Samsung LE26A451C1HX User manual

LCD-TV
Chassis : N55B
N56B
Model : LE26A451C1HX
LE32A451C1HX
LE37A451C1HX
LE40A451C1HX
SERVICEManual
TFT-LCD TV Contents
LE26A451C1HX/ LE32A451C1HX
LE37A451C1HX/ LE40A451C1HX
Refer to the service manual in the GSPN (see the rear cover) for the more information.
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Exploded View & Part List
6. Wiring Diagram

Contents
1. Precautions.............................................................................................................. 1-1
1-1. Safety Precautions ......................................................................................................... 1-1
1-2. Servicing Precautions..................................................................................................... 1-2
1-3. Electrostatically Sensitive Devices (ESD) Precautions .................................................. 1-2
1-4. Installation Precautions .................................................................................................. 1-3
2. Product specications............................................................................................ 2-1
2-1. Feature & Specications................................................................................................. 2-1
2-3. Spec Comparison to the Old Models.............................................................................. 2-7
2-4. Accessories .................................................................................................................... 2-8
3. Disassembly and Reassemble ............................................................................... 3-1
3-1. Disassembly ................................................................................................................... 3-1
4. Troubleshooting ...................................................................................................... 4-1
4-1. Troubleshooting .............................................................................................................. 4-1
4-2. Alignments and Adjustments ........................................................................................ 4-15
4-3. Factory Mode Adjustments ........................................................................................... 4-16
4-4. Hotel Interactive Mode.................................................................................................. 4-19
4-5. Stand Alone Hotel Mode............................................................................................... 4-20
4-6. White Balance - Calibration .......................................................................................... 4-21
4-7. White Ratio (Balance) Adjustment................................................................................ 4-23
4-8. HOW TO UPGRADE .................................................................................................... 4-24
5. Exploded View & Part List ...................................................................................... 5-1
5-1. LE26A451C1HX Exploded View..................................................................................... 5-1
5-2. LE32A451C1HX Exploded View..................................................................................... 5-3
5-3. LE37A451C1HX Exploded View..................................................................................... 5-5
5-4. LE40A451C1HX Exploded View..................................................................................... 5-7
5-5. LE26A451C1HX Parts List ............................................................................................. 5-9
5-6. LE32A451C1HX Parts List ........................................................................................... 5-36
5-7. LE37A451C1HX Parts List ........................................................................................... 5-63
5-8. LE40A451C1HX Parts List ........................................................................................... 5-90
6. Wiring Diagram........................................................................................................ 6-1
6-1. Wiring Diagram............................................................................................................... 6-1
6-2. Wiring Picture ................................................................................................................. 6-4
6-3. Connector Functions ...................................................................................................... 6-5
6-4. Cables ............................................................................................................................ 6-6

GSPN (Global Service Partner Network)
Area Web Site
North America http://service.samsungportal.com
Latin America http://latin.samsungportal.com
CIS http://cis.samsungportal.com
Europe http://europe.samsungportal.com
China http://china.samsungportal.com
Asia http://asia.samsungportal.com
Mideast & Africa http://mea.samsungportal.com
This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2008 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea
P/N: BN82-00453A-00

2-1
2. Product specications
2. Product specications
2-1. Feature & Specications
Model LE26A451C1HX
Feature
HD_READY(HD), RF, 2-HDMI, 1-Ext, 1-Component, 1-A/V, 1-S-video, 1- SCART, D-SUB
Brightness : 500cd/m2
Contrast Ratio : 8000:1
Response time : 6ms
Dynamic contrast, Super-PVA
PIP( in HDMI 1,2, Component 1, PC Mode and Sub picture is available only in TV, Ext, AV mode )
�
�
�
�
�
�
Specications
Item Description
LCD Panel TFT-LCD panel, RGB vertical stripe, SPVA mode, normaly black,
26-Inch viewable, 0.3635 (H) x 0.36375 (W) mm pixel pitch
Scanning Frequency Horizontal : 67.5 kHz (Automatic)
Vertical : 48 Hz ~ 63 Hz (Automatic)
Display Colors 16.7 million colors
Maximum resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω , internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock rate 310MHz
Active Display
Horizontal/Vertical 698.4(H) x 392.85(V) mm
AC power voltage & Frequency AC 110V ~ 240V, 50/60Hz
Power Consumption < 245 W
Dimensions
865.0 x 220.0 x 561.0 mm_with stand
865.0 x 79.0 x 449.8 mm_without stand
Set (W x D x H)
Weight (Set) 13.7 Kg
TV System Tuning Voltage / Frequency Synthesize (Refer to detailed Frequency Table)
System PAL - B/G, D/K, I / SECAM - D/K / SECAM L/L’
Sound STEREO
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Environmental Considerations - MAX Internal speaker Out : Right => 10W, Left => 10W
- BASS Control Range : -8 dB ~ + 8dB
- TREBLE Control Range : -8 dB ~ +8 dB
- Headphone Out : 10 mW MAX
- Output Frequency : RF : 80 Hz ~ 15 kHz
A/V : 80 Hz ~ 20 kHz

2-2
2. Product specications
Model LE32A451C1HX
Feature
HD_READY(HD), RF, 2-HDMI, 1-Ext, 1-Component, 1-A/V, 1-S-video,1- SCART, D-SUB
Brightness : 500cd/m2
Contrast Ratio : 8000:1
Response time : 6ms
Dynamic contrast, Super-PVA
PIP( in HDMI 1,2, Component 1, PC Mode and Sub picture is available only in TV, Ext, AV mode )
�
�
�
�
�
�
Specications
Item Description
LCD Panel TFT-LCD panel, RGB vertical stripe, SPVA mode, normaly black,
32-Inch viewable, 0.3635 (H) x 0.36375 (W) mm pixel pitch
Scanning Frequency Horizontal : 67.5 kHz (Automatic)
Vertical : 48 Hz ~ 63 Hz (Automatic)
Display Colors 16.7 million colors
Maximum resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω , internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock rate 310MHz
Active Display
Horizontal/Vertical 698.4(H) x 392.85(V) mm
AC power voltage & Frequency AC 110V ~ 240V, 50/60Hz
Power Consumption < 245 W
Dimensions
865.0 x 220.0 x 561.0 mm_with stand
865.0 x 79.0 x 449.8 mm_without stand
Set (W x D x H)
Weight (Set) 13.7 Kg
TV System Tuning Voltage / Frequency Synthesize (Refer to detailed Frequency Table)
System PAL - B/G, D/K, I / SECAM - D/K / SECAM L/L’
Sound STEREO
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Environmental Considerations - MAX Internal speaker Out : Right => 10W, Left => 10W
- BASS Control Range : -8 dB ~ + 8dB
- TREBLE Control Range : -8 dB ~ +8 dB
- Headphone Out : 10 mW MAX
- Output Frequency : RF : 80 Hz ~ 15 kHz
A/V : 80 Hz ~ 20 kHz

2-3
2. Product specications
Model LE37A451C1HX
Feature
HD_READY(HD), RF, 2-HDMI, 1-Ext, 1-Component, 1-A/V, 1-S-video,1- SCART, D-SUB
Brightness : 500cd/m2
Contrast Ratio : 8000:1
Response time : 6ms
Dynamic contrast, Super-PVA
PIP( in HDMI 1,2, Component 1, PC Mode and Sub picture is available only in TV, Ext, AV mode )
�
�
�
�
�
�
Specications
Item Description
LCD Panel TFT-LCD panel, RGB vertical stripe, SPVA mode, normaly black,
37-Inch viewable, 0.46125(H) x 0.46125(W) x 3 mm pixel pitch
Scanning Frequency Horizontal : 67.5 kHz (Automatic)
Vertical : 59.94 Hz (Automatic)
Display Colors 1.07 Billion
Maximum resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω , internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock rate 310MHz
Active Display
Horizontal/Vertical 885.6(H) x 498.15(V) mm
AC power voltage & Frequency AC 110V ~ 240V, 50/60Hz
Power Consumption < 245 W
Dimensions
43.08 x 11.41 x 26.59 inches (1094.3 x 289.9 x 675.4mm) with stand
43.08 x 4.04 x 23.9 inches (1094.3 x 102.8 x 607.3 mm) without stand
Set (W x D x H)
Weight (Set) Set : 20.2 kg(After installation of Stand)
Package : 25.1 kg (Stand : 3.2 Kg)
TV System Tuning Voltage / Frequency Synthesize (Refer to detailed Frequency Table)
System PAL - B/G, D/K, I / SECAM - D/K / SECAM L/L’
Sound STEREO
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Environmental Considerations - MAX Internal speaker Out : Right => 10W, Left => 10W
- BASS Control Range : -8 dB ~ + 8dB
- TREBLE Control Range : -8 dB ~ +8 dB
- Headphone Out : 10 mW MAX
- Output Frequency : RF : 80 Hz ~ 15 kHz
A/V : 80 Hz ~ 20 kHz

2-4
2. Product specications
Model LE40A451C1HX
Feature
HD_READY(HD), RF, 2-HDMI, 1-Ext, 1-Component, 1-A/V, 1-S-video,1- SCART, D-SUB
Brightness : 500cd/m2
Contrast Ratio : 8000:1
Response time : 6ms
Dynamic contrast, Super-PVA
PIP( in HDMI 1,2, Component 1, PC Mode and Sub picture is available only in TV, Ext, AV mode )
�
�
�
�
�
�
Specications
Item Description
LCD Panel TFT-LCD panel, RGB vertical stripe, SPVA mode, normaly black,
40-Inch viewable, 0.53025 (H) x 0.52025(W) pixel pitch
Scanning Frequency Horizontal : 67.5 kHz (Automatic)
Vertical : 59.94 Hz (Automatic)
Display Colors 1.07 Billion
Maximum resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω , internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock rate 310MHz
Active Display
Horizontal/Vertical 1018.08 (H) x 572.67 (V) mm
AC power voltage & Frequency AC 110V ~ 240V, 50/60Hz
Power Consumption < 245 W
Dimensions
43.08 x 11.41 x 26.59 inches (1094.3 x 289.9 x 675.4mm) with stand
43.08 x 4.04 x 23.9 inches (1094.3 x 102.8 x 607.3 mm) without stand
Set (W x D x H)
Weight (Set) Set : 20.2 kg(After installation of Stand)
Package : 25.1 kg (Stand : 3.2 Kg)
TV System Tuning Voltage / Frequency Synthesize (Refer to detailed Frequency Table)
System PAL - B/G, D/K, I / SECAM - D/K / SECAM L/L’
Sound STEREO
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Environmental Considerations - MAX Internal speaker Out : Right => 10W, Left => 10W
- BASS Control Range : -8 dB ~ + 8dB
- TREBLE Control Range : -8 dB ~ +8 dB
- Headphone Out : 10 mW MAX
- Output Frequency : RF : 80 Hz ~ 15 kHz
A/V : 80 Hz ~ 20 kHz

2-5
2. Product specications
CHANNEL FREQUENCY TABLE
OUTPUT FREQUENCY : ANALOG fv:45.75MHz, fs:41.25MHz DIGITAL Fc:44MHz
TUNING STEP SIZE : FIRST PLL 250KHz SECOND PLL 62.5KHz
1.
2.
OSD CH NO AIR CH NO CH NO CH NO
Air-DTV Air-NTSC BAND Cable STD BAND Cable HRC Cable IRC
1 1 A-8 72. 00 A-8 73. 25
2 2 57 55. 25 V-L 2 55. 25 V-L 2 54. 00 255. 25
3 3 63 61.25 V-L 3 61.25 V-L 3 60.00 3 61.25
4 4 69 67.25 V-L 4 67.25 V-L 4 66.00 4 67.25
5 5 79 77. 25 V-L 5 77. 25 V-L A-7 78. 00 A-7 79. 25
6 6 85 83.25 V-L 6 83.25 V-L A-6 84.00 A-6 85.25
7 7 177 175. 25 V-H 7 175. 25 V-H 7 174. 00 7175. 25
8 8 183 181.25 V-H 8 181.25 V-H 8 180.00 8 181.25
9 9 189 187.25 V-H 9 187.25 V-H 9 186.00 9 187.25
10 10 195 193.25 V-H 10 193.25 V-H 10 192.00 10 193.25
11 11 201 199.25 V-H 11 199.25 V-H 11 198.00 11 199.25
12 12 207 205.25 V-H 12 205.25 V-H 12 204.00 12 205.25
13 13 213 211.25 V-H 13 211.25 V-H 13 210.00 13 211.25
14 14 473 471. 25 UHF A 121. 25 MID A 120. 00 A121. 25
15 15 479 477.25 UHF B 127.25 MID B 126.00 B 127.25
16 16 485 483.25 UHF C 133.25 MID C 132.00 C 133.25
17 17 491 489.25 UHF D 139.25 MID D 138.00 D 139.25
18 18 497 495.25 UHF E 145.25 MID E 144.00 E 145.25
19 19 503 501.25 UHF F 151.25 MID F 150.00 F 151.25
20 20 509 507.25 UHF G 157.25 MID G 156.00 G 157.25
21 21 515 513.25 UHF H 163.25 MID H 162.00 H 163.25
22 22 521 519.25 UHF I 169.25 MID I 168.00 I 169.25
23 23 527 525.25 UHF J 217. 25 SUPER J 216. 00 J217. 25
24 24 533 531.25 UHF K 223.25 SUPER K 222.00 K 223.25
25 25 539 537.25 UHF L 229.25 SUPER L 228.00 L 229.25
26 26 545 543.25 UHF M 235.25 SUPER M 234.00 M 235.25
27 27 551 549.25 UHF N 241.25 SUPER N 240.00 N 241.25
28 28 557 555.25 UHF O 247.25 SUPER O 246.00 O 247.25
29 29 563 561.25 UHF P 253.25 SUPER P 252.00 P 253.25
30 30 569 567.25 UHF Q 259.25 SUPER Q 258.00 Q 259.25
31 31 575 573.25 UHF R 265.25 SUPER R 264.00 R 265.25
32 32 581 579.25 UHF S 271.25 SUPER S 270.00 S 271.25
33 33 587 585.25 UHF T 277.25 SUPER T 276.00 T 277.25
34 34 593 591.25 UHF U 283.25 SUPER U 282.00 U 283.25
35 35 599 597.25 UHF V 289.25 SUPER V 288.00 V 289.25
36 36 605 603.25 UHF W 295.25 SUPER W 294.00 W 295.25
37 37 611 609.25 UHF AA 301.25 HYPER AA 300.00 AA 301.25
38 38 617 615.25 UHF BB 307.25 HYPER BB 306.00 BB 307.25
39 39 623 621.25 UHF CC 313.25 HYPER CC 312.00 CC 313.25
40 40 629 627.25 UHF DD 319.25 HYPER DD 318.00 DD 319.25
41 41 635 633.25 UHF EE 325.25 HYPER EE 324.00 EE 325.25
42 42 641 639.25 UHF FF 331.25 HYPER FF 330.00 FF 331.25
43 43 647 645.25 UHF GG 337.25 HYPER GG 336.00 GG 337.25
44 44 653 651.25 UHF HH 343.25 HYPER HH 342.00 HH 343.25
45 45 659 657.25 UHF II 349.25 HYPER II 348.00 II 349.25
46 46 665 663.25 UHF JJ 355.25 HYPER JJ 354.00 JJ 355.25
47 47 671 669.25 UHF KK 361.25 HYPER KK 360.00 KK 361.25
48 48 677 675.25 UHF LL 367.25 HYPER LL 366.00 LL 367.25
49 49 683 681.25 UHF MM 373.25 HYPER MM 372.00 MM 373.25
50 50 689 687.25 UHF NN 379.25 HYPER NN 378.00 NN 379.25
51 51 695 693.25 UHF OO 385.25 HYPER OO 384.00 OO 385.25
52 52 701 699.25 UHF PP 391.25 HYPER PP 390.00 PP 391.25
53 53 707 705.25 UHF QQ 397.25 HYPER QQ 396.00 QQ 397.25
54 54 713 711.25 UHF RR 403.25 HYPER RR 402.00 RR 403.25
55 55 719 717.25 UHF SS 409.25 HYPER SS 408.00 SS 409.25
56 56 725 723.25 UHF TT 415.25 HYPER TT 414.00 TT 415.25
57 57 731 729.25 UHF UU 421.25 HYPER UU 420.00 UU 421.25
58 58 737 735.25 UHF VV 427.25 HYPER VV 426.00 VV 427.25
59 59 743 741.25 UHF WW 433.25 HYPER WW 432.00 WW 433.25
60 60 749 747.25 UHF XX 439.25 HYPER XX 438.00 XX 439.25
61 61 755 753.25 UHF YY 445.25 HYPER YY 444.00 YY 445.25
62 62 761 759.25 UHF ZZ 451.25 HYPER ZZ 450.00 ZZ 451.25
63 63 767 765.25 UHF AAA 457.25 HYPER AAA 456.00 AAA 457.25
64 64 773 771.25 UHF BBB 463.25 HYPER BBB 462.00 BBB 463.25
65 65 779 777.25 UHF CCC 469.25 ULTRA CCC 468.00 CCC 469.25
66 66 785 783.25 UHF DDD 475.25 ULTRA DDD 474.00 DDD 475.25
67 67 791 789.25 UHF EEE 481.25 ULTRA EEE 480.00 EEE 481.25
68 68 797 795.25 UHF FFF 487.25 ULTRA FFF 486.00 FFF 487.25
69 69 803 801.25 UHF GGG 493.25 ULTRA GGG 492.00 GGG 493.25

2-6
2. Product specications
OSD CH NO AIR CH NO CH NO CH NO
Air-DTV Air-NTSC BAND Cable STD BAND Cable HRC Cable IRC
70 70 HHH 499.25 ULTRA HHH 498.00 HHH 499.25
71 71 III 505.25 ULTRA III 504.00 III 505.25
72 72 JJJ 511.25 ULTRA JJJ 510.00 JJJ 511.25
73 73 KKK 517.25 ULTRA KKK 516.00 KKK 517.25
74 74 LLL 523.25 ULTRA LLL 522.00 LLL 523.25
75 75 MMM 529.25 ULTRA MMM 528.00 MMM 529.25
76 76 NNN 535.25 ULTRA NNN 534.00 NNN 535.25
77 77 OOO 541.25 ULTRA OOO 540.00 OOO 541.25
78 78 PPP 547.25 ULTRA PPP 546.00 PPP 547.25
79 79 79 553.25 ULTRA 79 552.00 79 553.25
80 80 80 559.25 ULTRA 80 558.00 80 559.25
81 81 81 565.25 ULTRA 81 564.00 81 565.25
82 82 82 571.25 ULTRA 82 570.00 82 571.25
83 83 83 577.25 ULTRA 83 576.00 83 577.25
84 84 84 583.25 ULTRA 84 582.00 84 583.25
85 85 85 589.25 ULTRA 85 588.00 85 589.25
86 86 86 595.25 ULTRA 86 594.00 86 595.25
87 87 87 601.25 ULTRA 87 600.00 87 601.25
88 88 88 607.25 ULTRA 88 606.00 88 607.25
89 89 89 613.25 ULTRA 89 612.00 89 613.25
90 90 90 619.25 ULTRA 90 618.00 90 619.25
91 91 91 625.25 ULTRA 91 624.00 91 625.25
92 92 92 631.25 ULTRA 92 630.00 92 631.25
93 93 93 637.25 ULTRA 93 636.00 93 637.25
94 94 94 643.25 ULTRA 94 642.00 94 643.25
95 95 A-5 91. 25 FM A-5 90. 00 A-5 91. 25
96 96 A-4 97.25 FM A-4 96.00 A-4 97.25
97 97 A-3 103.25 FM A-3 102.00 A-3 103.25
98 98 A-2 109.25 MID A-2 108.00 A-2 109.25
99 99 A-1 115.25 MID A-1 114.00 A-1 115.25
100 100 100 649. 25 ULTRA 100 648. 00 100 649. 25
101 101 101 655.25 ULTRA 101 654.00 101 655.25
102 102 102 661.25 ULTRA 102 660.00 102 661.25
103 103 103 667.25 ULTRA 103 666.00 103 667.25
104 104 104 673.25 ULTRA 104 672.00 104 673.25
105 105 105 679.25 ULTRA 105 678.00 105 679.25
106 106 106 685.25 ULTRA 106 684.00 106 685.25
107 107 107 691.25 ULTRA 107 690.00 107 691.25
108 108 108 697.25 ULTRA 108 696.00 108 697.25
109 109 109 703.25 ULTRA 109 702.00 109 703.25
110 110 110 709.25 ULTRA 110 708.00 110 709.25
111 111 111 715.25 ULTRA 111 714.00 111 715.25
112 112 112 721.25 ULTRA 112 720.00 112 721.25
113 113 113 727.25 ULTRA 113 726.00 113 727.25
114 114 114 733.25 ULTRA 114 732.00 114 733.25
115 115 115 739.25 ULTRA 115 738.00 115 739.25
116 116 116 745.25 ULTRA 116 744.00 116 745.25
. . . . . . . . .
. . . . . . . . .
125 125 125 799.25 ULTRA 125 798.00 125 799.25
. . . . . . . . .

2-7
2. Product speci cations
2-3. Spec Comparison to the Old Models
Model
Coral
(LE26A451C1HX/LE32A451C1HX/
LE37A451C1HX/LE40A451C1HX)
Jasmin (LA40S86B)
Design
Display Type LCD TV LCD TV
Built-in Tuner O O
Resolution 1366 x 768 1366 x 768
LCD Panel TFT LCD Panel 50Hz TFT LCD Panel 50Hz
Screen Size 26”/32”/37”/40” 40”
Picture ratio 16 : 9 16 : 9
Dimensions (W x H x D) 38.97 x 11.81 x 27.33 inches_with stand
38.97 x 3.22 x 25.22 inches_without stand
42.66 x 11.81 x 27.16 inches_with stand
42.66 x 3.73 x 25.13 inches_without stand
Brightness 450cd/m2500cd/m2
Contrast Ratio 8000:1 or 2000:1 8000:1
Picture Enhacer DNIe (FBE3) DNIe (FBE2)
Equalizer O O
Auto Motion Plus 100Hz X X
Surround Sound 3 Way SRS TruSurround Dolby Digital 2 Way SRS TruSurround Dolby Digital
Speaker Output 26”(5W + 5W )
32”/37”/40”( 10W + 10W ) 10W + 10W
Antenna 1 1

2-8
2. Product specications
2-4. Accessories
Product Description Code. No Remark
Remote Control & Batteries
(AAA x 2) BN59-00685A
Samsung Electronics
Service center
Power Cord 3903-000145
Cover-Bottom BN63-04269B
Owner’s Instructions BN68-01569A
Cleaning Cloth BN63-01798A
Warranty Card / Registration
Card / Safety Guide Manual
(Not available in all locations)
6801-001011
Stand Screw x 4 6002-001294
Stand BN90-01511A

5-1
5. Exploded View & Part List
5. Exploded View & Part List
5-1. LE26A451C1HX Exploded View
T0003
M0115
M0027
M0215
T0447
M0014
M0013
M0146
M0254
T0175

5-2
5. Exploded View & Part List
5-1-2. LE26A451C1HX Parts List
Location No. Code No. Description & Specication Q’ty S.A/S.N.A Remark
T0003 BN96-06783U ASSY COVER P-FRONT;26L450,EO(HOTEL),ABS+ 1 S.A
M0215 BN07-00528A LCD-PANEL;LTF260AP01 1 S.A
T0175 BN96-06822C ASSY SPEAKER P;8ohm,CORAL,LCD 26”,5W,4pi 1 S.A
T0447 BN96-06957D ASSY BRACKET P-PANEL;26L450,AMLCD,HOTEL, 1 S.N.A
M0014 BN94-01985A ASSY PCB MAIN;LE32A451C1HXXU 1 S.A
M0115 BN61-02947A BRACKET-STAND LINK;JASMINE 32”,SECC,T1.6 1 S.A
T0101 BN61-03346A BRACKET-WALL;LCD TV,SECC,T1.2 4 S.N.A
M0013 BN96-07209C ASSY COVER P-REAR;26L450,EO(HOTEL),HIPS, 1 S.A
M0027 BN96-06463F ASSY STAND P-BASE;22,26L450,ABS+PMMA,HB, 1 S.A

5-3
5. Exploded View & Part List
5-2. LE32A451C1HX Exploded View
T0003
M0215
M0146
T0447
M0027
M0115
T0175
M0254
M0014
M0013

5-4
5. Exploded View & Part List
5-2-1. LE32A451C1HX Parts List
Location No. Code No. Description & Specication Q’ty S.A/S.N.A Remark
T0003 BN96-06784Z ASSY COVER P-FRONT;32L450,EO(HOTEL),ABS+ 1 S.A
M0215 BN07-00511A LCD-PANEL;T315XW02 VL 1 S.A
T0447 BN96-06958C ASSY BRACKET P-PANEL;32L450,SECC,T1.0,CO 1 S.N.A
M0027 BN96-07211A ASSY STAND P-BASE;32L450,W/W,ABS+PMMA,HB 1 S.A
M0115 BN61-02947A BRACKET-STAND LINK;46M7,SECC,T1.6 1 S.N.A
M0146 BN61-03678A BRACKET-PANEL TOP;32L450,GPSP,T1.0 1 S.N.A
T0175 BN96-06818E ASSY SPEAKER P;8ohm,CORAL,L450,10W,350/1 1 S.A
M0014 BN94-01985A ASSY PCB MAIN;LE32A451C1HXXU 1 S.A
M0254 BN61-03699G HOLDER-SIDE AV;32L450,SO(HOTEL),HIPS,V0, 1 S.N.A
M0013 BN96-07208E ASSY COVER P-REAR;32L450,EO(HOTEL),HIPS, 1 S.A

5-5
5. Exploded View & Part List
5-3. LE37A451C1HX Exploded View
M0027
M0014
M0013
T0175
T0003
M0215
M0146
T0447
M0125
T0764
M0115
M0254

5-6
5. Exploded View & Part List
5-3-1. LE37A451C1HX Parts List
Location No. Code No. Description & Specication Q’ty S.A/S.N.A Remark
T0003 BN96-06785R ASSY COVER P-FRONT;37L450,EO(HOTEL),ABS+ 1 S.A
T0175 BN96-06818A ASSY SPEAKER P;8ohm,CORAL,LCD,PDP,10W,4p 1 S.A
M0215 BN07-00446A LCD-PANEL;CLAA370WA03SC 1 S.A
T0447 BN96-06959C ASSY BRACKET P-PANEL;37L450,CPT,AUO,,SEC 1 S.N.A
M0027 BN96-06259A ASSY STAND P-BASE;37,40L450,,ABS+PMMA,HB 1 S.A
M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.N.A
M0146 BN61-03684B BRACKET-PANEL TOP;L450 37INCH,SECC,T1.0 1 S.N.A
M0014 BN94-01848D ASSY PCB MAIN;37 INCH, EUROPE,CORAL HOTE 1 S.A
M0013 BN96-07207C ASSY COVER P-REAR;37L450,EO(HOTEL),HIPS, 1 S.A

5-7
5. Exploded View & Part List
5-4. LE40A451C1HX Exploded View
T0003
M0027
M0115
T0447
M0215
T0175
T0174
T0275
M0014
M0174 M0013
M0146

5-8
5. Exploded View & Part List
5-4-2. LE40A451C1HX Parts List
Location No. Code No. Description & Specication Q’ty S.A/S.N.A Remark
T0003 BN96-07886D ASSY COVER P-FRONT;40L450,EO(HOTEL),ABS+ 1 S.A
M0215 BN07-00523A LCD-PANEL;LTF400AA01 1 S.A
T0175 BN96-06818D ASSY SPEAKER P;8ohm,CORAL,L450,10W,400/6 1 S.A
T0447 BN96-06960A ASSY BRACKET P-PANEL;40A450C,SECC,T1.0,C 1 S.N.A
M0014 BN94-01986A ASSY PCB MAIN;LE40A451C1HX* 1 S.A
M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.N.A
T0101 BN61-03348A BRACKET-WALL;LCD TV 32,SECC T1.2,-,-,-,- 2 S.N.A
M0027 BN96-06259A ASSY STAND P-BASE;37,40L450,,ABS+PMMA,HB 1 S.A

5-9
5. Exploded View & Part List
5-5. LE26A451C1HX Parts List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
0 LE26A451C1HXXU LE26A451C1H,N55B/26AC1-GCR,26,LCD-TV,UNI 0 S.A
S.A
0.1 M0001 BN90-01500S ASSY COVER FRONT;26L450,EO(HOTEL) 1 S.N.A
..2 T0003 BN96-06783U ASSY COVER P-FRONT;26L450,EO(HOTEL),ABS+ 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.A
...3 T0069 AA60-00171N SPACER-FELT;61L3,FELT,620,T0.5,10 2 S.N.A
...3 M0279 AA63-01637A FELT;50P9,FELT,0.5,10,80 1 S.N.A
...3 BN61-03261B BOSS-TAPE;Tulip,ACRYL,T1.1,W20mm,GRAY,TA 0.8 S.N.A
...3 BN61-03676B HOLDER-BOSS BOTTOM;26L450,EO,HIPS,HB,-,- 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.559 S.N.A
...3 M0112 BN63-04168L COVER-FRONT;26L450,EO(HOTEL),ABS+PMMA,-, 1 S.N.A
...3 T0059 BN64-00379A INDICATOR LED;ROME-II,23,PC,CLEAR 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,VIOLET,DIFFUSER( 1 S.N.A
...3 T0022 BN64-00755A KNOB-CONTROL;32L450,ABS,V0,BK07 1 S.N.A
...3 BN64-00757A DECORATION-BOTTOM;L450 26INCH,PC,-,-,-,- 1 S.N.A
...3 M0145 BN96-07269A ASSY BOARD P-FUNCTION;LN40A450C1D,CT5000 1 S.A
...3 M0146 BN96-07640C ASSY BOARD P-POWER & IR;L450 US HOTEL TV 1 S.A
...3 T0069 BP60-00015Z SPACER-FELT;26L450,FELT,L360,BLK,T0.5,W1 2 S.N.A
..2 T0175 BN96-06822C ASSY SPEAKER P;16ohm,CORAL,LCD 26”,5W,4p 1 S.A
0.1 M0216 BN90-01511A ASSY STAND;26L450,UO,,, 1 S.N.A
..2 T0524 6902-000561 BAG PE;HDPE/NITRON,T0.015+T0.5,W500,L400 1 S.N.A
..2 M0027 BN96-06463F ASSY STAND P-BASE;22,26L450,ABS+PMMA,HB, 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 4 S.A
...3 BN61-02954A BRACKET-STAND BOTTOM;23,26 BORDEAUX PLUS 1 S.N.A
...3 T0920 BN61-03680C GUIDE-STAND;22,26L450,ABS,V0(NT),BLK 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 S.N.A
...3 T0004 BN63-03122A COVER-STAND BASE;23,26R81,ABS+PMMA,-,-,- 1 S.N.A
...3 M0126 BN73-00052C RUBBER-FOOT;LCD TV,CR RUBBER,T2.0 DIA19, 4 S.N.A
0.1 M0002 BN90-01578C ASSY COVER REAR;26L450,EO(HOTEL) 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 11 S.A
..2 M0013 BN96-07209C ASSY COVER P-REAR;26L450,EO(HOTEL),HIPS, 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.A
...3 T0101 BN61-03346A BRACKET-WALL;LCD TV,gpsp,T1.2 4 S.N.A
...3 M0006 BN63-04244C COVER-REAR;26L450,EO(HOTEL),HIPS,-,-,-,H 1 S.N.A
...3 T0071 BN64-00796A INLAY-TERMINAL;-,PS SHEET,T0.3,-,-,BLK,H 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,-,-,BLK,- 1 S.N.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 1 S.A
0.1 BN91-02199A ASSY LCD-AMLCD;BN07-00528A,AMLCD,PVA 72% 1 S.N.A
..2 M0215 BN07-00528A LCD-PANEL;LTF260AP01 1 S.A
0.1 M0112 BN91-02344N ASSY SHIELD;SPE-LE26A451C1HX* 1 S.N.A
..2 BN81-01805A A/S-TAPE FILAMENT;ELMATIT,T0.1,W49,L1200 0.28 S.N.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 4 S.A
