
channel): Sets the programme number using the ▲, ▼
or number (0~9) buttons.
Colour System■ → Auto / PAL / SECAM / NTSC4.43:
Sets the colour system value using the ▲ or ▼ button.
Sound System■ → BG / DK / I/ L: Sets the sound
system value using the ▲ or ▼ button.
Channel■(When you know the number of the channel
to be stored): Press the ▲ or ▼ button to select C(Air
channel) or S (Cable channel). Press the ► button, then
press the ▲, ▼ or number (0~9) buttons to select the
required number.
You can also select the channel number directly by
pressing the number (0~9) buttons.
If there is abnormal sound or no sound, reselect
the sound standard required.
Search■(When you do not know the channel numbers):
Press the ▲ or ▼ button to start the search. The tuner
scans the frequency range until the first channel or the
channel that you selected is received on the screen.
Store■(When you store the channel and associated
programme number): Set to OK by pressing the
ENTER E button.
Cable Search Option
(depending on the
country)
Sets additional search options such as the frequency and
symbol rate for cable network searches.
Freq.Start■(Frequency Start): Set the start frequency
Freq.Stop■(Frequency Stop): Set the stop frequency
Modulation■: Displays available modulation values.
Symbol Rate■: Displays available symbol rates.
If a channel is locked using the■Child Lock function, the PIN
input window appears.
Digital Channel■is only available
in DTV mode.
Ch■annel mode
P(Programme mode):
When completing tuning, the
broadcasting stations in your
area have been assigned
to position numbers from
P00 to P99. You can select
a channel by entering the
position number in this
mode.
C(Air channel mode):
You can select a channel
by entering the assigned
number to each air
broadcasting station in this
mode.
S(Cable channel mode):
You can select a channel
by entering the assigned
number for each cable
channel in this mode.
If you want to stop Auto Store,■press the ENTER
E button.
The Stop Auto Store? message
will be displayed. Select Yes by
pressing the ◄ or ► button, then
press the ENTER E button.
[430(19)-UK]BN68-03043G-Eng.indb 19 2010-04-12 �� 9:35:57

20
English Using the Menus
Channel
Option Description
Now & Next Guide /
Full Guide /
Default Guide
The EPG (Electronic Programme Guide) information is
provided by the broadcasters. Programme entries may
appear blank or out of date as a result of the information
broadcast on a given channel. The display will dynamically
update as soon as new information becomes available.
Now & Next Guide❑
For the six channels indicated in the left-hand column,
displays the Current programme and the Next programme
information.
Full Guide❑
Displays the programme information as time ordered One
hour segments. Two hours of programme information is
displayed which may be scrolled forwards or backwards in
time.
Default Guide❑ → Now & Next Guide /
Full Guide
You can decide whether to display either the Now & Next
Guide or the Full Guide when the GUIDE button on the
remote control is pressed.
Using the Now & Next Guide / Full Guide
To... Then...
Watch a programme in the EPG list Select a programme by pressing the ▲, ▼, ◄, ► button.
Exit the guide Press the Blue button
If the next programme is selected, it is scheduled with the clock icon displayed. If the ENTEREbutton is pressed again, press the
◄, ► button to select Cancel Schedules, the scheduling is cancelled with the clock icon gone.
View programme information Select a programme of your choice by pressing the ▲, ▼, ◄, ► button. Then press the INFO button when the programme of your choice is highlighted.
The programme title is on the upper part of the screen centre.
Please click on INFO button for the detailed information. Channel Number, Running Time, Status Bar, Parental Level, Video Quality
Information (HD / SD), Sound Modes, Subtitle or Teletext, languages of Subtitle or Teletext and brief summary of the highlighted
programme are included on the detailed information. “...” will be appeared if the summary is long.
Toggle between the Now & Next Guide and Full
Guide Press the Red button repeatedly.
In Full Guide
Scrolls backwards quickly (24 hours).
Scrolls forwards quickly (24 hours).
Press the Green button repeatedly.
Press the Yellow button repeatedly.
You can also display the guide■menu simply by pressing the
GUIDE button. (To configure
the Default Guide, refer to the
descriptions.)
1 2 3
4 5 6
7 8
0
9
P
(Red)
Full Guide
Full Guide
DTV Cable 900 f tn 2:10 Tue 1 Jun
Freshmen On Campus
2:00 - 2:30
No Detailed Information
Today 16:00 - 17:00 17:00 - 18:00
Mint Extra
Loaded
Fresh 40 with Dynamite MC
The Distillery
Smash Hits! Sunday
1 f tn
2 ITV Play
3 Kerrang!
4 Kiss
5 oneword
6 Smash Hits!
▼
Street Hypn..
Kisstory
No Information
No Information
No Information
Freshmen O..
Watch
INFO
Information ■ Now / Next ■ +24 Hours ■ Exit
Now & Next Guide
Now & Next Guide
DTV Cable 900 f tn 2:10 Tue 1 Jun
Freshmen On Campus
2:00 - 2:30
No Detailed Information
Now Next
Mint Extra
Loaded
Fresh 40 with Dynamite MC
The Distillery
Smash Hits! Sunday
1 f tn
2 ITV Play
3 Kerrang!
4 Kiss
5 oneword
6 Smash Hits!
▼
Street Hypn..
Kisstory
No Information
No Information
No Information
Freshmen O..
Watch
INFO
Information ■ Full Guide ■ Exit
[430(19)-UK]BN68-03043G-Eng.indb 20 2010-04-12 �� 9:35:58
