Contents
1. Precautions.............................................................................................................. 1-1
1-1. Safety Precautions ......................................................................................................... 1-1
1-2. Servicing Precautions..................................................................................................... 1-2
1-3. Electrostatically Sensitive Devices (ESD) Precautions .................................................. 1-2
1-4. Installation Precautions .................................................................................................. 1-3
2. Product specications............................................................................................ 2-1
2-1. Feature & Specications................................................................................................. 2-1
2-2. New Features explanation.............................................................................................. 2-7
2-3. Specication Comparison to Old Models........................................................................ 2-8
2-4. Accessories .................................................................................................................... 2-9
3. Disassembly and Reassembly ............................................................................... 3-1
3-1. Disassembly and Reassembly ....................................................................................... 3-1
4. Troubleshooting ...................................................................................................... 4-1
4-1. Troubleshooting .............................................................................................................. 4-1
4-2. Alignments and Adjustments ........................................................................................ 4-25
4-3. Factory Mode Adjustments ........................................................................................... 4-26
4-4. White Balance - Calibration .......................................................................................... 4-38
4-5. White Ratio (Balance) Adjustment................................................................................ 4-38
4-6. Servicing Information.................................................................................................... 4-39
4-7. HOW TO UPGRADE WITH JIG ................................................................................... 4-40
4-8. PCB diagram ................................................................................................................ 4-42
5. Exploded View & Part List ...................................................................................... 5-1
5-1. LE26B450C4H / LE26B457C6H Exploded View............................................................ 5-1
5-2. LE32B450C4H / LE32B457C6H Exploded View............................................................ 5-3
5-3. LE37B457C6H Exploded View....................................................................................... 5-5
5-4. LE26B45*C4H Parts List ................................................................................................ 5-9
5-5. LE32B45*C4H Parts List .............................................................................................. 5-32
5-6. LE37B45*C4H Parts List .............................................................................................. 5-55
6. Wiring Diagram........................................................................................................ 6-1
6-1. Wiring Diagram 26”/32”/37” ............................................................................................ 6-1
6-2. Connector Functions ...................................................................................................... 6-5
6-3. Cables ............................................................................................................................ 6-5
